Space Heater
US
Model:MG34QN
1
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk
of fire, electric shock, injury to persons, and hyperthermia, including the following:
1. Read all instructions before using this heater.
2. Before using the product for the first time, please check whether the voltage you are using
matches the one required by the product nameplate.
3. This machine is a high-power electrical appliances, before use must confirm that the power
socket and plug fit, not loose, the power supply can carry the maximum current must be
greater than the product use current, otherwise the machine in the long-term use of the
process may have poor contact or excessive current and lead to apparatus burn risk.
4. Do not use in the curtains and other places that are easy to be sucked in, should avoid the
surrounding obstacles and unstable places.
5. This product is strictly prohibited to use in the environment with flammable and explosive
materials, and the use of the environment should not exceed 40 ℃, at least 1 meter away from
combustible materials to prevent fire.
● INGESTION HAZARD: This product contains a buon cell or coin baery.
● DEATH or serious injury can occur if ingested.
● A swallowed buon cell or coin baery can cause Internal Chemical
Burns in as lile as 2 hours.
● KEEP new and used baeries OUT OF REACH Of CHILDREN
● Seek immediate medical aention if a baery is suspected to be
swallowed or inserted inside any part of the body.
WARNING
a. Remove and immediately recycle or dispose of used batteries according to local regulations
and keep away from children. Do NOT dispose of batteries in household trash or incinerate.
b. Even used batteries may cause severe injury or death.
c. Call a local poison control center for treatment information.
d. Replace the battery with 1 "CR2025" button cell battery and dispose of the used battery proper-
ly and in accordance with local law and ordinances.
e. The nominal battery voltage of the "CR2025" button battery is 3.0V.
f. Non-rechargeable batteries are not to be recharged.
g. Do not force discharge, recharge, disassemble, heat above 70°C(158°F) or incinerate. Doing so
may result in injury due to venting, leakage or explosion resulting in chemical burns.
h. Ensure the batteries are installed correctly according to polarity (+ and -).
i. Do not mix old and new batteries, different brands or types of batteries, such as alkaline,
carbon-zinc, or rechargeable batteries.
j. Remove and immediately recycle or dispose of batteries from equipment not used for an
extended period of time according to local regulations.
k. Always completely secure the battery compartment. If the battery compartment does not
close securely, stop using the product, remove the batteries, and keep them away from
children.
This product contains a button cell or coin battery
WARNING
2
IMPORTANT INSTRUCTIONS
6. Always unplug heater when not in use.
7. Make sure the machine is disconnected from the power supply when the power is off or the
product is moved.
8. Please check the power cord and the plug before use to see if there is damage.
9. Please do not violently bend, pull the power cord to avoid poor contact.
10. When using the tilt angle can not be greater than 10 degrees, can not be used upside down,
should be placed on a flat surface to use.
11. Prohibit the use of touching the air outlet protection network, in order to avoid burns.
12. Laid out the plug before the power should be turned off, do not pull the power cord, should
hold the plug head pull out.
13. Rush to pull the power plug with wet hands, the risk of electric shock.
14. Electric heater should not be placed directly under the power outlet.
15. Please do not cover the air inlet, and keep more than 15cm space with the wall.
16. When the electric heater is working, it is prohibited to touch the front air outlet to avoid burns.
17. When working, it is absolutely forbidden to insert hands or foreign objects into the body of the
machine.
18. Children should be supervised to ensure that they are not left alone with this product.
19. This product is not designed for use by people with physical, sensory or intellectual
impairments or lack of experience and common sense (including children) unless they are
given adequate care and guidance on how to use the product by their safety officer.
20. Electric heater surface stains, use a soft cloth or soap wipe clean, do not use gasoline or
alcohol and other organic solutions to wipe.
21. Do not use in high temperature, humid, dusty or volatile places such as acid and alkali oil.
22. Because the electric heater is covered or incorrectly placed can cause danger, so do not use
the programmer with automatic power on, timing dew or with any other device to use the
electric heater.
23. Please do not frequently open and close doors and windows when using, so as not to affect
the use of the effect.
24. When the power is connected to the heating product has a slight odor is a normal
phenomenon.
25. Water is strictly prohibited to shower the body, do not drip water into the electric heater.
26. Do not disassemble or disassemble the body at will, and do not modify the product in any
form to avoid danger.
27. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If
provided, use handles when moving this heater. Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front
of the heater and keep them away from the sides and rear.
28. Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
29. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has
been dropped or damaged in any manner. Discard heater, or return to authorized service
facility for examination and/or repair.
30. Do not use outdoors.
31. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
Never locate heater where it may fall into a bathtub or other water container.
32. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic
area and where it will not be tripped over.
IMPORTANT INSTRUCTIONS
33. To disconnect heater, turn controls to off, then remove plug from outlet.
34. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may
cause an electric shock or fire, or damage the heater.
35. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on
soft surfaces, like a bed, where openings may become blocked.
36. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline,
paint, or flammable liquids are used or stored.
37. Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
38. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord
or relocatable power tap (outlet/power strip).
39. Hyperthermia can result in death. Symptoms of hyperthermia include high body
temperature, headache, nausea, vomiting, tiredness, dizziness, fainting, and rapid pulse. If
you begin to experience symptoms related to hyperthermia, turn off the heater and seek
medical attention.
40. To avoid excessive room temperatures which can cause hyperthermia: DO NOT leave
product running unattended in a confined space around infants, or individuals with reduced
physical, sensory, or mental capabilities.
41.
READ AND SAVE THESE INSTRUCTIONS
3
SPECIFICATIONS
Model : MG34QN
Rated Voltage : 120V~
Rated Power : 1500W( at 25°C and 0°C )
Rated Frequency : 60Hz
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICEABLE
PARTS INSIDE
WARNING - Risk of
Heat Stroke
(Hyperthermia)
Hyperthermia can result in death in infants or others
Use caution to avoid overtheating indiviuals Read
and follow all instructions before use
REMOVE BEFORE USE！
4
STRUCTURE
Power Cord
Back Case
Handle
Control Panel
Display
PTC
Base
How to change the battery
1. Please push the locking latch
in the direction of arrow A,
and pull out the pull notch in
the direction of Arrow B at
the same time.
2. Use 1 'CR2025' Lithium
battery (included).
3. Insert the batteries, and
make sure that the positive
terminals are in the correct position.
4. Install back the cover.
REMOTE CONTROL
Baery installation
B
B
A
Pull Notch
Locking
latch
Power ON/OFF
Mode button
Temperature/Timer increase
Temperature/Timer decrease
Timer button
Oscillating button
5
INSTRUCTIONS FOR USE
Before use, please check all the parts are complete and undamaged.
Also, check the applied voltage matches with the label ( 120V~， 60Hz).
1. Power ON/OFF
● After plugging, the LED screen displays " -- " with a " Beep ". It's in the " stand-by " status.
● In standby mode, press " " button. The buzzer will sound once, and the display screen will
show " H3 ". The product will start operating in the default High-Heat mode, and the
indicator light will turn on in red.
● Press the " " button again, entering the product's shutdown state. The machine will
automatically blow out natural wind for 15 seconds to cool down its internal components.
At the same time, the screen will display a countdown starting from 15.
2. Switching Modes
● Touch " " button to switch between modes in the following sequence: Power Heat Mode
(H3) → ECO Mode → Natural Wind → Power Heat Mode (H3), and so on.
● Power heat with three heating levels: H3, H2, H1. In Power Heat mode, Touch " " or " "
to adjust the heating level.
① H3 Mode: the LED screen displays " H3 ", red light on.
② H2 Mode: the LED screen displays " H2 ", red light on.
③ H1 Mode: the LED screen displays " H1 ", red light on.
④ ECO Mode: the LED screen displays the temperature. Touch " " or " " to set the
temperature value from 59°F-95°F. Each press adjusts the temperature by 1°F, long
touch for 2 seconds to continuously change the temperature value. While setting the
temperature, the " °F " icon will flash. If there is no operation for 3 seconds, the setting
will be completed, and the " °F " icon will remain it.
⑤ Natural Wind: the LED screen displays shows no content, blue light on.
3. ECO Mode
● In ECO mode, the temperature adjustment range is between 59°F-95°F.
● The machine monitors the room temperature. When the temperature reaches the desired
level, it stops blowing warm air. Every 5 minutes, it activates the fan for 30 seconds to
promote air circulation and monitors the indoor temperature. If the temperature drops
below the set level, it resumes blowing warm air.
4. Timer Seing
When the heater is running, touch " " button for timer setting. Touch " " or " " to set
the timer from 0h to 24h. While setting the timer, the " " icon will flash. If there is no
operation for 3 seconds, the setting will be completed, and the " " icon will remain. The
heater will stop automatically when time is up.
5. Oscillation Function
Touch " " button it will start oscillating automatically, touch again to stop.
6. Memory Function
● The heater will record the temperature, mode and 24-Hour auto off function setting in the
last time. It will run as the last record when it turns on. (Not including timer setting.)
● After unplugged, Memory setting can be reset and back to default setting.
INSTRUCTIONS FOR USE
6
MAINTENANCE METHOD
● Before maintaining the product, be sure to turn off the power switch and unplug, and wait for
the product to cool completely before cleaning and maintenance.
● When the product has oil, it must be cleaned to avoid discoloration or breakage.
● Do not use water to rinse the body directly, use a soft cloth containing a little neutral
detergent to wipe lightly, and then wipe dry. Do not use acid and alkaline solvents to wipe, so
as not to cause discoloration or damage.
● After cleaning and maintaining the product, be sure to wait until it is fully dry before powering
on or storing.
● Please unplug the power cord when not in use for a long time. It is recommended that the
best use of the original packaging will be packed into the box of each component, placed in a
dry place for safekeeping.
● Avoid touching or scratching the product, so as not to affect the product performance.
● Any other servicing should be performed by an authorized service representative
7. 24-Hour Auto Off Function
● Long press the " " button for 3 seconds to turn this feature ON/OFF when this heater is
on standby. (Stand-by status: the LED screen displays '--') . When turn on, the display " "
icon will stay light on. If not, it will light off.
● When this feature is ON, the heater will shut off automatically after continuously running for
24hours.
● This feature is not ON by default. By memory function, the heater will record the 24-Hour
Auto Off function if the function have been turned on in the last time. After unplugged, it
need reset.
● Note: It can only be adjusted via the touch panel and cannot be controlled by a remote
control.
8. Reduce Brightless
● The lights are turned on by default;
● Press " " button for 3 seconds to turn off/on the display screen and the brightness of
the indicator light will decreased by 50%.(Tip:Due to strict safety regulations, protective
limitations prevent turning off the screen completely.)
● Note:lt can only be adjusted via the touch panel and cannot be controlled by a remote
control.
Note:
● When the heater is covered or blocked by foreign objects while it’s heating, it might stop
automatically due to overheating.
● With built-in tip over protection, the heater will stop automatically when it is tilted.
● If the heater is turned off because of overheat, after it cools down, unplugs the heater then
re-plugs in to restart.
● Keep flammable materials such as furniture, pillows, bedding, paper, clothing,and curtains at
least 0.9 meters away from the front of the heater and also maintain distance from the sides
and back.
● When it turns off, the PTC Will stop heating immediately, please allow 15 seconds for PTC to
cool down while the fan is still blowing air before completely stopping.
● If interrupted before confirmation in any mode, the changes will not take effect. For example,
if entering a specific mode and the corresponding indicator light is interrupted before blinking
5 times , the mode instruction will not take effect.
7
Unpleasant odor
The heater will emit some
odor in the first use.
Place the heater in a ventilated
environment before use.
The product is made from safe
flame-retardant material, so it's
normal to have some smells in the
first use. The odor will disappear
naturally after repeated use.
The remote control
doesn't work
Haven't pulled out the plastic
sheet in the remote control
before use.
Pull out the plastic sheet.
Replace the remote control battery.
Get closer to the machine and aim
at the infrared receiver in the front
of the machine.
The battery is running out of
power.
Beyond controllable distance.
Unable to find the
remote control
Check the beneath of the
control panel
Take out the remote control beneath
the control panel.
Plug wire overheats,
melts; Trip-out
Use the same power strip with
other high-power appliances.
Use the wall outlet instead of the
power strip.
Fault code on the
LED display
E2 - Temperature sensor is
shorted out.
Unplug it and contact Customer
Support.
Unplug it and contact Customer
Support.
Contact Customer Support.
E1 - Temperature sensor is
disconnected.
Unable to oscillate
Some electronic parts inside
the heater are damaged.
TROUBLE SHOOTING
Unable to start /
Stop working /
Frequent
sudden stops
Loud noise
Not enough heating
Low Heating Mode or Fan-only
Mode is on.
The space is too large to heat.
Set the temperature higher or have
the High Heating mode set.
Ensure a proper space for use; Users
get closer to the heater.
The plug is not properly in.
Overheat Protection has
been activated.
Something is closed to or
covering the heater.
The set temperature is lower
than the ambient temperature.
Make sure the thermostat is set at a
higher temperature than the ambient
temperature.
Unable to troubleshoot
the problem.
The fan goes wrong. Contact Customer Support.
Check and remove anything in the
air inlet.
Something blocks the air inlet
or outlet.
Contact Customer Support.
Connect the plug to a live electrical
outlet.
Turn off the heater, unplug it, and
let it cool for 5-10 minutes.
Check and remove anything on or
adjacent to the heater. Wait 5-10
minutes before re-plugging it.
Existing Problems Possible Causes Solution
8
BREEZOME CUSTOMER CARE
Thanks for choosing Breezome SPACE HEATER.
This product is covered with Breezome product and labor warranty for 12 months from the date
of its original purchase.
The warranty will not apply in cases of:
- Accident, misuse, or repairs performed by unauthorized personnel，
- Any unit that has been tampered with or used for commercial purpose.
- Normal wear and tear of wearable parts，
- Use enforce, damage caused by external influences，
- Damage caused by non-observance of the User Manual,e.g. connection to an unsuitable mains
supply or non-compliance with the instructions,
- Partially or completely demanded appliances，
- Defects caused by or resulting from damages from shipping or from repairs, service, or
alteration to the product or any of its parts that have been performed by a repair person not
authorized by Breezome.
We can only provide after sales service for products that are sold by Breezome or Breezome
authorized retailers and distributors. If you have purchased your unit from a different place,
please contact your seller for return and warranty issues.
