Instruction Booklet
Model: HP1269
portable infrared
cooktop
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
1. Read all instructions.
2. DO NOT touch hot surfaces. Use handles or knobs.
3. To protect against electrical hazards, DO NOT immerse cord,
plugs,or the appliance in water or other liquid.
4. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they do
not play with the appliance.
5. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person
responsible for their safety.
6. Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking o parts, and before cleaning the
appliance.
7. DO NOT operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to Salton for examination, repair or adjustment. All
servicing, other than cleaning, should be performed by an authorized
service representative. See Warranty section.
8. The use of accessories or attachments not recommended by Salton
may cause hazards.
9. DO NOT use outdoors.
10. DO NOT let cord hang over edge of table or counter, or touch hot
surfaces.
11. DO NOT place on or near a hot gas or electric burner, or in a heated
oven.
12. Always attach plug to appliance rst, then plug cord into the wall
outlet. To disconnect, turn any control to ‘OFF’, then remove plug
from wall outlet.
13. Extreme caution must be used when moving an appliance
containing hot liquids or hot oil. Hot oil is very dangerous and can
cause serious burns.
2
14. This appliance is for Household Use Only. DO NOT use appliance for
other than intended use.
15. DO NOT leave unit unattended while in use.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
GROUNDED PLUG
To reduce the risk of electric shock this appliance has a grounded plug
(2 blades and 1 pin). If the plug does not fit fully into the electrical outlet
contact a qualified electrician. Do not modify the plug in any way or use
an adaptor.
BEFORE FIRST USE
Place a pot with water on the elements and turn the Temperature
Control Knobs to the MAX position. Allow the unit to heat on the MAX
setting for 10 – 15 minutes. This will burn off any manufacturing oils on
any inside parts of the Cooktop. During this process, a small amount of
smoke may be seen coming from under the Cooktop and/or around the
Temperature Control Knobs.
HOW TO USE
Any flat-bottomed pot or container that can be used on a conventional
electric stove element can also be used on the cooktop. Cookware
made from solid aluminum or some other material with an encapsulated
aluminum base will provide the best results. Any cookware can be used
to reheat but if maximum energy is required, such as boiling water,
please use the recommended cookware.
IMPORTANT: For maximum heat transfer and stability cookware should
have a perfectly solid flat bottom. Make sure the diameter of your
cookware is close in size to the element you are using. NEVER use over-
sized cookware. Check the bottom of your cookware regularly to ensure
it is perfectly flat with no warping or abnormalities before use.
1. Place the Cooktop on a smooth, dry, at surface. For proper
ventilation provide at least 4 – 6 inches (10 - 15 cm) of space above
and around the appliance.
2. Be sure that the Temperature Adjustment Knobs on the front of the
unit are both on ‘0’.
3
3. Plug into a 120 Volt A.C. wall outlet.
4. Place lled cookware on the burner. NOTE: DO NOT operate the
burner without lled cookware on the burner. Always use a pot or
pan that is similar in size to the burner. Center the pot or pan on the
burner.
5. Turn the Temperature Control Knob(s) clockwise to desired setting.
6. Each burner is equipped with its own Temperature Control Knob and
Indicator Light. The Indicator Light(s) will glow and go ‘on’ and ‘o’
as the selected temperature is automatically maintained.
7. When nished cooking, always turn the appliance o by turning the
Temperature Control Knobs to the ‘0’ position. Unplug the unit from
the wall outlet.
CAUTION: Allow the unit to cool completely before handling. The
burners will remain hot for at least 1 hour.
IMPORTANT:
• DO NOT preheat before using.
• DO NOT switch on before filled cookware is placed on the burner.
• ALWAYS hold cookware handle(s) when stirring foods/liquids.
• The wattage of the small element is 600 W and the large element is
1200 W.
This appliance is 120V. Please do not compare this appliance to your
regular stove (240V) which is double the power of this hotplate.
For best results using your hotplate:
• ALWAYS USE COOKWARE WITH A FLAT BOTTOM.
• Make sure the diameter of your cookware is close in size to the
element you are using. Avoid over-sized cookware.
• When trying to boil water, use a lid on your cookware.
CARE AND CLEANING
1. Unplug unit and allow to cool.
2. The unit should be cleaned with a cloth or sponge dampened in
warm soapy water.
3. NEVER USE ABRASIVE CLEANSERS.
4. NEVER IMMERSE THIS UNIT IN WATER.
5. All servicing, other than cleaning, should be performed by an
authorized service representative. See Warranty section.
4
A short supply cord is provided to reduce the hazards of becoming
entangled in or tripping over a long cord. Extension cords may be used
if care is exercised in their use. If an extension cord is used, the marked
electrical rating of the detachable power-supply cord or extension cord
should be at least as great as the electrical rating of the appliance. If
the appliance is of the grounded type, the extension cord should be a
grounded 3-wire cord. The extension cord should be arranged so that
it will not drape over the counter top or table top, where it can be pulled
on by children or tripped over.
This warranty does not include the cost of shipping, which is to be borne by the
customer.
LIMITED WARRANTY
**The original sales receipt is the only acceptable proof of purchase**
Salton Appliances (1985) Corp. warrants that this appliance shall be free from
defects in material and workmanship for a period of five (5) year from the date of
original purchase. Salton Appliances (1985) Corp. at its sole discretion during this
warranty period, will repair or replace a defective product or issue a refund. Any
refund to the purchaser will be at a pro-rated value based on the remaining
period of the warranty. All liability is limited to the amount of the purchase price.
This warranty covers normal domestic usage and does not cover damage which
occurs in shipment or failure which results from alteration, accident, misuse,
abuse, glass breakage, neglect, improper maintenance, use contrary to the
operating instructions or commercial use. This warranty is not available to retailers
or other commercial purchasers or owners.
Contact one of our many Service Centers found on our website
www.salton.com/customer-care
For added protection, we suggest that you use an insured delivery service with
tracking information when returning your product. Salton Appliances (1985) Corp.
will not be held responsible for in-transit damage or for packages that are not
received.
This warranty does not include the cost of shipping, which is to be borne by the
customer.
To contact our Customer Service Department:
Salton Appliances (1985) Corp.
81A Brunswick,
Dollard-des-Ormeaux, Quebec H9B 2J5
Canada
Telephone: 514-685-3660 (Ext. 226)
E-mail: [email protected]
Fax: 514-685-8300
www.salton.com
Securely package and return the appliance to us. Please enclose:
• Original proof of purchase
• The completed form below with a $12.50 Return Shipping & Handling fee –
either a cheque, money order or credit card (A personal cheque will delay return
shipping by 2-3 weeks)
TO OBTAIN PROMPT WARRANTY SERVICE:
or
Name
Address
City Prov/State Postal/Zip Code
Daytime Phone No. Email
Product defect:
Type of payment Cheque/Money Order Visa MasterCard
Name on card Expiry Date CSV No
Card No.
□ □ □
