WARNING:
1.Assemble only according to these instructions.
Improper assembly can create hazards.
2.Wear heavy-duty work gloves during assembly.
3.Over-loading is strictly forbidden
4.While iting the load, passing or working or working
under a litting load is strictly forbidden.
5.Bearing and beam surface should be greased
regularly, and examine the bolts and nuts to make sure
that they are tightened
Caution:
1.Read this material before using this product. Failure
to do so can result in serious injury.
2.The trolley must be used flexibly, and it is strictly
prohibited to use it compulsorily when individual
connections are inflexible.
3. After use, please dry before storage to avoid rusting
of bolts affecting use.
SAVE THESE INSTRUCTIONS
This is the original instruction, please read all manual instructions carefully before
operating. VEVOR reserves a clear interpretation of our user manual. The
appearance of the product shall be subject to the product you received. Please
forgive us that we won't inform you again if there are any technology or software
updates on our product.
NEED HELP? CONTACT US!
030201
MANUAL TROLLEY
SAFETY INSTRUCTIONS
MODEL AND PARAMETERS
Have product questions? Need technical support? Please
feel free to contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
Model
0.5-F
1T-F
2T-F
3T-F
Load
Capacity
Ton
0.5
1
2
3
lbs
1100
2200
4400
6600
I-beam /
H-beam track
Rail width
inches (mm）
2.5-5.5
(64-
140mm)
2.5-7
(64-177mm)
Colour
Black
Model
0.5-K
1T-K
2T-K
3T-K
5T-K
Load
Capacity
Ton
0.5
1
2
3
5
lbs
1100
2200
4400
6600
11000
I-beam /
H-beam track
Rail width
inches (mm）
(64-203mm)
4.5-8
(114-
203
mm)
Colour
Orange
ASSEMBLY AND USE
①Trolley side plates and wheels assembly
② Hanging ring plate ③Trolley Pin
④ Thickened washers ⑤ Thin washers
⑥nut ⑦wire pin
Manual Trolley
Model: 0.5-F, 1T-F, 2T-F,3T-F
0.5-K, 1T-K, 2T-K, 3T-K,5T-K
Technical Support and E-Warranty Certificate
www.vevor.com/support
Technical Support and E-Warranty Certificate
www.vevor.com/support
Made In China
MAINTENANCE
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to
cover all categories of tools offered by us.
You are kindly reminded to verify carefully when you are placing an order with
us if you are actually saving half in comparison with the top major brands.
04
1.According to the rail width of your I-beams/H-beam,
the trolley must be adjusted with the washers .
Assemble the required number of washers equally to
the inside or outside of the trolley side plates so that
the dimension (W) between the Trolley Wheel Flanges
is about 1/5inch( 5mm) greater than the rail beam
width of I-beam /H-beam track.
2.The washers, the trolley side plates, and the hanging
ring plate are assembled on the trolley pin. They must
be locked with nuts, in order to prevent the nut from
falling off. The end of the trolley pin is locked with a
wire pin, and the wire pin is bent with pliers.(Model 0.5-
F and Model 0.5-K are the two nuts fixed at the end of
the trolley pin)
1.Avoid prolonged exposure to the sun to avoid aging.
