SF701
COUNTERTOP BLENDER
PROFESSIONAL
USER MANUAL
Important Safeguards ··················· 1
Specication ·························· 2
Parts Identication ····················· 3
How to Use ··························· 4
Warning ······························ 6
Care and Cleaning ······················ 7
Troubleshooting ······················· 8
Warranty ····························· 9
■
■
■
■
■
■
■
■
CONTENTS
1
Important Safeguards
IMPORTANT SAFEGUARDS
When using this electrical appliance, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Please check the voltage indicated on the product if corresponds with the
voltage of your electrical outlet before using.
3. Do not let cord hang on hot surface or over edge of table or counter.
4. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunction or has been damaged in any manner. Return the
appliance to the nearest authorized service facility for examination, repair or
adjustment.
5. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualied person in order to avoid a hazard.
6. Close supervision is necessary when any appliance is used by or near
children.
7. Avoid contacting the moving parts.
8. Keep hands and utensils out of container when blending to reduce the risk
of severe injury to persons or damage to the blender. A scraper may be used
but must be used only when the blender is not running.
9. The use of attachments not recommended or sold by manufacturer may
cause re, electric shock or injury.
10. Unplug from outlet when not in use, before putting on or taking o parts,
and before cleaning. To disconnect, turn any control to “off”, then
remove plug from wall outlet by grasping the plug, not the cord.
11. To reduce the risk of injury, never place blade assembly on motor unit
without the jar properly attached.
12. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliances by a person responsible for their safety.
13. Children should be supervised to ensure that they do not play with the
appliance.
14. Do not leave the machine on unattended.
15. When removing the blender from the motor unit, wait until the blades have
completely stopped.
16. Always operate blender with cover in place.
2
Specication
NOTE: Specications are subject to change without notice.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
Model
Max Power
Power Supply
Color
Dimension
SF701
1200W
120V~ 60Hz
Silver
6.89*6.34*15.71 inch
17. Always use the appliance on a secure, dry level surface.
18. Never place this appliance on or near a hot gas or an electric burner or
where it could touch a heated appliance.
19. Do not use outdoors.
20. Do not use appliance for other than its intended use.
3
Parts Identication
Ingredient Measuring Cup
Blender Jar
6-Blades Assembly
Motor Unit
Portable Jar
Small Cover Cover
Speed Knob
4-Blades Assembly
Lid
Seal Ring
Jar Base
2
4
6
1
3
5
7
9
11 12
8
10
1
2
3
4
5
6
7
8
9
6
12
10
4
11
4
4
1
5
6
3
How to Use
Before initial use
1. Before first use, unpack the appliance and place all parts on a horizontal
surface.
2. The jar assembly (including the measuring cup, lid, seal ring, jar, gasket,
blade assembly and jar base) has already been assembled into the motor
unit. Disassemble to wash all detachable parts except the motor unit. Refer
to the latter chapter CARE AND CLEANING.
3. Once all detachable parts have been cleaned and dry thoroughly, please
reassemble.
Blender Jar Operation
1. Holding the jar handle, put the jar base onto the jar bottom and secure the
jar base by turning it clockwise until tight. (Use 6-Blades Assembly)
2. Insert the assembled jar into the motor unit by ribs on the assembled jar
bottom with slots on the motor units, then rotate clockwise.
3. Add food ingredients to the blender jar. Usually, certain amount of puried
water has to be added to facilitate the smooth running of appliance. The
proportion of the food and water is 2:3.The amount of mixture should not
exceed the max level as indicated on the jar.
Food
6-Blades
Add the
Ingredient
2
5
1
5
2
3
4
4. Put the lid onto the jar assembly. Place the measuring cup exactly into the lid
by tting the small projection on both sides of the cup into the slots of the lid
and turning the cup clockwise until tight.
Note: When closing the lid, ensure that it is aligned and placed vertically
over the glass edge. Any tilting or inserting one side rst may prevent the lid
from closing properly.
5. With the unit plugged in, turn the knob to the speed (1、2 or P）you want.
6. If you want to add ingredients while the blender is working, remove the
measuring cup and place through the lid opening.
Portable Jar Operation
1. Add food ingredients to the portable jar. Usually, certain amount of puried
water has to be added to facilitate the smooth running of appliance.
2. Screw the jar base into the portable jar. (Use 4-Blades Assembly)
3. Insert the assembled jar into the motor unit by ribs on the assembled jar
bottom with Slots on the motor units, then rotate clockwise.
4. With the unit plugged in, turn the knob to the speed (1、2 or P）you want.
5. Turn the portable jar right side up and turn it over, turn blade assembly
counterclockwise to remove. Attach travel cup lid by twisting clockwise.
Food
4-Blades
6
Warning
1. Never use boiling liquids or run the appliance empty.
2. For each use, the consecutive operation time should not exceed 3 minutes.
3. If you want to stop the machine during operation, turn the knob to O position
anytime.
4. For best circulation of food that are to be blended with some liquid, pour the
liquid into the jar rst, then add solids.
5. Turn to "P" position rst to get smoother drinks for ice and large pieces of food.
6. Some of the tasks that cannot be performed eciently with a blender are:
beating egg whites, whipping cream, mashing potatoes, grinding meat,
mixing dough, extracting juice from fruit and vegetable
7. The following items should never be placed in the unit as they may cause
damage: bones, large pieces of solid, frozen food, or tough foods such as
turnips.
8. To crush ice, add up to 6 ice cubes which is not more than 2cm. If more ice is
needed, remove the cup and add cubes one by one through the lid opening.
9. The proportion of the food and water is 2:3. The amount of mixture should n
ot exceed the max level as indicated on the jar.
10. For best results in the fastest time, pulse a few times before running continu
ously. Pulses should be short bursts with about 1 second in between each o
ne to allow the blade to stop rotating between pulses.
7
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified
service personnel.
1. Before cleaning, unplug the blender.
2. Always wash immediately after use for easier cleaning. Don't let food dry on
the jar assembly as this will make cleaning dicult.
3. Pour a little warm soapy water into the jar and turn the knob to P position for
a few seconds. And then empty the jar.
4. Dismantle all detachable parts. Lift the assembled jar o the motor unit, then
unlock the jar base from the jar assembly, take the blade assembly and the
gasket out, nally remove the cup and the lid. Detach the seal ring from the
lid.
5. Rinse the cup, lid, seal ring, jar, gasket and jar base by hands or in a
dishwasher and then dry. They are dishwasher safe components, but the
temperature setting shall not exceed 70℃ .
6. Brush the blade clean using warm soapy water, then rinse thoroughly under
the tap. Don't touch the sharp blades, handle carefully. Don't immerse the
blade assembly in water. Leave to dry upside down away from children.
7. Wipe the motor unit with a damp cloth and dry thoroughly. Remove the
stubborn spots by rubbing with non-abrasive cleaner.
8. If liquids spill into the motor unit; first unplug the unit, then wipe with a
damp cloth and dry thoroughly.
CAUSION
1. Do not immerse the motor unit in liquid to prevent the risk of electric shock.
2. Do not use rough scouring pads or cleansers on parts or nish.
Environment Friendly Disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the
non-working electrical equipments to an appropriate waste
disposal centre.
8
If your problem is not listed or persists after trying the above solutions, please contact our
professional after sales team. Email: warr[email protected]
Troubleshooting
The blender stopped running
The seal ring won't come out
from the blade assembly for
cleaning.
The lid doesn't t in the glass
Unit appears to be leaking
The blade assembly is hard to
remove after blending
Food or ice isn't ne and smooth
The motor could have overheated. The resettable
fuse, which protects the motor due to overloading,
may have been tripped. When this happens, to reset
the appliance unplug the unit and let it cool for a
minimum of 15 minutes.
Then, reduce the contents of the blender jar and/
or clear any jams. Restart the unit as noted in the
operating directions.
Run under water and tap on the edge of sink upside
down to loosen the ring.
Ensure that both sides of the lid are inserted
simultaneously. Avoid inserting one side before the
other, as this can cause misalignment and prevent
proper closure.
1. Check if the correct jar assembly is used: 6-blade
assembly for blender jar, 4-blades assembly for
portable jar.
2. Check jar assembly is tightly attached to jar.
3. Make sure seal ring is properly in place.
4. Make sure seal ring is not damaged.
The ingredients cause pressure, and with the air
tight seal, pressure builds up creating a vacuum or a
suction eect. This is normal.
1. Better use Pulse function for starting the blending
process.
2. Check whether the food was not stirred around.
Scrape o the food and restart.
3. Check whether the food is too thick. The
proportion of the food and water is 2:3. Add more
water.
4. Don't overload blender jar or cups.
Problem Solution
9
Warranty
Free Extend Your Warranty to 2 Years
Register your product within 3 days after receiving the product. We will extend
warranty by an additional year.
Method 1: Please write down your order ID and purchase date on the form of
PRODUCT WARRANTY LEAFLET and shoot a photo.
Method 2: Just send a screenshot of your order details including order ID and
purchase date.
Method 3: Type your order ID and send.
Warranty Service Team: warr[email protected]
Thank you for purchasing the Countertop Blender
