USB C Docking Station Stand
Scam the QR Code to Receive a 2-Year Warranty
UDS047
Thank you for choosing the TobenONE Laptop Docking Station Stand!
Enhance your workspace with our all-in-one dock, enabling you to
link triple displays through 2 HDMI, connect 5 USB devices,utilize
high-speed SD/microSD 3.0 card slots, enjoy swift 1Gbps Ethernet,and
integrate audio with a 3.5mm jack-all through a singular USB-C
connection to your laptop.
If you nd the font size in our manual too small, please contact our
customer seice at suppo@tobenone.com with your product model,
and we will send you a digital version of the manual for your convenience.
4K/60Hz
4K/60Hz
1080P/60Hz 1080P/60Hz
4K/60Hz 4K/60Hz
To Laptop: Connect to the laptop
PD Po: Connect the included power adapter
HDMI 1: Resolution up to 4K/60Hz for single display (Plug-and-Play)
HDMI 2: Resolution up to 4K/60Hz for single display (Plug-and-Play)
Ethernet: Speed up to 1Gbps
USB A 3.0: Suppo data transfer 5Gbps
USB C 3.2: Suppo data transfer 10Gbps
USB C 3.2: Suppo data transfer 10Gbps
USB A 3.2: Suppo data transfer 10Gbps
USB A 3.0: Suppo data transfer 5Gbps
SD/microSD3.0 Slot: Suppo SD&TF work simultaneously
3.5mm Audio: Suppo mic&audio-out
Pos and Connectors
1. A laptop that has a full featured USB-C / USB4 / Thunderbolt 4
or 3 po that is running Windows 10 or 11, ChromeOS version 100+
should be compatible with the UDS047. Laptops that do not meet
these requirements are not suppoed.
2.Mac systems do not suppo MST and are not recommended with
the UDS047. Please note that Apple laptops do not suppo dual-
screen expansion through this dock.
3. The USB-C po of the dock does not suppo display output.
4. Monitors that include an HDMl input po are compatible with
UDS047. To achieve high resolution, it is necessa that your laptop's
USB-C po, the cable connecting the dock and the laptop, and the
monitor all suppo the desired resolution you wish to attain.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
Connect the included power adapter to the dock's PD po(②)
Use the USB C cable coming with the dock to connect the
dock and laptop via To Laptop po(①)
Connect monitor via HDMI 1 po (③) or HDMI 2 po (④)Attach
USB-C devices to the USB-C pos(⑦ ⑧). And
attach USB A devices(USB driver, keyboard, mouse, printer, etc.)
to the USB A pos(⑥ ⑨ ⑩)
Connect the speaker, headphones, or microphone to the audio
po( ). And connect the ethernet cable to the ethernet po(⑤)
