kobalttools.com
1
AB13802C
40 V LITHIUM-ION POLE SAW
ITEM #0506891
MODEL #KPS 80-06
Français p. 21
Español p. 41
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST,
Monday - Friday.
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
kobalttools.com
2
TABLE OF CONTENTS
Product Specications .............................................................................................................. 3
Package Contents ..................................................................................................................... 3
Symbols...................................................................................................................................... 4
Safety Information ..................................................................................................................... 5
Preparation ................................................................................................................................ 7
Know Your Pole Saw ................................................................................................................. 8
Assembly Instructions ............................................................................................................... 9
Operating Instructions ............................................................................................................... 9
Care and Maintenance............................................................................................................. 13
Troubleshooting ...................................................................................................................... 19
Warranty .................................................................................................................................. 19
Replacement Parts List ........................................................................................................... 20
kobalttools.com
3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Handle pole 1
B Extension pole 1
C Power head pole 1
D Battery 1
E Charger 1
E
PRODUCT SPECIFICATIONS
Type
Battery
Bar Length
Chain Pitch
Chain Type
Guide Bar Type
Weight
Cordless, Battery-powered
40 V Lithium-ion
8 in. (20.3 cm)
3/8 in. (9.5 mm)
91PJ033
080NDEA318
7.96 lbs. (3.6 kg)
D
C
A
B
SPECIFICATIONS
kobalttools.com
4
SYMBOLS DESIGNATION EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watts Power
hrs Hours Time
n
o
No Load Speed Rational speed, at no load
Class II Construction Double-insulated construction
/min Per Minute
Revolutions, strokes, surface speed, orbits, etc., per
minute.
Lithium-Ion Battery Recycling
Designates that this tool is in compliance with
Lithium-Ion battery recycling program requirements.
Safety Alert Symbol Precautions that involve your safety.
Read the Operator’s Manual
To reduce the risk of injury, user must read and
understand operator’s manual before using this product.
Eye and Head Protection
Wear eye and head protection when operating this
equipment.
Gloves
Wear non-slip, heavy-duty protective gloves when
handling the pole saw and the blade.
Safety Footwear
Wear non-slip safety footwear when using this
equipment.
Kickback DANGER! Beware of kickback.
Risk of Electrocution DANGER! Risk of electrocution!
Electric Shock
Failure to use in dry conditions and to observe
safe practices can result in electric shock.
No Hands Symbol
Failure to keep your hands away from the blade will
result in serious personal injury.
Keep Bystanders Away Keep all bystanders at least 50 ft. (15 m) away.
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOLS
kobalttools.com
5
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with
this product.
Save these Instructions
SAFETY INFORMATION
Read and understand all instructions. Failure to follow all instructions listed below may result in
electric shock, re, and/or serious personal injury.
• For safe operation, read and understand all instructions before using this product. Be familiar
with all controls and proper use of the machine. Follow all safety instructions. Failure to follow
all safety instructions listed below can result in serious personal injury.
• Do not allow children or untrained individuals to use this unit.
• Thoroughly inspect the area where the equipment is to be used and remove all foreign objects.
• Wear safety glasses or goggles that are marked as complying with ANSI Z87.1 standard as
well as head protection when operating this product.
• Dress properly. Wear heavy long pants, boots, and gloves. Do not wear loose tting clothing,
short pants, or go barefoot. Do not wear jewelry of any kind.
• Secure long hair above shoulder level to prevent entanglement in moving parts.
• Keep all bystanders, children, and pets at least 50 ft. (15 m) away.
• Stay Alert — Watch what you are doing; use common sense. Do not operate this unit when you are
tired, ill, or under the inuence of alcohol, drugs, or medication.
• Do not operate in poor lighting.
WARNING
SYMBOL SIGNAL MEANING
DANGER
Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
CAUTION
(Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
• To avoid serious personal injury, do not attempt to use this product until you have read this
Owner’s Manual thoroughly and understand it completely. If you do not understand the warnings and
instructions in this Owner’s Manual, do not use this product. Call 1-888-356-2258 for assistance.
The operation of any power tool can result in foreign objects being thrown into your eyes,
which can result in severe eye damage. Before beginning power tool operation, always wear
safety goggles or safety glasses with side shields and, when needed, a full face shield. We
recommend a wide vision safety mask for use over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is marked to comply with ANSI Z87.1.
WARNING
kobalttools.com
6
• Keep rm footing and balance. Do not overreach. Overreaching can result in loss of balance.
• Keep all parts of your body away from any moving part.
• Inspect the unit before each use for loose fasteners, etc. Replace any damaged parts before use.
• When not in use, product should be stored indoors in a dry, locked up place — out of the reach of
children.
• Use only original manufacturer’s replacement parts. Failure to do so may cause poor performance,
possible injury, and will void your warranty.
• Use the right appliance. Do not use the product for any job except that for which it is intended.
• Do not use on steps, a ladder, or unstable support. Stable footing on a solid surface enables
better control of the product in unexpected situations.
• Do not force the product. It will do the job better and with less likelihood of a risk of injury at
the rate for which it was designed.
DANGER: Keep hands away from cutting area. Keep both hands on handles when power is on.
CAUTION: Chain coasts after being turned off.
SAFETY INFORMATION
Specic safety rules
• Kickback is a dangerous reaction that can lead to serious injury. Kickback may occur when the
moving chain contacts an object at the upper portion of the tip of the guide bar or when the wood
closes in and pinches the chain in the cut. Contact at the upper portion of the tip of the guide bar
can cause the chain to dig into the object and stop the chain for an instant. The result is a
lightning-fast reverse reaction which kicks the guide bar up and back toward the operator. If the
chain is pinched along the top of the guide bar, the guide bar can be driven rapidly back toward the
operator, which can cause loss of control and may result in serious injury. Do not rely exclusively
upon the safety devices built into the product. With a basic understanding of kickback, you can
reduce or eliminate the element of surprise. Sudden surprise contributes to accidents.
• Use pole saw for cutting wood only. Do not use for cutting non-wood items.
• Make sure that the area in which you are cutting is free from obstructions. Do not let the nose
of the guide bar contact a log, branch, fence, or any other obstruction while you are operating the
unit. Have a planned retreat path.
• Do not grasp the exposed cutting blades or cutting edges when picking up or holding the product.
• Cut only when visibility and light are adequate for you to see clearly.
• To protect yourself from electrocution, do not operate within 50 ft. (15 m) of overhead electrical
lines.
• Before starting the motor, make sure the chain is not contacting any object. To protect yourself
from falling branches, do not stand directly under the branch or limb being cut. This unit should not
be held at an angle over 60° from ground level.
• Turn off the motor and make sure the cutting attachment has stopped before setting the unit down.
• Follow the sharpening and maintenance instructions for the saw chain.
• Use only the replacement guide bars and low kickback chains specied for the unit.
• Do not operate the saw with one hand! Serious injury to the operator, helpers, bystanders, or any
combination of these persons may result from one hand operation. This saw is intended for
two-handed use.
kobalttools.com
7
SAFETY INFORMATION
• Use extreme caution when cutting small sized brush and saplings because slender material may
catch the saw chain and be whipped toward you or pull you off balance.
• When cutting a limb that is under tension, be alert for spring back so that you will not be struck
when tension in wood bers are released.
• To avoid accidental starting, never carry a battery operated product with your nger on the switch.
Be sure switch is off when inserting the battery.
• Maintain product with care. Keep cutting edge sharp and clean for best performance and to reduce
the risk of injury. Follow instructions for lubricating and changing accessories. Inspect battery
periodically and, if damaged, have it replaced. Keep handles dry, clean, and free from oil and
grease.
• Check for damaged parts. Before further use of the product, a guard or other part that is damaged
should be carefully checked to determine that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any other condition that may affect its operation. A guard or other part that is
damaged should be properly repaired or replaced by an authorized service center unless indicated
elsewhere in this manual.
• Remove the battery from pole saw when not in use, before servicing, and when changing
accessories.
• Service on the product must be performed by qualied repair personnel only. Service or
maintenance performed by unqualied personnel could result in injury to the user or damage to the
product.
• Save these instructions. Refer to them frequently and use them to instruct others who may use this
product. If you loan someone this product, loan them these instructions also to prevent misuse of
the product and possible injury.
Service
Servicing requires extreme care and knowledge and should be performed only by a qualied service
technician. For service, we suggest you return the product to your nearest authorized service center
for repair. When servicing, use only identical replacement parts.
PREPARATION
Before beginning to assemble the product, make sure all parts are present. Compare parts with
package contents list. If any part is missing or damaged, do not attempt to assemble the product.
Helpful Tools (not included): Phillips screwdriver for tightening the chain.
kobalttools.com
8
WARNING
• If any parts are damaged or missing, do not operate this product until the parts are replaced.
Failure to heed this warning could result in serious personal injury.
• Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
• Do not install the battery until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
UNPACKING
• This product has been shipped unassembled.
• Carefully remove the product and any accessories from the box. Make sure that all items listed in
the package contents section are included.
• Inspect the product carefully to make sure no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily operated
the product.
• If any parts are damaged or missing, please call 1-888-3KOBALT (1-888-356-2258) for assistance.
PREPARATION
KNOW YOUR POLE SAW
PART DESCRIPTION
F Oil cap
G Safety lock button
H Collar
I Battery release button
J Trigger switch
K Bar cover knob
L Bar cover
M Chain tension screw
F
K
L
M
J
I
H
G
kobalttools.com
9
A
H
ASSEMBLY INSTRUCTIONS
Connecting the poles
Before using the pole saw, assembly is required. When
removed from the box, there are three parts.
• Remove packaging material and discard.
• Insert the extension pole (B) into the handle pole
(A) and slide together.
• Lower the collar (H) on the extension pole (B) to
the threaded base on the handle pole (A) and
rotate clockwise to secure.
• Repeat this process to attach the extension pole
(B) to the power head pole (C).
B
C
WARNING
• Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a second
is sufcient to inict serious injury.
• Always wear safety goggles or safety glasses with side shields when operating power tools.
Failure to do so could result in objects being thrown into your eyes, resulting in possible serious
injury.
• Do not use any attachments or accessories not recommended by the manufacturer of this product.
The use of attachments or accessories not recommended can result in serious personal injury.
• Failure to lock power head pole as directed above could result in serious injury or death.
Adding bar and chain lubricant
Use a bar and chain lubricant (not included) with this
product. It is designed for chains and chain oilers,
and is formulated to perform over a wide temperature
range with no dilution required.
Note: This pole saw comes from the factory with no
bar and chain oil added. Level should also be checked
after every 20 minutes of use and relled as needed.
• Remove oil cap (F).
• Carefully pour the bar and chain oil into the tank.
• Wipe off excess oil. Replace oil cap (F).
• Check and ll the oil tank when quick view oil indicator
is below the second to last indicator line.
• Repeat as needed.
N
I
A
H
C
T
N
A
C
I
R
B
U
L
F
Oil
Indicator
Note: Do not use dirty, used or otherwise contaminated oils. Damage may occur to the bar or chain.
Note: It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the oil tank
after each use, then run for one minute. When storing the unit for a long period of time (three months
or longer), be sure the chain is lightly lubricated; this will prevent rust on the chain and bar sprocket.
To preserve natural resources, please recycle or dispose of oil properly. Consult your local waste
authority for information regarding available recycling and/disposal options.
IMPORTANT
OPERATING INSTRUCTIONS
kobalttools.com
10
OPERATING INSTRUCTIONS
To install the battery:
1. Align the battery (D) with the battery opening.
2. Insert the battery into the battery opening until the
battery release button (I) locks into place.
3. Push down on the battery until it locks into place. You
should hear a “click” once it is installed.
To remove the battery:
1. Press the battery release button (I) on the pole saw.
This will cause the battery to slightly raise out of the
tool.
2. Grasp the pole saw rmly and pull the battery out of
the handle.
IMPORTANT: The battery may not be charged when
it is purchased. Before using the pole saw for the rst
time, place the battery in the battery charger and charge.
Make sure to read all safety precautions and follow the
instructions in the battery and charger manuals.
Battery
D
I
Follow these instructions in order to avoid injury and to reduce the risk of electric shock or re:
• Replace the battery or the charger immediately if the battery case or charger cord is
damaged.
• Verify that the switch is in the OFF position before inserting or removing the battery pack.
• Verify that the battery is removed and the switch is in the OFF position before inspecting,
adjusting, or performing maintenance on any part of the pole saw.
• Read, understand, and follow the instructions contained in the charger manual.
WARNING
IMPORTANT
This lithium-ion battery is equipped with an internal circuit breaker which will automatically shut off
the power to the tool and then reset itself once cooled. Follow these steps if an overload occurs while
under heavy use:
1. Release the power switch and restart tool by depressing switch.
2. The battery may need to be removed for approximately 1 minute, allowed to cool and then
reinstalled for use.
kobalttools.com
11
OPERATING INSTRUCTIONS
Starting and stopping
A. To start the motor:
• Press the safety lock button (G). Squeeze the trigger
switch (J) to start.
• Release the trigger switch (J) to stop.
Note: To lock out the trigger, you can pull back the
safety lock with your thumb. To unlock the safety lock,
push it forward. When the trimmer is not in use, you
can use the safety lock to prevent activation during
storage or transport.
Adjusting pole saw height
• Rotate the collar (H) counterclockwise to loosen.
• Remove power head pole from extension pole by
pulling up on it.
• Rotate second collar (H) counterclockwise to loosen.
• Remove extension pole from handle pole by pulling up
on it.
• Insert the handle pole into the power head pole.
• Rotate collar (H) clockwise to tighten.
Note:
• Adjust hand placement on the shaft of the pole saw
to keep proper balance.
• Assemble poles only to the length required to reach
the limb being cut. Do not extend the handle above
waist height.
G
H
J
Preparation for cutting
• Wear non-slip gloves for maximum grip and protection.
• Maintain a proper grip on the unit whenever the motor is running. Use your right hand to rmly grip
the rear handle while your left hand has a rm grip on the pole shaft.
• Hold unit rmly with both hands. Always keep your left hand on the pole shaft and your right hand
on the rear handle so your body is to the left of the chain line. Never use a left-handed (cross-
handed) grip, or any stance that places your body or arm across the chain line.
• Never stand directly under the limb you are cutting.
• Be certain the collars are fully tightened before
operating equipment; check them periodically for
tightness during use to avoid serious injury.
Basic cutting procedure
Follow the steps below to prevent damage to tree or shrub bark. Do not use a back-and-forth sawing motion.
• Make a shallow rst cut (1/4 of limb diameter) on the underside of the limb close to the main limb
or trunk.
• Make a second cut from the top side of the limb outboard from the rst cut. Continue the cut
through the limb until the limb separates from the tree. Be prepared to balance the weight of the
tool when the limb falls.
• Make a nal cut close to trunk.
kobalttools.com
12
OPERATING INSTRUCTIONS
• Release the trigger as soon as the cut is completed.
Failure to follow proper cutting procedures will result
in the bar and chain binding and becoming pinched or
trapped in the limb. If this should
happen:
• Stop the motor and remove the battery from the pole
saw.
• If the limb can be reached from the ground, lift the limb
while holding the saw. This should release the “pinch”
and free the saw.
• If the saw is still trapped, call a professional for
assistance.
Note: For second and nal cuts (from top of limb
or branch), hold front cutting guide against the limb
being cut. This will help steady the limb and make it
easier to cut. Allow chain to cut for you; exert only light
downward pressure. If you force the cut, damage to the
bar, chain, or motor can result.
Cutting Guide
Limbing and pruning
This unit is designed for trimming small branches
and limbs up to 6 in. (15.2 cm) in diameter. For best
results, observe the following precautions:
• Plan the cut carefully. Be aware of the direction in
which the branch will fall.
• Branches may fall in unexpected directions. Do not
stand directly under the branch being cut.
• The most typical cutting application is to position the
unit at an angle of 60° or less, depending on the
specic situation. As the angle of the pole saw shaft to
ground increases the difculty of making the rst cut
(from underside of limb) increases.
• Remove long branches in several stages.
• Cut lower branches rst to allow the top branches
more room to fall.
• Work slowly, keeping both hands on the saw with a
rm grip. Maintain secure footing and balance.
First Cut
1/4 Diameter
Final Cut
Second Cut
LOAD
60° Maximum
kobalttools.com
13
OPERATING INSTRUCTIONS
• Keep the tree between you and the chain while
limbing. Cut from the side of the tree opposite of the
branch you are cutting.
• Do not cut from a ladder; this is extremely dangerous.
Leave this operation for professionals.
• Do not make the ush cut next to the main limb or
trunk until you have cut off the limb further out to
reduce the weight.
Following proper cutting procedures will prevent
stripping the bark from the main member.
• Do not use the pole saw for felling or bucking.
• To prevent electrocution, do not operate within 50 ft.
(15 m) of overhead electrical lines.
• Keep bystanders at least 50 ft. (15 m) away.
CARE AND MAINTENANCE
• When servicing, use only identical replacement parts. Use of any other parts may create a hazard
or cause product damage.
• Always wear safety goggles or safety glasses with side shields during power tool operation or
when blowing dust. If operation is dusty, also wear a dust mask.
• Before inspecting, cleaning or servicing the unit, stop the motor, wait for all moving parts to stop,
and remove the battery. Failure to follow these instructions can result in serious personal injury or
property damage.
General Maintenance
• Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, and grease, etc.
• Do not at any time let brake uids, gasoline, petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can damage, weaken, or destroy plastic, which may
result in serious personal injury.
• All pole saw service, other than the items listed in the instruction manual maintenance instructions,
should be performed by authorized service centers.
WARNING
To avoid possible serious injury, never touch or adjust the chain while the motor is running. The saw
chain is very sharp; always wear protective gloves when performing maintenance to the chain.
WARNING
50’
15 m
Minimum
50’ (15 m)
kobalttools.com
14
Chain tension
• Stop the motor and remove the battery before
setting the chain tension. Turn the bar cover knob
counterclockwise to loosen the bar cover but do not
remove the bar cover. Turn the chain tensioning screw
clockwise to tension chain. Turn the guide bar knob
clockwise to tighten. Refer to the Replacing the bar
and chain section for additional information.
Note: A cold chain is correctly tensioned when there is
no slack on the underside of the guide bar, the chain is
snug, but it can be turned by hand without binding.
• Chain must be retensioned whenever the ats on the
drive links hang out of the bar groove.
• During normal operation, the temperature of the chain
will increase. The drive links of a correctly tensioned
warm chain will hang approximately 1/16 in. (1.3 mm)
out of the bar groove.
Note: New chain tends to stretch; check chain tension
frequently.
CARE AND MAINTENANCE
Chain tensioned while warm may be too tight upon
cooling. Check the “cold tension” before next use.
CAUTION
Replacing the bar and chain
WARNING
To avoid possible serious injury, stop the motor and
remove the battery from the pole saw before replacing the
bar, chain, or performing any maintenance operation.
APPROX 1/16 in. (1.3 mm)
Flats
kobalttools.com
15
CARE AND MAINTENANCE
• Loosen the bar cover knob (K) by turning
counterclockwise and remove the bar cover (L).
• The bar contains a bar stud slot that ts over the
bar stud. The bar also contains a chain tensioning pin
hole which ts over the chain tensioning pin.
• Place the bar onto the bar stud so that the chain
tensioning pin ts into the chain tensioning pin hole.
• Fit the chain over the sprocket and into the bar groove.
The cutters on the top of the bar should face toward
the bar tip, in the direction of the chain
rotation.
• Replace the bar and tighten the bar cover knob.
Tighten the bar cover knob nger tight only. The bar
must be free to move for tension adjustment.
• Remove all slack from chain by turning the chain
tensioning screw clockwise, ensuring that the chain
seats into the bar groove during tensioning.
• Lift the tip of the bar up to check for sag. Release the
tip of the bar and turn the chain tensioning screw
1/2 turn clockwise.
• Repeat this process until sag does not exist.
• Hold the tip of the bar up and tighten the bar cover
knob securely.
• Chain is correctly tensioned when there is no slack on
the underside of the bar, the chain is snug, but it can
be turned by hand without binding.
Note: If chain is too tight, it will not rotate. Loosen the
bar cover knob slightly and turn adjusting screw 1/4
turn counterclockwise. Lift the tip of the bar up and
retighten bar cover knob.
Tension
adjustment screw
Sprocket
Drivecase
Cover
Chain
Tensioning Pin
Bar Stud
Bar Stud Slot
K
kobalttools.com
16
CARE AND MAINTENANCE
• Hold the tip of the bar up and tighten the bar cover
knob (K) securely.
• Chain is correctly tensioned when there is no slack on
the underside of the bar, the chain is snug, but it can
be turned by hand without binding.
Note: If chain is too tight, it will not rotate. Loosen the
bar cover (L) slightly and turn adjusting screw 1/4 turn
counterclockwise. Lift the tip of the bar up and
retighten bar cover knob (K).
• Use Premium Bar and Chain Lubricant. It is designed
for chains and chain oilers and is formulated to
perform over a wide temperature range with no dilution
required.
• Remove the cap and carefully pour approximately
2 oz (57 g) of bar and chain lubricant into the bar lube
reservoir.
• Replace the cap and tighten securely.
• Check and rell the bar lube reservoir every time the
pole saw is used.
Note:
• Do not use dirty, used, or otherwise contaminated
lubricants. Damage may occur to the oil pump, bar,
or chain.
Chain oiler
WARNING
To avoid possible serious injury, stop the motor and
remove the battery from the pole saw before replacing the
bar, chain, or performing any maintenance operation.
Bar Lube Reservoir
K
F
kobalttools.com
17
CARE AND MAINTENANCE
Chain maintenance
For smooth and fast cutting, the chain needs to be maintained properly. The following conditions
indicate that the chain requires sharpening:
How to sharpen the cutters
Be careful to le all cutters to the specied angles and
to the same length, as fast cutting can be obtained only
when all cutters are uniform.
• Tighten the chain tension enough that the chain does
not wobble. Do all of your ling at the midpoint of the
bar. Wear gloves for protection.
• Use a round le and holder.
• Keep the le level with the top plate of the tooth. Do
not let the le dip or rock.
PARTS OF A CUTTER
Top Plate
Rivet Hole
Heel
Gullet
Toe
Depth
Gauge
Side
Plate
Cutting Corner
• Wood chips are small and powdery.
• Chain must be forced through the wood during cutting.
• Chain cuts to one side.
During maintenance of the chain, consider the following:
• Improper ling angle of the side plate can increase the
risk of a severe kickback.
• Depth gauge (or raker clearance) setting determines
the height the cutter enters the wood and the size of
the wood chip that is removed. Too much clearance
increases the potential for kickback. Too little
clearance decreases the size of the wood chip thus
decreasing the chain’s cutting ability.
• If cutter teeth have hit hard objects such as nails or
stones, or have been abraded by mud or sand on the
wood, have service dealer sharpen chain.
Raker (Depth Gauge) Clearance
1/32” (0.6mm)
kobalttools.com
18
CARE AND MAINTENANCE
• Using light but rm pressure, stroke towards the front
corner of the tooth. Lift le away from the steel on
each return stroke.
• Put a few rm strokes on every tooth. File all left hand
cutters in one direction. Then move to the other side
and le the right hand cutters in the opposite direction.
Occasionally remove lings from the le with a wire
brush.
Dull or improperly sharpened chain can cause excessive
motor speed during cutting which may result in severe
motor damage.
CAUTION
Improper chain sharpening increases the potential of
kickback. Failure to replace or repair damaged chain can
cause serious injury.
WARNING
Right Hand
Cutters
Left Hand
Cutters
kobalttools.com
19
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Bar and chain
running hot and
smoking.
1. Check chain tension for
overtightened condition.
2. Bar lube reservoir empty.
1. Tension chain. Refer to Chain
Tension earlier in this manual.
2. Check bar lube reservoir.
Motor runs, but
chain is not
rotating.
1. Chain tension too tight.
2. Check guide bar and chain
assembly.
3. Check guide bar and chain for
damage.
1. Re-tension chain. Refer to
Chain Tension earlier in this
manual.
2. Refer to Replacing the Bar and
Chain earlier in this manual.
3. Inspect guide bar and chain for
damage.
WARRANTY
5-YEAR HASSLE-FREE WARRANTY
This 40 V Lithiuim-Ion pole saw is warranted to the original purchaser from the original purchase date
for ve (5) years subject to the warranty coverage described herein.
This 40 V Lithiuim-Ion saw is warranted for the original user to be free from defects in material and
workmanship.
If you believe that the 40 V Lithiuim-Ion pole saw is defective at any time during the specied warranty
period, simply return the 40 V Lithiuim-Ion pole saw along with proof of purchase to the place of
purchase for a free replacement or refund, or call 1-888-3KOBALT (1-888-356-2258) for warranty
service.
This warranty is void if: defects in materials or workmanship or damages result from repairs or
alterations which have been made or attempted by others or the unauthorized use of nonconforming
parts; the damage is due to normal wear, damage is due to abuse (including overloading of the tool
beyond capacity), improper maintenance, neglect or accident; or the damage is due to the use of the
tool after partial failure or use with improper accessories or unauthorized repair or alteration.
This warranty gives you specic legal rights, and you may also have other rights that vary from state
to state.
kobalttools.com
20
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-888-3KOBALT (1-888-356-2258),
8 a.m. - 8 p.m., EST, Monday - Friday.
Printed in China
Kobalt
®
is a registered trademark of LF, LLC. All Rights Reserved.
PART DESCRIPTION PART #
D Battery 31101825
E Charger 29413
F Oil tank cap 341071071
O Side cover 341021071
D E F O
