INSTRUCTION MANUAL
MODEL:5624849
If you have any questions, please contact our professional after-sales
team first, we will provide you with satisfactory solutions.
E-mail address: service@callsupports.com
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
3
PRODUCT DIAGRAM
6
INSTALLATION INSTRUCTIONS
7
Before Using Your Cigar humidor
7
To Install Your Cigar humidor
7
OPERATION INSTRUCTIONS
9
Controls
9
Storage
10
Door Lock
10
CARE & MAINTENANCE
11
Cleaning Your Cigar humidor
11
Power Failure
11
Vacation Time
11
Moving Your Cigar humidor
12
Energy Saving Tips
12
TROUBLESHOOTING GUIDE
13
3
IMPORTANT SAFETY INSTRUCTIONS
Your safety and the safety of others are very important.
This Cigar humidor complies with the applicable safety requirements and is safe for daily use.
However, basic safety precautions should always be followed when using an electrical appliance,
to reduce the risk of fire, electric shock, and personal injury.
Plug into its own individual electrical outlet with a voltage rating that matches the rating
label on the Cigar humidor (115/120V AC only, 60Hz, 10A). Use receptacles that
cannot be turned off by a switch or pull chain. Be sure that the plug is fully inserted into
the receptacle.
Plug into a grounded 3-prong outlet. Do not under any circumstances cut or remove the
third ground prong from the power cord supplied.
To protect against electric shock, do not immerse the Cigar humidor, plug or cord in water
or other liquids.
Never unplug the Cigar humidor by pulling the power cord. To disconnect the Cigar
humidor, always grip the plug firmly and pull straight out from the wall outlet.
Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length or at
either end.
Do not connect or disconnect the electric plug when your hands are wet. Do not operate
the Cigar humidor with wet hands, while standing on a wet surface or while standing in
water.
Unplug the Cigar humidor or disconnect power before cleaning or servicing. Failure to do
so can result in electrical shock or death.
When moving the Cigar humidor, be careful not to roll over or damage the power cord.
Never clean Cigar humidor parts with flammable fluids. These fumes can create a fire
hazard or explosion. And do not store or use gasoline or other flammable vapor and liquids
in the vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
Do not attempt to repair or replace any part of your Cigar humidor unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified
technician.
An empty Cigar humidor can be dangerous to children. Remove any latches, lids, locks,
and/or doors from unused or discarded Cigar humidor to prevent child entrapment and
suffocation. Never allow children to operate, play with or crawl inside this Cigar humidor
4
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
1. Children should be supervised to ensure that they do not play with the appliance.
2. This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
4. To avoid a hazard due to instability of the appliance, it must be fixed in accordance with the instructions.
5. When positioning the appliance, ensure the supply cord is not trapped or damaged.
6. Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
7. Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
8. Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
9. Do not damage the refrigerant circuit.
10. Do not use electrical appliances inside the drink storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
11. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
12. This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
13. To avoid contamination of cigar , please respect the following instructions:
– Opening the door for long periods can cause a significant increase of the temperature in the compartments
of the appliance.
– Clean regularly surfaces that can come in contact with cigar and accessible drainage systems.
– Clean water tanks if they have not been used for 48 h, flush the water system connected to a water supply
if water has not been drawn for 5 days.
– If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent mould developing within the appliance.
5
Do not use this Cigar humidor for other than its intended purpose. For indoor, household
use only.
Move this Cigar humidor by 2 people. Failure to do so can result in injury.
Place this Cigar humidor in a well-ventilated area with temperatures above 15°C (60°F)
and below 32°C (90°F).
To ensure proper ventilation for your Cigar humidor, the front of the cigar humidor must
be completely unobstructed.
This Cigar humidor must be installed in an area away from wind, rain, water spray or drips.
The Cigar humidor should not be located next to ovens, grills or other sources of high heat.
Do not kink or pinch the power supply cord of Cigar humidor.
It is important for the Cigar humidor to be leveled in order to work properly. You may need
to make several adjustments to level it.
This Cigar humidor is designed for storing cigar. Do not store perishable food or medical
products inside the cigar humidor.
When disposing of refrigeration Cigar humidor, special handling is often required. It is the
consumer’s responsibility to comply with federal and local regulations when disposing of
this product.
WARNING: Risk of child entrapment and suffocation. Before you throw away this or an
old Cigar humidor, remove the door. Leave the shelves in place, so that children may not
easily climb inside.
FLAMMABLE REFRIGERANT GAS
DANGER - Risk of fire or explosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
DANGER - Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained
service personnel. DO NOT puncture refrigerant tubing.
CAUTION - Risk of fire or explosion. Flammable refrigerant used. Consult repair manual / owner’s
guide before attempting to service this product. All safety precautions must be followed.
CAUTION - Risk of fire or explosion. Dispose of property in accordance with federal or local
regulations. Flammable refrigerant used.
CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing. Follow handling
instructions carefully. Flammable refrigerant used.
CAUTION - To prevent a child from being entrapped, keep out of reach of children and not in the
vicinity of the Cigar humidor.
6
PRODUCT DIAGRAM
1
Top Hinge
4
Water Tray
2
Control Panel
5
Lock
3
Shelves
6
Door
7
Leveling Legs
7
INSTALLATION INSTRUCTIONS
Before Using Your Cigar humidor
Remove the exterior and interior packaging.
Check to be sure you have all of the following parts:
o
3 Shelves
o
1 Water Tray
o
2 Keys
o
Instruction Manual
IMPORTANT: Before connecting this Cigar humidor to a power source, let it stand upright for
approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system
from handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Install the handle on the left side of the door.
To Install Your Cigar humidor
This Cigar humidor is designed for free standing or built-in (fully recessed) installation.
Place your Cigar humidor on a solid and level floor that is strong enough to support it when it
is fully loaded. This will ensure a vibration-free and noise-free operation. Adjust the leveling
legs in and out to stabilize the Cigar humidor horizontally. If the legs are not properly adjusted,
the Cigar humidor may be unstable and result in excess noise or vibration.
Locate the Cigar humidor away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extremely cold ambient temperatures may also cause the Cigar humidor not to
perform properly.
8
It is not advisable to install this Cigar humidor in moist areas or directly adjacent to a kitchen
sink, as moisture could cause premature corrosion to the components of your new Cigar
humidor.
It is recommended you install the Cigar humidor in a place with temperatures above 60°F (15°C)
and below 90°F (32°C), and humidity is under 60%. If the ambient temperature is above or
below recommended temperatures, the performance of the Cigar humidor may be affected.
Placing your Cigar humidor in extremely cold or hot conditions may cause interior temperatures
to fluctuate, and the temperature range of 16ºC-22ºC (61°F-72°F) may not be reached.
Connect the Cigar humidor to an exclusive, properly grounded, standard electrical supply (115
V AC only, 60 Hz), in accordance with the National Electrical Code and local codes and
ordinances. Any questions concerning power and/or grounding should be directed toward a
certified electrician or an authorized products service center.
Warning: Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged, have it replaced by an authorized service center.
The Cigar humidor should always be plugged into its own individual electrical outlet which
has a voltage rating that matches the rating label on the Cigar humidor. This provides the
best performance and also prevents overloading house wiring circuits that could cause a
fire hazard from overheated.
Do not under any circumstances cut or remove the third ground prong from the power
cord supplied.
Do not use an extension cord or adapter plug. However, if you must use an extension cord,
it is absolutely necessary that it be a UL-listed, 3-wire grounding type Cigar humidor
extension cord having a grounding type plug and outlet and that the electrical rating of the
cord is 10 amperes (minimum) and 120 volts.
Do not use a cord that shows cracks or abrasion damage along its length or at either end.
If the Cigar humidor is going to be used in an area that is prone to power surges/outages,
it is suggested that you use a power surge protector. The surge protector that you select
must have a surge block high enough to protect the Cigar humidor it is connected to.
Damages due to power surges are not considered a manufacturer covered defect and will
void your product warranty.
9
OPERATION INSTRUCTIONS
Controls
After plugging the Cigar humidor into a wall outlet, the Cigar humidor would turn on automatically
and the LCD screen would show the temperature inside of the Cigar humidor.
After setting your desired serving temperature, allow the Cigar humidor to cool down for 3 to 4
hours before placing cigars in the Cigar humidor.
Temperature Range：16-22℃（61-72℉）
Humidity Range：65-75%RH
The best storage environment for cigars：Temperature:18-20℃，Humidity:65-70%RH
1. Lock Key
Operate this key to unlock/lock the control panel.
Press it for 3 seconds to unlock the control panel; the panel will be locked automatically if no
operation in 15 seconds
All operations can only be carried out under the premise of unlocking.
2. Temperature Up Key Left
This key can increase the temperature, press this key and the temperature will flash to display the
original set temperature, after each press, the temperature will increase by 1 unit. Press to increase
the temperature
The display will show the actual temperature after 5 seconds
3. Temperature Down Key Left
This key can decrease the temperature, press this key and the temperature will flash to
display the original set temperature, after each press, the temperature will decrease by 1 unit. Press
to decrease the temperature
After the key operation is completed, 5 seconds resumes displaying the actual temperature. The
display will show the actual temperature after 5 seconds.
10
4. Humidity Up Key Right
This key can increase the humidity. Press this key to display the original set humidity. After
each press, the humidity will increase by 1 unit. Press it to increase the humidity
. After the key operation is completed, The display will show the actual humidity after 5 seconds
5. Humidity Down Key Right
. This key can decrease the humidity. Press this key to display the original humidity setting,
and each time it is pressed, the humidity will decrease by 1 unit. Press it to decrease the humidity
. After the key operation is completed, The display will show the actual humidity after 5 seconds
6. Light Control Key
. Switch the interior light ON or OFF
7. Power On/Off Key
. Press left and at the same time to turn ON or OFF the unit.
8. Temperature Conversion Key
Press right and at the same time to toggle Celsius and Fahrenheit
Door Lock
This Cigar humidor can be secured with a lock and key. The keys are located inside the plastic bag
that contains the Instruction Manual. Insert the key into the lock and turn it clockwise to lock the
door, making sure the metal pin is engaged completely. To unlock the door, do the reverse.
Remove the key and put it in a secure location.
11
CARE & MAINTENANCE
Cleaning Your Cigar humidor
IMPORTANT: Always unplug the Cigar humidor before cleaning or performing maintenance.
Never use harsh cleansers or scouring pads to clean any part of the Cigar humidor.
Turn off the power, unplug the Cigar humidor, and remove all items including shelves.
Wash the inside surfaces with warm water and baking soda solution. The solution should
be about 2 tablespoons of baking soda to a quart of water.
Wash the shelves with a mild detergent solution.
Wring excess water out of the sponge or cloth when cleaning the area near the controls,
or any electrical parts.
Wash the outside cabinet with warm water and a mild liquid detergent. Rinse well and wipe
dry with a clean soft cloth. Do not use steel wool or steel brush to rub the stainless steel,
which will contaminate the stainless steel with steel particles and rusting may occur.
Power failure
Most power failures are corrected within a few hours and should not affect the temperature of
your Cigar humidor. If the power is off for an extended period of time, proper steps should be
taken to protect your contents.
Vacation Time
Leave the Cigar humidor operating during vacations of less than three weeks. For periods longer
than this, turn the Cigar humidor off and leave the door slightly ajar to prevent odor from building
inside the Cigar humidor.
12
Moving Your Cigar humidor
Remove all items (cigar) from the cigar humidor;
Securely tape down any loose items, such as shelves, inside the Cigar humidor.
Turn the adjustable leg up to the base to avoid damage.
Tape the door shut.
Ensure that the Cigar humidor stays securely in the upright position during transportation.
Protect the outside of the Cigar humidor with a blanket or a similar item.
Energy saving tips
- The Cigar humidor should be located in the coolest area of the room away from heat sources or
direct sunlight.
- Ensure that the Cigar humidor is adequately ventilated. Never cover air vents.
- Only open the Cigar humidor door for as long as necessary. Frequent opening of the door will
affect internal temperature.
13
TROUBLESHOOTING GUIDE
Before you reach out to customer service, please check if you can resolve the problems according
to the following hints.
PROBLEM
POSSIBLE CAUSE
SOLUTION
The Cigar
humidor does
not run.
The Cigar humidor may not be
plugged in, or plug may be loose.
Ensure the Cigar humidor has been
plugged in properly.
The Cigar humidor is turned off.
Press to turn on the humidor.
House fuse blown or tripped circuit
breaker.
Check/replace fuse. Reset circuit
breaker.
The Cigar
humidor is not
cold enough.
External environment may require a
higher setting.
Set a colder setting. Allow several hours
for the temperature to stabilize.
The Cigar humidor has recently been
disconnected for a period of time.
It takes 3-4 hours for the Cigar humidor
to cool down completely.
Prolonged or frequent door
openings.
Open the door less often.
The door is not closed completely.
Close the door properly.
The door gasket does not seal
properly.
Check the door gasket. Clean or change
gasket if necessary.
The compressor
turns on and off
frequently.
The room temperature is hotter than
normal.
It
’
s normal for the Cigar humidor to work
harder under these conditions.
A large amount of contents has been
added to the humidor.
A large amount of contents cause the
Cigar humidor to run more until the
desired temperature is reached.
Prolonged or frequent door
openings.
Open the door less often.
The temperature has not been set
correctly.
Press either or to check the set
temperature, and set the temperature
properly.
The door is not closed completely.
Close the door properly.
The door gasket does not seal
properly.
Check the door gasket. Clean or change
gasket if necessary.
14
PROBLEM
POSSIBLE CAUSE
SOLUTION
The light does not
work.
Not plugged in.
Plug the humidor in.
The circuit breaker tripped
or a blown fuse.
Check the breaker and/or fuses.
The light button is
“
OFF
”
.
Press to turn the light ON.
Vibrations.
The humidor is not leveled.
Check to assure that the humidor is level.
The bottles are vibrating.
Make sure the bottles don
’
t touch each
others.
There is an object under the
humidor.
Remove the object under the humidor.
The humidor seems
to make too much
noise.
The humidor is not level.
Level the humidor.
Normal noise from the flow
of the refrigerant
The rattling noise may come from the flow
of the refrigerant, which is normal. As each
cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your
humidor. Contraction and expansion of the
inside walls may cause popping and
crackling noises.
The door will not
close properly.
The humidor is not level.
Level the humidor.
The door was reversed and
not properly installed.
Re-install the door properly.
The gasket is dirty.
Clean the door gasket.
The shelves are out of
position.
Place the shelves properly.
Moisture build up on
interior or
exterior of the Cigar
humidor.
This is normal during high
humidity periods.
Lower the room humidity.
This is normal in high
temperature environment.
Move the humidor to a humidor place, and
avoid heat and sunlight.
Prolonged or frequent door
openings.
Open the door less often.
The door does not seal
completely.
Check door gaskets for proper seal.
