User Manual
Please read these instructions before operating the product
Bien lire ces instructions avant d’utiliser le produit
Lea estas instrucciones antes de utilizar el producto
Laser Level
D2 PLUS
model no.: PM011S
English
Warranty
Index
01~14
15
Figure A
1
2
6
3
4
5
7 8
Figure B Figure D
Figure E
Figure F
Figure C
Locked Unlock
Contents
1.Safety Warning
2.Package Content
3.Product Overview
4.Operation and Function
5.Specifications
6.Troubleshooting
02
08
09
10
12
13
- 01 -
Contents
1.Safety Warning
2.Package Content
3.Product Overview
4.Operation and Function
5.Specifications
6.Troubleshooting
1. Safety Warning
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please read the
manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
WARNING: Read and understand all instructions. Failure to follow the warnings
and instructions may result in electric shock,fire and/or serious injury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in property damage.
- 02 -
SAVE THESE INSTRUCTIONS
The label on your tool may include the following symbols.
Warning Labels
For your convenience and safety, the following labels are on your laser.
WARNING: Laser Radiation Exposure. Do not disassemble or modify the laser level.
There are no user serviceable parts inside. Serious eye injury could result.
WARNING: Hazardous Radiation. Use of controls or adjustments or performance of
procedures other than those specified herein may result in hazardous radiation
exposure.
V
mW
nm
2
volts
milliwatts
laser warning symbol
wavelength in nanometers
Class 2 Laser
WARNING: To reduce the risk of injury, user must read instruction manual.
WARNING: LASER RADIATION. DO NOT STARE INTO BEAM. Class 2 Laser
Product
- 03 -
SAVE THESE INSTRUCTIONS
The label on your tool may include the following symbols.
Warning Labels
For your convenience and safety, the following labels are on your laser.
•
•
•
•
•
•
•
•
•
Do not operate the laser in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Store idle laser out of reach of children and other untrained persons. Lasers are
dangerous in the hands of untrained users.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired
Do not use optical tools such as a telescope or transit to view the laser beam. Serious
eye injury could result.
Do not place the laser in a position which may cause anyone to intentionally or
unintentionally stare into the laser beam. Serious eye injury could result.
Do not position the laser near a reflective surface which may reflect the laser beam
toward anyone’s eyes. Serious eye injury could result.
Turn the laser off when it is not in use. Leaving the laser on increases the risk of staring
into the laser beam.
Do not modify the laser in any way. Modifying the tool may result in hazardous laser
radiation exposure.
Do not operate the laser around children or allow children to operate the laser. Serious
eye injury may result.
•
•
WARNING:Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire and/ or serious personal injury.
Work Area
•
•
•
Personal Safety
•
•
•
Tool Use and Care
•
•
•
Stay alert, watch what you are doing and use common sense when operating a laser
tool. Do not use tool while tired or under the influence of drugs, alcohol, or medica-
tion. A moment of inattention while operating power tools may result in serious
personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection may be required for appropriate conditions.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used on
another tool.
Service
•
•
Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of electric shock or injury.
Do not remove or deface warning labels. If labels are removed user or others may
inadvertently expose themselves to radiation.
Position the laser securely on a level surface. Damage to the laser or serious injury
could result if the laser falls
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate laser tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust.
Keep children and bystanders away while operating a laser tool.Distractions can cause
you to lose control.
- 04 -
•
•
•
•
•
•
•
•
•
Do not operate the laser in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Store idle laser out of reach of children and other untrained persons. Lasers are
dangerous in the hands of untrained users.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired
Do not use optical tools such as a telescope or transit to view the laser beam. Serious
eye injury could result.
Do not place the laser in a position which may cause anyone to intentionally or
unintentionally stare into the laser beam. Serious eye injury could result.
Do not position the laser near a reflective surface which may reflect the laser beam
toward anyone’s eyes. Serious eye injury could result.
Turn the laser off when it is not in use. Leaving the laser on increases the risk of staring
into the laser beam.
Do not modify the laser in any way. Modifying the tool may result in hazardous laser
radiation exposure.
Do not operate the laser around children or allow children to operate the laser. Serious
eye injury may result.
•
•
WARNING:Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire and/ or serious personal injury.
Work Area
•
•
•
Personal Safety
•
•
•
Tool Use and Care
•
•
•
Stay alert, watch what you are doing and use common sense when operating a laser
tool. Do not use tool while tired or under the influence of drugs, alcohol, or medica-
tion. A moment of inattention while operating power tools may result in serious
personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection may be required for appropriate conditions.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used on
another tool.
Service
•
•
Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of electric shock or injury.
Do not remove or deface warning labels. If labels are removed user or others may
inadvertently expose themselves to radiation.
Position the laser securely on a level surface. Damage to the laser or serious injury
could result if the laser falls
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate laser tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust.
Keep children and bystanders away while operating a laser tool.Distractions can cause
you to lose control.
- 05 -
•
•
•
•
•
•
•
•
•
Do not operate the laser in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Store idle laser out of reach of children and other untrained persons. Lasers are
dangerous in the hands of untrained users.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired
Do not use optical tools such as a telescope or transit to view the laser beam. Serious
eye injury could result.
Do not place the laser in a position which may cause anyone to intentionally or
unintentionally stare into the laser beam. Serious eye injury could result.
Do not position the laser near a reflective surface which may reflect the laser beam
toward anyone’s eyes. Serious eye injury could result.
Turn the laser off when it is not in use. Leaving the laser on increases the risk of staring
into the laser beam.
Do not modify the laser in any way. Modifying the tool may result in hazardous laser
radiation exposure.
Do not operate the laser around children or allow children to operate the laser. Serious
eye injury may result.
•
•
WARNING:Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire and/ or serious personal injury.
Work Area
•
•
•
Personal Safety
•
•
•
Tool Use and Care
•
•
•
Stay alert, watch what you are doing and use common sense when operating a laser
tool. Do not use tool while tired or under the influence of drugs, alcohol, or medica-
tion. A moment of inattention while operating power tools may result in serious
personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection may be required for appropriate conditions.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used on
another tool.
Service
•
•
Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of electric shock or injury.
Do not remove or deface warning labels. If labels are removed user or others may
inadvertently expose themselves to radiation.
Position the laser securely on a level surface. Damage to the laser or serious injury
could result if the laser falls
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate laser tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust.
Keep children and bystanders away while operating a laser tool.Distractions can cause
you to lose control.
- 06 -
•
•
•
•
•
•
•
•
•
Do not operate the laser in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.
Store idle laser out of reach of children and other untrained persons. Lasers are
dangerous in the hands of untrained users.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired
Do not use optical tools such as a telescope or transit to view the laser beam. Serious
eye injury could result.
Do not place the laser in a position which may cause anyone to intentionally or
unintentionally stare into the laser beam. Serious eye injury could result.
Do not position the laser near a reflective surface which may reflect the laser beam
toward anyone’s eyes. Serious eye injury could result.
Turn the laser off when it is not in use. Leaving the laser on increases the risk of staring
into the laser beam.
Do not modify the laser in any way. Modifying the tool may result in hazardous laser
radiation exposure.
Do not operate the laser around children or allow children to operate the laser. Serious
eye injury may result.
•
•
WARNING:Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire and/ or serious personal injury.
Work Area
•
•
•
Personal Safety
•
•
•
Tool Use and Care
•
•
•
Stay alert, watch what you are doing and use common sense when operating a laser
tool. Do not use tool while tired or under the influence of drugs, alcohol, or medica-
tion. A moment of inattention while operating power tools may result in serious
personal injury.
Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes,
hard hat, or hearing protection may be required for appropriate conditions.
Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled
with the switch is dangerous and must be repaired.
Store idle tools out of reach of children and other untrained persons. Tools are
dangerous in the hands of untrained users.
Use only accessories that are recommended by the manufacturer for your model.
Accessories that may be suitable for one tool, may become hazardous when used on
another tool.
Service
•
•
Tool service must be performed only by qualified repair personnel. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instructions in the
Maintenance section of this manual. Use of unauthorized parts or failure to follow
Maintenance Instructions may create a risk of electric shock or injury.
Do not remove or deface warning labels. If labels are removed user or others may
inadvertently expose themselves to radiation.
Position the laser securely on a level surface. Damage to the laser or serious injury
could result if the laser falls
Keep your work area clean and well lit. Cluttered benches and dark areas invite
accidents.
Do not operate laser tools in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust.
Keep children and bystanders away while operating a laser tool.Distractions can cause
you to lose control.
- 07 -
2.Package Content
Manual
Use Manual x 1
Drawstring Bag x 1
Target Plate x 1
D2 plus Laser level x 1
USB cablex 1
L Bracket x 1
- 08 -
3.Product Overview
1 - Vertical Laser outlet
2 - Horizontal Laser outlet
3 - Pendulum Lock
4 - Charging Port
5 - Tripod thread fitting (1/4”-20)
6 – Battery indicator
7 – Power Switch
8 – Pulse Indicator
WARNING:
Never modify the tool or any part of it. Damage to the laser or personal injury could
result.
1
2
6
3
4
5
7 8
- 09 -
4.Operation and Function
Two working mode- Manual and Self-level(See Figure B )
-
•
-
•
-
•
-
-
•
-
•
-
-
•
-
-
-
-
Pendulum lock ③ has two position – Locked/Unlock
Locked position:
The laser beam is fixed and flash every 5s, rotate the unit to get any angle beam you
expected.(see figure D)
Unlock position:
The lasers are designed to self-level. If the laser has been tilted so much that it cannot
self-level ( > 3° ), the laser beam will flash every 0.5s. THE LASER IS NOT LEVEL (OR
PLUMB) AND SHOULD NOT BE USED FOR DETERMINING OR MARKING LEVEL OR
PLUMB. Try repositioning the laser on a more level surface.
To Turn the Lasers On and Off
With the laser off (initially, Pendulum lock ③ on locked position), place it on a flat level
surface. Two ways to turn the laser on/off,
Way one: turn on the laser by pressing Power Switch ⑦ 0.5s, and shut it off by pressing 2s
Way two: turn on by pushing the Pendulum Lock③ to the Unlocked position, Turn off
by pushing it back.
Swith laser line
When laser is on and laser line is fixed or on levelling, short press the power switch⑦
then get which one you wanted.
Pulse Mode(See Figure F)
Active pulse function by press Power Switch ⑦ 2s when Pendulum lock ③ at unlock
position.
Under pulse mode, the unit can match with detector for working in a brighter environment.
Charging tips(See Figure C )
The machine is equipped with 3.7V lithium battery, which is built-in and non-remov-
able.
if battery is low or no power to turn on. you should charge machine directly with type C
cable,
The battery indicator will be displayed in flash way during charging process.
The battery indicator will be displayed as solid after battery is full charged.
- 10 -
Two working mode- Manual and Self-level(See Figure B )
-
•
-
•
-
•
-
-
•
-
•
-
-
•
-
-
-
-
Pendulum lock ③ has two position – Locked/Unlock
Locked position:
The laser beam is fixed and flash every 5s, rotate the unit to get any angle beam you
expected.(see figure D)
Unlock position:
The lasers are designed to self-level. If the laser has been tilted so much that it cannot
self-level ( > 3° ), the laser beam will flash every 0.5s. THE LASER IS NOT LEVEL (OR
PLUMB) AND SHOULD NOT BE USED FOR DETERMINING OR MARKING LEVEL OR
PLUMB. Try repositioning the laser on a more level surface.
To Turn the Lasers On and Off
With the laser off (initially, Pendulum lock ③ on locked position), place it on a flat level
surface. Two ways to turn the laser on/off,
Way one: turn on the laser by pressing Power Switch ⑦ 0.5s, and shut it off by pressing 2s
Way two: turn on by pushing the Pendulum Lock③ to the Unlocked position, Turn off
by pushing it back.
Swith laser line
When laser is on and laser line is fixed or on levelling, short press the power switch⑦
then get which one you wanted.
Pulse Mode(See Figure F)
Active pulse function by press Power Switch ⑦ 2s when Pendulum lock ③ at unlock
position.
Under pulse mode, the unit can match with detector for working in a brighter environment.
Charging tips(See Figure C )
The machine is equipped with 3.7V lithium battery, which is built-in and non-remov-
able.
if battery is low or no power to turn on. you should charge machine directly with type C
cable,
The battery indicator will be displayed in flash way during charging process.
The battery indicator will be displayed as solid after battery is full charged.
- 11 -
5.Specifications
Light Source
Laser Wavelength
Laser Power
Accuracy (Level):
Leveling/Compensation Range
Power Source
Working time per full charge
Operating Temperature
Storage Temperature
Environmental
Laser diodes
510-530nm
≤1mw (each beam) CLASS 2
100ft (30m) @100lux
200ft(60m) with detector
± 3/32in per 30’(±2mm per 10m)
±3 °
3.7V 2600mAh Li-ion
7hr
20°F to 115°F (-10°C to 45°C)
-5°F to 140°F (-20°C to 60°C)
Water & Dust Resistant to IP54
Working Range
Maximum relative humidity 80% for temperatures
up to 88°F (31°C) decreasing linearly to 50%
relative humidity at 104°F (40°C)
Humidity
- 12 -
The Laser Does Not Turn On
•
•
The Laser Beams Flash
The lasers are designed to self-level up to an average of 3° in all directions If the laser is
tilted so much that the internal mechanism cannot level itself, the laser beams will flash
indicating that the tilt range has been exceeded. THE FLASHING BEAMS CREATED BY
THE LASER ARE NOT LEVEL OR PLUMB AND SHOULD NOT BE USED FOR DETERMIN-
ING OR MARKING LEVEL OR PLUMB. Try repositioning the laser on a more level surface.
The Laser Beams Will Not Stop Moving
The laser is a precision instrument. Therefore, if it is not positioned on a stable (and
motionless) surface, the laser will continue to try to find level. If the beam will not stop
moving, try placing the laser on a more
stable surface. Also, try to make sure that the surface is relatively flat,so that the laser is
stable.
-14 -
- 15 -
Warranty Info
Your Warranty Includes
24-Month Coverage
Within 24 months of purchase, we will provide timely and effective online after-sales service.
We will repair or replace any defective product (due to manufacturing fault).
How to Return Your Fanttik Product
Contact [email protected] with your order number.
If your purchase was fulfilled by Amazon, please use Amazon’s 30-day return service.
