Power Outdoors for Camping
PROGENY 120W Solar Panel
USER GUIDE
OUTPUT: 120W/18V
1
2
3
4
5
6
7
8
9
Safety Tips
* Do not bend the solar panel ( the angle is more than 30° ), or it will
be broken.
* The solar panel is IPX4 water-resistant. Avoid falling into water or
used in the rain.
* Do not clean the solar panel with water. Please use the wet cloth to
scrub it gently.
* Do not use or store the solar panel near the heat sources like a fire
or heater
* Do not pierce the solar panel casing with a nail or other sharp object,
break it open with a hammer, or step on it.
* Do not disassemble the solar panel.
* This product cant contact strong corrosives objects.
Wide Compatibility
*QC 3.0 USB Port: Compatible with phones, tablets, DV, etc which can
support QC 3.0, and the device is 5V/3.4A, 9V/2.5A, 12V/2A Max
Type-c Port: Compatible with phones, tablets, DV. The device
is 5V/4.5A, 9V/3A, 12V/3A, 15V/3A Max
*18v DC port: With an Aderson cable can compatible with the Anderson
input of portable power station.
*With 4 in 1 cable included: 5.5*2.1mm connector can charge the
ROCKPALS 250W/Prymax 300W portable power station, 8mm
connector can support Jackery series and Blader 330 power station,
Aviation plug can compatible with ROCKPALS 300W/Aeiusny 500W
portable power station.
*With a parallel cable included: It can connect 2 pcs PROGENY 120W
solar panel to support the Anderson input power station.
Frequently Asked Questions
Q: Are the PROGENY 120W solar panels waterproof?
A: Yes. The solar panel surface is IPX4 waterproof. But do not
recommend to use in the rain or fall into the water.
Q: Can i chain the PROGENY 120W solar panel to other PROGENY
120W solar panel?
A: Yes, you should use a paralle cable included to connect one
PROGENY 120W solar panel to other PROGENY 120W
solar panel.
Q: If my USB device needs an input current of 1A, will the 2A output of
the solar panel damage it?
Contact Us
18 month warranty since purchase date and lifetime friendly customer
service.
A: No. This solar panel has intelligent charging, detecting the needs of
your device, and delivering exactly what it needs. If your phone
accepts 1A, the charger will deliver 1A
Q: What if the foldable solar panel is not charging my devices?
A: 1. Check the manual of your device to ensure the input voltage is 5V
or 18V.
2. Cloudy weather and indirect sunlight may cause fluctuations in the
current so that it may hinder or prevent charging. Place the charger in
direct sunlight or wait for the weather to clear.
3. Wipe the panels clean with a damp cloth between usages to prevent
scratching.
4. Avoid exposure to fire, water, and chemical liquid.
Q: If it is partly cloudy or shady will the solar panel still work?
A: Yes, however, the charging efficiency will be low causing prolonged
charging time.
parallel connection is only between PROGENY 120
1
QC 3.0: 24W Max
2
Type-C: 45W Max
3
indicator
4
5
5.5*2.1mm
DC Output/Anderson Connector
6
5.5*2.5mm
7
8mm
Aviation Plug
Parallel Adapter Cable
8
9
Model： PROGENY 120W Solar Panel
Peak Power: 120W
Cell Effciency: 23%
Power Voltage: 18v
Power Current: 6.6A Max
Short Circuit Current: 7.4A
QC 3.0: 24W Max
Type-C: 45W Max
Operating Temperature Range: -20℃-65℃
Folded Dimensions: 20.47*14.57*2.17in
Unfolded Dimensions: 68.11*20.47*1.18in
Foldable Solar Panel
120W/18V
