INSTALLATION INSTRUCTION SHEET
Installation Instructions:
1. Remove the mounting bracket from the body by loosening the setscrew.
2. Position the assembled unit on the wall where desired.
3. Lightly mark the outline of each base.
4. Center a mounting bracket within each base outline
.
5. Mark the 2 horizontal mounting hole locations of the mounting bracket.
6. Attach each mounting bracket to the wall, using the wall anchors provided
7. Mount each base on the corresponding mounting bracket. Check and make sure that the base set screw hole(s)
are facing down. Assemble a set screw to each base. Use the allen wrench included in hardware kit to tighten
each set screw and secure the assembly to the mounting bracket(s).
Cleaning Instructions:
To preserve the
finish of this produ
ct, clean with a soft, damp cloth. Dry well. Do not use commercial or abrasive
cleansers.
1.
.
2.
3.
4. Centrer un support de montage dans chaque contour de base.
5.
6. Fixer chaque support de montage sur le mur en utilisant les vis de support de montage avec les chevilles
murales en optionnelles fournies.
7.
montage.
Directives de nettoyage :
de ce produit, nettoyer avec un chiffon propre, doux et humide. Bien essuyer. Ne pas utiliser de
produits nettoyants commerciaux ou abrasifs.
1. Retire los soportes de montaje d
2. Coloque la unidad armada contra la pared en el lugar elegido.
3. Marque ligeramente el contorno de cada base.
4.
5. Marque la ubic
6.
7.
fijac
Instrucciones para la limpieza:
limpiadores ni abrasivos comerciales.
