wood block
Kwikset
Door edge NOT
chiseled
Door edge chiseled
Installation Guide
1-800-327-5625
www.kwikset.com
*Tools
Passage Privacy Entry Dummy
(Non-Rotating)
*Tools will depend on install type
66084 / 01
3/32" (2 mm)
This manual can be used to install a variety of knobs.
Please determine your function type prior to installation.
Do not
remove
screws!
If installing a
non-rotating
knob, skip to
step 4.
Hold the latch in front of the door hole, with
the latch face flush against the door edge.
If the latch holes are centered in the door hole,
no adjustment is required. Proceed to step 4.
If the latch holes are NOT centered, adjust
latch. See “Latch Adjustment” (step 3C).
Latch Adjustment (only if needed)
Move the pin to
extend the latch.
not centered
centered
wood block
slant of latch bolt
faces door frame
slant of latch bolt
faces door frame
Use hammer
and wood
block to tap in
latch without
damaging it.
door frame
Remove plates
Install drive-in collar
door frame
A
B
C
Twist the
side with the
holes.
counter-clockwise
Pull to
separate
knobs.
Set knobs aside until step 5.
A
B
C
or
Disconnect knobs (if pre-assembled)
1
2
Adjust the backset of the latch (if needed)
Install latch
3
Scroll to the bottom (STEP 6) if you need help in preparing your door
Weiser
Push up on knob while
tightening screws to
keep latch horizontal
and centered.
Align round edges.
Tip: Pull knob
slightly away
from door to see
where screws insert.
Ensure holes
are horizontal.
align
exterior
Press latch
bolt to install
exterior knob.
Align round edges.
1. Twist counter-
clockwise
2. Push while
twisting
3. Twist clockwise
To catch screws:
interior
OK if flipped
Press latch bolt
to install knob.
IMPORTANT: If installing a
passage lock on an entry
door, make sure the knob
with the screw holes is on
the interior side of the door.
Save the bedroom/bathroom emergency
unlock tool for future use.
If small bolt of latch enters strike hole, reposition strike.
small bolt in
strike hole
small bolt NOT
in strike hole
If latch is loose in the strike,
adjust the strike tab so it
grips the latch bolt better
when the door is closed.
tab
Close door, test latch operation and make adjustments as needed:
exterior
interior
A
A
B
D
A
B C
ED
A
B
C
Install knobs
4
Option 2: Install entry knobs
Option 3: Install dummy (non-rotating) knobs
Option 1: Install privacy/passage knobs
Privacy locks only
Install strike to door frame
5
1/8"
3 mm
2-1/8"
54 mm
1/8"
3 mm
1"
25 mm
1/8"
3 mm
2-1/8"
54 mm
1/8"
3 mm
1"
25 mm
1/8"
3 mm
2-1/8"
54 mm
1/8"
3 mm
1"
25 mm
1/8"
3 mm
2-1/8"
54 mm
1/8"
3 mm
1"
25 mm
Drill holes in door
Select the template that allows you to place
the template on the EXTERIOR side of door.
Fold template along fold line and place fold
line along the edge of door. Place centerline
approximately 38" (97 cm) from the floor.
Mark hole on the face of the door.
Select desired backset before mark-
ing hole. If there is another hole in
the door, or if you are drilling double
doors, make sure to keep the back-
set consistent.
Mark hole on the edge of the
door. Select door thickness be-
fore marking hole.
Drill from one side until the point
of drill just breaks through, then
complete hole from the other side
to prevent splintering.
Exterior
Floor
*Call Kwikset to order a
service kit for 2-1/4" (57
mm) thick doors.
2-3/8" (60 mm)
or
2-3/4" (70 mm)
1-3/8"–2-1/4"*
35 mm–57 mm*
2-1/8"
54 mm
1"
25 mm
For consumers requiring the door
prep template, please visit:
images.kwikset.com/is/content/
BDHHI/drilling-instructions_knob
B
A
B
C
D
A
C
Through door
2" [51 mm] deep
2" [51 mm] deep
Preparing Your Door
6
Use template to mark holes on door
1/8"
3 mm
B
A
C
D
E
1/8"
3 mm
B
A
C
D
E
1/8"
3 mm
B
A
C
D
E
1/8"
3 mm
B
A
C
D
E
1/8"
3 mm
B
A
C
D
E
1/8"
3 mm
B
A
C
D
E
Determine which latch will be installed and prepare door edge
Latch with drive-in collar
Proceed to Step 2.
Latch with rectangular faceplate
or
If latch is not pre-assembled
with desired faceplate, as-
semble it as shown.
If desired faceplate is not
supplied with the latch, please
contact Consumer Support.
1"
25 mm
1/8"
3 mm
3/32"
2 mm
2x
1"
25 mm
1/8"
3 mm
3/32"
2 mm
2x
1"
25 mm
1/8"
3 mm
3/32"
2 mm
2x
1"
25 mm
1/8"
3 mm
3/32"
2 mm
2x
1"
25 mm
1/8"
3 mm
3/32"
2 mm
2x
WARNING: This Manufacturer advises that no lock can provide complete security by itself. This lock
may be defeated by forcible or technical means, or evaded by entry elsewhere on the property. No lock
can substitute for caution, awareness of your environment, and common sense. Builder’s hardware
is available in multiple performance grades to suit the application. In order to enhance security and
reduce risk, you should consult a qualified locksmith or other security professional.
Register your product at www.kwikset.com/productregistration
Rate your product at www.kwikset.com/reviews
©2022 Spectrum Brands, Inc.
B
A
C
D
E
Chisel
Mark holes
1" [25 mm]
deep
A
B
C
Locate center of strike hole:
Measure back from door stop, 1/2 thickness of door.
5/8" [16mm] deep
5/8" [16mm] deep
E
F
G
D
Keep level and trace.
Chisel
Mark holes (2x)
1" [25mm] deep
Prepare door frame for strike
