PRO AUDIO SPEAKERS
FEATURES
• Lightweight voice coil for high SPL
• Double-roll cloth surround for precise sound reproduction
• High-tensile stamped steel basket for improved damping
• Stiff paper cone provides warm, smooth sound with enhanced damping
• Copper shorting ring widens bandwidth and reduces distortion
• High-quality mounting hardware included
• Ear defenders optional
EPICPRO6S | EPICPRO6X | EPICPRO8X
User Guide
2
User Guide
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not submerge this apparatus in water.
6. Clean only with a dry cloth.
7. WARNING: The speakers must be properly secured in the vehicle.
Improper installation may lead to permanent injury or death. Installation
of the speakers must be done with great care by qualified personnel, to
prevent damage to fuel lines, power and other electrical wiring, hydraulic
brake lines, and other systems that might compromise vehicle safety.
8. Use speaker wire of sufficient size to ensure adequate current to the
speaker. For EPIC Series Speakers, this typically means 14-18 gauge
speaker wire.
9. Refer all servicing to qualified service personnel. Servicing is required
if the apparatus has been damaged in any way, such as damaged input
terminals, objects falling into the apparatus, abnormal operation, or if it
has been dropped.
10. Exposure to high sound pressure levels may lead to permanent hearing
loss. Take every precaution to protect your hearing.
The exclamation point inside an equilateral triangle is used to alert
the user to important operating instructions in the literature that
comes with the speakers.
Recycling notice: If the time comes and this apparatus has fulfilled
its destiny, do not throw it out into the trash. It has to be carefully
recycled for the good of mankind, by a facility specially equipped
for the safe recycling of electronic apparatuses. Please contact your
local or state recycling leaders for assistance in locating a suitable
nearby recycling facility. Or, contact us and we might be able to
repair it for you.
3
Speaker Talk
Congratulations on acquiring this rad pair of beautifully engineered and
obnoxiously loud speakers!
We feel for your neighborhood.
If you didn't attend auto shop in school or struggle with plugging in power
tools, your best bet is to seek out a qualified AudioControl dealer. They have
the skills, experience, and specialized tools to get your vehicle sounding like a
live concert—and they usually smell alright too.
Pro Audio
This EPIC Pro range of speakers is a far cry from traditional car speakers. These
speakers are designed for one job—to be loud!
The speaker technology and engineering are all based around efficiency
which requires different components compared to 'normal car audio, such
as lightweight composite cones, and dual roll cloth surrounds, this helps
to increase the efficiency or "SPL". The greater the efficiency the louder we
go!. So, pairing these efficient soft parts with a perfectly engineered motor
structure and voice coil will produce concert-level sound directly from your
car.
Our range of EPIC Pro audio midrange speakers is designed to be paired with
EPIC Pro audio tweeters. This combination delivers full-range sound at levels
beyond your imagination.
We advise that you adjust the crossover on your amplifier according to each
speaker's technical specification in this manual.
Now get out there and bring the noise!
4
User Guide
Specifications - EPICPRO6S
200100 300
RMSMIN MAX
a
b
B
A
D
Epic Series Speakers
EPIC6S
6.5” / Midrange / 4Ω
Speaker Model ...................................................................................................... EPICPRO6S
Speaker size .................................................................................................... 6.5 in / 165 mm
DC Resistance (Re)......................................................................................................3.2 ohms
Voice Coil ......................................................................................................... 1.2 in / 30.5 mm
System Frequency Response ............................................................... 120 Hz to 8000 Hz
Sensitivity* ............................................................................................... 93.1 dB @ 1 W / 1 m
..................................................................................................................96.1 dB @ 2.83 V / 1 m
Magnet Weight .................................................................................................... 28 oz / 794 g
Magnet Dimensions .......................................4.33 x 1.77 x 0.79 in / 110 x 45 x 20 mm
The power handling of the EPICPRO6S is determined by the crossover points
at which the driver is used.
Please see below to determine the crossover points at which you will operate
and the power handling capabilities.
1. Enhanced bass/midbass – 100 Hz HPF, 12 dB slope, 120 W RMS
2. Warm midbass, high volume – 150 Hz HPF, 12 dB slope, 150 W RMS
3. Powerful midrange, max volume – 200 Hz HPF, 12 dB slope, 200 W RMS
Dimensions
Overall Diameter (A)(a) ............................................................................6.5 in / 165.8 mm
Cut Out Diameter (B)(b) ............................................................................. 5.6 in / 141 mm
Mounting Depth (C) ............................................................................. 2.0 in / 53 mm
Total Depth (D) .................................................................................. 2.4 in / 59.7 mm
C
*We show sensitivity in both 2.83V/1m and 1W/1m for the most helpful comparison. Most amps work by
delivering voltage, not a fixed wattage. Since 2.83 V equals 1 W into an 8 Ω speaker but 2 W into a 4 Ω speaker,
this gives you a reliable way to compare speakers, no matter the impedance.
Speaker Music Power
5
Qes 0.818
Qms 2.64
Qts 0.624
Fs 114.7 Hz
Vas 6.98 L
mms 7.66 g
Cms 0.00025 m/N
Rms 2.09 Ns/m
Re 3.2 Ω
Bl 4.65 T·m
le 0.167 mH
sd 0.0141 m2
XmaX 0.1 in / 2.5 mm (one way)
sensitivity
93.1 @ 1W/1m
96.1 @ 2.83V/1m
TS Parameters
Below are the TS parameters related to the EPICPRO6S midrange driver. The
parameters can be used to plot and design specific enclosures for the driver if
required.
Frequency Response Graph
The frequency response graph below details the bandwidth in which the
EPICPRO6S operates. This graph will help you determine the crossover set-
tings for your midrange drivers on your amplifier, as well as their integration
with additional tweeters and subwoofers in your system.
EPICPRO6S Specifications Continued
6
User Guide
Specifications - EPICPRO6X
a
b
B
A
D
Epic Series Speakers
EPIC6X
6.5” / Midrange / 4Ω
C
Speaker Model ......................................................................................................EPICPRO6X
Speaker size ....................................................................................................... 6.5" (165 mm)
DC Resistance (Re)......................................................................................................3.2 ohms
Voice Coil ......................................................................................................... 1.2 in / 30.5 mm
System Frequency Response .............................................................120 Hz to 12000 Hz
Sensitivity* ............................................................................................... 94.8 dB @ 1 W / 1 m
..................................................................................................................97.8 dB @ 2.83 V / 1 m
Magnet Weight .................................................................................................... 30 oz / 850 g
Magnet Dimensions .......................................4.72 x 1.77 x 0.79 in / 120 x 45 x 20 mm
The power handling of the EPICPRO6X is determined by the crossover points
at which the driver is used.
Please see below to determine the crossover points at which you will operate
and the power handling capabilities.
1. Enhanced bass/midbass – 100 Hz HPF, 12 dB slope, 120 W RMS
2. Warm midbass, high volume – 150 Hz HPF, 12 dB slope, 150 W RMS
3. Powerful midrange, max volume – 200 Hz HPF, 12 dB slope, 200 W RMS
Dimensions
Overall Diameter (A)(a) ...............................................................................6.7 in / 170 mm
Cut Out Diameter (B)(b) ...........................................................................5.9 in / 149.7 mm
Mounting Depth (C) ....................................................................................... 3.0 in / 77 mm
Total Depth (D) ............................................................................................. .3.3 in / 84.1 mm
Speaker Music Power
*We show sensitivity in both 2.83V/1m and 1W/1m for the most helpful comparison. Most amps work by
delivering voltage, not a fixed wattage. Since 2.83 V equals 1 W into an 8 Ω speaker but 2 W into a 4 Ω speaker,
this gives you a reliable way to compare speakers, no matter the impedance.
200100 300
RMSMIN MAX
7
Frequency Response Graph
The frequency response graph below details the bandwidth in which the
EPICPRO6X operates. This graph will help you determine the crossover set-
tings for your midrange drivers on your amplifier, as well as their integration
with additional tweeters and subwoofers in your system.
TS Parameters
Below are the TS parameters related to the EPICPRO6X midrange driver. The
parameters can be used to plot and design specific enclosures for the driver if
required.
Qes 0.641
Qms 3.27
Qts 0.536
Fs 131.3 Hz
Vas 5.40 L
mms 9.52 g
Cms 0.00015 m/N
Rms 2.40 Ns/m
Re 3.2 Ω
Bl 6.26 T·m
le 0.143 mH
sd 0.0158 m2
XmaX 3 mm (one way)
sensitivity
94.8 @ 1W/1m
97.8 @ 2.83V/1m
EPICPRO6X Specifications Continued
8
User Guide
Specifications - EPICPRO8X
a
b
B
A
D
C
Speaker Music Power
Speaker Model ......................................................................................................EPICPRO8X
Speaker size ........................................................................................................... 8" (200 mm)
DC Resistance (Re)......................................................................................................3.2 ohms
Voice Coil ............................................................................................................1.5 in. (38 mm)
System Frequency Response ............................................................... 80 Hz to 12000 Hz
Sensitivity* ............................................................................................... 96.2 dB @ 1 W / 1 m
..................................................................................................................99.2 dB @ 2.83 V / 1 m
Magnet Weight .................................................................................................... 32 oz / 907 g
Magnet Dimensions .......................................4.96 x 1.77 x 0.79 in / 126 x 45 x 20 mm
The power handling of the EPICPRO6X is determined by the crossover points
at which the driver is used.
Please see below to determine the crossover points at which you will operate
and the power handling capabilities.
1. Enhanced bass/midbass – 80 Hz HPF, 12 dB slope, 175 W RMS
2. Warm midbass, high volume – 150 Hz HPF, 12 dB slope, 225 W RMS
3. Powerful midrange, max volume – 200 Hz HPF, 12 dB slope, 250 W RMS
Dimensions
Overall Diameter (A)(a) ...............................................................................8.2 in / 208 mm
Cut Out Diameter (B)(b) ...........................................................................7.3 in / 186.6 mm
Mounting Depth (C) ................................................................................... 3.3 in / 84.5 mm
Total Depth (D) ............................................................................................. .3.3 in / 92.2 mm
*We show sensitivity in both 2.83V/1m and 1W/1m for the most helpful comparison. Most amps work by
delivering voltage, not a fixed wattage. Since 2.83 V equals 1 W into an 8 Ω speaker but 2 W into a 4 Ω speaker,
this gives you a reliable way to compare speakers, no matter the impedance.
250125 350
RMSMIN MAX
9
Frequency Response Graph
The frequency response graph below details the bandwidth in which the
EPICPRO8X operates. This graph will help you determine the crossover set-
tings for your midrange drivers on your amplifier, as well as their integration
with additional tweeters and subwoofers in your system.
TS Parameters
Below are the TS parameters related to the EPICPRO8X midrange driver. The
parameters can be used to plot and design specific enclosures for the driver if
required.
Qes 0.490
Qms 3.47
Qts 0.430
Fs 91.8 Hz
Vas 16.41 L
mms 14.79 g
Cms 0.0002 m/N
Rms 2.46 Ns/m
Re 3.2 Ω
Bl 7.46 T·m
le 0.112 mH
sd 0.0241 m2
XmaX 3 mm (one way)
sensitivity
96.2 @ 1W/1m
99.2 @ 2.83V/1m
EPICPRO8X Specifications Continued
10
User Guide
<!doctype html>
<html>
<head>
<title></title>
</head>
<body>
<p> </p>
<div class="element" style="border-left: 1px solid #CACFD6; border-right: 1px solid #CACFD6; border-top: 1px solid #CBD4C2; color: #273C2C; border-bottom: 1px solid #CACFD6; line-height: 45px">
<div class="container" style="padding: 40px 0 40px 0">
<div class="col-12 col-md-12">
<h1 style="text-align: center"> </h1>
<img alt="" class="mx-auto d-block img-fluid" src="https://i.postimg.cc/66ktFDD1/CROWNCUSTOMSLOGO.png" /></div>
</div>
</div>
<p> </p>
<div style="border-left: 1px solid #CACFD6; border-right: 1px solid #CACFD6; line-height: 25px">
<div class="container" style="padding-bottom: 20px; padding-top: 50px">
<div class="row">
<div class="col-12 col-md-6" style="padding-bottom: 40px"><img alt="" class="mx-auto d-block img-fluid" src="https://i.postimg.cc/8cDK8FLz/ZDAP-VAG1.jpg" /></div>
<div class="col-12 col-md-6">
<div typeof="Product" vocab="https://schema.org/">
<h1 itemprop="name">ZDAP-VAG1 Plug & Play DSP Power-Up Kit for Audi/Seat/Volkswagen vehicles from 2010 – Up</h1>
<p> </p>
<p>The ZDAP-VAG1 DSP Power Up Kit combines superior technology with user-friendly features, delivering an unparalleled audio upgrade. Whether you’re a casual listener or an audiophile, this kit provides the tools to achieve the perfect sound. Experience your music like never before—warmer, richer, and more dynamic.</p>
<p> </p>
<p>Transform your vehicle’s audio experience with the ZDAP-VAG1 DSP Power Up Kit, engineered to deliver exceptional sound quality. This plug-and-play kit includes a powerful 4x70W RMS Class A/B DSP Amplifier and all the necessary premium-quality harnesses for seamless installation and maximum performance. No vehicle modifications are required, plug it in and enjoy an elevated listening experience.</p>
<p>The <strong>ZDA4.8</strong> DSP Amplifier redefines in-car sound quality at this price point, outshining the standard factory-installed amplifiers. Unlike the typical Class D technology found in similar products, the ZDA4.8 employs Class A/B technology, delivering a warmer, more natural sound that brings your music to life. Even without DSP adjustments, the sound quality is significantly enhanced. However, the built-in DSP takes it further, allowing you to fine-tune your vehicle’s audio system to suit your preferences, no matter your music taste.</p>
<p><a href="https://phoenixgold-eu.com/wp-content/uploads/2024/11/connectors.png" rel="prettyPhoto[slideshow]"><img alt="connectors" data-src="https://phoenixgold-eu.com/wp-content/uploads/2024/11/connectors.png" data-was-processed="true" decoding="async" height="238" src="https://phoenixgold-eu.com/wp-content/uploads/2024/11/connectors.png" width="176" /></a></p>
<p> </p>
<p><strong>ZDC- and ZDT- Harness Benefits</strong></p>
<p>The ZDT- harness connects seamlessly behind the OEM head unit without cutting any wires, providing reliable power, clear signal transfer, and reduced noise thanks to its twisted cables and oversized power and ground wires.</p>
<p>The ZDC- harness extends this connection to the ZDA4.8 DSP Amplifier under the front seat, ensuring a clean installation and enhanced audio performance. Together, they deliver efficient integration and exceptional sound quality.</p>
<p> </p>
<p><b>Fitment</b><br />
The ZDAP-VAG1 is designed specifically for Audi, Seat and Volkswagen vehicles from 2010 onward. For a detailed list of compatible models, refer to our Vehicle Application List. </p>
<p><strong>OIS – OEM Impedance Simulation</strong><br />
The <strong>ZDA4.8</strong> is equipped with OEM Impedance Simulation (OIS), ensuring compatibility with modern head units and amplifiers. By simulating speaker impedance, it maintains the functionality of your vehicle’s OEM head unit, preventing potential issues with plug-and-play installations.</p>
<p><strong>Input Priority</strong><br />
The Input Priority feature ensures effortless integration with your vehicle’s OEM head unit. You can use low-level inputs or digital sources such as Bluetooth, Optical, or Coaxial, without losing vital system sounds like parking sensors, alerts, and radio signals. For instance, if your vehicle has a high-pass filter that limits bass output, you can bypass this limitation by streaming audio directly to the DSP via Bluetooth while maintaining full OEM functionality.</p>
<p><strong>DSP Outputs</strong><br />
The <strong>ZDA4.8</strong> doesn’t stop at upgrading your system—it also enables expansion. With four free DSP-configurable RCA outputs (<strong>Channels 5-8</strong>), you can connect additional amplifiers, such as a subwoofer amp, and fully optimize them using the DSP software. Delay settings, filters, and equalization options ensure top-tier performance for your additional components.</p>
<p> </p>
<p><a href="https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen.jpg" rel="prettyPhoto[slideshow]"><img alt="" data-sizes="auto, (max-width: 639px) 100vw, 639px" data-src="https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen.jpg" data-srcset="https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen.jpg 639w, https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen-300x169.jpg 300w, https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen-600x337.jpg 600w" data-was-processed="true" decoding="async" height="359" sizes="auto, (max-width: 639px) 100vw, 639px" src="https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen.jpg" srcset="https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen.jpg 639w, https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen-300x169.jpg 300w, https://phoenixgold-eu.com/wp-content/uploads/2024/11/ZDA-DSP-SoftwareScreen-600x337.jpg 600w" width="639" /></a></p>
<p><strong>Software</strong></p>
<p>Take control of your sound system with the free, user-friendly PC software (compatible with Windows 10 and 11). Connect via the included USB-B cable and unlock a suite of powerful tuning tools:</p>
<ul>
<li>31-Band Parametric EQ (PEQ) for precise frequency adjustments</li>
<li>Choose filter types (Bessel, Butterworth, Linkwitz-Riley) with adjustable slopes from -6dB to -48dB.</li>
<li>Time alignment with a built-in delay calculator</li>
<li>Fully custom channel routing</li>
<li>Custom link options (Copy or Relate)With these advanced features, you can tune your sound system to your preferences.</li>
</ul>
</div>
</div>
</div>
</div>
</div>
<div class="element" style="border-left: 1px solid #CACFD6; border-right: 1px solid #CACFD6; border-top: 1px solid #CACFD6; color: #273C2C; line-height: 25px">
<div class="container" style="padding: 40px 0 40px 0">
<div class="col-12 col-md-12">
<h2 style="line-height: 45px"> </h2>
<h2 style="line-height: 45px"><span style="line-height:45px"><font face="Arial"><font style="color: #273C2C">Specification & Fitment</font></font></span></h2>
<table width="600">
<thead>
<tr>
<th colspan="2">Hardware Specifications</th>
</tr>
</thead>
<tbody>
<tr>
<td>Product:</td>
<td>ZDA4.8</td>
</tr>
<tr>
<td>Type:</td>
<td>DSP Amplifier</td>
</tr>
<tr>
<td>Amplifier Class:</td>
<td>A/B</td>
</tr>
<tr>
<td>Amplified Channels:</td>
<td>4</td>
</tr>
<tr>
<td>DSP Channels:</td>
<td>8</td>
</tr>
<tr>
<td>Frequency Response (-3dB):</td>
<td>15Hz ~ 23kHz</td>
</tr>
<tr>
<td>MAX Power Rating:</td>
<td>560W</td>
</tr>
<tr>
<td>RMS Power Rating (2Ω):</td>
<td>N/A</td>
</tr>
<tr>
<td>RMS Power Rating (4Ω):</td>
<td>4 x 70W</td>
</tr>
<tr>
<td>RCA Voltage Output:</td>
<td>4V</td>
</tr>
<tr>
<td>DAC:</td>
<td>Burr Brown PCM1681</td>
</tr>
<tr>
<td>DSP Resolution:</td>
<td>24 Bit</td>
</tr>
<tr>
<td>Sampling Rate:</td>
<td>48kHz</td>
</tr>
<tr>
<td>SNR (Analogue/Digital Input):</td>
<td>-90dB</td>
</tr>
<tr>
<td>THD:</td>
<td>0.1%</td>
</tr>
<tr>
<td>Crosstalk:</td>
<td>-60dB</td>
</tr>
<tr>
<td>Damping Factor:</td>
<td>120</td>
</tr>
<tr>
<td>High-Level Input:</td>
<td>Yes</td>
</tr>
<tr>
<td>Auto Turn-On:</td>
<td>Yes</td>
</tr>
<tr>
<td>Input Sensitivity (High-Level):</td>
<td>0.2V – 20V</td>
</tr>
<tr>
<td>Input Sensitivity (Low-Level):</td>
<td>0.2V – 5V</td>
</tr>
<tr>
<td>Operating Voltage:</td>
<td>9V – 16V</td>
</tr>
<tr>
<td>Start-Stop Compatible:</td>
<td>Yes</td>
</tr>
<tr>
<td>Idle Current:</td>
<td>1.5A</td>
</tr>
<tr>
<td>Current Draw (MAX):</td>
<td>30A</td>
</tr>
<tr>
<td>Total Efficiency (4Ω):</td>
<td>60%</td>
</tr>
<tr>
<td>Power Terminal:</td>
<td>10mm²</td>
</tr>
<tr>
<td>Remote (Optional):</td>
<td>ZDAWCT</td>
</tr>
<tr>
<td>Low-Level Outputs (RCA):</td>
<td>8</td>
</tr>
<tr>
<td>Analogue Inputs:</td>
<td>6 x High-Level / 2 x Low-Level</td>
</tr>
<tr>
<td>Digital Inputs:</td>
<td>Bluetooth / Coaxial / USB / SPDIF</td>
</tr>
<tr>
<td>Remote Input:</td>
<td>Yes</td>
</tr>
<tr>
<td>Remote Output:</td>
<td>Yes</td>
</tr>
<tr>
<td>PC Connection Input:</td>
<td>USB-B</td>
</tr>
<tr>
<td>APP Control (Coming Soon):</td>
<td>Yes</td>
</tr>
</tbody>
</table>
<p> </p>
<table width="1000">
<tbody>
<tr>
<td width="88">Product No</td>
<td width="88">Make</td>
<td width="88">Model</td>
<td width="247">Year range</td>
<td width="88">Fitment</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A1</td>
<td>2010 – 2014 (8X)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A1</td>
<td>2015 – 2018 (8X) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A1</td>
<td>2019 – (GB)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A3</td>
<td>2012 – 2016 (8V)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A3</td>
<td>2016 – 2020 (8V) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A3</td>
<td>2020 – (8Y)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A4</td>
<td>2006 – 2012 (B8)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A4</td>
<td>2012 – 2015 (B8) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A4</td>
<td>2016 – 2018 (B9)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A4</td>
<td>2019 – (B9) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A5</td>
<td>2007 – 2011 (8T/8F)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A5</td>
<td>2011 – 2013 (8T/8F) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A5</td>
<td>2013 – 2016 (8T/8F) (2nd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A5</td>
<td>2017 – 2019 (F5)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A5</td>
<td>2019 – (F5) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A6</td>
<td>2011 – 2015 (C7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A6</td>
<td>2015 – 2018 (C7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A6</td>
<td>2018 – (C8)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>A7</td>
<td>2018 – (4K8)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q2</td>
<td>2016 – 2020 (GA)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q2</td>
<td>2021 – 2023 (GA) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q3</td>
<td>2011 – 2014 (8U)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q3</td>
<td>2015 – 2018 (8U) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q3</td>
<td>2018 – (F3)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q5</td>
<td>2008 – 2011 (8R)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q5</td>
<td>2012 – 2017 (8R) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q5</td>
<td>2017 – 2020 (FY)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Audi</td>
<td>Q5</td>
<td>2021 – (FY) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>MAN</td>
<td>TGE</td>
<td>2017 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Alhambra</td>
<td>2016 – 2020 (7N) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Arona</td>
<td>2017 – (KJ7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Ateca</td>
<td>2016 – 2020 (KH7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Ateca</td>
<td>2020 – (KH7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Ibiza</td>
<td>2017 – 2021 (6F)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Ibiza</td>
<td>2021 – (6F) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Leon</td>
<td>2012 – 2017 (5F)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Leon</td>
<td>2017 – 2020 (5F) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Leon</td>
<td>2020 – (KL1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Toledo</td>
<td>2012 – 2019 (KG)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Seat</td>
<td>Mii</td>
<td>2017 – 2021 (I) (Infotainment Update)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kodiaq</td>
<td>2017 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kodiaq</td>
<td>2021 – 2023 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kodiaq</td>
<td>2024 – (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Citigo</td>
<td>2017 – 2020 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Citigo-e iV</td>
<td>2019 – 2020 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Enyaq iV</td>
<td>2020 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Fabia</td>
<td>2014 – 2018 (NJ)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Fabia</td>
<td>2019 – 2021 (NJ) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Fabia</td>
<td>2021 – (PJ)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kamiq</td>
<td>2019 – 2023 (NW4)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kamiq</td>
<td>2023 – (NW4) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Karoq</td>
<td>2017 – 2021 (NU7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Karoq</td>
<td>2021 – (NU7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Octavia</td>
<td>2013 – 2017 (5E)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Octavia</td>
<td>2017 – 2019 (5E) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Octavia</td>
<td>2020 – 2024 (NX)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Octavia</td>
<td>2024 – (NX) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Superb</td>
<td>2015 – 2019 (3V)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Superb</td>
<td>2020 – 2023 (3V) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Superb</td>
<td>2024 – (3Y)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Scala</td>
<td>2019 – 2023 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Scala</td>
<td>2023 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Slavia</td>
<td>2022 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Skoda</td>
<td>Kushaq</td>
<td>2021 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Ateca</td>
<td>2018 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Ateca</td>
<td>2021 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Born</td>
<td>2021 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Formentor</td>
<td>2020 – 2024 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Formentor</td>
<td>2024 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Leon</td>
<td>2020 – 2024 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Leon</td>
<td>2024 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Cupra</td>
<td>Tavascan</td>
<td>2023 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Amarok</td>
<td>2016 – 2022 (2H) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Amarok</td>
<td>2022 – (NF)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Ameo</td>
<td>2016 – 2020 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Arteon</td>
<td>2017 – 2021 (3H7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Arteon</td>
<td>2021 – 2024 (3H7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Atlas</td>
<td>2017 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Atlas</td>
<td>2021 – 2023 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Atlas</td>
<td>2024 – (I) (2nd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Beetle</td>
<td>2016 – 2019 (A5) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Bora</td>
<td>2018 – 2022 (IV)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Bora</td>
<td>2022 – (IV) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Caddy</td>
<td>2015 – 2020 (2K) (2nd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Caddy</td>
<td>2020 – (SB)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>California</td>
<td>2015 – 2019 (T6)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>California</td>
<td>2019 – 2022 (T6.1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>California</td>
<td>2022 – (T7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Caravelle</td>
<td>2019 – 2024 (T6.1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Crafter</td>
<td>2017 – 2023 (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Crafter</td>
<td>2023 – (II) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>e-Tharu</td>
<td>2018 – 2023 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>e-up!</td>
<td>2013 – 2019 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>e-up!</td>
<td>2019 – 2023 (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Gol</td>
<td>2018 – 2022 (5U) (3rd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf</td>
<td>2012 – 2016 (VII)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf</td>
<td>2017 – 2020 (VII) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf</td>
<td>2020 – 2024 (VIII)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf</td>
<td>2024 – (VIII) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf Sportsvan</td>
<td>2014 – 2018 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Golf Sportsvan</td>
<td>2018 – 2020 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID. Buzz</td>
<td>2022 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID.3</td>
<td>2019 – 2023 (E11)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID.3</td>
<td>2023 – (E12)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID.4</td>
<td>2020 – (E21)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID.5</td>
<td>2022 – (E39)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>ID.7</td>
<td>2023 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Jetta</td>
<td>2018 – 2021 (A7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Jetta</td>
<td>2022 – (A7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Lamando</td>
<td>2014 – 2022 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Lamando</td>
<td>2022 – (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Lavida</td>
<td>2018 – 2022 (III)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Lavida</td>
<td>2022 – (III) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Magotan</td>
<td>2015 – 2019 (B8L)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Magotan</td>
<td>2020 – 2023 (B8L) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Magotan</td>
<td>2024 – (B9)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Multivan</td>
<td>2019 – 2022 (T6.1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Multivan</td>
<td>2022 – (T7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Nivus</td>
<td>2020 – (CS1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Passat</td>
<td>2014 – 2019 (B8)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Passat</td>
<td>2020 – 2023 (B8) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Passat</td>
<td>2023 – (B9)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Polo</td>
<td>2014 – 2017 (Mk5) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Polo</td>
<td>2017 – 2021 (Mk6)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Polo</td>
<td>2021 – (Mk6) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Polo Vivo</td>
<td>2018 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Sagitar</td>
<td>2019 – 2021 (A7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Sagitar</td>
<td>2022 – (A7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Saveiro</td>
<td>2018 – 2022 (5U) (3rd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Scirocco</td>
<td>2014 – 2017 (III) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Sharan</td>
<td>2016 – 2022 (7N) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>T-Cross</td>
<td>2019 – 2023 (C11)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>T-Cross</td>
<td>2023 – (C11) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>T-Roc</td>
<td>2017 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>T-Roc</td>
<td>2021 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tacqua</td>
<td>2019 – (C11)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Taigo</td>
<td>2021 – (CS1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Talagon</td>
<td>2021 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Taos</td>
<td>2020 – 2024 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Taos</td>
<td>2025 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tavendor</td>
<td>2022 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tayron</td>
<td>2018 – 2023 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tayron</td>
<td>2023 – 2024 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tayron</td>
<td>2024 – (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Teramont</td>
<td>2017 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Teramont</td>
<td>2021 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Teramont X</td>
<td>2019 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Teramont X</td>
<td>2021 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tharu</td>
<td>2018 – 2023 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tharu</td>
<td>2023 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tharu</td>
<td>2023 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan</td>
<td>2012 – 2015 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan</td>
<td>2016 – 2020 (II)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan</td>
<td>2020 – 2023 (II) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan</td>
<td>2024 – (III)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan Allspace</td>
<td>2017 – 2021 (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Tiguan Allspace</td>
<td>2021 – (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Touareg</td>
<td>2010 – 2015 (7P)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Touareg</td>
<td>2015 – 2018 (7P) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Touareg</td>
<td>2018 – 2023 (CR)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Touareg</td>
<td>2023 – (CR) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Touran</td>
<td>2015 – (5T)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Transporter</td>
<td>2015 – 2019 (T6)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Transporter</td>
<td>2019 – 2024 (T6.1)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td> </td>
<td> </td>
<td> </td>
<td> </td>
<td> </td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>UP!</td>
<td>2016 – 2023 (I) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Vento</td>
<td>2018 – 2021 (A7)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Vento</td>
<td>2022 – (A7) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Vento</td>
<td>2014 – 2019 (A05) (Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Vento</td>
<td>2019 – 2022 (A05) (2nd Facelift)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Viloran</td>
<td>2020 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Virtus</td>
<td>2018 – (I)</td>
<td>Basic Sound System</td>
</tr>
<tr>
<td>ZDAP-VAG1</td>
<td>Volkswagen</td>
<td>Voyage</td>
<td>2018 – 2022 (5U) (3rd Facelift)</td>
<td>Basic Sound System</td>
</tr>
</tbody>
</table>
</div>
</div>
</div>
<div style="border-left: 1px solid #CACFD6; border-right: 1px solid #CACFD6; border-bottom: 1px solid #CACFD6; border-top: 1px solid #CACFD6; color: #273C2C; line-height: 25px">
<div class="container" style="padding: 40px 0 40px 0">
<div class="col-12 col-md-12">
<h2 style="line-height: 45px"><img alt="" class="mx-auto d-block img-fluid" src="https://i.postimg.cc/nL4dqqtL/CROWN-CUSTOMS-BANNER.png" /></h2>
</div>
</div>
<div class="col-12 col-md-12 element" style="border-top: 1px solid #CACFD6; color: #273C2C; line-height: 25px">
<div class="container" style="padding: 20px 0 10px 0; font-size: 80%; text-align: center">
<p><font face="Arial" style="color: #273C2C">Free eBay listing template designed by <b>© dewiso.com</b>.</font></p>
</div>
</div>
</div>
</body>
<link href="https://dewiso.com/css/bootstrap.min.css" rel="stylesheet" />
<style type="text/css">.element{background-image:url("https://dewiso.com/images/f0f0f0_background.png");background-size:cover}
</style>
</html>
4Ω
4Ω
2-Speaker Installation: 4Ω Bridged
In this example, we are connecting two EPIC Pro 4Ω drivers to the EPICFOUR 4-channel amplifier in a bridged configuration.
Channels 1+2 and 3+4 are wired in bridge mode to the EPIC Pro speakers.
System Examples
11
4Ω
4Ω
4Ω
4Ω
4-Speaker Installation: 4Ω
In this example, we are connecting four EPIC Pro 4Ω drivers to the EPICBIGFOUR 4-channel amplifier.
Channels 1, 2, 3, and 4 are connected individually to the EPIC Pro speakers.
System Examples Continued
12
User Guide
2Ω
2Ω
2Ω
2Ω
System Examples Continued
8-Speaker installation: 2Ω
In this example, we are connecting eight EPIC Pro 4Ω drivers to the
EPICBIGFOUR 4-channel amplifier.
Channels 1, 2, 3, and 4 are each connected to a pair of EPIC Pro speakers wired
in series to deliver a 2Ω load.
See Page 13 for Speaker
wiring illustration
13
Speaker Wiring Configurations Midrange Installation
The illustrations below show how to configure your EPIC Pro audio speakers
for different impedance levels, ensuring optimal installation within your
system.
• First, determine where the speaker will be mounted. Next, make sure the area
has a flat surface for the speaker to mount.
• Check the mounting depth of the desired location (use pages 4/6/8 for
midrange mounting dimensions.)
• If the speaker will be mounted in a door, roll the windows up / down and lock
/ unlock the doors making sure there are no obstructions that the speaker
will hit.
• Using the cut out template, mark the location for the speaker to be mounted.
• With the tool of your choice cut out the marked hole" to "Using the tool of
your choice, cut out the marked hole.
• After the speaker has been wired, place the speaker into the hole. Use
supplied mounting hardware to keep speaker in place.
• Large speaker terminal = positive (+).
• Small speaker terminal = negative (-).
+
4Ω
+
2Ω
_
_
+
_
+
4Ω
_
+
_
+
_
_
+
+
_
Simple Installation Instructions
14
User Guide
The Warranty
Peace of Mind
In just the same way as walking into a room and seeing a big hairy spider on
the wall, people are scared of warranties. Lots of fine print. Months of waiting
around. Well, fear no more. This warranty is designed to make you rave about
AudioControl. It’s a warranty that looks out for you and your client, plus
helps you resist the temptation to have your friend Sparky, who’s “good with
electronics,” try to repair your AudioControl product. So go ahead, read this
warranty, then register the information at www.audiocontrol.com/product-
registration and include your comments.
Our warranty has conditional conditions! “Conditional” doesn’t mean anything
ominous. The Federal Trade Commission tells all manufacturers to use the
term to indicate that certain conditions have to be met before they’ll honor
the warranty. If you meet all of these conditions, AudioControl will, at its
discretion, repair or replace any AudioControl speaker products that exhibit
defects in materials and/or workmanship for one (1) year from the date you
bought it. We will repair or replace it, at our option, during that time.
Here are the conditional conditions:
1. You must fully register your purchase within 15 days of the purchase date
by going to the AudioControl product registration page at:
www.audiocontrol.com/product-registration
Failure to register your product will negate the warranty.
2. You need to hold on to your sales receipt! All warranty service requires
original sales receipt documentation. The warranty only applies to the
original purchaser from an authorized AudioControl dealer. Note: Products
purchased from unauthorized dealers are not covered under warranty.
3. The AudioControl speaker products must have originally been purchased
from an authorized AudioControl dealer. If an authorized AudioControl
dealer installs your AudioControl product, the warranty is extended to
two (2) years.
4. Our warranty covers AudioControl products that have been installed
according to the instructions in this manual.
5. You cannot let anyone who isn’t: (A) the AudioControl factory; or
(B) someone authorized in writing by AudioControl, service your
AudioControl product. If anyone other than (A), or (B) messes with your
AudioControl product, the warranty is void.
6. The warranty is void if the serial number is altered, defaced or removed,
or if your product has been used improperly. Now that may sound like a
big loophole, but here is what we mean by this: Unwarranted abuse is:
(A) physical damage (don’t use your product to pound in fence posts);
(B) improper connections (120 volts into the speaker terminals can fry
the poor thing). This is the best product we know how to build, but for
example, if you mount it to the front bumper of your car, drop it over
Niagara Falls, or use it for anchoring your boat, something will go wrong.
Assuming you conform to 1 through 6, and it really isn’t all that hard to do, we
get the option of fixing your product, or replacing it with a new one, at our
discretion.
In the event that your product is out of warranty or not covered under our
warranty, you may request to have any damage repaired at our normal “Out of
Warranty” repair cost.
15
Legalese
The warranty above is the only warranty issued by AudioControl. This warranty
gives you specific legal rights, and you may also have rights that vary from
state to state.
Promises of how well your AudioControl product will work are not implied by
this warranty. Other than what we’ve said we’ll do in this warranty, we have
no obligation, express or implied. We make no warranty of merchantability
or fitness for any particular purpose. Also neither we nor anyone else who
has been involved in the development or manufacture of the unit will have
any liability of any incidental, consequential, special or punitive damages,
including but not limited to any lost profits or damage to other parts of your
system by hooking up to the unit (whether the claim is one for breach of
warranty, negligence of other tort, or any other kind of claim). Some states do
not allow limitations of consequential damages.
And Now a Word from our Legal Department
For more information about this fine product, and for additional details of the
limited warranty and repair services, please visit www.audiocontrol.com
For technical questions, please visit www.audiocontrol.com/knowledge-base/
AudioControl – “a Stinger Company”
9620 Executive Center Dr N, Suite 200
St Petersburg, FL 33702
Support:
Phone: 425-777-7723
Email: [email protected]
©2025 AudioControl. All rights reserved.
As technology advances, AudioControl reserves the right to continuously change our
specifications, like our Pacific Northwest weather, although we are working on changing
that as well.
User Guide 915-044-0
The End ( We appreciate your patience)
Epic Series Speakers
EPIC6S
6.5” / Midrange / 4Ω
