ATV REAR CARGO RACK
MODEL NO’S: ATCR01R, ATCR02R
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! This product relies on the integrity of the existing structures on the ATV it is tted to. It is the owner’s responsibility to
ensure that:
9 The structure of the ATV is sound and capable of withstanding the weight of the rack and its contents.
9 The ATV manufacturer’s specication has been consulted to ensure that the ATV is safe to operate with cargo rack/s and their loads.
9 Ensure that the rack if tted to the ATV using the supplied ttings and that the ttings are capable of supporting both rack and load.
9 Check rack xings before each use.
9 Risk assess the load and where it is to be taken before use.
9 Remember that your ability to control the ATV by your body movements will be considerably reduced when carrying a load.
9 Racks and their loads should be tted as close to the centre of gravity as possible. Loads should be secured as appropriate.
8 DO NOT use racks to carry passengers.
2. INTRODUCTION
Lightweight but sturdy mesh surface to avoid accumulation of dust and water. Small mesh design protects items from falling through.
Constructed from high quality materials, capable of holding large items securely. Firmly attaches to ATV to prevent it falling o, even in
demanding conditions. Ample storage space with short sides and open top, allowing larger objects to t. Supplied with quick and easy ttings
and ts onto most standard ATVs. Powder coated metal frame, ensuring high strength and good wear resistance to withstand rugged outdoor
use.
3. INSTALLATION
3.1. The 4 U bolt xings must be used around the box section structure of the rack and the rack assembly of the ATV.
3.2. Location of the 4 U bolt xings is dependant on the design of the ATV. However they must be spaced so as to spread the load equally
across the rack.
Refer to
instruction
manual
ATCR01R ATCR02R Issue:1 27/11/24
Original Language Version
© Jack Sealey Limited
This edge to front of ATV
Original Language Version
© Jack Sealey Limited
ATCR01F ATCR02R Issue:1 27/11/24
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
