PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
Features:
• Loudspeaker PA System
• Rugged, Durable & Reliable Sound
• Wireless BT Streaming Ability
• Wireless BT Music Streaming Ability
• Speaker System: 2x12'' Active and Passive Subwoofer, 4 x 4” woofer,
4 x 1'' Tweeter
• Compression Driver with PEI Diaphragm
• 3-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• XLR Microphone Input
• 1/4’’ Jack, RCA (L/R) Stereo Line Input
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• Digital LCD Display
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Treble, Bass, Eect Adjustable
• 5 Band Graphic Equalizer
• Integrated Carry Handles
• 35mm Speaker Stand Mount Compatible
What's in the Box:
• 12'' Wireless BT Active Subwoofer Speaker
• 12'' Passive Subwoofer Speaker
• (4) 4” Passive Line Array Speaker
• (2) Stand
• Power Cable
• Audio Cable 98.43'' -inches (Both Sides are 6.35 1/4’’ Jack )
• Audio Cable 236.22'' -inches (Both Sides are 6.35 1/4’’ Jack )
• (2) Audio Cable 11.81'' -inches (Both Sides are 6.35 1/4’’ Jack)
• Audio Cable 196.85'' -inches (Both Sides are SpeakOn)
• Remote Control
Subwoofer:
• Size: 12'' -inch
• Material: Stamped Steel Basket
• Impendence: 8 Ohm
• Magnet: 50 oz.
Woofer:
• Size: 4'' -inch
• Material: Stamped Steel Basket
• Impendence: 8 Ohm
• Magnet: 10 oz.
Tweeter:
• Size: 1.0'' -inch
• Material: PEI
• Impendence: 8 Ohm
Technical Specs:
• Max Power Output: 1320 Watt
• RMS Power Output: 660 Watt
• Amplier Class: D
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Inputs/Outputs 1/4" TS/unbalanced and 3.5mm TRS/Stereo Input
with RCA Input
• T.H.D.: 1%
• Crossover Frequency: 120Hz/3.3kHz
• Voltage: AC 110/220V 60/50HZ
• Active Subwoofer Dimensions (L x W x H): 13.78’’ x 184.25’’ x 15.75’’ -inches
• Passive Subwoofer Dimensions (L x W x H): 13.78’’ x 184.25’’ x 15.75’’ -inches
• Passive Line Array Dimensions (L x W x H): 9.25’’ x 4.13’’ x 4.92’’ -inches
Wireless BT Streaming:
• Instantly Stream Music from Your BT Devices
• Works with All Your Favorite BT Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Wireless BT Version: 5.0
• Wireless BT Range: 100'+ Feet
• Wireless BT Network Name: 'Pyle'
• Voice Coil: 60.6mm, 2.5'' -inch
• Sensitivity: 93dB
• Frequency Response: 45Hz-3kHz
• Voice Coil: 25.5mm, 1'' -inch
• Sensitivity: 88dB
• Frequency Response: 80Hz-8kHz
• Sensitivity: 104dB
• Voice Coil: Kapton
• Frequency Response: 800Hz-20kHz
www.PyleUSA.com
4
www.PyleUSA.com
5
Control Panel Functions Connection
Assembly
Stereo 6.35mm output
array speakers
Speakon output to
passive subwoofer
Selectable 110V/220V Voltage
MP3 Media Player
with LCD Display
Individual Treble/Bass Control
Four Independent
volume controls
and master volume
control
Two XLR inputs for
Mic/Line-level Source
Stereo 6.35mm input for line-level source
5 Band graphic equalizer
Overload Indicator
Stereo RCA
inputs & outputs
AC 120/ 240V 60 /50Hz POWER
SPEAK ER OUT
(L)4/ 8 OHM
SPEAK ER OUT
(R)4/ 8 OHM
8 OHM
SUBWO OFER OU T
110V 220 V
PROT
330Hz 3.3KH z 10KH z1KHz1 00Hz
+12
-12
0
+ 6
- 6
+12
-12
0
+ 6
- 6
GRAP HIC EQUA LIZER
MIN MAX
MIN MAX
MIN MAX
MIN MAX
MIC LINE
CH1
MIN MAX
MIN MAX
MIN MAX
MIN MAX
MIC LINE
CH2
MIN MAX
MIN MAX
LINE
MP3
45Hz
L
R
CH3 /4
L
R
MIN MAX
83Hz
MIN MAX
TREBL E
BASS
EFFEC T
VOLUM E
TREBL E
BASS
EFFEC T
VOLUM E
DEPTH
VOLUM E
MONITO R
OUT
SUB VOL
MASTE R
VOLUM E
PROT
LEFT
LIMIT
RIGHT
LIMIT
DIGITA L ECHO EF FECTS
M FD
USB
BLUETO OTH
IR
SD
6
10
12
13
Stereo ECA input for iphone, iPad, iPod, Android
Devices, laptop, computer, TV, DVD, CD player etc
Array Speaker
Passive Subwoofer
Array Speaker
Connect to another
amplier, monitor
speaker, recorder, etc.
Align four identical speakers according
to the number sticked from top to
bottom, the icon of each speaker
should be placed to direction with the
“ ” on the bottom.
Attach the long bracket and short
bracket to the array speaker, secured
with screws and nuts.
STEP 1: STEP 2:
www.PyleUSA.com
6
www.PyleUSA.com
7
Assembly Adjustable Height
Connect the speakers with 8-in. cables.
Then attach the array speaker to the
stand pole and the subwoofer.
Repeat the above steps for the
second set.
STEP 3: STEP 4:
Line Array Speaker
Telescoping Speaker Pole
Active Subwoofer with Multifuntional control panel Passive Speaker
Two Line
Array Speakers
Subwoofer
Rugged MDF Enclosure
Rotating Knob
for securing
the stand pole
