Read all instructions before use
* Actual Model May Vary
Interpupillary Distance Adjustment
The distance between the eyes, called “interpupillary
distance” (IPD), varies from person to person. To
achieve perfect alignment of lens to eye, follow
these steps.
1. Hold your binocular in the normal viewing position
and look at an object in the distance.
2. Grasp each of the binocular barrels firmly. Move the
barrels closer together or further apart until you see a
single circular field.
Focusing
After adjusting the interpupillary distance, follow steps
below to focus the binoculars.
1. Close your right eye and look at an object in the
distance through the left eyepiece with your left eye.
Rotate the center focus until image is clear.
2. Close your left eye and look at the same object in the
distance through the right eyepiece with your right
eye. Rotate the right eye diopter until the image
is clear.
3. Look through the binocular with both eyes and image
should be clear, rotate the center focus for any further
image adjustments.
Eye Cups
The binocular is designed with twist up eye cups for
your comfort. To exclude extraneous external light thus
providing improved field of view.
Eye Cups Down
Sunglasses / Eyeglasses Wearers
Eye Cups Up
Non Sunglasses / Eyeglasses Wearers
DO NOT use this optical product to view the
Sun or any light source. CAUTION: Viewing
the Sun can cause permanent eye damage.
D
F
B
A
C
G
E
Parts Of The Binocular
A. Eyepiece
B. Right Eye Diopter
C. Center Focus
D. Twist Up Eye Cups
E. Neck Strap Eyelet
F. Objective Lens
G. Tripod Adaptable Fitting
Tripod Adapter Fitting
The binocular is equipped with a built in tripod adapter
fitting. Carefully unscrew the cover screw located at the
base of the binocular hinge to expose the threaded
mounting socket for the tripod adapter to attach to.
Tripod adapter NOT included.
Care and Cleaning
Care
If handled with care, this binocular will provide years of
trouble-free service. Like any fine optical instrument
your binocular should be given sensible care.
- Keep the lens covers on the lenses when binoculars
are not in use.
- Store binoculars with the eye cups down.
- Avoid banging and dropping.
- Store in a cool, dry place.
Cleaning
- Blow away any dust or debris on the lens (or use a
soft lens brush)
- To remove dirt or fingerprints, clean with a soft cotton
cloth rubbing in a circular motion. Use of a coarse
cloth or unnecessary rubbing may scratch the lens
surface and eventually cause permanent damage.
- For a more thorough cleaning, photographic lens
tissue and photographic-type lens cleaning fluid or
isopropyl alcohol may be used. Always apply the fluid
to the cleaning cloth never directly on the lens.
NEVER attempt to clean your binocular internally or
try to take it apart.
See reverse side for more information
Crush
User Manual
6/23
BC773
BC771
BINOCULARS / RIFLESCOPES / SPOTTING SCOPES
3 YEAR LIMITED WARRANTY
BARSKA warrants this new precision optical product to be free of
defects in material and/ or workmanship under normal use for a
period of 3 years from the date product is purchased. This limited
warranty is delimited to repair or replacement only. This warranty
does not include damage caused by improper use or maintenance.
BARSKA disclaims all liabilities for incidental or consequential
damages such as misuse, abuse, accident (such as dropping),
flood, service or repairs other than those performed by BARSKA,
acts of nature, or arising out of any breach of this warranty. Altering
the product under any circumstances will automatically void the
warranty.
This warranty DOES NOT COVER ANY ACCESSORIES. Loss of
the product or lens caps/covers, eyepieces, cases/pouches, or
straps are not covered. Product normal wear and tear are not
covered and the determination of such is at the sole discretion of
BARSKA.
For service under this limited warranty, please have available the
proof of purchase and the purchase date and location as well as a
detailed description of the problem. This warranty is not transferable
and only applies to the original purchaser with a proof of purchase
from BARSKA or from an authorized dealer. This warranty applies
only to products purchased within the United States, excludes
Alaska, the Hawaiian Islands and all U.S. territories in the
Caribbean and the Pacific.
BARSKA will examine and go through troubleshooting procedures,
product repair or replacement of defective part(s) or units with new
part(s) or provide a new unit if necessary during the warranty
period. Shipping/handling charges may apply and are at Baraka’s
sole discretion. Purchaser shall be required to prepay
Shipping/handling charges with a check or money order to BARSKA
at time product is returned. The Return Merchandise Authorization
Number (RMA#) and shipping/handling charge MUST be obtained
from BARSKA in advance of return. BARSKA shall not be liable for
damages or loss occurring during shipping. Please visit via
www.barska.com or call 909.445.8168 for more information.
BARSKA reserves the right to modify or discontinue, without prior
notice to the purchaser, any model or style of the product. BARSKA
will determine, at its sole discretion, whether a product will be
repaired or replaced. BARSKA reserves the right to discontinue or
change any feature of its products at any time. If an exact
replacement or product is not available, BARSKA reserves the right
to provide a part or product that matches as closely as possible.
LIMITATION OF REMEDIES
BARSKA disclaims any warranties, express or implied, whether of
merchantability of fitness for a particular use, except as expressly
set forth herein. The sole obligation of BARSKA under this limited
warranty shall be to repair or replace the covered product, in
accordance with the terms set forth herein. BARSKA expressly
disclaims any lost profits, general, special, indirect or consequential
damages which may result from breach of any warranty, or arising
out of the use or inability to use any BARSKA product. Any
warranties which are implied and which cannot be disclaimed shall
be limited in duration to a term of three year from the date of original
retail purchase. Some states do not allow the exclusion or limitation
of incidental or consequential damages or limitation on how long an
implied warranty lasts, so the above limitations and exclusions may
not apply to you.
BARSKA 855 Towne Center Drive, Pomona, CA 91767
Note: All information, feature, and specification displayed herein are
based on the data available at the time of publishing, thus they are
subject to change without notice. All product pictures displayed
herein are for illustration purposes only. The actual product may
vary due to different circumstances.
