CARPET WASHER
INSTRUCTION MANUAL
CPW-X1-BK-PP
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Carefully read this manual before using this appliance.
Ensure that you know how the appliance functions and how to operate it.
Maintain the appliance in accordance with the instructions to ensure that it functions properly.
Keep this manual with the appliance. If the appliance is to be used by a third party, this
instruction manual must be supplied with it.
The appliance is not designed for use by children.
This appliance is designed for domestic use only. Do not use outdoors.
Keep the appliance and cable away from heat sources.
Do not pull by the cord to unplug, hold the plug to separate the adaptor from the mains.
Do not leave the appliance unattended when it is switched on.
The safety instructions do not by themselves eliminate any danger completely and proper
accident prevention measures must always be used.
No liability can be accepted for any damage caused by non-compliance with these instructions
or any other improper use or mishandling.
Do not use this appliance if it has been dropped, damaged or if the plug or supply cord
is damaged.
PACKAGE CONTENTS
1x Carpet Washer
1x Handle
2x Screws
1x Instruction Manual
Confirm all parts before disposing of carton. Ensure all plastic bags and other packaging
components are kept away from children and disposed of safely.
TECHNICAL SPECIFICATION
Power: 220-240V ~ , 50Hz
Wattage:
800Watts
Clean water tank capacity: 3.2L
Dirt water tank capacity: 2.8L
Water spray rate: 552.5ml/min
1
When using electric appliances always observe safety regulations where applicable to
reduce the risk of fire, electric shock, and personal injury. Always check that the power supply
corresponds to the voltage on the rating plate. Always unplug the appliance when not in use.
Always unplug from mains supply when not in use. Do not handle the plug or cord with wet
hands. Do not abuse or damage the power cord. If the supply cord is damaged contact us
support in order to avoid a hazard. Do not let the supply cord touch hot surfaces.
Do not immerse appliance in water. Do not handle the plug or appliance with wet
hands. Only use the appliance on wet surfaces when cleaning them. Do not use
the appliance if it has been exposed to rain. Do not use to pick up flammable or
combustible liquids such as petrol or use in areas where they may be present.
Do not use this appliance for any use other than its intended purpose.
GENERAL AND ELECTRICAL SAFETY
SUPPLY CORD AND PLUG
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children must be supervised to ensure they do not play with the appliance.
GENERAL USE
Do not use outdoors. Do not use this appliance for anything other than its intended use. Use
only the attachments we recommend. Do not use without the tank in place.
Do not use with any opening or outlet blocked. Keep free of dust, lint, hair and anything that
may reduce airflow.
Keep hair, loose clothing, and fingers away from openings and moving parts.
Do not use to pick up flammable or toxic liquids, such as gasoline, chlorine bleach or drain
cleaner, or use in areas where they may be present.
Do not pick up anything that is burning or smoking including hot ashes.
Always inspect your appliance before use. Check parts are correctly attached. Do not use
this appliance if it has been damaged, dropped, left outdoors, or dropped in water.
USE AND ENVIRONMENT
DAMAGE
WATER
This appliance is double insulated for your protection. Do not attempt to repair a
double insulated appliance.
DOUBLE INSULATION SAFETY
2
1.Handle
2.Carry Handle
3. On / Off Switch
4.Clean Water Tank Cap
5.Clean Water Tank Release Handle
6.Clean Water Tank
7.Dirty Water Tank Locking Latch
8.Dirty Water Tank Handle
10.Dirty Water Tank
11.Brush Bar
12.Clean Water Release Trigger
13.Power Cord Tidy
14.Power Cord Holder Upper
15.Power Cord
16.Power Cord Holder Lower
17.Recline pedal
9.Exhaust Filter
CONTENTS
1
2
12
13
14
16
15
17
3
4
5
6
7
8
10
11
9
3
1.Carefully unpack all components and set aside the packaging.
2.Lift the carpet washer to the upright position.
3.Align the handle with the groove and insert onto body. If necessary,
use thumb and finger pressure to slide handle into position.
4.Secure the handle to the body with the two screws supplied (Fig.1)
1.Before use - Vacuum your carpet thoroughly.
2.Remove as much furniture from the room as possible. If unable to remove the furniture,
place plastic or foil under and around.
3.Determine where to start and end to prevent walking on the carpet whilst it is wet.
Before cleaning the carpet, we recommend testing for colour fastness. Dampen a white
cloth with shampoo and test a small area in an unseen area. Gently rub the cloth over the
area. Check each colour for colour bleeding.
1.Use only special Carpet Shampoo with this appliance.
2.Do not over saturate the carpet with the shampoo while using the carpet washer.
3.For heavily soiled areas, additional applications may be necessary.
4.Allow plenty of time to dry the carpet thoroughly. Increased air circulation (open doors,
turn on fans, etc.) or use of a dehumidifier will help carpet dry thoroughly and prevent the
growth of mould or mildew.
5.Try not to walk on the carpet until after the carpet is thoroughly dry
6.For best cleaning results use a steady, moderate, forwards and backward motion
7.Always ensure the carpet is vacuumed prior to washing and again once it is dry.
CAUTION: Do not over tighten. Over tightening could strip the screw
holes. Do not operate the appliance without the handle screws in place.
Do not plug the power cord into an electrical outlet
until the machine is fully assembled.
ASSEMBLY
CARPET PREPARATION
HELPFUL HINTS FOR CLEANING CARPET:
!CHECK FOR COLOUR FASTNESS:
Allow the carpet to dry completely. Try not to walk on the carpet until it is dry. If it is
necessary to walk on the carpet, place white towels on the areas to be walked on. If the
carpet is not dry and the furniture must be placed back in the room, use plastic or foil
under the furniture to prevent staining/marking the carpet. Thoroughly clean the dirty water
tank with warm (max 40°C) tap water.
AFTER CLEANING:
IMPORTANT:Do not use the carpet washer as a dry vacuum.
NOTE:
4
1.Hold the clean water tank and lift the water tank
release handle upwards. Tilt the water tank away
from the carpet washer and remove.
2.Unscrew the tank cap and add clean warm
water (max temperature 40°C).
1.Plug cord into the electrical socket. Turn on the
machine by using the on/off switch located on the
side of the machine.
2.Step on the recline pedal to lower the machine into the cleaning position. While pressing
the trigger, push the unit forward in a straight path to release the water. Release the trigger
and pull carpet washer in a backward motion to agitate and remove dirty water and
shampoo from the carpet. (For heavily soiled areas, repeat if necessary)
IMPORTANT: Never leave appliance unattended
with power on. Turn off when emptying and filling
tanks. Do not over-saturate the carpet.
3.Follow the instructions on the cleaning shampoo
to measure the correct volume of shampoo to add
to the water.
4.Replace the tank cap.
5.Place clean water tank back into original position
and press down release handle for security.
CAUTION: Do not use the carpet washer without the
dean water tank in position
IMPORTANT: Excessive volumes of shampoo will
cause foaming on the carpet and can prevent the
machine from working effectively
OPERATION
OPERATING INSTRUCTIONS
CARPET CLEANER USE
5
An automatic shut-off device prevents the extractor from picking up more dirty water than it
can hold in the dirty water tank. You will know the tank needs to be emptied:
・When the motor sound rises in pitch.
•You do not see dirty solution conning up through the recovery tank lid.
1. Always disconnect from the power supply when
not in use.Always empty and rinse out both theclean
and the dirty water tank after use.
Remember to refit the tank cap to the clean water
tank.
2. Remove the exhaust filter rinse with warm water
and allow it to dry thoroughly before storing.
3.Always ensure both tanks are fully dry before storage.
IMPORTANT: Do not use chemicals when cleaning
this filter. Always clean after each use.
1. Unplug the appliance from the electrical outlet.
2. Unlock by lifting the dirty water tank latch and
remove from the base unit using the handle
3. Empty, rinse and replace the dirty water tank.
4. Check the motor filter as below.
EMPTYING THE DIRTY WATER TANK
MAINTENANCE OF FILTERS
7
Regular maintenance of your appliance will keep it safe and in proper operational order.
No power to the appliance
Low suction / suction reducing
Cleaning shampoo not dispensing
APPLIANCE MAINTENANCE
When not in use always disconnect the appliance from the mains supply.
Never immerse the motor unit in water or any other fluid.
1.Check electrical plug
2.Check the fuse
3.Check the power supply - try using the appliance in
another socket
1.Empty the dirty water tank; it may be full and the
automatic shut-off has engaged.
2.Make sure the dirty water tank is properly installed.
3.Clean the motor filter regularly during use to prevent any
build up of carpet fibres or debris. This filter is designed to
trap them but MUST be kept clean.
1.Make sure clean water tank is fully inserted and securely
in place.
2.Ensure there is sufficient clean water and there is not a
higher volume of shampoo causing over-foaming inside
the tank.
BEFORE CLEANING
•Regularly clean the outside of the appliance with a soft damp cloth and dry it with a dry
towel.
•Do not use any chemicals to clean the appliance.
•Do not store the cleaner with any water or shampoo in either tank. Mineral deposits and
mildew can form which will affect the performance of the carpet washer.
•After cleaning, let the tanks dry and then store your appliance and all its accessories and
instruction manual in a safe and dry place.
This marking indicates that this product should not be disposed with other household waste throughout the EU. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To arrange safe disposal of your used device, please use the
return and collection systems or contact the retailer where the product was purchased.
CLEANING
TROUBLESHOOTING
Warranty Registration
Safe Disposal
PROBLEM SOLUTION
8
