INSTRUCTION MANUAL
10W COB Rechargeable Worklight
With Bluetooth Speaker
Multi-function, powerful
worklight & top torch with a
powerful speaker
COB Worklight
Featuring COB technology the
worklight delivers extremely high
output with uniform and even
illumination
Top Torch is powered by 3W LED
Light Output
High quality output in multiple
modes
OLED screen display with real
time display of lumens and
battery
User controlled output by
pressing the increase (+) or
decrease (–) buttons
Powerful Bluetooth Speaker
Superior sound quality speaker
with bluetooth function with 10
meter (32') range for endless
music at work
Durable Construction
Impact proof & water resistant
ABS body with rubber coating
Hands Free Operation
180° Swiveling stand with super
strong magnets to position light
on any metallic surface
Power Source
LITHIUM
RECHARGEABLE
RECHARGEABLE
BATTERY
3.7V 2400 mAh
Charging of Battery
Charge using Type C USB cable
provided with the light. USB port
protected by rubber bezel
Charge Time
2 hours (indicated via LED
display showing charge level in
percentage)
Charge You Mobile Device
USB output port for use as power
bank
DESCRIPTION
10W COB Rechargeable worklight with Bluetooth Speaker
RoHs
10W COB
main
light
3W LED top
torch
OLED screen
real time
display of
Lumens and
battery level
Power
button
Intensity
control
buttons
USB output port to
charge mobile devices
180°
Swivelling Magnetic Stand: The base can swivel
upto 180° to adjust to the required angle. The
magnetic end helps ax the light for hands free use
BEAM
ANGLE
120°
BEAM
DISTANCE
50m
WATER & DUST
PROOF RATING
IP65
−20°C TO +40°C
(-4°F TO 104°F)
OPERATING
TEMPERATURE
BLUETOOTH
1ST PRESS 2ND PRESS
3RD PRESS 4TH PRESS
TOP
TORCH
WORKLIGHT
CONTINUOUS
RED LIGHT
RED
FLASHING
LUMEN 260 500
RUN TIME 3.5 hrs 3 hrs
WORKING MODE
LED 397 neutral.indd 1LED 397 neutral.indd 1 01-10-20 11:08:35 AM01-10-20 11:08:35 AM
2
SAFETY INFORMATION
• Follow workshop health & safety rules,
regulations and conditions when using the
worklight.
• When not in use, worklight should be stored in
a dry location to inhibit rust.
• During their period of use, accessories must be
checked for wear, cracks and other damage,
replace any damaged or worn parts.
• Use genuine parts only. Unauthorized parts
may be dangerous and will void the warranty.
• Keep the worklight clean and in good working
order for best and safest performance.
• DO NOT use the lamp in the immediate vicinity
of inflammable materials or gases.
• DO NOT point the light directly in your own or
any other person’s or animal’s eyes.
• DO NOT drop, throw or abuse the worklight.
• Eyes protection: Wear a protective mask or
protective eyewear.
• Check that the product has not suered any
damage during transport or storage. Clean and
remove any dust or residual packing material.
• Read the instructions carefully before using
worklight and keep them for further reference.
WARNING!
• DO NOT immerse the worklight in water.
• DO NOT place the worklight near a fire or any
other source of intense heat.
• DO NOT attempt to open, disassemble, modify
or service the worklight.
• DO NOT expose the worklight to temperatures
above 40°C (104° F).
• DO NOT use the worklight if you suspect that
the batteries or the casing is damaged
PACKAGE CONTENT
DESCRIPTION QTY.
10W COB Rechargeable worklight with
bluetooth speaker
1
Type C USB cable 1
O.I.P.M. 1
OPERATING INSTRUCTIONS
LED Display at back shows charge levels in
percentage of battery remaining in the worklight
along with real time lumen output.
1. Fully charge the battery before the first use.
To charge, connect the worklight with Type C
USB charger cable provided with it.
2. While charging, the battery icon will blink
continuously on the LED screen.
3. When the battery is fully charged, the battery
icon will show 100%. Full charging takes about
2 hours.
4. Press the power button located at the back of
the light
• Once for top torch “ON”
• Twice for worklight “ON”
• Three times for continuous red light “ON”
• Four times for red SOS flashing “ON”
• Five times for switching “OFF” the light
5. Intensity of all four modes of light can be
controlled pressing the increase (+) or
decrease (–) buttons at the back of the
worklight.
6. For bluetooth connection of worklight to
phone, press and hold the power button for
switching on the Bluetooth of the worklight
and connect to “BT500” from your phone.
7. Built-in Mic is provided in the worklight for
taking calls while working.
8. The worklight can also be used as power bank
for charging mobile devices.
MAINTENANCE
• Clean any dirt from the housing or the lens
immediately, since it could cause overheating.
• If required, clean with a dry and clean cloth.
Do not use cleaners that contain abrasives or
solvents.
• When not in use, worklight should be stored in
a dry location.
TROUBLESHOOTING
PROBLEM POSSIBLE
CAUSE
CORRECTIVE ACTION
Worklight does not
work
Low battery Recharge the battery
The Bluetooth
speaker does not
work
Bluetooth
out of range
Worklight and the
phone should be within
10 meter (33ft) range
If the COB
Rechargeable
worklight with
bluetooth speaker
still doesn't work
Contact nearest
authorized service
dealer
DISPOSAL
The components or the used products must be
given to companies that specialize in the disposal
and recycling of industrial waste.
