MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 2
BULLETIN NO.
54-49-8390
SERVICE PARTS LIST
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 48-22-8392L Lid Assembly (20 oz.) (1)
48-22-8393L Lid Assembly (30 oz.) (1)
CATALOG NO. 48-22-8392R
48-22-8393R
48-22-8392B
48-22-8393B
REVISED BULLETIN
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
PACKOUT™ Tumblers
STARTING
SERIAL NO.
DATE
Aug. 2024
WIRING INSTRUCTION
1
LID COVER REMOVAL
STEP 1
Align arrows on the
lid and lid cover.
STEP 2
Insert nger through bottom
of the lid opening and push
the lid cover up.
STEP 3
Remove the lid cover with the
opposite hand.
Lid Cover Reinsertion
Place lid cover under groove
near opening and align
arrows on both lid and lid
cover for reinsertion.
