V0.1
SPORTS MATE P200
Ball Pump
(1)877-838-0209 Mon-Fri 8AM-5PM(PST)
Support@etenwolf.com
Read all instructions and safety warnings before use.
If you have questions or comments, contact us.
Register at http://www.etenwolf.com
to receive a 1-year extended warranty.
1. PRODUCT OVERVIEW
01
Pressure value
Preset modes － Rugby，American football,basketball ，
manual use , inflation
Battery indicator
Pressure unit
Target input value
"U" unit button－BAR/PSI/KPA
"M" mode button
Power Button
“+” button
“-“ button
Inflation port
Deflation port
USB-C charging
01
02
03
04
05
06
07
08
09
10
11
12
13
02
05
03
11
12 13
04
06
07
08
09
10
2. QUICK START GUIDE
STEPS TO INFLATE YOUR SPORTS BALL
1.
Take a needle , and connect it
to the inflation port (clockwise
rotation)
2.
Choose the appropriate pressure
mode and adjust to the target
pressure.
Note: The pump will automatically
turn off when the needle and ball
connects to the wrong port
(deflation port) to inflate.
3. 4.Press the power button to begin
releasing the air.
Press the power button again to
manually stop the deflation.
Note:
1. When in deflation mode, there is
no target pressure setting and
users need to stop the pump
manually.
2. Deflating a ball completely can
sometimes cause the leather or
synthetic panels to separate and
ruin the ball. Deflate it slowly and
keep an eye on the ball.
3. Because the pump sensor’s
minimum pressure is 3 psi, the
Display pressure will show 0 when
pressure is below that level.
Note:
The pump will stop every 20
seconds in deflation mode. To
continue deflation, press the
power button again.
3. AIR PRESSURE REFERENCE TABLE
Note:
1. To avoid injuries from bursting items due to over-inflation, make sure you
are aware of the maximum inflation pressure before you start.
2. The recommended air pressure for American footballs, soccer balls,
basketballs, volleyballs, and other balls is indicated near the ball’s air valve.
3. Pump cannot inflate items with pressure below 3 PSI, because it is under
the pump’s minimum pressure limitation.
Type
Rugby
American football
Basketball
Manual
Inflation mode
Pressure range
7-11PSI
8-16PSI
6-10PSI
3-17PSI
－
Recommended pressure
9PSI
13PSI
8PSI
Manual
－
1 Bar = 100 KPA = 14.5 PSI
6. BATTERY LEVEL INDICATOR AND CHARGING
BATTERY LEVEL INDICATOR AND CHARGING
The battery level is shown by color.
White = between 30% - 100%
Orange = between 10% - 30%
Orange flashing = under 10%
CHARGING
Fully charge the pump before using it for the first time. To take
responsibility for protecting our planet and leading on eco-friendly life,
the USB charger is not included. Please connect it to a certified USB
charger (5V/2A) with the charging cable.
While charging:
Orange flashing = under 30%
White flashing = between 30% - 100%
White Solid = fully charged
Note:
1. The pump will automatically turn off if it is inactive for five minutes after being
fully charged.
2. The pump cannot be used while charging.
4. BUTTON OPERATING GUIDE
5. PACKAGE CONTENTS
POWER BUTTON
ON
long-press for 2 seconds to turn on.
OFF
when the pump is turned on, long-press 4 seconds to turn off.
Pause
when the pump is inflating/deflating, press the button to pause the
machine whenever you want
Note:
The pump will turn on when connecting with a charger.
The pump will automatically turn off in the cases below:
1. Five minutes of inactivity.
2. When the charging cable is disconnected by accident during charging.
3. Five minutes of inactivity of after being fully charged.
4. When inflating balls over five minutes, but the target pressure value is still below
2.5psi. (need to check whether there is a misoperation or air leak)
“M” MODE BUTTON
Press the “M” button to switch between the five inflation modes below
“U” UNIT BUTTON
Press the “U” button to switch between the three units below
BAR/PSI/KPA
“+, -” PRESSURE ADJUSTMENT BUTTON
Press + or - to increase or decrease the target pressure value. Press and
hold the + or - button to quickly adjust the pressure value.
DRAWSRTING BAG
X 1
BALL PUMP NEEDLE
X 2
USER MANUAL
X 1
SPORTS MATE P200
X 1
7. TROUBLE SHOOTING
Problem
Solution
Slow inflating speed
Ball pump turns on,
but does not inflate
1. Check whether the battery level is sufficient.
2. Check whether the ball needle is screwed tightly.
3. Check whether the item inflated is leaking.
1. Check whether the battery level is sufficient.
2. Check whether the pressure of the item
being inflated exceeds the preset pressure.
The pump inflates normally
but the displayed pressure
is zero
If the air pressure under 3 PSI, the displayed
pressure will show zero due to the pump’s
minimum pressure range.
Unable to increase or
decrease the preset
pressure
Make sure the correct mode is chosen, and
the preset pressure does not exceed the range.
The battery level indicator
is different when inflating
compared to the standby
state
The lithium battery’s voltage level significantly
drops when discharging power, causing the
battery level indicator to have a different
display when inflating compared to standby
state. It is a normal situation.
The battery level indicator
does not show on
the screen after charging
Use a certified adapter and the included
charging cable, and try charging again.
8. SPECIFICATIONS
Name
Model
Executive Standard
Dimensions
Inflation Pressure Range
Operating Temperature
Storage Temperature
Battery Capacity
Working Noise
Input
Input Port
Charging Time
Sensor Accuracy
Ball pump
Sports Mate P200
ANSI B40.7
6.71"*1.85"*1.73"/170.4mm*46.9mm*44.0mm
3~17psi/0.2~1.17bar
Charging：32°F~113°F/0℃~45℃,
Discharging：-4°F~158°F/-20℃~70℃
-4°F~113°F/-20℃~45℃
P200 2,000mAh(7.4Wh)
Lower than 70dB within 1 meter
5V/2A
USB Type-C
P200 1 hour
±0.3psi
EU REP
SUCCESS COURIER SL
CALLE RIO TORMES NUM.1, PLANTA 1, DERECHA,
OFICINA 3, Fuenlabrada, Madrid, 28947 Spain
OST_EU_20230615000062
Manufacturer: Mozhen Technology (Shenzhen) Co., Ltd
CN-503, Floor 5, Building 4, Tianan Yungu Industrial Park Phase
ll, Gangtou Community, Bantian Street, Longgang District,
Shenzhen
(1)877-838-0209 Mon-Fri 8AM-5PM(PST)
support@etenwolf.com
www.etenwolf.com
www.facebook.com/etenwolf
Made in P.R.C
9. SAFETY INSTRUCTIONS
This product is not a toy and should not be used by children. Users should
be above 16 years old.
Keep a safe distance between children and the inflator while inflating.
There is a built-in lithium battery inside the product. Don't place the
product into fire or dump the battery.
Overheating.damage.or water may increase the risk of fire or explosion. It's
best to keep the product away from heat sources.and not leave it for
prolonged periods in a hot car. If the inflator becomes very hot.there is a
chance it could explode.
Please store the product within temperatures ranging from -4°F~113°F/-20
℃~45℃-. Extremely hot or cold environments may damage the battery and
shorten the lifetime of the inflator. Long-time storage of the product may
decrease the effectiveness of the battery. Charge the inflator at least once
every three months to maintain its performance.
The product has a built-in DC motor which may generate sparks during
operation. Do not use it in an environment with dust or gas that is liable to
explode.
If there is an unusual noise or the temperature becomes very high during
inflating.please turn off the inflator immediately.
Before setting the inflation pressure value, make sure the pressure unit is
correctly selected. Mixing up psi and bar could lead to dangerous
overinflation.
Unit conversion: 1bar = 14.5psi.1bar = 100kPa.
Do not leave the pump unattended while it is in operation.
Please use the product in a dry and clean environment. The intrusion of
sand and dust may cause damage to the product. Don’t wash the product
with water.
Please use a certified 5V/2A adapter and the included charging cable to
charge this product. Malfunction caused by actions not in accordance with
the above requirements is not covered by the warranty.
To reduce the risk of electric shock.do not expose to rain. Store indoors.
10. WARRANTY
Within 2 years of purchase, we will provide timely and effective online
after-sale service. We will repair or replace any defective product (due to
manufacturing fault) within this warranty period.
2-YEARS COVERAGE
