KOFFP46TK
KOFFP46TX
EN
User Manual | Oven
INSTALLATION
min. 550
20
595
+-1
18
590
min. 560
594
589
114
21548
3
5
70
60
520
60
20
198
523
(*mm)
18
594
589
114
21548
595
+-1
min. 550
20
600
min. 560
3
5
60
20
80
520
60
198
523
(*mm)
2
Welcome to Electrolux! Thank you for choosing our appliance.
In our drive to be sustainable, we are reducing paper assets and provide full user
manuals online. Access your full user manual at electrolux.com/manuals
Get usage advice, brochures, trouble shooter, service and repair information at
electrolux.com/support
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the product in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
• If the appliance has a child safety device, it should be
activated.
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
ENGLISH 3
• This appliance may be used in offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements or the surface of the oven cavity.
• Always use oven gloves to remove or put in accessories or
ovenware.
• To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence (if
applicable).
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• Use only the food sensor (core temperature sensor)
recommended for this appliance (if applicable).
• Remove all accessories and excessive spillage from the
appliance before the pyrolytic cleaning.
2. SAFETY INSTRUCTIONS
2.1 Installation and Electrical
connection
WARNING!
Only a qualified person must install and
connect this appliance.
Follow the installation instructions supplied
with the appliance.
Install the appliance in a safe and suitable
place that meets installation requirements.
Do not use the appliance before installing it in
the built-in structure.
Keep the minimum distance from other
appliances and units. Before mounting the
appliance, check if the oven door opens
without restraint.
Do not install or use a damaged appliance.
Remove all the packaging.
Always take care when moving the appliance
as it is heavy. Do not pull the appliance by
the handle. Always use safety gloves and
enclosed footwear.
The appliance is equipped with an electric
cooling system. It must be operated with the
electric power supply.
4 ENGLISH
WARNING!
Risk of fire and electric shock.
Make sure that the parameters on the rating
plate are compatible with the electrical ratings
of the mains power supply.
The appliance must be earthed. Always use a
correctly installed shockproof socket.
Do not use multi-plug adapters and extension
cables.
This appliance is supplied without a main
plug and a main cable.
Do not let mains cables touch or come near
the appliance door or the niche below the
appliance, especially when it operates or the
door is hot.
Use only correct isolation devices: line
protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips
and contactors.
The electrical installation must have an
isolation device which lets you disconnect the
appliance from the mains at all poles. The
isolation device must have a contact opening
width of minimum 3 mm.
For the section of the cable refer to the total
power on the rating plate. You can also refer
to the table:
Cable types applicable for installation or re‐
placement for Europe:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, H05
V2V2-F (T90), H05 BB-F
Total power (W) Section of the cable
(mm²)
maximum 1380 3 x 0.75
maximum 2300 3 x 1
maximum 3680 3 x 1.5
2.2 Use and Maintenance
WARNING!
Risk of injury, burns, electric shock, fire,
explosion or damage to the appliance.
Do not change the specification of this
appliance.
Do not let the appliance stay unattended
during operation. Deactivate the appliance
after each use.
Make sure that the ventilation openings are
not blocked.
If the appliance is installed behind a furniture
panel (e.g. a door) make sure the door is
never closed when the appliance operates.
Heat and moisture can build up behind a
closed furniture panel and cause subsequent
damage to the appliance, the furniture or the
floor. Do not close the furniture panel until the
appliance has cooled down after use.
Be careful when you open the appliance door
while the appliance is in operation. Hot air
can release.
Do not operate the appliance with wet hands
or when it has contact with water.
Do not apply pressure on the open door. Be
careful when you remove the door from the
appliance. The door is heavy.
Do not use the appliance as a work surface
or as a storage surface.
Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
When you place food into hot oil, it may
splash.
Always cook with the oven door closed. Open
the appliance door carefully. The use of
ingredients with alcohol can cause a mixture
of alcohol and air.
Always use glass and jars approved for
preserving purposes.
Do not let sparks or open flames to come in
contact with the appliance when you open the
door.
Do not share your Wi-Fi password (if
applicable).
To prevent damage or discoloration to the
enamel:
• do not put ovenware or other objects in
the appliance directly on the bottom.
• do not put aluminium foil directly on the
bottom of cavity of the appliance.
ENGLISH 5
• do not put water directly into the hot
appliance.
• do not keep moist dishes and food in the
appliance after you finish the cooking.
• be careful when you remove or install the
accessories.
Use a deep pan for moist cakes. Fruit juices
cause stains that can be permanent.
Discoloration of the enamel or stainless steel
has no effect on the performance of the
appliance.
Clean regularly the appliance to prevent the
deterioration of the surface material.
Before maintenance, deactivate the appliance
and disconnect from the mains. Do not clean
the catalytic enamel (if applicable) with
detergents.
Make sure the appliance is cold. There is the
risk that the glass panels can break. Replace
immediately the door glass panels when they
are damaged. Contact the Authorised Service
Centre.
Clean the appliance with a moist soft cloth.
Use only neutral detergents. Do not use
abrasive products, abrasive cleaning pads,
solvents or metal objects.
Do not clean the catalytic enamel with
detergents (if applicable).
If you use an oven spray, follow the safety
instructions on its packaging.
Concerning the lamp(s) inside this product
and spare part lamps sold separately: These
lamps are intended to withstand extreme
physical conditions in household appliances,
such as temperature, vibration, humidity, or
are intended to signal information about the
operational status of the appliance. They are
not intended to be used in other applications
and are not suitable for household room
illumination.
Use only lamps with the same specifications.
This product contains a light source of energy
efficiency class G.
To repair the appliance contact the
Authorised Service Centre. Use original spare
parts only.
2.3 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires / Chemical
Emissions (Fumes) in Pyrolytic Mode.
Do not start the Pyrolysis if the Plus
Steam button is pressed in ( if
applicable).
Before carrying out the pyrolytic cleaning and
initial preheating remove from the oven
cavity:
• any excess food residues, oil or grease
spills / deposits.
• any removable objects (including shelves,
side rails etc., provided with the product)
particularly any non-stick pots, pans, trays,
utensils etc.
Pyrolytic cleaning is a high temperature
operation that can release fumes from
cooking residues and construction materials,
as such consumers are advised to:
• provide good ventilation during and after
each pyrolytic cleaning.
• provide good ventilation during and after
the first use at maximum temperature
operation.
If there are other appliances installed in the
same cabinet, do not use them at the same
time as the pyrolytic cleaning. It can cause
damage to the oven.
Fumes released from all pyrolytic ovens /
cooking residues as described are not
harmful to humans, including children, or
persons with medical conditions.
Keep away small pets from the appliance
during and after the pyrolytic cleaning and
initial preheating. Birds and reptiles can be
highly sensitive to the temperature changes
and emitted fumes.
Non-stick surfaces on pots, pans, trays,
utensils etc., can be damaged by the high
temperature pyrolytic cleaning operation of all
pyrolytic ovens and can be also a source for
low level harmful fumes.
6 ENGLISH
2.4 Disposal
WARNING!
Risk of injury or suffocation.
Disconnect the appliance from the mains
supply.
Cut off the mains electrical cable close to the
appliance and dispose of it.
3. PRODUCT DESCRIPTION
3.1 General overview
6
5
9
7
8
5
4
1
2
3
31 42
1
Control panel
2
Knob for the heating functions
3
Display
4
Control knob
5
Heating element
6
Lamp
7
Fan
8
Shelf support, removable
9
Shelf positions
4. CONTROL PANEL
4.1 Turning the appliance on and off
To turn on the appliance:
1. Press the knobs. The knobs come out.
2. Turn the knob for the heating functions to
select a function.
3. Turn the control knob to adjust settings.
To turn off the appliance: turn the knob for the
heating functions to the off position .
4.2 Control panel overview
Press to set timer functions.
Press and hold to set the function:
Fast Heat Up.
Press to turn the appliance lamp on
and off.
Press and hold to set the function:
Lock.
Press to confirm your selection.
4.3 Display indicators
Display with key functions.
The appliance is locked.
Enter the menu and select the icon to
open: Assisted Cooking.
Enter the menu and select the icon to
open: Cleaning.
Enter the menu and select the icon to
open: Settings
ENGLISH 7
Fast Heat Up is turned on.
Minute minder is turned on.
End time is turned on.
Time Delayed Start is turned on.
Uptimer is turned on.
For temperature or time. The bar is fully
red when the appliance reaches the set
temperature.
5. BEFORE FIRST USE
5.1 Setting the time
After the first connection to the mains, wait
until the display shows: "00:00".
1. Turn the control knob to set the time.
2. Press .
5.2 Initial preheating and cleaning
Preheat the empty appliance before the first
use and contact with food. The appliance can
emit unpleasant smell and smoke. Ventilate
the room during preheating.
1. Remove all accessories and removable
shelf supports from the appliance.
2. Set the function
. Set the maximum
temperature. Let the appliance operate
for 1 h.
3. Set the function . Set the maximum
temperature. Let the appliance operate
for 15 min.
4. Set the function . Set the maximum
temperature. Let the appliance operate
for 15 min.
5. Turn off the appliance and wait until it is
cold.
6. Clean the appliance and the accessories
only with a microfibre cloth, warm water
and a mild detergent.
7. Put the accessories and removable shelf
supports back to their initial position.
6. DAILY USE
6.1 Heating functions
True Fan Cooking: Even baking, tender‐
ness, drying
Conventional Cooking: Traditional baking
Frozen Foods: French fries, potato wedges,
spring rolls
Pizza Function: Baking pizza
Bottom Heat: Baking cakes
Defrost: Defrosting
Moist Fan Baking: Baking
Grill: Toasting, grilling
Turbo Grilling: Roasting meat, browning
Menu: To enter the menu.
6.2 Notes on: Moist Fan Baking
This function was used to comply with the
energy efficiency class and ecodesign
requirements (according to EU 65/2014 and
EU 66/2014). Tests according to: IEC/EN
60350-1.
The oven door should be closed during
cooking so that the function is not interrupted
8 ENGLISH
and the oven operates with the highest
energy efficiency possible.
When you use this function the lamp
automatically turns off after 30 sec.
For general energy saving recommendations
refer to "Energy Efficiency" chapter, Energy
saving tips.
This function is designed to save energy
during cooking. When you use this function,
the temperature in the cavity may differ from
the set temperature. The heating power may
be reduced.
6.3 Setting: Heating functions
1. Turn the knob for the heating functions to
select a heating function.
2. Turn the control knob to set the
temperature.
- press and hold to turn on the function:
Fast Heat Up. It is available for some oven
functions.
6.4 Setting: Assisted Cooking
Each dish in this submenu has a
recommended heating function and
temperature. You can adjust the time and the
temperature during cooking.
For some of the dishes you can also cook
with Weight Automatic.
1. Turn the knob for the heating functions to
to enter Menu.
2. Select
. Press .
3. Turn the control knob to select a number
of the dish. Press .
4. Place the food inside the appliance.
Press .
Menu: Assisted Cooking
Legend
Weight Automatic available.
Preheat the appliance before you start
cooking.
Shelf level.
The display shows P and a number of the
dish that you can check in the table.
P1
Roast Beef, rare 2
P2
Roast Beef, medium 2
P3
Roast Beef, well done 2
P4
Steak, medium 3
P5
Beef roast / braised 2
P6
Roast Beef, rare LTC* 2
P7
Roast Beef, medium LTC* 2
P8
Roast Beef, well done LTC* 2
P9
Fillet of beef, rare LTC* 2
P10
Fillet of beef,, medium LTC* 2
P11
Fillet of beef,, done LTC* 2
P12
Veal roast 2
P13
Pork roast neck or shoulder 2
P14
Pulled pork LTC* 2
P15
Pork loin, fresh 2
P16
Pork spare ribs 3
P17
Lamb leg with bones 2
P18
Whole chicken 2
P19
Half chicken 3
P20
Chicken breast 2
P21
Chicken legs, fresh 3
P22
Duck, whole 2
P23
Goose, whole 2
P24
Meat loaf 2
ENGLISH 9
P25
Whole fish, grilled 2
P26
Fish fillet 3
P27
Cheesecake 2
P28
Apple cake 3
P29
Apple tart 2
P30
Apple pie 1
P31
Brownies 3
P32
Chocolate muffins 3
P33
Loaf cake 2
P34
Baked potatoes 2
P35
Wedges 3
P36
Grilled mixed vegetables 3
P37
Croquettes, frozen 3
P38
Pommes, frozen 3
P39
Meat / vegetable lasagna with dry pasta
sheets 2
P40
Potato gratin 1
P41
Pizza fresh, thin 2
P42
Pizza fresh, thick 2
P43
Quiche 2
P44
Baguette / Ciabatta / White bread 2
P45
Whole grain / Rye / Dark bread 2
*LTC - Low Temperature Cooking
6.5 Changing: Settings
1. Turn the knob for the heating functions to
to enter Menu.
2. Select . Press .
3. Turn the control knob to select the
setting. Press .
4. Adjust the value. Press
.
Turn the knob for the heating functions to the
off position to exit Menu.
Menu: Settings
Setting Value
01
Time of day Change
02
Display brightness 1 - 5
03
Key tones 1 - Beep, 2 - Click,
3 - Sound off
04
Buzzer volume 1 - 4
05
Uptimer On / Off
06
Light On / Off
07
Fast Heat Up On / Off
08
Cleaning Reminder On / Off
09
Demo mode Activation code:
2468
10
Software version Check
11
Reset all settings Yes / No
7. CLOCK FUNCTIONS
7.1 Clock functions description
Time of day
To set the clock that displays the cur‐
rent time.
Minute
minder
To set a countdown timer. When the
timer ends, the signal sounds. This
function has no effect on the operation
of the oven.
10 ENGLISH
Cooking
time
To set cooking duration. When the tim‐
er ends, the signal sounds and the
heating function will automatically turn
off.
Time De‐
layed Start
To postpone the start and / or end of
cooking.
Uptimer
To show how long the appliance oper‐
ates. Maximum is 23 h 59 min.This
function has no effect on the operation
of the oven.
8. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
8.1 Notes on cleaning
Cleaning Agents
• Clean the front of the appliance only with a
microfibre cloth with warm water and a
mild detergent.
• Use a cleaning solution to clean metal
surfaces.
• Clean stains with a mild detergent.
Everyday Use
• Clean the interior of the appliance after
each use. Fat accumulation or other
residue may cause fire.
• Moisture can condense in the appliance or
on the door glass panels. To decrease the
condensation, let the appliance work for
10 minutes before cooking. Do not store
food in the appliance for longer than 20
minutes. Dry the interior of the appliance
only with a microfibre cloth after each use.
Accessories
• Clean all accessories after each use and
let them dry. Use only a microfibre cloth
with warm water and a mild detergent. Do
not clean the accessories in a dishwasher.
• Do not clean the non-stick accessories
using abrasive cleaner or sharp-edged
objects.
8.2 Pyrolytic Cleaning
WARNING!
There is a risk of burns.
CAUTION!
If there are other appliances installed in
the same cabinet, do not use them at the
same time as this function. It can cause
damage to the oven.
Do not start the function if you did not fully
close the oven door.
When the cleaning starts, the appliance door
is locked and the lamp is off. Until the door
unlocks the display shows .
1. Turn off the appliance and wait until it is
cold.
2. Remove all accessories.
3. Clean the oven floor and the inner door
glass with warm water, a soft cloth and a
mild detergent.
4. Turn the knob for the heating functions to
enter the menu .
5. Turn the control knob to select Cleaning
and press .
Option Duration
C1 - Light cleaning 1 h
C2 - Normal cleaning 1 h 30 min
C3 - Thorough cleaning 2 h 30 min
6. Turn the control knob to select the
cleaning programme and press
.
7. Press to start cleaning.
8. After cleaning, turn the knob for the
heating functions to the off position.
When the oven is cool again, the door
unlocks.
ENGLISH 11
9. Wait until the appliance is cold and then
clean its interior with a soft cloth.
8.3 Cleaning Reminder
When flashes on the display after cooking
session, the appliance reminds you to clean it
with pyrolytic cleaning. You can turn off the
reminder in the submenu: Settings. Refer to
"Daily use" chapter, Changing: Settings.
8.4 Replacing the lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the appliance and wait until it is
cold.
2. Disconnect the appliance from the mains.
3. Place the cloth on the oven floor.
CAUTION!
Always hold the halogen lamp with a
cloth to prevent grease residue from
burning on the lamp.
Back lamp
1. Turn the glass cover to remove it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300 °C
heat-resistant lamp.
4. Install the glass cover.
9. TROUBLESHOOTING
9.1 What to do if...
Problem Check if...
You cannot activate or operate the appliance. The appliance is correctly connected to an electrical
supply.
The appliance does not heat up. The automatic switch-off is deactivated.
The appliance does not heat up. The appliance door is closed.
The appliance does not heat up. The fuse is not blown.
The appliance does not heat up. Lock is deactivated.
The lamp is turned off. Moist Fan Baking - is activated.
The lamp does not work. The lamp is burnt out.
Err C3 The appliance door is closed or the door lock is not bro‐
ken.
Err F102 The appliance door is closed.
Err F102 The door lock is not broken.
The display shows 00:00. There was a power cut. Set the time of day.
If the display shows an error code that is
not in this table, turn the house fuse off
and on to restart the appliance. If the
error code recurs contact an Authorised
Service Centre.
9.2 Service data
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is
on the rating plate. The rating plate is located
on the front frame of the appliance. It is
12 ENGLISH
visible when you open the door. Do not
remove the rating plate from the appliance.
We recommend that you write the data
here:
Model (MOD.) :
Product number (PNC):
Serial number (S.N.):
10. ENERGY EFFICIENCY
10.1 Product Information Sheet and Product Information according to EU
and UK Energy Labelling and Ecodesign Regulations
Supplier's name Electrolux
Model identification
KOFFP46TK 949498300
KOFFP46TX 949498301
Energy Efficiency Index 81.2
Energy efficiency class A+
Energy consumption with a standard load, conventional mode 0.93 kWh/cycle
Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 72 l
Type of oven Built-In Oven
Mass
KOFFP46TK 30.6 kg
KOFFP46TX 30.6 kg
IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐
ods for measuring performance.
10.2 Product Information for power consumption and maximum time to
reach applicable low power mode
Power consumption in standby 0.8 W
Maximum time needed for the equipment to automatically reach the applicable low power mode 20 min
10.3 Energy saving tips
Following tips below will help you save
energy when using your appliance.
Make sure that the appliance door is closed
when the appliance operates. Do not open
the appliance door too often during cooking.
Keep the door gasket clean and make sure it
is well fixed in its position.
Use metal cookware and dark, non-reflective
tins and containers to improve energy saving.
Do not preheat the appliance before cooking
unless specifically recommended.
Keep breaks between baking as short as
possible when you prepare a few dishes at
one time.
ENGLISH 13
Cooking with fan
When possible, use the cooking functions
with fan to save energy.
Residual heat
When the cooking duration is longer than 30
min, reduce the appliance temperature to
minimum 3 - 10 min before the end of
cooking. The residual heat inside the
appliance will continue to cook.
Use the residual heat to keep the food warm
or warm up other dishes.
When you turn off the appliance, the display
shows the residual heat.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep the food
warm. The residual heat indicator or
temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it on
only when you need it.
Moist Fan Baking
Function designed to save energy during
cooking.
When you use this function the lamp
automatically turns off after 30 sec. You may
turn on the lamp again but this action will
reduce the expected energy savings.
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
14 ENGLISH
*
867377799-A-092024
