en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
INFORMATION FOR USE
1 Safety ........................................................................ 2
2 Basic operation of the appliance ........................... 4
3 Eliminating faults .................................................... 6
4 Customer Service .................................................... 7
5 Environmental protection and saving energy ..... 7
6 INSTALLATION INSTRUCTIONS ........................... 7
6.1 General information ............................................. 7
6.2 Safe installation ................................................... 8
7 Access to the full version of the user manual ... 10
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instructions, the appliance and the
product information safe for future reference
or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
The appliance can only be used safely if it is
correctly installed according to the safety in-
structions. The installer is responsible for en-
suring that the appliance works perfectly at its
installation location.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ in private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of 4000m above sea level.
Do not use the appliance:
¡ With an external timer or a separate remote
control. This does not apply if operation with
appliances included in EN 50615 is
switched off.
If you wear an active implantable medical
device (e.g. a pacemaker or defibrillator),
check with your doctor that it complies with
Council Directive 90/385/EEC of 20th June
1990, EN 45502-2-1 and EN 45502-2-2, and
that it has been chosen, implanted and pro-
grammed in accordance with VDE-AR-E
2750-10. If these conditions are satisfied, and
if, in addition, non-metal cooking utensils and
cookware with non-metal handles are used, it
is safe to use this induction hob as intended.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
Never leave hot oil or fat unattended.
Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The cooking surface becomes very hot.
Never place flammable objects on the cook-
ing surface or in its immediate vicinity.
Never place objects on the cooking surface.
2
Safety en
The appliance will become hot.
Do not keep combustible objects or aerosol
cans in drawers directly underneath the hob.
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
Do not use hob covers.
After every use, switch off the hob using the
main switch.
Do not wait until the hob turns off automatic-
ally as there are no longer any pots and
pans on it.
Food may catch fire.
The cooking process must be monitored. A
short process must be monitored continu-
ously.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use, particularly
the hob surround, if fitted.
Caution should be exercised here in order to
avoid touching heating elements.
Young children under 8 years of age must
be kept away from the appliance.
Hob guards may cause accidents.
Never use hob guards.
The appliance becomes hot during operation.
Allow the appliance to cool down before
cleaning.
Metal objects on the hob quickly become very
hot.
Never place metal objects (such as knives,
forks, spoons and lids) on the hob.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord or the appliance power
cable of this appliance is damaged, it must
be replaced with a special power cord or
special appliance power cable, which is
available from the manufacturer or its Cus-
tomer Service.
If the power cord of this appliance is dam-
aged, it must be replaced by trained special-
ist staff.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
If the surface is cracked, you must switch off
the appliance in order to prevent a possible
electrical shock. To do this, switch off the
appliance via the fuse in the fuse box rather
than at the main switch.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cable is dam-
aged, immediately switch off the fuse in the
fuse box.
Call customer service.
Page7
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
The insulation on cables of electrical appli-
ances may melt if it touches hot parts of the
appliance.
Never bring electrical appliance cables into
contact with hot parts of the appliance.
If metallic objects come into contact with the
fan that is located on the underside of the hob,
this may cause an electric shock.
Do not store long, pointed metallic objects in
the drawers below the hob.
WARNING‒Risk of injury!
Saucepans may suddenly jump due to liquid
between the saucepan base and the hotplate.
Always keep hotplates and saucepan bases
dry.
Never use icy-cold cookware that has been
in the freezer.
When cooking in a bain marie, the hob and
cooking container could shatter due to over-
heating.
The cooking container in the bain marie
must not directly touch the bottom of the wa-
ter-filled pot.
Only use heat-resistant cookware.
An appliance with a cracked or broken surface
can cause cuts.
Do not use the appliance if it has a cracked
or broken surface.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
3
en Basic operation of the appliance
Do not let children play with small parts.
Basic operation of the appliance2 Basic operation of the appliance
2.1 Distribution of the cooking zones
The specified power has been measured with the standard pots, which are described in IEC/EN 60335-2-6. The
power may vary depending on the size of the cookware or cookware material.
B
A
A
C
Area Highest power level
14.5 cm dia-
meter
Power level 9 1400W
18cm dia-
meter
Power level 9
PowerBoost
1800W
3100W
18cm dia-
meter
Power level 9 1800W
2.2 Control panel
Individual details, such as colour and shape, may differ
from the figure.
Selection sensors
Sensor Function
Main switch
Selecting the cooking zone
/ Adjustment fields/Childproof lock
PowerBoost
Displays
Display Function
- Power levels
Display Function
Residual heat
PowerBoost
Childproof lock
2.3 Basic operation
Switching the hob on and off
Switch the hob on and off using the main switch .
If all of the cooking zones are switched off for longer
than 20seconds, the hob is automatically switched
off.
Selecting the cooking zone and power level
1.
Touch to select the cooking zone.
2.
Press or within the next 10 seconds.
Touch . The power level is displayed.
Touch . The power level is displayed.
The minimum power level is and the maximum
power level is .
The cooking zone switches itself off and the residual
heat indicator lights up.
Switching off the cooking zone quickly
Press and hold the cooking zone for longer than
threeseconds.
The cooking zone is switched off.
Suitable cookware
The quality of the cookware affects the speed and the
result of the cooking process.
Cookware that is suitable for induction cooking must
have a ferromagnetic base, i.e. it is attracted to mag-
nets. Furthermore, the base must match the size of the
cooking zone. If an item of cookware is not detected on
a cooking zone, place this cookware on the next smal-
lest cooking zone.
2.4 Main functions
PowerBoost
This function allows larger volumes of water to be
heated more quickly than with the power level .
Childproof lock
The hob is equipped with a childproof lock. This pre-
vents children from switching on the hob.
To switch the function on, the hob must be switched off.
To switch on and off, press and hold and for four
seconds. If the childproof lock is switched on, the dis-
play lights up in all cooking zones.
4
Basic operation of the appliance en
Cookware test
You can use this function to test the quality of the cook-
ware. The quality of the cookware affects the speed and
the result of the cooking process.
Basic settings
You can configure the basic settings for your appliance
to meet your needs.
Additional information about the appliance
functions
You can find additional information about these func-
tions in the full version of the user manual. You can
call up the interactive format via the QR code below:
2.5 Cleaning the hob
Clean the hob after every use to prevent cooking
residues from getting burnt on.
Requirement: The hob must be cold. Do not allow the
hob to cool down if it has sugar stains, rice starch,
plastic or aluminium foil on it.
1.
Remove heavy soiling using a glass scraper.
2.
Clean the hob with a cleaning agent for glass
ceramic.
Follow the cleaning instructions on the packaging of
the cleaning product.
Tips
You can achieve good cleaning results using a
special sponge for glass ceramic.
If you keep the base of the cookware clean, the
hob surface remains in a good condition.
2.6 Cooking recommendations
The table shows which power level ( ) is suitable for which food. The cooking time ( ) may vary depending on
the type, weight, thickness and quality of the food.
Melting
Chocolate coating 1-1 -
Heating and keeping warm
Stew, e.g. lentil stew 1-2 -
Defrosting and heating
Spinach, frozen 2-4 15-25
Poaching, simmering
White sauces, e.g. Béchamel
sauce
1-2 3-6
Boiling, steaming, braising
Rice pudding
1
2-3 30-40
Pasta, noodles
2
6-7 6-10
Vegetables 2-3 10-20
Braising
Pot roast 4-5 50-100
Roasting/frying with a small
amount of fat
2
Steak, 3 cm thick 6-8 8-12
Hamburgers (2 cm thick) 5-7 10-20
Frozen dishes, e.g. stir-fries 6-8 6-10
Pancakes, cooked one after the
other
6-7 -
Fried eggs 4-5 3-6
Frying (150 to 200g per batch in 1
to 2l oil, deep-fried in batches)
2
Frozen products, e.g. chips,
chicken nuggets
8-9 -
Vegetables, mushrooms, breaded,
beer-battered or tempura
5-7 -
1
Preheat to power level 8
2
Without lid
5
en Eliminating faults
Eliminating faults3 Eliminating faults
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page7
3.1 Warnings
Notes
If appears in the displays, press and hold the
sensor for the respective cooking zone and read the
fault code.
If the fault code is not listed in the following table, dis-
connect the hob from the power supply and wait
30seconds before reconnecting it. If this display ap-
pears again, contact Customer Service and specify
the exact fault code.
If an error occurs, the appliance does not switch to
standby mode.
In order to protect the appliance's electronic parts
from overheating or surge currents, the hob may tem-
porarily reduce the power level.
3.2 Information on the display panel
Fault Cause and troubleshooting
No displays light up. The power supply has been disconnected.
Use other electrical appliances to check whether there has been a power fail-
ure.
The appliance has not been connected as shown in the circuit diagram.
Connect the appliance in accordance with the circuit diagram.
Electronics fault
If you are unable to rectify the fault, inform the technical after-sales service.
The displays flash. The control panel is wet or an object is covering it.
Dry the control panel or remove the object.
, , , , The electronics have overheated and one or all of the cooking zones have been
switched off.
Wait until the electronics have cooled down sufficiently. Then touch any button
on the control panel.
+ power level and audible sig-
nal
There is hot cookware in the vicinity of the control panel. This may cause the
electronics to overheat.
Remove the cookware. The fault display goes out shortly afterwards. You can
continue to cook.
and signal tone There is hot cookware in the vicinity of the control panel. The cooking zone has
been switched off to protect the electronics.
Remove the cookware. Wait a few seconds. Touch any button. When the fault
display goes out, you can continue cooking.
/ The cooking zone has overheated and has been switched off to protect the work
surface.
Wait until the electronics have cooled down sufficiently before switching the
cooking zone back on.
The cooking zone has been operating continuously for an extended period.
Individual safety switch-off is switched on. Touch any button to switch off the
display so that you can set the cooking zone.
/ The operating voltage is incorrect and outside of the normal operating range.
Contact your energy supplier.
/ The hob is not connected correctly.
Disconnect the hob from the mains. Connect the hob in accordance with the
circuit diagram.
Demo mode is activated.
Disconnect the hob from the mains. Wait for 30 seconds and connect the hob.
Touch any sensor in the next threeminutes. Demo mode is deactivated.
Childproof lock is activated.
Childproof lock deactivate
6
Customer Service en
3.3 Normal noises from your appliance
An induction hob may sometimes cause noises or vibra-
tions, such as buzzing, crackling, hissing noises, fan
noises or rhythmic noises.
Customer Service4 Customer Service
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note: Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number (FD)
of your appliance.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
You can find the information required as per Regula-
tions (EU) 66/2014 and (EU) 2023/826 online at
www.bosch-home.com
on the product and service
pages for your appliance, in the area of user manuals
and additional documents.
4.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
The rating plate can be found:
on the appliance certificate.
on the lower section of the hob.
The product number (E no.) can also be found on the
glass ceramic. You can also display the customer ser-
vice index (KI) and the production number (FD) in the
basic settings.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Environmental protection and saving energy5 Environmental protection and saving energy
5.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
5.2 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
Installation instructions6 Installation instructions
Observe this information when installing the appliance.
6.1 General information
¡ Read this instruction manual carefully.
¡ Only a licensed expert may connect the ap-
pliance.
¡ Improper installation, opening of the appli-
ance, connection or assembly may lead to a
loss of validity of the product warranty.
¡ Switch off the power supply before carrying
out any work.
¡ After installation, ensure that the user does
not have access to the electrical compon-
ents.
¡ Never use this appliance in boats or in
vehicles.
7
en Installation instructions
6.2 Safe installation
Follow these safety instructions when installing
the appliance.
The appliance can only be used safely if it is
correctly installed in accordance with the in-
stallation instructions. The installer is respons-
ible for ensuring that the appliance works per-
fectly at its installation location.
WARNING‒Danger: Magnetism!
The appliance contains permanent magnets.
They may affect electronic implants, e.g. pace-
makers or insulin pumps.
Persons with electronic implants must stand
at least 10cm away from the appliance.
WARNING‒Risk of injury!
Parts that are accessible during installation
may have sharp edges and may lead to cut-
ting injuries.
Wear protective gloves.
Chemicals may be dangerous. When handling
chemicals, you must observe the recommend-
ations of the chemical producers.
Wear personal protective equipment.
6.3 Instructions for the electrical connection
In order to safely connect the appliance to the electrical
system, observe the following instructions.
Only an authorised expert or a specially trained ser-
vice technician may connect the appliance. The per-
son must be approved in accordance with the local
regulations of the country and the electricity supply
company.
Connect the appliance to a fixed installation and set
up appropriate isolating switches in accordance with
the installation regulations.
The manufacturer shall assume no liability for mal-
functions or damage resulting from incorrect electrical
wiring.
Connection type
The appliance corresponds to protection class 1. You
should therefore only use the appliance with a pro-
tective earth connection.
6.4 Information on fitted units
You can only install the induction hob above drawers
or ovens with fan ventilation. Do not install refrigerat-
ors, dishwashers, non-ventilated ovens or washing
machines below the hob.
Ensure that the fitted unit is heat-resistant up to at
least 90°C.
Worktop
Follow the worktop manufacturer's recommendations.
Level, horizontal, stable.
The worktop into which you are fitting the appliance
must be able to withstand loads of approx. 60kg.
For thin worktops, use heat-resistant and moisture-
resistant reinforcement material.
Only check the evenness of the hob after it has been
installed.
Extractor hood
The clearance between the extractor hood and the
hob must correspond at least to the clearance spe-
cified in the installation instructions for the extractor
hood.
6.5 Preparing the fitted units
1.
Mark the unit cut-out in accordance with the installa-
tion diagram.
Ensure that the angle of the cut surface to the
worktop is 90°.
2.
After making the cut-outs, remove any shavings.
3.
Seal the cut surfaces with heat-resistant material.
Ventilation
To guarantee that the appliance works correctly, the hob
must be sufficiently ventilated. The ventilation in the
lower section of the appliance requires a sufficient sup-
ply of fresh air. Therefore, if required, adjust the units for
this purpose.
1.
Maintain a minimum clearance between the rear of
the unit and the kitchen wall.
8
Installation instructions en
2.
Ensure that an opening at the top of the rear of the
unit is unobstructed.
3.
If the clearance from the back wall of the unit is less
than 20mm, create an opening on the underside.
4.
Do not hermetically seal the lower base.
Note: If the appliance is installed in an island unit or in
another location that is not described here, guarantee
that the hob is ventilated appropriately.
Installation above a drawer
In order to guarantee good ventilation, the clearance
between the surface of the worktop and the upper
area of the drawer must be 65mm.
Installation above an oven
To ensure good ventilation, the clearance between
the top of the worktop and the surface of the oven
front must be 30mm and the minimum clearance
between the oven and hob must be 5mm.
If the clearance between the hob and the oven needs
to be increased, refer to the installation instructions
for the oven.
6.6 Inserting the hob
1.
Adjust the hob in the front section of the built-in niche.
2.
Insert the hob in the cut-out.
3.
Seal the tile joints on tiled work surfaces with silicone
rubber.
Note: Do not kink or trap the connection cable, and
keep it away from sharp edges and hot parts.
6.7 Connecting the appliance
Requirement: Observe the connection data on the rat-
ing plate.
9
en Access to the full version of the user manual
1.
Only connect as shown in the circuit diagram:
– BN: Brown
– BU: Blue
– GN/YE: Green and yellow
2.
Check that the appliance is ready for operation: If
, or appears on the appliance's display, the
appliance is not connected correctly. Disconnect the
appliance from the power supply and check the
power cord connection at the mains supply.
6.8 Special combinations
If you install the hob above an oven made by another
brand, use a wooden partition floor.
6.9 Removing the appliance
ATTENTION
Tools may damage the appliance.
Never prise out the appliance from above.
1.
Disconnect the appliance from the mains power sup-
ply.
2.
Push out the hob from below.
Access to the full version of the user manual7 Access to the full version of the user manual
The condensed version of the user manual in a physical
format significantly improves environmental protection.
To call up the full version of the user manual, scan the
QR code below. Here you can find detailed information
on the following aspects in an interactive format:
Appliance functions
Basic settings
Cooking recommendations
Cookware test
Cleaning and maintenance
Environmental protection and saving energy
10
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9001997305*
9001997305 (050404) REG25
en
