Sterilizer Rack Return Gate
Engineers of Condence.
The Belimed Sterilizer Rack Return Gate, with
powered slide window, is designed to be used
with 2 door sterilizers to pass racks back from
the sterile stores area to the clean area.
Sterilizer Rack Return Gates, MST-V and MST-H
Product Guide
Engineers of Condence.
Belimed, Inc.
1.800.451.4118 | 1.843.216.7424
belimed.com
DEV1.29.2024_Q0
Product Description
The Belimed sterilizer rack return gate, with powered slide window, is
designed to be used with 2 door sterilizers to pass racks back from the
sterile stores area to the clean area.
There are two versions; one for use with racks for the MST-V series and
one for the MST-H series of steam sterilizers.
Application
For use in healthcare facilities.
Standard Features
Construction/Design
The rack return gate is mounted in a wall separating the clean and sterile
stores areas in the SPD.
· Stainless Steel Frame and Panels
· Green Tinted Safety Glass Powered Window
· Controls on Top, Both Sides
Dimensions
Reference cut sheets for construction use.
Gate for MST-V Sterilizer Racks
31.5” (800mm) W x 8.75” (220mm) D x 77.5” (1970mm) H
Gate for MST-H Sterilizer Racks:
31.5” (800mm) W x 8.75” (220mm) D x 77.5” (1970mm) H
Conguration
Electrical Requirements:
· 120V 60 Hz 1PH 10A, 3 wire
Options
· Manual Conveyor Queue Modules for either side
Benets
Provides an easy way to return racks to the clean side, in a 3 zone
SPD, while keeping the cart on the sterile stores side for unloading of
the sterilizer.
Ease of Use
· Cart docks to the gate on each side for transfer of the rack
· Simple controls to open the window
· Automatic control of closing after about 15 seconds
· Light will ash indicating that the window is about to close
· Closing can be delayed by pressing the ashing button
