REVISED BULLETIN
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 7
M18
™
BATTERY
48-11-1812, 48-11-1815, 48-11-1820, 48-11-1828, 48-11-1835,
48-11-1840, 48-11-1850, 48-11-1850
R
, 48-11-1860,
48-11-1865, 48-11-1880, 48-11-1890
2, 3
1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 12-20-0131 Service Nameplate (1)
2 10-20-4305 Front Label (1)
3 10-20-7238 Front Label for 48-11-1850R (1)
FIG. NOTES
1, 2, 3 Thefrontlabelwilltonallcatalognumbers
listedaboveexcept48-11-1850R:OrderFig.3.
Aclean,drysurfaceisessentialforproperperformanceforany
adhesivesystem.Theareaintendedforapplicationofanyadhesive
labelornameplatemustbepreparedbycleaningwithisopropyl
alcohol.Thesolventistobeappliedwithaclean,lintfreeapplicator
andthesurfaceallowedtodrybeforeapplyingthelabelornameplate.
TRANSPORT NOTE:
PersonaltransportofLi-Ionbatterypacksisallowedwhendonein
accordancewiththesewarningsandinstructions.Theproperclassication,
packaging,labeling,marking,anddocumentationrequirementsforshipping
Li-Ionbatteriesisdependentuponwhethertheparticularbatteriesarerated
greaterthanorlessthan100Wh.Generally,Li-Ionbatteriesrated100Wh
orlessare"excepted"fromcertainClass9DGrequirements.Alwayscheck
complianceofLi-Ionbatteryconsignmentsagainstthecurrentregulations
governingthechosenmodeoftransport.Whenindoubt,contactthecarrier
oranothertrainedDangerousGoodsprofessionaltoconrmacceptibility.
Li-IonpacksareshippedunderclassicationUN3480(batteryonly)orUN
3481(batteriescontainedinorpackedwithequipment).
NOTE:
For 48-11-1850R:
OrderFig.3.
Front Label: 10-20-7238
DATE
April 2025
BULLETIN NO.
54-04-1820
SERVICE PARTS LIST
