A18FL
Original instructions
2
p. 4 p. 5
Battery port
Carrying handle
Base
p. 6
p. 5
LED panel
Light switch
Head adjustment knob
Rafter hooks
Secondary handle
Wall mounting holes
1/4" tripod mount
Battery
3
75-100 %
50-75 %
25-50 %
0-25 %
1
2
4
2s
2s
OFF
1
2
1 2
3
4
ON
OFF
ON
265°
2
1
2500 Lm
800 Lm
1200 Lm
5
1
2
1/4”
57.25 mm
5 mm
6
TECHNICAL DATA A18FL
Type LED Flood Light
Wattage 17.7 W
Battery voltage 18 V
Run time with one fully charged battery (Li-ion 4.0 Ah) Up to 4 hrs on low mode
Luminous ux (High brightness level / Medium brightness levl / low brightness level) Up to 2500/ 1200 / 800 lm
Colour rendering index (CRI) ≥70
Colour temperature 5000 K
Overall dimension of oodlight 178 x 177 x 231 mm
Maximum projected area of the oodlight 0.04 m²
Maximum light coverage (irradiation) area 31.6 m²
Maximum mounting height 1.83 m
Weight - excluding battery pack 0.97 kg
COMPATIBLE BATTERY PACKS (NOT INCLUDED)
L1820R
L1820S
A18FB2
L1825R
L1830R-X5
A18B4
L1840R
A18FB4
L1850R
A18FB5
A18OB6
L1860R
L1860R-X5
L1890R
Use AEG 18V battery and charger only
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with the product.
Failure to follow all instructions listed in this user manual may result
in electric shock, re, and/or serious injury.
Save all warnings and instructions for future reference.
FLOODLIGHT SAFETY WARNINGS
The light source contained in this luminaire shall only be replaced
by the manufacturer, his service agent, or a similar qualied
person.
Do not direct the light beam at persons or animals, and do not stare
into the light beam yourself (not even from a distance). Staring into
the light beam may result in serious injury or vision loss.
Use the product only with the recommended battery pack and
charger. Any attempt to use another battery pack will cause
damage to the product and could possibly explode, cause a re, or
cause personal injury.
Do not disassemble the product.
If wrapped or in contact with fabrics, the lens can produce sufcient
heat to melt some fabrics. To avoid serious personal injury, never
allow the lens to come in contact with anything.
Do not place the product or battery pack near re or heat. This will
reduce the risk of explosion and possible injury.
To reduce the risk of injury or damage, avoid contact with any hot
surface.
Do not store the product in a damp or wet location, or in a location
where the temperature may reach or exceed 40°C (104°F). For
example, inside sheds, vehicles, or metal buildings in the summer.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of re, personal injury, and
product damage due to a short circuit, never immerse your tool,
battery pack, or charger in uid or allow uid to ow inside them.
Corrosive or conductive uids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG distributors offer to retrieve old batteries to
protect our environment.
Battery packs that have not been used for some time should be
recharged before use.
For an optimum lifetime, the battery packs have to be fully charged
after use.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C and
away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
Battery pack protection
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life.
Under extreme stress, the battery electronics turn off the product
automatically. To restart, turn the product off and then on again.
If the product does not start up again, the battery pack may have
discharged completely. Recharge the battery pack.
Transporting lithium batteries
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national, and international provisions and regulations.
• Batteries can be transported by road without further requirement.
• Commercial transport of lithium-ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
• Ensure that the battery contact terminals are protected and
insulated to prevent short circuit.
• Ensure that the battery pack is secured against movement within
the packaging.
• Do not transport batteries that are cracked or leaking.
• Check with the forwarding company for further advice.
SPECIFIED CONDITIONS OF USE
The LED ood light is intended for general illumination. Do not use
the product in wet conditions.
Do not use the product for any other purpose.
MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to various types of commercial solvents and may
be damaged by their use. Use clean cloths to remove dirt, carbon
dust, etc.
Use only AEG accessories and spare parts. Should components
that have not been described need to be replaced, contact one
of our AEG service agents (see our list of guarantee/service
addresses).
If needed, an exploded view of the product can be ordered. State
the product type and the serial number printed on the label, and
order the drawing at your local service agents or directly at:
7
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Read the instructions carefully before starting the
product.
Do not stare at the operating light source.
To reduce the risk of injury or damage, avoid contact
with any hot surface.
Class III protection
For indoor use only.
Do not dispose of electric tools, batteries/rechargeable
batteries together with household waste material.
Electric tools and batteries that have reached the end
of their life must be collected separately and returned
to an environmentally compatible recycling facility.
Check with your local authority or retailer for recycling
advice and collection point.
V
Voltage
Direct current
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
01924900301Q-01A
