EN Operator’s Manual
Clear Water Submersible Pump /
Dirty Water Submersible Pump
EN
A1
2
1
O1
>
3
A2
<
y
2
A3
Art. 7193
O2
3
>
A4
Art. 7195
y
A5
<
T1
6
5
4
4
3
1. SAFETY ...................................11
2. ASSEMBLY ................................12
3. OPERATION ................................13
4. MAINTENANCE .............................14
5. STORAGE .................................14
6. TROUBLESHOOTING ........................14
7. TECHNICAL DATA ...........................15
8. ACCESSORIES .............................15
9. SERVICE / WARRANTY ........................16
Original instructions.
This product may be used under
supervision, or if instruction
regarding the safe use of the product has
been provided and the resulting dangers
have been understood, by children aged
8and above, as well as by persons with
physical, sensory or mental disabilities or
a lack of experience and knowledge. Chil-
dren must not be allowed to play with the
product. Cleaning and user maintenance
must not be performed by children with-
out supervision. The use of this product by
young people under the age of 16 is not
recommended. Never operate the product
when you are tired, ill or under the influ-
ence of alcohol, drugs or medicine.
Intended use:
The GARDENA Submersible Pump is intended for drain-
age purposes if flooding occurs but also for transferring
water to and from tanks and pumping them out, for draw-
ing water from wells and shafts, for draining boats and
yachts and for aerating and circulating water for limited peri-
ods and for pumping chlorinated water in private domestic
gardens and allotments.
Liquids to be pumped:
The GARDENA Submersible Pump must only be used to
pump water.
The pump is fully submersible (water-tight encapsulation)
and is submerged in water (for max. submersion depth,
see 7. TECHNICAL DATA).
The product is suitable for pumping the following liquids:
• Clear Water Submersible Pump: clean to slightly dirty
water with amax. particle size of 5 mm.
• Dirty Water Submersible Pump: dirty water with a
max. particle size of 25 mm.
The product is not intended for long term use (continuous
circulation operation).
DANGER! Risk of injury!
v The pump should not be used for the delivery
of salt water, corrosive, easily inflammable or
explosive liquids (e. g. petrol, paraffin, thinners),
oil, heating oil or foodstuffs.
1. SAFETY
IMPORTANT!
Read the operator’s manual carefully before use
and keep for future reference.
Symbols on the product:
Read operator’s manual.
General safety warnings
Electrical safety
DANGER! Electric shock!
Risk of injury due to electric current.
v The product must be supplied through a residual
current device (RCD) having a rated residual
operating current not exceeding 30 mA.
DANGER! Risk of physical injury!
Risk of injury due to electric current.
v Disconnect the product from the mains before
you maintain or replace parts. Thereby the dis-
connected socket must be in the visual range.
Safe operating practices
The water temperature should not exceed 35 °C.
The pump must not be used when people are in the
water.
Pollution of the liquid could occur due to leakage of
lubricants.
Keep bystanders away from the water.
Operate the pump only with the elbow connector.
GARDENA Clear Water Submersible Pump /
Dirty Water Submersible Pump
EN
11
Circuit breaker
Thermal protection switch:
In the event of an overload, the pump is switched off by
the built-in thermal motor protection. After sufficient cool-
ing of the motor, the pump is operational again.
Automatic venting
This pump is equipped with a vent valve which eliminates
any air pockets in the pump. Depending on the function,
a small amount of water can escape from the side of the
housing.
Additional safety warnings
Electrical safety
DANGER! Cardiac arrest!
This product makes an electromagnetic field while
it operates. This field may under some conditions
interfere with active or passive medical implants.
To decrease the risk of conditions that can possibly
injure or kill, we recommend persons with medical
implants to speak with their physician and the medi-
cal implant manufacturer before you operate the
product.
Cables
If extension cables are used, these must comply with the
minimum cross- sections in the table below:
Voltage Cable length Cross section
230 – 240 V / 50 Hz Up to 20 m 1.5 mm
2
230 – 240 V / 50 Hz 20 – 50 m 2.5 mm
2
DANGER! Electric shock!
With a cut off mains plug, moisture can get into
electrical parts via the mains cable and cause
ashort circuit.
v Never cut the mains plug off (e. g. to feed through
wall).
v Don’t use the power cable for plugging off.
v If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Mains plug and extension connections must be protected
from water splashes.
Ensure that the electrical connections for plugs and sock-
ets are made in areas safe from flooding.
Protect the mains plug and the mains power cable from
heat, oil and sharp edges.
Observe the mains voltage. The information on the name-
plate must be in agreement with the data for the mains
power grid.
The pump’s mains plug must be disconnected before
anybody enters the swimming pool or touches the surface
of the water.
The mains power cable must not be used for fastening or
transporting the pump.
For submerging or lifting / securing the pump, please use
a fastening rope.
Please regularly check the connecting line.
Before using, always subject the pump (especially the
power cables and the power connections) to a visual
inspection.
A pump which is damaged should not be used. In the
event of damage, have the pump checked by GARDENA
Service.
Assembly instructions: Retighten all screws by hand.
Before use after maintenance, make sure that all parts are
screwed together.
When using our pumps with a generator, the warnings of
the generator manufacturer must be observed.
Personal safety
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There is also
arisk that the polybagcan suffocate toddlers. Keep
toddlers away when you assemble the product.
Observe the minimum water level in accordance with the
characteristics given for the pump.
Allow the pump to run no longer than 10 minutes against
a closed pressure side.
Sand and other abrasive substances cause increased
wear and reduce the pump’s output.
The float switch may only be operated outside the water.
The hose must not be disconnected during operation.
Allow the pump to cool down before troubleshooting.
The pump must not be operated without the mounted
contra-angle handpiece.
2. ASSEMBLY
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before
you assemble the product.
To screw the elbow connector into the pump
[ Fig. A1 ]:
DANGER! Risk of injury!
Cut Injury by the impeller.
v Operate the pump only with the elbow
connector.
EN
12
v Screw the elbow connector
1
clockwise into the pump.
The hose can be connected via the pump connection
1
and the con nection nipple
2
[25 mm (1") and
38 mm (11/2")] or via the GARDENA Connection System
[13 mm (1/2") / 16 mm (5/8") / 19 mm (3/4")]. When using
a 38 mm (1 1/2") hose, the pump has the maximum
delivery capacity.
Connect hose via connection nipple
[ Fig. A2 / A3 / A4 ]:
25 mm (1")- and 38 mm (1 1/2")-hoses can be connected
via the connection nipple
2
.
Hose diameter 25 mm (1") 38 mm (1 1/2")
GARDENA Hose Clamp Art. 7193 Art. 7195
Hose connection
[ Fig. A2 ]
Do not detach
nipple
[ Fig. A3 ].
Detach nipple
at
y
[ Fig. A4 ].
25 mm (1")- and 38 mm (1 1/2") hoses connected with
aconnection nipple
2
must be fastened, for example
with a GARDENA Hose Clamp Art. 7193 / 7195.
1. Screw the elbow connector into the pump.
2. Screw connection nipple
2
onto the pump connec-
tion
1
. (For 38 mm (1 1/2") hoses, first detach the
connection nipple
2
in the groove at
y
).
3. Push the hose onto the connection nipple
2
and fix e. g. with a GARDENA Hose Clamp
Art. 7193 / 7195.
Connect hose via the GARDENA Connection System
[ Fig. A5 ]:
We do not recommend to use hoses with a diameter
smaller than 19 mm (3/4"), as otherwise the flow rate will
be reduced.
Hose diameter Pump connection
19 mm (3/4") GARDENA Pump Connection Set Art. 1752
v Connect the hose via the relevant GARDENA Connec-
tion System.
3. OPERATION
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before
you connect, adjust or transport the product.
To pump water:
If the pump cannot be immersed into the water reservoir
via the handle, the pump must always be immersed into
the well or water reservoir via a rope. Minimum immersion
depth during initial operation see 7. TECHNICAL DATA.
Take care that the pump is located where the inlet
openings at the suction base are not obstructed neither
completely nor partly.
Stand the pump on a brick if using in a pond.
1. Submerge the pump in water reservoir.
2. Connect the pump to the mains.
Attention! The pump begins operating immediately.
Automatic mode with float switch [ Fig. O1 ]:
So that the pump automatically switches off when
there is no liquid to pump, the Float Switch
3
must
be able to freely move on the surface of the water.
To adjust the Cut-in and Cut-out Height [ Fig. O1 ]:
The maximum cut-in height and minimum cut-out height
(see 7. TECHNICAL DATA) can be adjusted by pushing the
float switch wire into the float switch lock.
• The shorter the length of cable between the float
switch
3
and the float switch lock
>
, the lower the
cut-in height and the higher the cut-out height.
v Push the cable of the float switch
3
into the opening
in the float switch lock
>
.
CAUTION!
In order to ensure that the float switch is able to
switch on and off, the cable length between the
float switch and the float switch lock must be at
least 10 cm.
Manual operation [ Fig. O2 ]:
The pump remains permanently in operation because
the float switch is bypassed.
1. Slide the float switch
3
with the cable downwards onto
the float switch locking device
>
.
2. Stand the pump on a firm surface.
3. Connect the pump to the mains.
Attention! The pump begins operating immediately.
The minimum residual water depth (see 7. TECHNICAL
DATA) is only achieved in manual mode because the float
switch already switches off the pump before this when in
automatic mode.
EN
13
4. MAINTENANCE
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before
you maintain the product.
To flush the pump:
After pumping chlorinated water, the pump must be
flushed.
1. Pump lukewarm water (max. 35 °C), possibly adding
amild cleaning agent (e. g. detergent) until the pumped
water runs clear.
2. Remove residuals according to the waste disposal laws
applicable in your area.
5. STORAGE
To put into storage:
The pump is not frost-proof!
The product must be stored away from children.
1. Disconnect the pump from the mains.
2. Turn the pump upside down until no more water runs
out.
3. Clean the pump (see 4. MAINTENANCE).
4. Store the pump in a dry, enclosed and frost-free place.
Disposal:
(in accordance with RL2012/19/EC)
The product must not be disposed of to normal
household waste. It must be disposed of in line
with local environmental regulations.
IMPORTANT!
v Dispose of the product through or via your municipal
recycling collection centre.
6. TROUBLESHOOTING
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before
you troubleshoot the product.
To clean the suction base and the impeller [ Fig. T1 ]:
1. Unscrew the 4 Phillips screws
4
.
2. Pull the suction base
5
off the pump.
3. Clean suction base
5
and impeller
6
(the warranty
does not become void as a result of this maintenance
work).
4. Reinstall the suction base
5
.
5. Screw in the 4 Phillips screws
4
again.
For safety reasons a damaged impeller can only be
exchanged by the GARDENA Service Centre.
Problem Possible Cause Remedy
Pump is running, but
doesn’t deliver water
Air cannot escape, because the
pressure line is closed. (Pos siblekink
in the pressure hose.)
v Open the pressure line (e. g. shut-off
valve, delivery units).
Air in suction foot. v Wait for about 60 seconds until
the pump has vented; if necessary,
turn off and then on again.
Suction opening is clogged. v Clean the suction opening with
awater jet.
Hose is clogged. v Remove the clog from the hose.
Impeller is blocked. v Clean the impeller.
Water level below minimum water
level when put into operation.
v Submerge the pump deeper.
Pump does not start, or stops
suddenly during operation
Thermal switch has turned the pump
off because of overheating.
v Clean the suction opening. Observe
the max. media temperature (35 °C).
No power supply to the pump. v Check fuses and electrical plug
connections.
RCD has triggered
(residual current).
v Disconnect the pump and contact
the GARDENA Service.
EN
14
Problem Possible Cause Remedy
Pump is running but the delivery
drops suddenly
Suction opening is clogged. v Clean the suction opening with
awater jet.
Hose is clogged. v Remove the clog from the hose.
NOTE: For any other malfunctions please contact the GARDENA service department.
Repairs must only be done by GARDENA service departments or specialist dealers approved
by GARDENA.
7. TECHNICAL DATA
Submersible Pump Unit Value
(Art. 9000)
Value
(Art. 9001)
Value
(Art. 9007)
Value
(Art. 9008)
Rated power W 250 400 250 400
Mains voltage V (AC) 230 230 230 230
Mains frequency Hz 50 50 50 50
Max. delivery capacity l/h 8200 8600 9200 10,500
Max. pressure /
max. delivery head
bar /
m
0.5
5.0
0.55
5.5
0.4
4.0
0.5
5.0
Max. submersion depth m 6 6 6 6
Min. / max. cut-in height cm 23 / 50 23 / 50 26 / 45 26 / 45
Min. / max. cut-out height cm 7 / 20 7 / 20 11 / 16 11 / 16
Residual water level mm 4 4 25 25
Dirty water with max. particle
diameter
mm 5 5 25 25
Minimum water depth for operation
(approx.)
cm 25 25 50 50
Power cable m 10 (H05RN-F) 10 (H05RN-F) 10 (H05RN-F) 10 (H05RN-F)
Weight without cable (approx.) kg 2.55 2.85 2.55 2.9
Max. media temperature °C 35 35 35 35
8. ACCESSORIES
GARDENA Hose Clamp For 25 mm (1") hoses via the connection nipple. Art. 7193
GARDENA Hose Clamp For 38 mm (1 1/2") hoses via the connection nipple. Art. 7195
GARDENA Pump Connection Set For 19 mm (3/4") hoses via the GARDENA Connection System. Art. 1752
GARDENA Flat Hose Set 10 m 38 mm (1/2") hose with hose clamp. Art. 5005
EN
15
9. SERVICE / WARRANTY
Service:
Please contact the address on the back page.
Warranty statement:
In the event of a warranty claim, no charge is levied to you
for the services provided.
GARDENA Manufacturing GmbH grants a warranty for all
original GARDENA new products for two years from the
date of original purchase from the retailer, provided that
the devices have been for private use only. This manu-
facturer’s warranty does not apply to products acquired
second hand. This warranty includes all significant defects
of the product that can be proved to be material or manu-
facturing faults. This war ranty is fulfilled by supplying afully
functional replacement product or by repairing the faulty
product sent to us free of charge; we reserve the right to
choose between these options. This service is subject
to the following provisions:
• The product has been used for its intended purpose as
per the recommendations in the operating instructions.
• Neither the purchaser nor a third party has attempted to
open or repair the product.
• Only Original GARDENA replacement parts and wear
parts have been used for operation.
• Presentation of the receipt.
Normal wear and tear of parts and components (such as
blades, blade fixing parts, turbines, light bulbs, V-belts /
toothed belts, impellers, air filters, spark plugs), visual
changes, wear parts and consumables are excluded from
the warranty.
This manufacturer’s warranty is limited to replacement
and repair of products in accordance with the abovemen-
tioned conditions. The manufacturer’s warranty does not
constitute an entitlement to lodge other claims against
us as amanufacturer, such as for damages. This manufac-
turer’s warranty does not, of course, affect statutory and
contractual warranty claims against the dealer / retailer.
The manufacturer’s warranty is governed by the law of
the Federal Republic of Germany.
In case of a warranty claim, please return the faulty
product, together with a copy of the receipt and
a description of the fault, with postage paid to the
service address.
Consumables:
The impeller is a consumable and is not included in the
warranty.
EN
16
Art. 9000
Art. 9007
Art. 9001
Art. 9008
Pumpen-Kennlinien
Performance characteristics
Courbes de performance
Prestatiegrafiek
Kapacitetskurva
Ydelses karakteristika
Pumpun ominaiskäyrä
Pumpekarakteristikk
Curva di rendimento
Curva característica
de la bomba
Características de
performance
Charakterystyka pompy
Szivattyú-jelleggörbe
Charakteristika čerpadla
Charakteristiky čerpadla
Χαρακτηριστικό διάγραμμα
Характеристика насоса
Karakteristika črpalka
Obilježja pumpe
Karakteristika pumpe
Крива характеристики насоса
Caracteristică pompă
Pompa karakter eğrisi
Помпена характеристика
Fuqia e pompës
Pumba karakteristik
Siurblio charakteristinė kreivė
Sūkņa raksturlīkne
max. 4.800 l/h
max. 2.400 l/h
max. 6.600 l/h
max.
3 m
2 m
m max. 7.700 l/h1
m4
m5
max. 5.500 l/h
max. 3.600 l/h
max. 900 l/h
max. 7.100 l/h
max.
3 m
2 m
m max. 8.000 l/h1
5 m
4 m
m5,5
max. 3.800 l/h
max. 6.400 l/h
max. 4 m
3 m
2 m
max. 8.400 l/h1 m
max. 5.500 l/h
max. 7.800 l/h
3 m
max. 2.800 l/h 4 m
2 m
max. 9.500 l/h1 m
max. 5 m
174
DE Produkthaftung
Wir weisen ausdrücklich darauf hin, dass wir in Übereinstimmung mit dem Produkthaftungsgesetz nicht für Schäden
haften, die durch unsere Produkte entstehen, wenn diese unsachgemäß und nicht durch einen von uns autorisierten
Servicepartner repariert wurden oder wenn keine Original GARDENA Teile oder von uns zugelassene Teile verwen-
det wurden.
EN Product liability
In accordance with the German Product Liability Act, we hereby expressly declare that we accept no liability for
damage incurred from our products where said products have not been properly repaired by a GARDENA-approved
service partner or where original GARDENA parts or parts authorised by GARDENA were not used.
FR Responsabilité
Conformément à la loi relative à la responsabilité du fait des produits défectueux, nous déclarons expressément
par la présente que nous déclinons toute responsabilité pour les dommages résultant de nos produits, si lesdits
produits n‘ont pas été correctement réparés par un partenaire d‘entretien agréé GARDENA ou si des pièces
d’origine GARDENA ou des pièces agréées GARDENA n‘ont pas été utilisées.
NL Productaansprakelijkheid
Conform de Duitse wet inzake productaansprakelijkheid verklaren wij hierbij uitdrukkelijk dat wij geen aansprakelijk-
heid aanvaarden voor schade ontstaan uit onze producten waarbij deze producten niet zijn gerepareerd door
een GARDENA-erkende servicepartner of waarbij geen originele GARDENA-onderdelen of onderdelen die door
GARDENA zijn goedgekeurd zijn gebruikt.
SV Produktansvar
I enlighet med tyska produktansvarslagar förklarar vi härmed uttryckligen att vi inte åtar oss något ansvar för skador
som orsakas av våra produkter där produkterna inte har genomgått korrekt reparation från en GARDENA-godkänd
servicepartner eller där originaldelar från GARDENA eller delar godkända av GARDENA inte använts.
DA Produktansvar
I overensstemmelse med den tyske produktansvarslov erklærer vi hermed udtrykkeligt, at vi ikke påtager os
noget ansvar for skader på vores produkter, hvis de pågældende produkter ikke er blevet repareret korrekt af en
GARDENA-godkendt servicepartner, eller hvor der ikke er brugt originale GARDENA-reservedele eller godkendte
reservedele fra GARDENA.
FI Tuotevastuu
Saksan tuotevastuulain mukaisesti emme ole vastuussa laitteiden vaurioista, jos korjauksia ei ole tehnyt GARDENAn
hyväksymä huoltoliike tai jos niiden syynä on muiden kuin alkuperäisten GARDENA-varaosien tai GARDENAn hyväk-
symien varaosien käyttö.
IT Responsabilità del prodotto
In conformità con la Legge tedesca sulla responsabilità del prodotto, con la presente dichiariamo espressamente
che decliniamo qualsiasi responsabilità per danni causati dai nostri prodotti qualora non siano stati correttamente
riparati presso un partner di assistenza approvato GARDENA o laddove non siano stati utilizzati ricambi originali
o autorizzati GARDENA.
ES Responsabilidad sobre el producto
De acuerdo con la Ley de responsabilidad sobre productos alemana, por la presente declaramos expresamente
que no aceptamos ningún tipo de responsabilidad por los daños ocasionados por nuestros productos si dichos
productos no han sido reparados por un socio de mantenimiento aprobado por GARDENA o si no se han utilizado
piezas originales GARDENA o piezas autorizadas por GARDENA.
PT Responsabilidade pelo produto
De acordo com a lei alemã de responsabilidade pelo produto, declaramos que não nos responsabilizamos por
danos causados pelos nossos produtos, caso os tais produtos não tenham sido devidamente reparados por
um parceiro de assistência GARDENA aprovado ou se não tiverem sido utilizadas peças GARDENA originais ou
peças autorizadas pela GARDENA.
PL Odpowiedzialność za produkt
Zgodnie z niemiecką ustawą o odpowiedzialności za produkt, niniejszym wyraźnie oświadczamy, że nie ponosimy
żadnej odpowiedzialności za szkody poniesione na skutek użytkowania naszych produktów, w przypadku gdy
naprawa tych produktów nie była odpowiednio przeprowadzana przez zatwierdzonego przez firmę GARDENA part-
nera serwisowego lub nie stosowano oryginalnych części GARDENA albo części autoryzowanych przez tę firmę.
175
HU Termékszavatosság
A németországi termékszavatossági törvénnyel összhangban ezennel nyomatékosan kijelentjük, hogy nem vállalunk
felelősséget a termékeinkben keletkezett olyan károkért, amelyek valamely GARDENA által jóváhagyott szervizpartner
által nem megfelelően végzett javításból adódtak, vagy amely során nem eredeti GARDENA alkatrészeket vagy
a GARDENA által jóváhagyott alkatrészeket használtak fel.
CS Odpovědnost za výrobek
V souladu s německým zákonem o odpovědnosti za výrobek tímto výslovně prohlašujeme, že nepřijímáme žádnou
odpovědnost za poškození vzniklá na našich výrobcích, kdy zmíněné výrobky nebyly řádně opraveny schváleným
servisním partnerem GARDENA nebo kdy nebyly použity originální náhradní díly GARDENA nebo náhradní díly auto-
rizované společností GARDENA.
SK Zodpovednosť za produkt
V súlade s nemeckými právnymi predpismi upravujúcimi zodpovednosť za výrobok týmto výslovne prehlasujeme,
že nenesieme žiadnu zodpovednosť za škody spôsobené našimi výrobkami, v prípade ktorých neboli náležité
opravy vykonané servisným partnerom schváleným spoločnosťou GARDENA alebo neboli použité diely spoločnosti
GARDENA alebo diely schválené spoločnosťou GARDENA.
EL Ευθύνη προϊόντος
Σύμφωνα με τον γερμανικό νόμο περί Ευθύνης για τα Προϊόντα, με το παρόν δηλώνουμε ρητώς ότι δεν
αποδεχόμαστε καμία ευθύνη για τυχόν ζημίες που προκύπτουν από τα προϊόντα μας εάν αυτά δεν έχουν
επισκευαστεί σωστά από κάποιον εγκεκριμένο συνεργάτη επισκευών της GARDENA ή εάν δεν έχουν
χρησιμοποιηθεί αυθεντικά εξαρτήματα GARDENA ή εξαρτήματα εγκεκριμένα από την GARDENA.
SL Odgovornost proizvajalca
V skladu z nemškimi zakoni o odgovornosti za izdelke,izrecno izjavljajo, da ne sprejemamo nobene odgovornosti
za škodo, ki jo povzročijo naši izdelki, če teh niso ustrezno popravili GARDENINI odobreni servisni partnerji ali pri tem
niso bili uporabljeni originalni GARDENINI nadomestni deli ali GARDENINIMI homologiranimi nadomestnimi deli.
HR Pouzdanost proizvoda
Sukladno njemačkom zakonu o pouzdanosti proizvoda, ovime izričito izjavljujemo kako ne prihvaćamo nikakvu
odgovornost za oštećenja na našim proizvodima nastala uslijed neispravnog popravka od strane servisnog partnera
kojeg odobrava GARDENA ili uslijed nekorištenja originalnih GARDENA dijelova ili dijelova koje odobrava GARDENA.
RO Răspunderea pentru produs
În conformitate cu Legea germană privind răspunderea pentru produs, declarăm în mod expres prin prezentul
document că nu acceptăm nicio răspundere pentru defecţiunile suferite de produsele noastre atunci când acestea
nu au fost reparate în mod corect de un atelier de service partener, aprobat de GARDENA, sau când nu au fost
utilizate piese GARDENA originale sau piese autorizate de GARDENA.
BG Отговорност за вреди, причинени от стоки
Съгласно германския Закон за отговорността за вреди, причинени от стоки, с настоящото изрично
декларираме, че не носим отговорност за щети, причинени от нашите продукти, ако те не са били
правилно ремонтирани от одобрен от GARDENA сервиз или ако не са използвани оригинални части
на GARDENA или части, одобрени от GARDENA.
ET Tootevastutus
Vastavalt Saksamaa tootevastutusseadusele deklareerime käesolevaga selgesõnaliselt, et me ei kanna mingisugust
vastutust meie toodetest tingitud kahjude eest, kui need tooted ei ole korrektselt parandatud GARDENA heakskii-
detud hoolduspartneri poolt või kui parandamisel ei ole kasutatud GARDENA originaalosi või GARDENA volitatud
osi.
LT Gaminio patikimumas
Mes aiškiai pareiškiame, kad, atsižvelgiant į Vokietijos gaminių patikimumo įstatymą, neprisiimame atsakomybės
dėl bet kokios žalos, patirtos dėl mūsų gaminių, jeigu jie buvo netinkamai taisomi arba jų dalys buvo pakeistos
neoriginaliomis GARDENA dalimis ar nepatvirtintomis dalimis, arba jeigu remonto darbai buvo atliekami ne
GARDENA techninės priežiūros centro specialistų.
LV Atbildība par produkcijas kvalitāti
Saskaņā ar Vācijas likumu par atbildību par produkcijas kvalitāti ar šo mēs paziņojam, ka neuzņemamies atbildību
par bojājumiem, kas radušies, lietojot mūsu izstrādājumus, kuru remontu nav veicis uzņēmuma GARDENA
apstiprināts apkopes partneris vai kuru remontam netika izmantotas oriģinālās GARDENA detaļas vai detaļas,
kuru lietošanu apstiprinājis uzņēmums GARDENA.
176
DE EU-Konformitätserklärung
Der Unterzeichnende bestätigt als Bevollmächtigte des Herstellers, der GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Schweden, dass das (die) nachfolgend bezeichnete(n)
Gerät(e) in der von uns in Verkehr gebrachten Ausführung die Anforderungen der harmonisierten
EU-Richtlinien, EU-Sicherheitsstandards und produktspezifischen Standards erfüllt / erfüllen.
Beieiner nicht mit uns abgestimmten Änderung des (der) Geräte(s) verliert diese Erklärung ihre
Gültigkeit.
EN EC Declaration of Conformity
The undersigned hereby certifies as the authorized representative of the manufacturer, GARDENA
Germany AB, PO Box 7454, S-103 92, Stockholm, Sweden, that, when leaving our factory, the
unit(s) indicated below is / are in accordance with the harmonised EU guidelines, EU standards of
safety and product specific standards. This certificate becomes void if the unit(s) is / are modified
without our approval.
FR Déclaration de conformité CE
Le soussigné déclare, en tant que mandataire du fabricant, la GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Suède, qu’à la sortie de ses usines le matériel neuf désigné
ci- dessous était conforme aux prescriptions des directives européennes énoncées ci-après et
conforme aux règles de sécurité et autres règles qui lui sont applicables dans le cadre de l’Union
européenne. Toute modification portée sur ce(s) produit(s) sans l’accord express de notre part
supprime la validité de ce certificat.
NL EU-conformiteitsverklaring
De ondergetekende bevestigt als gevolmachtigde van de fabrikant, GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Zweden, dat het/ de onderstaand vermelde apparaat/appara-
ten in de door ons in de handel gebrachte uitvoering voldoet/voldoen aan de eisen van de gehar-
moniseerde EU-richtlijnen, EU-veiligheidsnormen en productspecifieke normen. Bij een niet met ons
afgestemde verandering van het apparaat/de apparaten verliest deze verklaring haar geldigheid.
SV EU-försäkran om överensstämmelse
Undertecknad intygar som befullmäktigad företrädare för tillverkaren, GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Sverige, att nedan angiven apparat/nedan angivna appa-
rater i det utförande vi har släppt på marknaden, uppfyller fordringarna i de harmoniserade
EU-direktiven, EU-säkerhetsstandarderna och de produktspecifika standarderna. Denna försäkran
upphör att gälla vid en ändring av apparaten / apparaterna som inte har stämts av med oss.
DA EU-overensstemmelseserklæring
Underskriveren bekræfter som fuldmægtig for producenten, GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Sverige, at det (de) efterfølgende betegnede apparat(er)
i den af os markedsførte udførelse opfylder kravene i de harmoniserede EU-direktiver, EU-sikker-
hedsstandarder og produktspecifikke standarder. Foretages en ændring af apparatet / appara-
terne, der ikke er aftalt med os, mister denne erklæring sin gyldighed.
FI EU-vaatimustenmukaisuusvakuutus
Allekirjoittanut vahvistaa valmistajan, GARDENA Germany AB, PO Box 7454, S-103 92, Tukholma,
Ruotsi, valtuuttamana henkilönä, että seuraava laite täyttää / seuraavat laitteet täyttävät meidän
toimittamassa mallissa yhdenmukaistettujen EU-direktiivien, EU-turvallisuusmääräysten ja tuote-
kohtaisten standardien vaatimukset. Laitteen/laitteiden muutoksissa, joista ei ole sovittu meidän
kanssamme, menettää tämä selvitys voimassaolonsa.
IT Dichiarazione di conformità UE
Il sottoscritto, in quanto soggetto autorizzato dal produttore, GARDENA Germany AB,
PO Box 7454, S-103 92, Stoccolma, Svezia, dichiara che l’apparecchio/gli apparecchi di seguito
deno minato / i, nella versione da noi immessa in commercio, soddisfa / no i requisiti delle direttive
UE armonizzate, degli standard di sicurezza europei edegli standard specifici per il prodotto.
La presente dichiarazione perde di validità in caso di modifica dell’apparecchio / degli apparecchi
non concordata con noi.
ES Declaración de conformidad de la UE
El firmante confirma, en calidad de apoderado del fabricante GARDENA Germany AB,
PO Box 7454, S-103 92 Estocolmo (Suecia), que el / los aparato(s) mencionado(s) a continuación
cumple(n), en la versión lanzada al mercado por nuestra empresa, los requisitos de las directivas
de la UE armonizadas, los estándares de seguridad de la UE y los estándares específicos del
producto. La presente declaración perderá su validez si se modifica(n) el / los aparato(s) sin previa
aprobación por nuestra parte.
PT Declaração CE de Conformidade
O abaixo-assinado, na qualidade de representante do fabricante, GARDENA Germany AB,
PO Box 7454, S-103 92, Stockholm, Schweden, confirma que o(s) aparelho(s) a seguir
designado(s) no modelo lançado por nós no mercado cumpre/cumprem os requisitos das diretivas
UE harmonizadas, as normas de segurança UE e as normas específicas para estes produtos.
Esta declaração perde a sua validade se forem realizadas alterações no(s) aparelho(s) sem o nosso
consentimento.
PL Deklaracja zgodności UE
Niżej podpisany potwierdza jako upoważniony przedstawiciel producenta, spółki GARDENA
Germany AB, PO Box 7454, S-103 92, Sztokholm, Szwecja, że określone poniżej urządzenie / -nia
w wersji wprowadzonej przez nas do obrotu spełnia / -niają wymogi zharmonizowanych dyrektyw
UE, norm bezpieczeństwa UE oraz norm dotyczących konkretnych produktów. Niniejsza deklaracja
traci ważność w przypadku wprowadzania nieuzgodnionych z nami zmian urządzenia / ń.
HU EU megfelelőségi nyilatkozat
Az alulírott, a GARDENA Germany AB, Pf. 7454, S-103 92, Stockholm, Svédország
megbízotti minőségében megerősíti, hogy az általunk alábbi kivitelben forgalomba hozott, lent
nevezett eszköz(ök) megfelel(nek) az uniós irányelvekkel összhangba hozott nemzeti előírások
követelményeinek, az EU biztonsági szabványainak és a konkrét termékre vonatkozó szabvá-
nyoknak. Azeszköz(ök)nek velünk nem egyeztetett módosítása esetén ez a nyilatkozat érvényét
veszti.
CS EU prohlášení o shodě
Podepsaná osoba zplnomocněná výrobcem GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Švédsko potvrzuje, že v následujícím uvedený(-é) přístroj(-e) v provedení
námi uvedeném na trh splňuje / splňují požadavky směrnic EU, bezpečnostních norem EU
a norem specifických pro výrobek. V případě změny přístroje(-ů), která s námi nebyla dohodnuta,
ztrácí toto prohlášení svou platnost.
SK EÚ vyhlásenie o zhode
Dolu podpísaný potvrdzuje, ako splnomocnený zástupca výrobcu, GARDENA Germany AB,
PO Box 7454, S-103 92, Štokholm, Švédsko, že ďalej označené zariadenie/a vo vyhotovení
uvedenom na trh spĺňa/jú požiadavky harmonizovaných smerníc EÚ, bezpečnostných štandar-
dovEÚ a predpisov, špecifických pre dané výrobky. Pri zmene zariadenia / zariadení, ktorá
nebola odsúhlasená našou spoločnosťou, stráca toto vyhlásenie platnosť.
EL Δήλωση συμμόρφωσης ΕΕ
Ο υπογεγραμμένος βεβαιώνει ως πληρεξούσιος του κατασκευαστή, της εταιρείας GARDENA
Germany AB, Τ.Θ. 7454, S-103 92, Στοκχόλμη, Σουηδία, ότι η (οι) παρακάτω αναφερόμενη(ες)
συσκευή(ές) στην έκδοση που τίθεται από εμάς σε κυκλοφορία πληροί/πληρούν τις απαιτήσεις
των εναρμονισμένων οδηγιών της ΕΕ, προτύπων ασφαλείας της ΕΕ και των ειδικών για το προϊόν
προτύπων. Σε περίπτωση τροποποίησης της (των) συσκευής(ών) χωρίς προηγούμενη συνεννόηση
με την εταιρεία μας παύει να ισχύει η δήλωση.
SL Izjava EU o skladnosti
Spodaj podpisani kot pooblaščenec proizvajalca GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Švedska, potrjuje, da v nadaljevanju označene naprave v izvedbi, v kakršni
smo jih dali v promet, izpolnjujejo zahteve usklajenih direktiv EU, varnostnega standarda EU
in standardov, ki veljajo za posamezne izdelke. V primeru spremembe naprave, ki ni usklajena
z nami, ta izjava neha veljati.
HR EU izjava o sukladnosti
Dolje potpisani kao opunomoćenik proizvođača, tvrtke GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Švedska, potvrđujemo da niže navedeni uređaj(i) odgovarajuće izvedbe
koji/koje smo iznijeli na tržište ispunjavaju kriterije usklađenih direktiva EU i sigurnosnih standarda
EU kao i standarda koji se tiču proizvoda. Ova izjava gubi valjanost u slučaju izmjena uređaja koje
nisu prethodno ugovorene s nama.
RO Declaraţie de conformitate UE
Semnatarul, în calitatea sa de împuternicit al producătorului GARDENA Germany AB, PO Box 7454,
S-103 92, Stockholm, Suedia, confirmă că aparatul (aparatele) descrise în cele ce urmează, în
execuţia pusă de noi pe piaţă îndeplineşte (îndeplinesc) cerinţele directivelor armonizate UE, ale
standardelor de siguranţă UE şi ale standardelor specifice produsului. În cazul modificării fără apro-
barea noastră prealabilă a aparatului (aparatelor), această declaraţie îşi pierde valabilitatea.
BG ЕС-Декларация за съответствие
Долуподписаният удостоверява като пълномощник на производителя GARDENA Germany
AB, PO Box 7454, S-103 92, Стокхолм, Швеция, че по-долу описаният(ите) уред(и) във
варианта на изпълнение пуснат от нас на пазара изпълнява/изпълняват изискванията на
хармонизираните ЕС-директиви, ЕС-норми за безопасност и специфичните норми за
продукцията. В случай на промяна на уреда(ите), която не е съгласувана с нас, тази декла-
рация губи своята валидност.
ET EL-i vastavusdeklaratsioon
Allakirjutanu kinnitab tootja, GARDENA Germany AB, PO Box 7454, S-103 92, Stockholm, Rootsi,
poolt volitatud isikuna, et järgnevalt nimetatud seade (seadmed) täidab (täidavad) meie poolt
turule toodud versiooni kujul harmoneeritud EL-i direktiivide, EL-i ohutusstandardite ja tootepõhiste
standardite nõuded.
Seadmel (seadmetel) meiega kooskõlastamata muudatuse tegemise korral kaotab käesolev dekla-
ratsioon oma kehtivuse.
LT ES atitikties deklaracija
Pasirašantysis, kaip gamintojo, GARDENA Germany AB, PO Box 7454, S-103 92, Stokholmas,
Švedija, įgaliotasis atstovas patvirtina, kad žemiau nurodyto (-ų) prietaiso (-ų) modeliai, kurie
buvo pagaminti mūsų gamyklose, atitinka darniąsias ES direktyvas, ES saugumo standartus ir
specifinius gaminio standartus.
Atlikus bet kokį prietaiso (-ų) pakeitimą, kuris nėra suderintas su mumis, ši deklaracija praranda
galiojimą.
LV ES atbilstības deklarācija
Zemā parakstījusies persona kā ražotāja, uzņēmuma GARDENA Germany AB, PO Box 7454,
S-103 92, Stokholma, Zviedrija, pilnvarotais pārstāvis apstiprina, ka tālāk norādītā(-s) ierīce(-s)
izpildījumā, kādā mēs to (tās) esam laiduši tirgū, atbilst saskaņotajām ES direktīvām, ES drošības
standartiem un konkrētajam produktam noteiktajiem standartiem.
Ierīcē(-s) veicot ar mums nesaskaņotas izmaiņas, šī deklarācija zaudē savu spēku.
177
Produktbezeichnung:
Description of the product:
Désignation du produit :
Beschrijving van het product:
Beskrivning av produkten:
Beskrivelse af produktet:
Tuotteen kuvaus:
Descrizione del prodotto:
Descripción del producto:
Descrição do produto:
Opis produktu:
A termék leírása:
Popis výrobku:
Popis produktu:
Περιγραφή του προϊόντος:
Opis izdelka:
Opis proizvoda:
Descrierea produsului:
Описание на продукта:
Toote kirjeldus:
Gaminio aprašas:
Izstrādājuma apraksts:
EU-Richtlinien:
EC-Directives:
Directives CE :
EG-richtlijnen:
EU-direktiv:
EF-direktiver:
EY-direktiivit:
Direttive UE:
Directiva CE:
Diretivas CE:
Dyrektywy WE:
EK-irányelvek:
Předpisy ES:
Smernice EÚ:
Οδηγίες ΕΚ:
Direktive EU:
EC direktive:
Directive CE:
Директиви на ЕО:
EÜ direktiivid:
EB direktyvos:
EK direktīvas:
2011/65/EG
2014/30/EU
2014/35/EU
Harmonisierte EN-Normen /
Harmonised EN:
EN ISO 12100
EN 60335-1
EN 60335-2-41
Klarwasser-Tauchpumpe / Schmutzwasser-Tauchpumpe
Clear Water Submersible Pump / Dirty Water Submersible Pump
Pompe d’évacuation pour eaux claires / Pompe d’évacuation pour eaux sales
Schoonwaterpomp / Vuilwaterpomp
Dränkbar pump för rent vatten / Dränkbar pump för smutsvatten
Rentvands-dykpumpe / Spildevands-dykpumpe
Puhtaan veden uppopumppu / Likaveden uppopumppu
Pompa sommersa per acqua pulita / Pompa sommersa per acqua sporca
Bomba sumergible para agua limpia / Bomba sumergible para agua residual
Bomba submersível de água limpa / Bomba submersível de água suja
Pompa zanurzeniowa do czystej wody / Pompa zanurzeniowa do brudnej wody
Búvárszivattyú tiszta vízhez / Búvárszivattyú szennyezett vízhez
Ponorné čerpadlo na čistou vodu / Ponorné čerpadlo na špinavou vodu
Ponorné čerpadlo na čistú vodu / Ponorné čerpadlo na znečistenú vodu
Υποβρύχια αντλία καθαρού νερού / Υποβρύχια αντλία λυμάτων
Potopna črpalka za čisto vodo / Potopna črpalka za umazano vodo
Uronska pumpa za čistu vodu / Uronska pumpa za prljavu vodu
Pompă submersibilă pentru apă curată / pompă submersibilă pentru apă murdară
Потопяема помпа за чиста вода / Потопяема помпа за мръсна вода
Selge vee sukelpump / Reovee sukelpump
Panardinamas švaraus vandens siurblys / Panardinamas purvino vandens siurblys
Iegremdējamais tīrā ūdens sūknis / Iegremdējamais notekūdens sūknis
Anbringungsjahr der
CE-Kennzeichnung:
Year of CE marking:
Année d’apposition du marquage CE :
Installatiejaar van de CE-aanduiding:
Märkningsår:
CE-Mærkningsår:
CE-merkin kiinnitysvuosi:
Anno di applicazione della
certificazione CE:
Colocación del distintivo CE:
Ano de marcação pela CE:
Rok nadania oznakowania CE:
CE-jelzés elhelyezésének éve:
Rok umístění značky CE:
Rok udelenia značky CE:
Έτος σήματος CE:
Leto namestitve CE-oznake:
Godina dobivanja CE oznake:
Anul de marcare CE:
Година на поставяне на
CE-маркировка:
CE-märgistuse paigaldamise aasta:
Metai, kada pažymėta CE-ženklu:
CE-marķējuma uzlikšanas gads:
2020
Ulm, den 20.12.2020
Ulm, 20.12.2020
Fait à Ulm, le 20.12.2020
Ulm, 20-12-2020
Ulm, 2020.12.20.
Ulm, 20.12.2020
Ulmissa, 20.12.2020
Ulm, 20.12.2020
Ulm, 20.12.2020
Ulm, 20.12.2020
Ulm, dnia 20.12.2020
Ulm, 20.12.2020
Ulm, 20.12.2020
Ulm, dňa 20.12.2020
Ulm, 20.12.2020
Ulm, 20.12.2020
Ulm, dana 20.12.2020
Ulm, 20.12.2020
Улм, 20.12.2020
Ulm, 20.12.2020
Ulm, 20.12.2020
Ulme, 20.12.2020
Der Bevollmächtigte
Authorised representative
Le mandataire
De gevolmachtigde
Auktoriserad representant
Autoriseret repræsentant
Valtuutettu edustaja
Persona delegata
La persona autorizada
O representante
Pełnomocnik
Meghatalmazott
Zplnomocněnec
Splnomocnený
Ο εξουσιοδοτημένος
Pooblaščenec
Ovlaštena osoba
Conducerea tehnică
Упълномощен
Volitatud esindaja
Įgaliotasis atstovas
Pilnvarotā persona
Reinhard Pompe
Vice President
Produkttyp:
Product type:
Type de produit :
Producttype:
Produkttyp:
Produkttype:
Tuotetyyppi:
Tipo di prodotto:
Tipo de producto:
Tipo de produto:
Typ produktu:
Terméktípus:
Druh výrobku:
Typ produktu:
Τύπος προϊόντος:
Vrsta izdelka:
Vrsta proizvoda:
Tip produs:
Тип продукт:
Tootetüüp:
Gaminio tipas:
Produkta veids:
8200
8600
9200
10500
Artikelnummer:
Article number:
Référence :
Artikelnummer:
Artikelnummer:
Artikelnummer:
Tuotenumero:
Codice articolo:
Referencia:
Número de
referência:
Numer katalogowy:
Cikkszámok:
Objednací číslo:
Objednávacie číslo:
Κωδικός είδους:
Številka izdelka:
Kataloški broj:
Cod articol:
Артикул номер:
Artiklinumber:
Dalies numeris:
Artikula numurs:
9000
9001
9007
9008
Hinterlegte Dokumentation:
GARDENA-Technische Dokumentation,
M. Kugler, 89079 Ulm
Deposited Documentation:
GARDENA Technical Documentation,
M. Kugler, 89079 Ulm
Documentation déposée:
Documentation technique GARDENA,
M. Kugler, 89079 Ulm
178
Deutschland / Germany
GARDENA
Manufacturing GmbH
Central Service
Hans
-
Lorenser
-
Straße 40
D
-
89079 Ulm
Produktfragen:
(+49) 731 490
-
123
Reparaturen:
(+49) 731 490
-
290
service@gardena.com
http://www.gardena.com
Albania
KRAFT SHPK
Autostrada Tirane-Durres
Km 7
1051 Tirane
Argentina
ROBERTO C. RUMBO S.R.L.
Predio Norlog
Lote 7
Benavidez. ZC:1621
Buenos Aires
ventas@rumbosrl.com.ar
Australia
Husqvarna Australia Pty. Ltd.
Locked Bag 5
Central Coast BC
NSW 2252
Phone: (+61) (0) 2 4352 7400
customer.service@
husqvarna.com.au
Austria / Österreich
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: (+ 43) 732 77 0101
-
485
service.gardena@
husqvarnagroup.com
Azerbaijan
Firm Progress
a. Aliyev Str. 26A
1052 Baku
Belarus
Private Enterprise
“Master Garden”
Minsk
Sharangovich str., 7a
Phone: (+375) 17 257-00-33
Mob.: (+375) 29 676-16-09
mg
@mastergarden.by
Belgium
Husqvarna Belgium nv
Gardena Division
Leuvensesteenweg 542
Planet II E
1930 Zaventem
België
Bosnia / Herzegovina
SILK TRADE d.o.o.
Industrijska zona Bukva bb
74260 Tešanj
Brazil
Husqvarna do Brasil Ltda
Av. Francisco Matarazzo,
1400
–
19º andar
São Paulo
–
SP
CEP: 05001
-
903
Tel: 0800
-
112252
marketing.br.husqvarna@
husqvarna.com.br
Bulgaria
AGROLAND България АД
бул. 8 Декември, №13
Офис 5
1700 Студентски град
София
Тел.: (+359) 24 66 6910
info@agroland.eu
Canada / USA
GARDENA Canada Ltd.
100 Summerlea Road
Brampton, Ontario L6T 4X3
Phone: (+1) 905 792 93 30
info
@gardenacanada.com
Chile
REPRESENTACIONES
JCE S.A.
Av. Del Valle Norte 857,
Piso 4
Santiago RM
Phone: (+56) 2 24142560
contacto@jce.cl
China
Husqvarna (Shanghai)
Management Co., Ltd.
富世华（上海）管理有限公司
3F, Benq Square B,
No207, Song Hong Rd.,
Chang Ning District,
Shanghai
PRC. 200335
上海市长宁区淞虹路207号明
基广场B座3楼，邮编：200335
Colombia
Husqvarna Colombia S.A.
Calle 18 No. 68 D
-
31, zona
Industrial de Montevideo
Bogotá, Cundinamarca
Tel. 571 2922700 ext. 105
jairo.salazar@
husqvarna.com.co
Costa Rica
Compania Exim
Euroiberoamericana S.A.
Los Colegios, Moravia,
200 metros al Sur del Colegio
Saint Francis
–
San José
Phone: (+506) 297 68 83
exim_euro@racsa.co.cr
Croatia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: (+ 43) 732 77 0101
-
485
service.gardena@
husqvarnagroup.com
Cyprus
Med Marketing
17 Digeni Akrita Ave
P.O. Box 27017
1641 Nicosia
Czech Republic
Husqvarna Česko s.r.o.
Türkova 2319/5b
149 00 Praha 4 – Chodov
Bezplatná infolinka:
800 100 425
servis@cz.husqvarna.com
Denmark
GARDENA DANMARK
Lejrvej 19, st.
3500 Værløse
Tlf.: (+45) 7026 4770
husqvarna
@husqvarna.dk
www.gardena.com /dk
Dominican Republic
BOSQUESA, S.R.L
Carretera Santiago Licey
Km. 5 ½
Esquina Copal II.
Santiago
Dominican Republic
Phone: (+809) 736
-
0333
joserbosquesa@claro.net.do
Ecuador
Husqvarna Ecuador S.A.
Arupos E1
-
181 y 10 de
Agosto
Quito, Pichincha
Tel. (+593) 22800739
francisco.jacome@
husqvarna.com.ec
Estonia
Husqvarna Eesti OÜ
Valdeku 132
EE-11216 Tallinn
info@gardena.ee
Finland
Oy Husqvarna Ab
Gardena Division
Lautatarhankatu 8 B / PL 3
00581 HELSINKI
www.gardena.fi
France
Husqvarna France
9/11 Allée des pierres mayettes
92635 Gennevilliers Cedex
France
http: //www.gardena.com/fr
N° AZUR: 0 810 00 78 23
(Prix d’un appel local)
Georgia
Transporter LLC
113b Beliashvili street
0159 Tbilisi, Georgia
Great Britain
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
info.gardena
@
husqvarna.co.uk
Greece
Π.ΠΑΠΑΔΟΠΟΥΛΟΣ ΑΕΒΕ
Λεωφ. Αθηνών 92
Αθήνα
Τ.Κ.104 42
Ελλάδα
Τηλ. (+30) 210 5193100
info
@papadopoulos.com.gr
Hungary
Husqvarna Magyarország Kft.
Ezred u. 1
-
3
1044 Budapest
Telefon: (+36) 1 251
-
4161
vevoszolgalat.husqvarna
@
husqvarna.hu
Iceland
BYKO ehf.
Bildshöfoa 20
110 Reykjavik
Ireland
Husqvarna UK Ltd
Preston Road
Aycliffe Industrial Park
Newton Aycliffe
County Durham
DL5 6UP
info.gardena
@
husqvarna.co.uk
Italy
Husqvarna Italia S.p.A.
Via Santa Vecchia 15
23868 VALMADRERA (LC)
Phone: (+39) 0341.203.111
assistenza.italia
@
it.husqvarna.com
Japan
Husqvarna Zenoah Co., Ltd.
1-9 Minamidai
Kawagoe
350-1165 Saitama
gardena-jp
@
husqvarnagroup.com
Kazakhstan
LAMED Ltd.
155/1, Tazhibayevoi Str.
050060 Almaty
IP Schmidt
Abayavenue 3B
110 005 Kostanay
Korea
Kyung Jin Trading CO.,LTD.
107-4, SunDuk Bld.,
YangJae-dong,
Seocho-gu,
Seoul, (zipcode: 137-891)
Phone: (+82) (0)2 574-6300
Latvia
Husqvarna Latvija SIA
Ulbrokas 19A
LV-1021 Rīga
info
@gardena.lv
Lithuania
UAB Husqvarna Lietuva
Ateities pl. 77C
LT
-
52104 Kaunas
info
@gardena.lt
Luxembourg
Magasins Jules Neuberg
39, rue Jacques Stas
Luxembourg
-
Gasperich 2549
Case Postale No. 12
Luxembourg 2010
Phone: (+352) 40 14 01
api@neuberg.lu
Mexico
AFOSA
Av. Lopez Mateos Sur # 5019
Col. La Calma 45070
Zapopan, Jalisco
Mexico
Phone: (+52) 33 3818
-
3434
icornejo@afosa.com.mx
Moldova
Convel S.R.L.
290A Muncesti Str.
2002 Chisinau
Netherlands
Husqvarna Nederland B.V.
GARDENA Division
Postbus 50131
1305 AC ALMERE
Phone: (+31) 36 521 00 10
info@gardena.nl
Neth. Antilles
Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200
Curaçao
Phone: (+599) 9 767 66 55
pgm
@jonka.com
New Zealand
Husqvarna New Zealand Ltd.
PO Box 76
-
437
Manukau City 2241
Phone: (+64) (0) 9 9202410
support.nz@husqvarna.co.nz
Norway
Husqvarna Norge AS
Gardena Division
Trøskenveien 36
1708 Sarpsborg
info@gardena.no
Peru
Husqvarna Perú S.A.
Jr. Ramón Cárcamo 710
Lima 1
Tel : (+51) 1 3320 400 ext. 416
juan.remuzgo@
husqvarna.com
Poland
Husqvarna
Poland Spółka z o.o.
ul. Wysockiego 15 b
03
-
371 Warszawa
Phone: (+48) 22 330 96 00
gardena@husqvarna.com.pl
Portugal
Husqvarna Portugal, SA
Lagoa
-
Albarraque
2635
-
595 Rio de Mouro
Tel.: (+351) 21 922 85 30
Fax : (+351) 21 922 85 36
info@gardena.pt
Romania
Madex International Srl
Soseaua Odaii 117
-
123,
RO 013603 Bucure
ş
ti, S1
Phone: (+40) 21 352.76.03
madex@ines.ro
Russia / Россия
ООО „Хускварна“
141400, Московская обл.,
г. Химки,
улица Ленинградская,
владение 39, стр.6
Бизнес Центр
„Химки Бизнес Парк“,
помещение ОВ02_04
http: //www.gardena.ru
Serbia
Domel d.o.o.
Autoput za Novi Sad bb
11273 Belgrade
Phone: (+381) 1 18 48 8812
miroslav.jejina@domel.rs
Singapore
Hy
-
Ray PRIVATE LIMITED
40 Jalan Pemimpin
#02
-
08 Tat Ann Building
Singapore 577185
Phone: (+65) 6253 2277
shiying@hyray.com.sg
Slovak Republic
Husqvarna Česko s.r.o.
Türkova 2319/5b
149 00 Praha 4 – Chodov
Bezplatná infolinka: 800 154 044
servis
@sk.husqvarna.com
Slovenia
Husqvarna Austria GmbH
Industriezeile 36
4010 Linz
Tel.: (+ 43) 732 77 0101
-
485
service.gardena@
husqvarnagroup.com
South Africa
Husqvarna South Africa (Pty) Ltd
Postnet Suite 250
Private Bag X6,
Cascades, 3202, South Africa
Phone: (+27) 33 846 9700
info
@gardena.co.za
Spain
Husqvarna España S.A.
Calle de Rivas nº 10
28052 Madrid
Phone: (+34) 91 708 05 00
atencioncliente@gardena.es
Suriname
Deto Handelmaatschappij N.V.
Kernkampweg 72-74
P.O.Box: 12782
Paramaribo – Suriname
South America
Phone: (+597) 438050
www.deto.sr
Sweden
Husqvarna AB /
GARDENA Sverige
Drottninggatan 2
561 82 Huskvarna Sverige
Switzerland / Schweiz
Husqvarna Schweiz AG
Consumer Products
Industriestrasse 10
5506 Mägenwil
Phone: (+41) (0) 62 887 37 90
info@gardena.ch
Turkey
Dost Bahçe Dış Ticaret
Mümessillik A.Ş
Yunus Mah. Adil Sok. No:3
Ic Kapi No: 1 Kartal
34873 Istanbul
Phone: (+90) 216 38 93 939
info@dostbahce.com.tr
Ukraine / Україна
ТОВ «Хускварна Україна»
вул. Васильківська, 34,
офіс 204
-
г
03022, м. Київ
Тел. (+38) 0 800 504 804
info@gardena.ua
Uruguay
FELI SA
Entre Ríos 1083 CP 11800
Montevideo
–
Uruguay
Tel: (+598) 22 03 18 44
info@felisa.com.uy
Venezuela
C
orporación Casa y Jardín C.A.
Av. Caroní, Edif. Trezmen, PB.
Colinas de Bello Monte.
1050 Caracas.
Tlf: (+58) 212 992 33 22
info@casayjardin.net.ve
0000
-
20.960.00 /1220
©
GARDENA
Manufacturing GmbH
D- 89070 Ulm
9000-20.960.01/1220
© GARDENA Manufacturing GmbH
D-89079 Ulm
http://www.gardena.com
182
