IRON HANDRAIL
MODEL: D3602-4
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: D3602-4
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
IRON HANDRAIL
- 2 -
SAFE INSTRUCTIONS
CAUTION: Carefully read instructions and procedures for safe operations.
Failure to do so can result in serious injury.
WARNING:
1.Before using the handrail, ensure that the handrail is securely installed to
prevent personal injury and accidents.
2.When using the handrail, do not overload the handrail to avoid personal
injury or accident.
3. Do not draw, cut, or use sharp objects on the handrail to avoid damage.
4. If you need to disassemble the handrail, please follow the reverse steps
to disassemble and store it properly.
5. This product is not a toy. Do not allow children to play with this item.
ASSEMBLY PRECAUTIONS
1. Assemble only according to these instructions. Improper assembly can
create hazards.
2. Wear ANSI-approved safety goggles and heavy-duty work gloves during
assembly.
3. Keep the assembly area clean and well-lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or under the influence of alcohol, drugs or
medication.
6. Product capabilities apply to properly and completely assembled
products only.
7. For additional information regarding the parts listed in the following
pages, please refer to the Assembly Diagram of this manual. Unwrap and
separate all parts in a clean work area.
8. For safety reasons, this hardware is recommended to be installed by 2
people.
SAVE THESE INSTRUCTIONS
- 3 -
Model
D3602-4
Suitable Number Of Steps
4～5
Suggested Height (in/mm)
26.7/678
Column Spacing (in/mm)
48.2/1224
Maximum Bearing Capacity（kg）
300
Code
Name
No.
A
Armrest Tube
1
B
Supporting Pipe
2
C
Small Supporting Pipe
7
- 4 -
D
Columns
2
E
blind flange
2
F
Screws M6*30
14
G
Screws M8*55
2
H
Screws M8*45
4
I
Screws M8*45
8
J
Drill Bit 10*150mm
1
K
Expansion Screw M8*50
8
L
Cap Nut M6
14
M
Cap Nut M8
6
N
Inner Hexagon Spanner
4mm
1
O
Inner Hexagon Spanner
5mm
1
P
Wrench
1
- 5 -
INSTALLATION INSTRUCTION
Installation preparation:
STEP 1: A, B, C, D, load up the banisters!
STEP 2: Mark on the ground and drill with J.
- 6 -
STEP 3: Lock L on the ground. STEP 4: Drop the E！
