WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
¡
¢
¢
¡
£
¤
¥
¦
£
§
¤
¨
¢¢¢¤©
¤
¤
¤¤
¤
ª
ª¤¤¤
¡¤
Upon purchasing the product, check inside the box to make sure all the following accessories are included. External
appearances and colors of the accessories may vary depending on the model.
Dimens
io
n
CAMERA
QUICK GUIDE
DRILL TEMPLATE
125.0
SCREW (3EA), ANCHOR (3EA),
ALLEN WRENCH (1EA), RJ-45 WATERPROOF CAP (1EA)
¨
«¦
«
«¬®
¯°
Image Sensor 1/2.8" SONY IMX 335 Starvis CMOS Sensor
Total Number of Pixels 2704 x 2104
Scanning Mode Progressive Scan
Lens Type Fixed Lens
Focal Length f=2.8mm
F No. F=1.6
Iris Control Fixed
Field of View 127.9º(D), 106.9º(H), 56.9º(V)
Shutter Speed Control Min. 1/100,000 sec ~ Max. 1/2 sec
Day and Night Mode Auto / Day(Color) / Night(BW) / External
Infrared Distance 20 m
Auto White Balance Mode Automatic, Manual
Noise Reduction 2DNR/3DNR
Backlight
Correction WDR
Video Compression H.265 Main profile, H.264(High, Main, Base line profile), MJPEG
SDK Support API, ONVIF Profile S/T Compliant
Video Frame Rate Up to 30fps@1920x1080p
Video Resolution 1920x1080, 1280x720,1024x576, 768x432, 704x392, 640x360, 384x216
Video Streaming Simultaneously H.265 and MJPEG (Multi Streaming) or
(3 Streaming) Simultaneously H.264 and MJPEG (Multi Streaming)
Independent Frame R
ate and Bandwidth Control, VBR/CBR Mode
Protocols TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf
Security Multi User Authority, IP Filtering, HTTPS
Ethernet RJ45 (10/100BASE-T)
Edge Storage micro SDHC/SDXC
Event In Onboot/Trigger/Network Loss/Tampering/Motion
Event Out Notification E-mail, FTP
Audio -
Alarm Control -
Vandal Proof Casing IK10
Outdoor Ready IP67
Operation Temperature -10
°C ~ +50°C
Operation Humidity 0% ~ 95%
Power Source DC 12V, PoE (IEEE 802.3af Class 2)
Power Consumption 3.82W
Approval CE, FCC
Dimension Ø125.0 x 90.2(H)mm
Video
Network
Alarm/Event
General
Electrical
Mechanical
IDIS Co., Ltd.
For more informa�on, please visit
www.idisglobal.com
