3-SPEED LOW AMP CENTRIFUGAL AIR MOVER
WITH DAISY CHAIN CAPABILITY
READ AND SAVE THESE INSTRUCTIONS
OWNERS MANUAL
CM
USC
READ AND UNDERSTAND ALL WARNINGS AND INSTRUCTIONS
BEFORE USING THIS AIR MOVER!
Page 2
VOLTS
POWER
CYCLE
MAX AIR VOLUME
AMPS
WEIGHT
SIZE L/W/H
SPEED
CORD LENGTH
115V
1/5HP
60Hz
800CFM
2.1AMPS
11 Ibs
13"x12.2"x11"
3 SPEEDS
10ft/14AWG
Problem Cause Solution
Unit will not run.
Unit runs but air mover makes
loud scraping noise.
Unit runs but vibrates
excessively.
Unit runs but blower wheel
does not turn.
1. No power to nuit.
2. Switch not on.
3. Switch is faulty.
4. Faulty/broken cord or motor wire
1. Unit has been severely jolted causing blower wheel
to rub against housing.
2. Unit has been severely jolted causing housing to
deform.
1. Severe jolt has bent motor shaft causing unit to be
out of balance.
2. Air mover blade damaged.
3. Dirt build up on one side of air mover blade.
1. Motor bearings are failing or motor has developed
an internal electrical fault.
2. Intake grill and/or exhaust grill is obstructed.
3. Excessive duct length.
1. Plug unit in. Check circuit breaker.
2. Place in “ON” position.
3. Replace switch.
4. Perform continuity check, using volt/amp meter.
Repair/replace faulty broken wire.
1. Remove motor and replace damaged motor
mounts.
2. Replace blower wheel.
1. Remove and replace motor.
2. Replace blade if necessary.
3. Clean air mover blade.
1. Replace motor.
2. Remove obstruction.
3. Reduce duct length to recommended maximum
Page 3
Page 4
PA-330-AM MOVER ASSEMBLY
ITEM
NUMBER
PART
NUMBER
DESCRIPTION
QTY
1
2
3
4
5
6
7
8
200-01
200-02
200-03
200-04
200-05
200-06
200-07
200-08
SCREW
SWITCH ASSEMBLY
SWITCH KNOB
STRAIN RELIEF CAP
POWER CORD
NUT
FRONT GUARD
MOTOR
21
1
1
1
1
1
1
1
ITEM
NUMBER
PART
NUMBER
DESCRIPTION
QTY
9
10
11
12
13
14
15
16
200-09
200-10
200-11
200-12
200-13
200-14
HOUSING CASE
RUBBER FEET
WHEEL FAN
KICKSTAND
GFCI PLUG
CIRCUIT BREAKER
1
6
1
1
1
1
1
5
4
11
1
9
7
8
13
2
6
12
3
10
1
1
2
14
1
PURAERO'S WARRANTY POLICY
1-Year Warranty
Subject to the conditions stated below. PURAERO offers a limited warranty on parts and labor on the following equipment, parts
and accessories to be free from defects in material and workmanship for a period of one year to the original purchaser.
Wear items exempt from warranty consideration include but may not be limited to: power cords, transport wheels, castors,
handle grips, filters, screens. Subject to the conditions and exceptions stated in this warranty. PURAERO warrants the PURAERO
products to be free from defects in material and workmanship. Under normal use and service. for the periods listed under the warranty
policy to the original purchaser. At any time during the warranty period, original owner will be liable for transportation costs to repair
facility. PURAERO will furnish replacement parts for the PURAERO products to the original purchaser. Such parts will be fumished
and charged including transportation costs, to the original owner. Replacement parts that have become defective through wear or
abuse are not included in this warranty. This warranty does not apply to damage or defect caused by accident, misuse, negligence, fire
or to any PURAERO product which has been serviced or repaired by other than an authorized PURAERO Service Distributor or
PURAERO factory personnel. This warranty is void if products are used for any purpose other than that which was intended. There are
no other warranties expressed or implied. In no event shall PURAERO be liable for incidental or consequential damages or any damage
to person or property.(Please note some states do not allow the exclusion or limitations for incidental and consequential damages.)
