Please read these operating instructions before using the unit
and save them for future reference.
Introduction
This is a multifunctional Wireless BT speaker with professional-quality for meetings
at home, in oce or on-the-go. You can use it as a basic Wireless BT speaker too.
If you want to have a better experience, please read this instruction carefully.
Important:
Your speakerphone is shipped from the factory in a deep sleep mode to conserve
battery. Activate your speakerphone by connecting the USB cable to a power
source before rst use.
What's in the Box:
• Conference Speakerphone
• Protective Carrying Case
• USB-C Data Cable
• 3.5mm Aux Cable
At a Glance
1. Phone call button
2. Volume down
3. Power button
4. Mute button
5. Volume up
6. Pause/Play
7. Status LED
8. USB port (type-C) for charging
9. Audio Input port
www.PyleUSA.com
3
Connecting
a. Connect to your computer by using a USB-C data cable.
b. Connect to your computer or mobile device via Wireless BT pairing.
Power ON this product for the rst time, it will automatically enter the Wireless
BT pairing mode.
Note: in our sample, usually the Wireless BT pairing name is PYLE Conference
Speaker
Conference Speakerphone
Flashes blue quickly Enter Wireless BT pairing mode
Flashes blue every 5 seconds Wireless BT paired
www.PyleUSA.com
4
Each time you power on the product, it will automatically connect with the
last successfully connected device if available.
Powering ON/OFF
Press and hold the power button for 2 seconds to power ON. The status LED will
light on counterclockwise and then fade out. To power OFF, press and hold the
power button for 2 seconds.
Power LED behavior
•
Once connected to your computer, it will automatically power ON.
• It will automatically power o after 4 minutes of inactivity when the Wireless BT
is not paired.
Button Controls
Flashes light purple slowly and
turns blue and ashes quickly
in circles
Power ON
Flashes red in circles
and light o
Power OFF
Press to increase and decrease Volume
Press to Answer/End a call
Press and hold for 2 seconds to reject a call
Press to Mute or restore the microphone
Press to Play/Pause music
www.PyleUSA.com
5
Status LED behaviors
• Steady purple: USB connected to computer
• No LED Flash but a “beep”: Incoming call
• Lights up light purple counterclockwise or counterclockwise:
Increase or decrease volume
• Steady red: Muted
• Lights up red: Press Power button to check the battery level
• Steady blue: Aux connected
• Flashes blue every 5 seconds: Wireless BT paired
Charging
Power LED behavior
• Steady purple: Being charged
• Light o: Fully charged
• Flashes red: Low battery
Audio Input
Connect an external audio source to the AUX jack of this product by using an
AUX cable (included). The audio will be played through the speakerphone.
Wireless BT Streaming:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: V5.1
• Wireless BT Pair Name: “PYLE Conference Speaker“
• Wireless Range: Up to 32’ ft
www.PyleUSA.com
6
Features:
• Easy to use with Dedicated Answer/End, Volume Control, and mute buttons
• Compatible with Windows Microsoft Team
• HD Voice for conversations in High-Denition sound quality,
• Supports USB TO Mobile/PC, AUX TO Mobile/PC, and Bluetooth TO Mobile/ PC
• Optimizes the Voices on the other End to Enable To Hear Clearer
• Powered by Qualcomm Bluetooth A2DP Technology for Crystal Sound
• Universal Compatibility, Services such as Skype, Zoom, Microsoft Teams, WebEx, etc.
• Private Acoustic Algorithm "SWISS" to Provide a Truly Wireless Immersive
Sound System
Technical Specs:
• Microphone: Omni-directional MIC (3PCS)
• Microphone Sensitivity: -27dB;
• Microphone Distortion: ≤3%;
• Microphone SNR:70dB;
• Microphone Coverage: 10 meters ( 33 feet);
• Microphone Frequency Response: 100Hz-7.5KHz;
• Talk Time: Up to 12 hours
• Music streaming: Up to 10 hours
• Rechargeable Lithium-ion Battery: 2600mAh
• Charging Time: 3 hours
• Speaker: Φ 2.05'' x 0.91'' -inches, 4 Ω , 3 Watts;
• Speakerphone Dimensions: 5.12'' x 1.4'' -inches
www.PyleUSA.com
7
12-Hour Call Time (under max volume)
2600mAh battery powers meeting in wireless mode
