MVA670 Power
Steering Adapter Kit
Page Number - 1
Form 824864
Figure 1
PRECAUTIONS
• Always read carefully and under-
stand instructions prior to using
this equipment.
• Wear safety glasses at all times.
• Operate vehicle only in a well ven-
tilated area, and away from poten-
tial sources of lame or ignition.
• Prior to and during operation of the
engine, make sure all equipment
components, body parts, and per-
sonal clothing are clear of rotating
engine components.
• Avoid burns by remaining cautious
of engine parts that may become
hot when the engine is running.
• Never leave a vehicle unattended
while performing this procedure.
KIT INCLUDES
• MVA662
Ford Power Steering Adapter
• MVA661
GM Power Steering Adapter
• MVA660
Universal Power Steering Adapter
• Instruction manual
MVA662
Ford
Fluid Bottle
(sold separately)
Hand Vacuum Pump
(sold separately)
MVA661
GM
MVA660
Universal
Page Number - 2
Form 824864
PROCEDURES
Bleeding air from the power
steering system
1. Check the level of power steering
luid in the reservoir. It should be
between the MAX and MIN level
when the luid is at normal ambient
temperature. Adjust the level as
necessary.
2. Remove the reservoir cap and
insert the appropriate Power
Steering Adapter into the neck
of the reservoir until it is snug.
NOTE: In the case of limited
clearance, a right angle adapter
is included for use with the Ford
and GM adapters. To install the
adapter, unscrew the thumb-knob
securing the straight barb in place.
Remove the straight barb and
install the right angle adapter in its
place.
3. Connect the hand vacuum pump
and reservoir to the adapter as
shown in igure 1.
NOTE: The luid bottle is required
to prevent luid from entering the
pump.
4. Operate the vacuum pump to ap-
ply 20-25 in-Hg (68-85 kPa) vac-
uum to the system. Maintain the
vacuum for at least three minutes.
IMPORTANT: To prevent damage
to the pump, do not run the engine
while the system is under vacuum.
5. Release the vacuum and remove
the plug from the reservoir.
6. Top-off the luid level as required.
7. Repeat the process until the luid
level remains stable.
8. Start the engine and turn the wheel
lock-to-lock three to ive times.
IMPORTANT: Do not hold the
wheel at the stops.
9. Stop the engine and check the
power steering system for leaks.
10. Check the luid in the reservoir for
bubbles and check the level.
If bubbles are present or the luid
level is low, repeat the procedure
as necessary.
Checking for power steering leaks
1. Check the level of power steering
luid in the reservoir. It should be
between the MAX and MIN level
when the luid is at normal ambient
temperature. Adjust the level as
necessary.
2. Remove the reservoir cap and
insert the required Power Steering
Adapter into the neck of the reser-
voir until it is snug.
3. Connect the hand vacuum pump
and reservoir to the evac adapter
as shown in igure 1.
NOTE: The luid bottle is required
to prevent luid from entering the
pump.
4. Operate the vacuum pump to
apply 20-25 in-Hg (68-85 kPa)
vacuum to the system.
IMPORTANT: To prevent damage
to the pump, do not run the engine
while the system is under vacuum.
5. Watch the gauge needle. A drop of
more than 2 or 3 in-Hg indicates a
leak in the system. Also, air bub-
bles can typically be seen in the
reservoir.
6. If a leak exists, repair and retest.
MVA670 Power
Steering Adapter Kit
Page Number - 3
Form 824864
MVA670 Power
Steering Adapter Kit
MVA662
MVA661
MVA665 (sold separately)
Page Number - 4
Form 824864
