48-22-1985 FASTBACK™ Hawkbill Flip Knife
48-22-1990 FASTBACK™ Flip Knife
48-22-1995 FASTBACK™ Spring Assisted Knife
FASTBACK™ POCKET KNIVES
June 2014
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- Belt Clip (1)
2 --------------- M3 x 0.5 Pan Hd. Phillips Screw (1)
3 --------------- M2 x 0.4 Pan Hd. T-6 Screw (6)
4 14-46-1903 Belt Clip/Screw Service Kit (1)
54-49-3140
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
MILWAUKEE TOOL
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
1
2
1 2
3
4
NOTE:
Prior to installing Belt Clip/Screw Service Kit #3
be sure that the blade of your Fastback™ Knife
is folded (closed) for safety.
NOTE:
Apply a drop of non-permanent thread locking
sealant (Loctite
®
222 or the equivalent) to the
thread of screws #2 and #3 prior to installation.
3(6x)
3 screws on
each side of
knife
No. 48-22-1985
No. 48-22-1990
No. 48-22-1995
