Operating and installation
instructions
Refrigerators
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-GB M.-Nr. 12 794 230
Contents
2
Warnings and safety notes ......................................................................................... 5
Sustainability and environmental protection.......................................................... 13
Caring for the environment ...........................................................................................
13
How to save energy.......................................................................................................
14
Familiarisation................................................................................................................ 16
Guide to the appliance ..................................................................................................
16
KU7015...................................................................................................................... 16
KU7016 ..................................................................................................................... 17
Display .............................................................................................................................
18
Operating the refrigeration appliance via the display................................................
19
Operation.........................................................................................................................
20
Briefly touching the symbol................................................................................. 20
Touching and holding the symbol for 3seconds.............................................. 20
Touching and holding the symbol for 7seconds .............................................. 20
Main menu................................................................................................................. 20
Sub-menu .................................................................................................................. 20
Display idle mode ..................................................................................................... 20
LED indicators........................................................................................................... 20
Safety ...............................................................................................................................
21
Lock function ............................................................................................................ 21
Door alarm ................................................................................................................. 21
Appliance functions .......................................................................................................
22
Miele@home ....................................................................................................... 22
SuperCool ............................................................................................................. 22
Sabbath mode........................................................................................................... 23
Factory defaults ........................................................................................................ 24
Demo mode............................................................................................................... 24
Adjusting the interior fittings ........................................................................................
24
Moving the door shelf/bottle shelf......................................................................... 24
Clipping the egg trays on......................................................................................... 24
Adjusting or removing the bottle holder................................................................ 24
Moving the adjustable shelves ............................................................................... 25
Optional accessories .....................................................................................................
25
Commissioning.............................................................................................................. 26
Before using for the first time.......................................................................................
26
Switching on and off ......................................................................................................
26
Switching the refrigeration appliance on............................................................... 26
Switching off the refrigeration appliance .............................................................. 26
To note when switching off for longer periods of time........................................ 26
Operation........................................................................................................................ 27
Setting the temperature ................................................................................................
27
Contents
3
Switching on SuperCool...........................................................................................
27
Switching off SuperCool...........................................................................................
27
Storing food in the fridge zone .....................................................................................
28
Different storage zones............................................................................................ 28
Storing food correctly............................................................................................... 29
Storing food in the fruit and vegetable drawers (VeggieBoxes) ..............................
29
Freezing and storing fresh food ....................................................................................
31
Using the freezer compartment ............................................................................. 31
Storing frozen food ................................................................................................... 31
Home freezing........................................................................................................... 31
Cooling drinks quickly....................................................................................................
32
Making ice cubes............................................................................................................
32
Adjusting settings ......................................................................................................... 33
Switching the lock function on .....................................................................................
33
Switching the lock function off.....................................................................................
33
Switching Sabbath mode on.........................................................................................
33
Switching Sabbath mode off ........................................................................................
33
Resetting the settings to their factory default settings ............................................
33
Activating the WiFi connection ....................................................................................
34
Deactivating the WiFi connection................................................................................
34
Switching on demo mode .............................................................................................
34
Switching off demo mode.............................................................................................
34
Exiting service mode......................................................................................................
35
Cleaning and care ......................................................................................................... 36
Cleaning agents ..............................................................................................................
36
Preparing the refrigeration appliance for cleaning.....................................................
37
Cleaning the inside of the appliance ...........................................................................
37
Cleaning accessories by hand or in the dishwasher .................................................
37
Removing and dismantling accessories for cleaning ................................................
38
Cleaning the door seal...................................................................................................
38
Cleaning the ventilation gaps .......................................................................................
38
Defrosting........................................................................................................................
39
Troubleshooting............................................................................................................. 41
Customer Service Department.................................................................................. 45
Contact in the event of a fault......................................................................................
45
EPREL database .............................................................................................................
45
Warranty ..........................................................................................................................
45
Installation...................................................................................................................... 46
Installation site ...............................................................................................................
46
Climate range ............................................................................................................ 47
Ventilation........................................................................................................................
48
Contents
4
Side-by-side installation................................................................................................
48
Changing the door hinging ............................................................................................
48
Furniture door panel.......................................................................................................
49
–Gap.......................................................................................................................... 49
Weight of the furniture door.................................................................................... 50
Limiting the opening angle of the appliance door......................................................
50
Building-in dimensions .................................................................................................
51
Niche/side view ........................................................................................................ 51
Connections .............................................................................................................. 52
Installing the appliance..................................................................................................
53
To install the refrigeration appliance, you will need the following tools: .......... 53
Preparing the refrigeration appliance..................................................................... 53
Positioning the refrigeration appliance.................................................................. 54
Aligning the refrigeration appliance........................................................................ 55
Securing the refrigeration appliance in the niche................................................. 56
Fitting the furniture door ...............................................................................................
57
Electrical connection .....................................................................................................
61
EU Conformity declaration.......................................................................................... 62
UK Conformity declaration ......................................................................................... 63
Copyrights and licences .............................................................................................. 64
Warnings and safety notes
5
This refrigeration appliance complies with current safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Please read the operating and installation instructions carefully
before using the refrigeration appliance for the first time. They
contain important information on installation, safety, use and
maintenance. This is to protect yourself from injury, and from
damaging your refrigeration appliance.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow all information provided
on installing the refrigeration appliance, as well as the warning and
safety notes.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating and installation instructions in a safe place
and pass them on to any future owner.
Correct application
This refrigeration appliance is intended for use in the home and in
similar environments, for example
– in shops, offices and similar work settings
– by the guests in hotels, motels, bed & breakfasts and other typical
home settings.
This refrigeration appliance is not intended for outdoor use.
The refrigeration appliance is intended exclusively for domestic use
for cooling and storing food and drink and, depending on the model,
storing deep frozen food, freezing fresh food and making ice.
The refrigeration appliance without a freezer compartment is not
suitable for freezing food.
The refrigeration appliance is suitable for integrated under-counter
installation.
Any other usage is not permitted.
Warnings and safety notes
6
This refrigeration appliance is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar
substances or products that are subject to the Medical Device
Directive. Incorrect use of the refrigeration appliance for such
purposes may cause deterioration of the items stored. The
refrigeration appliance is also not suitable for use in areas where
there is a risk of explosion.
Miele cannot be held liable for damage caused by improper or
incorrect use or operation of the appliance.
The appliance can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
if they are supervised whilst using it, or have been shown how to use
it in a safe way and recognise and understand the consequences of
incorrect operation.
Safety with children
Children under 8 years of age must be kept away from the
refrigeration appliance unless they are constantly supervised.
Children 8 years and older may only use the appliance
unsupervised if they have been shown how to use it in a safe way and
recognise and understand the consequences of incorrect operation.
Children must not be allowed to clean or maintain the appliance
unsupervised.
Please supervise children in the vicinity of the appliance and do
not let them play with it.
Danger of suffocation! Whilst playing, children could become
entangled in packaging (such as plastic wrapping) or pull it over their
head and suffocate. Keep packaging material away from children.
Technical safety
The coolant circuit has been checked for leaks. The refrigeration
appliance complies with statutory safety requirements and the
appropriate EU directives.
If the cooling circuit is damaged, refrigerant and oil can escape and ignite.
Warnings and safety notes
7
Warning: fire hazard/flammable materials. This symbol is on the
compressor and indicates flammable materials. Do not remove this
sticker.
The refrigerant inside the appliance (details on the data plate) is
environmentally friendly but flammable.
The use of this refrigerant does, however, sometimes lead to a slight
increase in the noise level of the appliance. In addition to the noise of
the compressor, you might be able to hear the refrigerant flowing
around the cooling circuit. Unfortunately, this cannot be avoided, but
it does not affect the performance of the refrigeration appliance.
When transporting and installing the refrigeration appliance, ensure
that no parts of the cooling circuit are damaged. Splashes of
refrigerant can damage the eyes and leaking refrigerant can ignite.
In the event of damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the refrigeration appliance from the mains electricity
supply.
- Ventilate the room where the refrigeration appliance is located for
several minutes.
- Contact the Miele Customer Service Department.
The more refrigerant there is in a refrigeration appliance, the larger
the room it should be installed in. In the event of a leakage, if the
appliance is in a small room, there is the danger of a combustible
gas/air mixture building up. For every 8g of refrigerant at least 1m
3
of
room space is required. The amount of refrigerant in the refrigeration
appliance is stated on the data plate inside the appliance.
To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data plate
corresponds to the household supply.
Check that this is the case before connecting the appliance. Consult
a qualified electrician if in any doubt.
The electrical safety of this appliance can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.
Warnings and safety notes
8
Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronised
with the mains power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
If the electrical connection cable supplied is damaged, it must only
be replaced by an original spare part to prevent a hazard for the user.
Miele can only guarantee the safety of the appliance when original
Miele spare parts are used. For safety reasons, such replacement
may only be carried out by a qualified specialist or the Miele
Customer Service Department.
Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and do
not guarantee the required safety of the appliance.
If moisture gets into electrical components or into the mains
connection cable, it could cause a short circuit. Therefore, do not
operate this refrigeration appliance in areas which are exposed to
moisture (e.g in a garage or utility room).
This appliance must not be used in a non-stationary location (e.g.
on a ship).
Do not use a damaged appliance. It could be dangerous. Check the
appliance for visible signs of damage.
For safety reasons, this appliance may only be used after it has
been built in.
The appliance must be isolated from the electricity supply during
installation, maintenance and repair work.
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user.
Installation, maintenance and repairs must only be carried out by a
Miele authorised technician.
Warnings and safety notes
9
While the appliance is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
Faulty components must only be replaced with genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the appliance when Miele replacement parts are used.
This refrigeration appliance is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This lamp must only be
used for the purpose for which it is intended. The lamp is not suitable
for room lighting. Replacement lamps may only be fitted by a Miele
authorised technician or by the Miele Customer Service Department.
This refrigeration appliance contains several light sources with at
least energy efficiency classG.
Proper installation
Install the refrigeration appliance in accordance with the
installation instructions.
Always wear protective gloves when transporting and installing the
refrigeration appliance.
Two people are required to install the refrigeration appliance.
Change the door hinging (if necessary) as described in the
installation instructions.
Correct use
This refrigeration appliance is designed for use within specific
ambient temperatures (climate range). Do not use in ambient
temperatures for which it is not designed. The climate range is stated
on the data plate in the interior cabinet of the refrigeration appliance.
A lower ambient temperature will cause the compressor to switch off
for longer periods, meaning that the refrigeration appliance is unable
to maintain the required temperature.
Do not cover or block the air vents as this could impair the
efficiency of the appliance, increase the electricity consumption and
could cause damage to the components.
If storing food which contains a lot of fat or oil in the appliance or
the door, make sure that it does not come into contact with plastic
components as this could cause stress cracks or break the plastic.
Warnings and safety notes
10
Risk of fire and explosion. Do not store explosive materials in the
refrigeration appliance or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion. Do not operate any electrical equipment (e.g.
an electric ice-cream maker) inside the refrigeration appliance.
Danger of sparking and explosion.
Danger of injury and damage to the appliance. Do not store cans or
bottles containing carbonated drinks or liquids which could freeze in
the freezer compartment. Otherwise they could burst.
Danger of injury and damage to the appliance. When chilling drinks
in the freezer section, make sure that bottles are not left in for more
than one hour. Otherwise they could burst.
Danger of injury. Never handle frozen food or the metal parts of the
appliance with wet hands. Your hands may freeze to the frozen food
or to the metal.
Danger of injury. Do not take ice cubes out with your bare hands
and never place ice cubes or ice lollies in your mouth straight from
the freezer compartment.
The very low temperature of the frozen food could cause frost burn to
the lips and tongue.
Do not refreeze partially or fully defrosted food. Consume
defrosted food as soon as possible, as it will lose its nutritional value
and spoil if left for too long. Defrosted food may only be re-frozen
after it has been cooked.
Observe the manufacturer's “use-by” dates and storage
instructions given on food to avoid the risk of food poisoning. Storage
times will depend on several factors, including the freshness and
quality of the food, as well as the temperature at which it is stored.
Accessories and spare parts
Only use original Miele accessories. If other parts are used,
warranty, performance and product liability claims will be invalidated.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the discontinuation
of your refrigeration appliance.
Warnings and safety notes
11
Cleaning and care
Do not use any oils or grease on the door seals, as these will cause
the seals to deteriorate and become porous with time.
Do not use a steam cleaning appliance to clean or defrost this
appliance.
Steam could reach electrical components and cause a short circuit.
WARNING! DANGER of injury and damage! Do not use any
mechanical or other types of aids which are not recommended by the
manufacturer to accelerate the defrosting process.
Sharp edged or pointed objects will damage the evaporator,
causing irreversible damage to the appliance. Do not use sharp edged
or pointed objects to
- remove frost and ice,
- separate frozen food or remove ice trays.
Do not place electric heaters or candles in the appliance to defrost
it. These can damage the plastic parts.
Do not use defrosting sprays or de-icers, as they could contain
substances which could damage the plastic parts or which might
cause the build-up of gases and pose a danger to health.
Transporting the appliance
To avoid damage to the refrigeration appliance, always transport it
upright and in its packaging.
Danger of injury and damage to the appliance. The refrigeration
appliance is very heavy and must be transported by two people.
Disposal of your old appliance
Children playing could become trapped in the appliance and could
suffocate.
- Remove the appliance doors.
- Remove the drawers.
- Leave the adjustable shelves in the refrigeration appliance so
children cannot climb inside.
- If your old refrigeration appliance has a door lock, destroy it. This
will prevent the risk of children playing accidentally locking
themselves in and endangering their lives.
Warnings and safety notes
12
Risk of electric shock!
- Cut the plug off the mains connection cable.
- Cut the mains connection cable off the old appliance.
Dispose of the plug and mains connection cable separately from the
old appliance.
During and after disposal, make sure that the refrigeration
appliance is not placed near petrol or other flammable gases and
liquids.
Risk of fire due to escaping oil or refrigerant!
The refrigerant and oil inside the appliance are flammable. In high
enough concentrations, escaping refrigerant or oil may ignite if they
come into contact with an external heat source.
During disposal, make sure that the cooling circuit is not damaged in
order to prevent refrigerant and oil escaping in an uncontrolled
manner (see the data plate for details of the refrigerant).
Splashes of coolant can damage the eyes. Be careful not to
damage any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the coolant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Symbol on the compressor (depending on model)
This information is only relevant for recycling. There is no risk during normal
operation.
The oil in the compressor can be fatal if swallowed or if it
penetrates the airways.
Sustainability and environmental protection
13
Caring for the environment
Disposing of the packaging material
The packaging material is used for
handling and protects the appliance
from transport damage. The packaging
material used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material
reduces the use of raw materials. Use
material-specific collection points for
valuable materials and take advantage
of return options. Your Miele dealer will
take the packaging material away.
Disposing of your old appliance
Electrical and electronic appliances
contain many valuable materials. They
also contain certain materials,
compounds and components which
were essential for their correct
functioning and safety. These could be
hazardous to human health and to the
environment if disposed of with
household waste or if handled
incorrectly. Please do not, therefore,
dispose of your old appliance with
household waste.
Take care not to damage your
refrigeration appliance before or during
disposal in an authorised,
environmentally friendly manner.
This is to ensure that refrigerant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle
electrical and electronic appliances in
your local community, with your dealer
or with Miele, free of charge. By law, you
are solely responsible for deleting any
personal data from the old appliance
prior to disposal. You are legally obliged
to remove any old batteries which are
not securely enclosed by the appliance
and to remove any lamps without
destroying them, where this is possible.
These must be taken to a suitable
collection point where they can be
handed in free of charge. Please ensure
that your old appliance poses no risk to
children while being stored for disposal.
Sustainability and environmental protection
14
How to save energy...
Installation site The refrigeration appliance has to cool more often at higher
ambient temperatures and consumes more energy in the process.
Therefore:
- Install the refrigeration appliance in a well-ventilated room.
- Do not install the refrigeration appliance near to a heat source
(heater element, cooker).
- Protect the refrigeration appliance from direct sunlight.
- Ensure an ideal ambient temperature of 20°C.
- Clean the ventilation openings on a regular basis to remove any
dust.
Temperature
setting
The colder the temperature, the higher the energy consumption.
The following settings are recommended:
- 4 to 5°C in the refrigerator section.
- Freezer compartment -18°C.
Use Energy consumption is increased by heat input and impeded air
circulation. Therefore, you should:
- Only open the appliance door(s) when necessary and for as
short a time as possible. Arrange the food in such a way that
makes it easy to find in the appliance.
- Always close the appliance door(s) properly after opening
them.
- Allow hot food and drinks to cool down before placing them in
the refrigeration appliance.
- Store food well packaged or covered.
- Do not overfill the compartments to allow air to circulate.
- Keep drawers and shelves arranged as they were when the
appliance was delivered.
- Place frozen food in the fridge zone to defrost.
Sustainability and environmental protection
15
Defrosting A layer of ice hinders the cold from reaching the frozen food.
Therefore, you should:
- Defrost the freezer compartment when a layer of ice max.
0.5cm thick has built up.
Familiarisation
16
Guide to the appliance
KU7015
a
Shelf with egg tray in the appliance door
b
Display
c
Adjustable shelf
d
Fruit and vegetable drawer (VeggieBox)
e
Bottle shelf with bottle holder:
You can move the bottle holder to the right or left to create space for drinks
cartons.
f
Condensate channel and condensate drain hole:
Precipitated condensate runs off and evaporates automatically.
g
Fruit and vegetable drawer (VeggieBox)
h
Ventilation grille
Familiarisation
17
KU7016
a
Shelf with egg tray in the appliance door
b
Freezer compartment
c
Display
d
Adjustable shelf
e
Bottle shelf with bottle holder:
You can move the bottle holder to the right or left to create space for drinks
cartons.
f
Condensate channel and condensate drain hole:
Precipitated condensate runs off and evaporates automatically.
g
Fruit and vegetable drawer (VeggieBox)
h
Ventilation grille
Familiarisation
18
Display
The display can be scratched by
pointed or sharp objects, e.g. pens.
Only touch the display with your
fingertips.
It is possible that the display will not
react to finger contact if your fingers
are cold.
a
WiFi LED
b
9°C LED
c
7°C LED
d
Control symbol
e
5°C LED
(sub-menu:
back to factory default settings)
f
3°C LED
(sub-menu: Sabbath mode)
g
SuperCool
(sub-menu: lock function)
Familiarisation
19
Operating the refrigeration appliance via the display
Touch and hold the symbol for 3seconds to switch on the refrigeration
appliance.
Touch the symbol a few times in succession to activate the LEDs in the main
menu and in the sub-menu.
The LED for the selected temperature or function lights up.
Touch and hold the symbol for 7seconds to switch from the main menu to the
sub-menu.
If 5seconds pass without a function being selected, the display will return to the
main menu.
When a function is selected in the sub-menu, the corresponding LED lights up.
Touch and hold the symbol for 3seconds to exit the sub-menu and return to
the main menu.
Familiarisation
20
Operation
The refrigeration appliance is operated
using the symbol on the display. This
symbol can be used to switch between
the main menu and sub-menu and to
navigate in both menus. Which
functions are selected depends on how
long the symbol is pressed.
Briefly touching the symbol
Briefly touch the symbol to navigate
through the main menu and the sub-
menu until you reach the required
temperature or function.
Touching and holding the symbol for
3seconds
If you touch and hold the symbol for
3seconds, the current status of the
refrigeration appliance does not matter.
A switched-off appliance will be
switched on. The appliance is switched
off in the main menu. An appliance in
the sub-menu switches to the main
menu. An active function is deactivated.
Touching and holding the symbol for
7seconds
If you touch and hold the symbol in
the main menu for 7seconds, the sub-
menu opens. You are in the sub-menu
when all 5 LEDs light up at the same
time. If no function is selected within
5seconds, the display returns to the
main menu.
Main menu
In the main menu, you can choose
between 5 settings; specifically,
temperatures 9°C, 7°C, 5°C and 3°C,
and the SuperCool function.
Sub-menu
In the sub-menu, you can choose from
3 functions; specifically, the lock
function at LED, Sabbath mode at
3°C LED and resetting to the factory
default settings at 5°C LED.
Display idle mode
Idle mode switches on when the
symbol in the main menu has not
been touched for 10seconds. This
prevents the temperature from being
changed inadvertently. Idle mode is
ended by briefly touching the symbol.
LED indicators
The LEDs can light up or flash to
indicate the appliance status. If the LED
lights up, the temperature is selected or
the function is active. A flashing LED
indicates a power failure or a
temperature alarm until the set
temperature is reached. If several LEDs
flash at the same time, a fault has
occurred. If the symbol flashes, the
WiFi connection can be established or
the appliance is in the process of
connecting.
Familiarisation
21
Safety
Lock function
When the lock function is switched on,
it protects the refrigeration appliance
from being switched off unintentionally
and being adjusted unintentionally by
unauthorised persons, e.g. children.
The lock function is located in the
LED sub-menu.
Door alarm
The refrigeration appliance is fitted
with a door alarm to avoid increased
energy consumption and food
becoming warm if the door is left
open.
The alarm will sound and the interior
lighting pulses if the door is left open for
a long time.
As soon as the appliance door is closed,
the alarm tone will stop.
Switching the door alarm off early
Tap briefly.
The alarm tone will stop.
If the appliance door is not closed, the
alarm will sound again after a short
time.
Familiarisation
22
Appliance functions
Miele@home
Your refrigeration appliance is
equipped with an integrated WiFi
module.
Networking is deactivated at the
factory.
Here you can set up the Miele@home
function for the first time, deactivate
and activate the WiFi or reset the
network configuration (see “Adjusting
settings”).
To use this feature, you will need:
- A WiFi network
- The Miele app
- A Miele user account. You can create
a user account via the Miele app
The Miele app will guide you as you
connect your refrigeration appliance to
your home WiFi network.
Once the refrigeration appliance is
connected to your WiFi network, you
can use the app to carry out the
following activities, for example:
- Call up information on the operating
status of your refrigeration appliance
- Change the settings on your
refrigeration appliance
Connecting your refrigeration appliance
to your WiFi network will increase
energy consumption, even when the
appliance is switched off.
Make sure that the signal of your
WiFi network is sufficiently strong in
the place where you want to set up
your refrigeration appliance.
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.
Miele@home availability
The ability to use the Miele app
depends on the availability of the
Miele@home service in your country.
The Miele@home service is not
available in every country.
For information about availability, please
visit www.miele.com.
Miele App
The Miele App is available to download
free of charge from the Apple App
Store
®
or from the Google Play Store™.
SuperCool
When switched on, the SuperCool
function can be used to rapidly reduce
the temperature in the fridge zone and
the freezer compartment (depending
on the model) to its lowest setting
(depending on the ambient
temperature). The refrigeration
appliance will work at full power and
lower the temperature. Select this
function for the rapid chilling of large
amounts of fresh food or drink or before
Familiarisation
23
freezing fresh food. This helps food to
freeze quickly and retain its nutrients,
vitamins, flavours and appearance.
When the SuperCool function is
switched on, the appliance may make
more noise than usual.
The SuperCool function should be
switched on 3hours before placing
food or drinks in the fridge zone.
The SuperCool function will switch
itself off automatically after a
maximum of 18hours. The
refrigeration appliance will then run at
normal power again.
Tip: To save energy, you can switch the
SuperCool function off yourself once
food and drinks are sufficiently chilled.
Sabbath mode
The refrigeration appliance offers a
Sabbath mode for the purposes of
religious observance.
When Sabbath mode is switched on,
the following are deactivated:
- Interior lighting when the appliance
door is opened
- All visual and audible signals
- The temperature display
- WiFi connection
- Deactivate all functions in the display
except for the Sabbath mode function
All other functions switched on
previously remain activated.
The Sabbath mode function will switch
off automatically after approx.
80hours.
After a power cut, the appliance
returns to Sabbath mode.
The Sabbath mode function is located in
the 3°C LED sub-menu.
Familiarisation
24
Factory defaults
You can reset the refrigeration
appliance‘s settings to their factory
default settings. The WiFi connection is
also reset.
Tip: We recommend doing this if you
are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation.
The factory default settings function is
located in the 5°C LED sub-menu.
Demo mode
Demo mode allows the refrigeration
appliance to be presented in the
showroom without the cooling system
being switched on. This setting is not
needed for domestic use.
Adjusting the interior fittings
Moving the door shelf/bottle shelf
Only move the door/bottle shelves in
the appliance door when they are
empty.
Push the door/bottle shelves
upwards, then remove them by pulling
them forwards.
Replace the door/bottle shelves at
the required height.
Clipping the egg trays on
Clip the egg trays onto the rear edge
of the door shelf.
Adjusting or removing the bottle
holder
The non-slip fins of the bottle holder
make bottles more secure when you
open and close the appliance door.
The bottle holder can be moved to the
left or right to create more room for
drink cartons.
The bottle holder can be removed
completely, e.g. for cleaning:
pull the bottle holder up to remove it.
Familiarisation
25
Moving the adjustable shelves
The shelves can be adjusted according
to the height of the food.
Raise the shelf slightly at the front
and pull it forwards a little.
Lift it until the notches at the side are
in line with the shelf supports. The
shelf can then be raised or lowered to
the required level.
Push the shelf in.
Stoppers prevent the shelves from
being dislodged by mistake.
The raised edge on the protective strip
at the back must face upwards to
prevent food from touching the back of
the appliance and freezing to it.
Optional accessories
A range of useful Miele accessories and
care products are available for your
appliance.
Products specially tailored to your
refrigeration appliance – such as
appliance care products and
accessories – are available from the
Miele online shop, from Miele Customer
Service or from your Miele specialist
dealer.
You can access the Miele online shop
via the following QR code:
Commissioning
26
Before using for the first time
Remove all packaging material and
protective film.
Clean the inside of the appliance and
the accessories (see “Cleaning and
care”).
Connecting the refrigeration appliance
Connect the refrigeration appliance to
the electricity supply as described in
“Electrical connection”.
Switching on and off
Switching the refrigeration appliance
on
Open the appliance door.
Touch the symbol for 3seconds
until a buzzer sounds.
The refrigeration appliance will start to
cool and the interior lighting will come
on when the appliance door is opened.
The refrigeration appliance will adjust to
the preset temperature.
During initial commissioning or if the
appliance was not previously connected
to the WiFi, the connection process
may take several minutes.
If the appliance was already connected
to the WiFi, it will connect
automatically.
To enable the temperature to get
sufficiently cold inside the
refrigeration appliance, allow the
appliance to run for a few hours
before placing food in it.
Switching off the refrigeration
appliance
You are in the main menu.
Touch the symbol for 3seconds
until a buzzer sounds.
The LEDs in the display no longer light
up, the interior lighting is switched off
and the appliance is no longer cooling.
Please note: The refrigeration
appliance is not disconnected from
the power supply when it is switched
off.
To note when switching off for longer
periods of time
If, during a long absence, the
refrigeration appliance is switched off
but not cleaned and the door is left
shut, there is a danger of mould
building up inside the appliance.
It is essential to clean the
refrigeration appliance before a long
period of absence.
If the refrigeration appliance is not going
to be used for a longer period of time,
observe the following:
Switch the refrigeration appliance off.
Switch off at the wall and disconnect
the plug from the socket, or
disconnect the fuse.
Defrost the freezer compartment
(depending on model).
Clean the refrigeration appliance and
leave the door ajar to air the appliance
and avoid odours building up inside.
Operation
27
Setting the temperature
You are in the main menu.
Touch the symbol a few times in
succession until you reach the LED
for the required temperature.
Health risk caused by
decomposing food.
The preset temperature of 5°C in the
fridge zone results in -18°C in the
freezer compartment.
Please note that if the temperature in
the fridge zone is any warmer, the
temperature in the freezer
compartment will exceed -18°C.
To freeze fresh food in the freezer
compartment, a temperature of
-18°C is required.
If the temperature in the freezer
compartment is any warmer, the food
will also have a shorter shelf life.
Please note that the temperatures in
the freezer compartment may
fluctuate if there is not much food
stored in it. Under certain
circumstances, temperatures that are
warmer than -18°C can be reached.
By keeping the freezer compartment at
a constant temperature of -18°C and
taking appropriate hygiene measures
you can maximise the storage life of
your food and avoid food waste.
Switching on SuperCool
The SuperCool function should be
switched on 3hours before placing
food or drinks in the fridge zone.
When the SuperCool function is
switched on, the appliance may make
more noise than usual.
Touch the symbol a few times in
succession until you reach the
LED.
The LED lights up orange.
Switching off SuperCool
The SuperCool function will switch
itself off automatically after a
maximum of 18hours. The
refrigeration appliance will then run at
normal power again.
Tip: To save energy, you can switch the
SuperCool function off yourself once
food and drinks are sufficiently chilled.
Touch the symbol a few times in
succession until you reach the
required temperature.
SuperCool is deactivated and the
LED no longer lights up orange.
Operation
28
Storing food in the fridge zone
Risk of explosion due to
flammable mixes of gases.
Electrical components can cause
flammable mixes of gases to ignite.
Do not store explosive materials in
the refrigeration appliance or any
products containing propellants (e.g.
spray cans). The spray cans in
question can be identified by the
contents printed on the can or by a
flame symbol. Electrical components
can cause escaping gases to ignite.
Risk of damage due to greasy or
oily foods.
If storing food which contains a lot of
fat or oil in the refrigeration appliance
or the appliance door, make sure that
it does not come into contact with
plastic components as this could
cause stress cracks or break the
plastic.
Make sure that no fat or oil leaks onto
the plastic parts of the refrigeration
appliance.
If there is insufficient air circulation,
the cooling performance will
decrease and energy consumption
will increase.
To allow air to circulate efficiently, do
not pack food too closely together in
the appliance.
Different storage zones
Due to natural air circulation, there are
different temperature regions in the
refrigerator section.
Cold, heavy air sinks to the lowest
section of the refrigeration section.
Make use of the different zones when
placing food in the appliance.
Warmest area
The warmest area in the refrigerator
section is at the top in the front area
and in the door. Use this for storing
butter and cheese.
Coldest area
The coldest area in the fridge zone is
directly above the DailyFresh drawer
and at the back of the appliance.
A temperature setting of 4°C or
colder combined with appropriate
hygiene measures delays the
propagation of bacteria, e.g.
salmonella and listeria, which can
lead to serious food poisoning.
Therefore, you should use these areas to
store all delicate and highly perishable
food, including:
- Fish, meat, poultry
- Cold cuts, ready meals
- Dishes or baked goods containing
eggs or cream
- Fresh dough, cake mixtures, pizza or
quiche dough
- Raw milk cheese and other raw milk
products
- Hummus, vegetable spreads, plant-
based cream cheese substitutes
- Pre-packed vegetables
Operation
29
- Other fresh food (with a label stating it
should be kept at a temperature of
approx. 4°C)
Tip: Store food in such a way that it
does not touch the rear wall of the
fridge zone. Otherwise it could freeze to
the rear wall.
Storing food correctly
Ensure that food stored in the fridge
zone is covered or wrapped properly.
This will prevent food odours from
affecting other foods, stop food from
drying out and also prevent any cross-
contamination of bacteria. This is
particularly important when storing
meat products. Make sure that food
such as raw meat and fish in particular
does not come into contact with other
food.
By ensuring that the temperature
settings are correct and by taking
appropriate hygiene measures you can
prolong the storage life of your food
considerably and avoid food waste.
Fruit and vegetables
Store fresh fruit and vegetables
wrapped in the fruit and vegetable
drawers (VeggieBoxes). Store cut fruit
and vegetables covered or wrapped in
an airtight container.
Protein-rich food
Please note that food rich in protein
deteriorates faster than other types of
food. Shellfish, for example, deteriorates
faster than fish, and fish deteriorates
faster than meat.
Storing food in the fruit and
vegetable drawers
(VeggieBoxes)
The VeggieBoxes provide good storage
conditions for fruit and vegetables.
Food retains its own moisture if stored
at a higher humidity and so does not dry
out as quickly. The temperature is
approximately equivalent to the
temperature in the fridge zone.
Remember that the fresher the food
when placed in the appliance, the
longer it will stay fresh.
Changing the humidity in the
VeggieBoxes
The moisture level in the VeggieBoxes
greatly depends on the type and
quantity of food being stored, if stored
unwrapped.
If the quantity of food being stored in
this compartment is small, the
humidity level may be too low.
If you are only storing a small amount
of food, wrap it in airtight packaging.
Operation
30
Observe the following tips if you find that food you have stored does not keep
well (e.g. food becomes limp or wilts after only being stored for a short time):
Only place fresh food in the appliance. The initial condition of the food is crucial
to maintaining freshness.
Clean the VeggieBoxes before storing the food.
Very wet food should be dried off before storing it.
Do not store food which is sensitive to cold in the VeggieBoxes (see “Storing
food in the fridge zone – Food which is not suitable for storage in the fridge
zone”).
An increased humidity level in the humidity-controlled compartment is achieved
with the moisture present in the food being stored if it is stored unwrapped. The
more food stored in the compartment, the higher the humidity.
Always store cut fruit and vegetables covered or wrapped in an airtight container.
If too much moisture collects in the compartment and the food is affected, dry
the floor and place a rack or similar item in the compartment so that excess
moisture can drip down.
If the humidity is too low when you are only storing a small amount of food, wrap
the food in airtight packaging.
Operation
31
Freezing and storing fresh food
Health risk caused by
decomposing food.
If the temperature in the freezer
remains above -18°C for a long time,
the frozen food can start to defrost.
This will reduce the storage life of the
food.
Check whether the frozen food has
started to defrost. If it has, check that
the food is safe to use and if it is,
then use it as soon as possible or
cook it before freezing it again.
Fresh food should be frozen as quickly
as possible. This way the nutritional
value of the food, its vitamin content,
appearance and taste are not impaired.
Using the freezer compartment
Use the freezer compartment to:
- Store frozen food
- Make ice cubes
- Freeze small quantities of fresh food
Information on the maximum freezing
capacity can be found on the data
plate.
The freezing capacity indicates the
amount of food that can be frozen
through to the core and the number of
hours it takes to do so.
Storing frozen food
When buying frozen food to store in
your freezer, check:
- That the packaging is not damaged
- The use-by date
- That the temperature at which the
frozen food is being stored in the shop
is -18°C or colder
Where possible, transport frozen food
in an insulated bag and then store it
quickly in the refrigeration appliance.
Home freezing
Not suitable for freezing
Please note that some food is not
suitable for freezing. This includes, for
example, vegetables that are usually
eaten raw, such as lettuce or radishes.
To note before placing food in the
freezer
Switch on the SuperCool function
3hours before placing food and
drinks in the appliance.
This helps the frozen food which is
already stored in the freezer to stay
frozen.
Only freeze fresh food which is in
good condition.
Tip: To retain colour, taste, aroma and
vitamin C, vegetables should be
blanched before they are frozen. To do
so, place vegetables portion by portion
into boiling water for 2–3minutes. Then
remove and plunge the vegetables into
ice-cold water to cool quickly. Leave the
vegetables to drain.
Packaging food for freezing
Freeze food in portions.
Tip: Use suitable packaging to avoid
freezer burn (such as freezer
containers).
Expel as much air as possible from
the packaging and close it tightly.
Make a note of the contents and the
date of freezing on the packaging.
Operation
32
Placing food in the freezer
Unfrozen food should not touch
frozen food as this will cause the
frozen food to begin to thaw.
To prevent food sticking together
when frozen, make sure that the
packaging and containers are dry.
Place the food to be frozen flat in the
bottom of the freezer compartment or
in contact with the interior side walls,
so that it freezes through to the core
as quickly as possible.
After freezing
Switch off the SuperCool function.
Cooling drinks quickly
When chilling drinks in the freezer
compartment, make sure that bottles
are not left in for more than 1hour.
Otherwise they could burst.
Making ice cubes
Fill the ice cube tray 3/4 full with
water and place it on the bottom of
the freezer compartment.
Once frozen, use a blunt instrument,
for example a spoon handle, to
remove the ice cube tray from the
freezer if it is stuck.
Tip: Ice cubes can be removed easily
from the tray by twisting the tray gently
or by holding it under cold running water
for a short time.
Adjusting settings
33
Switching the lock function on
The refrigeration appliance must be
switched on.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the LED.
The LED lights up and the safety lock
has been activated.
Switching the lock function off
Touch the symbol for 3seconds
until a buzzer sounds.
The lock function has been switched off.
You are back in the main menu.
Switching Sabbath mode on
The refrigeration appliance must be
switched on.
When Sabbath mode is switched on,
you cannot make any settings on your
refrigeration appliance.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the 3°C LED.
The 3°C LED lights up and Sabbath
mode is switched on.
Ensure that the appliance door is
properly closed, as visual and audible
alarms are switched off.
Health risk caused by
decomposing food.
As power failures are not indicated
while Sabbath mode is active, food
may be exposed to increased
temperatures for a certain period of
time. This will reduce the storage life
of the food.
If there is a power failure during
Sabbath mode, check the quality of
the food.
Switching Sabbath mode off
The Sabbath Mode function will
switch off automatically after approx.
80hours.
However, you can switch the Sabbath
mode function off early.
Touch the symbol for 3seconds
until a buzzer sounds.
Sabbath mode is switched off. You are
back in the main menu.
The interior lighting is activated. The
LED for the previously set temperature
lights up. The appliance connects to the
WiFi if it was previously connected to
the WiFi. If the appliance was not
previously connected to the WiFi, the
symbol flashes for several minutes. A
connection can be established during
this time.
Resetting the settings to their
factory default settings
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Adjusting settings
34
Touch the symbol multiple times
briefly until you reach the 5°C LED.
The 5°C LED lights up and all settings
are reset to the factory default settings.
The appliance switches off after a short
time.
Activating the WiFi connection
The WiFi connection is switched off at
the factory. The symbol is dark.
Touch and hold the symbol for
3seconds to switch off the
refrigeration appliance.
Then touch and hold the symbol for
3seconds to switch on the
refrigeration appliance.
The symbol flashes in the display for
several minutes. During this time, you
can connect the appliance to the WiFi.
If the time window for the connection is
not long enough, switch the appliance
off and on again.
As soon as the connection is
established, the symbol lights up.
Deactivating the WiFi
connection
To deactivate the WiFi connection, you
must reset the appliance to the factory
default settings.
Touch the symbol until a dual
buzzer sounds after 7seconds.
All 5 LEDs light up. You are in the sub-
menu. If 5seconds pass without a
function being selected, the display will
return to the main menu.
Touch the symbol multiple times
briefly until you reach the 5°C LED.
The 5°C LED lights up and all settings
are reset to the factory default settings.
The appliance switches off after a short
time.
Reset the network configuration if
you are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation. All personal data is
removed from the refrigeration
appliance. This will also ensure that a
previous owner is no longer able to
access the refrigeration appliance.
Switching on demo mode
Touch and hold the symbol for
3seconds to switch off the appliance.
Touch the symbol for 10seconds
until a buzzer sounds.
Touch the symbol briefly 5 times.
All LEDs light up twice briefly after
2seconds. Demo mode has been
activated.
Switching off demo mode
Touch and hold the symbol for
3seconds to switch off the appliance.
Touch the symbol for 10seconds
until a buzzer sounds.
Touch the symbol briefly 5 times.
All LEDs light up briefly four times after
2seconds. The display goes dark. Demo
mode is switched off.
After demo mode is switched off, the
appliance is reset to the factory default
settings.
Adjusting settings
35
Exiting service mode
If you have accidentally entered service
mode, you can easily exit it again. The
WiFi LED and the 9°CLED flash
simultaneously.
Either wait 5minutes or touch the
symbol for 3seconds to exit service
mode.
Cleaning and care
36
The data plate located inside the
interior cabinet of the refrigeration
appliance must not be removed. It
contains information which is required
in the event of a fault.
Do not let water get into the
electronic unit or the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaner can
damage plastic and electrical
components.
Do not use a steam cleaner to clean
the refrigeration appliance.
Cleaning water must not get into the
drain hole.
Cleaning agents
Cleaning and conditioning agents
used in the interior cabinet of the
refrigeration appliance must be food
safe.
To avoid damaging the surfaces of the
appliance, do not use the following:
- Cleaning agents containing soda,
ammonia, acids or chlorides
- Cleaning agents containing descaling
agents
- Abrasive cleaning agents (e.g.
scouring powder, scouring liquid or
pumice stones)
- Cleaning agents containing solvents
- Stainless steel cleaners
- Dishwasher cleaner
- Oven sprays
- Glass cleaning agents
- Hard, abrasive sponges and brushes
(e.g. pot scourers)
- Eraser stain remover blocks
- Sharp metal scrapers
We recommend using a clean sponge
and lukewarm water with a little
washing-up liquid to clean the surfaces
of the appliance.
Cleaning and care
37
Preparing the refrigeration
appliance for cleaning
Switch the refrigeration appliance off.
Take any food out of the refrigeration
appliance and store it in a cool place.
Defrost the freezer compartment
(depending on the model; see
“Defrosting”).
Take out all other removable parts for
cleaning.
Cleaning the inside of the
appliance
Clean the refrigeration appliance
regularly, at least once a month, and
the freezer compartment each time it
is defrosted.
If soiling is left on for any length of
time, it may become impossible to
remove under certain circumstances.
Surfaces may suffer discolouration or
damage.
It is therefore best to remove any
soiling immediately.
Clean the interior with a clean sponge
cloth, lukewarm water and a little
washing-up liquid.
After cleaning, wipe with clean water
and dry with a cloth.
Clean the freezer compartment each
time it is defrosted.
Clean the condensate channel and
drain hole frequently using a cotton
swab or similar item to ensure that
condensate can drain away freely.
Leave the door open to air the
refrigeration appliance sufficiently for
a short while and to prevent odour
build-up.
Cleaning accessories by hand
or in the dishwasher
The following components must be
cleaned by hand only:
- The stainless steel trim
- Protective strips at the back of the
adjustable shelves
- Adjustable shelf with printing
- The fruit and vegetable trays
(VeggieBoxes)
- All drawers and compartment lids
(these vary depending on model)
- The flexible bottle rack (available as an
optional accessory)
- Organisation box (available as an
optional accessory)
The following components are
dishwasher-safe:
Risk of damage due to high
dishwasher temperatures.
Parts of the refrigeration appliance
may become unusable, e.g. deform, if
they are washed in the dishwasher at
more than 55°C.
For dishwasher-safe components,
always select dishwasher
programmes with a maximum
temperature of 55°C.
Contact with natural dyes from
carrots, tomatoes and ketchup, etc.,
may discolour the plastic parts in the
dishwasher. This discolouration does
not affect the stability of the parts.
- Bottle holder, egg tray
- The door and bottle shelves in the
appliance door (without stainless
steel trim)
Cleaning and care
38
- Adjustable shelves (without the trim
or printing)
- The holder for the charcoal filter
(available as an optional accessory)
Removing and dismantling
accessories for cleaning
Dismantling the door shelf/bottle shelf
Remove the stainless steel trim before
cleaning the door shelf/bottle shelf in
the dishwasher.
To remove the stainless steel trim,
proceed as follows:
Place the door shelf/bottle shelf on
the worktop.
Pull the trim off the shelf beginning at
one side.
After cleaning the door shelf/bottle
shelf, reattach the trim.
Dismantling an adjustable shelf
Remove the trim and the rear protective
strip before cleaning the shelf. Proceed
as follows:
Place the shelf on a worktop covered
with a soft material (e.g. a tea towel).
Pull the trim off the shelf, beginning at
one side.
Then pull the protective strip off.
After cleaning the shelf, reattach the
trim and the protective strip.
Cleaning the door seal
Risk of damage as a result of
incorrect cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seal.
The door seal should be cleaned
regularly with clean water, and then
wiped dry with a soft cloth.
Cleaning the ventilation gaps
A build-up of dust will increase the
energy consumption of the appliance.
The ventilation gaps should be
cleaned on a regular basis with a
brush or vacuum cleaner (you could
use a Miele vacuum cleaner dusting
brush, for example).
After cleaning
Replace all shelves and accessories in
the refrigeration appliance.
Switch the refrigeration appliance
back on.
Switch on the SuperCool function for
a while so that the fridge zone can
cool down quickly.
Place food in the fridge zone and
close the appliance door.
When the temperature in the freezer
compartment is low enough, place
food back in the freezer compartment
and close the door.
Cleaning and care
39
Defrosting
The refrigerator section defrosts
automatically.
Condensate and frost can build up on
the back wall of the refrigerator section
whilst the compressor is running. You
do not need to remove this.
The condensate drains through a
channel and drain hole into an
evaporation system at the back of the
refrigeration appliance. The warmth
generated by the compressor causes
the condensate to evaporate
automatically.
Keep the condensate channel and
drain hole clean to enable this.
Condensate must be able to drain
away unhindered at all times.
Defrosting the freezer compartment
The freezer compartment does not
defrost automatically.
In normal use, ice and frost will form in
the freezer compartment, e.g. on the
internal walls. How much ice and frost
accumulates in the appliance will
depend on the following:
- Whether the freezer compartment
door has been opened frequently or
left open for a while
- Whether a large quantity of food has
been placed in the freezer at once
- Whether the humidity in the room has
increased
Too thick a layer of ice will make it hard
to open the freezer compartment. Too
thick a layer of ice also reduces cooling
performance and thus increases energy
consumption.
The freezer compartment should be
defrosted from time to time. It must
be defrosted if a layer of ice approx.
0.5cm thick has accumulated.
Tip: It is best to defrost when only very
little or no frozen food at all is left in the
freezer compartment or the humidity
level and the ambient temperature in
the room are low.
Risk of damage from an incorrect
defrosting process.
When defrosting the freezer, make
sure that you do not damage the
evaporator as this would cause
irreversible damage to the
refrigeration appliance.
Do not scrape off ice and frost. Do
not use sharp objects.
Do not use any mechanical tools or
other types of aid which are not
recommended by the manufacturer
to accelerate the defrosting process.
Switch on the SuperCool function
1day before defrosting. This helps the
frozen food to retain the cold reserve
for longer when taken out of the
freezer.
Remove the frozen food and wrap it in
several layers of newspaper or cloths.
Tip: You could also place the frozen food
in a cool box or bag.
Store it in a cool place until the
freezer compartment is ready for use
again.
The longer the frozen food is left out
at room temperature, the faster it
deteriorates.
Carry out the defrosting procedure as
quickly as possible.
Cleaning and care
40
Risk of damage due to heat and
moisture ingress.
The steam from a steam cleaner as
well as electric heaters and candles
can damage plastic and electrical
components.
Do not use a steam cleaner, electric
heaters or candles to defrost the
refrigeration appliance.
Risk of damage and risk to health
caused by defrosting sprays or de-
icers.
Defrosting sprays or de-icers can
contain substances which could
damage the plastic parts or which
might cause a build-up of explosive
gases and pose a danger to health.
Never use defrosting sprays or de-
icers to defrost the refrigeration
appliance.
Ensure that water does not get into
the surrounding cabinetry.
Switch the refrigeration appliance off.
Switch off at the wall and disconnect
the plug from the socket, or
disconnect the fuse.
Leave the freezer compartment door
and the appliance door open.
Tip: To speed up defrosting, a bowl of
hot water (not boiling) can be placed on
a saucer in the freezer compartment.
Closing the freezer compartment door
in this instance will help retain the
warmth and speed up the defrosting
process.
Remove any loose pieces of ice.
Use a sponge or cleaning cloth to
soak up the defrosted water as often
as necessary.
After defrosting
Clean and dry the freezer
compartment.
Close the freezer compartment door
and the appliance door.
Reconnect the refrigeration appliance
to the mains and switch it back on.
Switch on the SuperCool function
for a while so that the freezer
compartment can cool down quickly.
Place the food back into the freezer
compartment.
Troubleshooting
41
Many malfunctions and faults can be easily remedied. You can save time and
money in many cases, as you do not need to contact Customer Service.
More information to help you remedy faults yourself can be found at
www.miele.co.uk/support/customer-assistance.
To prevent unnecessary loss of temperature it is advisable not to open the door
while waiting for the appliance to be serviced.
Problem Cause and remedy
The refrigeration appli-
ance is not getting cold
and the interior lighting
does not come on when
the appliance door is
opened.
Demo mode has been activated. This allows the
refrigeration appliance to be presented in the dealer
showroom without the cooling system being switched
on. This setting is not needed for domestic use.
Switch off demo mode (see “Adjusting settings –
Switching off demo mode”).
The compressor is
switching on more fre-
quently and for longer
periods of time. The
temperature in the refri-
geration appliance is too
low.
The ventilation openings have been covered or
become dusty.
Do not block the ventilation openings.
Dust the ventilation openings regularly.
The appliance door and the freezer compartment door
(depending on the model) have been opened too
frequently, or a large amount of fresh food has been
placed in the appliance at once for chilling or freezing.
Only open the appliance doors when necessary and
for as short a time as possible.
After a while, the temperature will return to normal by
itself.
The appliance doors are not closed properly. A thick
layer of ice may have already formed in the freezer
compartment.
Close the appliance doors.
Troubleshooting
42
Problem Cause and remedy
After a while, the temperature will return to normal by
itself.
If a thick layer of ice has already formed, this will
affect cooling and increase energy consumption.
Defrost the freezer compartment and clean it.
The ambient room temperature is too high. The higher
the ambient temperature, the longer the compressor
has to run.
See the information in “Installation – Installation
site”.
The temperature setting in the refrigeration appliance
is too low.
Correct the temperature setting.
A large amount of food has been frozen at once.
See the information in “Operation – Freezing and
storing food”.
The SuperCool function is still switched on.
Switch off SuperCool earlier to save energy.
The compressor comes
on less and less often
and for shorter periods
of time. The temperature
in the refrigeration appli-
ance rises.
This is not a fault. The temperature setting is too high.
Correct the temperature setting.
Check the temperature again after 24hours.
The frozen food begins to defrost.
The ambient temperature is too low for this
refrigeration appliance.
If the ambient temperature is too low, the compressor
will run less frequently. This may cause the freezer
compartment to become too warm.
See the information in “Installation – Installation
site”.
Increase the ambient temperature.
Other problems
Problem Cause and remedy
The external walls of the
appliance feel warm.
This is not a fault. The heat created by the evaporator
is used to prevent condensation.
Troubleshooting
43
Display warnings
Message Cause and remedy
The 3°C, 7°C and
LEDs flash in the dis-
play.
This message appears if the appliance cannot be
connected to the WiFi or the connection is
interrupted.
Briefly touch the symbol to switch the alarm off,
and then check the WiFi connection (see
“Familiarisation” and “Adjusting settings –
“Activating the WiFi connection”).
and the 9°CLED
flash simultaneously in
the display.
This message appears if you have accidentally entered
service mode.
Either wait 5minutes or touch the symbol for
3seconds to exit service mode.
Troubleshooting
44
Interior lighting
Problem Cause and remedy
Risk of electric shock due to exposed, live electrical components.
When removing the lighting cover, there is a risk of coming into contact with
live electrical components.
Do not remove the lighting cover. The LED lighting may only be repaired or
replaced by the Miele Customer Service Department.
Risk of injury from LED lighting.
This lighting corresponds to risk group RG2. If the cover is defective, there is a
risk of eye injury.
If the lighting cover is defective, do not look from a close range directly into the
lighting with optical instruments (e.g. magnifying glass or similar).
Problem Cause and remedy
The interior lighting is
not working.
The refrigeration appliance has not been switched on.
Switch the refrigeration appliance on.
Sabbath mode is switched on.
To avoid overheating, the lighting switches itself off
automatically after approx. 15minutes if the appliance
door is left open. If this is not the case, then there is a
fault.
Call the Miele Customer Service Department.
Customer Service Department
45
Information to help you rectify faults
yourself and about Miele spare parts
can be found at www.miele.com/
service.
Contact in the event of a fault
In the event of a fault which you cannot
remedy yourself, please contact your
Miele dealer or Miele Customer Service.
You can book a Miele Customer
Service call-out online at
www.miele.com/service.
Contact information for Miele
Customer Service can be found at the
end of this document.
Please quote the model identifier and
serial number of your appliance (SN)
when contacting Miele Customer
Service. Both numbers can be found on
the data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
EPREL database
Since 1 March 2021, information on
energy labelling and ecodesign
requirements has been available in the
European Product Database (EPREL).
You can find the product database at
the following link https://
eprel.ec.europa.eu/. You will be asked to
enter the model identifier.
The model identifier can be found on the
data plate inside the refrigeration
appliance or, depending on the model,
in Settings mode under Information.
SN-ST
R600a:
XXXXXX
Nr. XX/ XXXXXXXXX.
XXX l
XXg
Warranty
For information on the appliance
warranty specific to your country please
contact Miele. See back cover for
address.
In the UK, your appliance warranty is
valid for 2 years from the date of
purchase. However, you must activate
your cover by calling 0330 160 6640 or
registering online at www.miele.co.uk.
Installation
46
Installation site
Risk of damage and danger of
injury due to the refrigeration
appliance tipping over.
This refrigeration appliance is very
heavy and can tip forwards when the
appliance door is open.
Keep the appliance door(s) closed
until the refrigeration appliance has
been built in. The refrigeration
appliance must be secured in its
building-in niche in accordance with
the operating and installation
instructions.
Fire risk and risk of damage from
appliances which give off heat.
Appliances which give off heat can
catch fire and set fire to the
refrigeration appliance.
The mains connection cable must not
come into contact with heat sources.
This refrigeration appliance must not
be installed underneath a hob.
Fire risk and danger of damage
from open flames.
Open flames can set fire to the
refrigeration appliance.
Keep open flames (e.g. a candle)
away from the refrigeration
appliance.
Risk of damage caused by
appliances discharging vapours.
Installing appliances that discharge
vapours behind the refrigeration
appliance will put it at risk of damage.
Do not install appliances that
discharge air or vapours behind the
refrigeration appliance. Provide a
separate air guide or install a partition
wall between the appliances.
Installation
47
This appliance should be installed in a
dry, well-ventilated room.
Risk of damage due to high
humidity.
In environments with high humidity,
condensation can build up on
external refrigeration appliance
panels.
This condensate can cause corrosion
on external appliance panels.
Install the refrigeration appliance in a
dry and/or air-conditioned room with
sufficient ventilation.
After installation please make sure
that the appliance door(s) closes
(close) properly and the refrigeration
appliance is installed in accordance
with these installation instructions. It
is essential to comply with the
specified ventilation cutout
requirements.
When deciding on the installation site,
please bear in mind that your
refrigeration appliance will use more
energy if installed near to a heater, a
cooker or another appliance that gives
off heat. Avoid direct sunlight.
The higher the ambient temperature, the
longer the compressor runs and the
higher the energy consumption is.
When installing the refrigeration
appliance, please note the following:
- The socket must be easily accessible
in an emergency, not concealed
behind the appliance.
- The mains plug and mains connection
cable must not touch the rear of the
refrigeration appliance as they could
be damaged by vibrations from the
appliance.
- Other appliances must also not be
plugged into a socket located directly
behind the refrigeration appliance.
- When installing the refrigeration
appliance, make sure that the mains
connection cable does not get
trapped or damaged.
- Do not position or operate multi-
socket adapters, distributor strips or
other electronic devices (e.g. halogen
transformers) at the rear of the
appliance.
- The floor at the installation site must
be horizontal and level and must be as
high as the surrounding floor.
Climate range
This refrigeration appliance is designed
for use within specific ambient
temperatures (climate range). Do not
use in ambient temperatures for which
it is not designed.
A lower ambient temperature leads to
the compressor switching off for longer
periods. This can cause the internal
temperature in the refrigeration
appliance to rise with the risk of food
deteriorating and going off.
The climate range is stated on the data
plate in the interior cabinet of the
refrigeration appliance.
Climate range Ambient
temperature
SN 10to32°C
N 16to32°C
ST 16to38°C
T 16to43°C
SN-ST 10to38°C
SN-T 10to43°C
Installation
48
Ventilation
Ventilation takes place through a
ventilation grille in the refrigeration
appliance plinth.
Risk of fire and damage due to
insufficient ventilation.
If the refrigeration appliance is not
ventilated sufficiently, the
compressor will run more frequently
and for longer periods. This will result
in increased energy consumption and
a higher operating temperature for
the compressor. This may, in turn,
cause damage to the compressor.
Please ensure that there is adequate
ventilation around the refrigeration
appliance.
It is essential to observe the required
ventilation gaps.
The ventilation gaps must not be
covered or blocked in any way.
They must also be regularly dusted.
Side-by-side installation
Risk of damage due to
condensation on external appliance
panels.
In environments with high humidity,
condensation can build up on
external appliance panels, which can
cause corrosion.
Do not place different refrigeration
appliance models directly next to or
on top of one other.
Your refrigeration appliance must not be
installed “side-by-side” because it is not
equipped with built-in heating units in
the side panels.
This refrigeration appliance can,
however, be installed next to certain
models that are equipped with
integrated heating in their side panel, as
long as they are installed in separate
building-in niches.
Please contact your dealer for specific
information about which combinations
will work with your appliance.
Changing the door hinging
Danger of injury and damage to
the appliance due to heavy door.
There is an increased risk of injury
and damage if the door hinging is
installed by a single person.
Always change the door hinging with
the help of a second person.
Risk of crushing at the hinge.
Fingers can get trapped in or around
the hinge.
Do not reach into the hinge when
opening and closing the door.
The refrigeration appliance is supplied
with right-hand hinging. If left-hand
hinging is required, the hinges must be
changed (see accompanying installation
instructions) before the refrigeration
appliance is installed in the niche.
Tip: Place a suitable cover on the floor
in front of the refrigeration appliance to
protect the appliance door and your
floor from damage during door hinging.
Be careful not to damage the door
seal. If the door seal is damaged, the
appliance door may not close
properly and cooling will be
insufficient.
Installation
49
Furniture door panel
–Gap
Depending on the style of kitchen
furniture, the thickness and edge radius
of the furniture door and the gap that
runs around the door, vertically and
horizontally, are specified.
It is essential to pay attention to the
following:
If the gap between the refrigeration
appliance furniture door panel and the
adjoining housing unit door or wall on
the hinged side is too small, the
appliance door could collide with the
adjoining housing unit door or wall
when opened.
It may be necessary to adjust the size
of this gap to suit the thickness and
edge radius of the appliance furniture
door.
Tip: This must be taken into
consideration when planning your
kitchen and when replacing an old
refrigeration appliance with a new one
to ensure the installation conditions
required are met.
Appliance
furniture
door
thickness
A [mm]
Gap X [mm]
for different
edge radiiB
R0 R1.2 R2 R3
≥16–19 min. 3
20 5 4 4 3.5
21 5.5 5 4.5 4
22 6.5 6 5.5 5
Adjoining kitchen furniture front
A=Furniture front thickness
B=Edge radius
X=Gap
Adjoining side wall
A=Furniture front thickness
B=Edge radius
X=Gap
Tip: Fit a spacer between the housing
unit carcase and the side wall. This way
you will get a sufficiently wide gap.
Installation
50
Weight of the furniture door
If the furniture door panel is too
heavy, this can cause damage.
Fitting a furniture front which is
heavier than the maximum permitted
weight could damage the hinges. This
damage can affect various factors,
such as operation of the appliance.
Before fitting a furniture door, ensure
that the weight of the door does not
exceed the maximum permitted.
The maximum permissible weight of the
furniture door is 10kg.
Limiting the opening angle of
the appliance door
The door hinges are set ex works to
enable the appliance door to be opened
wide.
If required, the opening angle can be
limited to approx. 90° using the
enclosed pins.
The locking pins for limiting the door
opening must be fitted before the
refrigeration appliance is installed.
Insert the pin into the door hinge from
above.
Installation
*INSTALLATION*
51
Building-in dimensions
Niche/side view
All dimensions are given in mm.
The refrigeration appliance will function correctly if the specified ventilation
openings are kept clear.
+4
≤10kg
560
≥150cm²
560
≤18
60
55
+54
21
Installation
*INSTALLATION*
52
Connections
All dimensions are given in mm.
3
+60
≥150cm²
a
View from the front
b
Mains connection cable, length = 2200mm
A longer mains connection cable is available to order from the Miele Customer
Service Department.
c
No connection sockets in this area
Installation
*INSTALLATION*
53
Installing the appliance
To install the refrigeration appliance,
you will need the following tools:
Tip: Store the enclosed metal rod in a
safe place. It is required for adjusting
the rear appliance feet.
Preparing the refrigeration appliance
Position the refrigeration appliance in
front of the niche.
Hold the plinth panel at the side and
pull it forwards and off.
You have a choice of two different
ways of securing your refrigeration
appliance:
1. Secured at the top
This method is suitable for securing
the appliance underneath a plastic
worktop, e.g., laminate. The worktop
must be suitable for screwing a fixing
bracket onto.
With the appliance feet fully
extended the appliance should sit
lightly tensioned between the floor
and the worktop.
2. Secured at the side
This method is suitable for securing
the appliance underneath a solid
worktop, e.g. granite. The furniture
side walls to the right and left of the
refrigeration appliance must be
suitable for screwing fixing brackets
to.
With the feet fully extended the
refrigeration appliance will sit lower
than the worktop.
1.Secured at the top
Fit the bracket in the opening in the
appliance lid.
Bend the bracket at the perforated
position.
Installation
*INSTALLATION*
54
2.Secured at the side
Both ends of the bracket must be
bent.
Fit the bracket in the opening in the
appliance lid.
Bend the bracket at the perforated
position.
Remove the bracket from the opening
and insert the straight end of the
bracket.
Now bend this end of the bracket at
the perforated position.
Positioning the refrigeration appliance
Risk of damaging the mains
connection cable.
When pushing the refrigeration
appliance into its niche, the mains
connection cable can get trapped
and damaged.
Carefully push the refrigeration
appliance into the niche.
Risk of damaging the floor.
Moving the refrigeration appliance
can cause damage to the floor.
Move the refrigeration appliance
carefully on floors that are sensitive
to scratching.
Risk of damaging the appliance
feet.
The appliance feet can break off.
The feet should be almost fully
screwed in when you push the
refrigeration appliance into the niche.
Tip: Before pushing the appliance into
the niche the two rear feet should be
loosened by half a turn. After pushing it
into the niche, the feet will be easier to
adjust from the front (see “Aligning the
refrigeration appliance”).
Position the mains connection cable
so that the refrigeration appliance can
be connected easily once installed.
Tip: To help you push it into position, tie
a piece of string around the plug to
“lengthen” the mains connection cable.
Then pull the mains connection cable by
the end of the string through the
housing unit.
Installation
*INSTALLATION*
55
If the refrigeration appliance is
pushed too far into the niche, the
appliance door may not close
properly once the furniture panel has
been fitted. This can cause ice to
build up, condensate to accumulate
and lead to faults in the appliance.
These can all lead to increased
energy consumption.
Push the refrigeration appliance into
the niche, making sure a gap of
42mm is maintained all round
between the appliance carcase and
the front of the housing unit side
walls.
Push the refrigeration appliance into
the niche until the front edges of the
hinges at the top and bottom are flush
with the front edge of the housing unit
side wall.
This will create a gap all round of
42mm to the front edges of the
housing unit side walls.
On furniture with door fittings (e.g.
stubs, seals, etc.), the dimension of
these must be taken into account to
ensure there is a gap all round of
42mm.
Pull the refrigeration appliance
forwards by the appropriate
dimension.
Check again to make sure there is a
gap of 42mm to the front edges of
the door fittings.
Tip: If possible, remove the door fittings
and push the refrigeration appliance into
the niche until all fixing brackets at the
top and bottom are touching the front
edge of the housing unit side wall.
Aligning the refrigeration appliance
When securing the refrigeration
appliance in the niche at the top, it
should sit lightly tensioned between
the floor and the worktop.
Adjust the front and rear feet
alternately according to the niche
height and make sure the refrigeration
appliance is correctly aligned.
Proceed as follows:
Adjust both rear feet with appropriate
screws at the front right and left in the
appliance plinth using the rod
supplied and a flat-head screwdriver.
Unscrew the two front levelling feet
alternately with the rear ones. The
maximum adjustment range is 6cm.
Tip: As soon as the feet have been
unscrewed slightly, you can adjust them
with a screwdriver at the bottom of the
foot (see small illustration).
The foam attached to the
ventilation grille ensures the airflow is
separated to prevent malfunctioning
of the appliance.
Installation
*INSTALLATION*
56
Replace the plinth panel with the
ventilation grille, but do not fix it in
place yet.
Without a continuous plinth facing:
Pull the plinth panel forwards until
the ventilation slots are in alignment
with adjacent cabinet plinth panels.
Hold the plinth panel securely and
attach it to the right and left using the
bolts supplied.
With the plinth panel attached, the
rear feet can only be adjusted when
the plinth panel is fully inserted.
Otherwise, the bar is not long enough.
With a continuous plinth facing:
Push the plinth panel with the
ventilation grille right up against
the refrigeration appliance, and attach
it to the right and left using bolts.
If a continuous plinth facing is to be
fitted, a suitable ventilation gap will
need to be made in it for the
ventilation grille of the refrigeration
appliance.
Trim the furniture plinth facing (U) to
the correct height.
Adjust the height (V) along the niche
width (W) underneath the appliance
plinth facing.
Securing the refrigeration appliance in
the niche
1.Secured at the top
Screw the refrigeration appliance in
place underneath the worktop with
two screws in each case.
Installation
*INSTALLATION*
57
2.Secured at the side
Screw the refrigeration appliance into
the niche on the right and left with
one screw in each case.
Fitting the furniture door
If fitted in a run of units make sure that
the top edge of the furniture door is at
the same height as neighbouring unit
doors.
The furniture door must be fitted
correctly and not under tension.
The next section gives instructions on
how to fit a furniture door that is at
least 16–19 mm thick.
Ensure that the plinth panel is refitted
correctly.
The distance between the appliance
door and the fixing bracket is set to
8mm at the factory. Check this
distance and adjust it if necessary.
Push the fitting aids up to the
height of the furniture door: the lower
edge X of the fitting aids must be at
the same height as the upper edge of
the furniture door being fitted (see
in diagram).
Installation
*INSTALLATION*
58
Tip: Push up the fitting aids with the
furniture front until they are the same
height as the doors of adjacent kitchen
units.
Undo the nuts and take the fixing
bracket off together with the fitting
aids .
Using a pencil, lightly mark a line
down the centre of the inside of the
furniture door.
Hang the fixing bracket with the
fitting aids onto the inside of the
furniture door. Align the fixing bracket
centrally.
Attach the fixing bracket securely
using at least 6 short chipboard
screws. (On cassette doors only
use 4 screws on the edges.) Drill
holes into the furniture door if
necessary.
Pull the fitting aids upwards to
remove them .
Turn them around and fit them into
the middle slots on the fixing bracket
for safe keeping.
Installation
*INSTALLATION*
59
Fit the side cover to the fixing bracket
on the opposite side of the hinge.
Turn the furniture door over and
attach the handle (if required).
Open the appliance door.
Hang the furniture door onto the
adjusting bolts.
Loosely attach the nuts on the
adjusting bolts.
Close the door and check the
distance between the door and
neighbouring furniture doors.
Align to match neighbouring doors if
necessary:
Side adjustments X are made by
sliding the furniture door, and height
adjustments Y by turning adjusting
bolts with a screwdriver.
Whilst counterholding adjusting
bolts with a screwdriver, tighten
nuts on the appliance door with
screwdriver.
Attach the appliance door and the
furniture door using screws through
fixing brackets:
- Drill holes in the furniture door (mark
the position of the holes first).
- Screw in the short chipboard
screws (4x14mm).
Align the furniture door along the
depth plane Z: loosen the screws in
the long slots at the top of the
Installation
*INSTALLATION*
60
appliance door as well as under the
appliance door. By moving the
furniture door, create a gap of 2mm
between the furniture door and the
front edge of the niche. Align
according to the adjacent furniture
doors.
Close the door, check it is secured
correctly, and align it with adjacent
furniture doors.
Tighten all the screws again.
Replace the cover and click it into
place.
To make sure the appliance is
correctly fitted:
- The door must close properly.
- The door must not touch the housing
unit.
- The seal at the top edge of the handle
side must fit properly.
To double check place a torch in the
appliance and close the door.
Turn the lights out in the room. If you
can see any light shining out from the
sides double check the installation.
Installation
*INSTALLATION*
61
Electrical connection
The refrigeration appliance must only be
connected to an earthed socket using
the mains connection cable supplied.
The socket must be easily accessible
after the refrigeration appliance has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the refrigeration
appliance to a multi-socket plug
adapter or to an extension lead can
overload the cable.
For safety reasons, do not use an
extension lead or multi-socket
adapter.
The electrical installation must comply
with VDE0100 requirements.
For safety reasons, we recommend
using a type residual current device
(RCD) in the assigned electrical
installation for connecting the
refrigeration appliance.
If the mains connection cable is
damaged, it must only be replaced with
a specific mains connection cable of the
same type (available from the Miele
Customer Service Department). For
safety reasons, such replacement may
only be carried out by a qualified
specialist or the Miele Customer
Service Department.
These operating instructions and the
data plate indicate the nominal power
consumption and the appropriate fuse
rating. Compare this information with
the data of the on-site electrical
connection. If in any doubt, consult a
qualified electrician.
Temporary or permanent operation on
an autonomous power supply system or
a power supply system that is not
synchronised with the mains power
supply (e.g. island networks, back-up
systems) is possible. A prerequisite for
operation is that the power supply
system complies with the specifications
of EN50160 or an equivalent standard.
The function and operation of the
protective measures provided in the
domestic electrical installation and in
this Miele product must also be
maintained in isolated operation or in
operation that is not synchronised with
the mains power supply, or these
measures must be replaced by
equivalent measures in the installation.
As described, for example, in the current
version of VDE-AR-E2510-2.
Connecting the refrigeration appliance
Insert the plug connector into the
socket at the back of the refrigeration
appliance.
Make sure that the plug connector has
clicked into position correctly.
Insert the plug of the refrigeration
appliance into the socket.
The refrigeration appliance is now
connected to the electricity supply.
EU Conformity declaration
62
Miele hereby declares that this
refrigerator complies with Directive
2014/53/EU.
The complete text of the EU declaration
of conformity is available from one of
the following internet addresses:
- Products, Download from
www.miele.ie
- For service, information, operating
instructions etc: go to
https://miele.co.uk/manuals and enter
the name of the product or the serial
number
Frequency range
of the WiFi
module
2.4000–
2.4835GHz
Maximum
transmission
power of the WiFi
module
<100mW
UK Conformity declaration
63
Miele hereby declares that this refrigerator complies with UK Radio Equipment
Regulations 2017, as amended.
The complete text of the UK declaration of conformity is available from one of the
following internet addresses:
- Products, Download from www.miele.co.uk
- For service, information, operating instructions etc: go to https://miele.co.uk/
manuals and enter the name of the product or the serial number
Frequency band of the WiFi module 2.4000GHz – 2.4835GHz
Maximum transmitting power of the
WiFi module
<100mW
ThisStatement of Compliance confirms this Miele product fully complies with the
Product Security and Telecommunications Infrastructure (Security Requirements
for Relevant Connectable Products) Regulations 2023.
1) Household Appliance –
2)
Manufactured by: Miele & Cie KG,
Carl Miele Street 29, 33332 Gutersloh Germany
Imported by and contact point: Miele Company Ltd, Fairacres, Marcham Road,
Abingdon, Oxon, OX14 ITW Great Britain
The defined support period at the time of first supply is 10 years
3)
To report vulnerabilities and cybersecurity issues please contact: [email protected]4)
5) Signature
Name: Paul Wright
Company Position: Head of Technical Management
Date of signature: 19th March 2024
Place of signature:
Abingdon, Oxfordshire
Freezer - 120002, 120003, 220009, 320001, 320002
Refrigerator - 110001, 110002, 210010, 310001, 310002,
310003
Fridge-freezer - 130001, 130002, 130003, 130004,
330001, 330002
Wine unit - 210007, 210011, 310004, 330004
Copyrights and licences
64
For the purpose of operating and controlling the communication module, Miele
uses proprietary or third-party software that is not covered by open source
licensing terms. This software/these software components are protected by
copyright. The copyrights held by Miele and third parties must be respected.
Furthermore, the communication module integrated in the appliance contains
software components which are distributed under open source licence conditions.
The open source components contained in the appliance along with the
corresponding copyright notices, copies of the licensing terms valid at the time and
any further information can be accessed locally by IP via a web browser (http[s]://
<IP address>/Licenses). The liability and warranty arrangements for the open
source licences displayed in this location only apply in relation to the respective
rights holders.
United Kingdom
Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW
Tel: 0330 160 6600, Internet: www.miele.co.uk, E-mail: [email protected]
Australia
Miele Australia Pty. Ltd.
ACN 005 635 398
ABN 96 005 635 398
Level 4, 141 Camberwell Road
Hawthorn East, VIC 3123
Tel: 1300 464 353
E-mail: [email protected]
Internet: www.miele.com.au
Miele Electrical Appliances Co. Ltd.
No. 82, Shimenyi Road, JingAn District
Shanghai, China, P.R.C
Post Code: 200040
Phone: +86 21 6157 3500
Fax: +86 21 6157 3511
E-mail: info@miele.cn
Internet: www.miele.cn
China Mainland
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road
Kowloon Bay, Hong Kong
Tel: (852) 2610 1025
Fax: (852) 3579 1404
E-mail:
Website: www.miele.hk
Hong Kong, China
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9, Mathura Road,
Jasola, New Delhi - 110025
E-mail: customercare@miele.in
Website: www.miele.in
India
Miele Ireland Ltd.
2024 Bianconi Avenue
Citywest Business Campus
Dublin 24
Tel: (01) 461 07 10
Fax: (01) 461 07 97
E-mail: [email protected]
Internet: www.miele.ie
Ireland
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana
Petroleum
Solaris Dutamas No. 1
Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Miele New Zealand Limited
IRD 98 463 631
8 College Hill
Freemans Bay, Auckland 1011
Tel: 0800 464 353
Internet: www.miele.co.nz
New Zealand
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
Tel: +65 6735 1191
Fax: +65 6735 1161
E-mail: [email protected]
Internet: www.miele.sg
Singapore
Miele (Pty) Ltd.
63 Peter Place, Bryanston 2194
Tel: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
Miele Appliances Ltd.
Showroom 1, Eiffel 1 Building
P.O. Box 114782 - Dubai
Tel. +971 4 3044 999
Fax. +971 4 3418 852
800-MIELE (64353)
E-mail: [email protected]
Website: www.miele.ae
United Arab Emirates
Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Sheikh Zayed Road, Umm Al Sheif
E-mail: customercare@miele.co.nz
P.O. Box 69434, Bryanston 2021
M.-Nr. 12 794 230 / 03en-GB
KU 7015 ..., KU 7016 ...
