2
User Manual
Welcome
Congratulations on purchasing your new Front Load Washing Machine.
Sôlt is proudly distributed within Australia by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for information
regarding your product’s parts and labour warranty, or visit us online at:
→ www.residentiagroup.com.au
At Residentia Group, we are customer obsessed and our Support Team are
there to ensure you get the most out of your appliance. Should you want
to learn more about your unit such as the various temperature guides or
importantly taking care of the appliance, our Support Team are here to help.
You can use our online Support Centre at any time by visiting:
→ http://support.residentiagroup.com.au
Or you can contact us via phone by dialling: 1300 11 HELP (4357).
It is important that you read through the following use and care manual
thoroughly to familiarise yourself with the installation and operation
requirements of your appliance to ensure optimum performance.
Again, thank you for choosing an Sôlt appliance and we look forward to being
of service to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Office
165 Barkly Avenue
Burnley Victoria
Australia 3121
—
ACN
600 546 656
—
Online
residentia.group
www.Sôlt.house
@Solt.house
—
Postage
PO BOX 5177, Burnley
VIC Australia 3121
—
Telephone
1300 11 4357
—
Email
3
User Manual
Sôlt recommends the use of original spare parts.
When contacting our customer service team by calling 1300 11 4357,
or by e-mailing support@residentiagroup.com.au, please ensure that
you have the following information at hand.
(found on your appliances’ rating plate).
• Model Number
• Serial Number
Safety Information 04
Installation Instructions 07
Your Washing Machine 10
Quick Start Guide 14
Operating Instructions 15
Cleaning & Maintenance 20
Troubleshooting 22
Technical Specifications 23
Purchase Details 24
Warranty Information 26
Contents
Customer Care
4
User Manual
Conditions of Use
• This appliance is intended to be used in household and
similar applications such as farm houses or by customers
in serviced apartments, holiday apartments and other
residential type of environments.
Safety Instructions
• Before the installation and use of the appliance,
carefully read the supplied instructions.
• The manufacturer is not responsible if an incorrect
installation and use causes injuries and damages.
• Always keep the instructions with your appliance for
future reference.
WARNING: To prevent any damages to yours
or others’ life or property, it is critical
that you follow the safety notes.
WARNING: Caution, risk of fire!
Children & Vulnerable People’s Safety
WARNING: Risk of suffocation, injury or
permanent disability.
• This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction for the operation of the appliance by a
person who is responsible for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door
when it is open. Check the machine before
every operation.
• Cleaning and user maintenance shall not be made by
children without supervision.
• Glass door may be very hot during the operation.
Keep kids and pets far away from the machine during
the operation very wet rooms as well as in the rooms
with explosive or caustic gas.
Installation
• Carefully rremove all the packaging.
• Do not install or use a damaged appliance.
• Carefully follow the installation instructions supplied
with the appliance.
• Old hose-sets are not to be reused and the new
hose-sets supplied with the appliance are to be used.
• Before any maintenance the device, unplug the
appliance from the mains.
• Make sure that the water and electrical devices are
connected by a qualified technician in accordance with
the user manual and local safety regulations.
• Plug must be accessible after installation.
• Make sure that the floor where you install the appliance
is flat, stable, heat resistant and clean.
• Always remove the plug and turn off the water supply to
the appliance after every use.
• This washing machine is for indoor use only.
• Sharp and rigid items such as coins, nails and screws
may cause serious damage to this appliance- always
ensure pockets of clothing are empty.
• Always ensure that the drum has drained all water
before opening the appliance door. If water is visible, do
not open the appliance door.
• Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite side,
where the appliance door cannot be fully opened.
• Always be careful when you move the appliance
because it is heavy. Always wear safety gloves.
• Always move the appliance vertically.
• The rear surface of the appliance must be placed
against a wall.
• The openings must not be obstructed by a carpet.
• This appliance should not be installed in a bathroom
or similar wet rooms, as well as rooms with explosive or
caustic gases.
• Washing machines with a single water inlet and should
only be connected to the cold water supply outlet.
Models featuring two inlet valves should be correctly
connected to the hot and cold water outlets.
Safety Information
5
User Manual
• The appliance can be installed as freestanding or below
the kitchen counter with correct space. This washing
machine is not intended to be built-in.
• When the appliance is put in its permanent position,
check if it is fully level with the aid of a spirit level. If it is
not, adjust the feet until it is.
• The max. inlet water pressure, in pascals. The min. inlet
water pressure, in pascals.
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
Max. Inlet Pressure 1.0Mpa
Min. Inlet Pressure 0.05Mpa
Electrical Connection
WARNING: Caution, risk of fire and electrical shock!
• To ensure your safety, power plug must be inserted into
an earthed three-pole socket. Check carefully and make
sure that your socket is properly and reliably earthed.
• Plug must be accessible after installation.
• Make sure that the electrical information on the rating
plate aligns with your power supply. If it does not,
contact an electrician for assistance.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and
to the mains cable. Should the appliance power supply
cable need to be replaced, this must be carried out by
our Service Centre.
• Connect the mains plug to the mains socket only at the
end of the installation. Make sure that there is access to
the mains plug after the installation. Do not connect the
appliance plug with a power connection board.
• Do not pull the mains cable to disconnect the appliance.
Always pull the mains plug.
• Under no circumstances should you touch the mains
cable or the mains plug with wet hands.
• This appliance complies with the E.E.C. Directives.
Care & Cleaning
WARNING: Risk of injury or damage to the appliance.
• Before maintenance, deactivate the appliance and
disconnect the mains plug.
• Never use spraybottles or steam to clean the appliance.
• Clean the appliance with a moist soft cloth and only
use neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
Transport
• Always move the appliance cautiously. Do not use the
machine door or the handle of the detergent dispenser,
to lift the appliance.
• Transportation bolts should be reinstalled within the
machine by a specialised person, prior to transporting
the appliance.
• Ensure that all accumulated water is drained from the
appliance before moving.
Product Disposal
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
6
User Manual
Safety Information (continued)
Appliance Use
WARNING: Risk of fire, explosion, electric shock or
damage to the appliance.
• Use this appliance in a household only.
• Before operating this appliance, ensure that all
packaging and transport bolts have been removed.
Otherwise, serious damage can occur to the appliance.
• Before washing any clothes for the first time, the
washing machine should be operated for one whole
cycle without any clothes inside.
• Always unplug the machine and turn off the water
supply after use. The max. inlet water pressure, in
pascals. The min. inlet water pressure, in pascals.
• Do not climb up or sit on top of the appliance.
• Do not change the specification of this appliance.
• If you use fabric softener or similar products, obey the
instructions on the packaging.
• Do not sit or stand on the open door.
• Obey the maximum load volume of 9.0 kg
(refer to the Program chart on page XX of the manual).
• Ensure all objects are removed from clothing pockets
such as lighters and matches.
• Please only use front load washing machine detergents.
Flammable and explosive or toxic solvents are forbidden
for use with this appliance. Gasoline and alcohol should
not be used as a detergent.
• Do not wash or dry articles that have been cleaned
in, washed in, soaked in, or dabbed with combustible
or explosive substances( such as wax, oil, paint,
gasoline, degreasers, dry-cleaning solvents,
kerosene, etc.) This may result in fire or explosion.
If they have been in contact with any of the above,
beforehand thoroughly rinse items of washing by hand.
• Never wash carpets or rugs within the appliance.
• Never refill the water by hand during washing.
• Be careful to avoid burns when the machine drains hot
washing water.
• After a wash program completes, please wait two
minutes before opening the door.
• If wanting to install a tumble dryer on top of your
washing machine, use the suitable stacking kit.
The stacking kit, available from your authorised vendor,
can be used only with the appliance specified in the
instructions, supplied with the accessory. Carefully read
the instructions before proceeding with installation.
• Never lean against the machine door.
• Please do not close the machine door with excessive
force and if you find it difficult to close the door, ensure
that the clothing load isn’t excessive.
• Glass door may become hot during operating.
7
User Manual
Installation Instructions
Installation Positioning
• Ensure that your appliance is installed on solid and
flat ground, in a level position. Please do not place the
appliance on a slope, soft carpet or wooden floor.
• Avoid positioning the appliance in direct sunlight or
where there is inadequate ventilation.
• Your appliance should only be installed within an
internal environment. Do not install the appliance
outdoors.
• Room temperature must be above 0°C.
Unpacking the Washing Machine
WARNING: Packaging material can be dangerous for
children. There is a risk of suffocation!
Keep packaging well away from children.
1 Remove the cardboard box and styrofoam packing.
2 Lift the washing machine and remove the base packing.
Make sure the small triangle foam is removed with the
bottom one together. If not, lay the unit down with
side surface, then remove the small foam from the unit
bottom manually.
3 Remove the tape securing the power supply cord and
drain hose.
4 Remove the inlet hose from the drum.
Removing the Transportation Bolts
WARNING: Before using, the transport bolts must be
removed from the back of this machine.
Please take the following steps to remove the bolts:
1 Loosen all 4 bolts with a spanner
2 Remove the bolts including the rubber parts and keep
them for future use.
3 Close the holes using the cover caps.
4 Keep the transport bolts for future use.
5 Note: You’ll need the transport bolts again if you move
the appliance, so please keep them in a safe place.
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
Installation
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0℃
5.Keep far away from the heat resources such as coal or gas.
as
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Make sure the small triangle
foam is removed with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Stop the holes with transport hole plugs.
3.Keep the transport bolts properly for future use.
Remove transport bolts
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
•
•
Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
There is a risk of suffocation ! Keep all packaging
well away from children.
Warning!
•
• product
you
You must remove the transport bolts from the backside before using the product.
You’ll need the transport bolts again if you move the , so make sure
keep them in a safe place.
Warning!
INSTALLATION
w
w
W> 20mm
Installation area
9
8
User Manual
Installation Instructions (continued)
Leveling the Washing Machine
WARNING: The lock nuts on all four feet must be screwed
tightly against the housing. If the floor is
obviously uneven, your appliance feet need
to be adjusted. If your appliance isn’t level,
it will cause your appliance to vibrate, and
potentially move from its position.
1 Once you’ve positioned your washing machine, press
down from the top in all four corners to ensure that it’s
completely stable (i.e. not rocking in any direction). Also
use a spirit level to ensure that it is completely level in all
directions.
2 Should you need to make adjustments, use a spanner to
turn the appliance legs until it makes contact with the
floor.
Turn the leg using one hand and then fasten the nut up
against the appliance cabinet, to lock the leg in place.
3 After making any adjustments to the appliance legs,
re-check to ensure it is level and no rocking occurring.
Leveling the Washing Machine
WARNING: To prevent leakage or water damage, follow
the instructions in this chapter. Do not kink,
crush, modify or sever the water inlet hose!
• Connect the water supply hose to the water inlet valve
and a water tap with cold water as indicated.
NOTE: Connect by hand, do not use tools. Ensure that the
connections are tightly fitted.
Position the Drain Hose
The outlet hose (used to drain the discharged water) is to
be ideally connected to the relevant waste pipe, although
it can also be positioned to drain into a sink/trough.
Note that the outlet hose has a minimum outlet position of
60cm and a maximum position of 100cm.
WARNING: If you are positioning the outlet hose to drain
into a sink or trough, please ensure that it
is fixed in place and that the sink remains
unblocked at all times. If drain hose is too
long, do not force it into washing machine
as it will cause abnormal noises.
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
9
9
INSTALLATION
Remove transport bolts
• You must remove the transport bolts from the backside before using the product.
Warning!
！
Loosen the 4
transport bolts with
a spanner.
Remove the bolts
including the rubber
parts and keep them
for future use.
Close the holes
using the cover caps.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Warning!
！
1. Loosen the lock nut.
2. Turn the foot until it reaches the floor.
3. Adjust the legs and lock the nuts with a
spanner. Make sure the machine is level
and
steady.
Connect the water supply hose
To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush or modify water inlet hose.
Warning!
！！
Connect the water supply
hose to the water inlet valve
and a water tap with cold
water as indicated.
• Connect manually, do not use tools. Check if the connections are tight.
Note!
Warning!
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Min.60cm
100cm
Max.
Warning!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
11
Warning!
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
When installing drain hose, fix it properly with a rope.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
Min.60cm
100cm
Max.
Warning!
INSTALLATION
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
11
9
User Manual
Applying the Acoustic Sponge
NOTE: Please make sure to assemble the acoustic
sponges, which can effectively reduce the noise caused by
the machine while working, in order to provide you with a
more peaceful and quiet living environment.
1 Lie the machine laid on the floor, using some soft
material like foam or clothes between the machine
and floor for protection;
2 Stick the 2× longer sponges to the longer bottom edges
of machine, and the 2× shorter sponges to the shorter
bottom edges.
10
10
INSTALLATION
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the water trough. 2.Connect it to the branch drain pipe of
the trough.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Water
trough
100cm
Max.
Warning!
！！
Warning!
！
Min.60cm
• Please make sure to assemble the acoustic sponges, which can effectively
reduce the noise caused by the machine while working, in order to provide
you with a more peaceful and quiet living environment.
Note!
Acoustic Sponge
2x
2x
1. Get the machine laid on the floor, using some soft material like foam or clothes
between the machine and floor for a protection;
2. Stick the 2x longer sponges to the longer bottom edges of machine, and the 2x
shorter sponges to the shorter bottom edges.
10
User Manual
NOTE: The images in this user manual are for explanatory purposes only.
Your Front Load Washing Machine may appear slightly different.
Your Washing Machine
be ideally connected to the
relevant waste pipe, although
Water Supply Hose Power Supply Cord
Control Panel
9kg Capacity Drum Drain Hose
Service Panel
Detergent Dispenser
Front Load Door
Front Load Washing Machine
11
User Manual
1
Program Selection Dial Display
Different washing cycles can be selected
according to the users need and the type of
laundry to be washed.
The display shows the setting, estimated program time remaining,
options and status messages of your washer. This display will
remain on through the cycle.
1 Additional Function Buttons: These buttons are used for setting
additional functions to your cycle.
2 Drum Clean: Select this program to clean the drum and tube.
3 Start/Pause Button: Press this button to start of pause the
drying cycle. Press for 3 seconds to use the Reload function.
1 2 3
Accessories
7
Accessories
Product Description
• The product line chart is for reference only, please refer to real product as
standard.
Note!
Drum
Power supply cord
Control panel
Detergent dispenser
Service filter
Door
Water supply hose
Top cover
Drain hose
INSTALLATION
4 x Cover caps
1 x Supply hose
cold water
1 x Owner’s manual
Acoustic
sponge
(Optional)
1 Transport hole plug 2 Supply hose cold water 3 Owner’s manual 4 Acoustic sponges 5 Quick Start Guide
12
User Manual
Your Washing Machine (continued)
Display
GFHA
B C D E
A Display
E
Drum Clean
B Child lock
F
Pre Wash
C Door lock
G
Extra Rinse
D Delay
H
Mute
13
User Manual
Detergent Dispenser
The detergent drawer of your washing machine
is split into three compartments:
I Pre-wash detergent compartment.
Refer to the Wash Programs Table
to see which programs utilise a pre-wash.
II Main detergent compartment.
This is the common detergent drawer.
Softener compartment.
WARNING: Liquid detergent is only required in
compartment “I” after selecting the
Pre-Wash function.
NOTE: When using granulated detergent or additive,
before they are poured into the detergent box,
it is suggested to mix water for dilution and then
to pour into the detergent box. This prevents the
inlet of the detergent box from blockages and
overflowing. Please choose a suitable type of
detergent for the various washing temperature to
get the best washing performance with less water
and energy consumption.
Caution!
• Detergent only need to be added in "case I “after selecting pre-washing
for machines with this function.
10
14
Detergent Dispenser
Pre wash detergent
Main wash detergent
Softener
II
I
Pull out the dispenser
Caution!
OPERATIONS
• As for the agglomerated or ropy detergent or additive, before they are
poured the detergent box, it is suggested to use some water for
dilution to prevent inlet of detergent box from being blocked and
overflowing while filling water.
•
into
the
Please choose suitable type of detergent for the various washing
temperature to get the best washing performance with less water and
energy consumption.
Note!
Mandatory ○ Optional
Programme
Cotton
Synthetic
Mix
Jeans
Spin Only
Rinse & Spin
ECO Wash
20
Programme
Bulky
Baby Care
Wool
Sport Wear
Rapid 45’
Quick 15’
Steam Wash
Program Pre Wash Main Detergent Softener
Steam Wash
Optional Required Optional
Cotton
Optional Required Optional
Synthetic
Optional Required Optional
Mix
Optional Required Optional
Jeans
Optional Required Optional
ECO Wash
— Required Optional
20° C
— Required Optional
Spin
— — —
Rinse & Spin
— — Optional
Bulky Load
Optional Required Optional
Baby Care
Optional Required Optional
Wool
— Required Optional
Sport Wear
Optional Required Optional
Rapid 45’
— Required Optional
Quick 15’
— Required Optional
14
User Manual
Quick Start Guide
Calibration
• It’s recommended to calibrate the washing machine, so
that provide the best performance.
• The appliance is able to detect the amount of laundry
loaded. This function is optimising the product
performance by minimising energy and water
consumption, saving you money and time. For this
reason it’s recommended to calibrate the appliance for
best use.
• Remove all accessories from the drum and close door;
• Insert the mains plug to the socket;
• Switch on the washing machine and within 10
seconds, press “Delay” and “Temp.” simultaneously for
approximately 3 seconds until “t19” is shown on the
display screen.
• Press the Start/Pause to start the appliance,
initially“---” is displayed, and then “***” (such as “126”)
is displayed to indicate the real time drum speed.
When the number reaches a certain value (and
stop changing), it means the washing machine is
successfully calibrated.
Before Washing
• Install your washing machine.
• Plug in the power supply.
• Turn on the water supply.
• Open the door and load in the laundry.
• Close the machine door.
• Measure detergent and pour in appropriate amount
• Power on the washing machine.
• Select the desired program.
• Select any additional functions if required.
• Press the Start/Pause button to begin.
Completion Of The Washing Cycle
• At the completion of a wash program, the washing
machine will make an audible tone and “End” will be
displayed on the screen.
• Turn off the water supply
• Although the washing machine would be switched off,
the power outlet should be switched off and the plug
should be pulled out for safety reasons.
CAUTION: Before washing, please make sure it’s installed
properly. Your appliance was thoroughly
checked before it left the factory. To remove
any residual water and to neutralise potential
odours, it’s recommended to clean your
appliance before first use. For this reason, start
the Cotton program at 90°C without laundry
and detergent
15
User Manual
Operating Instructions
Preparation Before Washing Clothes
Please follow these steps carefully to avoid trouble with
your washing machine and damaging your clothing
Washing Considerations
• The working condition of the washer should be
(0-40)°C. If used under 0°C,the inlet valve and draining
system may be damaged. If the machine is placed
under condition of 0°C or less, then it should be
transferred to normal ambient temperature to ensure
the water supply hose and drain hose are not frozen
before use.
• Please check the labels and the explanation of using
detergent before wash. Use non-foaming or less-
foaming detergent suitable for machine washing
properly.
• New clothes in particular, can leach colour onto other
clothing items, particularly whites.
Consider washing these and bright colours separately.
• Stained clothing should be treated with a stain
remover, prior to washing.
• Temperature sensitive clothes should be washed in
accordance with their care direction label. Otherwise
distortion and/or changes in colour could occur.
• Never allow washing to sit in the machine for a long
period of time- particularly when wet. Clothes can
become mouldy and develop an odour.
• Certain clothing cannot be washed in a washing
machine and their care directions may state dry
cleaning or hand washing required.
• Wrinkle style clothes, embossed clothes, resin clothes,
etc may become distorted when immersed in water.
• Avoid washing clothes without care direction labels
within the appliance, to be safe.
• Always remove all items from clothing pockets, as hard
items can cause damage to the appliance.
• Try to wash clothing colours and sizes in like loads,
as this will improve the effectiveness of the washing
and results.
• Close all clothing zips and ensure all buttons are
fastened securely.
• Delicate items such as bras, handkerchiefs and ties
should be washed within a special washing bag, to
prevent damage to themselves and other clothes.
• When washing a large single item that could become
heavy (i.e. a towel or jacket), it can cause the
appliance to become unbalance during its spin cycle.
Therefore it’s recommended to add one or two more
clothing items to help the machine balance.
• Try to remove any pet hair, dust and stains from
clothing prior to washing.
• Baby clothing should be washed separately.
• Clothing that gets easily “fuzzed” or loses fibres easily,
should be washed separately.
• Black clothing items should be washed separately.
• Do not wash waterproof materials within the
washing machine.
Pay Attention to Detergents
• Only use suitable front load washing machine
detergents with this appliance. Powders and liquid
detergents only.
• Only ever use the recommended quantity of detergent,
as per the manufacturer’s guidelines, as an excessive
quantity can cause excessive bubbles and overflow
to occur.
• It can also result in detergent residue remaining on the
clothing after completion of the wash cycle.
WARNING: Always keep detergents and additives out of
reach from children.
Clothing Classifications
• The symbol types on care labels are typically classified
into the following textiles: Cotton, Blended Fibre,
Synthetic Fibre, Silk, Wool and Artificial Fibre.
Confirm the Washing Capacity
• Never load the machine with excessive weights, as it
will affect your washing results.
16
User Manual
Operating Instructions (continued)
Washing Clothes for the First Time
• Before washing any clothes, please perform one cycle
without clothes inside as follows:
• Connect the power source and water.
• Insert a small amount of detergent into the detergent
drawer and close it.
• Select a Cotton program at 90°C.
• Press the “Start/Pause” button on the appliance.
• Allow the program to complete and your washing
machine is now ready for use.
Selecting a Procedure
You should select you washing program based on the type
of clothing, quantity and dirtiness level, in combination
with the following temperature table.
Temperature Mode Application
90º C
Seriously soiled clothing, pure white cotton
(I.e. bed linen, towels, table cloths, etc)
60º C
Moderately soiled clothing, cotton and
synthetic articles with certain decolourising
degree (I.e. shirts, pajamas, etc)
40º C, 30º C,
20º C, Cold Water
Lightly soiled clothing, synthetics and wool
To Select a Program:
• First turn the Program Selection Dial to the
corresponding wash program, according to the type of
textiles being washed.
• Secondly, select the desired temperature based on
the level of dirtiness. Note: Generally the higher the
temperature, the more power that’s consumed.
• Finally, select your desired spin speed. The higher the
spin speed, the drier the textiles will be at completion,
however more delicate textiles will be more wrinkled.
Delicate textiles should be set with a lower spin speed.
Selecting the main washing program depend on the
types of clothing to be washed, as follows:
Steam Wash
Select this function for steam-assisted washing. The higher
temperature makes it easier to break down stains more
effectively, getting rid of allergens and bacteria whilst also
reducing the need to iron wrinkles in clothing.
Cotton
Suitable for hard wearing and heat resistant textiles made
from cotton or linen. To increase the washing results the
main washing time is increased.
Synthetic
The procedure is shorter compared with that for cottons
and the washing intensity is relatively gentle. It is
recommended for washing synthetic articles, for example:
shirts, coats, etc.
Mix
You can select this procedure for washing durable clothes,
that typically require more wash time and intensity. It is
ideal for any “daily” clothing such as cotton, including
sheets, pillowcases, bathrobes and underwear.
Jeans
Suitable for durable garments such as denim.
ECO Wash
This procedure saves energy and limits the washing
temperatures between 20°C–60°C. The default set
temperature is 20°C. Use with a small quantity of clothes
which are only lightly dirty.
20° C
You can select this procedure for washing delicate items
where the care label suggests Cold Wash. To be used with
only a small quantity of clothing at a time with light soiling
only. The default temperature for this program is 20° C.
17
User Manual
Spin
This procedure provides a spin only option. Residual soapy
water shall be drained out before spinning.
Rinse & Spin
This procedure provides a short rinse cycle followed by a
spin cycle.
Bulky Load
You can select this procedure for washing bulky items.
Baby Care
Washing the baby’s clothes, it can make the baby’s wear
cleaner and make the rinse performance better to protect
the baby skin.
Wool
You can select this procedure to wash wool textiles labeled
with “Machine Wash”. Please select the proper washing
temperature according to the clothings care label.
Furthermore, the proper detergent amount should be
used for wool textiles, which is generally less than normal
wash loads.
Sport Wear
You can select this procedure for washing sport and
active-wear clothing.
Rapid 45’
This procedure is suitable for washing a small quantity of
clothes without heavy soiling.
Quick 15’
You can select this procedure for washing a small quantity
of clothing, where items are only lightly soiled.
Additional Functions
Delay Function
The Delay function can be set with this button, where the
delay is 0–24 Hrs.
To set the Delay function:
• Select a wash program;
• Press the Delay button to choose the time;
• Press Start/Pause to commence the delay operation.
To Cancel the Delay function:
• Press the Delay button until the display shows 0H.
• It should be pressed prior to starting the program.
• If the program has already started, press the On/Off
button to reset.
Spin Function
Select this button to manually set the spin speed of your
wash program from the following options:
• 0
• 400
• 600
• 800
• 1000
• 1200
• 1400
Temperature Function
Select this button to manually set the temperature of your
wash program from the following options:
• Cold
• 20°C
• 40°C
• 60°C
• 90°C
18
User Manual
Operating Instructions (continued)
Pre Wash Function
The Pre Wash function adds an additional wash prior to
the main wash. Extra detergent should be placed in the
detergent compartment when selected.
Extra Rinse Function
The laundry will undergo an extra rinse cycle at the
completion of the program.
Drum Clean
After 25 washes, the Drum Clean light will illuminate to
remind you to run this cycle. This program provides a 90°C
high temperature sterilisation cycle to clean the drum and
tube. When this procedure is performed, clothes or other
items should not be added. Use this program regularly
according to your needs.
To cancel the reminder for another 25 cycles, press and
hold the Drum Clean button for 3 seconds.
Mute Function
This function allows you to turn the audible tone on or off,
to indicate that your washing program is complete. By
default, the audible signal is set to On.
When the Mute function is on, your appliance will make an
audible tone when:
• The additional wash functions are pressed.
• If the washing machine is operating and the program
selector knob is turned, the appliance will make an
audible tone to alert the user that an invalid choice has
been made.
• At the completion of a washing program, an audible
tone will sound.
• To activate or deactivate the Mute function:
• Press and hold the “Spin” buttons for 3 seconds.
Reload (Add a Garment) Function
This function can be executed during operation of a
washing program. When the drum of the machine is still in
motion and/or there is a large amount of water inside, the
machine will not allow the door to be opened.
To Use the Reload function:
• Press and hold the Start/Pause button for 3 seconds.
• Once the drum stops rotating, the door will unlock and
allow you to open.
• Add your additional clothing items and close the door.
• Press the Start/Pause button once again to continue
the wash program.
Child Lock
To avoid the washing procedure being altered by children,
you can activate the child lock function. All buttons and
dials won’t alter the machines settings, however the
On/Off button will still function.
When Child Lock is activated, “CL” will display alternating
with the remaining wash time on the screen. At the
completion of your cycle, “CL” and “END” will alternate on
the display for 10 seconds, then the indicator will flash for 3
seconds.
NOTE: If the machine is switched off when Child Lock
is active, it will remain in Child Lock mode when
switched back on.
To Activate or Deactivate the Child Lock:
• Press and hold the “Temp.” and “Function” buttons
together at the same time for 3 seconds, whilst the
machine is operating.
• The machine will make an audible tone to let you know
that the Child Lock is activated or deactivated.
NOTE: At the completion of a wash program, the child lock
will become deactivated automatically.
19
User Manual
Washing Program Table
Program Load (kg) Default Temp (° C) Default Speed (RPM) Default Time
Steam Wash 4.5 40 1000 1:26
Cotton 9.0 40 1000 1:28
Synthetic 4.5 40 1000 1:25
Mix 9.0 40 1000 0:58
Jeans 9.0 40 800 1:40
ECO Wash 9.0 20 1000 0:59
20° C 4.5 20 1000 1:01
Spin 9.0 – 1000 0:12
Rinse & Spin 9.0 – 1000 0:20
Bulky Load 4.5 40 1000 1:48
Baby Care 9.0 60 1000 2:01
Wool 2.0 40 600 1:07
Sport Wear 9.0 20 800 0:47
Rapid 45’ 2.0 20 800 0:45
Quick 15’ 2.0 Cold 800 0:15
• Energy test program: ECO Wash, Temp: 60° C.
Speed: the highest speed; Other as the default.
Half load for 9.0kg machine: 4.5kg.
• “ECO Wash” is the standard washing programs to which the information in the
label and the fiche relates, and they are suitable to clean normally soiled cotton
laundry and that they are the most efficient programs in terms of combined
energy and water consumptions for washing that type of cotton laundry, that
the actual water temperature may differ from the declared cycle temperature.
NOTE: The parameters in this table are only for user’s
reference. The actual parameters may be different
with the parameters in above mentioned table.
20
User Manual
Cleaning Procedures
WARNING: Before beginning cleaning or maintenance,
always ensure the appliance is switched off,
the power plug is removed from the power
outlet and the water supply has been closed.
Cleaning the Washing Machine Exterior
• Proper maintenance of your washing machine will
keep it looking as new and extend its working life.
• The exterior surface can be cleaned with household
cleaners and a soft damp cleaning cloth.
• If there is any residual water at the completion of a
washing program, please use a cloth to wipe it off
immediately.
NOTE: Never use solvents or harsh cleaning chemicals on
your washing machine’s exterior.
Cleaning the Internal Drum
Should any rust form on the inside drum (i.e. water was
left to sit for an extended period of time), please remove
immediately using a chlorine free detergent. Never use
steel wool or a harsh abrasive.
NOTE: Never place laundry in the washing machine when
performing the Drum Clean program.
Cleaning the Door Seal and Glass
• Wipe the glass and seal after each wash to remove lint
and stains. If lint builds up it can cause leaks.
• Remove any coins, buttons and other foreign objects
from the seal after each wash.
Frozen Washing Machine
• Should the temperature drop below zero and your
washing machine becomes frozen, you should:
• Disconnect the power supply for the washing machine.
• Wash the tap connection with warm water, to help you
to disconnect the inlet pipe.
• Remove the inlet pipe and immerse in warm water
(i.e. within a bathtub).
• Pour some warm water into the washing machine
drum and wait for approximately 10 minutes.
• Reconnect the inlet pipe to the tap and washing
machine and open the water supply.
• Wait until the room’s ambient temperature returns to
above 0°C before operating the washing machine.
Cleaning the Detergent Drawer
• You should periodically follow these steps to ensure
the detergent drawer remains clean.
• Press down on the arrow, located on the cover for the
fabric softener compartment of the detergent drawer
and remove the drawer out of the recess.
• Clean the inside of the recess with a brush.
• Lift the softener cover off the dispenser drawer and
wash both items with water.
• Re-install the fabric softener compartment cover
into the detergent drawer, and push the drawer back
into position.
NOTE: Never use abrasive or caustic agents to clean
the plastic parts. Ensure you clean the detergent
dispenser every 3 months to ensure the normal
operation of the appliance.
Cleaning & Maintenance
21
User Manual
Cleaning the Inlet Filter
You should clean the inlet filter every 3 months, or if
you find that insufficient water is being supplied to your
washing machine when the supply tap is open.
To clean the inlet filter:
• Close the water supply tap and remove the water
supply hose from it.
• Clean the filter a brush.
• Unscrew the water supply hose from the rear of the
machine. Pull out the filter with long pliers.
• Use a brush to clean the filter.
• Reinstall the filter to the water inlet and reconnect
the water supply hose.
Cleaning the Drum Pump Filter
WARNING: To avoid the risk of an electric shock,
always remove the power plug from the power
outlet before cleaning the Drain Pump filter.
Periodically you should clean the drain pump filter to
ensure normal operation of your washing machine. The
type of washing, frequency and soil level of your washing
cycles will alter how often this procedure needs to be
undertaken, however you should inspect the filter regularly.
Should your washing machine not empty and/or spin, or
your machine makes unusual noises during operation, your
Drain Pump filter could be blocked. Follow this procedure
to check or remove any foreign objects.
• After disconnecting the power, open the filter cover at
the front base of your washing machine.
• Unscrew the filter in an anti-clockwise direction and
remove any foreign objects.
• Re-install the filter and close the service panel.
Leaking my occur if it is not re-installed correctly.
WARNING: Never remove the pump cover when the
washing machine is in operation, always
wait until the appliance has finished and the
is empty. There can be hot water within the
pump, so be careful to avoid burns, should it
have operated recently. When replacing the
cover, be careful to ensure it is closed securely.
22
User Manual
Troubleshooting
PROBLEM SOLUTION
Washing Machine Won’t Turn On • Check that the mains plug is inserted and switched on at the power point.
• Check that the door is closed securely or if there are clothes preventing it from closing.
• Check that the relevant fuse hasn’t blown.
• Check that the On/Off button has been pressed.
• Check that the water supply tap has been opened.
Door Won’t Open • The machine’s safety protection is in operation. Disconnect the power and reconnect the power.
Water is Leaking • The inlet pipe or outlet hose may not be tightened or blocked.
• Check and fasten all water connection pipes.
• Inlet or Outlet hoses may be damaged. Please check.
Detergent Residues Remain in
the Detergent Drawer
• Ensure you are using a correct amount of detergent.
• Follow the cleaning steps to remove any damp residual detergent from the drawer.
Display Isn’t Lighting Up • Check that the power isn’t disconnected.
• PC board may have issues. Please contact our customer service team.
Washing Results Aren’t
to Expectations
• Ensure you are using a sufficient amount of detergent.
• Ensure the correct quantity of clothes are being used depending on the wash program selected.
• Ensure you are using the correct wash program to suit the clothing and level of dirtiness.
• Try using an alternative detergent.
Washing Machine is Making An
Abnormal Noise or Vibrating
• Ensure the washing machine is level.
• Ensure that all transportation bolts have been removed.
• Ensure the appliance has been installed on a solid and level floor.
• Ensure that all legs are making contact with the floor and adjust as required.
• Follow the Drain Pump cleaning procedure and ensure there are no foreign objects.
If the above steps don’t resolve your issue or you cannot resolve the fault by yourself, press the “On/Off” button.
Switch off the appliance at the power outlet and remove the plug, and call our customer service team.
Before contacting our customer service team, please refer to the table below to see if your fault can be fixed by yourself.
Should a service technician be arranged and it's found there are no faults with the appliance, a call out charge will apply.
WARNING: Only authorised technicians can carry out repairs to your appliance.
INDICATION PROBLEM SOLUTION
E30 Door is not closed properly
• Restart after the door is closed
• Check if there are clothes or washing articles stuck
E10
Water injecting problem
while washing
• Check if the water pressure is too low
• Straighten the water pipe
• Check if the inlet valve filter is blocked
E21 Overtime water draining • Check if the drain hose is blocked
E12 Water overflow • Restart the washer
23
User Manual
Technical Specifications
Model GGSFLW900B
Washing Capacity 9.0kg
Dimensions (W × D × H mm) 595 × 535 × 850 mm
Net Weight 61kg
Rated Power 2000W
Power Supply 220-240V, ~50Hz, 10Amp
Standard Water Pressure 0.05MPa~1.0MPa
GGSFLW900B Testing Methods
ADDITIONAL INFORMATION FOR Standard performance TESTING:
(AS/NZS 2040.1:2005+Amdt1-2007+Amdt2-2009)
• Water Connections: Cold & hot water connection
• Water Supply Pressure: 320 kPa
• Warm Wash Program: ECO Wash, 60°C, Spin 1400 RPM, Display: 6:56
Cold Wash Program: Cotton Cold (no temperature display is cold wash)
• Detergent Type: Drum detergent
• Detergent Quantity: Default
• Adding Detergent:
The detergent is dissolved and added as Paragraph B7.3 of AS/NZS
2040.1 The detergent shall be dissolved in 1 L of water
• Anti-sudsing Agent: Max
• Test Load Mass: 9.0kg
• Water Consumption: 91L
• Test Voltage: 220-240V~,50Hz
24
User Manual
For future reference, please record the following information which can be found
on the rating plate and the date of purchase which can be found on your sales invoice.
STORE DETAILS
STORE NAME
|
ADDRESS
|
TELEPHONE
|
PURCHASE DATE
|
PRODUCT DETAILS
MODEL NO.
|
SERIAL NO.*
|
Purchase Details
Attach Your Receipt Here
25
User Manual
Notes
26
User Manual
WARRANTY TERMS AND CONDITIONS
LAUNDRY APPLIANCES
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of
this warranty has the same meaning referred to in
the ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian
Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Burnley VIC 3121, ACN 600 546 656 in
respect of Appliances purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10 of this warranty
has the same meaning referred to in the ACL and
includes a situation when an Appliance cannot be
repaired or it is uneconomic for Residentia Group, at its
discretion, to repair an Appliance during the Warranty
Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal, domestic
or household use (i.e. normal single family use) as
set out in the instruction manual, the Appliance is
warranted against manufacturing defects for 24
months, following the date of original purchase of
the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having
purchased the Appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. This warranty only applies to Appliances purchased and
used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or its
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment and
subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Residentia
Group or its ASR may use remanufactured parts to repair
your Appliance. You agree that any replaced Appliances
or parts become the property of Residentia Group. This
warranty does not apply to light globes, batteries, seals,
lters or similar perishable parts.
4. Parts and Appliances not supplied by Residentia Group
are not covered by this warranty.
Warranty Information
27
User Manual
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia Group
or its ASR. If you reside outside of the service area, you
will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance to and from
Residentia Group or its ASR, in all instances, unless the
Appliance is transported by Residentia Group or its ASR,
the Appliance is transported at the owner’s cost and risk
while in transit to and from Residentia Group or its ASR.
6. Proof of purchase is required before you can make
a claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to properly
maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm damage or incorrect
power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional instructions
supplied with the Appliance;
(b) the Appliance is modied without authority from
Residentia Group in writing;
(c) the Appliance’s serial number or warranty seal has been
removed or defaced;
(d) the Appliance was serviced or repaired by anyone other
than Residentia Group, an authorised repairer
or ASR.
8. This warranty, the contract to which it relates and the
relationship between you and Residentia Group are
governed by the law applicable where the Appliance was
purchased.
9. To the extent permitted by law, Residentia Group
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising from
your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the Appliance
repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a
major failure. The benets to you given by this warranty
are in addition to your other rights and remedies under a
law in relation to the Appliances or services to which the
warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether repair,
replacement or refund will apply if an Appliance has a
valid warranty claim applicable to it.
12. Missing parts are not covered by warranty.
Residentia Group reserves the right to assess each
request for missing parts in a case by case basis.
Any parts that are not reported missing in the rst week
after purchase will not provide free of charge.
13. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user manual
and the terms of this warranty;
(b) have the model and serial number of the Appliance
available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty claim, Residentia
Group and its ASR may exchange information in relation
to you to enable Residentia Group to meet its obligations
under this warranty.
IMPORTANT
Before calling for service, please ensure that the steps
in point 13 have been followed.
CONTACT SERVICE
→ Please call 1300 11 HELP (4357)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
The Australian Consumer Law requires the
inclusion of the following statement with
this warranty:
T. 1300 11 4357
E. support@residentiagroup.com.au
E S S E N T I A L S FOR LIFE
www.solt.house
An initiative by
Residentia Group
