LED BACKLIGHT TV / MONITOR
OPERATION MANUAL
Please choose your favourite page from the content.
If you want to close the operation manual, press the
(HOME) button.
Also, if you want to return to the previously displayed page,
press the
(Back) button.
Please scan the code below to access PDF E-Manual.
The networks of the internet charges will be applied.
ENGLISH | 中文(台灣) | 中文 | FRANÇAIS | PORTUGUÊS | INDONESIA | ภาษาไทย | TIẾNG VIỆT | ﻲﺑرﻋ | РУССКИЙ | O'ZBEK
>>
1. Get started
1-1. Introduction - Remote Control Unit
1-2. Introduction - Remote Control Unit
(Taiwan only)
1-3. Introduction - HOME screen
1-4. Initial setup
1-5. Software Updates
2. TV and Channel settings (TV tuner
models only)
2-1. How to tune the Analog Broadcast channels
2-1. How to tune the Digital Broadcast channels
2-1. Channel Management
2-1. Auto Channel Update (Antenna input only)
2-1. Channel Update Message (Antenna input only)
2-1. How to enable Subtitle
2-1. Teletext settings (Antenna input only)
2-2. Set the Audio Language (Antenna input only)
2-2. Set the Sound Track (Antenna input only)
2-2. Set the Audio Type (Antenna input only)
2-2. Set the Visually Impaired (Antenna input only)
2-2. How to change Audio output
2-3. How to enable EPG (Antenna input only)
2-3. Postal code (Indonesia only)
2-4. How to operate Parental Controls
2-5. How to set your device name
2-5. System Information
2-5. Screen
3. Connection/External Devices
3-1. Network and Internet setup
3-4. Chromecast-enabled devices
3-4. Audio Devices
3-5. Bluetooth setup
3-6. USB setup
4. Apps
4-1. Google Assistant
4-1. Google Account setting
4-2. Unique feature from SHARP
4-3. Tools screen setting
5. Picture settings
5-1. Picture Mode (Changing Pic. Quality)
5-1. Configuring Picture settings
5-2. Configure advanced Picture settings
5-2. HDR related settings
5-2. Unique Picture setting from SHARP
5-3. Input settings
6. Sound settings
6-1. Sound Style
6-1. Configuring Sound settings
6-1. Configure advanced Sound settings
6-2. Unique Sound setting from SHARP
7. Other
7-1. Sleep Timer
7-1. Picture Off
7-1. Switch Off Timer
7-1. Auto Sleep
7-1. Accessibility
7-1. Language
7-1. Storage
7-1. Energy saver
7-1. Restart
7-1. Factory reset
7-2. Power on behavior
7-2. Timer
7-2. Automatic date & time
7-2. Set date
7-2. Set time
7-2. Set time zone
7-2. Use 24-hour format
7-2. Ambient mode
7-2. Help & Feedback
8. Appendix
8-1. Troubleshooting
8-2. Troubleshooting - Error Message
8-3. Trademarks
8-3. Connecting RCA jack
Contents
EN Contents
>><<
Remote Control Unit
1
/ (POWER): Switch the TV power on or enter standby.
2 0-9: Set the channel.
3
(AD/MPX): Select the sound multiplex mode and audio description.
4
/ / / / / / : Operate media contents on TV and VOD
x (Video On Demand) service playback.
5 INPUT: Select an input source.
6
(YouTube): Display the YouTube screen.
7
(Apps): Open all Apps launcher.
Use the Type A remote control for all operations.
The Remote Control Unit illustration in this operation manual is for explanation purpose
and may vary slightly from the actual remote control unit depending on the selected
region.
Google Assistant is not available in certain languages and countries. Availability of
services varies by country and language.
8
(Google Assistant)
x Press the Google Assistant button on your remote to do more on your TV with your
x voice.
9
(Profile): Switch profile.
10
/ / / , ENTER/OK: Select a desired item on the screen.
11
(Back): Return to the previous screen.
12
(HOME): Display the HOME screen.
13
(Watchlist): To add a program to your watchlist.
14 VOL+/-: Set the volume.
15
(Mute): Mute the sound. Mute can be cancelled by pressing VOL +/-
xx or
(Mute).
16
, , , : The coloured buttons are correspondingly used to select the
xx coloured items on the screen.
17
(Subtitle): Switch subtitle languages on/off.
18
(Teletext): Select the teletext mode.
19 INFO: Display the programme information (Antenna input only).
20
(TOOLS): Display the Tools screen.
xx You can access menu screen by pressing TOOLS while watching TV in "Live TV" apps.
21
(prime video): Display the prime video screen.
22
(SHARP COCORO ALBUM): To view the picture where SHARP COCORO ALBUM
xx using AI recognize faces and organize memories automatically.
23
(NETFLIX): Display the NETFLIX screen.
xx If you press the NETFLIX button when the TV is turned off, the TV turns on and the
xx NETFLIX screen is displayed.
24
(Dashboard): Access the settings (direct or through the dashboard in Google TV)
xx from any place in the system.
25
(Live Guide): Open Live TV EPG.
26 CH
/ : Select the channel.
Introduction
Type B
Type A
EN 1-1
>><<
Remote Control Unit (Taiwan only)
1
/ (
電
源
) (POWER): Switch the TV power on or enter standby.
2 0-9: Set the channel.
3
(
聲
音
) (AUDIO): Selects the audio mode during multichannel audio broadcasts.
4
/ / / / / / : Operate media contents on TV and VOD
x (Video On Demand) service playback.
5
輸
入
(INPUT): Select an input source.
6
(YouTube): Display the YouTube screen.
7
(Apps): Open all Apps launcher.
Use the Type A remote control for all operations.
The Remote Control Unit illustration in this operation manual is for explanation purpose
and may vary slightly from the actual remote control unit depending on the selected
region.
Google Assistant is not available in certain languages and countries. Availability of
services varies by country and language.
8
(Google Assistant)
x Press the Google Assistant button on your remote to do more on your TV with your
x voice.
9
(Profile): Switch profile.
10
/ / / ,
確
定
(ENTER) / OK: Select a desired item on the screen.
11
(Back): Return to the previous screen.
12
(HOME): Display the HOME screen.
13
(Watchlist): To add a program to your watchlist.
14
音
量
+/- (VOL+/-): Set the volume.
15
(Mute): Mute the sound. Mute can be cancelled by pressing
音
量
+/- (VOL+/-)
xx or
(Mute).
16
(R), (G), (Y), (B): The coloured buttons are correspondingly used to
xx select the coloured items on the screen.
17
字
幕
(Subtitle): Switch subtitle languages on / off.
18
定
時
關
機
(SLEEP): Set the sleep timer.
19
資
訊
(INFO): Display the programme information (Antenna input only).
20
(TOOLS): Display the Tools screen.
xx You can access menu screen by pressing
工
具
(TOOLS) while watching TV in "Live TV"
xx apps.
21
(prime video): Display the prime video screen.
22
(COCORO VISION): Display the COCORO VISION screen.
23
(NETFLIX): Display the NETFLIX screen.
xx If you press the NETFLIX button when the TV is turned off, the TV turns on and the
xx NETFLIX screen is displayed.
24
(Dashboard): Access the settings (direct or through the dashboard in Google TV)
xx from any place in the system.
25
(Live Guide): Open Live TV EPG.
26
頻
道
/ (CH / ): Select the channel.
Introduction
Type A
Type B
EN 1-2
>><<
HOME screen
Connect to
(HOME) for apps, games, movies and more.
Example
NOTE
The on-screen displays in this manual are for explanation purposes and
may vary slightly from the actual display.
Google TV™ selections (Search / For you / Movies / Shows /
Apps / Library).
The contents of the programmes that user is watching or
watched are displayed here.
Among the applications installed on the TV, the icons for the
favourite applications are shown inside here. (Favourite
applications can be added / deleted / changes its order by
users.)
User Google Account.
Introduction
EN 1-3
>><<
Auto installation
When the TV is powered on for the first time after purchase, the initial auto
installation wizard appears. Follow the menus and make the necessary
settings one after another.
Confirm the following before turning on the power
Is the antenna cable connected?
Is the AC cord plugged in?
1 Press
/ POWER
on the TV.
The initial auto installation wizard appears.
2 You have to follow the procedure shown to pair the remote control unit
x with the TV.
3 Setting the OSD language.
x Press
/ to select the desired language, and then press ENTER/OK.
4 Setting the region or country.
x Press
/ to select your region or country, and then press ENTER/OK.
NOTE
Digital broadcasting (DTV) cannot be viewed in the area where digital
broadcasting is not yet launched. (TV tuner models only)
DTV concerned menu may not displayed in some region.
5 Press
/ to select "Set up Google TV" or "Set up basic TV".
If select "Set up Google TV", the screen will jump to step 6.
If select "Set up basic TV", after select your Wi-Fi network, the screen
will jump to step 8.
6 Press
/ to select your Wi-Fi network.
7 Press
/ to sign into your Google Account.
8 Press
/ to select "Accept", "Terms of Service", "Play Terms of
xx Service" and "Privacy Policy".
9 Select "Accept" to confirm your selection of these Google services
x settings.
For "Set up basic TV", after select "Accept", the screen will jump to
step 13.
10 Select "Continue" for Google Assistant settings.
11 Select "Allow" or "No thanks" for search across all your TV apps.
12 Select "Confirm" to choose your subscriptions.
13 Select "OK" for Energy Saving Tips.
14 Select "Accept" for Network Privacy Policy.
15 Press
/ to select "Agree to Terms of Use and Continue", "View
SHARP Terms Of Use" or "View SHARP Privacy Policy".
16 Please set a password.
17 Select TV mode.
xx Press
/ to select where you will use this TV, and then press
xx ENTER/OK.
Home:
"Home" mode is optimized for efficient energy usage for home use.
If you plan to use this TV at home, please select "Home".
Retail:
"Retail" mode is optimized for store demo with fixed settings.
"Retail" mode is for store demo only and setting are not saved. Please
select "Retail" to proceed.
NOTE
Retail: A demonstration image will be displayed after initial auto
installation is completed. If you have chosen "Retail" by mistake, go to
"
(Dashboard)" > "Settings" > "System" > "Store Mode" > "Continue"
> "Off".
18 Press
/ to select "Off" or "On" to enable Chromecast built-in™.
19 Press
/ to select "Only digital channels", "Only analogue channels",
"Digital and analogue channels" or "Skip Scan" to start channel scan.
(TV tuner models only)
20 The description of Nexflix screen will appear.
Select "Next" to finish Netflix setup procedure.
Select "Setup Network" if Wi-Fi network is not connected.
21 Press ENTER/OK to start exploring your Google TV .
Initial setup
EN 1-4
>><<
To search for new software updates via Over-The-Air
Press "
(Dashboard)".
Select "Settings" > "System" > "About" > "System update".
NOTE
Make sure your TV is connected to the internet when performing software
updates via OTA.
After finished downloading, please allow some time to apply the installed
updates.
During installation, please do not perform any operations, including power
off or unplug your TV.
Software updates performance is depending on internet connection.
OAD (TV tuner models only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "OAD".
This function is for automatically download the data for the version update
software over digital broadcasts when the "Auto Download" is set to "On".
To download, follow the instructions when the download message appears
during a digital broadcast.
Once the software upgrade is done, the TV will automatically go to
standby state with Red LED.
CAUTION
Do not disconnect the AC cord when the software upgrade is in
progress, as this may cause the upgrade to fail. If problem arises ask
a qualified service personnel before the software upgrade period
expires.
Software License
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Open Source Licenses".
You can read the software licenses in the on-screen display menu.
Software composition
The software included in this product is comprised of various software
components whose individual copyrights are held by SHARP or by third
parties.
Software Version
Press "
(Dashboard)".
Select "Settings" > "System" > "About" > "Software Version".
You can check the current version of the software on the screen.
Software Updates
EN 1-5
>><<
How to tune the Analog Broadcast channels
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Inputs" > "Channels" >
"Analog".
You can tune Analog broadcast channels manually.
Select from the following available settings.
Channel Scan / Update Scan / Analog Manual Scan
How to tune the Digital Broadcast channels
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Inputs" > "Channels" >
"Antenna".
In areas where DTV can be viewed, you can tune Digital broadcast channels
manually.
Select from the following available settings.
Channel Scan / Update Scan / Single RF Scan / Manual Service Update /
LCN / Channel Scan Type / Channel Store Type
When you view DTV, select Antenna input from the input menu.
Channel Management
Press "
(TOOLS)".
Select "Channels" > "Channel Management".
Use this menu to set up a channel individually.
Select from the following available settings.
Channel Skip / Channel Swap / Channel Move / Channel Edit /
Channel Delete / Clear Channel List
Auto Channel Update (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Inputs" > "Channels" >
"Auto Channel Update".
Select from the following available settings.
On / Off
Channel Update Message (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Inputs" > "Channels" >
"Channel Update Message".
Select from the following available settings.
On / Off
How to enable Subtitle
Subtitle
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Subtitle".
You can display subtitles for the hearing impaired in the Teletext broadcast if
the subtitle languages are available.
Analog Subtitle / Digital Subtitle / Subtitle Tracks / Digital Subtitle
Language / 2nd Digital Subtitle Language / Subtitle Type
Teletext settings (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Teletext".
If you set the language of the initial page (this page is displayed for the first
time after pressing
) for teletext in Antenna input mode, it will start from
the selected language page.
Select from the following available settings.
Digital Teletext Language / Decoding Page Language
NOTE
This function is available for teletext in Antenna input mode. This is not
available for teletext in ATV or external input mode.
If the initial teletext page of the selected language in this function is not
included in a received broadcast, the default initial page will be displayed.
TV and Channel settings (TV tuner models only)
EN 2-1
>><<
Set the Audio Language (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Audio" > "Audio Language".
You can set primary language.
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Audio" > "2nd Audio
Language".
You can set secondary language.
NOTE
If there are multiple languages in the broadcast, it will be played in the
order of the first language and the second language. If the language
specified by these is not broadcast, it will be played in the first language of
the broadcast.
Set the Sound Tracks (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Audio" > "Sound Tracks".
You can choose from the multilanguages options based on your preferences.
NOTE
Selectable item is depend on broadcast signal.
Set the Audio Type (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Audio" > "Audio Type".
Select from the following available settings.
Normal / Audio Description / Spoken Subtitle / Hearing Impaired / Audio
Description and Spoken Subtitles
Set the Visually Impaired (Antenna input only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Audio" > "Visually Impaired".
Activate the audio guide for the visually impaired.
NOTE
Selectable item is depend on broadcast signal.
How to change Audio output
If multi sound are received, each time you press
(AD/MPX) the mode
switches.
When watching Digital broadcasting
You can select audio signal when watching a multi-language or stereo
program.
The sound mode screen disappears in six seconds.
Selectable items vary depending on the received broadcasts.
The audio description sound is selected depending on the main audio.
When watching Analog broadcasting
You can select audio signal when watching a multi-language or stereo
program.
In the NICAM TV broadcasts
Stereo mode
Nicam Stereo
Mono
Bilingual mode
Nicam Dual1
Nicam Dual2
Mono
Monaural mode
Nicam Mono
Mono
In the TV mode of A2 TV broadcasts
Stereo mode
Stereo
Mono
Bilingual mode
Dual1
Dual2
Monaural mode
Mono
TV and Channel settings (TV tuner models only)
EN 2-2
>><<
How to enable EPG (Antenna input only)
EPG
What is an EPG?
An "EPG (Electronic Programme Guide)" is a programme schedule, which is
displayed on the TV screen. The EPG is broadcasted together with DTV. The
TV screen shows the EPG when the viewer presses
(Live Guide) on the
remote control, provided that the TV is receiving the digital broadcasting
signal. The EPG enables you to search for a programme, do timer view the
programme schedule in detail.
Basic Operation
Display the EPG screen
Press (Live Guide).
Press / to select the desired programme.
Press / to display programme in the next time span.
Close the EPG screen
Press (Live Guide) again or (Back) to exit.
NOTE
EPG will be not displayed when DTV is not yet tuned after AC on.
Postal Code (Indonesia only)
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Postal Code".
This function enable you to select your local postal code.
NOTE
"Postal Code" will be appear only when region "Indonesia" is selected.
TV and Channel settings (TV tuner models only)
EN 2-3
>><<
How to operate Parental Controls
Press "
(TOOLS)".
Select "TV options" > "Parental Controls".
This function allows TV channels to be restricted. It prevents children from
watching violent or sexual scenes that may be considered inappropriate.
If you have already set the password, enter it here.
Channels Blocked
You can block the viewing of any selected channel.
Inputs Blocked
You can block the viewing of any selected input.
Change PIN
You can set and change the Password by using 0-9.
NOTE
As a precautionary measure, make a note of your Password and keep it in
a familiar place.
PIN input is required when executing "Parental Controls" screen. The
default PIN is "1234".
Program Restrictions
Used to enable or disable the parental control function. This function will
not be selectable from the menu if you do not first configure your
password.
Ratings
Singapore
None: Cancel the blocking.
G: Suitable for all ages.
PG: Suitable for all but parents should guide their young.
PG13: Suitable for persons aged 13 and above but parental guidance is
advised for children below 13.
NC16: Suitable for persons aged 16 and above.
M18: Suitable for persons aged 18 and above.
R21: Suitable for adults aged 21 and above.
Thailand
None: Cancel the blocking.
P: Suitable for children kid 3-6 years.
C: Suitable for children kid 6-12 years.
G: Suitable for general audience.
PG13: Suitable for people aged 13 and above.
PG18: Suitable for people aged 18 and above. And parental guidance for
children under 18.
R: Suitable for adult.
NOTE
The rating selection may vary slightly different for regions other than
Singapore and Thailand.
TV and Channel settings (TV tuner models only)
EN 2-4
>><<
How to set your device name
Press "
(TOOLS)".
Select "TV options" > "Settings" > "System" > "About" > "Device name".
Set the name of the TV displayed.
Use the software keyboard when you need to input text at device name
setting.
System Information
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "System Information".
Check for system updates and view various information of signal.
Screen
Press "
(TOOLS)".
Select "TV options" > "Screen".
This function changes the screen size.
The Screen menu varies depending on the input source.
For Standard-Definition signals
Automatic: Keeps the original aspect ratio based on source information
and enlarge the picture as much as possible.
Full: For 16:9 squeeze pictures.
Super zoom: Removes the black bars on the side of 4:3 broadcasts. There
is minimal distortion.
Unscaled: Detects the resolution of the signal and displays an image with
the same number of pixels on the screen.
4:3: Keeps the original aspect ratio in a full screen display.
Movie expand 14:9: For 14:9 letterbox pictures. Bars may appear on the
top and bottom with some programmes.
Movie expand 16:9: For 16:9 letterbox pictures. Bars may appear on the
top and bottom with some programmes.
NOTE
Some items do not appear depending on the type of received signal.
TV and Channel settings
EN 2-5
>><<
Network and Internet setup
Connecting to the Internet
To configure the network settings in order to enjoy streaming content and
internet applications.
NOTE
When an Internet connection is made, LAN and wireless connection
cannot be used at the same time. Use only one of the connection types.
Using Wi-Fi
This TV is equipped with a wireless LAN function.
For a wireless LAN connection, you must use wireless setup to connect the
access point and TV.
Press "
(Dashboard)".
Select "Settings" > "Network & Internet" > "Wi-Fi" to select a network you
want to connect to and set the password.
NOTE
Standby power consumption will be increase when Wow (Wake on
wireless network) is turned ON.
Using LAN
Using a LAN cable (commercially available) to connect the LAN terminal on
the TV to your broadband router (commercially available).
How to connect:
1 Switch on the router (commercially available).
Refer to the router's operation manual for switching on.
2 Connect the LAN terminal on the TV to the router (commercially available)
with a LAN cable (commercially available).
3 Press "
(Dashboard)".
Select "Settings" > "Network & Internet" > "Wake configs".
NOTE
Standby power consumption will be increase when Wol (Wake on LAN) is
turned ON.
Connection/External Devices
EN 3-1
>><<
Network and Internet setup (Continue)
NOTE
This TV has a built-in wireless LAN function. Using a separate wireless
USB LAN adapter may result in radio communications that do not comply
with regulations on radio communications. Therefore, do not use a
separate wireless LAN adapter.
A wireless LAN connection and performance cannot be guaranteed for all
residential environments. In the following cases, the wireless LAN signal
may be poor or drop, or the connection speed may become slower.
- When used in buildings made with concrete, reinforced steel, or metal
- When placed near objects that obstruct the signal
- When used with other wireless devices that emit the same frequency
- When used in the vicinity of microwave ovens and other devices that
emit a magnetic field, electrostatic charge, or electromagnetic interference
When there is significant interference in the 2.4-GHz frequency (such as
from other wireless LAN devices, Bluetooth
®
devices, 2.4-GHz cordless
telephones, and microwave ovens), it is recommended that you use a
wireless LAN router/access point that supports IEEE802.11ac (5 GHz)
and set the access point to transmit at 5 GHz. For setup details, see the
operation manual of your access point.
Operations cannot be guaranteed when used with access points that do
not have Wi-Fi
®
certification.
A wireless LAN router/access point is required to connect the TV to the
Internet using a wireless LAN. See the operation manual of your access
point for setup.
If your access point is set to a stealth mode (that prevents detection by
other devices), you may not be able to establish a connection. In this
case, disable the stealth mode on the access point.
A stable connection speed is required to play back streaming content. Use
LAN connection if the wireless LAN speed is unstable.
Before transferring to a third party or disposal, be sure to initialise the
wireless LAN settings.
Please follow the legislation in your region when using the wireless LAN
outdoors.
If you have failed to connect to the Internet in the above operation, then
an error message will appear. In this case, press
(Dashboard) to exit
from the connected TV feature to make changes to the network settings.
If you still cannot connect to the Internet, please consult your Internet
service provider or telephone company.
You cannot configure the settings from " (Dashboard)" > "Settings" >
"Network & Internet" while using an application. If you must configure your
"Network" settings, press the
(Dashboard) key to exit the function.
Connection/External Devices
EN 3-2
>><<
Network and Internet setup (Continue)
NOTE
DISCLAIMERS
This SHARP device facilitates the access to content and services provided
by third parties. The content and services accessible via this device belong
to and may be proprietary to third parties. Therefore, any use of such third
party content and services must be in accordance with any authorization or
terms of use provided by such content or service provider. SHARP shall not
be liable to you or any third party for your failure to abide by such
authorization or terms of use. Unless otherwise specifically authorized by
the applicable content or service provider, all third party content and
services provided are for personal and non-commercial use; you may not
modify, copy, distribute, transmit, display, perform, reproduce, upload,
publish, license, create derivative works from, transfer or sell in any
manner or medium any content or services available via this device.
SHARP is not responsible, nor liable, for customer service-related issues
related to the third party content or services. Any questions, comments or
service-related inquiries relating to the third party content or service should
be made directly to the applicable content or service provider.
You may not be able to access content or services from the device for a
variety of reasons which may be unrelated to the device itself, including,
but not limited to, power failure, other Internet connection, or failure to
configure your device properly. SHARP, its directors, officers, employees,
agents, contractors and affiliates shall not be liable to you or any third party
with respect to such failures or maintenance outages, regardless of cause
or whether or not it could have been avoided.
ALL THIRD PARTY CONTENT OR SERVICES ACCESSIBLE VIA THIS
DEVICE IS PROVIDED TO YOU ON AN "AS-IS" AND "AS AVAILABLE"
BASIS AND SHARP AND ITS AFFILIATES MAKE NO WARRANTY OR
REPRESENTATION OF ANY KIND TO YOU, EITHER EXPRESS OR
IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES OF
MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR A
PARTICULAR PURPOSE OR ANY WARRANTIES OF SUITABILITY,
AVAILABILITY, ACCURACY, COMPLETENESS, SECURITY, TITLE,
USEFULNESS, LACK OF NEGLIGENCE OR ERROR-FREE OR
UNINTERRUPTED OPERATION OR USE OF THE CONTENT OR
SERVICES PROVIDED TO YOU OR THAT THE CONTENT OR
SERVICES WILL MEET YOUR REQUIREMENTS OR EXPECTATIONS.
SHARP IS NOT AN AGENT OF AND ASSUMES NO RESPONSIBILITY
FOR THE ACTS OR OMISSIONS OF THIRD PARTY CONTENT OR
SERVICE PROVIDERS, NOR ANY ASPECT OF THE CONTENT OR
SERVICE RELATED TO SUCH THIRD PARTY PROVIDERS.
IN NO EVENT WILL SHARP AND/OR ITS AFFILIATES BE LIABLE TO
YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, PUNITIVE, CONSEQUENTIAL OR OTHER DAMAGES,
WHETHER THE THEORY OF LIABILITY IS BASED ON CONTRACT,
TORT, NEGLIGENCE, BREACH OF WARRANTY, STRICT LIABILITY OR
OTHERWISE AND WHETHER OR NOT SHARP AND/OR ITS
AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Connection/External Devices
EN 3-3
>><<
Chromecast-enabled devices
With Chromecast built-in, your phone becomes your remote. Simply tap the
Cast button from apps you already know and love to stream entertainment
from your phone, tablet or laptop to the TV.
NOTE
When the TV is turned off or the connection is ended on the device, you
must connect the device again.
For details about the operation of Chromecast-enabled devices, check the
manual for that device.
Audio Devices
HDMI Input
eARC (Enhanced Audio Return Channel)
Press "
(TOOLS)".
Select "TV options" > "Sound" > "eARC".
You can select to listen to the TV sound only from the LINK-compatible audio
system.
Auto / Off
Inputs
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Inputs" > "Inputs".
Change the label for an input terminal, and switch between HDMI CEC
Control Settings.
NOTE
Height speakers are activated with Dolby technology. Sound output
depends on audio signal of the source. Basically, height speakers are
enjoyed Dolby Atmos contents in Dolby Atmos mode.
Audio Output
Digital Output
Press "
(Dashboard)".
Select "Settings" > "Display & Sound" > "Audio Output" > "Digital Output".
This function allows you to select the digital audio signal type.
Auto / Bypass / PCM / Dolby Audio-Dolby Digital Plus / Dolby Audio-Dolby
Digital
Digital Output Delay
Press "
(Dashboard)".
Select "Settings" > "Display & Sound" > "Audio Output" > "Digital Output
Delay".
You can delay the output of audio to minimize the time gap between audio
output and a visual display.
Selected item
button button
Digital Output
Delay
For later delay For advance delay
Blue Mute
Press "
(TOOLS)".
Select "TV options" > "Advanced Options" > "Blue Mute".
The TV screen will turn blue if no signal detected.
On / Off
Connection/External Devices
EN 3-4
>><<
Bluetooth setup
This feature enable a TV to connect with other Bluetooth devices via
Bluetooth connection.
NOTE
When you use the Bluetooth device with your TV for the first time, you
must make pairing between the device and the TV. Once the pairing is
correctly carried out, the Bluetooth device will be registered on the TV.
Connectivity and reception range may depend on condition, environment,
and distance of Bluetooth devices.
Sound quality and compatibility are depending on Bluetooth devices.
The Bluetooth Profile only supports HID, A2DP and AVRCP.
Bluetooth devices
You can add, delete or select Bluetooth devices.
Connection/Selection Procedure
1 Turn the Bluetooth device on and put it in pairing mode.
To put your Bluetooth device in pairing mode, refer to the operation
manual of the device.
2 Press "
(Dashboard)".
Select "Settings" > "Remotes & Accessories" > "Pair accessory" to put
the TV in pairing mode.
A list of available Bluetooth device will be displayed.
3 Select the desired device from the list, then follow the on screen display
instruction.
If you are prompted to enter a password, refer to the operation manual of
the device.
After pairing is completed, the device connects to the TV.
NOTE
To pair the remote control unit with the TV, please hold (HOME) and
button for 10 seconds. Wait for about 1 minute before pairing.
NOTE
When there is significant interference in the 2.4-GHz frequency (such as
from other wireless LAN devices, Bluetooth
®
devices, 2.4-GHz cordless
telephones, and microwave ovens), to prevent mutual interference, please
turn off the power off unused devices.
Connection/External Devices
EN 3-5
>><<
USB setup
You can connect the TV to a USB memory device to enjoy viewing pictures,
listening to music, and watching videos.
NOTE
Depending on the USB memory device, the TV may not be able to
recognise the recorded data.
It may take time to read the recorded data if the USB memory device
contains many files or folders.
Use only alphanumeric characters for naming files.
File names (may vary depending on character set) may not be displayed.
Connecting a USB Memory Device
Insert the USB memory device with recorded photos, music or videos into the
USB terminal on the TV.
Use the specified external power supply for devices that can be externally
powered.
Do not remove a USB memory device from the TV while transferring files,
using the slide show function, or switching screens, or before you exit
"MultiMediaPlayer".
Do not insert and remove a USB memory device to and from the TV
repeatedly.
When using a card reader, be sure to insert a USB memory device first.
CAUTION
Do not use a USB extension cable when connecting a USB memory
device to the USB terminal on the TV.
Using a USB extension cable with the USB memory device may
prevent the TV from performing correctly.
Operation using USB hubs is not guaranteed.
Selecting the Folders to Play Back
To play back data on a USB memory device insert the USB memory
device on the TV.
1 Press "
(HOME)" > "Your apps" > "MultiMediaPlayer" to open the
Playback screen.
2 Press
/ to select "VIDEO", "PHOTO", "MUSIC" or "TEXT", and then
press ENTER/OK.
3 Press
/ (or / ) to select the drive/server where you want to find
your file, and then press ENTER/OK. (Only can select if more than one
USB input.)
4 Press
/ to select the desired folder, and then press ENTER/OK.
NOTE
USB only support device up to DC5V 500mA.
USB only support device up to DC5V 0.5A Max (Taiwan only).
Connection/External Devices
EN 3-6
>><<
USB setup (Continue)
USB Device Compatibility
USB device USB Memory, USB card reader (Mass
Storage class)
File system FAT/FAT32
Photo file format
Format JPEG, PNG, BMP
NOTE
Progressive jpeg format files are not supported.
Music file format
Format Sampling rate
[KHz]
Bitrate
[Kbps]
MP3 8/11.025/12/16/
22.050/24/32/44.1/48
8~320
AAC 32/44.1/48 8~320
WMA 8/11.025/16/22.05/
32/44.1/48/64/88.2/96
8~384
WAV 8/11.025/12/16/
22.050/24/32/44.1/48
8~1024
NOTE
If the TV is turned off and then on again, the number assigned to the USB
may change.
Video file format
Container Video Music
AVI
MPEG-1
MPEG-2
MPEG-4
H.264
AV1
PCM
MP2: MPEG-1 Layer2
MP3: MPEG-1 Layer3
AAC
AC3
WMA
MKV
MPEG-1
MPEG-2
MPEG-4
H.264
VP8
H.265(HEVC)
AV1
PCM
MP2: MPEG-1 Layer2
MP3: MPEG-1 Layer3
AAC
AC3
WMA
VORBIS
ASF
MPEG-4
VC1(WMV3)
AV1
MP3: MPEG-1 Layer3
WMA
PS
MPEG-1
MPEG-2
AV1
MP2: MPEG-1 Layer2
MP3: MPEG-1 Layer3
AC3
TS
MPEG-2
VC1(WMV3)
H.264
H.265(HEVC)
AV1
MP2: MPEG-1 Layer2
AAC
AC3
MP4
MPEG-4
H.264
H.265(HEVC)
VP8
VC1(WMV3)
AV1
MP2: MPEG-1 Layer2
MP3: MPEG-1 Layer3
AAC
NOTE
USB 1.1 devices may not be played properly.
Some video file formats may not be played depending on the file.
Some images may not be displayed in the appropriate aspect ratio
depending on the file format.
File extensions are not used to determine the file format.
Vertical video files are not supported.
Portrait format cannot display. Only support landscape format.
Connection/External Devices
EN 3-7
>><<
USB setup (Continue)
Playing Back Files on a USB Memory Device
Photo Mode/Music Mode/Video Mode
Buttons for thumbnail/list operations
Buttons Description
/ / /
Select a desired item.
ENTER/OK When selecting a folder icon: Enter this directory.
When selecting a photo file: Enlarge the photo.
When selecting an audio file: Play audio.
When selecting a video file: Play the video file.
(Back)
Return to the previous process.
(Blue)
Change Thumbnail/List mode.
(TOOLS)
Display the Menu screen.
NOTE
When you are viewing the MultiMediaPlayer app in Music Mode, you
cannot configure Picture/Audio settings.
Menu for thumbnail operations
Press
/ to select an item and make settings to your preferences.
Example
Sort
- You can change the way in which files are ordered.
- Press
/ to select "Type", "Date" or "Name" and then press ENTER/OK.
Media Type
- Switch the media type when the Recursive parser display is displayed.
Thumbnail Size
- Change the thumbnail size.
Small/Medium/Large
Recursive Parser
- Display all files according to the Media type settings.
Photo Frame
- You can add frame to your photo.
NOTE
You can see the file name, file size and pixel size of the selected photo in
the upper-left corner of the screen.
Connection/External Devices
EN 3-8
>><<
USB setup (Continue)
Playing Back Files on a USB Memory Device (Continue)
Photo Mode
Slide Show
The photos displayed on the thumbnail selection screen are displayed as a
slide show.
Buttons for slide show operation
Buttons Description
Play the Slide Show.
Pause the Slide Show.
/ / / ,
ENTER/OK
Select the desired item.
(Back)
Return to the thumbnail selection screen.
(TOOLS)
Display the USB Menu screen.
Menu for slide show
Example
Play/Pause
Start or pause slideshow.
Repeat
Set whether to show the slide show repeatedly.
None/Repeat One/Repeat All
Shuffle On/Shuffle Off
Shuffle the image files within the folder and display as a slide show.
Duration
Specify the length of time before the next image appears.
Press
/ to select the desired length of the time, and then press
ENTER/OK.
Short/Medium/Long
Effect
Specify the effect for transitioning to the next image.
None/Dissolve/Wipe Right/Wipe Left/Wipe Up/Wipe Down/Box In/
Box Out/Random
Rotate*
Rotate the photo by 90 degrees to the right.
* Only displayed when playback is paused.
Zoom*
Zoom in on the image.
1 X/2 X/4 X
* Only displayed when playback is paused.
Show Info
Display the photo information.
Photo Frame Image
Display the photo in frame.
Picture Settings
See pages 5-1 to 5-3.
NOTE
The slide show continues until you press (Back).
For setting the slide show speed, select "Duration" on the Menu screen.
Depending on the contents, the TV system cannot display the picture at
its original resolution in some cases. TV system may adjust the picture
resolution accordingly.
Connection/External Devices
EN 3-9
>><<
USB setup (Continue)
Playing Back Files on a USB Memory Device (Continue)
Music Mode
Playing Mode
Buttons for playing mode
Buttons Description
The fast reverse speed changes every time you press .
The fast forward speed changes every time you press .
Pause the music.
Go to the previous file.
Go to the next file.
/ / / , ENTER/OK
Select a desired item.
(Back)
Return to the previous process.
(TOOLS)
Display the Menu screen.
NOTE
The displayed play time may differ slightly from the actual play time
depending on the files.
Menu for playing mode
Example
Play/Pause
Start or pause music.
Repeat
Configure the repeat playback settings.
None/Repeat One/Repeat All
Shuffle On/Shuffle Off
Shuffle the music within the folder.
Show Info
Display audio information.
Hide Spectrum/Show Spectrum
Show or hide the spectrum.
Lyric Options
You can change the lyric display type.
This is only available when a lyrics file (".lrc") is presented.
Only UTF-8 character code lyric files (without BOM) are supported.
Picture Off
See page 7-1.
Sound Settings
See pages 6-1 to 6-2.
Audio Output
See page 3-4.
Connection/External Devices
EN 3-10
>><<
USB setup (Continue)
Playing Back Files on a USB Memory Device (Continue)
Video Mode
Playing Mode
Buttons for playing mode
Buttons Description
The fast reverse speed changes every time you press .
Play the video.
The fast forward speed changes every time you press .
Pause the video.
Go to the previous file.
Stop the video.
Go to the next file.
/ / / , ENTER/OK
Select a desired item.
(Back)
Return to the previous process.
(TOOLS)
Display the Menu screen.
NOTE
The displayed play time may differ slightly from the actual play time
depending on the files.
Menu for playing mode
Example
Play/Pause
Start or pause the video.
Repeat
Configure the repeat playback settings.
None/Repeat One/Repeat All
Show Info
Display the video information.
Screen Mode
This function changes the screen size.
Full Screen/4:3/16:9/Auto
Picture Settings
See pages 5-1 to 5-3.
Sound Settings
See pages 6-1 to 6-2.
Audio Output
See page 3-4.
Sound Tracks
Display soundtracks info.
Last Memory
Press
/ to select "Off" or "Time", and then press ENTER/OK.
Seek
Jump to the specific scenes.
Connection/External Devices
EN 3-11
>><<
Google Assistant
Talk to Google to control your TV using your voice.
Press the Google Assistant button on your remote to do more on your
TV with your voice.
NOTE
Google Assistant is not available in certain languages and countries.
Availability of services varies by country and language.
Find out more at https://support.google.com/assistant
Google Account setting
Accounts & sign-in
Press "
(Dashboard)".
Select "Settings" > "Accounts & sign-in".
To sign in, enter your email address and password.
You can also sign in another account and kids account.
Location
Press "
(Dashboard)".
Select "Settings" > "Privacy" > "Location".
Configure the location settings.
Usage & diagnostics
Press "
(Dashboard)".
Select "Settings" > "Privacy" > "Usage & diagnostics".
Automatically send diagnostic information to Google, like crash reports and
usage data from your device, apps, and Chromecast built-in. You can adjust
these permissions at any time from device settings. Learn more at
g.co/tv/diagnostics.
Security & Restrictions
Press "
(Dashboard)".
Select "Settings" > "Privacy" > "Security & Restrictions".
Unknown sources.
Allow installation of apps from sources other than the Play Store.
Apps
EN 4-1
>><<
Unique feature from SHARP
Azan - Prayer time (Malaysia & Indonesia only)
Press "
(Apps)".
Select "Your apps" > "Azan" app.
This feature could help a Muslim user to stay on top of Prayers with Azan by
getting the accurate prayer times via notification. By configuring location and
time zone, all five times prayer will be calculated according to the pointed
calculation method.
Auto Setup: This function allows you to select the address configuration
through pre-set data. (Country, Province, City)
Manual Setup: You can insert manually all informations in the screen.
Prayer Time Selection: You can select or deselect between 5 prayers for
Azan notification.
Notification: You can select or deselect prayer time to notify and enable or
disable prayer alert.
Info: A quick reference for you to get info on five times prayer after setup
completed.
Demo: A demonstration video will be displayed when Azan is implemented.
NOTE
The notification will be displayed on the screen for 5 minutes. After 5
minutes, the notification screen will be off automatically.
The notification is based on the setting in Prayer time selection.
Press (Back) to off the notification screen immediately.
The TV and Azan time information prior to internet connection.
The TV time information from digital TV signal will be used if internet
connection is not available.
Deviation of the TV and Azan display time may occur due to improper
digital broadcast standard.
SHARP SELECT
Press "
(Apps)".
Select "Your apps" > "SHARP SELECT" app.
This app shows recommended apps that can be enjoyed with AQUOS.
SHARP COCORO ALBUM (TV tuner models only)
Press "
(Apps)" or " (SHARP COCORO ALBUM)".
Select "Your apps" > "SHARP COCORO ALBUM" app.
You can import your photo to display, view and manage on SHARP COCORO
ALBUM.
SHARP COCORO VISION (Taiwan only）
Press "
(Apps)" or " (SHARP COCORO VISION)".
Select "Your apps" > "SHARP COCORO VISION" app.
This apps provides free entertainment, life information and application
platform to makes life more comfortable.
Apps
EN 4-2
>><<
Tools screen setting
Tools menu screen
1 Press
(TOOLS) to display the TOOLS screen.
2 Press
/ to select the desired menu.
Channels - Program Guide, Channel, Channel Management
TV options - Inputs, Picture, Screen, Sound, Power, Parental Controls, Manual OAD Download, Advanced Options, Settings
3 Press
(TOOLS) to exit.
Apps
EN 4-3
>><<
Picture Mode (Changing Pic. Quality)
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Picture Mode".
Picture Mode gives you several viewing option to choose from to best match
the surrounding environment of the TV, which can vary due to factors like
room brightness, type of programme watched or the type of device
connected.
Comfort: Reduce the blue light of the TV.
Standard: Default picture settings for common users.
Dynamic: For a clear-cut image emphasising high contrast.
Sport: Useful for sports viewing.
Movie: Dim down the colour for long hour viewing.
Game: Lower latency for fast gaming illustration.
Eco: Reduce the backlight brightness to save power consumption.
NOTE
You can set the Picture Mode on each input individually. These settings
will be automatically saved on each input for convenience.
When playing Dolby Vision content, the "Picture Mode" selection will be
displayed "Dolby Vision IQ", "Dolby Vision Dark" and "Dolby Vision Vivid".
Configuring Picture settings
Press "
(TOOLS)".
Select "TV options" > "Picture".
Adjusts the picture to your preference with the following picture settings.
Selected item
button button
Backlight The screen dims The screen brightens
Brightness For less brightness For more brightness
Contrast For less contrast For more contrast
Saturation For less colour saturation For more colour saturation
HUE Light orange become
reddish
Light orange become
greenish
Sharpness For less sharpness For more sharpness
NOTE
For resetting all Picture settings items to the factory preset values, press
/ to select "Reset to Default", press ENTER/OK, press / to
select "OK", and then press ENTER/OK.
Auto Brightness
Automatically adjust the brightness of the screen.
Off / On
Picture settings
EN 5-1
>><<
Configure advanced Picture settings
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings".
Gamma
Adjusts the differences of picture tones between bright parts and dark parts.
Dark / Middle / Bright
Color Temperature
For a better white balance, use colour temperature correction.
User
Cool:
White with bluish tone
Standard:
Warm: White with reddish tone
Red/Green/Blue Gain: Adjusts the white balance by changing the value of
each item
Color Tuner
Colour tone is managed using the six-colour adjustment setting.
Enable / HUE / Saturation / Brightness / Offset / Gain
NOTE
A lower value makes the image darker.
HDR related settings
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings".
HDR (High Dynamic Range)
The HDR (High Dynamic Range) technology implements video image that is very
similar to the image shown through human eyes by finely adjusting the contrast of
the source.
On: Enable HDR effect for HDR source.
Off: Disable HDR effect for HDR source.
NOTE
This feature only available when input signal is playing HDR content.
Unique Picture setting from SHARP
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings".
DNR
Reduces noise on screen and produces a clearer video image.
Off / Low / Medium / Strong / Auto
MPEG NR
This feature improves the quality of pictures by reducing the block noise and
mosquito noise without compromising the picture resolution.
Off / Low / Medium / Strong
Adaptive Luma Control
Automatically adjusts the image contrast according to the scene.
Off / Low / Medium / Strong
Local Contrast Control
Automatically adjusts the brightness of image contrast according to the scene.
Off / Low / Medium / High
Game Mode
Lowers image brightness for easier viewing.
Turning on Game Mode will disable these non-essential processing effects to cut
down on unnecessary lag. The end result is a picture that might look a little less
polished or refined because the TV isn't doing anything fancy to it but will almost
certainly feel significantly more responsive.
Off / On
Color Space
Color Space refers to the range of colour of image or video content that the SHARP
TV can support.
Auto / Off / sRGB/BT.709 / Adobe RGB / BT.2020 / DCI
Dolby Vision Notification
You can turn off or on Dolby Vision Notification on the screen.
Off / On
Blue Stretch
This feature can make picture colour temperature more bluish.
Off / On
Picture settings
EN 5-2
>><<
Unique Picture setting from SHARP (Continue)
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings".
Local Dimming
This feature can balances the backlight on the TV to make scene look darker or
lighter.
Off / Low / Middle / High
10-bit Colour Reproduction
This feature reduce contour of picture image.
Off / Low / Middle / High
Motion Enhancement
Use Motion Enhancement to view fast-action video more clearly.
Effect / Demo Partition / Demo
Low Blue Light
Adjust the differences of blue light colour of the TV.
Off / Low / Middle / High
*Automatic Playback Optimization
To optimize image quality based on content type when Dolby Vision content
changes.
Off / On
*Dolby Vision PQ Calibration
Select from the following available settings.
View Mode: The "View Mode" is updated based on "End User Calibration".
End User Calibration: You can set picture quality based on your preferences.
Last Modified Time: The last date of setting was modified.
*Light sense
Automatically adjust brightness based upon the changing ambient lighting
conditions.
Off / On
11-Point White Balance Correction
Adjust white balance to your preference.
Enable / Gain / Red / Green / Blue
AISR (AI Super Resolution)
When input a signal other than 4K, outline of picture can be emphasized according
to your preference.
Off / Low / Middle / High
*
NOTE
This feature only available when input signal is playing Dolby Vision content.
Input settings
PC Mode
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings" > "PC Mode".
Adjusts the picture when a PC is connected to the TV via HDMI.
Off / On
ALLM (Auto Low Latency Mode)
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings" > "ALLM".
To use "ALLM", you need to set the "HDMI EDID Version" to be "EDID 2.1".
Auto Low Latency Mode enables the ideal latency setting to automatically be set
allowing for smooth, lag-free and uninterrupted viewing and interactivity.
Off / On
HDMI RGB Range
Press "
(TOOLS)".
Select "TV options" > "Picture" > "Advanced Settings" > "HDMI RGB
Range".
Sets the HDMI type for HDMI IN 1, 2, 3 and 4 terminals.
This feature provides picture colour quality of HDMI input signal.
Auto / Full / Limit
HDMI EDID Version
Press "
(TOOLS)".
Select "TV options" > "Settings" > "Channels & Input" > "Inputs" >
"Consumer Electronics Control (CEC)" > "HDMI EDID Version".
When you use device that supports Variable Refresh Rate (VRR) such as game
console, you need to set each HDMI input to be "EDID 2.1".
EDID 1.4 / EDID 2.0 / Auto EDID / EDID 2.1
Picture settings
EN 5-3
>><<
Sound Style
Press "
(TOOLS)".
Select "TV options" > "Sound" > "Sound Style".
This function allows you to convert the audio quality. Select from the following
available settings.
User: Customise the sound setting.
Standard: Optimise sound quality for general content.
Vivid: Enhances the treble and bass for a clearer sound.
Sports: Simulates the larger space of a stadium or other venue.
Movie: Optimise surround sound suitable for movie.
Music: Optimise sound for listening to music.
News: Makes voice clearer by lowering background sound.
Configuring Sound settings
Press "
(TOOLS)".
Select "TV options" > "Sound".
You can adjust the sound quality to your preference with the followings
settings.
Selected item
button button
Balance Decrease audio from the
right speaker
Decrease audio from the
left speaker
Bass For weaker bass For stronger bass
Treble For weaker treble For stronger treble
NOTE
For resetting all Sound settings items to the factory preset values, press
/ to select "Reset to Default", press ENTER/OK, press / to
select "OK", and then press ENTER/OK.
Configure advanced Sound settings
Press "
(TOOLS)".
Select "TV options" > "Sound".
Surround Sound
The surround function produces Surround effect from the speakers.
Off / On
Equalizer Detail
This function allows you to change the sound quality.
120Hz / 500Hz / 1.5KHz / 5.0KHz / 10.0KHz
Speakers
You can choose to listen TV sound from speaker system.
On / Off
Speaker Delay
If you are hearing an audio delay across all sources or channels and you
have a home theatre system or other speakers connected to your TV, you
can access the Speaker Delay settings to increase the Speaker Delay.
Selected item
button button
Speaker Delay For later delay For advance delay
Dolby Audio/Height Speaker
Select from the following available settings.
Dolby Audio/Height Speaker / Sound Mode / Volume Leveler / Surround
Virtualizer / Dolby Atmos
NOTE
When "Dolby Audio/Height Speaker" is "Off", you can select "Sound
Style", "Balance", "Bass", "Treble", "Surround Sound" and "Equalizer
Detail".
When "Sound Mode" in "Dolby Audio/Height Speaker" is set to "User", you
can turn on or off "Volume Leveler", "Surround Virtualizer" and "Dolby
Atmos".
Dialog Enhancer
This function emphasises speech against background noise for greater
clarity.
Off / Low / Medium / High
Sound settings
EN 6-1
>><<
Unique Sound setting from SHARP
Press "
(TOOLS)".
Select "TV options" > "Sound".
Auto Volume Control
Different sound sources sometimes do not have the same loudness level,
such as a programme and its commercial breaks. The Auto Volume reduces
this problem by equalising it.
Off / On
Downmix Mode
You can select the multi-channel downmix method that is compatible with
your stereo system.
Stereo / Surround
Sound settings
EN 6-2
>><<
Sleep Timer
Press "
(TOOLS)".
Select "TV options" > "Power" > "Sleep Timer".
Allows you to set a time when the TV automatically switches to standby.
Picture Off
Press "
(TOOLS)".
Select "TV options" > "Power" > "Picture Off".
When listening to music from a music programme, you can turn the screen off and
enjoy audio only.
Switch Off Timer
Press "
(TOOLS)".
Select "TV options" > "Power" > "Switch Off Timer".
Allows you to set a time to shut off the TV automatically.
Auto Sleep
Press "
(TOOLS)".
Select "TV options" > "Power" > "Auto Sleep" > "4 hours" to continue watching TV.
NOTE
The default setting for "Auto Sleep" is "4 hours".
Accessibility
Press "
(Dashboard)".
Select "Settings" > "System" > "Accessibility".
Configure Captions, High contrast text, Text to speech and Accessibility shortcut.
Some of the Caption settings may not be applied.
Language
Press "
(Dashboard)".
Select "Settings" > "System" > "Language".
You can select a language.
Storage
Press "
(Dashboard)".
Select "Settings" > "System" > "Storage".
View the memory usage status.
Energy saver
Press "
(Dashboard)".
Select "Settings" > "System" > "Power & Energy" > "Energy saver".
Set to turn off display screen to reduce the power consumption.
Restart
Press "
(Dashboard)".
Select "Settings" > "System" > "Restart".
When your TV is not properly working, restart of the TV is required.
Factory reset
Press "
(Dashboard)".
Select "Settings" > "System" > "About" > "Reset" > "Factory reset".
When you perform a reset, the TV will be returned to the factory preset values, and
the Google Accounts will also be removed.
NOTE
Your purchased apps will remain.
Other
EN 7-1
>><<
Power on behavior
Press "
(Dashboard)".
Select "Settings" > "System" > "Power & Energy" > "Power on behavior".
The default setting for "Power on behavior" is the Google TV home screen. You can
change the TV startup behavior to "Last used input" if you prefer your TV to power
on with the last watched TV channel.
Timer
Press "
(Dashboard)".
Select "Settings" > "System" > "Power & Energy" > "Timer".
You can use this function to turn the TV on and off.
NOTE
"Auto Power On Time" / "Auto Power Off Time" is not available when you set
"Power On Time Type" / "Power Off Time Type" to "Off".
Automatic date & time
Press "
(Dashboard)".
Select "Settings" > "System" > "Date & Time" > "Automatic date &
time".
This function allows you to set Date & Time automatically.
Set date
Press "
(Dashboard)".
Select "Settings" > "System" > "Date & Time" > "Set date".
This function allows you to set date manually.
NOTE
"Set date" is not available when you set "Automatic date & time" to "Use
network-provided time".
Set time
Press "
(Dashboard)".
Select "Settings" > "System" > "Date & Time" > "Set time".
This function allows you to set time manually.
NOTE
"Set time" is not available when you set "Automatic date & time" to
"Use network-provided time".
Set time zone
Press "
(Dashboard)".
Select "Settings" > "System" > "Date & Time" > "Set time zone".
This function enable you to select your local time zone.
Use 24-hour format
Press "
(Dashboard)".
Select "Settings" > "System" > "Date & Time" > "Use 24-hour format".
You can select the time format (either "24HR" or "AM/PM") for the clock time.
Ambient mode
Press "
(Dashboard)".
Select "Settings" > "System" > "Ambient mode".
This function allows you to display your Google Photos or curated images from
other sources when the TV is idle.
Help & Feedback
Press "
(Dashboard)".
Select "Settings" > "Help & Feedback".
You can help improve Google TV when you share your feedback and tell us about
any problems you have.
Visit Google TV Help at g.co/tv/help.
Other
EN 7-2
>><<
Troubleshooting
Problem Possible Solution
No power.
Check if you pressed / (POWER) on the remote control
unit.
Is the AC cord disconnected?
Has the power been turned on?
Unit cannot be
operated.
External influences such as lightning, static electricity, may cause
improper operation. In this case, operate the unit after first turning off
the power of the TV or unplugging the AC cord and replugging it in
after 1 or 2 minutes.
Remote control unit
does not operate.
Is the equipment to be operated by the remote control unit set
correctly?
Are batteries inserted with polarity (+, -) aligned?
Are batteries worn out? (Replace with new batteries.)
Are you using it under strong or fluorescent lighting?
Is a fluorescent light illuminated near the remote control sensor?
Picture is cut off/with
sidebar screen.
Are Screen adjustments such as picture size made correctly?
Page 2-5
Strange colour, light
colour, or colour
misalignment.
Adjust the picture tone.
Pages 5-1 to 5-3
Is the room too bright? The picture may look dark in a room that is
too bright.
Power is suddenly
turned off.
Is the sleep timer set?
Page 7-1
Check the power control settings.
Page 7-1
The unit's internal temperature has increased. Remove any objects
blocking vent or clean.
The top of the TV is
hot.
Since the air warmed by the heat generated from the internal circuit
passes through the upper part due to natural convection, the upper
part becomes warm. However, it is not a defect and does not affect
the TV's functionality.
Power may turn on by
itself.
Is "Auto Power On Time" set to "On"? Please check the setting.
Page 7-2
Problem Possible Solution
Even if you turn
off, power lamp
does not turn off.
The power lamp does not go out even when the power is turned off. To
turn the lamp off, you must unplug the power plug.
No picture. Is the connection to the device correct?
If the PC image is not displayed, check the following:
- When connecting a laptop PC to the TV, check that display output mode
of the PC is set to external monitor.
If picture not displaying in HDMI input, please choose suitable "HDMI
EDID Version".
Page 5-3
Picture quality of
HD programmes is
poor.
To enjoy HD images from external equipment, you are required to set up
HDMI connection.
If the programme content is not of HD quality, HD images cannot be
displayed. Check that the programme you are viewing provides HD
images.
The HD cable/satellite set-top box may need to be configured to output
HD images via cable/satellite.
The cable/satellite broadcast may not support a signal resolution of
1080p.
The TV
sometimes makes
a cracking sound.
This is not a malfunction. This happens when the cabinet slightly
expands and contracts according to change in temperature. This does not
affect the TV's performance. Do not open the rear cover of the cabinet to
reconstruct the circuits. There exists high voltage within the cabinet and it
may cause electric shock and injury. If maintenance is required, contact
your dealer.
NOTE
If require any assistance with troubleshooting, please contact SHARP
Customer Care.
Appendix
EN 8-1
>><<
Troubleshooting (Continue)
Problem Possible Solution
No sound. Is the connection to the device correct?
Is the volume too low?
Have you pressed (Mute) on the remote control unit?
Check the audio output of the connected external equipment. Is
the volume too low or muted?
When external equipment is connected via an HDMI cable, you
may need to configure the audio to be output through the HDMI
cable.
When connecting a PC via an HDMI-certified cable, check the
following:
- Is the audio output of the PC configured correctly? Check the
audio output settings and output audio format in Sound Properties
on the PC.
The audio formats compatible with this TV are PCM, Dolby Digital.
With other formats, audio cannot be output.
Chromecast built-in
image/ audio cannot be
output to the TV.
Check if the smartphone/tablet is connected in the same Wi-Fi
network.
Software updates via
Over-The-Air (OTA) is not
successful.
Make sure your internet connection is working.
If the TV is connected to Internet, but no connection available,
please disconnect the internet from your TV and then reconnect
again.
Apps and services
cannot be operated.
Make sure your internet connection is working.
Depending on certain apps and services, you may not be able to
connect those apps and services if the date and time is incorrect.
Set the date and time correctly.
Page 7-2
Troubleshooting - Error Message
The example of an
error message
displayed on a screen
Possible Solution
No broadcast now. (TV
tuner models only)
Check the antenna cable. Check that the antenna is correctly
setup.
Check the broadcast time in the programme guide.
An incompatible audio
signal has been received.
Check the output device
settings.
This message is displayed when an audio format other than
PCM, Dolby Digital is input.
- Set the audio output format of connected external HDMI
equipment to PCM, Dolby Digital.
- Refer to the operation manual of the external equipment for
setting details.
NOTE
If require any assistance with troubleshooting, please contact SHARP
Customer Care.
Appendix
EN 8-2
>><<
Trademarks
Google TV is the name of this device's software experience and a trademark
of Google LLC. Google, YouTube, Google Photos, Chromecast built-in and
other marks are trademarks of Google LLC.
Google Assistant is not available in certain languages and countries.
Availability of services varies by country and language.
Connecting RCA jack
Instruction for using AV IN.
Requires RCA jack conversion.
Buy the service parts (QCNWGA252WJPZ).
Appendix
Side terminal
3-Audio L
Yellow
(Video)
White
(Audio L)
Red
(Audio R)
Video
Audio L
Audio R
4-Video
1-GND
2-Audio R
Game console,
DVD player, etc.
AV IN
EN 8-3
>><<
