MR11 Halogen Replacement Reflector
Specification Sheet
Physical Characteristics
Lens ...................................................... Clear Lens
Base ...................................................... GU4
MOL ...................................................... 1 3/8" (35mm)
Item Number 04766
Specifications
Energy Used (Watts) ............................... 5
Domestic Code ....................................... 5MR11Q/NFL/LN
Volts ...................................................... 12
Candle Power ......................................... 200
Beam Spread ......................................... 16°
Beam Type ............................................. Narrow Flood
Filament Type ........................................ C8
Light Center Length (LCL) ....................... 7/8"
Light Appearance (Kelvin) ...................... 2900
ANSI Code ............................................. N/A
Average Rated Hours .............................. 2000
Life (in years)*....................................... 1.8
Estimated Yearly Energy Cost**............... $0.60
Country of Origin ................................... China
Limited Warranty
This lamp is warranted to be free from defects in material and workmanship for 2 years (based on using 3 hours per day).
Warning
The inner capsule of this lamp is pressurized and could shatter, use only in fixtures that provide a protective shield of tempered glass. Use only in fixtures
rated for specified lamp type and voltage. Do not exceed the maximum wattage rating of the fixture. Do not use if outer glass is scratched or broken since
it may break during operation or removal. This lamp gets extremely hot during operation. To avoid risks of burns or other injury, turn power off and allow
lamp to fully cool before attempting to replace. To avoid the possibility of fire, do not operate lamp close to materials that are negatively affected by heat.
Socket condition may affect lamp life. Inspect and replace socket if deterioration has occurred. FOR INDOOR OR OUTDOOR USE. Suitable for damp locations
when used in an outdoor rated fixture.
2014 WESTINGHOUSE LIGHTING / 0414 / 103948
Call 1-800-999-2226 or visit www.westinghouselighting.com.
Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. Westinghouse Lighting, a Westinghouse Electric Corporation licensee
“Westinghouse” and “You can be sure...if it’s Westinghouse” are all registered trademarks of Westinghouse Electric Corporation.
* Based on 3 hrs./day
* * Based on 3 hrs./day 11¢/kWh - Cost depends on rates and use.
