USER MANUAL
TABLE TOP HEATER
EQODETT
Thank you for choosing electriQ
Please read the manual before using this heater
and keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire product range
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR
OCCASIONAL USE
2
CONTENTS
SAFETY INSTRUCTIONS
3
OPERATION
5
CLEANING AND MAINTENANCE
6
TECHNICAL SPECIFICATIONS
6
TROUBLESHOOTING
6
SUPPORT
7
3
SAFETY INSTRUCTIONS
IMPORTANT
• Carefully read the instructions before operating this unit.
• Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
• Installation must be in accordance with the regulations of the country where the unit is
used.
• If you are in any doubt about the suitability of your electrical supply have it checked and,
if necessary, modified by a qualified electrician.
• This heater has been tested and is safe to use. However, as with any electrical
appliance - use it with care.
• Disconnect the power from the unit before dismantling, assembling or cleaning.
• Avoid touching the main body when in use.
• Do not use the heater with wet hands.
• Never insert fingers, pencils or any other objects through the guard.
• This appliance can be used by Children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be carried out by children.
• Children aged from 3 years and less than 8 years shall only switch on/off the appliance
provided that it has been placed or installed in its intended normal operating position
and they have been given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children aged from 3 years and less
than 8 years shall not plug in, regulate, or clean the appliance or perform user
maintenance.
• Children under 3 years should be kept away unless continuously supervised.
• Some parts of this product can become very hot and cause burns. Particular attention
has to be given where children and vulnerable people are present.
• Do not clean the unit by spraying it or immersing it in water.
• Do not use the heater within reach of a shower, bath or swimming pool.
• Avoid connecting the unit to an electrical outlet using an extension cord. If an outlet is
not available, one should be installed by a qualified electrician. If an extension cord is
used, it should be fully unwound from its spool, and be suitable for the power of the unit.
• Never operate this appliance if the unit, cord or plug is damaged. Ensure the power
cord is not stretched, exposed to sharp objects / edges, or routed under the unit.
• Any service other than regular cleaning should be performed by an authorised service
representative. Failure to comply could result in a voided warranty.
• Never use the plug as a switch to start and turn off the heater. Use the provided power
button on the unit.
• Do not use an external timer.
• Always ensure the unit is secure before operation. Do not use on unstable or uneven
surfaces.
• Avoid keeping the unit in direct sunlight for long periods of time.
• The heater is designed to be used at temperatures above -20°C. If it is exposed to
temperatures below this, it must be allowed to warm above this level before operation.
4
• Do not attempt to repair, disassemble or modify the appliance. This unit contains no
user-serviceable parts.
• Always unplug or disconnect the appliance from the mains power supply when not in
use, or when moving or cleaning it. Do not pull the cord to unplug the heater.
• Keep the heater clean. Do not allow any object to enter the ventilation or exhaust
opening as this may cause electric shock, fire, or damage to the heater.
• Do not use the appliance for anything other than its intended use.
• There may be a trace of odour during the first few minutes of initial use, or after a period
of storage. This is normal and will quickly disappear.
• This appliance has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or any flammable liquids are used or stored.
• Never locate this appliance where it may become exposed to water.
• This appliance is IPX4 rated, and so although it resistant to water ingress, should not
be allowed to be submerged, or subjected to overly wet conditions.
• The unit must be sited in an area sheltered from adverse weather conditions such as
rain, wind, snow and ice.
• The appliance must be disconnected from the mains when not in use.
• To prolong the life of the product, and to ensure its safety we advise the unit is stored
in a secure dry location when not in use.
• Minimum distances should always be complied with from top: 60 cm, from sides: 150
cm.
• The heater should not face flammable substances or surfaces.
• Do not run the power cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Arrange cord away from traffic area and where it will not be tripped
over.
• Heaters should not be installed in areas where hazardous vapours may be present.
Defined in BS 5345.
• Ensure that there is no possibility of flammable material coming into contact with the
heater, or in the near vicinity of the heater.
• The heaters are fitted with safety guards. These are intended only to stop large objects
from hitting the emitters. On no account should the heater be operated with the guard
removed.
• Do not install or use immediately above or below a power socket.
• Due to continual product development, there may be variations between the pictures
and the specifications within the manual and the actual product.
• WARNING: To reduce the risk of fire or electrical shock, DO NOT use this appliance
with any solid-state Speed Control Device or any variable speed controllers.
ENERGY SAVING AND UNIT SAFETY PROTECTION TIP
• Do not cover or restrict the airflow. Do not use in a dusty environment.
• For safety and maximum performance, when used as a portable unit the minimum
distance from a wall or objects should be 50cm.
5
OPERATION
The main control dial can be turned anti
clockwise to select the power level without
the oscillating function.
To use the oscillation function turn the main
control dial clockwise to:
In addition to turning the oscillating function
on or off, the top dial can be used to select
the extent of the oscillation:
When you have finished using the heater, the main control dial must be turned to the
OFF position before unplugging the heater.
LOW
600W
HIGH
1200 W
600W with oscillation
1200 W with oscillation
120°
The unit will twist in a 120 degree arc, heating the area in front of it.
360°
The unit will turn 360 degrees, providing warmth in a full circle around
the unit.
6
CLEANING AND MAINTENANCE
ATTENTION: Please turn off the unit and unplug from the mains and allow to
fully cool before cleaning or performing any maintenance.
CLEANING THE SURFACE
• Clean the heater with a duster or a soft wet cloth.
• Do not use chemical solvents (such as benzene, alcohol or gasoline) as they
may cause irreversible damage. Make sure no water enters the control panel or
gaps in the casing.
• Do not run the unit until completely dry.
• Place the heater in its original box or cover to protect it from dust when not in
use.
TECHNICAL SPECIFICATIONS
Model
EQODETT
Voltage
220-240V~
Frequency
50 Hz
Power
1200W Max
IP Rating
IPX4
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will
invalidate the warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. There is no power from socket
3. The power switch on the rear of the unit
is turned off.
1. Connect the power cord
2. Check socket is turned on
3. Ensure the power switch on
the rear of the unit is in the on
position
Odour
emission
from unit
1. New unit. When the unit is used for the
first time the heater may produce and odour
which will dissipate within a week of use
1. No action required
7
electriQ UK SUPPORT
www.electriQ.co.uk/support
Please, for your own convenience, make these simple checks before calling
the service line.
If the unit still fails to operate call: 0330 390 3061 or complete the online
form
1. Is the unit plugged into the mains?
2. Is the fuse OK?
3. Switch the unit off and wait three minutes to see if the issue is resolved.
Restart the unit.
Office hours: 9AM - 5PM Monday to Friday
www.electriQ.co.uk
Unit J6, Lowfields Business Park
Lowfields Way, Elland
West Yorkshire, HX5 9DA
Disposal: Do not dispose this product as unsorted municipal waste. Collection of such
waste must be handled separately as special treatment is necessary.
Recycling facilities are now available for all customers at which you can
deposit your old electrical products. Customers will be able to take any
old electrical equipment to participating civic amenity sites run by their
local councils. Please remember that this equipment will be further
handled during the recycling process, so please be considerate when
depositing your equipment. Please contact the local council for details of
your local household waste recycling centres.
8
Model Identifier: EQODETT
Item
Symbol
Value
Unit
Item
Unit
Heat Output
Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat
output
P
nom
1.2
kW
manual heat charge control, with
integrated thermostat
N/A
Minimal heat
output
P
min
0.6
kW
manual heat charge control with room
and/or outdoor temperature feedback
N/A
Maximum
continuous
heat output
P
max
1.2
kW
electronic heat charge control with room
and/or outdoor temperature feedback
N/A
Auxiliary electricity consumption
fan assisted heat output
N/A
At nominal
heat output
el
max
1.2
kW
Type of heat output/room temperature control
(select one)
At minimum
heat output
el
min
0.6
kW
single stage heat output and no room
temperature control
No
In standby
mode
el
SB
0
kW
two or more manual stages, no room
temperature control
Yes
with mechanical thermostat room
temperature control
No
with electronic room temperature control
No
with electronic room temperature control
plus day timer
No
with electronic room temperature control
plus week timer
No
Other control options (multiple selections
possible)
room temperature control with presence
detection
No
room temperature control, with open
window detection
No
with distance control option
No
with adaptive start control
No
with working time limitation
No
with black bulb sensor
No
Contact
Details
BuyItDirect, Unit J6, Lowfields Business Park, Lowfields Way, Elland,
West Yorkshire, HX5 9DA
