BINOCULAR PARTS
Figure 1.
Encounter
16x70mm
Binocular Telescope
Operating Instructions
WARNING!
NEVER LOOK DIRECTLY AT THE SUN
THROUGH YOUR BINOCULARS WITHOUT
PROFESSIONALLY MADE SOLAR
FILTERS, EVEN FOR AN INSTANT
OR PERMANENT EYE DAMAGE
COULD RESULT. YOUNG CHILDREN
SHOULD USE THESE BINOCULARS
ON SUNNY DAYS ONLY WITH
ADULT SUPERVISION.
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
www.barska.com
Telescope. Please carefully read the following instructions. With proper c
this instrument, you will be assured of many years of enjoyable viewing.
Congratulations on your purchase of a BARSKA Encounter 16x70mm Binocular
Removeable
Carry Handle
Mounting Plate
(Not visible)
Lens Shades (Retracted)
Diopter Scale
Eyepiece Holder
Focus Ring Grip
IP Knob (Not visible)
Eyepiece
are and use of
Hard Storage Case
Encounter 16x70mm Binocular
Telescope Operating Instructions
2.
BARSKA Model AF10738
Professional Photo Tripod
www.barska.com
Figure 4.
ENCOUNTER - BREATHTAKING VIEWS
OF THE NIGHT SKY AND THE WORLD
AROUND YOU.
The large optical system of the BARSKA
Encounter Binocular Telescope provides the
amount of light gathering that is necesssary
for astronomical observation and , unlike a
conventional telescope, allows you to use
both eyes simultaneously for viewing. As a
result, you have better image resolution,
contrast and brightness than a similar size
telescope.
The 90-degree eyepiece viewing
angle makes observing at night more
comfortable and convenient. With proper
care, the rugged body construction and
waterproof design of this inst
rument will
ensure years of enjoyable viewing.
Important: P
lease read the following
instructions carefully.
2. INSERTING THE EYEPIECES
To install the included eyepieces:
1. Remove the cover caps from the
binoculars and eyepieces.
2. Insert the eyepieces into the binocular's
eyepiece holders.
3. Gently push the eyepieces
down into the holders until
they are fully seated (Fig.2).
4. T
o remove the eyepieces,
carefully pull the eyepieces
from the holders.
3. EXTENDING THE LENS SHADES
The extendable lens shades help to increase
contr
ast by preventing unwanted glare from
entering the objective lenses. They also slow
the formation of dew or moisture on the
objective lens exterior surface.
To extend the lens shades:
1. Grasp lens shade with
your fingers.
2. Carefully pull lens shade
outwards (Fig.3).
4. ADJUSTING THE EYEPIECE
DISTANCE BETWEEN YOUR
EYES (INTERPUPILLARY DISTANCE)
T
o adjust the interpupillary (IP) distance:
1. Turn the chrome IP knob located between
the eyepieces.
2. Rotate the knob until the distance between
the eyepieces matches the distance
between your eyes.
3. When properly
adjusted, y
ou should
see a single round
field of view when
looking through
the eyepieces.
4. Important: Make this adjustment
BEFORE you attempt to focus the
binoculars.
1. USING A TRIPOD
W
hen observing with a large aperture
binocular like the Encounter, a sturdy photo
tripod such as the
BARSKA AF10738 or
an altazimuth mount
is required. T
o attach
the Encounter to a
photo tripod, simply
thread the tripod's
1/4"-20 mounting
stud into the threaded
hole in the Encounter's
mounting plate.
T
o attach the binocular
to an altazimuth mount,
that utilizes a dovetail holder, an optional
dovetail L-Bracket (available from a camera
or telescope dealer) is required. The
L-B
racket connects to the Encounter's
mounting plate and has a dovetail bar that
goes directly into the mount's dovetail
holder.
Figure 2.
Figure 3.
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
3.
www.barska.com
Figure 5.
Diopter Scale
Figure 6.
5. FOCUSING THE ENCOUNTER
BINOCULAR TELESCOPE
The BARSKA Encounter Binocular Telescope
eyepieces can be individually focused and
help maintain optical alignment (Fig.5).
T
o focus the binocular:
1. During daylight, pick
a stationary distant
object to view such
as a street sign. At
night, the best focus
will be achieved by
focusing on the Moon or a bright star.
2. Cover your right eye (or cover the right
objective lens of the binocular) and focus
the left eyepiece by slowly rotating the
rubber grip ring on the eyepiece holder
until the image appears clearest. To focus
the right eyepiece, repeat this procedure
but cover your left eye or the left
objective lens of the binocular. The
binocular should now be in focus.
3. If y
ou want to view an object at a
different distance, re-focusing of both
eyepieces is required.
4. Changing the eyepieces may also require
some slight focus adjustments.
Astronomical Observation:
All
objects will always appear focused at the
infinity focus point. This means that you only
need to focus the binoculars once per
viewing session. This also means that you
can take note of the diopter scale setting for
each eyepiece when
focused on an
astronomical object and
return to those settings
when observing another
night (Fig.6). Since
ev
eryone's eyes focus
on images slightly
differently, other observers who are using
the binoculars will need to re-focus the
binoculars and adjust them to their own
vision and interpupillary distance.
6. FOLD-DOWN EYEGUARDS
The Encounter Binocular Telescope features
fold-down eyeguards on the eyepieces.
The eyeguards are usually left
in the up position for use
without ey
eglasses as this
helps prevent glare from
entering between the eye
and eyepiece.
To use the binoculars with eyeglasses:
1. Fold the eyeguards down in order to get
your eyes close enough to the eyepieces
to see the entire f
ield of view.
7. CLEANING AND CARE OF BINOCULAR
T
o protect your binocular, please follow these
important instructions:
Outside Surface
1. The Encounter Binocular Telescope is
nitrogen-purged and sealed to be
waterproof and internally fogproof.
However, DO NOT immerse the binocular
in water under any circumstances.
2. If the binocular becomes wet with fresh
water, blot it dry with a clean dry cloth.
3. If the binocular becomes wet with salt
water, the surface should be rinsed off
completely and the binocular blotted dry
with a clean cloth.
4. If the binocular body becomes dirty, it
can be cleaned with warm water and a dry
cloth.
5. If extremely dirty or oily, clean the body
with a dilute solution of warm water and
mild soap on a cloth, then rinse with clean
water and blot dry.
Lens Surface
The lens surfaces of the Encounter Binocular
Telescope are coated with anti-reflection
multi-coatings than can be easily damaged
with careless handling. To protect the
binocular's lenses, please follow these
recommendations:
1. DO NOT CLEAN LENS SURFACE WITH
SOAP AND WATER!
Figure 7.
Encounter 16x70mm Binocular
Telescope Operating Instructions
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
4.
www.barska.com
2. Avoid touching the lens surface with
fingers or any coarse material.
3. All optics, even if stored, should be
cleaned at least once per year or
whenever they become dirty.
4. Avoid over-cleaning as this can also
damage the lens coatings.
5. Alw
ays use lens cleaning tissue and lens
cleaning fluid that are specifically
designed for multicoated lenses.
6. DO NOT use fluids or tissues that are for
eyeglasses or household use.
7. DO NOT attempt to disassemble the
binocular or eyepieces in order to clean
them. This could result in damage to the
binocular and void the Warranty.
Cleaning The Lenses
1. Blow off the lens with a blower bulb or
gently wipe the lens with a lens cleaning
brush to remo
ve the larger dust particles.
2. Put a few drops of lens cleaning fluid on a
fresh piece of lens cleaning tissue (NEVER
apply directly on the lens surface) and
gently wipe the lens.
3. Quickly wipe the excess fluid with a new
dry piece of lens cleaning tissue.
4. On large lenses, clean only a small area
at a time using a new tissue each time.
5. On excessively dirty lenses, wipe across
the lens using one stroke per tissue,
alternating wet and dry.
6. To avoid scratching the lens surface,
always avoid excessive pressure or
rubbing when wiping.
Storing and Transporting the Binocular
1. Always keep the binoculars in their
storage case with the cover caps on when
not in use.
2. To prevent the optics from becoming
misaligned, avoid unnecessary shocks to
the binocular whether it is in the storage
case or not. This is not covered by the
Warranty.
3. A metal carry handle is supplied with the
binocular
. This handle connects to the
dovetail holder on the binoculars which is
located in front of the eyepieces (Fig.8).
4. Slide the handle's base into the do
vetail
holder and secure it in place by tightening
the thumbscrew.
5. Use the handle to lift the
binocular when mounting
to a tripod.
6. R
emove the handle
before placing the
binocular into its
storage case.
Important Note:
Allow the optics to slowly adjust to cold
weather by storing the binocular in its case
in a cold area such as an unheated garage,
unheated basement, or the trunk of a car for
a few hours before use. When bringing the
binoculars back inside a warm house, open
up the case, remove the binoculars, remove
the cover caps and allow everything to dry
out. The binoculars should be stored in a
cool, dry place to prevent mold growth which
can damage the optics. This is not covered
by the Warranty.
Figure 8.
SPECIFICATIONS
o
o
Encounter 16x70mm Binocular
Telescope Operating Instructions
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
©2023 BARSKA
®
5/23BC771
3 YEAR LIMITED WARRANTY
BINOCULARS / RIFLESCOPES / SPOTTING SCOPES
BARSKA | Pomona, CA 91767 | Tel: 888.666.6769 | Fax: 909.445.8169
www.barska.com
BC775
5.
BARSKA warrants this new precision optical product to be free of defects in
material and/ or workmanship under normal use for a period of 3 years from the
date product is purchased. This limited warranty is delimited to repair or
replacement only. This warranty does not include damage caused by improper
use or maintenance. BARSKA disclaims all liabilities for incidental or
consequential damages such as misuse, abuse, accident (such as dropping),
flood, service or repairs other than those performed by BARSKA, acts of nature,
or arising out of any breach of this warranty. Altering the product under any
circumstances will automatically void the warranty.
This warranty DOES NOT COVER ANY ACCESSORIES. Loss of the product or
lens caps/covers, eyepieces, cases/pouches, or straps are not covered. Product
normal wear and tear are not covered and the determination of such is at the
sole discretion of BARSKA.
For service under this limited warranty, please have available the proof of
purchase and the purchase date and location as well as a detailed description of
the problem. This warranty is not transferable and only applies to the original
purchaser with a proof of purchase from BARSKA or from an authorized dealer.
This warranty applies only to products purchased within the United States,
excludes Alaska, the Hawaiian Islands and all U.S. territories in the Caribbean
and the Pacific.
BARSKA will examine and go through troubleshooting procedures, product
repair or replacement of defective part(s) or units with new part(s) or provide a
new unit if necessary during the warranty period. Shipping/handling charges
may apply and are at Baraka’s sole discretion. Purchaser shall be required to
prepay Shipping/handling charges with a check or money order to BARSKA at
time product is returned. The Return Merchandise Authorization Number
(RMA#) and shipping/handling charge MUST be obtained from BARSKA in
advance of return. BARSKA shall not be liable for damages or loss occurring
during shipping. Please visit via www.barska.com or call 909.445.8168 for more
information.
BARSKA reserves the right to modify or discontinue, without prior notice to the
purchaser, any model or style of the product. BARSKA will determine, at its sole
discretion, whether a product will be repaired or replaced. BARSKA reserves the
right to discontinue or change any feature of its products at any time. If an exact
replacement or product is not available, BARSKA reserves the right to provide a
part or product that matches as closely as possible.
LIMITATION OF REMEDIES
BARSKA disclaims any warranties, express or implied, whether of
merchantability of fitness for a particular use, except as expressly set forth
herein. The sole obligation of BARSKA under
this limited warranty shall be to
repair or replace the covered product, in accordance with the terms set forth
herein. BARSKA expressly disclaims any lost profits, general, special, indirect or
consequential damages which may result from breach of any warranty, or
arising out of the use or inability to use any BARSKA product. Any warranties
which are implied and which cannot be disclaimed shall be limited in duration to
a term of three year from the date of original retail purchase. Some states do not
allow the exclusion or limitation of incidental or consequential damages or
limitation on how long an implied warranty lasts, so the above limitations and
exclusions may not apply to you.
BARSKA 855 Towne Center Drive, Pomona, CA 91767
