ESPAÑOL

OWNER’S MANUAL

GE is a trademark of the General Electric Company. Manufactured under trademark license.

Write the model and serial

numbers here:

Model # _________________

Serial # _________________

You can find the rating label on a

metal flag behind the rear control

panel. From the front of the range,

reach behind the middle of the rear

control panel and rotate the rating

label up.

RANGES

Self-Cleaning Gas

SAFETY INFORMATION .......... 3

USING THE RANGE

In Case of a Power Failure ............... 8

Surface Burners ........................ 8

Griddle ................................10

Oven Controls ..........................11

Special Features ......................12

Sabbath Mode - Standard ..............13

Oven Racks ............................14

Aluminum Foil and Oven Liners ...........14

Oven Cooking Modes ...................15

Oven Air Vents .........................16

Oven Cooking Guide ....................17

Air Fry Cooking Guide ...................18

CARE AND CLEANING

Range – Exterior ........................19

Range – Interior .......................20

Cooktop ...............................21

Oven Door ............................ 23

Oven Light ............................ 25

TROUBLESHOOTING TIPS .......26

LIMITED WARRANTY ............30

ACCESSORIES .....................31

CONSUMER SUPPORT ........... 32

PCGB965

Para consultar una version en

español de este manual de

instrucciones, visite nuestro sitio de

internet GEAppliances.ca/en/

295D1703P022 Rev. 0 03-21

THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.

Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.

We take pride in the craftsmanship, innovation and design that goes into every GE Appliances

product, and we think you will too. Among other things, registration of your appliance ensures that we

can deliver important product information and warranty details when you need them.

Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration

card included in the packing material.

295D1703P022 R ev. 0

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

SAFETY INFORMATION

ANTI-TIP DEVICE

To reduce the risk of tipping the range,

the range must be secured by a properly

installed anti-tip bracket. See installation

instructions shipped with the bracket for

complete details before attempting to

install.

For Free-Standing and Slide-In Ranges

To check if the bracket is installed and

engaged properly, look underneath the

range to see that the rear leveling leg is engaged in the bracket. On

some models, the storage drawer or kick panel can be removed for easy

inspection. If visual inspection is not possible, slide the range forward,

confirm the anti-tip bracket is securely attached to the floor or wall, and

slide the range back so the rear leveling leg is under the anti-tip bracket.

If the range is pulled from the wall for any reason, always repeat this

procedure to verify the range is properly secured by the anti-tip bracket.

Never completely remove the leveling legs or the range will not be secured

to the anti-tip device properly.

WARNING

If the information in this manual is not followed exactly, a fire or

explosion may result, causing property damage, personal injury or death.

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of

this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS

 ■ Donottrytolightanyappliance.

 ■ Donottouchanyelectricalswitch;donotuseanyphoneinyourbuilding.

 ■ Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegas

supplier’sinstructions.

 ■ Ifyoucannotreachyourgassupplier,callthefiredepartment.

- Installation and service must be performed by a qualified installer, service agency or

the gas supplier.

WARNING

Read all safety instructions before using the product. Failure to follow these instructions may result

in fire, electrical shock, serious injury or death.

Anti-Tip

Bracket

Leveling Leg

Free-Standing and Slide-In Ranges

• A child or adult can tip the range and be killed.

• Install the anti-tip bracket to the wall or floor.

• Engage the range to the anti-tip bracket by sliding the

range back such that the foot is engaged.

• Re-engage the anti-tip bracket if the range is moved.

• Failure to do so can result in death or serious burns

to children or adults.

Tip-Over Hazard

WARNING

295D1703P022 R ev. 0

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

GENERAL SAFETY INSTRUCTIONS

WARNING

NEVER use this appliance as a

space heater to heat or warm the room. Doing

so may result in carbon monoxide poisoning

and overheating of the oven.

■ Usethisapplianceforitsintendedpurposeas

described in this owner’s manual.

■ Haveyourrangeinstalledandproperlygroundedby

a qualified installer in accordance with the provided

installation instructions.

■ Anyadjustmentandserviceshouldbeperformed

only by a qualified gas range installer or service

technician. Do not attempt to repair or replace

any part of your range unless it is specifically

recommended in this manual.

■ Yourrangeisshippedfromthefactorysetforuse

with natural gas. It can be converted for use with

propane gas. If required, these adjustments must be

made by a qualified technician in accordance with

the installation instructions and local codes. The

agency performing this work assumes responsibility

for the conversion.

■ Havetheinstallershowyouthelocationofthe

range gas shut-off valve and how to turn it off if

necessary.

■ Plugyourrangeintoa120-voltgroundedoutlet

only. Do not remove the round grounding prong

from the plug. If in doubt about the grounding of the

home electrical system, it is your responsibility and

obligation to have an ungrounded outlet replaced

with a properly grounded, three prong outlet in

accordance with the National Electrical Code. Do

not use an extension cord with this appliance.

■ Beforeperforminganyservice,unplugtherange

or disconnect the power supply at the household

distribution panel by removing the fuse or switching

off the circuit breaker.

■ Besureallpackingmaterialsareremovedfromthe

range before operating to prevent ignition of these

materials.

■ Avoidscratchingorimpactingglassdoors,

cooktops, or control panels. Doing so may lead

to glass breakage. Do not cook on a product with

broken glass. Shock, fire, or cuts may occur.

■ Donotleavechildrenaloneorunattendedinan

area where an appliance is in use. They should

never be allowed to climb, sit or stand on any part

of the appliance.

■

CAUTION

Do not store items of interest

to children in cabinets above an oven - children

climbing on the oven to reach items could be

seriously injured.

■ Neverblockthevents(airopenings)oftherange.

They provide the air inlets and outlets that are

necessary for the range to operate properly with

correct combustion. Air openings are located at the

rear of the cooktop, at the top and bottom of the

oven door, and at the bottom of the range under the

drawer, lower oven drawer or kick panel.

■ Useonlydrypotholders—moistordamppot

holders on hot surfaces may result in burns from

steam. Do not let pot holders touch surface burners,

burner grate, or oven heating element. Do not use a

towel or other bulky cloth in place of pot holders.

■ Donottouchtheheatingelementsortheinterior

surface of the oven. These surfaces may be hot

enough to burn even though they are dark in color.

During and after use, do not touch, or let clothing

or other flammable materials contact any interior

area of the oven; allow sufficient time for cooling

first. Other surfaces of the appliance may become

hotenoughtocauseburns.Potentiallyhotsurfaces

include the burners, grates, oven vent opening,

surfaces near the opening, and crevices around the

oven door.

■ Donotheatunopenedfoodcontainers.Pressure

could build up and the container could burst,

causing an injury.

■ Cookfoodthoroughlytohelpprotectagainst

foodborne illness. Minimum safe food temperature

recommendations can be found at

IsItDoneYet.gov and fsis.usda.gov.Useafood

thermometer to take food temperatures and check

several locations.

■ Donotallowanyonetoclimb,standorhangonthe

oven door, drawer or cooktop. They could damage

the range or tip it over causing severe injury or death.

295D1703P022 R ev. 0

WARNING

KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE

Failure to do so may result in fire or personal injury.

■ Donotstoreoruseflammablematerialsinanoven

or near the cooktop, including paper, plastic, pot

holders, linens, wall coverings, curtains, drapes and

gasoline or other flammable vapors and liquids.

■ Neverwearloose-fittingorhanginggarmentswhile

using the appliance. These garments may ignite if

they contact hot surfaces causing severe burns.

■ Donotletcookinggreaseorotherflammable

materials accumulate in or near the range. Grease

in the oven or on the cooktop may ignite.

WARNING

IN THE EVENT OF A FIRE, TAKE THE FOLLOWING

STEPS TO PREVENT INJURY AND FIRE SPREADING

■ Donotusewaterongreasefires.Neverpickup

a flaming pan. Turn the controls off. Smother a

flaming pan on a surface unit by covering the pan

completely with a well-fitting lid, cookie sheet or flat

tray.Useamulti-purposedrychemicalorfoam-type

fire extinguisher.

■ Ifthereisafireintheovenduringbaking,smother

the fire by closing the oven door and turning the

oven off or by using a multi-purpose dry chemical or

foam-type fire extinguisher.

■ Ifthereisafireintheovenduringself-clean,turn

the oven off and wait for the fire to go out. Do not

force the door open. Introduction of fresh air at self-

clean temperatures may lead to a burst of flame

from the oven. Failure to follow this instruction may

result in severe burns.

SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

READ AND SAVE THESE INSTRUCTIONS

WARNING

COOKTOP SAFETY INSTRUCTIONS

WARNING

NEVER Operate the

Top Surface Cooking Section of this

Appliance Unattended.

• Failure to follow this warning

statement could result in fire,

explosion, or burn hazard that could

cause property damage, personal

injury, or death.

• If a fire should occur, keep away from

the appliance and immediately call

your fire department.

DO NOT ATTEMPT TO EXTINGUISH

AN OIL/GREASE FIRE WITH WATER.

■ Neverleavethesurfaceburnersunattended.Foods,

especially oily foods, may ignite resulting in fire that

could spread to surrounding cabinets.

■ Neverleaveoilunattendedwhilefrying.Ifallowed

to heat beyond its smoking point, oil may ignite

resulting in fire that may spread to surrounding

cabinets.Useadeepfatthermometerwhenever

possible to monitor oil temperature.

■ Toavoidoilspilloverandfire,usetheminimum

amount of oil when using a shallow pan-frying

and avoid cooking frozen foods with excessive

amounts of ice.

■ Useproperpansizeandavoidpansthatare

unstable or easily tipped. Select cookware that is

matched to the size of the burner. Burner flames

should be adjusted so that they do not extend

beyond the bottom of the pan. Excessive flame may

be hazardous.

■ AlwaysusetheLITEpositionwhenignitingthetop

burners and make sure the burners have ignited.

■ Whenusingglass/ceramiccookware,makesureit

is suitable for cooktop service; others may break

because of sudden change in temperature.

295D1703P022 R ev. 0

SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

WARNING

OVEN SAFETY INSTRUCTIONS

WARNING

NEVER cover any slots,

holes, or passages in the oven bottom or

cover an entire rack with materials such as

aluminum foil or oven liners. Doing so blocks

air flow through the oven and may cause

carbon monoxide poisoning. Never place foil

or oven liners on the oven bottom. They can

trap heat causing risk of smoke or fire.

■ Standawayfromtherangewhenopeningtheoven

door. Hot air or steam which escapes can cause

burnstohands,faceand/oreyes.

■ Neverplacecookingutensils,pizzaorbakingstones,

or any type of foil or liner on the oven floor. These

items can trap heat or melt, resulting in damage to

the product and risk of shock, smoke or fire.

■ Placeovenracksindesiredlocationwhileovenis

cool. If rack must be moved while oven is hot, be

careful to avoid touching hot surfaces.

■ Donotleaveitemssuchaspaper,cookingutensils,

or food in the oven when not in use. Items stored in

an oven can ignite.

■ Donotleaveitemsonthecooktopneartheoven

vent. Items may overheat resulting in a risk of fire or

burns.

■ Neverbroilwithdooropen.Open-doorbroilingis

not permitted due to overheating of control knobs.

WARNING

COOKTOP SAFETY INSTRUCTIONS

■ Tominimizethepossibilityofburns,ignitionof

flammable materials and spillage, the handle of a

container should be turned toward the center of the

range without extending over nearby burners.

■ Donotuseawokwitharoundmetalsupportring.

The ring may trap heat and block air to the burner

resulting in a carbon monoxide hazard.

■ Donotattempttoliftthecooktop.Doingsomay

damage the gas tubing to the surface burners

resulting in a gas leak and risk of fire.

■ WhendisablingLockControl,makesurethe

surface controls are set to the OFF position. This

will prevent unintended gas flow from the burners.

■ Donotusealuminumfoiltocoverthegratesor

line any part of the cooktop. Doing so may result

in carbon monoxide poisoning, overheating of the

cooktop surfaces, or a potential fire hazard.

WARNING

SELF-CLEANING OVEN SAFETY INSTRUCTIONS

The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.

Follow these instructions for safe operation.

■ Donottouchovensurfacesduringself-clean

operation. Keep children away from the oven during

self-cleaning. Failure to follow these instructions

may cause burns.

■ Beforeoperatingtheself-cleancycle,removepans,

shiny metal oven racks, and other utensils from the

oven. Only porcelain-coated oven racks may be left

in the oven.

■ Beforeoperatingtheself-cleancycle,wipegrease

and food soils from the oven. Excessive amount

of grease may ignite leading to smoke damage to

your home.

■ Iftheself-cleaningmodemalfunctions,turnthe

oven off and disconnect the power supply. Have it

serviced by a qualified technician.

■ Donotuseovencleaners.Nocommercialoven

cleaner or oven liner protective coating of any kind

should be used in or around any part of the oven.

■ Donotcleanthedoorgasket.Thedoorgasketis

essential for a good seal. Care should be taken not

to rub, damage or move the gasket.

■ IMPORTANT: The health of some birds is

extremely sensitive to the fumes given off during

the self-cleaning cycle of any range. Move birds to

another well-ventilated room.

READ AND SAVE THESE INSTRUCTIONS

295D1703P022 R ev. 0

How to Remove Protective Shipping Film and Packaging Tape

Carefully grasp a corner of the protective shipping film

with your fingers and slowly peel it from the appliance

surface. Do not use any sharp items to remove the film.

Remove all of the film before using the appliance for the

first time.

To assure no damage is done to the finish of the

product, the safest way to remove the adhesive from

packaging tape on new appliances is an application of

a household liquid dishwashing detergent. Apply with a

soft cloth and allow to soak.

NOTE: The adhesive must be removed from all parts. It

cannot be removed if it is baked on.

SAFETY INFORMATION

IMPORTANT SAFETY INFORMATION

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE

Remote Enable Equipment

Thisdevicecomplieswithpart15oftheFCCRules.

Operationissubjecttothefollowingtwoconditions:(1)

This device may not cause harmful interference, and

(2)thisdevicemustacceptanyinterferencereceived,

including interference that may cause undesired operation.

The wireless communication equipment installed on this

range has been tested and found to comply with the

limitsforaClassBdigitaldevice,pursuanttopart15of

the FCC Rules. These limits are designed to:

(a) provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio

or television reception, which can be determined by

turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the

following measures:

■Reorientorrelocatethereceivingantenna.

■Increasetheseparationbetweentheequipmentand

receiver.

■Connecttheequipmentintoanoutletonacircuit

different from that to which the receiver is connected.

■Consultthedealeroranexperiencedradio/TV

technician for help.

(b) accept any interference received, including interference

that may cause undesired operation of the device.

Note that any changes or modifications to the wireless

communication device installed on this oven that are not

expressly approved by the manufacturer could void the

user’s authority to operate the equipment.

READ AND SAVE THESE INSTRUCTIONS

295D1703P022 R ev. 0

USING THE RANGE: InCaseofaPowerFailure/SurfaceBurners

In Case of a Power Failure

Types of Surface Burners

Round Burner

Usethisburnerforgeneral

cooking purposes. Size cookware

appropriately to the flames.

Surface Burners

In the event of a power failure, the oven is inoperable

and no attempt should be made to operate it. However,

thesurfaceburnersmaybelitwithamatch.Using

extreme caution, hold a lit match near the ports beneath

the surface burner cap, then slowly turn the knob to the

LITE position. Once lit, surface burners will continue to

operate normally.

Lighting a Surface Burner

WARNING

Burners should be operated only

when covered by cookware. Burner flames not

covered by cookware present a risk of fire or

clothing ignition. Never let flames extend beyond the

sides of the cookware. Failure to comply may result

in serious injury.

Make sure all burners are in their correct locations and

fully assembled before attempting to operate any burner.

Selectaburnerandfinditscontrolknob.Pushtheknob

in and turn it to the LITE position.

Youwillhearaclickingnoise—

the sound of the electric spark

igniting the burner. When one

burner is turned to LITE, all

burners will spark. Sparking will

continue as long as the knob

remains at LITE. Once gas is

ignited, turn the knob to adjust

the flame size.

Using the Surface Burners

NOTES:

■ Donotoperatetheburnerforanextendedperiodof

time without cookware on the grate. The finish on

the grate may discolor or chip without cookware to

absorb the heat.

■ Donotattempttodisassembleanyburnerwhileanother

burner is on. Damage to the product may occur.

■ Besuretheburnersandgratesarecoolbeforeyou

place your hand, a pot holder or cleaning materials

on them.

Your rangetop has sealed gas burners that offer

convenience, cleanability and flexibility for a wide range

of cooking applications.

The smallest burner is the simmer burner. A simmer

burner turned down to LO provides precise cooking

performance for foods such as delicate sauces that

require low heat for a long cooking time.

The extra-large burner is designed to quickly bring

large amounts of liquid to a boil. Some models have a

POWERBOIL™settingespeciallydesignedforusewith

cookwarewithadiameterof11inchesorlarger.

Selecting a Flame Size

Watch the flame, not the knob, as you adjust heat. When

rapid heating is desired, the flame size should match the

size of the cookware you are using. Flames larger than

the bottom of the cookware will not heat faster and may

be hazardous.

Pushthecontrolknobinand

turn it to the LITE position.

These flames are too large for the pot

Oval Burner

Usethisburnertocookonthegriddle.

Multi-Ring Burner

Usethisburnerforlarge

cookware or for simmering

applications.

295D1703P022 R ev. 0

Surface Burners (Cont.)

Stove Top Grills

Do not use an after-market stove top grill on your

gas surface burners. A stove top grill will cause

incomplete combustion resulting in carbon monoxide

levels above allowable standards. This could be

hazardous to your health.

Using a Wok

Useonlyaflat-bottomedwokwithadiameterof14inches

or less. Make sure the wok bottom sits flat on the grate.

Donotuseawoksupportring.Placingtheringoverthe

burner or grate may cause the burner to work improperly,

resulting in carbon monoxide levels above allowable

standards. This could be hazardous to your health.

Useaflat-bottomedwok.

Do not use stove top grills

Top-of-Range Cookware

Aluminum: Medium-weight cookware is recommended

because it heats quickly and evenly. Most foods brown

evenlyinanaluminumskillet.Usesaucepanswithtight-

fitting lids when cooking with minimum amounts of water.

Stainless Steel: This metal alone has poor heating

properties and is usually combined with copper,

aluminum or other metals for improved heat distribution.

Combination metal skillets usually work satisfactorily if

they are used with medium heat or as the manufacturer

recommends.

Cast-Iron: If heated slowly, most skillets will give

satisfactory results.

Enamelware:Undersomeconditions,theenamel

of some cookware may melt. Follow the cookware

manufacturer’s recommendations for cooking methods.

Glass:Therearetwotypesofglasscookware—those

for oven use only and those for top-of-range cooking

(saucepans,coffeeandteapots).Glassconductsheat

very slowly.

Heatproof Glass Ceramic: Can be used for either

surface or oven cooking. It conducts heat very slowly and

cools very slowly. Check the cookware manufacturer’s

directions to be sure it can be used on gas ranges.

USING THE RANGE: Surface Burners

295D1703P022 R ev. 0

USING THE RANGE: Griddle

Griddle

Positioning Your Griddle

The reversible cast-iron griddle can only be used over the center burner of the rangetop. To position the griddle,

removethecentergrate(ifpresent),andreplaceitwiththegriddle.Donotturnonthecenterburneruntilyouare

certain the griddle has been positioned correctly.

Preheating Your Griddle

If your center burner is a single oval burner, preheat your griddle for 2-5 minutes on Hi before placing food on the

griddle.Ifyourcenterburnerisadualovalburner,preheatyourgriddlefor5-10minutesonHibeforeplacingfoodon

the griddle. Once the griddle is preheated, turn the heat down to the cook setting outlined in the table corresponding

to your griddle. To determine the type of burner you have, see the Types of Surface Burners section.

Using Your Reversible Cast-Iron Griddle

The ribbed side of the reversible griddle can be used for

food normally grilled.

Your griddle provides an extra-large cooking surface for

meats, pancakes and other foods usually prepared in

a skillet. Before first use, rinse with hot water and dry

thoroughly.Preparethesurfacewithcookingsprayor

vegetable oil.

Griddle Precautions:

■ Donotplacethegriddleinamicrowaveoven.

■ Donotcleanyourgriddleinthedishwasher.

■ Ifsomethinghasspilledunderthegriddle,itshouldbe

cleaned up as soon as possible to prevent “baked on”

food soil.

■ Donotallowgreasetoaccumulateunderthegriddle

as it can be a fire hazard. Clean under the griddle with

hot, soapy water as soon as it is cool.

WARNING

Fire Hazard

■ Usecarewhencookinggreasyfoods.Spilledgreasemayresultinfire.

■ Neverplaceanyitemsonthegriddlewhenitisnotinuse.Heatfromsurroundingburnerscanheat

the griddle and may result in fire.

■ PlaceandremovethegriddleonlywhengriddleiscoolandallsurfaceburnersareturnedOFF.

Type of Food Cook Setting

Bacon Med

Breakfast Sausage Links Med

Eggs Lo

Grilled Cheese Med-Lo

Hamburgers Med-Lo

Pancakes Med-Lo

Warming Tortillas Lo

Cook settings may need to be reduced if the griddle is used for an

extended time.

Preseasoned Reversible Cast-Iron Griddle

Replacethecentergrate(ifpresent)withthe

PreseasonedCast-IronReversibleGriddle

295D1703P022 R ev. 0

Oven Controls

1. Traditional Cooking Modes: Your oven has the

following traditional cooking modes: Bake, Broil and

Warm. See the Oven Cooking Modes section for

more information.

2. Convection Cooking Modes: Convection cooking

mode uses increased air circulation to improve

performance. See the Oven Cooking Modes section

for more information.

3. Clean: Your oven has two cleaning modes: Self

Clean and Steam Clean. See the Cleaning the Oven

section for important information about using these

modes.

4. Start: Must be pressed to start any cooking,

cleaning, or timed function.

NOTE: If your display and keys dim, opening

the oven door or pressing any key will wake and

illuminate the control.

5. Cancel/Off: Cancels ALL oven operations except

the clock and timer.

6. Timer: Worksasacountdowntimer.Pressthe

Timer pad and use the number pads to program

thetimeinhoursandminutes.PresstheStart pad.

The oven will continue to operate when the timer

countdown is complete. To turn the timer off, press

the Timer pad.

7. Cook TIme: Counts down cooking time and turns

off the oven when the cooking time is complete.

Selectadesiredcookingmode.Usethenumber

padstoprogramabakingtemperature.Press

the Cook Time pad and use the number pads

to program a cooking time in hours and minutes.

Then press Start. This can only be used with Bake,

Convection Bake, Convection Roast, and Air Fry.

8. Delay Time: Delayswhentheovenwillturnon.Use

this to set a time when you want the oven to start.

Selectadesiredcookingmode.Usethenumber

padtoprogramabakingtemperature.Pressthe

Delay Time pad.Usethenumberpadstoprogram

the time of day for the oven to turn on, and then

press Start.

NOTE: When using the Delay Time feature, foods

that spoil easily – such as milk, eggs, fish, stuffing,

poultry, and pork – should not be allowed to sit for

morethan1hourbeforeoraftercooking.Room

temperature promotes the growth of harmful

bacteria. Be sure that the oven light is off because

heat from the bulb will speed harmful bacteria

growth.

9. Lock Controls: Locks out the control so that

pressing the pads does not activate the controls.

PressandholdtheLock Controls pad, for three

seconds to lock or unlock the control. Cancel/Off is

always active, even when the control is locked.

10. Oven Lights: Turns the oven lights on or off.

11. Air Fry: The Air Fry mode is designed to produce

foods with a crispier exterior than traditional oven

cooking. See the Oven Cooking Modes section for

more information.

12. Set Clock: Settheovenclocktime.PresstheSet

Clockpad.Usethenumberpadstoprogramthe

clock.PressStart to save the time.

13. Remote Enable: Allows you to control your oven

remotely. To be able to start the oven remotely,

press the Remote Enable pad, and “Remote” will

be lit in the display. The oven can now be remotely

started with a connected device. This appliance

is configurable to allow remote operation at any

time. Do not store any flammable materials or

temperature sensitive items inside, on top or near

the surface units of the appliance. If “Remote” is not

shown in the display, you are still able to change the

oven settings or turn the oven off. After using the

oven, remember to verify that the “Remote” icon is

displayed if you wish to start the oven remotely in

the future. For instructions on how to connect your

oven, see the WiFi Connect section of this manual.

14. Chef Connect: This is a Bluetooth

pairing feature

for use with other compatible Chef Connect enabled

products like an over-the-range microwave oven or

range hood. To pair those products to the range,

press and hold the 6 and 7 pads for 3 seconds

and follow the corresponding instructions included

with the mating Chef Connect enabled product if

needed. The range will cancel pairing mode after

two minutes if no mating device is detected.

USING THE RANGE: Oven Controls

3 4 5 45

39 8 13 14 11710 6

295D1703P022 R ev. 0

SPECIAL FEATURES

There are several different special features on your range. To change the settings of these special features:

■ PresstheUpperOvenBake and Broil pads at the same time and hold until the special features menu is

displayed.

■ Usethe3 or 8 number pads to scroll through the special features until the desired feature is displayed.

■

Pressthe0 number pad to enter into the feature’s menu and use the 3 or 8 number pads to scroll through the options.

■ Oncethedesiredoptionisdisplayed,pressthe0 pad to save the setting and the 6 pad to exit the menu.

Adjust the Oven Temperature

This feature allows the oven baking temperature to be

adjustedupto35ºhotterordownto35ºcooler.Usethis

feature if you believe your oven temperature is too hot or

too cold and wish to change it. This adjustment affects

every cooking mode except broil.

Enter into the special features menu as outlined above.

Scroll through the features until “Lo offset” is displayed

toadjusttheloweroventemperatureor“Upoffset”

is displayed to adjust the upper oven temperature

thenpress0.Usethe3 pad to increase the adjusted

temperature or use the 8 pad to decrease the adjusted

temperature. Save and exit the special features menu.

End of Timer Signals

This is the tone that signals the end of a timer. The

tonecanbeeithercontinuous(Cont)orsingle(bEEp).

Thecontinuoussetting(Cont)willrepeatedlysounda

tone every few seconds until a button on the control

ispressed.Asinglesetting(bEEp)willsoundjusta

single tone at the end of the timer. Enter into the special

features menu as outlined above. Scroll through the

options until “End tonE” is displayed and press 0. Scroll

through the options until the desired setting is displayed.

Press0 to save the setting and then 6 to exit the menu.

Fahrenheit or Celsius Temperature

Display

The oven control is set to use Fahrenheit temperatures

(F),butyoucanchangeittouseCelsiustemperatures

(C).Enterintothespecialfeaturesmenuasoutlined

above.Scrollthroughtheoptionsuntil“degUnit”is

displayed and press 0. Scroll through the options until

thedesiredsettingisdisplayed.Press0 to save the

setting and then 6 to exit the menu.

Clock Display

Thisfeature(On/Off)specifiesifthetimeofdayis

displayed. Enter into the special features menu as

outlined above. Scroll through the options until “Cloc

diSP”isdisplayedandpress0. Scroll through the

optionsuntilthedesiredsettingisdisplayed.Press0 to

save the setting and then 6 to exit the menu.

Clock Configuration

This feature specifies how the time of day will be

displayed.Youcanselectastandard12-hourclock(12)

or 24-hour military time display. Enter into the special

features menu as outlined above. Scroll through the

options until “Cloc cFg” is displayed and press 0. Scroll

through the options until the desired setting is displayed.

Press0 to save the setting and then 6 to exit the menu.

Sound Volume

This feature allows the oven tone volume to be adjusted

betweenhigh(Hi),medium(reg),low(Lo)andoff(oFF).

Enter into the special features menu as outlined above.

Scroll through the options until “sound” is displayed

and press 0. Scroll through the options until the desired

settingisdisplayed.Press0 to save the setting and then

6 to exit the menu. The selected sound option will play

once 0 is pressed.

Auto Recipe Conversion

Thisfeature(On/Off),automaticallyadjuststhe

programmed recipe temperature in Convection Multi-

Bake mode. Enter into the special features menu as

outlined above. Scroll through the options until “Auto

rEciPE”isdisplayed.Scrollthroughtheoptionsuntilthe

desiredsettingisdisplayed.Press0 to save the setting

and then 6 to exit the menu.

NOTE: This option does not convert baking time, only

temperatures. This option does not adjust temperatures

for Convection Roast mode.

6=Cancel/Back,3=Up,8=Down,0=Save/Forward

Oven Controls

USING THE RANGE: Oven Controls - Special Features

295D1703P022 R ev. 0

USING THE RANGE: Oven Controls - Sabbath Mode - Standard

Oven Controls

SABBATH MODE - STANDARD

This range offers a standard Sabbath mode*. Some of the Sabbath mode features that will be noticed by the

consumerincludethedisablingoftones,disablingofovenlights,anddelaysofabout30secondstooneminute

between a request for a temperature change and its implementation. Only continuous baking or timed baking is

allowed in the Sabbath mode. Cooking in the Sabbath mode is a two-step process, first the Sabbath mode must

be set and then the bake mode must be set. For double ovens, each oven can be set independently by using the

corresponding upper or lower bake pad.

Setting the Sabbath Mode

1. PresstheUpperOvenBake and Broil pads at the

same time and hold until the special features menu is

displayed.

2. Usethe3 or 8 number pads to scroll through the

special features until “SAbbAth” is displayed and then

press 0. Refer to the graphic in the Special Features

section to see how the number keys are mapped.

3. Usethe3 or 8 number pads to scroll through the

options until “On” is shown in the display, then press

the 0numberpadtosavethesetting.Press6 to exit

the Special Features menu. A single bracket “]” will

appear in the display indicating that the Sabbath mode

is set. The clock will not be displayed. Continuous

bake or timed bake can now be programmed.

Starting a Continuous Bake

1. PresstheBake pad.

2. Ifthedesiredtemperatureis350F,pressStart. If

a different cooking temperature is desired, use the

1 through 5 number pads or Timer pad to select a

preset cooking temperature, then press Start. Refer

to the graphic below to determine which pad sets the

desired cooking temperature.

After a delay, a second bracket “] [“ will appear in the

display indicating that the oven is baking.

Adjusting the Temperature

1. PressBake, use the 1 through 5 number pads and

the Timer pad to select a different preset cooking

temperature, and press Start.

2. Since no feedback is given during temperature

change, an oven thermometer can be used to confirm

temperature changes.

Starting a Timed Bake

1. PresstheBake pad.

2. Ifthedesiredtemperatureis350°F,usethe6

through 0 number pads or the Lock Control pad to

select a cooking time. If a cooking temperature other

than350°Fisdesired,usethe1 through 5 number

pads or the Timer pad to select a preset cooking

temperature, then select the cooking time. Refer to

the graphic on this page to determine which pad sets

the desired cooking temperature and cooking time.

3. PressStart.

After a delay, a second bracket “] [“ will appear in the

display indicating that the oven is baking. When the cook

time expires, the display will change back to a single

bracket “]” indicating that the oven is no longer baking.

No tone will sound when the cook time is complete.

Exit the Sabbath Mode

Exiting the Sabbath mode should be done after the

Sabbath is over.

1. PressCancel/Off to end any bake mode that may be

running.

2. PressBake and Broil pads at the same time and

hold until the Special Features menu is displayed.

3. Usethe3 or 8 number pads to scroll through the

special features until “SAbbAth” is displayed, then

press 0.

4. Usethe3 or 8 number pads to scroll through the

options until “OFF” is displayed and press 0 to save

thesetting.Pressthe6 number pad to exit the

Special Features menu.

Sabbath Mode Power Outage Note

If a power outage occurs while the oven is in Sabbath

Mode, the unit will return to Sabbath Mode when power

is restored, however the oven will return to the off state

even if it was in the middle of a bake cycle when the

power outage occurred.

1=170°F,2=200°F,3=250°F,4=300°F,5=325°F,Timer=400°F

6 = 2 hours, 7 = 2.5 hours, 8 = 3 hours, 9 = 3.5 hours,

0=4hours,LockControls=6hours

Temperature(°F) 400

Time(hours)

170

200

2.5h

250

300

3.5h

325

*ThestandardSabbathmodehasnotbeenreviewedorapprovedbyOrthodoxUnion.

295D1703P022 R ev. 0

Rack Positions

Your oven has two rack positions in the upper oven

(A,B)andfourrackpositionsintheloweroven(R,1,

2,3).Recommendedrackpositionsforvarioustypes

of foods are provided in the Cooking Guide. Adjusting

rack position is one way to impact cooking results. For

example, if you would prefer darker tops on cakes,

muffins, or cookies, try moving food one rack position

higher. If you find foods are too brown on top try moving

them down next time.

When baking with multiple pans and on multiple racks,

ensure there is sufficient space between pans to allow

air to flow. This may improve cooking evenness.

Removing and Replacing Flat Racks

When placing and removing cookware, pull the rack out

tothebump(stopposition)ontheracksupport.

To remove a rack, pull it toward you until it reaches the

stop position, tilt up the front of the rack and pull it out.

To replace a rack, place the curved end of the rack onto

the rack supports. Tilt up the front of the rack and push

the rack in until it stops. Then lay the rack flat and push

it in until it is all the way into the oven.

Racks may become difficult to slide, especially after a

self-clean cycle. To improve sliding conditions, use a soft

cloth or paper towel to rub vegetable oil on the left and

rightedgesoftheracksand/orracksupports.

NOTE: Remove unused racks when using the oven for

faster preheat, improved efficiency, and optimal cooking

performance.

Oven Racks

CAUTION

Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat

or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of

these items is not covered by the product warranty.

Foil may be used to catch spills by placing a sheet on a lower rack, several inches below the food. Do not use more

foilthannecessaryandneverentirelycoveranovenrackwithaluminumfoil.Keepfoilatleast1-1/2”fromovenwalls

to prevent poor heat circulation.

Aluminum Foil and Oven Liners

USING THE RANGE:OvenRacks/AluminumFoil

Removing racks

Replacing racks

Rack stop

position

UpperOven

Lower Oven

295D1703P022 R ev. 0

USING THE RANGE:OvenRacks/AluminumFoil

Oven Cooking Modes

Your new oven has a variety of cooking modes to help you get the best results. These modes are described below.

Refer to the Cooking Guide section for rack position and other recommendations for specific modes and foods.

Bake

The traditional bake mode is intended for single rack

cooking. This mode uses heat primarily from the lower

element but also from the upper element to cook food.

Preheatingisgenerallyrecommendedwhenusingthis

mode. To use this mode press the Bake pad, enter a

temperature with the number pads, and then press Start.

Convection Bake

This mode is intended for single rack baking when

additional airflow is desired to enhance evenness.

Preheatingisgenerallyrecommendedwhenusingthis

mode. To use this mode press the Conv Bake pad,

enter a temperature with number pads, and then press

Start.

Convection Roast

This mode is intended for roasting whole cuts of meat

on a single rack. The utilization of all three elements and

direct airflow down from the top of the oven improves

browning and reduces cooking time. Check food earlier

than the recipe suggests when using this mode. To

use this mode press the Conv Roast pad, enter a

temperature with number pads, and then press Start.

Broiling Modes

Always broil with the door closed. The broil element in

this oven is very powerful. Monitor food closely while

broiling.Usecautionwhenbroilingonupperrack

positions as placing food closer to the broil element

increases smoking, spattering, and the possibility of fats

igniting. Broiling on rack position 6 is not recommended.

Broiling can be used for foods that would typically be

grilled.

Adjust the rack position in order to vary the intensity

oftheheattothefood.Placefoodsclosertothebroil

element when a seared surface and rare interior are

desired. For best performance center the food below the

broil heating element.

PresstheBroilpadtwiceforHighoronceforLow

depending on the amount of searing and the internal

temperature that is preferred. The High setting is best for

thinnercutsofmeatand/orfoodsyoupreferlessdone

on the interior. The Low setting is preferred for thicker

cuts of meat and foods you liket o be cooked all the way

through. It is not necessary to preheat the oven for these

modes. Then press Start.

Air Fry

Air Fry is a special, no-preheat, cooking mode that is

designed to produce foods with a crispier exterior than

traditional oven cooking. The Air Fry mode is intended

for single rack cooking only. Select Air Fry, then input

the desired set temperature and press Start. The

temperaturecanbesetbetween300°Fand500°F.

Preheatingisnotrecommendedforthismode.Follow

traditional oven recipe or package guidelines for set

temperatures and cook times; adjust cook time to

achieve your desired crispness. Additional guidelines for

using this mode can be found in the Cooking Guide.

Warm

Warm mode is designed to keep hot foods at a higher

temperatureforupto3hours.Preheatingisnotrequired.

Do not use warm to heat cold food other than crisping

crackers, chips, or dry cereal. It is also recommended

thatfoodnotbekeptwarmformorethan2hours.Press

the Warm pad and then press Start.

295D1703P022 R ev. 0

Oven Air Vents

Neverblockthevents(airopenings)oftherange.They

provide the air inlet and outlet that are necessary for the

range to keep cool and operate properly with correct

combustion.

Air openings are located at the rear of the cooktop, at

the top and bottom of the oven door, and at the bottom

of the range.

Ventappearanceandlocationvary.

USING THE RANGE: OvenAirVents/OvenCookingGuide

Oven Cooking Guide

Cook food thoroughly to help protect against food borne illness. Minimum safe food temperature recommendations

for food safety can be found at IsItDoneYet.gov.Useafoodthermometertomeasurefoodtemperatures.

Oven Cookware Guidelines

The material, finish, and size of cookware affect baking

performance.

Dark, coated and dull pans absorb heat more readily

thanlight,shinypans.Pansthatabsorbheatmore

readily can result in a browner, crisper, and thicker crust.

If using dark and coated cookware check food earlier

than minimum cook time. If undesirable results are

obtained with this type of cookware consider reducing

oventemperatureby25°Fnexttime.

Shiny pans can produce more evenly cooked baked

goods such as cakes and cookies.

Glass and ceramic pans heat slowly but retain heat well.

These types of pans work well for dishes such as pies

and custards.

Air insulated pans heat slowly and can reduce bottom

browning.

Keep cookware clean to promote even heating.

Stoneware heats slowly and retains heat well. It is

recommended to preheat this type of cookware if

possible. Additional cook time may be required.

Cookware used in broil modes and air fry must be broil-

safe.

295D1703P022 R ev. 0

USING THE RANGE: Oven Cooking Guide

Oven Cooking Guide

*When baking four cake layers at a time, stagger the

pans as shown so that one pan is not directly above

another.

Cook food thoroughly to help protect against food

borne illness. Minimum safe food temperature

recommendations for food safety can be found at

IsItDoneYet.gov. Make sure to use a food thermometer

to take food temperatures.

NOTE: Remove unused racks when using the oven for

faster preheat, improved efficiency and optimal cooking

performance.

Front

Placement

Rear

Placement

FOOD TYPE

RECOMMENDED

MODE(S)

OVEN

(Upper/Lower)

RECOMMENDED

RACK POSITION(S)

ADDITIONAL

SUGGESTIONS

Baked Goods

Layer cakes, sheet cakes, bundt

cakes, muffins, quick breads,

biscuits, scones on a Single Rack

Bake

Lower

Upper

Useshinycookware.

Layer cakes* on Multiple Racks Convection Bake Bake Lower 2 and 4

Ensure adequate airflow

(seeillustrationbelow).

Chiffoncakes(angelfood) Bake Lower 2 Useshinycookware.

Cookies, biscuits, scones on a

Single Rack

Bake

Lower

Upper

Useshinycookware.

Cookies, biscuits, scones on

Multiple Racks

Convection Bake

Bake

Lower 2 and 4 Ensure adequate airflow.

Beef & Pork

Hamburgers Broil Hi Upper 2

Useabroilpan;movefooddown

formoredoneness/lesssearing.

Watch food closely when broiling.

Steaks & Chops Broil Hi Upper 2

Useabroilpan;movefooddown

formoredoneness/lesssearing.

Watch food closely when broiling.

Roasts

Convection Roast

Bake

Lower 1or2

Leave uncovered, use a low sided

pan such as a broil pan.

Poultry

Whole chicken

Convection Roast

Bake

Lower 1or2

Leave uncovered, use a low sided

pan such as a broil pan.

Bone-in chicken breasts, legs,

thighs

Broil Lo

Bake

Upper

Lower

If breaded or coated in sauce

avoid Broil Hi modes. Broil skin

side down first. Watch food closely

when broiling.

Boneless chicken breasts

Broil Lo

Bake

Upper

Lower

Watch food closely when broiling.

Whole turkey

Convection Roast

Bake

Lower 1or2

Leave uncovered, use a low sided

pan such as a broil pan. Watch

food closely when broiling.

Turkey Breast Bake Lower 3

Leave uncovered, use a low sided

pan such as a broil pan.

Fish

Broil Lo

Bake

Upper

Lower

Watch food closely when broiling.

Casseroles Bake

Lower

Upper

Frozen Convenience Foods

Pizza,potatoproducts,chicken

nuggets, appetizers on a Single

Rack

Bake

Lower

Upper

Useshinycookware.

Pizza,potatoproducts,chicken

nuggets, appetizers on Multiple

Racks

Convection Bake

Bake

Lower 2 and 4 Useshinycookware.

295D1703P022 R ev. 0

USING THE RANGE: Oven Cooking Guide

Oven Cooking Guide

Air Fry Cooking Guide

Air Fry is a special, no-preheat, cooking mode that

is designed to produce foods with a crispier exterior

than traditional oven cooking. Select Air Fry, then

input the desired set temperature and press Start. The

temperaturecanbesetbetween300°Fand500°F.

Air Fry Cookware Guidelines

• Only use broil safe cookware when using Air Fry mode.

• A dark sheet pan is recommended. A dark pan

promotes better browning and crisping.

• Oven baking baskets and baking grids can also be

used. A sheet pan should be placed on the rack below

the foods to catch any drippings when using a baking

basket.

General Tips for Air Fry Mode

• The Air Fry mode is designed for cooking on a single

rack.

• The Air Fry mode is designed to be used without

preheating.

•Rackposition4isrecommendedformostfoods.Use

rack position 3 for thicker foods.

• Foods may cook faster than expected if the oven is

already hot when food is placed in the oven.

• When air frying foods with sauce, it is recommended to

apply the sauce at the end of cooking.

• If foods are browning too quickly, try a lower rack

position or lower oven set temperature.

• For packaged foods, use traditional oven cooking

instructions for set temperature and expected cook

time.

• It is not necessary to flip or stir food during cooking

• Arrange food in a single layer on the pan, do not

overload the pan.

• Always check internal food temperature to confirm

minimum safe temperatures have been reached.

Minimum safe food temperatures can be found on

packages and at IsItDoneYet.gov.

FOOD TYPE

RECOMMENDED

RACK POSITION(S)

RECOMMENDED

SET TEMPERATURES (F°)

RECOMMENDED

COOK TIME (MIN) NOTES

Fresh boneless fish or

poultry pieces, breaded such

as nuggets, tenders, fillets

4 375-400 15-30

Userlowersettemperaturesforlargerpieces.

Useshinycookware.

Fresh bone in

chicken wings

4 375-400 25-40

Salt wings or coat in a dry rub, if using sauce

apply after cooking or toward the end of cooking

Fresh bone in chicken

drumsticks or thighs

3 or 4 375-400 30-55 Userlowersettemperaturesforlargerpieces.

Fresh French fries,

thin(<½inch)

4 400-425 15-30

Parchmentpaperisrecommendedwhen

preparing fresh French fries. For crispier fries,

toss fries in corn starch or rice flour before

cooking.

Fresh French fries,

thick(>½inch)

3 or 4 375-400 20-35

Parchmentpaperisrecommendedwhen

preparing fresh French fries. For crispier fries,

toss fries in corn starch or rice flour before

cooking.

Frozen packaged

foods

3 or 4

(userackposition3for

thickerfoods)

Usetraditionaloven(notAirFry)cookinginstructionsasaguidelineforsettemperatureandcooktime.Additional

cook time beyond recommended package time may be required for some foods. If oven is hot when starting, food

may cook faster than the minimum package time.

Primaryrecommendedcookware

Alternate cookware options

295D1703P022 R ev. 0

CARE AND CLEANING: Range – Exterior

A child or adult can tip the range and be killed.

Verify the anti-tip bracket has been properly installed

and engaged.

Ensure the anti-tip bracket is re-engaged when the range

is moved.

Do not operate the range without the anti-tip bracket in

place and engaged.

Failure to follow these instructions can result in death or

serious burns to children or adults.

Tip-Over Hazard

WARNING

Range – Exterior

WARNING

If your range is removed for cleaning, servicing or any reason, be sure the

anti-tip device is reengaged properly when the range is replaced. Failure to

take this precaution could result in tipping of the range and can result in death

or serious burns to children or adults.

Be sure all controls are off and all surfaces are cool before cleaning any part of the range.

Control Lockout

If desired, the touch pads may be deactivated before

cleaning.

See Lock Controls in the Oven Controls section in this

manual.

Clean up splatters with a damp cloth.

You may also use a glass cleaner.

Remove heavier soil with warm, soapy water. Do not use

abrasives of any kind.

Reactivate the touch pads after cleaning.

Control Panel

It’s a good idea to wipe the control panel after each use.

Clean with mild soap and water or vinegar and water,

rinse with clean water and polish dry with a soft cloth.

Do not use abrasive cleansers, strong liquid cleansers,

plastic scouring pads or oven cleaners on the control

panel—theywilldamagethefinish,includingBlack

Stainless Steel.

Oven Exterior

Do not use oven cleaners, abrasive cleansers, strong

liquid cleansers, steel wool, plastic scouring pads, or

cleaning powders on the interior or exterior of the oven.

Clean with a mild soap and water or vinegar and water

solution. Rinse with clean water and dry with a soft cloth.

When cleaning surfaces, make sure that they are at

room temperature and not in direct sunlight.

If stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Spillage of marinades, fruit juices, tomato sauces and

basting liquids containing acids may cause discoloration

and should be wiped up immediately. Let hot surfaces

cool, then clean and rinse.

Painted Surfaces

Paintedsurfacesincludethesidesoftherangeandthe

door, top of control panel and the drawer front. Clean

these with soap and water or a vinegar and water solution.

Do not use commercial oven cleaners, cleaning

powders, steel wool or harsh abrasives on any painted

surface, including Black Stainless Steel.

Stainless Steel excluding Black Stainless Steel (on some models)

Do not use a steel wool pad; it will scratch the surface.

Cleaners with oxalic acid such as Bar Keepers Friend

SoftCleanser™willremovesurfacerust,tarnishand

smallblemishes.Useonlyaliquidcleanserfreeofgrit

and rub in the direction of the brush lines with a damp,

soft sponge.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always wipe

the surface in the direction of the grain. Follow the cleaner

instructions for cleaning the stainless steel surface.

To inquire about purchasing cleaning products including

stainless steel appliance cleaner or polish, see the

Accessories and Consumer Support sections at the end

of this manual.

295D1703P022 R ev. 0

CARE AND CLEANING: Range – Interior

The interior of your new oven can be cleaned manually or by using Steam Clean or Self Clean modes.

Spillage of marinades, fruit juices, tomato sauces and basting liquids containing acids may cause discoloration and

should be wiped up immediately. Let hot surfaces cool, then clean and rinse.

Manual Cleaning

Do not use oven cleaners, strong liquid cleansers, steel

wool, or scouring pads on the interior of the oven. For

soils on the oven bottom and other enameled surfaces,

use a gentle abrasive containing oxalic acid, such as

Bar Keepers Friend

, with a non-scratch sponge. Take

care not to apply any abrasive cleaners or sponges to

the door glass, as it will scratch the reflective coating.

The oven interior and door glass may be cleaned using

a soft cloth with a mild soap and water, or vinegar and

water solution. After cleaning, rinse with clean water and

dry with a soft cloth.

Range – Interior

Steam Clean Mode

The Steam Clean feature is for cleaning light soil from

your oven at a lower temperature than Self Clean.

To use the Steam Clean feature:

1.Startwiththeovenatroomtemperature.

2. Wipe excess grease and soils from the oven.

3.Pouronecupofwaterontothebottomoftheoven.

4. Close the door.

5.PresstheClean pad, select Steam Clean and

then press Start.

Donotopenthedoorduringthe30minuteSteamClean

cycle. At the end of the Steam Clean cycle, soak up the

remaining water, and wipe the moisture-softened soil

from the oven walls and door.

Self Clean Mode

Read Self-Cleaning Oven Safety Instructions at the

beginning of this manual before using the Self Clean

Mode. Self Clean uses very high temperatures to clean

the oven interior. For a moderately soiled oven, run a

3 hour self-clean cycle. For a heavily soiled oven, run

a5hourself-cleancycle.Onlyself-clean(black)racks

and grates may remain in the oven during the self-clean

cycle.Allotheritems,includingnickelplated(silver)

racks,shouldberemoved.Ifnickelplated(silver)racks

are left in the oven during a self-clean cycle, the racks

will tarnish. If either type of rack is left in the oven during

a self-clean cycle, the rack may become difficult to slide.

See the Oven Racks section for instructions on how to

improve.

IMPORTANT: The health of some birds is extremely

sensitive to the fumes given off during the self-cleaning

cycle of any range. Move birds to another well-ventilated

room.

To use the Self Clean feature:

1.Startwiththeovenatroomtemperature.

2. Wipe excess grease and soils from the oven and

interior door.

3.Removeallitemsotherthanself-clean(black)

racks and grates, if desired. See Cleaning the

Cooktop to determine if your grates may be self-

cleaned and for important details regarding grate

placement.

4. Close the door.

5.PresstheClean pad, select Self Clean and then

press Start.

You cannot open the door during the self-clean cycle.

The door will remain locked after the self-clean cycle

until the oven cools below the unlocking temperature.

At the end of the self-clean cycle, allow the oven to cool

and wipe any ash out of the oven.

Racks

All racks can be washed with warm, soapy water.

Enameled(notshiny)rackscanbeleftinthecavity

during self clean.

Racks may be more difficult to slide, especially after

aself-clean.Putsomevegetableoilonasoftclothor

paper towel and rub onto the left and right edges.

295D1703P022 R ev. 0

CARE AND CLEANING: Cooktop

Removal of Surface Burners for Cleaning

Turn all controls OFF. Allow cooktop to cool before removing grates and burner parts. When removing the burner

caps and heads, remember their size and location. Replace them in the same location after cleaning.

CAUTION

Do not attempt to remove oval burner cap from the burner heads.

Cooktop

Round Burner

Round Burner Cap

(Removable)

Electrode

Round

Burner

Head

Cleaning the Surface Burners

Cleaning the Burner Caps

Wash burner caps in hot, soapy water and rinse with

clean water. You may scour with a plastic scouring pad

to remove burned-on food particles. The round burner

caps may also be cleaned in your dishwasher.

Cleaning the Burner Heads

Wash the burner heads routinely, especially after bad

spillovers which could clog the burner openings. Lift

burners off when cool. Wash with hot, soapy water. Rinse

with clean water. For more stubborn stains, use a brush

with plastic bristles.

NOTE: Do not use steel wool or scouring pads to clean

the burner parts as these may clog the openings. Never

wash burner heads in your dishwasher as dishwasher.

Doing so may cause them to discolor.

The ports in the burner heads must be kept clean at all

times for an even, unhampered flame.

Clogged or dirty burner ports or electrodes will not allow

the burner to operate properly.

Replacing Surface Burners

Before replacingtheburnercaps,headsandovalhead/

cap assembly, shake out excess water and allow them to

dry thoroughly.

Replace burner heads in the correct locations according

to size. Ensure each cap is properly seated on the

burner head, as pictured below.

CAUTION

Do not operate the cooktop without

all burner parts and grates in place.

Any spill on or around an electrode must be carefully

cleaned. Avoid hitting the electrode with anything hard or

it could be damaged.

The electrode of the spark igniter is exposed

when the burner head is removed. When one

burner is turned to LITE, all the burners spark.

Do not attempt to disassemble or clean around

any burner while another burner is on.

Electrode

Oval Burner

Oval Burner Cap

(Non-Removable)

Oval

Burner

Head

Electrode

Burner cap is

properly seated.

Burner cap is

NOT properly

seated.

Burner cap is

NOT properly

seated.

Round hole in

burner head must

be kept clear

Multi-Ring Burner

Inner Burner Cap

(Removable)

Outer Burner Cap

(Removable)

Round

Burner

Head

Electrode

295D1703P022 R ev. 0

CARE AND CLEANING: Cooktop

Cooktop (Cont.)

Griddles

Aluminum and Reversible Cast-Iron: Clean your

reversible cast-iron griddle with a stiff brush and hot

water.Usingsoapisnotrecommended,andharsh

detergents should never be used as they will remove

the seasoning. Rinse with hot water and dry thoroughly.

After rinsing, preseason the griddle by applying a light

coat of cooking oil to the griddle surface. Wipe off

excess oil with a paper towel.

Store in a cool, dry place.

Griddle Precautions:

■ If something has spilled under the griddle, it should

be cleaned up as soon as possible to prevent the

spill from getting baked onto the cooktop.

■ Do not allow grease to accumulate under the griddle

as it can be a fire hazard. Clean under the griddle

with hot, soapy water as soon as it is cool.

■ Do not wash your griddle in the dishwasher.

■ Donotcleanthegriddleintheself-cleaningoven.

Grate Support Bumpers

      

To insert the new bumpers, simply place the cone-

shaped end of the bumper into the hole in the cooktop

and push down while gently twisting the bumper.

Grate Support Bumpers

Burner Grates

Manual Cleaning

Grates should be washed in hot, soapy water and

rinsed with clean water. To soften burned-on food,

place grates in a solution containing ¼-cup of

household ammonia for several hours. Afterward, scrub

grates with a plastic scouring pad soaked in hot, soapy

water. Rinse well and dry.

Self Clean Mode

If your grates do not have rubber bumpers on their

bottom surface, they may be cleaned in the oven using

the self-clean cycle. Do not attempt to clean your grates

in the oven if your grates have rubber bumpers. Doing

so will destroy the rubber bumpers and may affect the

function of your surface burners.

Porcelain-coatedgratesmaygraduallydullifcontinually

exposed to self-clean temperatures.

Ifyourovenisequippedwithself-clean(black)racks,

it is recommended to follow the instructions for placing

grates on racks. If your oven is equipped with nickel-

plated(silver)racks,itisrecommendedtofollowthe

instructions for placing grates on the oven bottom.

Nickel-plated racks should not remain in the oven during

the self clean cycle. Doing so will tarnish the racks. If

either type of rack is left in the oven during a self-clean

cycle, the rack may become difficult to slide.

NOTE: When placing or removing grates from the oven,

do not slide the grates on the racks or oven bottom.

Doing so could damage the enamel on the racks or oven

bottom.

To self-clean your grates on self-clean racks:

1. Insertracksinpositions1,3,and5orpositions2and4.

2. Gently place one grate on each rack.

NOTE: DO NOT operate your cooktop during the

Self Clean Mode because the Self Clean cycle will be

canceled.

To self clean your grates on the oven bottom:

1. Removeallovenracks.

2. Gently place one grate on the center of the oven

bottom with the grate oriented in the upright position.

Stackremaininggrate(s)asshownbelow.Donot

place or stack grates in any other configuration or in

the upper oven.

Once the grates are placed in the oven, operate the self-

clean cycle per the instruction in the Cleaning the Oven

section.

NOTE:Usecautionwhenremovingthegratesfromthe

oven after the self-clean cycle has ended. The grates

may still be hot.

Once the self-clean cycle is complete, the grates may

carefully be removed. You may notice a white residue on

the grates. Wipe it off with a damp sponge. If white spots

persist,wetthespongewitha50/50solutionofvinegar

and water and wipe the grates again.

When replacing the grates on the cooktop, be sure to locate

them correctly. Grates should fit securely into the cooktop.

295D1703P022 R ev. 0

If any of the rubber grate support bumpers in the cooktop

are missing or damaged, replacement parts can be

obtained by calling GE Ap plian ces at 1.800.661.1616

CARE AND CLEANING: Oven Door

Cleaning the Oven Door

Cleaning the Door Interior

Do not allow excess water to run into any holes or slots

in the door .

Wipe dish soap over any baked-on spatters on the glass.

Useasinglesidedsafetyrazorbladetocleanitoff.Then

wipe over the glass with a soapy cloth to remove any

residue and dry off.

The area outside the gasket can be cleaned with a soap-

filled plastic scouring pad. Do not rub or clean the door

gasket - it has an extremely low resistance to abrasion.

If you notice the gasket becoming worn, frayed or

damaged in any way or if it has become displaced on the

door, you should have it replaced.

Cleaning the Door Exterior

If a stain on the door vent trim is persistent, use a mild

abrasive cleaner and a sponge-scrubber for best results.

Do not use this method on any other surface.

Stainless Steel Surfaces

Do not use a steel wool pad; it will scratch the surface.

To clean the stainless steel surface, use warm sudsy

water or a stainless steel cleaner or polish. Always wipe

the surface in the direction of the grain. Follow the cleaner

instructions for cleaning the stainless steel surface.

To inquire about purchasing cleaning products

including stainless steel appliance cleaner or polish,

see the Accessories and Consumer Support sections

at the end of this manual.

Oven Door

Lift-Off Lower Oven Door

The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.

To Remove the Door:

1. Fullyopenthedoor.

2. Pullthehingelocksupandawayfromtherange

frame to the unlocked position.

3. Firmly grasp both sides of the door near the top.

4. Close door until the top of the door is approximately

6” from the range frame.

5. Lift door up and away from the range until both hinge

arms are clear of the slots in the range frame.

To Replace the Door:

1. Firmlygraspbothsidesofthedoornearthetop.

2. With the door at the same angle as the removal

position, rest the notch on the underside of the left

hinge arm on the bottom edge of the left hinge slot.

The notch in the hinge arm must be fully seated into

the bottom of the slot. Repeat for the right side.

3. Fully open the door. If the door will not fully open, the

notches in the bottoms of the hinge arms have not

seated correctly in the bottom edge of the slot. Lift the

door off the range and repeat previous step.

4. Pushthehingelockstowardtherangecavityand

down to the locked position.

5. Close the oven door.

Removal positionPullhingelocksuptounlock

PushhingelocksdowntolockRest notch on bottom edge

of hinge slot

Notch

Bottom

edge of

slot

Hinge arm

295D1703P022 R ev. 0

CARE AND CLEANING: Oven Door

Oven Door

Lift-Off Upper Oven Door

The door is very heavy. Be careful when removing and lifting the door. Do not lift door by the handle.

To Remove the Door:

1. Fullyopenthedoor.

2. Lift up on the hinge lock toward the oven frame until

they stop.

3. Closethedoorto45degrees(youwillfeelthedoor

stop).Thehingelockwillcontacttheovenframe.

4. On both sides of the door, press down on the release

buttons on each hinge.

5. Lift door up until it is clear of the hinge.

6. Pullonhingearmsslightlytorelievepressureonthe

locking tabs.

7. Pushthehingelocksdownonto

the hinge.

8. Pushthehingesintowardtheunit

so they are closed.

To Replace the Door:

1. Pullthehingesdownawayfromtheovenframeto

the fully open position.

2. Lift up on the hinge locks toward the oven frame until

they stop.

3. The hinges will release to the 45-degree position. The

hinge locks will contact the oven frame.

4. Slide the door back onto the hinges. Make sure the

buttons pop back out.

5. Fully open the door.

6. Pushthehingelocksdownontothehinge.

7. Close the oven door.

Oven

frame

Door

frame

Release

buttons

Pulldown

Pushin

295D1703P022 R ev. 0

CARE AND CLEANING: Oven Light

NOTE: The glass cover should be removed only when

cold. Wearing latex gloves may offer a better grip.

Before replacing the bulb, disconnect electrical power to

the oven at the main fuse or circuit breaker panel. Let

the bulb cool completely before removing it. For your

safety do not touch a hot bulb with a damp cloth. If you

do the bulb may break.

To remove:

Turntheglasscovercounterclockwise1/4turnuntilthe

tabs of the glass cover clear the grooves of the socket

and pull the cover off. Remove the bulb.

To replace:

Putinanew40-wattappliancebulb.Placethetabsof

the glass cover into the grooves of the socket. Turn the

glasscoverclockwise1/4turn.

NOTE:

■ A40-wattappliance

bulb is smaller than

astandard40-watt

household bulb.

■ Reconnectelectrical

power to the oven

once the new bulb is

installed.

■ Forimprovedlighting

inside the oven,

clean the glass cover

frequently using a wet

cloth. This should be

done when the oven is

completely cool.

WARNING

SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical power to the

range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.

CAUTION

BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with

bare hands or a damp cloth can cause burns.

Oven Light

Bulb

Socket

Tab

⁄

”

Max

length

Glass cover

295D1703P022 R ev. 0

TROUBLESHOOTING TIPS

Problem Possible Cause What To Do

My new oven doesn't

cook like my old one.

Is something wrong

with the temperature

settings?

Your new oven has a different cooking system

from your old oven and therefore may cook

differently than your old oven.

For the first few uses, follow your recipe times

and temperatures carefully and use rack

positions recommended in the Cooking Guide.

If you still think your new oven is too hot or too

cold, you can adjust the temperature yourself

to meet your specific cooking preference. See

the Settings section.

Food does not bake

properly

Oven controls improperly set. See the Cooking Modes section.

Rack position is incorrect or rack is not level. See the Cooking Modes section and Cooking

Guide.

Incorrect cookware or cookware of improper

size being used.

See the Cookware section.

Oven temperature needs adjustment. See the Settings section.

Food does not broil

properly

Oven controls improperly set. Make sure you select the appropriate broil

mode.

Improper rack position being used. See Cooking Guide for rack location

suggestions.

Cookware not suited for broiling. Useapanspecificallydesignedforbroiling.

Aluminum foil on the broil pan has not been

fitted properly or slit to drain grease.

If using aluminum foil on broil pan, wrap tightly

and add slits conforming to those in the pan to

allow grease to drain.

Oven temperature too

hot or too cold

Oven temperature needs adjustment. See the Oven Controls section.

Oven and/or display

appears not to work

A fuse in your home may be blown or the

circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Oven controls improperly set. SeetheUsingtheOvensection.

Oven is in Sabbath Mode. Verify,thattheovenisnotinSabbathMode.

See the Sabbath Mode section.

The clock is turned off. See the Settings section.

“Crackling” or

“popping” sound

This is the sound of the metal heating and

cooling during both the cooking and cleaning

functions.

This is normal.

Why is my range

making a "clicking"

noise when using my

oven?

Your range has been designed to maintain a

tighter control over your oven's temperature.

You may hear your oven's heating elements

"click" on and off more frequently than in

older ovens to achieve better results during

baking, broiling, and self-clean cycles.

This is normal.

Sometimes the

oven takes longer to

preheat to the same

temperature

Cookware, food, and/or number of racks in

oven.

Cookware, food, and racks in the oven will

cause differences in preheat times. Remove

excess items to reduce preheat time.

Troubleshooting Tips ... Before you call for service

Save time and money! Review the charts on the following pages first and you may not need to call for service.

295D1703P022 R ev. 0

TROUBLESHOOTING TIPS

Troubleshooting Tips ... Before you call for service

Problem Possible Cause What To Do

Oven light does not

work

Light bulb is loose or defective. Tighten or replace bulb. See the Maintenance section for

instructions on how to replace the bulb.

Oven will not self-clean The temperature is too high to set

a self-clean operation.

Allow the oven to cool and reset the controls.

Oven controls improperly set. See the Cleaning the Oven section.

Excessive smoking

during clean cycle

Excessive soil or grease. Pressthe Cancel/Off pad. Open the windows to rid the

room of smoke. Wait until the LOCKED light goes off.

Wipe up the excess soil and reset the clean cycle.

Oven not clean after a

clean cycle

Oven controls improperly set. See the Cleaning the Oven section.

Oven was heavily soiled. Clean up heavy spillovers before starting the clean cycle.

Heavily soiled ovens may need to self-clean again or for

a longer period of time.

Strong “burning” or

“oily” odor emitting

from the vent

This is normal in a new oven and

will disappear in time.

To speed the process, set a self-clean cycle for a

minimum of 3 hours. See the Cleaning the Oven section.

This is temporary.

Excessive smoking

during broiling

Food too close to burner element. Lower the rack position of the food.

Oven door will not open

or LOCKED light is on

when you want to cook.

The oven door is locked because

the temperature inside the oven

has not dropped below the locking

temperature.

PresstheCancel/Off pad. Allow the oven to cool below

the locking temperature.

"LOCK DOOR" flashes

in the display

The self-clean cycle has been

selected but the door is not closed.

Close the oven door.

“F— and a number

or letter” flash in the

display

You have a function error code. PresstheCancel/Off pad. Allow the oven to cool for one

hour.Puttheovenbackintooperation.Ifthefunctioncode

repeats,disconnectallpowertotheovenforatleast30

seconds and then reconnect power. If the function error code

repeats again, call for service.

Power outage, clock

flashes

Power outage or surge Reset the clock. If the oven was in use, you must reset

it by pressing the Cancel/Off pad, setting the clock and

resetting any cooking function.

Lock Controls or

Control Lockout feature

is activated

If LOC ON appears in the display, the range control is

locked. Turn this feature off to use the range. See the

Lock Control feature in the Oven Controls section.

Burners do not light Plug on range is not completely

inserted in the electrical outlet.

Make sure electrical plug is plugged into a live, properly

grounded outlet.

Gas supply not connected or

turned on.

See the Installation Instructions that came with your

range.

A fuse in your home may be blown

or the circuit breaker tripped.

Replace the fuse or reset the circuit breaker.

Burner parts not replaced correctly. See the Care and Cleaning of the range section.

Burner slots near the electrode, or

the round lighter port on the oval

burner, may be clogged.

Remove the burners and clean them. Check the

electrode area for burned-on food or grease. See the

Care and Cleaning of the range section.

Food residue on electrode Lightly polish flat tip of electrode with nail file or

sandpaper until shiny.

295D1703P022 R ev. 0

TROUBLESHOOTING TIPS

Troubleshooting Tips ... Before you call for service

Problem Possible Cause What To Do

Top burners do not

burn evenly

Improper burner assembly. Make sure the burner caps are seated correctly. See the Care and

Cleaning of the range section.

Burner slots on the side of the

burner may be clogged.

Remove the burners for cleaning. See the Care and Cleaning of

the range section.

Burner flames are

very large or yellow

Improper air to gas ratio. IfrangeisconnectedtoPropanegas,contactthetechnician

who installed your range or made the conversion.

Surface burners light

but bake and broil

burners do not.

Gas to the oven burners may

have been shut off.

The oven gas shut-off is located on the gas regulator near the

gas line attachment to your range. Locate it and flip the lever.

My oven door glass

appears to be

"tinted" or have a

"rainbow" color.

The inner oven glass is coated

with a heat barrier to reflect

the heat back into the oven to

prevent heat loss and keep the

outer door cool while baking.

Thisisnormal.Undercertainlightorangles,youmayseethis

tint or rainbow color.

Drawer does not slide

smoothly or drags

The drawer is out of alignment. Fully extend the drawer and push it all the way in. See the Care

and Cleaning of the range section.

Drawer is over-loaded or load is

unbalanced.

Reduce weight or redistribute drawer contents.

Lever is

shown closed.

PULLTOOPEN.

Sealed burner models

295D1703P022 R ev. 0

Notes

295D1703P022 R ev. 0

        

Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory

service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its

products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be

sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.

■ Service trips to your home to teach you how to use

the product.

■ Improperinstallation,delivery,ormaintenance.

■ Failureoftheproductifitisabused,misused,

modified, or used for other than the intended purpose

or used commercially.

■ Replacementofhousefusesorresettingofcircuit

breakers.

■ Damagetotheproductcausedbyaccident,fire,

floods, or acts of God.

■ Damagetofinish,suchassurfacerust,tarnish,or

small blemishes not reported within 48 hours of

delivery.

■ Incidentalorconsequentialdamagecausedby

possible defects with this appliance.

■ Damagecausedafterdelivery.

■ Productnotaccessibletoproviderequiredservice.

■ Servicetorepairorreplacelightbulbs,exceptforLED

lamps.

EXCLUSION OF IMPLIED WARRANTIES

Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,

including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or

the shortest period allowed by law.

This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for home

usewithintheUSA.IftheproductislocatedinanareawhereservicebyaGEAppliancesAuthorizedServicerisnot

available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE

Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service calls to

your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This

limited

warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your

legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Extended Warranties:PurchaseaGEAppliancesextendedwarrantyandlearnaboutspecialdiscountsthatare

available while your warranty is still in effect. You can purchase it online anytime at

orcall800.626.2224duringnormalbusinesshours.GEAppliancesServicewillstillbethereafteryourwarrantyexpires.

For the period of

One year

From the date

of the original

purchase

Any part of the range which fails due to a defect in materials or workmanship. During this

limited one-year warranty, GE Appliances will provide, free of charge, all labor and in-home

service to replace the defective part.

Stapleyourreceipthere.Proofoftheoriginalpurchase

date is needed to obtain service under the warranty.

LIMITED WARRANTY

GE Appliances Gas Range Limited Warranty

Warrantor: MC Commercial Inc.

Burlington ON. LR7 5B6

What MC Commercial will not cover:

www.geappliance.ca/en/support/purchase-extended-warranty

MC Commercial will replace

All warranty service is provided by our Factory Service Centers, or an authorized Customer Care® technician. To schedule

service online, visit us at www.geappliances.ca/en/support/service-request or call GE Appliances at (800.561.3344.

Please have your serial number and your model number available when calling for service.

GEAppliances.ca/en/

295D1703P022 R ev. 0

ACCESSORIES

Looking For Something More?

GE Appliances offers a variety of accessories to

improve your cooking and maintenance experiences!

Refer to the Consumer Support page for phone numbers

and website information.

The following products and more are available:

Accessories

Nickel Flat Rack

Reinforced Nickel Flat Rack

Self Clean Flat Rack

Nickel Extension Rack

Self Clean Extension Rack

 BroilerPan(12¾”x1¼”x16½“)

Roasting Rack Accessory

Cooktop Center Grate

Nonstick Aluminum Griddle

Reversible Cast-Iron Griddle

Cleaning Supplies

 CitruShine™StainlessSteelWipes

 StainlessSteelPolishingCloth

Burnt-On Grease Remover

295D1703P022 R ev. 0

Consumer Support

GE Appliances Website

       

           

Schedule Service

         

     

Extended Warranties

               

    

     

Remote Connectivity

         

     

Parts and Accessories

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes

(VISA,MasterCardandDiscovercardsareaccepted).Orderon-linetoday24hourseveryday.

  

If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the

details including your phone number, or write to:

              

PrintedinMexico

CONSUMER SUPPORT

https:// www.geappliances.ca/en/contact-us

General Manager, Customer Relation | MC Commercial Inc. Burlington ON. L7R 5B6

Instructions contained in this manual cover procedures to be performed by any user. Other servicing

generally should be refe rred to qualified service personnel. Caution must be exercised, since improper

servicing may cause unsafe operation.

For assistance with wireless network connectivity (for models with remote enable), visit our website at

https://www.geappliances.ca/en/contact-us or call 800.220.6899.

https://www.geappliances.ca/en/products/parts-filters-accessories or by phone at 1-800-661-1616 during normal

business hours.

Purchase a GE Appliances extended warranty and learn about special discounts that are available while your

warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your

warranty expires. www.geappliances.ca/en/support/purchase-extended-warranty or call 866.277.9842 during

normal business hours.

Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at

your convenience any day of the year. https://www.geappliances.ca/en/support/service-request

or call 800.561.3344 during normal business hours.

communication and prompt service under the terms of your warranty, should the need arise. You may also mail in

the pre-printed registration card included in the packing material.

https://www.geappliances.ca/support/register-your-appliance

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day

of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support

services designed for your convenience. GEAppliances.ca/en/

295D1703P022 Rev. 0

GE - General Electric PCGB965YPFS GE Profile 30" Double Oven Gas Range

Product's Documents

User Manual

Specifications

GE - General Electric PCGB965YPFS Questions and Answers
