PLMW36
3.5'' Single Voice Coil Car Subwoofer
WIRING CONNECTION
Connect the power amplier to the positive
and negative terminals accordingly as shown.
www.PyleUSA.com
D/114mm
d/88mm
H/56mm
h/43.5mm
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: suppor[email protected]
Features:
• PP Cone with Rubber Edge
• High-Powered Car Subwoofer
• Lab Tested Pro Audio Woofer Performance
• SVC: Single Voice Coil Sub Speaker Design
• Massive Butyl Rubber Surround
• High Strength Engineering Plastic Basket
• Quick Connect Speaker Terminal Plate
• Compatible with Sealed Enclosure Speaker Box Audio Setup
• Impressive Bass Response, Low-Resonance Frequency Output
• Designed for Custom Audio Car, Truck, Mobile Vehicle Applications
What's in the Box:
• SVC Subwoofer with Grill
Technical Specs:
• Construction Materials: Engineered ABS
• Power Handing: 20 Watts MAX, 10 Watts RMS
• Impedance: 4 Ohm
• Voice Coil: 1.0'' -in
• Voice Coil Type: High-Temp Aluminum
• Magnet Size: 25*6mm
• Magnet Type: NdFeb Magnet
• Frequency Response: 110Hz-156kHz
• Sensitivity: 85 dB (1w/1m)
• Product Dimensions: 4.5 '' x 4.5'' x 2.2'' –inches
• Cutout Size: 3.46'' –inches
