Dryer
User Manual
C YSD 82D WW UK
C YSD 82D BB UK
C YSD 82D SS UK
EN
2960314427_EN/ 07-04-25.(11:00)
Dear Customer,
Please read this guide prior to use this product!
Thank you for choosing INDESIT product. We would like you to achieve the optimal efficiency
from this high quality product which been manufactured with state of the art technology. Please
make sure you read and understand this guide and supplementary documentation fully before
use.
Observe all warnings and information herein. Therefore you can protect both yourself and your
product against potential damages.
Keep the manual. Include this guide with the unit if you hand it over to someone else.
Symbols and Remarks
The following symbols are used in the user guide:
Danger that may cause death or injury
Read the manual
Important information or useful usage tips
Warning against hot surfaces
B
Warning against electric shock
Warning against UV Radiation hazard
Warning against scalding
The product's packaging is made of recyclable materials, in accordance with the
National Environment Legislation.
Warning against fire
NOTICE Danger that may cause material damage on the product or surrounding area
This product was manufactured using the latest technology in environmentally friendly conditions.
3
Dryer / User manual
Table Of Contents
1 SAFETY INSTRUCTIONS .................................................................... 5
2 Environmental instructions................................................................. 12
2.1 Compliance with the WEEE Regulations and Waste Disposal ..........................12
2.2 Packaging information .....................................................................................12
2.3 Standard conformity and test information / EU declaration of conformity .........12
3 Your drying machine ........................................................................... 13
3.1 Technical specifications ...................................................................................13
3.2 General appearance ........................................................................................14
3.3 Scope of delivery .............................................................................................14
4 Installation .......................................................................................... 15
4.1 Right place for installation ................................................................................15
4.2 Removing the shipping safety group ................................................................15
4.3 Water connection ............................................................................................16
4.4 Adjusting the stands ........................................................................................16
4.5 Moving the drying machine .............................................................................. 16
4.6 Warning regarding the noise ............................................................................16
4.7 Replacing the lighting bulb ............................................................................... 16
5 Preparation ......................................................................................... 17
5.1 Laundry suitable for drying in drying machine ..................................................17
5.2 Laundry not suitable for drying in drying machine ............................................17
5.3 Preparing the laundry to be dried ..................................................................... 17
5.4 What to do for energy saving ...........................................................................17
5.5 Correct load capacity ......................................................................................18
4
Dryer / User manual
6 Running the product .......................................................................... 19
6.1 Control Panel
1. On/Off/Programme selection button. ............................................................................... 19
6.2 Symbols ..........................................................................................................19
6.3 Preparation of drying machine .........................................................................20
6.4 Program selection and consumption chart ....................................................... 21
6.5 Auxiliary functions ............................................................................................23
6.6 Warning indicators ........................................................................................... 23
6.7 Starting the program ........................................................................................23
6.8 Child Lock .......................................................................................................24
6.9 Changing the program after it is started ...........................................................24
6.10 Cancelling the program ..................................................................................24
6.11 End of program .............................................................................................25
6.12 Odour feature ................................................................................................25
6.13 SteamTechnology Odour and Wrinkle Removal Function ..............................25
7 Maintenance and cleaning ................................................................ 26
7.1 Lint filters (internal and external filters) / Cleaning of the Interior Surface of the
Loading Door ........................................................................................................26
7.2 Cleaning the sensor ........................................................................................ 27
7.3 Emptying the water tank ..................................................................................28
7.4 Cleaning the condenser ................................................................................... 28
8 Troubleshooting ................................................................................. 30
5
Dryer / User manual
1 SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
This symbol reminds you to read this instruction manual.
Before using the appliance, read these safety instructions. Keep them
nearby for future reference. These instructions and the appliance itself
provide important safety warnings, to be observed at all times. The
manufacturer declines any liability for failure to observe these safety
instructions, for inappropriate use of the appliance or incorrect setting of
controls.
WARNING:
• This symbol shows that this appliance uses a flammable refrigerant.
If the refrigerant is leaked and exposed to an external ignition source,
there is a risk of fire.
This appliance contains R290 refrigerant that is flammable but
environment-friendly.
Very young children (0-3 years) should be kept away from the
appliance. Young children (3-8 years) should be kept away from the
appliance unless continuously supervised. Children from 8 years old
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can use this appliance
only if they are supervised or have been given instructions on safe use
and understand the hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not be carried out by
children without supervision.
WARNING:
Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and spread out so that
the heat is dissipated.
6
Dryer / User manual
Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and
wax removers and items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber-backed articles and clothes or pillows fitted
with foam rubber pads should not be dried in the tumble dryer. Remove
all objects from pockets, such as lighters and matches. Do not use the
tumble dryer if industrial chemicals have been used to clean it.
Oil-soaked items should not be dried in the tumble dryer due to
their high flammability.
Never open the door forcibly or use it as a step.
PERMITTED USE
CAUTION:
The appliance is not intended to be operated by
means of an external switching device, such as a timer, or separate
remote controlled system.
This appliance is intended to be used in household and similar
applications such as: staff kitchen areas in shops, offices and other
working environments; farm houses; by clients in hotels, motels, bed &
breakfast and other residential environments.
This appliance is not for professional use. Do not use the appliance
outdoors.
Do not store explosive or flammable substances (e.g. gasoline or
aerosol cans) inside or near the appliance - risk of fire.
Do not load the machine above the maximum capacity (kg of dry
cloth) indicated in the programme table.
Do not dry unwashed items in the tumble dryer.
Take care that no lint or dust is accumulated around the dryer.
7
Dryer / User manual
Fabric softeners, or similar products, should be used as specified
by the fabric softener instructions.
Do not overdry the laundry.
Do not drink, reuse or prepare food with condensed water. It can
be harmful to your health and cause property damage.
WARNING:
Do not damage the appliance refrigerant circuit pipes.
INSTALLATION
The appliance must be handled and installed by two or more
persons - risk of injury. Use protective gloves to unpack and install - risk
of cuts.
Installation, including water supply (if any), electrical connections
and repairs must be carried out by a qualifi ed technician. Do not repair
or replace any part of the appliance unless specifi cally stated in the user
manual. Keep children away from the installation site. After unpacking
the appliance, make sure that it has not been damaged during transport.
In the event of problems, contact the dealer or your nearest After-sales
Service. Once installed, packaging waste (plastic, styrofoam parts
etc.) must be stored out of reach of children - risk of suff ocation. The
appliance must be disconnected from the power supply before any
installation operation - risk of electric shock. During installation, make
sure the appliance does not damage the power cable - risk of fi re or
electric shock. Only activate the appliance when the installation has been
completed.
WARNING:
In the appliance enclosure or in the built-in structure,
keep ventilation openings clear of obstruction.
8
Dryer / User manual
Install the dryer in rooms with adequate ventilation (open door,
ventilation grid or slot larger than 500 cm2) in order to avoid the backflow
of gases into the room from appliances burning other fuels, including
open fires. If the dryer is installed under a worktop, provide a distance of
10 mm between the upper panel of the dryer and any objects above it,
and 15 mm between the sides of the appliance and the walls or furniture
units adjacent to it.
Make sure that the appliance is not installed near a heat source.
The appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of the
tumble dryer, in such a way that a full opening of the tumble dryer door is
restricted.
The appliance shall be placed against the wall to limit access to its
rear side.
Take care not to use a carpet which obstructs ventilation openings
in the base of the dryer.
If you want to stack the dryer on a washing machine, first contact
our After-Sales Service or your specialist dealer to verify the complete list
of suitable models. The stacking is only possible if the dryer is attached to
the washing machine by means of the appropriate stacking kit available
through our After-Sales Service or your specialist dealer. Instructions for
the correct assembly are supplied with the stacking kit.
ELECTRICAL WARNINGS
It must be possible to disconnect the appliance from the power
supply by unplugging it if plug is accessible, or by a multi-pole switch
installed upstream of the socket in accordance with the wiring rules and
the appliance must be earthed in conformity with national electrical safety
standards.
9
Dryer / User manual
Do not use extension leads, multiple sockets or adapters.
The electrical components must not be accessible to the user after
installation. Do not use the appliance when you are wet or barefoot. Do
not operate this appliance if it has a damaged power cable or plug, if it is
not working properly, or if it has been damaged or dropped.
If the supply cord is damaged, it must be replaced with an identical
one by the manufacturer, its service agent or similarly qualifi ed persons in
order to avoid a hazard - risk of electric shock..
CLEANING AND MAINTENANCE
WARNING:
Ensure that the appliance is switched off and
disconnected from the power supply before performing any maintenance
operation. To avoid risk of personal injury use protective gloves (risk
of laceration) and safety shoes (risk of contusion); be sure to handle
by two persons (reduce load); never use steam cleaning equipment
(risk of electric shock). Non-professional repairs not authorized by the
manufacturer could result in a risk to health and safety, for which the
manufacturer cannot be held liable. Any defect or damage caused from
non-professional repairs or maintenance will not be covered by the
guarantee, the terms of which are outlined in the document delivered with
the unit.
Make sure that all lint traps are cleaned before starting any drying
cycle.
Do not use any tool to clean the secondary filter, which can
damage the appliance leading to a gas leakage.
10
Dryer / User manual
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable and is marked with the recycle
symbol.
The various parts of the packaging must therefore be disposed of
responsibly and in full compliance with local authority regulations
governing waste disposal.
DISPOSAL OF HOUSEHOLD APPLIANCES
This appliance is manufactured with recyclable or reusable materials.
Dispose of it in accordance with local waste disposal regulations. For
further information on the treatment, recovery and recycling of household
electrical appliances, contact your local authority, the collection service for
household waste or the store where you purchased the appliance. This
appliance is marked in compliance with European Directive 2012/19/EU,
Waste Electrical and Electronic Equipment (WEEE) and with the Waste
Electrical and Electronic Equipment regulations 2013 (as amended).
By ensuring this product is disposed of correctly, you will help prevent
negative consequences for the environment and human health.
The symbol on the product or on the accompanying
documentation indicates that it should not be treated as domestic
waste but must be taken to an appropriate collection center for
the recycling of electrical and electronic equipment.
11
Dryer / User manual
• Washing machine cannot be placed on top of the drying machine.
Installation Table for Washing Machine and Tumble Dryer
Stacking Kit Type Depth Size (TD=Tumble Dryer, WM: Washing Machine)
Plastic - 54/60cm w or w/o belt 60cm TD --> WM≥50cm / 54cm TD --> WM>45cm
Plastic - 46cm w or w/o belt 46cm TD --> WM≥54cm
With Shelf - 60cm 60cm TD --> WM≥50cm
With Shelf - 54cm 54cm TD --> WM>45cm
Policies, standard documentation, ordering of spare parts and
additional product information can be found by:
Using QR code in your appliance.
Visiting our vebsite docs.indesit.eu and parts-selfservice.
europeanappliances.com
Alternatively,contact our After-sales Service (See phone number in
the warranty booklet). When contacting our After-sales Service, please
state the codes provided on your product’s identification plate. You can
find more information about your model online at https://eprel.ec.europa.
eu/ which is the offical EU EPREL product database. After selecting the
Product Category, enter the Model Identifier of the product. The Model
Identifier is made up of letters and numbers and can be found on the
identification plate, as Mod. (see image on fhe right).
In order to receive a more complete assistance, please register your
product on www.register10.eu
xxxxxxxxxxxx
12
Dryer / User manual
2 Environmental instructions
2.1 Compliance with the WEEE Regulations and Waste Disposal
This product does not contain the dangerous and prohibited materials indicated in the
“Regulation on The Control of Waste Electrical and Electronic Equipment” published by
Ministry of Environment and Urbanisation of Republic of Turkey. Complies WEEE
Regulations. This product was manufactured from recyclable and reusable high quality
parts and materials. Therefore, do not dispose of this product with other domestic
wastes at the end of its life cycle. Take it to a collection point for electrical and electronic
equipment. You can ask your local administration about these collection points. You can help
protect the environment and natural resources by delivering the used products for recycling.
Also R290 is a flammable refrigerant. Therefore ensure that the system and pipes are
not damaged during operation and transportation.
Keep the product from heat sources, otherwise it may catch fire if damaged.
Do not dispose of the product by throwing it into fire.
2.2 Packaging information
The product’s packaging is made of recyclable materials, in accordance with the National
Legislation. Do not dispose the packaging waste with the household waste or other wastes,
dispose it to the packaging collection areas specified by local authorities.
2.3 Standard conformity and test information
/ EU declaration of conformity
The development, manufacturing and sales phases of this product is conducted in
conformity with the safety rules specified in all related instructions of the European
Union.
13
Dryer / User manual
3 Your drying machine
3.1 Technical specifications
The model information as stored in the product
database can be reached by entering following
website and searching for your model identifier
(*) found on energy label.
https://eprel.ec.europa.eu/
* Min. height: Height with the adjustable stand closed.
Max. height: Height with the adjustable stand opened at maximum height.
** Weight of dry laundry before washing.
*** Data plate is under the door on the drying machine.
In order to increase the drying machine’s quality, the technical specifications may be
changed without prior notice.
Figures in this manual are schematic and may not exactly match the product.
The values provided with the drying machine or its accompanying documents are
laboratory readings in accordance with the respective standards. These values may
differ depending on the use and ambient conditions.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,8 cm
Depth 54,5 cm
Capacity (max.) 8 kg**
Net weight (± %10) 42 kg
Voltage
See type label***Rated power input
Model code
14
Dryer / User manual
3.2 General appearance
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Toe board handle
5. Ventilation grids
6. Adjustable feet
7. Toe board
8. Rating plate
9. Lint filter
10. Water tank drawer
11. Power cord
3.3 Scope of delivery
1. Water
discharge
hose*
6. Water
filling cap*
2. Filter
drawer
spare
sponge*
7. Pure
Water*
3. User
Manual
8. Odour
Capsule
Group*
4. Drying
basket*
9. Brush*
5. Drying
basket user
manual*
10. Filter
cloth*
*Optional - may not be included, depends on
model.
15
Dryer / User manual
4 Installation
Read the “Safety Instructions” first!
Before consulting the nearest Authorized
Service for installing the drying machine, see
the information in the user guide and make sure
the electric and water utilities are as required. If
not, call an electrician and plumber to arrange
the utilities as necessary.
It is customer's responsibility to
prepare the location the drying
machine shall be placed on and
also have power and waste water
installation prepared.
Check for any damage on the
drying machine before installing it. If
drying machine is damaged, do not
get it installed. Damaged products
cause a risk for your safety.
Wait 12 hours prior to operating the
drying machine.
NOTICE
The product includes a cooling
agent and if the product is operated
right after its transported, it may
get damaged. After each time the
product is moved, it shall be left to
rest for 12 hours.
4.1 Right place for installation
• Install the drying machine on a flat and
stable surface.
• Dryer machine is heavy. Do not move it by
yourself.
• Operate the drying machine in an
environment free of dust with good
ventilation.
• The gap between the drying machine and
the floor shall not be reduced via materials
such as rugs, pieces of wood and bands.
• Do not block the ventilation grilles of the
drying machine.
• There shall not be doors that can be
locked, sliding doors or hinged doors near
the installation environment of the drying
machine that may block the loading door
to be opened.
• Once the drying machine is installed,
the connections must stay stable. After
placing the drying machine, ensure that
the back wall does not come in contact
with any extrusion (a water tap, electrical
outlet etc.).
• Place the drying machine with at least 1
cm space between the product and the
furniture edges.
• Your drying machine is suitable to be
operated between +5°C to +35°C. If
operated outside this temperature range,
your drying machine’s operation may be
compromised and get damaged.
• The drying machine shall not be placed
with the back side against a wall.
B
Do not place the drying machine on
its power cord.
* Ignore following warning if your
product’s system does not contains
R290.
Dryer contains R290 refrigerant.*
R290 is an environment-friendly, but
flammable refrigerant.*
Ensure that the air inlet of the dryer
is open and it is well-ventilated.*
Keep potential flame sources away
from the dryer.*
4.2 Removing the shipping
safety group
Remove the shipping
safety group prior to
first use the product.
NOTICE
Do not leave an accessory or any
parts of the shipping safety group
inside the drum.
16
Dryer / User manual
4.3 Water connection
Instead of periodically draining the water
accumulated in the water tank, you can
discharge via the water discharge hose
supplied with the drying machine.
Connecting the water drainage hose
1
3 4
2
1-2 Remove the
hose behind the
drying machine
by pulling it
manually from
where it is
attached. Do
not use a tool
to remove the
hose.
3 Insert one end of the water discharge hose
supplied with the drying machine to where
you have removed the hose on the drying
machine.
4 Fix the other end of the water discharge
hose to directly waste water drainage or a
sink.
NOTICE
The water discharge hose shall be
fixed at maximum 80 cm height.
Ensure that the water discharge
hose do not get kinked, collapsed
or pressed on between the
discharge and the drying machine.
Hose shall be connected not to
be disconnected from its location.
Leaked water may cause damage.
Do not extend the water drainage
hose.
Check whether the water runs at an
appropriate flow. The drainage line
shall not be closed or clogged.
If an accessory package is provided
with your product, check the
detailed instructions.
4.4 Adjusting the stands
Until the drying
machine stands level
and sturdy, adjust
the stands by turning
them left and right.
4.5 Moving the drying machine
• Drain the water in the drying machine
completely.
• If the product is connected via direct
discharge, remove the hose connections.
The drying machine is
recommended to be moved in
upright position. Otherwise, tilt it to
the right side when viewed from the
front and move the drying machine.
Wait 12 hours prior to operating the
drying machine.
4.6 Warning regarding the noise
As the product is
operated, metallic
noises may come
from the compressor
from time to time, it is
normal.
When the product is operated,
the accumulated water is pumped
to the water tank. It is normal to
hear pumping sounds from the
appliance during this operation.
4.7 Replacing the lighting bulb
If your drying machine has drum lighting lamp;
Consult the authorized service to replace the
bulb/LED used in lighting your drying machine.
The bulb in this product is not suitable for home
lighting. The intended use of this lamp is to
ensure safely loading the laundry to the drying
machine. The lamps used in this appliance is
resistant to heavy physical conditions such as
temperatures over 50°C.
17
Dryer / User manual
Read the “Safety Instructions” first!
5.1 Laundry suitable for
drying in drying machine
NOTICE
Laundry that are not drying machine
safe may damage the appliance and
the laundry during drying. Follow
the instructions on the labels on the
laundry to be dried. Only dry the
laundry with “drying machine safe”
written on their labels.
Do not dry
with dryer
5.2 Laundry not suitable for
drying in drying machine
NOTICE
Undergarments with metal supports
shall not be dried in drying machine.
If these metal supports get loose
and ripped from the garment, it may
damage the machine.
Delicate embroidery textiles, cotton
and silk garments, garments
manufactured from delicate and
valuable textiles, non breathing
garments and tulle curtains shall not
be dried in drying machine.
5.3 Preparing the laundry to be dried
NOTICE
Items such as coins, metal parts,
needles, nails, screws, stones etc.
may damage the drum group of the
product or may cause functional
operation issues. Therefore check
all laundry that will be loaded to the
product.
Dry the laundry with metal
accessories such as zippers by
turning them inside out.
Close the zippers, hooks and
clasps, button up the covers’
buttons, tie textile belts and apron
belts.
5.4 What to do for energy saving
• Use the highest possible wringing option
as you wash the laundry. Therefore you
can reduce the drying period and reduce
energy consumption. Sort the laundry
based on their types and thickness.
Dry same types of laundry together. For
instance kitchen towels and table cloths
dry faster than bathroom towels.
• Follow the recommendations in the user
manual for program selection.
• During drying do not open the loading
door unless necessary. If you are required
to open the loading door, do not keep it
open for too long.
• Do not add wet laundry as the drying
machine operates.
• Clean the Fibre Filter before and after
each drying session.
• For condensation models, be sure to
clean the condenser at least once a
month or after each 30 drying sessions.
• Make sure the filters are clean. Refer to
maintenance and cleaning for details.
• For models with flue, follow the flue
connection rules specified in the guides
and clean the flue.
• During drying session, properly ventilate
the environment in which the drying
machine is in.
• On models with heat pump, check the
condenser at least every six months and
clean it if it is dirty.
5 Preparation
18
Dryer / User manual
• The Eco program is the most energy-
efficient program for drying wet cotton
laundry and is used to assess compliance
with environmentally conscious design
regulations.
• Keep the loading door shut to prevent
heat loss.
5.5 Correct load capacity
NOTICE
If the laundry in the
product exceed
maximum load
capacity, it may not
operate as intended
and may cause
material damage or
damage the product.
For each program,
follow the maximum
load capacity.
• Loading the domestic drying machine up
to the maximum capacity specified by the
manufacturer for the relevant programs
will help save energy.
The weights below are provided as examples.
Laundry
Approx.
weight
(g)*
Laundry
Approx.
weight
(g)*
Cotton
bedding
(double
size)
1500 Cotton dress 500
Bedding
(single size)
1000 Dress 350
Bed sheet
(double
size)
500 Denim 700
Bed sheet
(single size)
350
Handkerchief
(10 pcs)
100
Large table
cloth
700 T-Shirt 125
Small table
cloth
250 Blouse 150
Tea napkin 100 Cotton shirt 300
Bath towel 700 Shirt 200
Hand towel 350
*Weight of dry laundry before washing.
19
Dryer / User manual
6.1 Control Panel
6 Running the product
3
5
1
2 4
6
1. On/Off/Programme selection button.
2. Low temperature selection button.
3. Dryness level and Wrinkle prevention
selection button.
4. End time and Child lock selection button.
5. Timer program and the audible warning
selection button.
6. Start / Standby button.
6.2 Symbols
Filter
Cleaning
Water tank
Filter drawer /
Heat exchanger
cleaning
Start
pause
cancel
Iron Dry
Buzzer
Cupboard
Dry
Cupboard
Dry +
Extra dry
Anti-
creasing
Child-proof
lock
Low
temperature
TimeDry Ending In
Dryness
Level
Delicates
Synthetics
Towels Mix Cottons
Eco
Eco
Cottons Jeans Sport Duvet
Shirts
Express Extra Heat
On / Off
Wool Protect
Night
Downwear Steam
Bedding
Refresh
30’
Reverse
Drum
20
Dryer / User manual
6.3 Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Remove any foreign material inside it.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
NOTICE
Ensure that no
laundry is jammed to
the loading door.
Do not close the
loading door with
force.
• Select the desired program by using
On/Off/Program Selection button, the
machine will turn on.
Selecting the program with the On/
Off/Program Selection button does
not mean that the program started.
Press Start / Stand-by button to
start the program.
21
Dryer / User manual
6.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg)
Spin speed in
washing machine
(rpm)
Drying Time
(minutes)
Cotton
You can dry your heat-resistant cotton textiles
with this programme. A drying setting suitable
for the thickness of the products to be dried
and the desired level of dryness should be
selected.
8 1000 215
Eco
It dries single layer, casual cotton textiles in the
most economical way.
8 1000 209
Cottons Iron dry***
You may dry your cotton laundry to be ironed
in this program to have them slightly damp for
ease of ironing. (Shirt, T-shirt, tablecloth, etc.)
8 1000 160
Synthetics
You can dry all your synthetic textiles with this
programme. A drying setting suitable for the
level of dryness you desire should be selected.
4 800 75
Mixed
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
Sports and fitness clothes may be dried with
this program.
4 1000 125
Towels
Drying towels such as kitchen towel, bath towel
and hand towel.
5 1000 170
Sport
Use it to dry your clothes made of synthetics,
cotton or mixed fabrics or waterproof products
such as functional jacket, raincoat etc. Turn
them inside out prior to drying.
2 1000 130
Cool Refresh
It only ventilates for 10-160 minutes without
giving hot air. You can ventilate the cotton and
linen clothes that have been enclosed for a long
time with this program to remove their odour.
- - -
Timed Drying / Steam
You may select from time programmes
between 10 and 160 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble drier’s operation lasts for
the set time independently from the dryness
of laundry. SteamTechnology is a refreshing
function making ironing easier on less worn
clothes and reducing odours (cigarette, food
etc.) due to medium air.
- - -
Delicates
You may dry your delicate laundry or laundry
with hand wash symbol (silk blouses, thin
underwear, etc.) at low temperature in this
program.
2 1200 55
Bed Linen
Dry 1 cotton or synthetic duvet cover set by
closing the button / zipper.
2 1000 121
Down Wear
Turn clothes such as down coats, jackets
inside out for drying.
- 800 119
22
Dryer / User manual
* Above values have been specified under standard conditions. Consumption values may vary
from the values in the chart depending on laundry type, spin speed, ambient conditions and
voltage levels.
***The “Cotton Iron Dry” program can be set by selecting the “Cotton” program on the control
panel and then choosing the “Iron Dry” drying level using the dryness level selection button. You
can identify the “Iron Dry” symbol in section 6.2 Symbols.
Jeans
You may dry denim pants, skirts, shirts or
jackets in this program.
4 1200 130
Shirts
It dries the shirts in a more sensitive manner,
and causes less creasing and easier ironing.
1,5 1200 50
Baby
This program is designed to dry your washed
textiles at a higher temperature than other
cycles, making it ideal for items like baby
clothes, underwear, towels, and similar fabrics.
5 800 185
Express 30’
Use this program to have 2 shirts ready for
ironing.
0,5 1200 30
Energy consumption values
Programmes Capacity (kg)
Spin speed in
washing machine
(rpm)
Approximate
amount of
remaining humidity
Energy
consumption value
kWh
Cottons Eco* 8 1000 60% 2,18
Cottons Iron dry 8 1000 60% 1,60
Synthetics Cupboard Dry 4 800 40% 0,70
“If you regularly dry the 8 Kg maximum load of Cottons we suggest to connect the drain hose to
prevent the dryer stopping mid-cycle in order to empty the tank” (see Section “Connection to the
drain”)
23
Dryer / User manual
6.5 Auxiliary functions
Dryness level
Dryness level button is used for adjusting to
desired dryness. Program time may change
depending on the selection.
You can activate this function only
prior to start of program.
Wrinkle prevention
You can turn the wrinkle prevention function
on or off by pressing the end time button for
3 seconds. If you will not take the laundry out
immediately after the program has completed,
you may use Wrinkle prevention function to
prevent wrinkling of your laundry.
Audible warning
Drying machine makes an audible warning
when the program is completed. Press the
“Audible Warning” button if you do not want
audible warning. When you press the audible
warning button, the light goes off and it does
not sound when the program is completed.
Low Temperature
You can activate this function only prior to
operation of program. If you want to dry your
laundry at a lower temperature, you can
activate this function. Once activated, the
program will be extended.
You can select this function before
the program starts or after the
program starts.
End time
You can delay the end time of the program up
to 24 hours with end time function.
1. Open the loading door and place the
laundry.
2. Select the drying program.
3. Press the End Time selection button and
set the delay time you wish. End time LED
turns on. (When pressed and hold the
button, End Time proceeds non-stop).
4. Press the Start / Stand-by button. End
Time countdown begins. The “:” sign in the
middle of displayed delay time flashes.
You can add or remove laundry
within end time. Displayed time is
the sum of normal drying time and
end time. End Time LED turns off at
the end of countdown, the drying
starts and the drying LED turns on.
Changing the end time
If you want to change the duration during the
countdown:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and
repeat the End Time selection.
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and press
the “Start/Pause” button.
6.6 Warning indicators
Warning indicators may vary
depending on the model of your
drying machine.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning indicator turns off and program
resumes.
Cleaning of filter drawer/
heat exchanger
Warning symbol flashes periodically to remind
that filter drawer must be cleaned.
6.7 Starting the program
Press the Start/Stand-by button to start the
program.
Start/Stand-by and Drying indicators turn on to
show that program started.
24
Dryer / User manual
6.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the Child Lock is
activated, all buttons on the panel except
the On/Off/Program Selection button are
deactivated.
Press the End Time button for 3 seconds in
order to activate the child lock. The child lock
has to be deactivated to be able to start a new
program after the current program is finished
or to be able to interfere with the program.
To deactivate the child lock, keep the same
buttons pressed for 3 seconds.
When the child lock is activated,
the child lock warning indicator on
the screen turns on.
When the child lock is active:
The drying machine runs, or in stand-by state
the indicator symbols will not change upon
changing the position of the program selection
button.
When the drying machine is
operated and the child lock is
active, if the program selection
button is turned, a double beeping
noise will be heard. If the child lock
is deactivated before the program
selection button is turned to its
original place, the program will
be terminated since the program
selection button is displaced.
6.9 Changing the program
after it is started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running.
• For example, Pause the program and turn
the On/Off/Program Selection button to
select the Extra Dry program in order to
select the Extra Dry program instead of
Ironing Dryness.
• Press the Start/Stand-by button to start
the program.
Adding and removing
clothes during stand-by
If you want to add or remove clothes to/from
the drying machine after the drying program
starts:
• Press the Start/Stand-by button to put
the drying machine in Stand-by state. The
drying operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.
Adding laundry after the drying
operation starts may cause the
dried laundry inside the drying
machine to mix with wet laundry
and leave the laundry damp at the
end of operation.
Adding or removing laundry
during drying may be repeated as
many times as you wish. But this
operation continuously interrupts
the drying operation, and thus
increases program duration and
energy consumption. So, it is
recommended to add laundry
before the program starts.
If a new program is selected by
turning the program selection
button while the drying machine is
in stand-by, the running program
terminates.
Do not touch the inner surface of
the drum while adding or removing
clothes during a continuing
program. The drum surface is hot.
6.10 Cancelling the program
If you want to cancel the program and ter-
minate the drying operation for any reason after
the drying machine starts running, turn the On/
Off/Program Selection button after pressing
the Start / Standby selection button; and the
program terminates.
25
Dryer / User manual
The inside of the drying machine
shall be extremely hot when you
cancel the program during machine
operation, so run the refreshing
program to allow it to cool down.
6.11 End of program
When the program ends, the LED’s of End/
Wrinkle Prevention and Fibre Filter Cleaning
Warning on the program follow-up indicator
turn on. Loading door can be opened and
drying machine is ready for another operation.
Turn the On/Off/Program Selection button to
On/Off position in order to turn off the drying
machine.
If the Wrinkle Prevention mode
is active and the laundry is not
removed after the program is
completed, the wrinkle prevention
function activates for 2 hours to
prevent the laundry inside the
machine to get wrinkled. The
program tumbles the laundry with
10-minute intervals to prevent them
from wrinkling.
6.12 Odour feature
If your drying machine has odour feature, read
the ProScent manual to use this feature.
6.13 SteamTechnology Odour
and Wrinkle Removal Function
SteamTechnology is a refresher function that
helps ironing the dry clothes that worn very little
and aims to reduce airborne (cigarettes, food,
etc.) odours.
It is recommended to wash the clothes to
remove odours that can be absorbed by them
such as perfumes, deodorants and sweat.
Do not dry products that includes sharp or hard
accessories and leather.
Filling the water tank
1 blue wing in the machine performs the
process of watering the laundry.
If the wing is on top, you can manually rotate
the drum to the lower position and fill the water.
Before using the SteamTechnology program,
the water in the filling container at max. Level
must be filled manually into the wing.
To remove wrinkles, tap or drinking water
should be used.
A few drops of water that may overflow from
the wing during filling will not cause any
problem.
Additives or descaling agents
should not be used.
Chemicals that can be dissolved
with liquid chemicals and liquids
should not be used.
Starting the Program
The wing should be brought to the lower
position and should be filled with water up
to the marked area with the filling container.
The SteamTechnology program must be
selected.
When you select the program, the screen
time will appear as 10 minutes. The time
program is set to the desired time by
pressing the selection button and the Start/
Standy-By button is pressed.
For an effective odour removal,
it is recommended to operate 1-6 pieces of
dry clothing for 50 minutes.
This function does not clean clothes, it
reduces the odours and wrinkles and allows
you to wear them again.
26
Dryer / User manual
7 Maintenance and cleaning
Read the “Safety Instructions” first!
7.1 Lint filters (internal and external
filters) / Cleaning of the Interior
Surface of the Loading Door
The hair and fibres that are separated from
the laundry during drying process is collected
by the Lint filter. Insufficient cleaning of filters
can increase the drying duration and energy
consumption level.
Insufficient cleaning of filters can cause damp
laundries after drying cycle. While cleaning the
filters, in order to prevent microplastics from
spreading to the water system used, the dirt
and hair should be removed. While cleaning
the filters, the water should not be discharged
towards the drains.
After each drying cycle, clean the
lint filter and the inner surface of the
loading door.
NOTICE
Your drying machine has 2 lint filters
with one placed inside the other. Do
not operate the product without the
lint filters.
To clean the lint filter:
• Open the loading door.
• Hold the first part (inner filter) of the two part
lint filter and remove it by pulling it upwards.
• Remove the second part (outer filter) by
pulling it upwards.
Ensure that hair, fibre and cotton
balls do not fall into the slot where
the filters are installed.
• Open both of the lint filters (outer and inner)
and remove the fibres with your hands or
with the brush on the air deflector. You can
clean the hair in the filters with a vacuum
cleaner. The lint should be thrown in the
garbage bin and not washed through
the drain in order to avoid spreading
microplastics in the used water system.
27
Dryer / User manual
• Insert the lint filters on one another and
place it back in its place.
• Clean the inner surface of the loading door
and the gasket with a soft damp cloth or the
brush on the air deflector.
7.2 Cleaning the sensor
• There are temperature sensor in the
dryer that detect whether the laundry is
dry or not.
To clean the sensors:
• Open the loading door of the dryer.
• Remove the lint filter by pulling it up.
• Clean the sensor with your hand if any
fluff accumulation on it.
.
Clean the metal surfaces of the
sensor 4 times a year.
Do not use metal tools to clean the
sensors’ metal surfaces.
Due to fire and explosion hazard, do
not use solutions, cleaning materials
or similar tools to clean sensors.
28
Dryer / User manual
7.3 Emptying the water tank
During drying, the moisture is removed from
the laundry and condensed, then the water
is accumulated in the water tank. Empty the
water tank after each drying session.
Condensed water is not potable
water!
Do not remove the water tank as a
program is running!
If you do not empty the water tank, during the
next drying sessions the machine will stop
operating due to the water tank being full and a
Water Tank warning icon will blink. In this case
empty the water tank and to continue drying
operation, press the Start / Stand-by button.
To drain the water tank:
Pull the water tank out from its drawer carefully.
Drain the water in the tank.
Remove the water tank in the drawer or the
kickplate carefully.
If lint builds up in the funnel on the water tank,
remove it under running water.
Place back the water tank.
If direct discharge option is used,
water tank is not required to be
drained.
7.4 Cleaning the condenser
The hair and the fibre that are not collected by
the lint filter accumulates on the metal surface
of the condenser behind the air deflector. These
fibres shall be cleaned regularly.
If the condenser cleaning icon blinks, check
the metal surface. If there is any fibre, clean it. It
must be checked at least every 6 months.
Open the toe board
by pulling its button.
Move the latches to
open the air deflector
lid.
Pull the brush to the
left to remove it. You
can use the cleaning
brush to clean
filter, condensing
metal surface and
accumulated fibre on
the door.
The cleaning brush is inside the
documentation bag. Get your
brush from the documentation bag
and insert it to its place on the air
deflector to store it.
29
Dryer / User manual
Clean the fibre on the
metal surface of the
condenser with damp
cloth or the brush on
the air deflector in
up - down direction.
Do not clean with
left - right direction
since it will damage
the metal plates of the
condenser.
You can use a
vacuum cleaner with
a brush for cleaning.
If the vacuum cleaner
does not have
a brush, it is not
recommended to be
used for condenser
cleaning.
After cleaning the
filter, door and the
condenser, drag the
brush to the right and
lock it in its place.
After the cleaning
process is completed,
place the air deflector
cover to its place,
move the latches to
close it and close the
toe board.
You can clean by hand, provided
you wear protective gloves. Do not
try to clean with bare hands. The
condenser fins may damage your
hands. Cleaning from left to right
may damage the condenser fins.
This may lead to drying issues.
When the air deflector cover is
removed, it is normal to have water
at the plastic section in front of the
condenser.
If you see fibre
accumulation on the
fan cover and the toe
board, remove with a
cloth.
Do not have weight
on the toe board
when it is open.
NOTICE
Do not use abrasive materials or
steel wool to clean the drum.
30
Dryer / User manual
8 Troubleshooting
The drying takes too long.
Lint filter (interior and exterior filters) pores may be clogged. >>> Can be cleaned with vacuum cleaner.
The front side of the condenser may be clogged. >>> Clean the front of the condenser.
The ventilation grills in front of the machine might be closed. >>> Remove any object in front of the ventilation grills
that blocks ventilation.
Ventilation may be insufficient if the dryer is installed in a small space. Open the door or windows to prevent the room
temperature from rising very high.
If there is a humidity sensor;
Limescale may have accumulated on the humidity sensor. >>> Clean the humidity sensor.
The machine may be overloaded with laundry. >>> Do not load the drying machine excessively.
The laundry may not have been spun enough. >>> Spin at a higher speed in the washing machine.
The laundry comes out damp after drying.
The right program for the type of laundry might not have been used. >>> Check the care labels on the laundry and
select a program ideal for the kind of laundry or use longer programs.
Lint filter (interior and exterior filters) pores may be clogged. >>> Can be cleaned with vacuum cleaner.
The front side of the condenser may be clogged. >>> Clean the front of the condenser.
The machine may be overloaded with laundry. >>> Do not load the drying machine excessively.
The laundry may not have been spun enough. >>> Spin at a higher speed in the washing machine.
Drying machine does not turn on or program cannot be started. The dryer does not turn on when set.
The power plug may not be plugged in. >>> Make sure the power plug is plugged in.
The loading door may be left open. >>> Make sure that the loading door is properly closed.
The program may not have been set or the Start / Pause button may not have been pressed. >>> Make sure that the
program is set and it is not in Standby position.
Child lock may be activated. >>> Turn off the child lock.
The program was interrupted for no reason.
The loading door might not be closed properly. >>> Make sure that the loading door is properly closed.
There might be a power outage. >>> Press the Start / Standby / Cancel button to start the program.
The water tank may be full. >>> Empty the water tank.
Laundry shrunk, matted or spoiled.
The right program for the type of laundry may not have been used. Check the maintenance labels on the clothes and
select a program suitable for the clothes.
Water is flowing from the loading door.
Lint might have gathered on the inner surfaces of the loading door and on the surfaces of the loading door gasket.
>>> Clean the inner surfaces of the loading door and the loading door gasket surfaces.
The loading door opens by itself.
The loading door might not be closed properly. >>> Push the loading door until the closing sound is heard.
The water tank warning symbol is on/flashing.
The water tank may be full. >>> Empty the water tank.
The water discharge hose might have folded. If the product is connected directly to the water drain check the
water discharge hose.
The lighting inside the drying machine does not turn on. (in models with lamps)
The drying machine might not have been turned on by the On/Off button. >>> Check that the drying machine is
turned on.
Lamp might be broken. >>> Contact Authorized Service to replace the lamp.
Anti-Wrinkle icon or light is lit.
An anti-wrinkle program that prevents the laundry in the dryer from creasing may be activated. >>> Turn the drier off
and remove the laundry.
Fiber filter cleaning icon is lit
Lint filters (interior and exterior filters) may be unclean. >>> Can be cleaned with vacuum cleaner.
A layer may be formed in the lint filter pores, leading to clogging. >>> Can be cleaned with vacuum cleaner.
A layer may be formed in the lint filter (inner and outer filters) pores that leads to clogging.<<Can be cleaned with
vacuum cleaner.>>
Lint filters might not be in place. >>> Insert the interior and exterior filters into their places.
Eco-friendly filter cloth may not be installed on the plastic part, and the front of the condenser may have
clogged.>>>Install the eco-friendly filter to the plastic part and place it on the filter housing.
Eco-friendly filters may not have been replaced, although the warning symbol is illuminated. “Replace your filter.”
31
Dryer / User manual
The machine gives an audible warning,
Lint filters might not be in place. >>> Insert the interior and exterior filters into their places.
Filters of the machine might not have been installed.>>> Install the lint filters (internal and external) or the
environmentally-friendly filter in their housing.
The condenser warning icon is flashing.
Condenser front may be clogged with fibres. >>> Clean the front of the condenser.
Lint filters might not be in place. >>> Insert the interior and exterior filters into their places.
The lighting inside the drying machine turns on. (in models with lamps)
If the drying machine is plugged to the power outlet, the On/Off button is pressed and the door is open; the light
turns on. >>> Unplug the drying machine or bring the On/Off button to Off position.
Wi-Fi icon flashes continuously. (HomeWhiz Function models)
>>> The product may not be connected to the wireless network. Follow the instructions to connect to the network.
The device the appliance uses to connect to the network may be faulty. Check it. The appliance might not be
connected to the network due to being out of wi-fi range.
Check the steps below if you see "F L t" on the screen.
The filters may be dirty. Clean the internal and external filters
In the loading door area, if you are using the inner and outer dual filters. >>> Make sure that both filters
are installed.
The front side of the condenser may be dirty. >>> Open and check the kick zone and make sure it is
clean.
Check out the Maintenance and Cleaning section.
The foreign objects, if any, should be removed from the drying machine drum,
Spare parts will be available for a period of up to 10 years, according to the specific Regulation
requirements.
If the problem persists after following the instructions in this section, contact your vendor or an
Authorized Service. Never attempt to repair a malfunctioning product yourself.
If you experience a problem with any part of your appliance, you can request a replacement
by consulting the nearest authorised service with the appliance model number.
Operating the appliance with non-genuine parts may cause it to malfunction.
The manufacturer and distributor are not responsible for malfunctions caused by non-genuine
parts.
(4) Scale from G (lest efficient) to A (most efficient)
(5) Weighted average value — L
WA
expressed in dB(A) re 1 pW
(1) Scale from A+++ (most efficient) to D (least efficient)
(2) Energy consumption based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of
the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
(3) "Cotton cupboard dry programme" used at full and partial load is the standard drying programme to which the information in the
label and the fiche relates, that this programme is suitable for drying normal wet cotton laundry and that it is the most efficient
programme in terms of energy consumption for cotton
: Yes - : No
Supplier name or trademark
Model name
Rated capacity (kg)
Type of Tumble Dryer
Condenser
Air Vented
Energy efficiency class
(1)
Annual Energy Consumption (kWh)
(2)
Type of Control
Energy consumption of the standard cotton programme at full load (kWh)
Energy consumption of the standard cotton programme at partial load (kWh)
Power consumption of the off-mode for the standart cotton programme at full load, P
O
(W)
Power consumption of the left-on mode for the standart cotton programme at full load, P
L
(W)
The duration of the left on mode (min)
Standard cotton programme
(3)
Programme time of the standard cotton programme at full load, T
dry
(min)
Programme time of the standard cotton programme at partial load, T
dry1/2
(min)
Weighted programme time of the standard cotton programme at full and partial load (T
t
)
Condensation efficiency class
(4)
Average condensation efficiency of the standard cotton programme at full load, C
dry
Average condensation efficiency of the standard cotton programme at partial load, C
dry1/2
Weighted condensation efficiency of the standard cotton programme at full load and partial load, C
t
Sound power level for the standard cotton programme at full load
(5)
Built-in
PRODUCT FICHE
Complying Commission Delegated Regulation (EU) No 392/2012
Non-automatic
Automatic
A+
265,0
-
2,18
1,21
0,50
1,00
30
209
161
B
82%
82%
82%
64
-
8.0
125
-
C YSD 82D BB UK / 7188304970
C YSD 82D WW UK / 7188304910
INDESIT
C YSD 82D SS UK
7188304950
