PROJ:
GB/T 1804-M
120g铜版纸
1/1
Janet.Guo
21/5/2020
成品没有边框正面
96mm
96mm
智能控制底部套件
注意
面板和底座必须同时为PoE版本才能
搭配使用。
请勿将PoE面板用于其他底座，或将
PoE底座用于其他面板。
面板和底座未成套使用可能会导致
设备损坏。
NOTE
The Smart Control Panel and Accessory
must be of PoE version at the same time
to be used together.
Do not use the PoE panel for other
accessoriess, or use the PoE accessory
for other panels.
If the panel and accessory are used
incorrectly as a set, the equipment may
be damaged.
输入
DC 12V 或 PoE 48V
两种供电方式选其中一种即可
www.ilifesmart.com
所有技术信息以实机性能为准
杭州行至云起科技有限公司保留最终解释权
杭州市萧山区平澜路518号悦盛国际中心22楼
P/N：88010290 A0
Notice: This device may be used
in each member state in EU.
INPUT
DC 12V or PoE 48V
DECLARATION OF CONFORMITY
Hereby, LifeSmart declares that the radio
equipment type is in compliance with
Directive 2014/53/EU. The full text of the
EU declaration of conformity is available
at the following internet address:
http://global.ilifesmart.com/ce/docs/
智能控制底部套件(POE底座)说明卡纸
88010290
A0
PoE
网口
DC输入
+12V
预留扩展接口区域，请以实物端口为准
GND
PoE
Ethernet
DC In
+12V
Area reserved for expansion ports
Please refer to the actual product
GND
iot.ilifesmart.com
Manufacturer: HANGZHOU LIFESMART TECHNOLOGY CO.,LTD.
