BELLE-AQUA KETTLE
User Guide
KE7110
1
Sunbeam’s Safety Precautions
Sunbeam’s Safety Precautions 1
Features of your Sunbeam Belle-Aqua
™
Kettle 2
Using your Sunbeam Belle-Aqua
™
Kettle 3
Sunbeam’s 3-Way Safety System 4
Care and Cleaning of your Sunbeam 4
Belle-Aqua
™
Kettle
Contents
SAFETY PRECAUTIONS FOR YOUR SUNBEAM
KETTLE.
• Always operate the kettle on a flat, level surface.
• Boiling water will scald. Do not leave a boiling or
hot kettle near or where children may touch it.
• Do not leave the power cord near the edge of a
bench top where children may touch or pull it.
• Boiling water may be ejected, if overfilled.
• Always ensure lid is securely closed to ensure
correct operation of the kettle.
• Do not operate the kettle without water.
• Always turn the power off and unplug the cord
while the kettle is NOT in use.
• Your kettle must only be used with the power base
supplied.
• Do not move kettle while switched on.
• Never fill above the 'max' indication as hot water
may be ejected.
• Always store excess cord in the storage facility
underneath the power base.
• Always be aware of steam being emitted from the
spout or lid especially during refilling.
• Do not use the kettle to heat anything other than
water.
• Avoid spillage on the connector.
• Do not use an appliance for any purpose other
than its intended use.
• The heating element surface is subject to residual
heat after use.
Important instructions – retain for
future use.
Sunbeam is very safety conscious when designing and
manufacturing consumer products, but it is essential
that the product user also exercise care when using
an electrical appliance. Listed below are precautions
which are essential for the safe use of an electrical
appliance:
• Read carefully and save all the instructions provided
with an appliance.
• Always turn the power off at the power outlet before
you insert or remove a plug. Remove by grasping the
plug - do not pull on the cord.
• Turn the power off and remove the plug when the
appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord
unless this cord has been checked and tested by a
qualified technician or service person.
• Always use your appliance from a power outlet of the
voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• The temperature of accessible surfaces may be high
when the appliance is operating.
• Never leave an appliance unattended while in use.
• Do not use an appliance for any purpose other than
its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang over
the edge of a table or bench top or touch any hot
surface.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair or
adjustment.
• For additional protection, Sunbeam recommend the
use of a residual current device (RCD) with a tripping
current not exceeding 30mA in the electrical circuit
supplying power to your appliances.
• Do not immerse the appliance in water or any other
liquid unless recommended.
• Appliances are not intended to be operated by means
of an external timer or separate remote control
system.
• This appliance is intended to be used in household
and similar applications such as: staff kitchen areas
in shops, offices and other working environments;
farm houses; by clients in hotels, motels and other
residential type environments; bed and breakfast
type environments.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
32
Features of your Sunbeam
Belle-Aqua
™
Kettle
Large spout
Enables quick and easy
filling at the tap, without
the need for removal of the
lid.
1800 watt concealed
element
The fast boil 1800 watt
element is concealed in
the base of the kettle for
longer element life. The
smooth stainless floor
reduces scale build up and
allows for easy cleaning.
Lid release button
Simply pull the lid
release button to open
the lid.
ON/OFF switch with auto
cut-out on handle
Lights up to indicate
that the kettle is on and
heating. Switches the
kettle off automatically
after boiling.
Stylish brushed stainless
steel design
Long life stainless steel to
suit any kitchen décor.
Cord storage facility
Excess cord can be wound
around the cord storage
facility underneath the
power base.
360 degree cordless power
base
Designed to allow you to
place the kettle
on the base in any
direction.
3-Way Safety System.
1 – Automatically switches the kettle off after boiling.
2 – Cuts out for boil-dry protection.
3 – Shuts down in case of overheating.
Before using your kettle.
It is recommended that you clean your kettle
before first use by filling the kettle with water,
up to the maximum level indicator, boil and
discard.
Using your kettle.
1. To fill the kettle, remove it from the power
base and open the lid by pushing the
button on the top of the lid. Alternatively,
the kettle may be filled through the pouring
spout.
2. Fill the kettle with the desired amount of
water (minimum 1 cup/250ml). Always
fill the kettle between the minimum and
maximum marks. Too little water will result
in the kettle switching off before the water
has boiled.
Note: Do not fill the kettle over the maximum
level, as water may spill out of the spout
when boiling.
3. Push the lid closed firmly until it locks into
position.
4. Place the kettle on the power base and
connect the plug into a 230/240 Volt
AC power outlet. Turn the power ON.
5. Press the ON/OFF switch located on the
handle downwards. The light will illuminate
to indicate the kettle is heating.
The
kettle will switch off automatically once
the water has boiled.
Important: Ensure the lid is firmly closed. The
kettle will not turn off if the lid is left open.
Do not remove the kettle from the power base
while in use.
Important: Avoid touching metal surfaces when
operating the kettle as these will be hot.
6. Lift the kettle from the power base and
pour the water.
Note: Use caution when pouring the water
from your kettle as boiling water will scald.
7. The kettle may be stored on the power
base while not in use. The kettle will not
re-boil until the ON/OFF switch is pressed
downward.
Note:
Ensure the power is turned off at the
power outlet when the kettle is not in use.
Should you accidentally allow the kettle to
operate without water, it will cut out for boil-
dry protection. If this occurs, allow the kettle
to cool before filling with cold water and
re-boiling.
Cord Storage Facility.
Excess cord can be stored by winding the
cord around the storage facility underneath
the power base.
Using your Sunbeam Belle-Aqua
™
Kettle
360° power base
54
Safety is a major consideration in the
design of a Sunbeam kettle. This is why we
have developed our 3-Way Safety System,
which ensures that your kettle will:
1. Automatically switch off after boiling.
For convenience, safety and energy
efficiency, your Sunbeam kettle features an
auto cut-out device.
2. Cut-out for boil-dry protection.
If the kettle is operated without water, it
will automatically cut-out,
preventing any damage to
the element.
3. Shut-down in case of
overheating.
In the event of overheating, the kettle will
automatically shut down to prevent further
damage. Should this occur, take your kettle
to a Sunbeam Service Centre or Appointed
Service Agent.
Sunbeam’s 3-Way Safety System
Care and Cleaning
Always disconnect the kettle from the power
outlet before cleaning.
Never immerse the kettle switch area, cord
or power base in water, or allow moisture to
come into contact with these parts.
Descale Your Kettle Regularly
Mineral deposits in tap water solidify when
the water is heated. Lime scale may be
white, coloured, even rusty-looking and is
normally visible but phosphate scale isn’t
generally visible but may cause the water to
appear cloudy when heated. This may cause
the interior of the water gauge to discolour,
trigger the boil-dry cut-out mechanism or even
reduce the kettle’s life.
Even in soft water areas it is important to
descale your kettle regularly to help maintains
its lifecycle.
NOTE: Failure to descale products regularly
can be deemed as negligent handling and
any faults caused by mineral build up will
not be covered by the Sunbeam 12 Month
Guarantee.
To remove this build-up, use Sunbeam Liquid
Descaler, a simple to use, non-toxic cleaner
available from Sunbeam Appointed Service
Agents.
Alternatively:
1. Fill the kettle with 1 cup of white vinegar
and the remainder with water and allow to
stand overnight. DO NOT BOIL.
2. Empty the solution from the kettle. Any
stains remaining inside the spout can be
removed by rubbing with a damp cloth. Fill
the kettle with clean water, bring to boil
and then discard the water. Repeat and the
kettle will then be ready to use.
To clean the kettle exterior
The plastic surface may be wiped over with a
damp cloth and polished with a soft dry cloth.
CAUTION: To prevent damage to the appliance,
do not use alkaline, chemical or abrasive
cleaners. Use a soft cloth and a mild
detergent to protect the exterior surface.
To clean the mesh filter
CAUTION: Before removing or refitting the
filter, switch off the kettle and empty it. Allow
it to cool completely, then unplug the power
base from the main supplied socket. Never
operate the kettle without the filter fitted.
Open the lid. Grasp the top of the mesh
filter and pull upwards to remove. Wash in
warm soapy water and dry thoroughly before
replacing in the kettle.
Cleaning the concealed heating element
This kettle features a non-corrosive stainless
steel heating element. Over time, scale may
build up on the concealed element inside the
kettle, causing discolouration that may have
the appearance of rust. Be assured this is not
rust. If this occurs clean with a Scotchbrite
scourer or similar and a suitable abrasive
cleaning cream. Rinse and clean throughly
with tap water before using your kettle again.
Should you experience any
difficules with your product
during the warranty period,
please contact our customer
service line for advice on 1300
881 861 in Australia, or 0800
786 232 in New Zealand.
Australia
www.sunbeam.com.au
1300 881 861
New Zealand
www.sunbeam.co.nz
0800 786 232
This product is covered by a 12 month
replacement or repair warranty, which is
in addion to your rights under the
Australian Consumer Law (if your product
was purchased in Australia) or New Zealand
Consumer Guarantees Act (if your product
was purchased in New Zealand).
Upon receipt of your claim, Crock-Pot will
seek to resolve your difficules or, if the
product is defecve, advise you on how to
obtain a replacement or refund.
To assist us in managing warranty claims, we
recommend you register your product as soon
as praccable aer purchase, on our
Sunbeam website and uploading a copy of
your original receipt. View the Support
secon of the Sunbeam website.
In order to make a claim under our warranty,
you must have the original proof of purchase
documentaon for the product and present it
when requested (if not already uploaded to
our website).
Should your product develop any defect
within 12 months of purchase because of
faulty materials or workmanship, we will
replace or repair it, at our discreon, free of
charge. A product presented for repair may be
replaced by a refurbished product of the same
type rather than being repaired. Refurbished
parts may be used to repair the product.
Our replacement or repair warranty only
applies where a defect arises as a result of
faulty material or workmanship during the
warranty period. Your warranty does not
cover misuse or negligent handling
(including damage caused by failing to use the
product in accordance with this instrucon
booklet), accidental damage, or normal wear
and tear.
Your warranty does not:
• cover freight or any other costs incurred in
making a claim, consumable items,
accessories that by their nature and limited
lifespan require periodic renewal (such as
filters and seals) or any consequenal loss or
damage; or
• cover damage caused by:
-power surges, power dips, voltage supply
problems, or use of the product on
incorrect voltage;
-servicing or modificaon of the product
other than by Crock-Pot or an authorised
service centre;
-use of the product with other
accessories, aachments, product
supplies, parts or devices that do not
conform to Crock-Pot specificaons; or
-exposure of the product to abnormally
corrosive condions; or
• extend beyond 3 months if the product is
used in commercial, industrial, educaonal or
rental applicaons.
The benefits given to you by our warranty
are in addion to other rights and remedies
under law in relaon to the product.
In Australia our goods come with guarantees
that cannot be excluded under the
Australian Consumer Law. You are entled
to a replacement or refund for a major
failure and for compensaon for any other
foreseeable loss or damage. You are also
entled to have the goods repaired or
replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
Our goods also come with guarantees that
cannot be excluded under the New Zealand
Consumer Guarantees Act.
If your warranty claim is not accepted, we
will inform you and if requested to do so by
you, repair the product provided you pay
the usual charges for such repair. You will
also be responsible for all freight and other
costs.
Should your product require repair or
service aer the warranty period, contact
your nearest service centre. For a complete
list of service centres, visit our website or
call our customer service line for advice on
1300 881 861 in Australia, or 0800 786 232
in New Zealand.
KE7110_21EM1 (ANZ)
GCDS-SUN1992729-JC
Part Number: 4181A
Need help with your appliance?
Contact our customer service team or visit our
website for information and tips on getting the
most from your appliance.
Australia | visit www.sunbeam.com.au
phone 1300 881 861
New Zealand | visit www.sunbeam.co.nz
phone 0800 786 232
Newell Australia Pty Ltd. ABN 68 075 071 233
Sunbeam is a registered trade mark.
Made in China to Sunbeam’s specification.
Due to minor changes in design or otherwise,
the product you buy may differ slightly from the one shown here.
Approved by the appropriate electrical regulatory authorities.
©Copyright Sunbeam 2021.
