User manual – XG Solid Lid Chest Freezer
To ensure safe operation, please read this user manual thoroughly before use.
© Husky. Husky reserve the right to change specifications at any time without notice.
Images used are for illustration only. Stock not included.
XG Solid Lid Chest Freezer manual 2021.indd 1 /12/2021 12:11
Welcome to your new Husky
2
Thank you for buying this Husky freezer. It has been designed and manufactured for many years
of trouble-free service.
Operation is very simple, but please take a few minutes to read this user manual. It contains
important safety information, and tips to ensure you receive the best possible service from your
Husky unit.
CONTENTS
Important Notes .................................................................................................................................................................................3
Warning! Risk of electrical shock hazard ........................................................................................................................3
Disposal of old freezers ............................................................................................................................................................3
WEEE Compliance ......................................................................................................................................................................3
Safety instructions and warnings ..........................................................................................................................................3
Before using for the first time ...............................................................................................................................................4
Troubleshooting ..................................................................................................................................................................................5
Operating Instructions ...............................................................................................................................................................6
Illustration ..........................................................................................................................................................................................7
Circuit diagram ...............................................................................................................................................................................7
XG Solid Lid Chest Freezer manual 2021.indd 2 /12/2021 12:11
All models
Important Notes
WARNING: RISK OF ELECTRICAL SHOCK HAZARD
USERS IN EUROPE: This freezer unit must be earthed.
If the power cable is damaged, it must be replaced by a qualified engineer to avoid shock hazard.
DO NOT ATTEMPT TO SERVICE THE ITEM YOURSELF. Ensure that the unit is properly
earthed. Stop using the unit immediately if electric shock is felt when touching the cabinet.
DISPOSAL OF OLD FREEZERS
BE SURE TO MAKE ANY LOCKS UNUSABLE. IF POSSIBLE, REMOVE THE
LID AND DISCARD SEPARATELY.
WARNING – CHEMICAL HAZARD: DO NOT ALLOW CHILDREN TO PLAY
WITH OLD FREEZERS. CONTACT YOUR LOCAL AUTHORITY FOR PROPER
DISPOSAL PROCEDURES.
Before disposing of an old freezer please make sure it is switched off and safe. Unplug the freezer
and break any locks in order to avoid children becoming trapped.
Please note: the refrigeration system contains gases and refrigerants which require specialist
waste disposal. The valuable materials contained in a freezer can be recycled.
Contact your local waste disposal depot for proper disposal of an old freezer and contact your
local authority or dealer if you have any questions.
Ensure the pipework of your freezer is not damaged prior to disposal. You can contribute to
the environmental awareness by insisting on an appropriate non-polluting method of disposal.
WEEE COMPLIANCE
Husky freezers are authorised to carry the CE (Conformité
Européene) and WEEE (Waste Electrical and Electronic
Equipment Directive) symbols.
The WEEE symbol on this unit indicates that the product must
not be disposed of with household waste. To help prevent
possible harm to health and the environment, the product must be disposed of by recycling
methods authorised as environmentally safe. For more information on how to dispose of this
product appropriately, contact your dealer or the recycling department at your local authority.
Husky freezers and their components undergo strict product testing by independent companies
to comply or exceed all applicable local and international regulatory standards.
SAFETY INSTRUCTIONS & WARNINGS
Before switching on your Husky freezer, read the information in this user manual carefully. The
user manual contains important observa tions relating to the assembly, operation and
maintenance of the unit.
Please keep this user manual in a safe place for future reference. If you ever sell this unit, hand
this user manual to the new owner.
The manufacturer does not accept responsibility for any damages that may arise due to non-
observation of these instructions.
3
Technical Support: 01455 555340 (UK)
XG Solid Lid Chest Freezer manual 2021.indd 3 /12/2021 12:11
4
• Do not use the unit if it is damaged. If you are in any doubt, consult an engineer.
• Connection and installation of your Husky unit are to be carried out in strict compliance
with the relative instructions in this user manual.
• Make sure there is a suitable power outlet (230 volts, 13 amps outlet) with proper
grounding to power the freezer.
• For safety, the unit must be properly earthed in accordance with specifications.
• Always remember to unplug the unit before cleaning. Never unplug this unit by pulling on
the power cable. Always grip plug firmly and pull straight out from the socket.
• All electrical repairs must be carried out by a qualified engineer. Inadequate repairs may
be dangerous.
• Do not damage any parts of the unit which carry refrigerant by piercing, perforating,
crushing, twisting or scraping. If refrigerant comes into contact with the eyes it may cause
serious eye injury.
• Do not obstruct or cover the ventilation grille.
• Do not allow children to play with the unit, or to sit on it.
• This unit is not intended for use by persons (including children) with reduced physical,
sensory or mental capabil ities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the unit by a person responsible for their
safety.
HOW TO MINIMISE THE ENERGY CONSUMPTION OF
YOUR APPLIANCE
• Energy consumption will be lower if the appliance stands in a well ventilated space and in
particular if the vents on the appliance are clear of obstruction.
• Do not place the appliance in direct sunlight or near a heat source such as ovens, radiators,
heaters, etc as this will increase energy consumption.
• Keep the freezer lid closed as much as possible.
• Setting the thermostat colder means higher energy consumption, so set only as cold as you
really require.
• Do not overfill the appliance - overfilling means the cool air cannot circulate freely inside
the appliance which may slow the process of freezing the contents and make the appliance
less efficient.
• Defrost the appliance if frost can be seen building up inside - frost will increase energy
consumption and make the freezing process slower (see section ‘Defrosting’).
• Turn the appliance off completely if it is not required for a period of days (or longer) to
avoid wasting energy.
BEFORE USING FOR THE FIRST TIME
IMPORTANT: Before switching the unit on, we recommend you allow it to stand
upright for 8 hours. Failure to do this may result in damage to the unit.
• Remove the wooden pallet and the packing.
• To ensure correct operation, it is important that the unit is level. Use a spirit level to check.
• Before operation, we recommend that the cabinet is cleaned for reasons of hygiene and to
remove any residue left from manufacture.
• For good circulation, vents must not be blocked. Keep a minimum of 150mm of clear space
around the freezer. Your Husky unit should be placed on flat and firm surface for quieter
operation.
• Do not expose the unit to direct sunlight or a heat source such as ovens, radiators, heaters,
etc.
• Do not under any circumstances place heated food or beverages in your Husky freezer.
• Do not open the solid lid more often than necessary to lessen the escape of cold air.
• For better air circulation, do not overfill the unit.
• Adjust the thermostat according to the amount of product and the ambient temperature.
Technical Support: 01455 555340 (UK)
XG Solid Lid Chest Freezer manual 2021.indd 4 /12/2021 12:11
Tr oubleshooting
Before calling Technical Support, please check the following points; you may be able to solve any
problem yourself.
Problem
The sound of flowing liquid may be
heard.
There is frost on the unit.
The compressor cannot be heard but
the freezer inner temperature reads
normally.
Compressor does not work.
The unit is excessively noisy.
The compressor may be heard
working constantly.
Solution
This is the refrigerant circulating and is part of
normal operation.
A little frost develops if the ambient humidity is high.
Wipe away with a soft cloth.
This is part of normal operation. High levels of
insulation means that the compressor may not need
to operate for long periods.
1. Check the power cable is con nected and the
socket is switched on.
2. Check the fuse and replace with a fuse of a similar
rating if necessary.
3. Check the power switch is in the ON position and
the thermostat is on the correct setting.
Check the floor is level and the unit is securely
positioned.
If the temperature inside is too high, this constant
running of the compressor may be explained by:
1. Warm items being placed into the unit. Ensure
warm items are never placed into the unit.
2. The lid is not being closed properly. Always
ensure the lid is closed securely.
3. A build-up of ice on the evaporator. Defrost the
freezer regularly.
If the temperature inside is correct, then this
constant running may be due to:
1. The ambient temperature is too high. If possible
try to move the unit to a cooler location, or out of
direct sunlight.
2. The thermostat is set too low. Check and adjust
as necessary.
3. The thermostat is not working correctly. Refer to
an engineer.
5
Technical Support: 01455 555340 (UK)
XG Solid Lid Chest Freezer manual 2021.indd 5 /12/2021 12:11
6
Operating Instructions
TO ADJUST THE TEMPERATURE
If temperature adjustment is required, the controller
can be found at the bottom of the front face of the
freezer (see Fig.4 on page 7). If the temperature is set
colder than it is is required then the compressor will
run constantly. This is not recommended due to
increased wear on parts and it will also increase energy
consumption of your freezer.
DEFROSTING
Remove any stock to a suitable back-up freezer. Switch your Husky chest freezer off and
disconnect the plug from the mains socket. Remove the drain plug (see Fig. 2 on page 7) and
place a tray under the drain to collect melted water. Empty the tray regularly.
Allow any ice to melt naturally. DO NOT use boiling water, corrosive detergents, abrasive
scourers, wire brushes, electric heaters or sharp or metal objects to remove ice or hasten
defrosting. These may damage the unit and void the warranty.
When all the ice is clear and waste water removed, refer to ‘Cleaning’ below to sanitise and dry
the unit thoroughly. The freezer may then be reconnected and switched on. Wait at least two
hours before returning any stock to the unit.
CLEANING
The condenser and the compressor compartment MUST be cleaned quarterly. Use a vacuum
cleaner fitted with a soft brush attachment to remove dust carefully from the condenser, the
components and grilles.
The external and internal surfaces of the unit should be cleaned regularly. Switch the unit off
and disconnect the plug from the mains socket. Clean the external and internal surfaces of the
unit with a mild soap solution, then wipe dry. Do NOT use cleansers containing chlorine or
other harsh cleansing agents, as these can damage the stainless steel surfaces and components.
Use mild soapy water to clean the gasket and seals.
GETTING SERVICE ASSISTANCE
The cooling system is a hermetically sealed circuit and does not require any maintenance other
than regular cleaning (see ‘Cleaning’).
If the unit fails to work, first check the power supply. If you cannot locate the reason for the
failure, please contact your supplier, stating the model and serial number of the cabinet.
Technical Support: 01455 555340 (UK)
TEMPERATURE TEMPERATUREDISPLAY ADJUST
For fast freezing, coldest setting
XG Solid Lid Chest Freezer manual 2021.indd 6 /12/2021 12:11
7
Technical Support: 01455 555340 (UK)
1. Lid
2. Drain
3. Temperature display
4. Temperature control
5. Compressor compartment
(behind grille)
6. Lock
Circuit Diagram
L
E
N
XG Solid Lid Chest Freezer manual 2021.indd 7 /12/2021 12:11
