Step 1: Insert six large cross-head bolts (1/4-20*1") to mount the top. Ensure the cam is flush.
Step 2: Mount the L-Bracket hinge. Insert two 1/4-20-1" screws, and attach
it to the left side.
Step 3: Insert two 3/8-16*1" screws, then screw and tighten them to the
bottom.
Step 4: Mount two plastic caps. Insert and screw four #10-32*0.375
cross sink heads, then tighten.
INSTALLATION MANUAL
Aluminum Swinging Traffic Door
Models: KM-SWD30, KM-SWD36
