Important Safety Instructions
The following symbols and labels are used throughout this
manual to indicate immediate or potential safety hazards. It is
the owner’s and installer’s responsibility to read and comply
with all safety information and instructions accompanying these
symbols. Failure to heed safety information increases the risk
of personal injury, property damage, and/or product damage.
Only personnel that have been trained to install, adjust, service or
repair (hereinafter, “service”) the equipment specified in this manual
should service the equipment. The manufacturer will not be
responsible for any injury or property damage arising from improper
service or service procedures. If you service this unit, you assume
responsibility for any injury or property damage which may result. In
addition, in jurisdictions that require one or more licenses to service
the equipment specified in this manual, only licensed personnel
should service the equipment. Improper installation, adjustment,
servicing or repair of the equipment specified in this manual, or
attempting to install, adjust, service or repair the equipment specified
in this manual without proper training may result in product damage,
property damage, personal injury or death.
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
HIGH VOLTAGE!
Failure to do so may cause property damage,
Disconnect ALL power before servicing.
Multiple power sources may be present.
personal injury or death.
Scroll equipped units should never be used to evacuate
the air conditioning system. Vacuums this low can cause
internal electrical arcing resulting in a damaged or failed
compressor.
CAUTION
CONDENSING UNIT
HEAT PUMP
INSTALLATION & SERVICE REFERENCE
© 2016-2019 Goodman Manufacturing Company, L.P.
19001 Kermier Rd., Waller, TX 77484
www.goodmanmfg.com
P/N: IOG-4002C Date: October 2019
Shipping Inspection
Always keep the unit upright; laying the unit on its side or top
may cause equipment damage. Shipping damage, and subse-
quent investigation is the responsibility of the carrier. Verify
the model number, specifications, electrical characteristics,
and accessories are correct prior to installation. The distribu-
tor or manufacturer will not accept claims from dealers for trans-
portation damage or installation of incorrectly shipped units.
Codes & Regulations
This product is designed and manufactured to comply with
national codes. Installation in accordance with such codes and/
or prevailing local codes/regulations is the responsibility of the
installer. The manufacturer assumes no responsibility for equip-
ment installed in violation of any codes or regulations. Rated
performance is achieved after 20 hours of operation. Rated per-
formance is delivered at the specified airflow. See outdoor unit
specification sheet for split system models or product specifi-
cation sheet for packaged and light commercial models. Speci-
fication sheets can be found at www.goodmanmfg.com for
Goodman
®
brand products or www.amana-hac.com for Amana
®
brand products. Within either website, please select the resi-
dential or commercial products menu and then select the
submenu for the type of product to be installed, such as air
conditioners or heat pumps, to access a list of product pages
that each contain links to that model’s specification sheet.
The United States Environmental Protection Agency (EPA)
has issued various regulations regarding the introduc-
tion and disposal of refrigerants. Failure to follow these
regulations may harm the environment and can lead to
the imposition of substantial fines. Should you have any
questions please contact the local office of the EPA.
If replacing a condensing unit or air handler, the system must
be manufacturer approved and Air Conditioning, Heating and
Refrigeration Institute (AHRI) matched. NOTE: Installation of
unmatched systems is not allowed.
Outdoor units are approved for operation above 55°F in cooling
mode. Operation below 55°F requires the use of an approved
low ambient kit. Note: LAKT01 Low ambient kit cannot be used
with outdoor units containing ECM motors.
Damage to the unit caused by operating the unit in a structure
that is not complete (either as part of new construction or reno-
vation) is not covered under the warranty.
2
Installation Clearances
Special consideration must be given to location of the con-
densing unit(s) in regard to structures, obstructions, other units,
and any/all other factors that may interfere with air circulation.
Where possible, the top of the unit should be completely unob-
structed; however, if vertical conditions require placement be-
neath an obstruction there should be a minimum of 60
inches between the top of the unit and the obstruction(s).
The specified dimensions meet requirements for air circulation
only. Consult all appropriate regulatory codes prior to deter-
mining final clearances.
Another important consideration in selecting a location for the
unit(s) is the angle to obstructions. Either side adjacent the
valves can be placed toward the structure provided the side
away from the structure maintains minimum service clearance.
Corner installations are strongly discouraged.
OK!
OK!
AA AAA
A
CC
C
C
OK!
OK!
OK!
OK!
NOT
RECOMMENDED
AA
AA
AA
AA
AA
B B B
B
Model Type A B C AA
Residential
10" 10" 18" 20"
Light Commercial
12" 12" 18" 24"
Minimum Airflow Clearance
This unit can be located at ground floor level or on flat roofs. At
ground floor level, the unit must be on a solid, level foundation
that will not shift or settle. To reduce the possibility of sound
transmission, the foundation slab should not be in contact with
or be an integral part of the building foundation. Ensure the
foundation is sufficient to support the unit. A concrete slab
raised above ground level provides a suitable base.
Rooftop Installations
If it is necessary to install this unit on a roof structure, ensure
the roof structure can support the weight and that proper con-
sideration is given to the weather-tight integrity of the roof. Since
the unit can vibrate during operation, sound vibration transmis-
sion should be considered when installing the unit. Vibration
absorbing pads or springs can be installed between the con-
densing unit legs or frame and the roof mounting assembly to
reduce noise vibration.
NOTE: These units require special location consideration in
areas of heavy snow accumulation and/or areas with prolonged
continuous subfreezing temperatures. Heat pump unit bases
have cutouts under the outdoor coil that permit drainage of
frost accumulation. Situate the unit to permit free unobstructed
drainage of the defrost water and ice.
In more severe weather locations, it is recommended that the
unit be elevated to allow unobstructed drainage and air flow.
The following elevation minimums are recommended:
Design Temperature Suggested Minimum Elevation
+15° and above 2 1/2"
-5° to +14° 8"
below -5° 12"
Safe Refrigerant Handling
While these items will not cover every conceivable situation,
they should serve as a useful guide.
To avoid possible injury, explosion or death, practice
safe handling of refrigerants.
WARNING
Refrigerants are heavier than air. They can "push out"
the oxygen in your lungs or in any enclosed space. To
avoid possible difficulty in breathing or death:
Never purge refrigerant into an enclosed room or
space. By law, all refrigerants must be reclaimed.
If an indoor leak is suspected, thoroughly ventilate the
area before beginning work.
• Liquid refrigerant can be very cold. To avoid possible
frostbite or blindness, avoid contact and wear gloves
and goggles. If liquid refrigerant does contact your
skin or eyes, seek medical help immediately.
• Always follow EPA regulations. Never burn refrigerant,
as poisonous gas will be produced.
•
•
To avoid possible explosion:
•
Never apply flame or steam to a refrigerant cylinder.
If you must heat a cylinder for faster charging,
partially immerse it in warm water.
•
Never fill a cylinder more than 80% full of liquid re-
frigerant.
• Never add anything other than R-22 to an R-22 cy-
linder or R-410A to an R-410A cylinder. The service
equipment used must be listed or certified for the
type of refrigerant used.
• Store cylinders in a cool, dry place. Never use a cy-
linder as a platform or a roller.
WARNING
3
To avoid possible explosion, use only returnable (not
disposable) service cylinders when removing refrigerant
from a system.
• Ensure the cylinder is free of damage which could lead to
a leak or explosion.
• Ensure the hydrostatic test date does not exceed 5 years.
• Ensure the pressure rating meets or exceeds 400 PSIG.
When in doubt, do not use cylinder.
Refrigerant Lines
The compressor POE oil for R-410A units is extremely
susceptible to moisture absorption and could cause
compressor failure. Do not leave system open to atmos-
phere any longer than necessary for installation.
CAUTION
Use only refrigerant grade (dehydrated and sealed) copper tub-
ing to connect the condensing unit with the indoor evaporator.
After cutting the tubing, install plugs to keep refrigerant tubing
clean and dry prior to and during installation. Tubing should
always be cut square keeping ends round and free from burrs.
Clean the tubing to prevent contamination.
Do NOT let refrigerant lines come in direct contact with plumb-
ing, ductwork, floor joists, wall studs, floors, and walls. When
running refrigerant lines through a foundation or wall, openings
should allow for sound and vibration absorbing material to be
placed or installed between tubing and foundation. Any gap
between foundation or wall and refrigerant lines should be filled
with a pliable silicon-based caulk, RTV or a vibration damping
material. Avoid suspending refrigerant tubing from joists and
studs with rigid wire or straps that would come in contact with
the tubing. Use an insulated or suspension type hanger. Keep
both lines separate and always insulate the suction line.
These sizes are recommended for line lengths of 79 feet or
less to obtain optimum performance. For alternate line siz-
ing options or runs of more than 79 feet, refer to TP-107
Long Line Set Application R-410A, or contact your distribu-
tor for assistance.
Cond
Unit
Tons Suct Liq Suct Liq Suct Liq
1 1/2 5/8 1/4 3/4 3/8 3/4 3/8
2 5/8 1/4 3/4 3/8 3/4 3/8
2 1/2 5/8 1/4 3/4 3/8 7/8 3/8
3 3/4 3/8 7/8 3/8 1 1/8 3/8
3 1/2 7/8 3/8 1 1/8 3/8 1 1/8 3/8
4 7/8 3/8 1 1/8 3/8 1 1/8 3/8
5 7/8 3/8 1 1/8 3/8 1 1/8 3/8
Line Diameter (In. OD)
RECOMMENDED INTERCONNECTING TUBING (Ft)
0-24 25-49 50-79*
* Lines greater than 79 feet in length or vertical elevation changes mor
e
than 50 feet refer to the TP-107 R-410A Long Line Set Application
Guidelines or contact your distributor for assistance.
Insulation is necessary to prevent condensation from forming
and dropping from the suction line. Armflex (or satisfactory
equivalent) with 3/8” min. wall thickness is recommended. In
severe conditions (hot, high humidity areas) 1/2” insulation may
be required. Insulation must be installed in a manner which
protects tubing from damage and contamination.
Existing Line Sets
Where possible, drain as much residual compressor oil from
existing systems, lines, and traps; pay close attention to low
areas where oil may collect. Use of an approved flushing agent
is recommended followed by a nitrogen purge to remove any
remaining flushing agent from the lines or indoor coil. Replace-
ment of indoor coil is recommended.
NOTE: If using existing indoor coil and changing refrigerant
types, ensure the indoor coil and metering device are compat-
ible with the type of refrigerant being used. If new indoor coil is
required check spec sheet or AHRI for approved coil. If system
is being replaced due to compressor electrical failure, assume
acid is in system. Refer to Service Procedure S-115 Compres-
sor Burnout in service manual for clean-up procedure.
Burying Refrigerant Lines
If burying refrigerant lines can not be avoided, use the following
checklist.
1. Insulate liquid and suction lines separately.
2. Enclose all underground portions of the refrigerant lines
in waterproof material (conduit or pipe) sealing the ends
where tubing enters/exits the enclosure.
3. If the lines must pass under or through a concrete slab,
ensure lines are adequately protected and sealed.
4
Refrigerant Line Connections
IMPORTANT
To avoid overheating the service valve, TXV valve, or filter
drier while brazing, wrap the component with a wet rag, or
use a thermal heat trap compound. Be sure to follow the
manufacturer’s instruction when using the heat trap
compound. Note: Remove Schrader valves from service
valves before brazing tubes to the valves. Use a brazing
alloy of 2% minimum silver content. Do not use flux.
Torch heat required to braze tubes of various sizes is
proportional to the size of the tube. Tubes of smaller size
require less heat to bring the tube to brazing temperature
before adding brazing alloy. Applying too much heat to
any tube can melt the tube. Service personnel must use
the appropriate heat level for the size of the tube being
brazed. Note: The use of a heat shield when brazing is
recommended to avoid burning the serial plate or the finish
on the unit.
1. The ends of the refrigerant lines must be cut square, de-
burred, cleaned, and be round and free from nicks or dents.
Any other condition increases the chance of a refrigerant
leak.
2. “Sweep” the refrigerant line with nitrogen or inert gas dur-
ing brazing to prevent the formation of copper-oxide in-
side the refrigerant lines. The POE oils used in R-410A
applications will clean any copper-oxide present from the
inside of the refrigerant lines and spread it throughout the
system. This may cause a blockage or failure of the me-
tering device.
3. After brazing, quench the joints with water or a wet cloth
to prevent overheating of the service valve.
4. Ensure the filter drier paint finish is intact after brazing. If
the paint of the steel filter drier has been burned or chipped,
repaint or treat with a rust preventative. This is especially
important on suction line filter driers which are continu-
ally wet when the unit is operating.
NOTE: Be careful not to kink or dent refrigerant lines. Kinked
or dented lines will cause poor performance or compressor
damage.
Do NOT make final refrigerant line connection until plugs are
removed from refrigerant tubing.
NOTE: Before brazing, verify indoor piston size by checking
the piston kit chart packaged with indoor unit.
Leak Testing (Nitrogen or Nitrogen-Traced)
To avoid the risk of fire or explosion, never use
oxygen, high pressure air or flammable gases for leak
testing of a refrigeration system.
WARNING
To avoid possible explosion, the line from the
nitrogen cylinder must include a pressure regulator
and a pressure relief valve. The pressure relief valve
must be set to open at no more than 150 psig.
WARNING
Pressure test the system using dry nitrogen and soapy water
to locate leaks. If you wish to use a leak detector, charge the
system to 10 psi using the appropriate refrigerant then use
nitrogen to finish charging the system to working pressure then
apply the detector to suspect areas. If leaks are found, repair
them. After repair, repeat the pressure test. If no leaks exist,
proceed to system evacuation.
System Evacuation
Condensing unit liquid and suction valves are closed to contain
the charge within the unit. The unit is shipped with the valve
stems closed and caps installed. Do not open valves until
the system is evacuated.
REFRIGERANT UNDER PRESSURE!
Failure to follow proper procedures may cause
property damage, personal injury or death.
NOTE: Scroll compressors should never be used to evacuate
or pump down a heat pump or air conditioning system.
Prolonged operation at suction pressures less than 20
psig for more than 5 seconds will result in overheating of
the scrolls and permanent damage to the scroll tips, drive
bearings and internal seal.
CAUTION
1. Connect the vacuum pump with 250 micron capability to
the service valves.
2. Evacuate the system to 250 microns or less using suc-
tion and liquid service valves. Using both valves is nec-
essary as some compressors create a mechanical seal
separating the sides of the system.
3. Close pump valve and hold vacuum for 10 minutes. Typi-
cally pressure will rise during this period.
5
5000
4500
4000
3500
3000
2500
2000
1500
1000
500
0 1 2 3 4 5 6 7 8 9
10
LEAK(S)
PRESENT
MINUTES
V
ACUUM
IN
MICRONS
CONDENSIBLES OR SMALL
LEAK PRESENT
NO LEAKS
NO CONDENSIBLES
• If the pressure rises to 1000 microns or less and remains
steady the system is considered leak-free; proceed to
startup.
• If pressure rises above 1000 microns but holds steady
below 2000 microns, moisture and/or noncondensibles
may be present or the system may have a small leak.
Return to step 2: If the same result is encountered check
for leaks as previously indicated and repair as necessary
then repeat evacuation.
• If pressure rises above 2000 microns, a leak is present.
Check for leaks as previously indicated and repair as nec-
essary then repeat evacuation.
Electrical Connections
HIGH VOLTAGE!
Disconnect ALL power before servicing.
Multiple power sources may be present.
Failure to do so may cause property damage,
personal injury or death due to electric shock.
Wiring must conform with NEC or CEC and all
local codes. Undersized wires could cause
poor equipment performance, equipment damage
or fire.
WARNING
To avoid the risk of fire or equipment damage, use
copper conductors.
WARNING
NOTICE
Units with reciprocating or rotary compressors and
non-bleed TXV’s require a Hard Start Kit
.
The condensing unit rating plate lists pertinent electrical data
necessary for proper electrical service and overcurrent protec-
tion. Wires should be sized to limit voltage drop to 2% (max.)
from the main breaker or fuse panel to the condensing unit.
Consult the NEC, CEC, and all local codes to determine the
correct wire gauge and length.
Local codes often require a disconnect switch located near the
unit; do not install the switch on the unit. Refer to the installa-
tion instructions supplied with the indoor furnace/air handler for
specific wiring connections and indoor unit configuration. Like-
wise, consult the instructions packaged with the thermostat
for mounting and location information.
Overcurrent Protection
The following overcurrent protection devices are approved for
use.
• Time delay fuses
• HACR type circuit breakers
These devices have sufficient time delay to permit the motor-
compressor to start and accelerate its load.
Three Phase Compressor Rotation
Use care when handling scroll compressors. Dome temp-
eratures could be hot.
CAUTION
Three phase compressors are power phase dependent and
can rotate in either direction.
Verify proper rotation for three phase compressors by ensuring
the suction pressure drops and discharge pressure rises when
the compressor is energized. NOTE: When operated in re-
verse, a three phase scroll compressors is noisier and its cur-
rent draw substantially reduced compared to marked values.
To correct, disconnect power and switch any two leads at the
unit contactor and re-observe.
High Voltage Connections
Route power supply and ground wires through the high voltage
port and terminate in accordance with the wiring diagram pro-
vided inside the control panel cover.
Low Voltage Connections
The indoor transformer must supply 24 volt AC low voltage
power to the outdoor section for the control wiring. Cooling
only units require 25VA minimum and heat pump units require
40VA minimum. Low voltage wiring for two-stage units de-
pends on the thermostat used and the number of control wires
between the indoor unit and the condensing unit. Route con-
trol wires through the low voltage port and terminate in accor-
dance with the wiring diagram provided inside the control panel
cover.
6
NOTES:
1) TERMINAL BLOCK MARKINGS ARE FOR GOODMAN/AMANA
AIR HANDLERS.
NOMENCLATURE
EHR -EMERGENCY HEAT RELAY (OPTIONAL)
COLOR CODES
BL-- BLUE
BR--BROWN
GR--GREEN
OR--ORANGE
RD--RED
WH-WHITE
Y--YELLOW
BL/PK--BLUE/PINK STRIPE
O
R
A
N
G
E
#18 GA. 5 WIRE
BL
O
W
BL
W
G
C
BLUE
W2
G
WHITE
GREEN
ROOM THERMOSTATHEAT PUMP
B
L
U
E
W
H
I
T
E
R
E
D
R
#18 GA. 7 WIRE
R
INDOOR UNIT
R RED
W3
BROWN
BR
R
G
BR
BL
W2COYR
YOC
GR E
SYSTEM COMPOSITE DIAGRAM - ALL SIZES (EXCEPT 5T 16 SEER) HEAT PUMPS - ABOVE 10 KW
W2
TYPICAL H/P
ROOM THERMOSTAT
HEAT PUMP
R
G
C
W2
RED
GREEN
WHITE
BLUE
INDOOR UNIT
R
O
W
BL
#18 GA. 5 WIRE
R
G
BR
W
BL
R
E
D
O
R
A
N
G
E
W
H
I
T
E
B
L
U
E
BL
W
G
R
COYR
YOCW2GR E
SYSTEM COMPOSITE DIAGRAM - ALL SIZES (EXCEPT 5T 16 SEER) HEAT PUMPS - 10 KW & BELOW
NOTES:
1) TERMINAL BLOCK MARKINGS ARE FOR GOODMAN/AMANA
AIR HANDLERS.
NOMENCLATURE
EHR -EMERGENCY HEAT RELAY (OPTIONAL)
COLOR CODES
BL-- BLUE
BR--BROWN
GR--GREEN
OR--ORANGE
PU--PURPLE
RD--RED
WH-WHITE
Y--YELLOW
BL/PK--BLUE/PINK STRIPE
O
R
A
N
G
E
#18 GA. 5 WIRE
BL
O
W
ROOM THERMOSTAT
HEAT PUMP
B
L
U
E
W
H
I
T
E
W2COY
Y
Y2
Y
BL
W
G
C
BLUE
W2
G
WHITE
GREEN
R
INDOOR UNIT
R RED
W3
BROWN
BR
R
G
BR
BL
OC GR E
SYSTEM COMPOSITE DIAGRAM - 5T 16 SEER ONLY HEAT PUMPS - ABOVE 10 KW
W2
ROOM THERMOSTAT
HEAT PUMP
R
O
W
BL
#18 GA. 5 WIRE
O
R
A
N
G
E
W
H
I
T
E
B
L
U
E
COY
R
E
D
R Y
R
G
C
W2
RED
GREEN
WHITE
BLUE
INDOOR UNIT
R
G
BR
W
BL
BL
W
G
R
OC
W
GR E
SYSTEM COMPOSITE DIAGRAM - 5T 16 SEER ONLY HEAT PUMPS - 10 KW & BELOW
Y2
Y2
Y
R
E
D
R
R
Y2
Thermostat
with Low Voltage Wires to Heat Pump Unit
System Start Up
NOTE: Units with crankcase heaters should have high
voltage power energized for 24 hours prior to start up.
Heat pumps are equipped with a time/temperature defrost
control with field selectable defrost intervals of 30, 60, or
90 minutes. This setting should be adjusted at this time if
needed. The defrost control also has SmartShift™
technology, which delays compressor operation at defrost
initiation and termination. If disabling this function is
desired, move the jumper from “DLY” to “NORM” on the
defrost control
Adequate refrigerant charge for the matching HSVTC evapora-
tor coil and 15 feet of lineset is supplied with the condensing
unit. If using evaporator coils other than HSVTC coil, it may be
necessary to add or remove refrigerant to attain proper charge.
If line set exceeds 15 feet in length, refrigerant should be added
at .6 ounces per foot of liquid line.
NOTE: Charge should always be checked using superheat when
using a piston and subcooling when using TXV equipped in-
door coil to verify proper charge.
Open the suction service valve first! If the liquid service valve is
opened first, oil from the compressor may be drawn into the
indoor coil TXV, restricting refrigerant flow and affecting opera-
tion of the system.
POSSIBLE REFRIGERANT LEAK
To avoid a possible refrigerant leak, open the service
valves until the top of the stem is 1/8” from the retainer.
CAUTION
When opening valves with retainers, open each valve only until
the top of the stem is 1/8” from the retainer. To avoid loss of
refrigerant, DO NOT apply pressure to the retainer. When open-
ing valves without a retainer remove service valve cap and in-
sert a hex wrench into the valve stem and back out the stem
by turning the hex wrench counterclockwise. Open the valve
until it contacts the rolled lip of the valve body.
NOTE: These are not back-seating valves. It is not necessary
to force the stem tightly against the rolled lip.
After the refrigerant charge has bled into the system, open the
liquid service valve. The service valve cap is the secondary seal
for the valve and must be properly tightened to prevent leaks.
Make sure cap is clean and apply refrigerant oil to threads and
sealing surface on inside of cap. Tighten cap finger-tight and
then tighten additional 1/6 of a turn (1 wrench flat), or to the
following specification, to properly seat the sealing surfaces.
1. 3/8” valve to 5 - 10 in-lbs
2. 5/8” valve to 5 - 20 in-lbs
3. 3/4” valve to 5 - 20 in-lbs
4. 7/8” valve to 5 - 20 in-lbs
Do not introduce liquid refrigerant from the cylinder into the
crankcase of the compressor as this may damage the
compressor.
7
1. Break vacuum by fully opening liquid and suction base
valves.
2. Set thermostat to call for cooling. Check indoor and out-
door fan operation and allow system to stabilize for 10
minutes for fixed orifices and 20 minutes for expansion
valves.
Charge Verification
REFRIGERANT UNDER PRESSURE!
• Do not overcharge system with refrigerant.
• Do not operate unit in a vacuum or at negative pres-
sure.
Failure to follow proper procedures may cause
property damage, personal injury or death.
WARNING
Use refrigerant certified standards. Used refrigerant
may cause compressor damage. Most portable machines
cannot clean used refrigerant to meet tandards.
to AHRI
AHRI s
CAUTION
NOTICE
Violation of EPA regulations may result in fines or other
penalties.
Damage to the unit caused by operating the compressor with the
suction valve closed is not covered under the warranty and may
cause serious compressor damage.
CAUTION
Final Charge Adjustment
The outdoor temperature must be 60°F or higher. Set the room
thermostat to COOL, fan switch to AUTO, and set the tem-
perature control well below room temperature.
Purge gauge lines. Connect service gauge manifold to base-
valve service ports. Run the system (on low stage for two-
stage units) for 10 minutes to allow pressures to stabilize,
then check subcooling and/or superheat as detailed in the fol-
lowing sections.
Superheat = Suct. Line Temp. - Sat. Suct. Temp.
Subcooling = Sat. Liquid Temp. - Liquid Line Temp.
CAUTION
To prevent personal injury, carefully connect and disconnect
manifold gauge hoses. Escaping liquid refrigerant can cause
burns. Do not vent refrigerant into the atmosphere. Recover
all refrigerant during system repair and before final unit
disposal.
SUPERHEAT FORMULA = SUCT. LINE TEMP. - SAT. SUCT. TEMP.
55 57 59 61 63 65 67 69 71
10 13 17 20 23 26 29 30 31
8 1114161922262729
5 8 10 13 15 19 23 24 25
------ 6 9 1115202123
--- --- --- --- 7 12 17 18 20
--- --- --- --- --- 8 13 15 16
--- --- --- --- --- 7 10 11 13
--- --- --- --- --- --- 7 8 10
--- --- --- --- --- --- --- 7 8
--- --- --- --- --- --- --- --- 7
--- --- --- --- --- --- --- --- ---
--- --- --- --- --- --- --- --- ---
SYSTEM SUPERHEAT (+/- 1°F)
Indoor Wet Bulb Temperature, °F
Outdoor Dry Bulb
Temperature, °F
60
65
70
105
110
115
75
80
85
90
95
100
8
SUCTION PRESSURE
PSIG R-22 R-410A
50 26 1
52 28 3
54 29 4
56 31 6
58 32 7
60 34 8
62 35 10
64 37 11
66 38 13
68 40 14
70 41 15
72 42 16
74 44 17
76 45 19
78 46 20
80 48 21
85 50 24
90 53 26
95 56 29
100 59 31
110 64 36
120 69 41
130 73 45
140 78 49
150 83 53
160 86 56
170 90 60
SATURATED SUCTION PRESSURE
TEMPERATURE CHART
SATURATED SUCTION
TEMPERATURE ºF
LIQUID PRESSURE
PSIG R-22 R-410A
200 101 70
210 105 73
220 108 76
225 110 78
235 113 80
245 116 83
255 119 85
265 121 88
275 124 90
285 127 92
295 130 95
305 133 97
325 137 101
355 144 108
375 148 112
405 155 118
415 157 119
425 n/a 121
435 n/a 123
445 n/a 125
475 n/a 130
500 n/a 134
525 n/a 138
550 n/a 142
575 n/a 145
600 n/a 149
625 n/a 152
SATURATED LIQUID PRESSURE
TEMPERATURE CHART
SATURATED LIQUID
TEMPERATURE ºF
NOTE: SPECIFICATIONS AND PERFORMANCE DATA LISTED HEREIN ARE SUBJECT TO CHANGE WITHOUT NOTICE.
9
Fixed Orifice
1. Temporarily install a thermometer 4-6" from the compres-
sor on the suction line. Ensure the thermometer makes
adequate contact and is insulated for best possible read-
ings. Use vapor temperature to determine superheat.
2. Refer to the superheat table provided for proper system
superheat. Add charge to lower superheat or recover
charge to raise superheat.
Expansion Valve System
NOTE: Units matched with indoor coils equipped with a
non-adjustable TXV should be charged by Subcooling only.
SUBCOOLING FORMULA = SATURATED LIQUID LINE TEM-
PERATURE - LIQUID LINE TEMPERATURE
1. Purge the gauge lines and connect the service gauge
manifold to the base valve service ports.
2. Clamp a pipe clamp thermometer on the liquid line near
the liquid line service valve and 4-6" from the compressor
on the suction line.
a. Ensure the thermometer makes adequate contact to
obtain the best possible readings.
b. The temperature read with the thermometer should be
lower than the saturated condensing temperature.
3. The difference between the measured saturated con-
densing temperature and the liquid line temperature is
the liquid Subcooling value.
4. TXV-based systems should have a Subcooling value
of 8°F +/- 1°F.
5. Add refrigerant to increase Subcooling and remove re-
frigerant to decrease Subcooling.
NOTE: Units matched with indoor coils equipped with a
TXV should be charged by Subcooling only. Superheat
can also be utilized to best verify charge levels with an
adjustable TXV and make adjustments when needed in
unique applications due to refrigerant line length, differ-
ences in height between the indoor and outdoor unit and
refrigerant tubing sizes. These adjustments should only
be performed by qualified service personnel.
Advanced Adjustment Recommendations
SUPERHEAT FORMULA = SUCTION LINE TEMPERA-
TURE - SATURATED SUCTION TEMPERATURE
1. Clamp a pipe clamp thermometer near the suction line
service valve at the outdoor unit.
a. Ensure the thermometer makes adequate contact for
the best possible readings.
b. The temperature read with the thermometer should be
higher than the saturated suction temperature.
2. The difference between the measured saturated suction
temperature and the suction line temperature is the Su-
perheat value.
3. TXV-based systems should have a Superheat value of
8°F +/- 1°F.
4. Adjust Superheat by turning the TXV valve stem clock-
wise to increase and counterclockwise to decrease.
a. If Subcooling and Superheat are low, adjust the TXV
to 8°F +/- 1°F, and then check Subcooling.
b. If Subcooling is low and Superheat is high, add charge
to raise Subcooling to 8°F +/- 1°F then check Super-
heat.
c. If Subcooling and Superheat are high, adjust the TXV
valve to 8°F +/- 1°F Superheat, then check the
Subcooling value.
d. If Subcooling is high and Superheat is low, adjust
the TXV valve to 8°F +/- 1°F Superheat and remove
charge to lower the Subcooling to 8°F +/- 1°F.
NOTE: DO NOT adjust the charge based exclusively on
suction pressure unless for general charging in the case of a
gross undercharge.
NOTE: Check the Schrader ports for leaks and tighten valve
cores if necessary. Install caps finger-tight.
Heat Pump - Heating Cycle
The proper method of charging a heat pump in the heat mode
is by weight with the additional charge adjustments for line
size, line length, and other system components. For best
results, on outdoor units with TXVs, superheat should be 5°F
+/- 1°F at 4-6" from the compressor. Make final charge adjust-
ments in the cooling cycle.
10
Troubleshooting Information
For detailed service information refer to the Remote Condensing Unit Service manual.
NOTICE
Units with rotary or reciprocating compressors and non-bleed TXV’s
require a Hard Start Kit.
Complaint
System
Operating
Pressures
POSSIBLE CAUSE
DOTS IN ANALYSIS
GUIDE INDICATE
"POSSIBLE CAUSE"
SYMPTOM
System will not start
Compressor will not start - fan runs
Comp. and Cond. Fan will not star t
Evaporator fan will not start
Condenser fan will not start
Compressor runs - goes off on overload
Compressor cycles on overl oad
System runs continuously - little cooling/htg
Too cool and then too warm
Not cool enough on warm days
Certain areas too cool , others too warm
Compressor is noisy
System runs - blows cold air in heating
Unit will not terminate defrost
Unit will not defrost
Low suction pressure
Low head pressure
High suction pressure
High head pressure
Test Method
Remedy
Power Failure
•
Test Volta
g
e
Blown Fuse
•••
Inspect Fuse Size & Type
Unbalanced Power, 3PH
•••
Test Voltage
Loose Connection
•••
Ins
p
ect Connection - Ti
g
hten
Shorted or Broken Wires
••••••
Test Circuits With Ohmmeter
Ope n Fan Overload
••
Test Continuit
y
of Overload
Faulty Thermostat
••• •
Test Continuity of Thermostat & Wi ring
Faulty Transformer
••
Check Control Circuit with Voltmeter
Shorted or Open Capacitor
•••••
Test Ca
p
acitor
Internal Com
p
ressor Overload O
p
en
•
♦
Test Continuit
y
of Overload
Shorted or Grounded Compressor
••
Test Motor Windin
g
s
Compre sso r Stuck
•••
♦
Use Test Cord
Faulty Compressor Contactor
•••
Test Continuity of Coil & Contacts
Faulty Fan Relay
•
Test Continuit
y
of Coil And Contacts
Open Control Cir cuit
•
Test Control Circuit with Voltmeter
Low Voltage
•••
Test Volta
g
e
Faulty Evap. Fan Motor
••
♦
Repair or Replace
Shorted or Grounded Fan Motor
••
Test Motor Windings
Improper Cooli ng Anticipator
••
Check Resistance of Antici
p
ator
Shortage of Refrigerant
••
♦
••
Test For Leaks, Add Refri
g
erant
Restricted Liquid Line
•• •• •
Remove Restriction, Re
p
lace Restricted Part
Open Element or Limit on Elec. Heater
♦♦
Test Heater Element and Controls
Di rty Air Fil te r
••• •
♦
Ins
p
ect Filter-Clean or Re
p
lace
Di rty Indoor Coil
••• •
♦
Ins
p
ect Coil - Clean
Not enough air across Indoor Coil
••• •
♦
Check Blower S
p
eed, Duct Static Press, Filter
Too much air across Indoor Coil
♦
•
Reduce Blower S
p
eed
Overcharge of Refrigerant
•• •
♦
••
Recover Part of Charge
Di rty Outdoor Coil
•• •
♦
•
Ins
p
ect Coil - Clean
Noncondensibles
••
♦
•
Recover Char
g
e, Evacuate, Rechar
g
e
Recirculation of Condensing Air
•• •
Remove Obstruction to Air Flow
Infil trati on of Outdoor Ai r
•••
Check Wi ndows, Door s, Vent Fans, Etc.
Improperly Located Thermostat
••
Relocate Thermostat
Air Flow Unbalanced
••
Read
j
ust Air Volume Dam
p
ers
System Undersized
••
Refi
g
ure Coolin
g
Load
Broke n Internal Parts
•
♦
Re
p
lace Com
p
ressor
Broken Valves
•• ••
Test Com
p
ressor Efficienc
y
Inefficient Co mpre ssor
•
♦
••
Test Compressor Efficiency
Wrong Type Expansion Valve
••• • ••
♦
Re
p
lace Valve
Expansion Device Restricted
••• • •• •
Remove Restriction or Re
p
lace Ex
p
ansion Device
Oversized Expansion Valve
••
Re
p
lace Valve
Undersized Expansion Val ve
••• • •
Re
p
lace Valve
Expansion Valve Bulb Loose
••
Tighten Bulb Bracket
Inoperative Expansion Valve
•• •
Check Valve O
p
eration
Loose Hold-down Bolts
•
Ti
g
hten Bolts
Faulty Reversing Valve
•
♦♦ ♦ ♦♦♦
Re
p
lace Valve or Solenoid
Faulty Defrost Con trol
•
♦♦ ♦♦♦ ♦
Test Control
Faulty Defrost Thermostat
♦♦♦♦♦♦♦
Test Defrost Thermostat
Flowrator Not Seatin
g
Pro
p
erl
y
•••
Check Flowrator & Seat or Re
p
lace Flowrator
•
Cooling or Heating Cycle (Heat Pump)
♦
No Cooling Unsatisfactory Cooling/Heating
Heating Cycle Only (Heat Pump)
11
SPLIT SYSTEMS
AIR CONDITIONING AND HEAT PUMP HOMEOWNER’S ROUTINE MAINTENANCE RECOMMENDATIONS
We strongly recommend a bi-annual maintenance checkup be performed
before the heating and cooling seasons begin by a qualified servicer.
Replace or Clean Filter
IMPORTANT NOTE: Never operate unit without a filter installed
as dust and lint will build up on internal parts resulting in loss
of efficiency, equipment damage and possible fire.
An indoor air filter must be used with your comfort system. A
properly maintained filter will keep the indoor coil of your com-
fort system clean. A dirty coil could cause poor operation and/
or severe equipment damage.
Your air filter or filters could be located in your furnace, in a
blower unit, or in “filter grilles” in your ceiling or walls. The
installer of your air conditioner or heat pump can tell you where
your filter(s) are, and how to clean or replace them.
Check your filter(s) at least once a month. When they are
dirty, replace or clean as required. Disposable type filters should
be replaced. Reusable type filters may be cleaned.
You may want to ask your dealer about high efficiency filters.
High efficiency filters are available in both electronic and non-
electronic types. These filters can do a better job of catching
small airborne particles.
Compressor
The compressor motor is hermetically sealed and does not
require additional oiling.
Motors
Indoor and outdoor fan motors are permanently lubricated and
do not require additional oiling.
Clean Outside Coil (Qualified Servicer Only)
Air must be able to flow through the outdoor unit of your com-
fort system. Do not construct a fence near the unit or build a
deck or patio over the unit without first discussing your plans
with your dealer or other qualified servicer. Restricted airflow
could lead to poor operation and/or severe equipment damage.
Likewise, it is important to keep the outdoor coil clean. Dirt,
leaves, or debris could also restrict the airflow. If cleaning of
the outdoor coil becomes necessary, hire a qualified servicer.
Inexperienced people could easily puncture the tubing in the
coil. Even a small hole in the tubing could eventually cause a
large loss of refrigerant. Loss of refrigerant can cause poor
operation and/or severe equipment damage.
Do not use a condensing unit cover to “protect” the outdoor
unit during the winter, unless you first discuss it with your
dealer. Any cover used must include “breathable” fabric to avoid
moisture buildup.
• Check the thermostat to confirm that it is properly set.
• Wait 15 minutes. Some devices in the outdoor unit or in
programmable thermostats will prevent compressor op-
eration for awhile, and then reset automatically. Also,
some power companies will install devices which shut
off air conditioners for several minutes on hot days. If
you wait several minutes, the unit may begin operation
on its own.
T
O
AVOID
THE
RISK
OF
EQUIPMENT
DAMAGE
OR
FIRE
,
INSTALL
THE
SAME
AMPERAGE
BREAKER
OR
FUSE
AS
YOU
ARE
REPLACING
. I
F
THE
CIRCUIT
BREAKER
OR
FUSE
SHOULD
OPEN
AGAIN
WITHIN
THIRTY
DAYS
,
CONTACT
A
QUALIFIED
SERVICER
TO
CORRECT
THE
PROBLEM
.
I
F
YOU
REPEATEDLY
RESET
THE
BREAKER
OR
REPLACE
THE
FUSE
WITHOUT
HAVING
THE
PROBLEM
CORRECTED
,
YOU
RUN
THE
RISK
OF
SEVERE
EQUIPMENT
DAMAGE
.
BEFORE CALLING YOUR SERVICER
• Check the electrical panel for tripped circuit breakers
or failed fuses. Reset the circuit breakers or replace fuses
as necessary.
• Check the disconnect switch near the indoor furnace or
blower to confirm that it is closed.
• Check for obstructions on the outdoor unit . Confirm that
it has not been covered on the sides or the top. Remove
any obstruction that can be safely removed. If the unit
is covered with dirt or debris, call a qualified servicer to
clean it.
• Check for blockage of the indoor air inlets and outlets.
Confirm that they are open and have not been blocked
by objects (rugs, curtains or furniture).
• Check the filter. If it is dirty, clean or replace it.
• Listen for any unusual noise(s), other than normal oper-
ating noise, that might be coming from the outdoor unit.
If you hear unusual noise(s) coming from the unit, call a
qualified servicer.
CUSTOMER FEEDBACK
We are very interested in all product comments.
Please fill out the feedback form on one of the following links:
Goodman® Brand Products: (
http://www.goodmanmfg.com/about/contact-us).
You can also scan the QR code on the right for the product brand
you purchased to be directed to the feedback page.
PRODUCT REGISTRATION
Thank you for your recent purchase. Though not required to get the protection of
the standard warranty, registering your product is a relatively short process, and
entitles you to additional warranty protection, except that failure by California
and Quebec residents to register their product does not diminish their warranty
rights.
For Product Registration, please register as follows:
Goodman® Brand products: (
https://www.goodmanmfg.com/product-registration).
You can also scan the QR code on the right for the product brand
you purchased to be directed to the Product Registration page.
GOODMAN® BRAND
GOODMAN® BRAND
