en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
INFORMATION FOR USE
1 Safety ........................................................................ 2
2 Preventing material damage .................................. 4
3 Environmental protection and saving energy ...... 5
4 Familiarising yourself with your appliance .......... 6
5 Operating modes ..................................................... 8
6 Accessories ........................................................... 10
7 Before using for the first time .............................. 11
8 Basic operation ..................................................... 13
9 Rapid heating ......................................................... 15
10 Time-setting options ........................................... 15
11 Steam ................................................................... 16
12 Dishes ................................................................... 20
13 Favourites ............................................................ 21
14 Childproof lock .................................................... 22
15 Basic settings ...................................................... 22
16 HomeConnect ................................................... 23
17 Cleaning and servicing ...................................... 25
18 Cleaning function "EcoClean" ........................... 27
19 Cleaning aid ........................................................ 28
20 Descaling ............................................................. 29
21 Drying .................................................................. 29
22 Appliance door .................................................... 30
23 Rails ..................................................................... 33
24 Troubleshooting ................................................. 34
25 Disposal ............................................................... 36
26 Customer Service ............................................... 37
27 Information regarding Free and Open Source
Software ............................................................... 37
28 Declaration of Conformity .................................. 37
29 How it works ........................................................ 38
30 INSTALLATION INSTRUCTIONS ....................... 46
30.1 General installation instructions .................... 46
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product
information safe for future reference or for
the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built into
kitchen units. Read the special installation in-
structions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ in private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of 2000m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
2
Safety en
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
"Accessories", Page10
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
Never store combustible objects in the cook-
ing compartment.
If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order to
stifle any flames.
Loose food remnants, fat and meat juices may
catch fire.
Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.
Opening the appliance door creates a draught.
Greaseproof paper may come into contact with
the heating element and catch fire.
Never place greaseproof paper loosely over
accessories when preheating the appliance
and while cooking.
Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
Caution should be exercised here in order to
avoid touching heating elements.
Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire. The ap-
pliance door may spring open. Hot steam and
jets of flame may escape.
Only use small quantities of drinks with a
high alcohol content in food.
Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
Open the appliance door carefully.
WARNING‒Risk ofscalding!
The accessible parts of the appliance become
hot during operation.
Never touch these hot parts.
Keep children at a safe distance.
Hot steam may escape when you open the ap-
pliance door. Steam may not be visible, de-
pending on the temperature.
Open the appliance door carefully.
Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
Never pour water into the cooking compart-
ment when the cooking compartment is hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may de-
velop into a crack.
Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The appliance and its parts that can be
touched may have sharp edges.
Take care when handling and cleaning them.
If possible, wear protective gloves.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
Keep your hands away from the hinges.
Components inside the appliance door may
have sharp edges.
Wear protective gloves.
Alcoholic vapours may catch fire in the hot
cooking compartment, and the appliance door
may spring open and may fall off. The door
panels may shatter and fragment.
"Preventing material damage", Page4
Only use small quantities of drinks with a
high alcohol content in food.
Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
Open the appliance door carefully.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord or the appliance power
cable of this appliance is damaged, it must
be replaced with a special power cord or
special appliance power cable, which is
available from the manufacturer or its Cus-
tomer Service.
3
en Preventing material damage
If the power cord of this appliance is dam-
aged, it must be replaced by trained special-
ist staff.
If the insulation of the power cord is damaged,
this is dangerous.
Never let the power cord come into contact
with hot appliance parts or heat sources.
Never let the power cord come into contact
with sharp points or edges.
Never kink, crush or modify the power cord.
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cord is dam-
aged, immediately unplug the power cord or
switch off the fuse in the fuse box.
Call customer service.
Page37
Once the appliance has been installed, the
openings in the back panel of the appliance
must not be accessible to children.
Read the special installation instructions.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
1.5 Steam
Follow these instructions when using a steam
function.
WARNING‒Risk ofscalding!
The water in the water tank may become very
hot if you operate the appliance for long peri-
ods.
Always empty the water tank after using the
steam function.
Hot steam is generated in the cooking com-
partment.
Do not reach into the cooking compartment
when using steam.
Hot liquid may spill over the sides of the ac-
cessory when it is removed from the cooking
compartment.
Remove hot accessories with care and al-
ways wear oven gloves.
WARNING‒Risk of fire!
Due to the hot surfaces, vapours from flam-
mable liquids may catch fire in the cooking
compartment (explosion). The appliance door
may spring open. Hot steam and jets of flame
may escape.
Do not pour flammable liquids (e.g. alcoholic
drinks) into the water tank.
Only fill the water tank with water or with the
descaling solution we have recommended.
1.6 Cleaning function
WARNING‒Risk of burns!
The outside of the appliance gets very hot
when the cleaning function is in progress.
Never touch the appliance door.
Allow the appliance to cool down.
Keep children at a safe distance.
Preventing material damage2 Preventing material damage
2.1 General
ATTENTION
Alcoholic vapours may catch fire in the hot cooking
compartment and cause permanent damage to the ap-
pliance. The appliance door may spring open due to an
explosion and it may fall off. The door panels may shat-
ter and fragment. Due to the resulting negative pres-
sure, the cooking compartment may become consider-
ably deformed inwards.
Do not heat spirits (≥ 15% vol.) when undiluted (e.g.
for marinating or pouring over food).
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and roast-
ing times will no longer be correct and the enamel will
be damaged.
Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
4
Environmental protection and saving energy en
Only place cookware on the cooking compartment
floor if a temperature under 50°C has been set.
When the cooking compartment is hot, any water inside
it will create steam. The change in temperature may
cause damage.
Never pour water into the cooking compartment when
it is still hot.
Never place cookware containing water on the cook-
ing compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
Allow the cooking compartment to dry after use.
Do not keep moist food in the cooking compartment
for a long time with the door closed.
Do not store food in the cooking compartment.
Take care not to trap anything in the appliance door.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
When baking very juicy fruit flans, do not pack too
much on the baking tray.
If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment dam-
ages the enamel.
Never use oven cleaner in the cooking compartment
when it is still warm.
Remove all food remnants from the cooking compart-
ment and the appliance door before you next heat up
the appliance.
If the seal is very dirty, the appliance door will no longer
close properly during operation. This may damage the
front of adjacent kitchen units.
Keep the seal clean at all times.
Never operate the appliance if the seal is damaged or
missing.
Sitting or placing objects on the appliance door may
damage it.
Do not place, hang or support objects on the appli-
ance door.
Do not place cookware or accessories on the appli-
ance door.
With certain models, accessories may scratch the door
pane when closing the appliance door.
Always push accessories fully into the cooking com-
partment.
If aluminium foil comes into contact with the door pane,
it could cause permanent discolouration.
Do not allow aluminium foil in the cooking compart-
ment to come into contact with the door pane.
2.2 Steam
Follow these instructions when using the steam function.
ATTENTION
Silicone bakeware is not suitable for combined opera-
tion with steam.
Cookware must be heat- and steam-resistant.
Using cookware with rust spots may cause corrosion in
the cooking compartment. Even the smallest spots of
rust can cause corrosion.
Do not use cookware with rust spots.
Dripping liquids make the cooking compartment floor
dirty.
When steaming with a perforated cooking container,
always place the baking tray, the universal pan or the
unperforated cooking container underneath. This will
catch any liquid that drips down.
Hot water in the water tank may damage the steam sys-
tem.
Only fill the water tank with cold water.
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
A lot of steam is produced during operation with the
types of steam heating. Condensate that collects in the
drip trough underneath the cooking compartment may
overflow and damage adjacent units.
Do not open the appliance door, or open it as infre-
quently as possible, while the appliance is in opera-
tion.
If descaling solution comes into contact with the control
panel or other delicate surfaces, it will damage them.
Remove descaling solution immediately with water.
Cleaning the water tank in the dishwasher will damage
it.
Do not clean the water tank in the dishwasher.
Clean the water tank with a soft cloth and standard
washing-up liquid.
If several steam operations are carried out one after the
other without wiping out the cooking compartment floor
and the condensate tray afterwards in each case, the
water collected may overflow and may damage furniture
panels or bases.
Wipe down the cooking compartment floor and the
condensate tray after every steam operation.
Environmental protection and saving energy3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so. How it works
"How it works", Page38
Not preheating the appliance can reduce the energy
used by up to 20%.
Use dark-coloured, black-coated or enamelled baking
tins.
These types of baking tin absorb the heat particularly
well.
5
en Familiarising yourself with your appliance
Open the appliance door as little as possible during op-
eration.
This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance to
reheat.
When baking multiple dishes, do so in succession or in
parallel.
The cooking compartment is heated after baking the
first dish. This reduces the baking time for the sub-
sequent cakes.
For longer cooking times, you can switch the appliance
off 10minutes before the cooking time ends.
There is sufficient residual heat to finish cooking the
dish.
Remove any accessories that are not being used from
the cooking compartment.
Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
This saves the energy that would otherwise be re-
quired to defrost it.
Switch off the display in the basic settings.
"Basic settings", Page22
Energy is saved when the display is switched off.
Note: In accordance with the EU Ecodesign Directive
2023/826, this appliance is in a different state when
switched off. This is referred to below as low power
mode.
Even when the main function is not active, the appliance
needs energy for:
Detecting operation of the touch keys
Monitoring door opening
Editing the time (without display)
By definition, therefore, there is neither an “off” nor a
“standby” mode, which is why the term low power mode
is used. EN IEC 60350-1:2023 must be used to meas-
ure low power mode.
Familiarising yourself with your appliance4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2 2
Display with setting ring
You can use the digital setting ring to set the appli-
ance via the display.
You will see the current setting values, options or
relevant information.
"Display", Page6
Buttons
You can use the buttons to directly set various
functions.
"Buttons", Page6
4.2 Buttons
You can use the buttons to directly select various func-
tions.
Button Function
Switch the appliance on or off.
"Basic operation", Page13
Open the "Operating modes" menu.
"Operating modes", Page8
Select the favourites operating mode dir-
ectly.
"Favourites", Page21
Go back one setting.
Start or pause operation.
"Basic operation", Page13
Select the timer.
"Setting the timer", Page16
Press and hold for approx. 4seconds to
activate the childproof lock.
"Childproof lock", Page22
Open the control panel to remove the wa-
ter tank.
"Filling the water tank", Page16
4.3 Display
The display is divided into different areas.
Digital setting ring
You can use the digital setting ring on the display to
change the setting values.
When you reach the minimum or maximum value avail-
able, this value remains on the display. If required, use
the setting ring to turn the value back again.
Finely tuned setting values
To fine-tune the setting values, e.g. to set a time to the
precise minute, press and hold the corresponding area
in the setting ring for around 1-2 seconds. The finely
tined setting values are shown in dots.
6
Familiarising yourself with your appliance en
Status indicator
Status information is shown at the top of the display.
Symbol Meaning
Timer is activated.
"Setting the timer", Page16
Childproof lock is activated.
"Childproof lock", Page22
Wi-Fi signal strength for HomeConnect.
The more lines of the symbol are filled,
the better the signal.
If the symbol is struck through , there is
no Wi-Fi signal.
If there is an "x" at the symbol , there is
no connection to the HomeConnect
server.
"HomeConnect ", Page23
Remote start with HomeConnect is activ-
ated.
"HomeConnect ", Page23
Remote diagnostics with HomeConnect
for maintenance is activated.
"HomeConnect ", Page23
Settings area
The settings area is in the centre of the display.
You can see current options and settings that have
already been made in the settings area.
The menu and other setting options are arranged hori-
zontally. Selection lists for functions are vertically ar-
ranged. Swipe over the display to scroll in the settings
area. To select a function, press the function on the dis-
play.
"Setting the operating mode", Page13
Possible symbols in the settings area
Symbol Meaning
Confirm the setting value.
Reset the setting value.
Change the setting value while the appli-
ance is in operation.
Note: A blue marking "new" or a blue dot on a function
indicates that a new function, a new favourite or an up-
date was downloaded to your appliance using the
HomeConnect app.
4.4 Cooking compartment
Various functions in the cooking compartment provide
support when operating your appliance.
Shelf supports
The shelf supports in the cooking compartment enable
you to place accessories at different heights.
"Accessories", Page10
Your appliance has 3 shelf positions. The shelf positions
are numbered from bottom to top.
You can remove the shelf supports, e.g. for cleaning.
"Rails", Page33
Self-cleaning surfaces
The self-cleaning surfaces in the cooking compartment
are coated with a porous, matt ceramic layer and have
a rough surface. When the appliance is in operation, the
self-cleaning surfaces absorb splashes from roasting or
grilling and break them down.
The following surfaces are self-cleaning:
Back wall
Ceiling
Side walls
Use the cleaning function regularly to help retain the
cleaning ability of the self-cleaning surfaces and prevent
damage.
"Cleaning function EcoClean", Page27
Lighting
One or more oven lights illuminate the cooking compart-
ment.
When you open the appliance door, the light in the
cooking compartment switches on. If the appliance door
remains open for longer than around 18 minutes, the
light switches off again.
For most operating modes, the lighting is switched on
during operation. The lighting switches off again when
the operation ends.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above the
door.
ATTENTION
Covering the ventilation slots will cause the appliance to
overheat.
Do not cover the ventilation slots.
To cool down the appliance and remove residual mois-
ture from the cooking compartment, the cooling fan runs
for a certain time after operation.
Note: You can change the run-on time in the basic set-
tings. If you frequently prepare very moist food or keep
it warm in the cooking compartment, set a longer run-on
time.
"Basic settings", Page22
7
en Operating modes
Appliance door
If you open the appliance door during operation, the op-
eration stops. If you close the appliance door, operation
resumes automatically.
Water tank
You need the water tank for the types of steam heating.
The water tank is behind the control panel.
"Filling the water tank", Page16
1 2
3
Tank cover
Opening for filling and emptying
Handle for removing and inserting
Operating modes5 Operating modes
This is where you can find an overview of your appli-
ance's operating modes and main functions.
Press to open the menu.
Operating
mode
Use
Types of
heating
Select finely tuned types of heating for the
optimal preparation of your food.
"Types of heating", Page8
"Basic operation", Page13
Steam Gently prepare food with types of steam
heating.
"Steam", Page16
Favourites Use your own saved settings.
"Favourites", Page21
Dishes Use programmed, recommended settings
for various types of food.
"Dishes", Page20
Operating
mode
Use
Cleaning Select the cleaning function for the cook-
ing compartment.
"Cleaning function EcoClean",
Page27
"Cleaning aid", Page28
"Descaling", Page29
"Drying", Page29
Basic set-
tings
Adjust the basic settings.
"Basic settings", Page22
HomeConnect
With HomeConnect, you can connect and remotely con-
trol the oven with a mobile device, and use the full func-
tionality of the appliance.
Depending on the appliance type, additional or more
comprehensive functions are available for your appli-
ance with the HomeConnect app. You can find more in-
formation about this in the app.
"HomeConnect ", Page23
5.1 Types of heating
To ensure that you always find the right type of heating to cook your food, we explain the differences and applica-
tions below.
The symbols for each type of heating help you to remember them.
When you select a type of heating, the appliance suggests a suitable temperature or setting. You can use these val-
ues or change them within the specified range.
For grill setting3, the appliance reduces the temperature to grill setting1 after approx. 40minutes.
Symbol Type of heating Temperature
range
What it's used for and how it works
4D hot air 30 - 250°C Bake or roast on one or more levels.
The fan distributes the heat from the ring-shaped heating element
in the back wall evenly around the cooking compartment.
8
Operating modes en
Symbol Type of heating Temperature
range
What it's used for and how it works
Top/bottom heating 30 - 250°C Traditionally bake or roast on one level. This type of heating is es-
pecially good for cakes with moist toppings.
The heat is emitted evenly from above and below.
Hot air gentle 125 - 250 °C Cook selected dishes gently on one level without preheating.
The fan distributes the heat from the ring-shaped heating element
in the back wall evenly around the cooking compartment.
The food is cooked in phases using residual heat. Always keep
the appliance door closed when cooking. If you open the appli-
ance door even briefly, the appliance will continue to heat without
utilising any residual heat.
This type of heating is used to determine the energy consumption
in air recirculation mode and the energy efficiency class.
Air Fry 30 - 250 °C Cook until crispy, on one level with little fat. Especially suitable for
food that is usually fried in oil, e.g. chips.
The fan circulates heat from the grill element around the food at
high speed. The exhaust air is extracted more intensively from of
the cooking compartment.
Top/bottom heating
gentle
150 - 250 °C Gently cook selected dishes.
Heat is emitted from above and below.
The food is cooked in phases using residual heat. Always keep
the appliance door closed when cooking. If you open the appli-
ance door even briefly, the appliance will continue to heat without
utilising any residual heat.
This type of heating is used to measure the energy consumption
in the conventional mode.
Circulated air grilling 30 - 250°C Roast poultry, whole fish or larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan
circulates the hot air around the food.
Full-surface grill Grill settings:
1 = low
2 = medium
3 = high
Grill flat items such as steak and sausages, or make toast. Gratin-
ate food.
The entire area below the grill element becomes hot.
Centre-area grill Grill settings:
1 = low
2 = medium
3 = high
Grill small quantities such as steak and sausages, or make toast.
Gratinate small quantities of food.
The central area below the grill element becomes hot.
Pizza setting 30 - 250°C Cook pizza or food that requires a lot of heat from below.
The bottom heating element and the ring-shaped heating element
in the back wall heat the cooking compartment.
Low-temperature
cooking
70 - 120°C Slowly and gently cook seared, tender pieces of meat in un-
covered cookware.
The heat is emitted evenly from above and below at a low temper-
ature.
Bottom heating 30 - 250°C Final baking or cooking food in a bain marie.
The heat is emitted from below.
Keeping warm 50 - 100°C Keep cooked food warm.
Plate warming 30 - 90°C Preheat cookware.
Types of steam heating
The types of steam heating can be found in the menu under "Steam".
Symbol Type of heating Temperature
range
What it's used for and how it works
Defrost 30 - 60°C Gently defrost frozen food.
Reheating 80 - 180°C Gently reheat plated meals and baked items.
The steam ensures that the food does not dry out.
Steam Plus 30 - 120°C Gently steam vegetables, meat, fish and cereal. Juice fruit. Blanch
food.
9
en Accessories
Symbol Type of heating Temperature
range
What it's used for and how it works
In order to reduce the cooking time, more robust food can be
steamed at above 100°C.
Proving dough 30 - 50°C Leave the yeast dough to prove.
The dough rises considerably more quickly than at room temper-
ature. The surface of the dough does not dry out.
5.2 Temperature
With most types of heating , you can read the current
temperature in the cooking compartment from ap-
prox.30°C and the set temperature side-by-side on the
display during heating, e.g.120|210°C.
When you are preheating the appliance, the optimal
time to place the food in the cooking compartment is as
soon as the displayed temperature in the cooking com-
partment and the set temperature are the same.
Note: Due to thermal inertia, the temperature that is dis-
played may differ slightly from the actual temperature in-
side the cooking compartment.
Residual heat indicator
When the appliance is switched off, a red line around
the control ring indicates the residual heat in the cook-
ing compartment. The further the temperature drops, the
darker the ring. The ring goes out completely at approx.
60°C.
Accessories6 Accessories
Use original accessories. These have been made especially for your appliance.
Note: Accessories may become deformed if they get hot. Deformation has no effect on function. As the accessory
cools down, it will regain its original shape.
The accessories supplied may differ depending on the appliance model.
Accessories Use
Wire rack Cake tins
Ovenproof dishes
Cookware
Meat, e.g. roasting joints or steak
Frozen meals
Universal pan Moist cakes
Baked items
Bread
Large roasts
Frozen meals
Catch dripping liquids, e.g. fat when grilling
food on the wire rack or water when cook-
ing with steam.
Steam container, solid, size
M
Cooking:
Rice
Pulses
Cereals
Do not place the steam container on the wire
rack.
Steam container, perfor-
ated, size M
Steaming vegetables.
Juicing berries.
Defrosting.
Do not place the steam container on the wire
rack.
Perforated steam container,
size XL
Steaming large quantities of food.
6.1 Information on accessories
Some accessories are only suitable for certain types of
heating.
Steam container
The steam containers are suitable for steam-only types
of heating up to 120°C.
10
Before using for the first time en
The steam containers are not suitable for higher temper-
atures or other types of heating. The containers become
permanently discoloured and deformed.
6.2 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
6.3 Sliding accessories into the cooking
compartment
Always slide the accessory into the cooking compart-
ment the right way round. This is the only way to ensure
that accessories can be pulled out approximately
halfway without tipping.
1.
Turn the accessories so that the notch is at the rear
and is facing downwards.
2.
Insert the accessory between the two guide rods for a
shelf position.
Wire rack Insert the wire rack with the open side
facing the appliance door and the
curved lip facing downwards.
Tray
E.g. univer-
sal pan or
baking tray
Slide the tray in with the sloping edge
towards the appliance door.
Steam con-
tainer, per-
forated, size
XL
3.
Push the accessory all the way in, making sure that it
does not touch the appliance door.
Note: Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
Combining accessories
You can combine the wire rack with the universal pan to
catch any liquid that drips down.
1.
Place the wire rack on the universal pan so that both
spacers are on the rear edge of the universal pan.
2.
Insert the universal pan between the two guide rods
for a shelf position. In so doing, the wire rack is on
top of the upper guide rod.
Wire rack
on universal
pan
6.4 Other accessories
You can purchase other accessories from our customer
service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.bosch-home.com
Accessories are appliance-specific. When purchasing
accessories, always quote the exact product number (E
no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our customer
service.
Before using for the first time7 Before using for the first time
Implement the settings for the initial configuration. Calib-
rate the appliance. Clean the appliance and accessor-
ies.
11
en Before using for the first time
7.1 Determining the water hardness before switching on the appliance for the first time
Before using the appliance for the first time, ask your water supplier about the hardness of your tap water. To ensure
that the appliance can reliably remind you to descale it when required, you must set your water hardness range cor-
rectly.
ATTENTION
If the wrong water hardness has been set, the steam function is impaired and appliance cannot remind you to de-
scale it at the right time.
Set the water hardness correctly.
Using unsuitable liquids may damage the appliance.
Do not use distilled water or other liquids.
Only use cold, fresh tap water, softened water or non-carbonated mineral water.
Malfunctions may occur when using filtered or demineralised water. The appliance may request that you top up the
water tank even though it may be full, or operation with steam is cancelled after approx. twominutes.
If required, mix filtered or demineralised water with the bottled non-carbonated mineral water with a ratio of
onetoone.
Notes
If you are using mineral water, set the water hardness range to "very hard". If you are using mineral water, you
must only use non-carbonated mineral water.
If your tap water is very hard, we recommend that you use softened water. If you are using only softened water, set
the "softened" water hardness range.
Setting Water hardness in
mmol/l
German hardness °dH French hardness °fH
0 (softened)
1
- - -
1 (soft) Up to 1.5 Up to 8.4 Up to 15
2 (medium) 1.5-2.5 8.4-14 15-25
3 (hard) 2.5-3.8 14-21.3 25-38
4 (very hard)
2
Over 3.8 Over 21.3 Over 38
7.2 Performing initial start-up
After connecting the appliance to the power supply, you
must configure the settings for its initial start-up. It may
take a few minutes for the settings to appear on the dis-
play.
1.
Press to switch the appliance on.
The first setting appears.
2.
To change the setting as required, press a value in
the list or change the value using the setting ring.
Possible settings:
– Language
– HomeConnect
"HomeConnect ", Page23
– Time
"Setting the time", Page23
– Water hardness
"Determining the water hardness before switch-
ing on the appliance for the first time", Page12
3.
Press and switch to the next setting.
4.
Work through the settings and make changes as re-
quired.
After the last setting, a message appears on the dis-
play confirming that the initial start-up is complete.
5.
To check the appliance before heating for the first
time, open and close the appliance door once.
7.3 Cleaning the appliance before using it
for the first time
Before using the appliance to cook food for the first
time, you must clean the cooking compartment and ac-
cessories.
1.
Remove the product information and the accessories
from the cooking compartment. Remove any leftover
packaging, such as polystyrene pellets, and any ad-
hesive tape that is in or on the appliance.
2.
Wipe the smooth surfaces in the cooking compart-
ment with a soft, damp cloth.
3.
Clean the accessories thoroughly using a detergent
solution and a dish cloth or soft brush.
7.4 Calibrating the appliance before using it
for the first time
The boiling point of water depends on the air pressure.
During the calibration process, the appliance makes ad-
justments to adapt to the pressure conditions in the loc-
ation where it is installed based on the height above sea
level.
Calibrating the request in the display
When you switch on the appliance, a notification ap-
pears on the display to calibrate the appliance. You can
close the notification and use your appliance as normal.
However, the request appears every time the appliance
is switched on until calibration is complete.
1
Only set this if you will be using solely softened water.
2
Also set for mineral water. Only use non-carbonated mineral water.
12
Basic operation en
Incorrect calibration impairs the steam function.
Note: Depending on the software status of your appli-
ance, you must first download this function to your appli-
ance. You can find more information in the HomeCon-
nect app.
Or calibrate your appliance manually by letting the
steam function run for 30 minutes when the cooking
compartment is empty.
"Steam", Page16
Calibrating the device automatically
Automatic calibration is more precise than manual calib-
ration. The appliance runs for approx. 30 minutes in
steam mode.
Note: Do not open the appliance door while calibration
is in progress, as this will cancel the calibration process.
Requirements
The appliance is cleaned.
"Cleaning the appliance before using it for the first
time", Page12
The cooking compartment is cold.
Accessories have been removed.
1.
Switch on the appliance.
2.
Select automatic in the request that appears in the
display.
3.
Fill the water tank.
"Filling the water tank", Page16
4.
Start the operation.
Calibration starts. This creates a lot of steam.
When the time has elapsed, a signal sounds. A noti-
fication appears on the display confirming that the
operation has finished.
5.
Allow the appliance to cool down and then dry the
cooking compartment floor thoroughly.
6.
Switch off the appliance.
7.
Dry the appliance.
"After using steam operation", Page19
Calibrating the device manually
You can also set the basic setting for height above sea
level directly.
1.
Switch on the appliance.
2.
Select manual in the request that appears in the dis-
play.
The basic setting for height above sea level appears
in the display.
3.
Set the height above sea level.
"Basic settings", Page22
7.5 Heating up the appliance before using it
for the first time
Heat up the appliance before using it to cook food for
the first time.
Requirements
The appliance is cleaned.
"Cleaning the appliance before using it for the first
time", Page12
Accessories have been removed.
1.
Switch on the appliance.
2.
Apply the following settings:
Type of heating Hot air
Temperature Maximum
Duration 1hour
"Basic operation", Page13
3.
Start the operation.
Ventilate the kitchen while the appliance is heating.
4.
Switch off the appliance after 1hour.
5.
Once the appliance has cooled down, clean the
smooth surfaces in the cooking compartment with a
detergent solution and a dish cloth.
Basic operation8 Basic operation
8.1 Switching on the appliance
Press to switch the appliance on.
The display shows the menu.
8.2 Switching off the appliance
Switch your appliance off when you are not using it. The
appliance will switch itself off automatically if it is not
used for a certain period of time.
Press to switch the appliance off.
The appliance switches off. Any functions currently in
progress are cancelled.
The time or residual heat indicator appears on the
display.
8.3 Starting the operation
You must start each operation.
ATTENTION
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
Press to start the operation.
The settings appear on the display.
8.4 Interrupting the operation
You can interrupt the operation and then continue again.
1.
To interrupt the operation, press .
2.
Press again to resume the operation.
8.5 Setting the operating mode
After you have switched on the appliance, the menu ap-
pears on the display.
13
en Basic operation
1.
To scroll through the various selection options, swipe
to the left or right on the display.
Swipe right or left to scroll through the menu and
other setting options.
Swipe down or up to scroll through selection lists.
2.
To select a function, press the function on the display.
Depending on the function, possible setting values or
other tiles are available for selection.
3.
To go back to a setting if necessary, press .
4.
To change the setting values, use the digital setting
ring:
Swipe over the setting ring clockwise or anticlock-
wise, as required.
Or press a specific position on the setting ring.
Or, as soon as the setting ring is pressed, press
the symbol that appears and enter the value dir-
ectly via the number field.
5.
Use to confirm the setting.
6.
Press to start the operation.
7.
If the operation is ended:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Note: You can save your settings as "Favourites" and
use these again.
"Favourites", Page21
8.6 Setting the type of heating and the
temperature
1.
Press "Types of heating" in the menu.
2.
Press the type of heating that you want to use.
3.
Press the temperature in °C or, depending on the
type of heating, the setting.
4.
Use the setting ring to set the temperature.
5.
Press on the display to confirm the set temperat-
ure.
If required, you can implement additional settings:
–
"Rapid heating", Page15
–
"Time-setting options", Page15
–
"Steam", Page16
6.
Press to start the operation.
The appliance starts heating.
The setting values and how long the appliance has
already been in operation are shown on the display.
7.
If the operation is ended:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Note: The most suitable type of heating for your food
can be found in the description of the type of heating.
"Types of heating", Page8
Changing the type of heating
When you change the type of heating, the other settings
are also reset.
1.
Press .
2.
Press .
3.
Press the type of heating that you want to use.
4.
Reset the operation and use to start.
Changing the temperature
Once the operation has started, you can change the
temperature at any time.
1.
Press on the display.
2.
Press the temperature.
3.
Change the temperature with the setting ring.
4.
To confirm the change, press on the display.
The change is applied.
8.7 Displaying information
In most cases, you can call up information about the
function that you have just started. The appliance auto-
matically displays certain information, e.g. to ask you to
do/confirm something or to issue a warning.
1.
Press "Info".
Information is displayed for a few seconds.
2.
To scroll through lots of content in the message,
swipe over the display.
3.
If necessary, use to exit the message.
8.8 Keeping warm over an extended period
You can use your appliance to keep meals warm for up
to 24 hours without changing the behaviour of the appli-
ance. Use the time functions and change the basic set-
tings.
Note: If you open the appliance door during operation,
the appliance stops heating. When you close the appli-
ance door, the appliance continues to heat again. To
ensure that the behaviour of the appliance is not
changed during operation, only open the appliance door
once the set time has elapsed.
1.
Change the basic settings.
"Basic settings", Page22
Change the "Lighting" basic setting to "Always off".
Change the "Standby screen" basic setting to "On".
Change the "Signal tone" basic setting to "Very
short duration".
This will ensure that the light in the cooking compart-
ment is always off while the appliance is in operation
and when you open the appliance door. The clock
display does not change. The duration of the signal
tone is reduced at the end of the operation.
2.
Set the required operating mode.
"Setting the operating mode", Page13
"Setting the type of heating and the temperature",
Page14
3.
Set the required cooking time depending on the oper-
ating mode.
"Setting the cooking time", Page15
"Time-setting options", Page15
4.
Use "End time" to set the time at which the operation
should end.
"Setting the end time", Page15
"Time-setting options", Page15
5.
Place the food in the cooking compartment before
the appliance starts to heat.
6.
Press to start the operation.
The display shows the time remaining until the opera-
tion starts. The appliance is in standby mode.
Once the start time has been reached, the appliance
starts heating and the cooking time starts counting
down.
14
Rapid heating en
7.
When the operation has ended, remove the food from
the cooking compartment. The appliance automatic-
ally switches off completely after approximately 15 to
20minutes.
Note: If required, change the different basic settings
again.
Rapid heating9 Rapid heating
To save time, rapid heating can shorten the preheat-
ing time for set temperatures over 100°C.
Rapid heating is possible for the following types of heat-
ing:
4Dhot air
Top/bottom heating
9.1 Setting rapid heating
To ensure an even cooking result, do not place the food
in the cooking compartment until rapid heating has
come to an end.
Note: Do not set a cooking time until rapid heating has
come to an end.
1.
Set a suitable type of heating and a temperature of at
least 100°C.
Rapid heating automatically switches on at temperat-
ures of 200°C and above.
2.
Press "Rapid heating".
The symbol lights up red.
3.
Press to start the operation.
Rapid heating starts.
Once rapid heating has ended, a signal sounds. The
symbol changes back to white.
4.
Place the food in the cooking compartment.
Cancelling rapid heating
1.
Press on the display.
2.
Press "Rapid heating".
The symbol changes back to white.
Time-setting options10 Time-setting options
For an operation, you can set the cooking time and the
time at which the operation should be finished. The
timer runs independently of the operation.
Time-setting
option
Use
Cooking time If you set a cooking time, the appli-
ance stops heating automatically once
this time has elapsed.
End time Along with the cooking time, you can
set the time at which you want the op-
eration to end. The appliance starts up
automatically so that the operation fin-
ishes at the required time.
Timer You can set the timer to run independ-
ently of the appliance during operation.
It does not affect the appliance.
10.1 Setting the cooking time
You can set the cooking time for the operation up to
24hours.
Requirement: An operating mode and temperature or
level have been set.
1.
Press "Cooking time".
2.
To set the cooking time, press the relevant time
value, e.g. hour display "h" or minute display "m".
The selected value is marked in blue.
3.
Use the setting ring to set the cooking time.
If required, use to reset the setting value.
4.
To confirm the set cooking time, press on the dis-
play.
5.
Press to start the operation.
The appliance starts to heat and the time counts
down.
When the time has elapsed, a signal sounds. A mes-
sage appears on the display confirming that the oper-
ation has finished.
6.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Changing the cooking time
You can change the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Use the setting ring to change the cooking time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
Cancelling the cooking time
You can cancel the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Reset the cooking time using .
Note: For operating modes that always require a
cooking time, the appliance resets the cooking time
to the preset value.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
10.2 Setting the end time
You can delay the time at which the cooking time for the
operation is due to end by up to 24 hours.
15
en Steam
Notes
To achieve good cooking results, do not delay the
time once the operation has already started.
Food will spoil if you leave it in the cooking compart-
ment for too long.
Requirements
An operating mode and temperature or level have
been set.
A cooking time is set.
1.
Press "End time".
2.
To set the time, press the hour display or the minute
display.
The selected value is marked in blue.
3.
Use the setting ring to delay the time.
If required, use to reset the setting value.
4.
To confirm the set time, press on the display.
5.
Press to start the operation.
The display shows the time remaining until the opera-
tion starts. The appliance is in standby mode.
Once the start time has been reached, the appliance
starts heating and the cooking time starts counting
down. For some types of heating, e.g. steaming, the
cooking time only starts after a heating-up time. The
heating-up time depends on the volume and temper-
ature of the food. The end time is postponed.
When the time has elapsed, a signal tone sounds. A
notification appears on the display confirming that the
operation has finished.
6.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
Changing the end time
To achieve good cooking results, only change the set
time before the operation starts and before the cooking
time starts counting down.
1.
Press to pause the operation.
2.
Press the end time .
3.
Use the setting ring to change the end time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
Cancelling the end time
You can delete the set end time at any time.
1.
Press to pause the operation.
2.
Press the end time .
3.
Use to reset the end time.
Note: For operating modes that always require a
cooking time, the appliance resets the time at which
the cooking time ends to the next possible time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
10.3 Setting the timer
The timer runs independently during the operation. You
can set the timer for up to 24hours. The timer has its
own signal so that you can tell whether it is the timer or
a cooking time that has elapsed.
Requirement: If the appliance is switched off, press the
display first. The button lights up.
1.
Press .
2.
To set the timer, press the relevant time value on the
display, e.g. minute display "m" or second display "s".
The selected value is marked in blue.
3.
Set the timer using the setting ring.
To fine-tune the setting values, e.g. to set a time to
the precise second, press and hold the corres-
ponding area in the setting ring for around 1-2
seconds. The finely tined setting values are shown
in dots.
If required, use to reset the setting value.
4.
To start the timer, press on the display.
The timer counts down.
The timer remains visible on the display if the appli-
ance is switched off.
When the appliance is switched on, the display
shows the settings for the current operation. The
timer is displayed in the status display.
Once the timer has elapsed, a signal sounds. A noti-
fication appears on the display confirming that the
timer has finished.
Changing the timer
You can change the timer at any time.
1.
If the timer is running in the background, use to se-
lect the timer beforehand.
2.
Press .
3.
Change the timer using the setting ring.
4.
Press to confirm.
Cancelling the timer
You can cancel the timer at any time.
1.
If the timer is running in the background, use to se-
lect the timer beforehand.
2.
Press .
3.
Reset the timer using .Reset the timer using .
Steam11 Steam
Food can be cooked particularly gently using steam.
You can use the special types of steam heating, or use
steam assistance with certain types of heating.
WARNING‒Risk ofscalding!
Hot steam may escape when you open the appliance
door. Steam may not be visible, depending on the tem-
perature.
Open the appliance door carefully.
Keep children at a safe distance.
11.1 Before using the steam function
Before using the steam function each time, make sure
that your appliance is supplied with sufficient water.
Filling the water tank
WARNING‒Risk of fire!
Due to the hot surfaces, vapours from flammable liquids
may catch fire in the cooking compartment (explosion).
16
Steam en
The appliance door may spring open. Hot steam and
jets of flame may escape.
Do not pour flammable liquids (e.g. alcoholic drinks)
into the water tank.
Only fill the water tank with water or with the descal-
ing solution we have recommended.
WARNING‒Risk of burns!
The water tank may heat up while the appliance is in op-
eration.
Wait until the water tank has cooled down from the
previous operation.
Remove the water tank from the tank recess.
Requirement: The water hardness is set correctly.
1.
Press .
The control panel pops out automatically.
2.
Pull the control panel towards you with both hands
and then push it upwards until it clicks into place .
3.
Remove the water tank from the tank recess .
4.
Press down on the water tank lid along the seal to
prevent water from leaking out of the water tank.
5.
Remove the cover on the water tank.
6.
Fill the water tank with water up to the "max" mark.
7.
Put the cover back into the opening on the water
tank.
8.
Insert the full water tank . When doing so, make
sure that the water tank clicks into place behind the
retainers .
9.
Slowly slide the control panel downwards and then
push it away from you until it is closed completely.
11.2 Setting options with steam
There are various ways in which you can prepare your
food with steam.
Types of steam heating
A variety of types of steam heating are available for
which hot steam is used to gently prepare food.
ATTENTION
A lot of steam is produced during operation with the
types of steam heating. Condensate that collects in the
drip trough underneath the cooking compartment may
overflow and damage adjacent units.
Do not open the appliance door, or open it as infre-
quently as possible, while the appliance is in opera-
tion.
Steaming
During steaming , the food is enveloped by hot steam,
which helps to retain the nutrients. This cooking method
also helps to retain the shape, colour and typical flavour
of the food.
When temperatures between 105°C and 120°C are
set, the cooking time is reduced. This means that even
more nutrients and vitamins are retained when steam-
ing.
Reheating
The reheating function can be used to warm up food
that has already been cooked, or bread and pastries
from the day before, without affecting their quality.
Proving dough
Dough proves considerably more quickly using the
dough proving steam heating type than at room tem-
perature and does not dry out.
Defrost
Use the defrost function to defrost deep-frozen and
frozen products gently without affecting the quality.
Added steam
When you cook with added steam, the appliance intro-
duces steam into the cooking compartment at various
intervals. This gives your food a crispy crust and a shiny
17
en Steam
surface. Meat stays juicy and tender, and only under-
goes a minimum reduction in volume.
You can combine added steam with the following func-
tions:
Types of heating
Page14
– 4Dhot air
– Top/bottom heating
– Circulated air grilling
– Keeping warm
"Dishes", Page20
Steam jet
You can use the steam jet function to specifically add in-
tensive steam at various intervals. This makes bread
and bread rolls in particular wonderfully crispy and gives
them a golden colour.
The appliance adds clouds of steam to the cooking
compartment for approx. 3to 5minutes. Depending on
the operation, you can activate the steam jet several
times.
You can add the steam jet for the following functions:
Types of heating
Page14
– 4Dhot air
– Top/bottom heating
– Circulated air grilling
Note: Only use the steam jet when cooking compart-
ment temperatures are above 120°C.
11.3 Setting the type of steam heating
Note
Observe the instructions for the types of steam heating:
"Types of steam heating", Page17
Requirement: The water tank has been filled. If the wa-
ter tank runs dry during operation, a message appears
on the display. Operation is stopped.
"Filling the water tank", Page16
1.
Press "Steam" in the menu.
2.
Press the required type of steam heating.
3.
Press the temperature in °C.
4.
Use the setting ring to set the temperature.
5.
Press on the display to confirm the set temperat-
ure.
6.
Press "Cooking time".
A cooking time must always be set for types of steam
heating.
7.
To change the preset cooking time, press the relevant
time value, e.g. hour display"h" or minute display"m".
The selected value is marked in blue.
8.
Use the setting ring to set the cooking time.
If required, use to reset the setting value.
9.
To confirm the set cooking time, press on the dis-
play.
10.
Press to start the operation.
The appliance starts to heat and the cooking time
counts down. For some types of heating, e.g. steam-
ing, the cooking time only starts after a heating-up
time. The heating-up time depends on the volume
and temperature of the food.
When the time has elapsed, a signal tone sounds. A
notification appears on the display confirming that the
operation has finished.
11.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
12.
Empty the water tank and dry the cooking compart-
ment.
"After using steam operation", Page19
Changing the type of heating
When you change the type of heating, the other settings
are also reset.
1.
Press .
2.
Press .
3.
Press the type of heating that you want to use.
4.
Reset the operation and use to start.
Changing the temperature
Once the operation has started, you can change the
temperature at any time.
1.
Press on the display.
2.
Press the temperature.
3.
Change the temperature with the setting ring.
4.
To confirm the change, press on the display.
The change is applied.
Changing the cooking time
You can change the cooking time at any time.
1.
Press to pause the operation.
2.
Press the cooking time .
3.
Use the setting ring to change the cooking time.
4.
To confirm the change, press on the display.
5.
Press to start the operation.
11.4 Setting added steam
Requirements
Observe the information about the respective operat-
ing mode.
"Setting options with steam", Page17
The water tank has been filled. If the water tank runs
dry during operation, a message appears on the dis-
play. The appliance continues to operate but without
injecting steam into the cooking compartment.
"Filling the water tank", Page16
1.
Press the operating mode that you require in the
menu.
2.
Select the settings for the operating mode, e.g. type
of heating and temperature.
3.
Press "Added steam".
4.
Use the setting ring to set the steam level.
Steam level Added steam
1 Low
2 Medium
3 High
5.
To confirm the set steam level, press on the dis-
play.
6.
Press to start the operation.
The appliance starts heating.
The setting values and how long the appliance has
already been in operation are shown on the display.
18
Steam en
7.
When the food is ready, use to switch the appli-
ance off.
8.
Empty the water tank and dry the cooking compart-
ment.
"After using steam operation", Page19
Changing added steam
You can change or deactivate the added steam function
at any time.
1.
Press on the display.
2.
Press added steam .
3.
Change or deactivate added steam using the setting
ring.
4.
To confirm the change, press on the display.
The change is applied.
11.5 Setting the steam jet function
Requirements
Observe the information about the respective operat-
ing mode.
"Setting options with steam", Page17
The water tank has been filled. If the water tank runs
dry during operation, a message appears on the dis-
play. Operation is stopped.
"Filling the water tank", Page16
1.
Press the operating mode that you require in the
menu.
2.
Select the settings for the operating mode, e.g. type
of heating and temperature.
3.
Press to start the operation.
4.
Press on the display at the desired time.
Do not use the steam jet until the appliance has com-
pletely heated up.
5.
Press "Steam jet".
The symbol lights up red and the appliance heats
up the water.
6.
When the water is heated up, press "Steam jet"
again.
Note: If rapid heating is activated, the steam jet can
only be triggered once rapid heating is complete.
The steam jet is triggered and the appliance adds
clouds of steam to the cooking compartment for ap-
prox. 3 to 5 minutes.
When the steam jet has finished, the operation contin-
ues to run as normal. Depending on the operation,
the steam jet can be triggered again if necessary.
7.
When the food is ready, use to switch the appli-
ance off.
8.
Empty the water tank and dry the cooking compart-
ment.
"After using steam operation", Page19
Cancelling the steam jet
You can cancel the steam jet at any time.
1.
Press on the display.
2.
Press "Steam jet".
The symbol changes back to white.
The operation continues without the steam jet.
11.6 After using steam operation
Dry the appliance after each steam operation.
Note: Traces of limescale may remain in the cooking
compartment after operation with steam. The functional-
ity of the appliance is not affected by this. You can re-
move traces of limescale using hot water or a cloth
soaked in vinegar. Observe the information on cleaning.
"Cleaning and servicing", Page25
Emptying the water tank
WARNING‒Risk of burns!
The water tank may heat up while the appliance is in op-
eration.
Wait until the water tank has cooled down from the
previous operation.
Remove the water tank from the tank recess.
ATTENTION
Drying the water tank in the hot cooking compartment
leads to damage to the water tank.
Do not dry the water tank in the hot cooking compart-
ment.
Cleaning the water tank in the dishwasher will damage
it.
Do not clean the water tank in the dishwasher.
Clean the water tank with a soft cloth and standard
washing-up liquid.
1.
Use to open the control panel.
2.
Remove the water tank.
3.
Carefully remove the lid of the water tank.
4.
Empty the water tank, clean it with detergent and then
rinse it thoroughly with clean water.
5.
Dry all parts with a soft cloth.
6.
Rub the seal on the lid until dry.
7.
Leave the water tank to dry with the lid open.
8.
Place the lid on the water tank and push down on it.
9.
Insert the water tank and close the control panel.
Drying the condensation tray
WARNING‒Risk of burns!
The appliance becomes hot during operation.
Allow the appliance to cool down before cleaning.
Requirement: The cooking compartment has cooled
down.
1.
Open the appliance door.
2.
Note: The condensation tray is underneath the
cooking compartment.
3.
Soak up the water in the condensation tray with a
tea towel and wipe it carefully.
Note: You can remove the condensation tray in order to
clean it.
"Removing the condensate tray", Page30
19
en Dishes
Drying the cooking compartment
Dry the cooking compartment after each steam opera-
tion.
Dry the cooking compartment by hand or use the dry-
ing function.
"Drying", Page29
Dishes12 Dishes
The "Dishes" operating mode helps you to use your ap-
pliance to prepare different meals by selecting the op-
timum settings automatically.
12.1 Cookware for dishes
The cooking result depends on the composition of the
meat and the size of cookware.
You should therefore use heat-resistant cookware that is
suitable for temperatures up to 300°C. Glass or glass
ceramic cookware is best. The joint should cover ap-
prox.2/3 of the cookware base.
Cookware made from the following material is not suit-
able:
Bright, shiny aluminium
Unglazed clay
Plastic or plastic handles
12.2 Setting options for the dishes
To cook the dishes perfectly, the appliance uses differ-
ent settings depending on the dish.
The display shows you the settings that are used. You
can adjust certain settings. Follow the instructions on
the display.
Note: The cooking result depends on the quality and
composition of the food. Use fresh and, ideally, chilled
food. Use frozen food straight from the freezer.
Tips and information about the settings
If you set a dish, the display shows relevant information
for this dish, e.g.:
Suitable shelf position
Suitable accessory or cookware
Added liquid
Time for turning or stirring
When this time is reached, a signal sounds.
To call up the information, press "Info". Some mes-
sages are displayed automatically.
Programmes
The optimum type of heating, temperature and cooking
time are preset for programmes.
To achieve an optimal cooking result, you must also set
the weight, thickness or the cooking level. You can set
the weight only in the intended range.
Unless otherwise indicated, set the total weight for your
dish.
Recommended settings
For the recommended settings, the optimum type of
heating is preset as a fixed value.
You can adjust the preset temperature and the cooking
time.
Dishes with steam
For some dishes, you can select a cooking method with
steam . The food is cooked gently.
Observe the information on operating with steam.
"Steam", Page16
12.3 Overview of the dishes
You can find out which individual dishes are available to
you on the appliance when you call up the operating
mode. The selection of dishes depends on the features
of your appliance.
The dishes are sorted by category and food.
Note: In the basic settings, you can regionally specialise
the displayed dishes.
"Basic settings", Page22
Category Food
Cakes Cakes in tins
Cakes on a baking tray
Small baked items
Biscuits
Bread,
bread rolls
Bread
Bread rolls
Pizza, sa-
voury cakes
Pizza
Savoury cakes, quiche
Bakes,
soufflés
Bake, savoury, fresh, cooked ingredients
Potato gratin, raw ingredients, 4cm deep
Fresh lasagne
Lasagne, chilled
Bake, sweet, fresh
Fruit crumble
Soufflés in individual moulds
Yorkshire pudding
Poultry Chicken
Duck, goose
Turkey
Meat Pork
Beef
Veal
Lamb
Game
Meat dishes
Fish. Fish, whole
Fish fillet
Fish cutlet
Fish dishes
Seafood
Frozen
products
Pizza
Bakes
Potato products
Vegetables
Poultry, fish
Bread rolls
20
Favourites en
Category Food
Side dishes,
vegetables
Potatoes
Rice
Cereals
Vegetables
Pulses
Pasta, dumplings
Eggs
Desserts,
compote
Yeast dumplings
Crème caramel
Rice pudding
Fruit compote
Yoghurt in glass jars
Preserving,
extracting
juice, steril-
ising
Preserving food
Extracting juice
Bottles, sterilise
Reheating,
crisping up
Baked items
Side dishes
Vegetables
Menu
Defrosting
food
Fruit, vegetables
12.4 Setting a dish
1.
Press "Dishes" in the menu.
2.
Press the required category.
3.
Press the required food.
4.
Press the required dish.
Tip: For some dishes, you can select a preferred
cooking method.
"Setting options for the dishes", Page20
The settings for the dish appear on the display.
5.
Adjust the settings if required.
You can adjust only certain settings depending on the
dish.
"Setting options for the dishes", Page20
6.
For information about the accessory and shelf posi-
tion, for example, press "Info".
7.
Press to start the operation.
The appliance starts to heat and the time counts
down.
Once the dish is ready, a signal sounds. The appli-
ance stops heating.
8.
Once the cooking time has elapsed:
If required, you can select other settings and restart
the operation.
When the food is ready, use to switch the appli-
ance off.
12.5 Automatic switch-off function
The automatic switch-off function for the dishes al-
lows you to bake and fry without any stress.
When the operation has finished, the appliance automat-
ically stops heating.
To achieve an optimum cooking result, remove your
dish from the cooking compartment once the operation
has finished.
Favourites13 Favourites
In the "Favourites", you can save your settings and use
these again.
Note: Depending on the appliance type/software status,
you must first download this function to your appliance.
You can find more information in the HomeConnect
app.
13.1 Saving favourites
You can save up to 30 different operating modes as
your favourites.
If you set an operating mode, at the end of the selec-
tion list, press "Save as favourites".
To rename a favourite, you must use the HomeCon-
nect app. When your appliance is connected, follow
the instructions in the app.
13.2 Selecting favourites
If you have saved favourites, you can use these to set
the operation.
1.
Press "Favourites" in the menu.
Or select the favourites directly using the button.
2.
Press the required favourites.
3.
If required, you can change the settings.
4.
Press to start the operation.
The setting values are shown on the display.
Note
Observe the instructions for the various operating
modes:
"Steam", Page16
13.3 Changing favourites
You can change, sort or delete your saved favourites at
any time.
1.
To sort or rename the favourites, you must use the
HomeConnect app. When your appliance is connec-
ted, follow the instructions in the app.
2.
To change the setting values on the appliance, press
"Favourites" in the menu.
Or select the favourites directly using the button.
3.
Press the required favourites.
4.
At the end of the selection list, press "Edit favourite"
5.
Change the setting values.
6.
Confirm the change.
Deleting favourites
1.
To delete a favourite, press "Favourites" in the menu.
Or select the favourites directly using the button.
2.
Press the required favourites.
3.
At the end of the selection list, press "Delete favour-
ite"
4.
Confirm the deletion.
21
en Childproof lock
Childproof lock14 Childproof lock
You can secure your appliance to prevent children from
accidentally switching it on or changing the settings.
14.1 Activating the childproof lock
The childproof lock can be activated regardless of
whether the appliance is on or off.
Press and hold for approx. 4seconds to activate
the childproof lock.
A confirmation message appears on the display.
The control panel is locked. The appliance can only
be switched off using .
When the appliance is switched on, lights up.
When the appliance is switched off, does not light
up.
14.2 Deactivating the childproof lock
You can deactivate the childproof lock at any time.
1.
Press anywhere on the display.
2.
To deactivate the childproof lock:
Follow the instructions on the display so that the
graphic on the ring fills up completely.
Alternatively, press and hold for approximately
4seconds.
A confirmation message appears on the display.
Basic settings15 Basic settings
You can configure the basic settings for your appliance
to meet your needs.
15.1 Overview of the basic settings
Here you can find an overview of the basic settings and
factory settings. The basic settings depend on the fea-
tures of your appliance.
You can find more information about the individual basic
settings on the display using "Info".
Basic settings Selection
Language See selection on the appliance.
HomeConnect Connect the oven to a mobile device
and remotely control it.
"HomeConnect ", Page23
Clock Time in 24-hour format.
Display Selection
Brightness Levels 1, 2, 3, 4 and 5
1
Standby screen On for a limited time
On (this setting increases energy
consumption)
Off
1
Clock Digital
1
Analogue
Alignment Align the display horizontally and
vertically.
Tone Selection
Button tone On
1
Off
Signal tone Very short duration (once)
Short duration (approx.5seconds)
Medium duration
(approx.10seconds)
1
Long duration (approx.30seconds)
Appliance set-
tings
Selection
Fan run-on time Minimum
Recommended
1
Long
Very long
Pull-out system Not retrofitted (if shelf supports and
a single set of pull-out rails are
fitted)
1
Retrofitted (if 2 or 3 sets of pull-out
rails are fitted)
Lighting When cooking and when the door is
opened
1
Only when the door is opened
Always off
Water hardness 4 (very hard)
1
3 (hard)
2 (medium)
1 (soft)
0 (softened)
Height above
sea level
If calibration takes place automatically,
this basic setting disappears.
"Calibrating the appliance before us-
ing it for the first time", Page12
0 m - 300 m
300 m - 600 m
600 m - 900 m
900 m - 1200 m
1200 m - 1500 m
1500 m - 1800 m
1800 m - 2100 m
Height above sea level unknown
1
(calibration required)
Personalisa-
tion
Selection
Brand logo Display
1
Do not display
1
Factory setting (may vary according to model)
22
HomeConnect en
Personalisa-
tion
Selection
Operation after
switch-on
Main menu
1
Types of heating
Steam
Dishes
Favourites
Elapsed cook-
ing time
Do not display
Display
1
Regional
dishes
All
1
European dishes
British dishes
Dishes All
1
No pork
Kosher only
Childproof lock Available
1
Deactivated
Automatic
rapid heating
off
On
1
Factory set-
tings
Selection
Factory set-
tings
Restore
Info Indicator
Appliance in-
formation
Display technical information about the
appliance.
15.2 Changing the basic settings
1.
Press "Basic settings" in the menu.
2.
Press the required basic settings area.
3.
Press the required basic setting.
4.
Press to select the required basic setting.
The change is applied directly for most basic set-
tings.
5.
To change additional basic settings, use to go
back and select a different basic setting.
6.
To exit the basic settings, use to go back to the
main menu or switch off the appliance using .
The changes are saved.
Note: Your changes to the basic settings will be re-
tained even after a power failure.
15.3 Setting the time
1.
Press "Basic settings" in the menu.
2.
Press "Time".
3.
To set the time, press the hour display or the minute
display.
The selected value is marked in blue.
4.
Use the setting ring to set the time.
The minutes are counted in 5-minute increments.
To set it to the precise minute, press and hold the
corresponding area in the setting ring for around
1-2 seconds. The minutes are shown in dots. Use
the setting ring to set the minutes.
5.
To exit the basic settings, use to go back to the
main menu or switch off the appliance using .
The time is saved.
HomeConnect 16 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings and
monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services in
your country. You can find information about this at:
www.home-connect.com
.
The HomeConnect app guides you through the entire
login process. Follow the instructions in the HomeCon-
nect app to configure the settings.
Tip: Please also follow the instructions in the
HomeConnect app.
Notes
Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeConnect
app.
"Safety", Page2
Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
In networked standby mode, the appliance requires a
maximum of2W.
16.1 Setting up the HomeConnect app
1.
Install the HomeConnect app on your mobile device.
2.
Start the HomeConnect app and set up access for
HomeConnect.
The HomeConnect app guides you through the entire
login process.
16.2 Setting up HomeConnect
Requirements
The appliance is connected to the power supply and
is switched on.
You have a mobile device with a current version of
the iOS or Android operating system, e.g. a smart-
phone.
The appliance is receiving signals from the WLAN
home network (Wi-Fi) at its installation location.
The mobile device and the appliance are within range
of your home network's Wi-Fi signal.
1
Factory setting (may vary according to model)
23
en HomeConnect
1.
Scan the following QR code.
You can install the HomeConnect app and connect
your appliance via the QR code.
2.
Follow the instructions in the HomeConnect app.
16.3 HomeConnect settings
You can adjust the HomeConnect settings and network settings in your appliance's basic settings.
Which settings the display shows will depend on whether HomeConnect has been set up and whether the appliance
is connected to your home network.
Basic setting Possible settings Explanation
Home Connect assist-
ant
Start the assistant
Disconnect
You can connect your appliance to the Home Connect app via
the Home Connect assistant.
Note: If you are using the Home Connect assistant for the first
time, only the "Start assistant" setting is available.
Wi-Fi On
Off
You can use the Wi-Fi to switch off the network connection for
your appliance. When you have connected successfully once,
you can deactivate the Wi-Fi and not lose your detailed data. As
soon as you activate Wi-Fi again, the appliance connects auto-
matically.
Note: In networked standby mode, the appliance requires a
maximum of 2W.
Remote control status Monitoring
Manual remote start
Permanent remote start
During monitoring, you can only view the operating status of the
appliance in the app.
If you convert from monitoring or permanent remote start to
manual remote start, you must activate the remote start each
time. You can open the appliance door within 15 minutes of
having activated remote start. Remote start will not be deactiv-
ated by this. Once 15 minutes have elapsed, opening the appli-
ance door will deactivate manual remote start.
For permanent remote start, you can start and operate the ap-
pliance remotely at any time. If you often operate the appliance
remotely, it is helpful to set the remote start to "Permanent".
16.4 Operating the appliance with the
HomeConnect app
You can use the HomeConnect app to set and start the
appliance remotely.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
Never store combustible objects in the cooking com-
partment.
If smoke is emitted, the appliance must be switched
off or the plug must be pulled out and the door must
be held closed in order to stifle any flames.
Requirements
The appliance is switched off.
The appliance is connected to the home network and
to the HomeConnectapp.
In order to be able to set the appliance via the app,
the manual or permanent remote start must be selec-
ted in the "Remote control status" basic setting.
1.
To activate manual remote start, press .
You only have to confirm on the oven if you are
switching from monitoring or permanent remote start
to manual remote start.
With permanent remote start, you do not need to con-
firm on the oven.
2.
Configure a setting in the HomeConnectapp and
send it to the appliance.
Notes
When you start the oven using the controls on the
appliance itself, the remote start function is activ-
ated automatically. You can use the HomeCon-
nectapp to adjust the settings or start a new pro-
gramme.
You can open the appliance door within 15
minutes of having activated remote start. Remote
start will not be deactivated by this. Once 15
minutes have elapsed, opening the appliance door
will deactivate manual remote start.
24
Cleaning and servicing en
16.5 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of optim-
isation, troubleshooting or security updates. This may
lead to minor changes of visualizations and operation in
the display.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
home network (Wi-Fi). The HomeConnectapp informs
you once installation is successful.
Notes
The software update consists of two steps.
– The first step is the download.
– The second step is the installation on your appli-
ance.
You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
Installation takes a few minutes. You cannot use your
appliance during installation.
We recommend that you install security updates as
soon as possible.
16.6 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip: For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
.
16.7 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the HomeCon-
nect server (initial registration):
Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the in-
stalled Wi-Fi communication module).
Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
The current software and hardware version of your
appliance.
Status of any previous resetting to factory settings.
This initial registration prepares the HomeConnect func-
tions for use and is only required when you want to use
the HomeConnect functions for the first time.
Note: Please note that the HomeConnect functions can
only be utilised with the HomeConnect app. Information
on data protection can be retrieved in the HomeCon-
nect app.
Cleaning and servicing17 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
17.1 Cleaning products
In order to avoid damaging the various oven surfaces
on the appliance, do not use unsuitable cleaning
products.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Do not use steam- or high-pressure cleaners to clean
the appliance.
ATTENTION
Unsuitable cleaning agents damage the surfaces of the
appliance.
Do not use harsh or abrasive cleaning products.
Do not use cleaning products with a high alcohol con-
tent.
Do not use hard scouring pads or cleaning sponges.
Do not use any special cleaners for cleaning the ap-
pliance while it is hot.
Using oven cleaner in a hot cooking compartment dam-
ages the enamel.
Never use oven cleaner in the cooking compartment
when it is still warm.
Remove all food remnants from the cooking compart-
ment and the appliance door before you next heat up
the appliance.
If different cleaning agents are mixed together, there
may be a chemical reaction between these.
Do not mix cleaning agents.
Completely remove any cleaning agent residue.
Salt contained in new sponge cloths may damage sur-
faces.
Wash new sponge cloths thoroughly before use.
Suitable cleaning agents
Only use cleaning agents that are suitable for the different surfaces on your appliance.
Follow the instructions on cleaning the appliance.
"Cleaning the appliance", Page27
25
en Cleaning and servicing
Appliance front
Surface Suitable cleaning agents Information
Stainless steel Hot soapy water
Special stainless steel
cleaning products suit-
able for hot surfaces
To prevent corrosion, remove any patches of limescale, grease,
starch or albumin (e.g. egg white) from stainless steel surfaces imme-
diately.
Apply a thin layer of the stainless steel cleaning product.
Plastic or painted
surfaces
Hot soapy water Do not use glass cleaner or a glass scraper.
To avoid permanent stains, immediately remove any descaling agent
that gets onto the surface.
Glass Hot soapy water Do not use glass cleaner or a glass scraper.
Appliance door
Range Suitable cleaning agents Information
Door panels Hot soapy water
Oven cleaner
Steel wool
Do not use a glass scraper.
Tip: Remove the door panels in order to clean them thoroughly.
"Appliance door", Page30
Door cover Made of stainless
steel:
Stainless steel cleaner
Made from plastic:
Hot soapy water
Do not use glass cleaner or a glass scraper.
Do not use stainless steel care products.
Tip: Remove the door cover for thorough cleaning.
"Appliance door", Page30
Stainless steel in-
terior door frame
Stainless steel cleaner Discolouration can be removed using stainless steel cleaner.
Do not use stainless steel care products.
Door handle Hot soapy water To avoid permanent stains, immediately remove any descaling agent
that gets onto the surface.
Door seal Hot soapy water Do not remove or scrub.
Cooking compartment
Range Suitable cleaning agents Information
Enamel surfaces Hot soapy water
Vinegar solution
Oven cleaner
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
Leave the appliance door open to dry the cooking compartment after
cleaning it.
Notes
Enamel burns at very high temperatures, causing minor discoloura-
tion. The functionality of your appliance is not affected by this.
The edges of thin trays cannot be completely enamelled and may
be rough. This does not impair the corrosion protection.
Food residues leave a white coating on the enamel surfaces. The
coating does not pose a health risk. The functionality of your appli-
ance is not affected by this. You can remove residues with lemon
juice.
Self-cleaning sur-
faces
- Follow the instructions for self-cleaning surfaces.
"Regenerating self-cleaning surfaces in the cooking compartment",
Page27
Shelf supports Hot soapy water
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
Note: To clean thoroughly, detach the shelf supports.
"Rails", Page33
Accessories Hot soapy water
Oven cleaner
Steel wool
Soak any heavily soiled areas and use a brush or steel wool.
Enamelled accessories are dishwasher-safe.
Do not use stainless steel wool on steam containers made from stain-
less steel.
Use a vinegar solution to remove any dirt on stainless steel steam
containers caused by starchy foods (e.g. rice).
Water tank Hot soapy water To remove residual detergent after cleaning, rinse thoroughly with
clean water.
To dry the water tank after cleaning, leave the water tank to dry with
the lid open. Dry the seal on the lid.
Do not clean in the dishwasher.
26
Cleaning function EcoClean en
17.2 Cleaning the appliance
In order to avoid damaging the appliance, you must
clean your appliance only as specified, and with suitable
cleaning products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
Caution should be exercised here in order to avoid
touching heating elements.
Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement: Read the information on cleaning
products.
"Cleaning products", Page25
1.
Clean the appliance using hot soapy water and a dish
cloth.
For some surfaces, you can use alternative clean-
ing agents.
"Suitable cleaning agents", Page25
2.
Dry with a soft cloth.
Regenerating self-cleaning surfaces in the
cooking compartment
The back panel, ceiling and side walls in the cooking
compartment are self-cleaning and have a coarse sur-
face.
ATTENTION
If you do not clean the self-cleaning surfaces regularly,
they may become damaged.
If dark stains are visible on the self-cleaning surfaces,
use the cleaning function to clean the cooking com-
partment.
If a prompt to clean appears in the display, use the
cleaning function to clean the cooking compartment.
Do not use oven cleaner or abrasive cleaning aids. If
oven cleaner accidentally comes into contact with the
self-cleaning surfaces, dab it off immediately using
water and a sponge cloth. Do not rub.
Use the cleaning function.
"Cleaning function EcoClean", Page27
Cleaning function EcoClean18 Cleaning function "EcoClean"
Use the cleaning function "EcoClean" regularly to help
retain the cleaning ability of the self-cleaning surfaces
and prevent damage.
The self-cleaning surfaces in the cooking compartment
are coated with a porous, matt ceramic layer and have
a rough surface. When the appliance is in operation, the
self-cleaning surfaces absorb splashes from roasting or
grilling and break them down.
The following surfaces are self-cleaning:
Back wall
Ceiling
Side walls
ATTENTION
If you do not clean the self-cleaning surfaces regularly,
they may become damaged.
If dark stains are visible on the self-cleaning surfaces,
use the cleaning function to clean the cooking com-
partment.
If a prompt to clean appears in the display, use the
cleaning function to clean the cooking compartment.
Do not use oven cleaner or abrasive cleaning aids. If
oven cleaner accidentally comes into contact with the
self-cleaning surfaces, dab it off immediately using
water and a sponge cloth. Do not rub.
18.1 Cleaning recommendation
The appliance records the type and duration of the op-
eration and, if required, recommends which cleaning
function to use.
When you switch on the appliance, a notification ap-
pears on the display stating that you should use the
cleaning function. Start the cleaning function as soon as
possible.
You can use your appliance as normal. However, the
cleaning recommendation appears on the display until
you have run the cleaning function in full.
Note: If the appliance is prematurely contaminated, e.g.
by greasy poultry or roasts, or if dark spots appear on
the self-cleaning surfaces, do not wait until the notifica-
tion appears on the display before you use the cleaning
functions. The more often you use the cleaning function,
the longer the cleaning ability of the self-cleaning sur-
faces is retained.
18.2 Preparing the appliance for the cleaning
function
In order to achieve a good cleaning result, prepare the
appliance carefully.
ATTENTION
Using oven cleaner on the self-cleaning surfaces dam-
ages the surfaces.
Do not use oven cleaner on the self-cleaning sur-
faces. If oven cleaner does get onto these surfaces,
dab it off immediately using water and a sponge
cloth. Do not rub the surface and do not use abrasive
cleaning aids.
1.
Remove accessories and cookware from the cooking
compartment.
2.
Detach the shelf supports and remove them from the
cooking compartment.
"Rails", Page33
27
en Cleaning aid
3.
Remove coarse dirt using soapy water and a soft
cloth:
– From the cooking compartment floor
– From the inside of the appliance door
– From the glass cover on the oven lamp
This prevents stains that cannot be removed.
4.
Remove any objects from the cooking compartment.
The cooking compartment must be empty.
18.3 Setting the cleaning function
Ventilate the kitchen while the cleaning function is run-
ning.
WARNING‒Risk of burns!
The outside of the appliance gets very hot when the
cleaning function is in progress.
Never touch the appliance door.
Allow the appliance to cool down.
Keep children at a safe distance.
Note: The oven light does not light up while the cleaning
function is running.
Requirement: .
"Preparing the appliance for the cleaning function",
Page27
1.
Press "Cleaning" in the menu.
2.
Press "EcoClean".
The duration of 1hour cannot be changed.
You can delay the time at which the operation should
be finished.
"Setting the end time", Page15
3.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for the cleaning function
appears on the display.
4.
Confirm the notification.
The cleaning function starts and the duration counts
down.
A signal tone sounds when the cleaning function has
finished. A notification appears on the display con-
firming that the operation has finished.
5.
Press to switch the appliance off.
If dark oily stains remain after the cleaning function,
repeat the cleaning function.
6.
.
"Preparing the appliance after the cleaning func-
tion", Page28
18.4 Preparing the appliance after the
cleaning function
1.
Allow the appliance to cool down.
2.
Wipe the cooking compartment with a damp cloth.
Note: Marks may appear on the self-cleaning sur-
faces. Residues of sugar and egg white in the food
are not removed and stick to the surfaces. Red stains
are residues from salty food – they are not rust. The
stains are not hazardous to health. These marks do
not impair the cleaning ability of the self-cleaning sur-
faces.
3.
Attach the shelf supports.
"Rails", Page33
Cleaning aid19 Cleaning aid
The cleaning aid is a quick alternative for occasionally
cleaning the cooking compartment. The cleaning aid
softens dirt by evaporating the soapy water. It is then
easier to remove the dirt.
19.1 Setting the cleaning aid
WARNING‒Risk ofscalding!
If there is water in the cooking compartment when it is
hot, this may create hot steam.
Never pour water into the cooking compartment when
the cooking compartment is hot.
Note: The oven light does not come on while the clean-
ing aid is running.
Requirement: The cooking compartment must have
cooled down completely.
1.
Remove any accessories from the cooking compart-
ment.
2.
ATTENTION‒Distilled water in the cooking compart-
ment leads to corrosion.
Do not use distilled water.
Mix 0.4litres water with a drop of washing-up liquid
and pour into the centre of the cooking compartment
floor.
3.
Press "Cleaning" in the menu.
4.
Press "Cleaning aid".
The duration cannot be changed.
5.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for the cleaning aid ap-
pears on the display.
6.
Confirm the message.
The cleaning aid starts and the duration counts down.
Once the cleaning aid has ended, a signal tone
sounds. A message appears on the display confirm-
ing that the operation has finished.
7.
Press to switch the appliance off.
8.
.
"Cleaning the cooking compartment after using the
cleaning aid", Page28
19.2 Cleaning the cooking compartment
after using the cleaning aid
ATTENTION
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
After using the cleaning assistance, wipe the cooking
compartment and allow it to dry completely.
1.
Allow the appliance to cool down.
2.
Wipe out the remaining water in the cooking compart-
ment using an absorbent sponge cloth.
3.
Clean the smooth enamel surfaces in the cooking
compartment with a dish cloth or a soft brush. Re-
move stubborn food remnants using a stainless steel
scouring pad.
28
Descaling en
4.
Remove limescale with a cloth soaked in vinegar, and
wipe this away with clean water.
5.
Dry the cooking compartment with a soft cloth.
6.
To dry the cooking compartment completely, leave
the appliance door open for approx.1hour or use the
drying function.
"Setting the drying process", Page29
Descaling20 Descaling
Regular descaling is necessary to ensure that your
appliance continues to operate correctly.
How frequently you need to run the descaling pro-
gramme depends on the water hardness and how many
times you have used the steam-assisted operations. The
appliance indicates when only another 5 or fewer
steam-assisted operations are possible. If you do not
carry out descaling, you can no longer set any operation
with steam.
Descaling comprises several steps and takes approxim-
ately 70-95minutes:
Descaling (approx.55-70minutes)
First rinse cycle (approx.8 -12minutes)
Second rinse cycle (approx. 8 -12minutes)
For reasons of hygiene, the descaling programme must
be run in full.
If descaling is interrupted, you can no longer set any op-
eration. To ensure that the appliance is ready for opera-
tion again, carry out 2 rinse cycles.
20.1 Preparing descaling
ATTENTION
The length of time for which the descaler is left to work
is based on the recommended, liquid descaler. Other
descalers may damage the appliance.
Only use the liquid descaler recommended by us for
the descaling programme.
If descaling solution comes into contact with the control
panel or other delicate surfaces, it will damage them.
Remove descaling solution immediately with water.
1.
Mix the descaling solution:
200ml liquid descaler
400ml water
2.
Open the control panel.
3.
Remove the water tank and fill it with descaling solu-
tion.
4.
Once the descaling solution has been poured into the
water tank, slide the tank back in.
5.
Close the control panel.
20.2 Setting the descaling programme
Requirement:
"Preparing descaling", Page29
1.
Press "Cleaning" in the menu.
2.
Press "Descaling".
The duration cannot be changed.
3.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for descaling appears on
the display.
4.
Confirm the message.
The descaling programme starts and the duration
counts down.
Once the first part of the descaling programme has
finished, a signal tone sounds. The appliance
prompts you to rinse twice.
5.
To rinse the appliance, for each rinse cycle:
Open the control panel and remove the water tank.
Thoroughly rinse the water tank and fill it with fresh
water.
Slide in the water tank and close the control panel.
A signal tone sounds when each rinse cycle has
ended.
6.
Once the second rinse cycle is complete:
Empty and dry the water tank.
"Emptying the water tank", Page19
Press to switch the appliance off.
Drying21 Drying
To prevent residual moisture , dry the cooking compart-
ment following operation with steam and after using the
cleaning aid.
ATTENTION
If there is water on the cooking compartment floor when
operating the appliance at temperatures above 120°C,
this will damage the enamel.
Do not use the appliance if there is water on the
cooking compartment floor.
Wipe away any water on the cooking compartment
floor before operation.
21.1 Drying the cooking compartment
You can leave the cooking compartment to dry or use
the drying function.
1.
Allow the appliance to cool down.
2.
Remove any dirt from the cooking compartment.
3.
Wipe away any water in the cooking compartment.
4.
Dry the cooking compartment.
To dry the cooking compartment, leave the appli-
ance door open for 1hour.
To use the drying function, set "Drying function".
"Setting the drying process", Page29
Setting the drying process
Requirement:
"Drying the cooking compartment", Page29
1.
Press "Cleaning" in the menu.
2.
Press "Drying function".
The duration cannot be changed.
29
en Appliance door
3.
Press .
A notification stating that you should carry out the ne-
cessary preparatory work for the drying appears on
the display.
4.
Confirm the message.
The drying process starts and the duration counts
down.
Once the drying has ended, a signal tone sounds. A
message appears on the display confirming that the
operation has finished.
5.
Press to switch the appliance off.
6.
To dry the cooking compartment completely, leave
the appliance door open for 1 to 2minutes.
Appliance door22 Appliance door
To clean the appliance door thoroughly, you can disas-
semble the appliance door.
Note: Wipe the condensate trough without pressure.
22.1 Detaching the appliance door
WARNING‒Risk of injury!
Components inside the appliance door may have sharp
edges.
Wear protective gloves.
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
1.
Open the appliance door fully.
2.
WARNING‒Risk of injury!
When the hinges are not secured, they can snap shut
with great force.
Make sure that the locking levers are always either
fully closed or (when detaching the oven door) fully
open.
Open the locking levers on the left- and right-hand
hinges.
Locking levers opened
The hinge is now secured
and cannot snap shut.
Locking levers closed
The appliance door is se-
cured and cannot be de-
tached.
The locking levers are open. The hinges are now se-
cured and cannot snap shut.
3.
Close the appliance door fully . Grab hold of the ap-
pliance door with both hands (on the left and right)
and pull it upwards and out .
4.
Carefully place the appliance door on a level surface.
Removing the condensate tray
Notes
Wipe down the condensate tray after every steam op-
eration or before removing it.
Do not clean the condensate tray in the dishwasher
Requirement: The appliance door must be removed.
1.
Press on the left-hand pressure surface until the
hook is released.
2.
Press on the right-hand pressure surface until the
hook is released.
3.
Tilt the condensate tray forwards slightly until the
lower retaining hooks are released.
30
Appliance door en
4.
Use both hands to pull the condensate tray up-
wards and out at an angle .
Installing the condensate tray
1.
Use both hands to insert the condensate tray at an
angle .
2.
Snap the hooks on the left and right of the con-
densate tray into the gap .
3.
Push the condensate tray until the hooks on the right,
left and bottom click into place.
The condensate tray is installed horizontally.
22.2 Attaching the appliance door
WARNING‒Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
When the hinges are not secured, they can snap shut
with great force.
Make sure that the locking levers are always either
fully closed or (when detaching the oven door) fully
open.
1.
Slide the appliance door straight onto the two
hinges . Slide the appliance door on as far as it will
go.
2.
Open the appliance door fully.
3.
Close the locking levers on the left- and right-hand
hinges .
The locking levers are closed. The appliance door is
secured and cannot be detached.
4.
Close the appliance door.
22.3 Removing the door panes
WARNING‒Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
Components inside the appliance door may have sharp
edges.
Wear protective gloves.
1.
Open the appliance door fully.
2.
Open the locking levers on the left- and right-hand
hinges .
The locking levers are open. The hinges are now se-
cured and cannot snap shut.
3.
Close the appliance door fully .
4.
Push on the left- and right-hand side of the door
cover from the outside until it is released.
31
en Appliance door
5.
Remove the door cover .
6.
Lift out the inner pane and set it down carefully on
a flat surface.
7.
Lift out the intermediate pane and set it down care-
fully on a flat surface.
8.
Open the appliance door and remove the door seal.
9.
If necessary, you can remove the condensate trough
for cleaning.
Open the appliance door.
Tilt the condensate trough upwards and remove it.
10.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
Do not use any harsh or abrasive cleaners or
sharp metal scrapers to clean the glass on the
oven door, as they may scratch the surface.
Clean the removed door panels on both sides with
glass cleaner and a soft cloth.
11.
Clean the condensate trough with a cloth and hot
soapy water.
12.
Clean the appliance door.
"Suitable cleaning agents", Page25
13.
Dry the door panels and refit them.
"Fitting the door panes", Page32
22.4 Fitting the door panes
WARNING‒Risk of injury!
The hinges on the appliance door move when the door
is opened and closed, which could trap your fingers.
Keep your hands away from the hinges.
Components inside the appliance door may have sharp
edges.
Wear protective gloves.
1.
Open the appliance door fully.
2.
Place the condensate trough vertically into the re-
tainer and turn it downwards.
3.
Slide the intermediate pane into the left- and right-
hand retainers .
32
Rails en
4.
Push the intermediate pane upwards until it is in the
left- and right-hand retainers .
5.
Open the appliance door and attach the door seal.
6.
Note: When sliding the pane in, ensure that the
glossy side of the pane is on the outside and the cut-
outs on the left and right are at the top.
7.
Slide the inner pane into the left- and right-hand
retainers .
8.
Push the inner pane upwards until it is in the left- and
right-hand retainers .
9.
Put the door cover into position and push down on
it until you hear it click into place.
10.
Open the appliance door fully.
11.
Close the locking levers on the left- and right-hand
hinges .
The locking levers are closed. The appliance door is
secured and cannot be detached.
12.
Close the appliance door.
Note: Do not use the cooking compartment again until
the door panes have been correctly fitted.
Rails23 Rails
To thoroughly clean the rails and the cooking compart-
ment, or to replace the rails, you can remove the rails.
23.1 Detaching the rails
WARNING‒Risk of burns!
The shelf supports get very hot
Never touch the shelf supports when hot.
Always allow the appliance to cool down.
Keep children at a safe distance.
1.
Lift the rail forwards slightly and detach it .
33
en Troubleshooting
2.
Pull the whole rail to the front and remove it.
3.
Clean the rail.
"Cleaning products", Page25
23.2 Attaching the rails
Notes
The rails only fit on the right or left.
For both rails, ensure that the curved rods are at the
front.
1.
First, push the rail into the middle of the rear socket
until the rail rests against the cooking compartment
wall, and then push this back .
2.
Push the rail into the front socket until the rail also
rests against the cooking compartment wall, and then
press this downwards .
Troubleshooting24 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page37
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged, it must be replaced with a special
power cord or special appliance power cable, which is available from the manufacturer or its Customer Service.
If the power cord of this appliance is damaged, it must be replaced by trained specialist staff.
24.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The circuit breaker in the fuse box has tripped.
Check the circuit breaker in the fuse box.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
Electronics fault
1.
Disconnect the appliance from the power supply for at least 30 seconds by
switching off the fuse.
2.
Reset the basic settings to the factory settings.
"Basic settings", Page22
"Sprache Deutsch" appears in the
display.
There has been a power cut.
Configure the initial configuration settings.
"Performing initial start-up", Page12
The operation does not start or is
interrupted.
Different causes are possible.
Check the notifications that appear on the display.
"Displaying information", Page14
34
Troubleshooting en
Fault Cause and troubleshooting
The operation does not start or is
interrupted.
Malfunction
Call .
"Customer Service", Page37
Appliance does not heat up. Demo mode is switched on.
1.
Briefly disconnect the appliance from the power supply by switching the circuit
breaker in the fuse box off and then on again.
2.
Switch off demo mode in the basic settings within approx.5minutes.
"Changing the basic settings", Page23
There has been a power cut.
Open and close the appliance door once after a power failure.
The appliance is checked and is ready to use.
The time is not displayed when
the appliance is switched off.
Basic setting has been changed.
Change the basic setting for the time display.
"Basic settings", Page22
HomeConnect is not working
properly.
Different causes are possible.
Go to
www.home-connect.com
.
The control panel cannot be
opened.
The circuit breaker in the fuse box has tripped.
Check the circuit breaker in the fuse box.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
Malfunction
1.
Call the after-sales service.
"Customer Service", Page37
2.
If there is water in the water tank, empty the water tank:
Open the appliance door.
Grip on the right and left below the control panel.
Slowly pull out the control panel and push it upwards.
Intense steam generation when
steaming.
The appliance is automatically calibrated.
No action required.
If the cooking times are too short, the appliance is not automatically calibrated.
If a lot of steam is generated repeatedly, the appliance is recalibrated.
1.
Reset the appliance to the factory setting.
"Basic settings", Page22
2.
Repeat the calibrations.
"Before using for the first time", Page11
The appliance requests descaling
without the counter appearing in
advance.
The set water hardness range is too low.
1.
Descale the appliance.
"Descaling", Page29
2.
Check the water hardness and set this in the basic settings.
"Basic settings", Page22
The appliance prompts you to
rinse it.
During the descaling, the power supply is interrupted or the appliance is switched
off.
Rinse the appliance.
"Descaling", Page29
"Fill water tank" appears in the
display even though the water
tank has been filled.
The water tank has not clicked into place.
Insert the water tank correctly so that it engages in the holder.
"Filling the water tank", Page16
The water tank has fallen out. Shaking has caused parts to come loose in the wa-
ter tank. The water tank is leaking.
Order a new water tank.
"Customer Service", Page37
Malfunction
Do not use deionised or filtered water.
"Determining the water hardness before switching on the appliance for the
first time", Page12
The sensor is defective.
Call .
"Customer Service", Page37
35
en Disposal
Fault Cause and troubleshooting
Buttons are flashing. Condensation has formed behind the control panel.
No action required. As soon as the condensation has evaporated, the buttons no
longer flash.
"Plopping" sounds can be heard
when cooking with steam.
Water vapour requires the cold/heat effect for frozen food.
No action required.
The appliance hums during oper-
ation and after it is switched off.
Functional test of the pump creates operating noise.
No action required.
The interior lighting does not
work.
Basic setting has been changed.
Change the basic setting for the lighting.
"Basic settings", Page22
The LED light is defective.
Call .
"Customer Service", Page37
Maximum operating time
reached.
To prevent an unwanted permanent operation, the appliance automatically stops
heating after several hours if the settings are unchanged. A message appears in
the display.
The point at which the maximum operating time is reached is determined by the
corresponding settings for an operating mode.
1.
To continue operation, switch the appliance off and on again using . Reset
and start the operation.
2.
If you do not need to use the appliance, press to switch it off.
Tip: To prevent the appliance from switching off when you do not want it to, set a
cooking time.
"Time-setting options", Page15
Error code made up of letters
and numbers appears on the dis-
play, e.g. E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the
exact error message when calling.
"Customer Service", Page37
The cooking result is not satis-
factory.
Settings were unsuitable.
Adjustment values, e.g. temperature or cooking time, depend on the recipe,
quantity and food.
Next time, set lower or higher values.
Tip: A lot of other information about the preparation, corresponding adjustment
values and recipes can be found in the HomeConnect app or on our website
www.bosch-home.com
.
Disposal25 Disposal
25.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
36
Customer Service en
Customer Service26 Customer Service
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.), the production number (FD)
and the consecutive numbering (Z-Nr.) of your appli-
ance.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
This product contains light sources from energy effi-
ciency class G. These light sources are available as a
spare part and should only be replaced by trained spe-
cialist staff.
You can find the information required as per Regula-
tions (EU) 65/2014, (EU) 66/2014 and (EU) 2023/826
online at
www.bosch-home.com
on the product and ser-
vice pages for your appliance, in the area of user manu-
als and additional documents.
26.1 Product number (E-Nr.), production
number (FD) and consecutive numbering (Z-
Nr.)
You can find the product number (E-Nr.), the production
number (FD) and the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
You will see the rating plate with these numbers if you
open the appliance door. On some appliances with
steam-assisted cooking, you will find the rating plate be-
hind the control panel.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
You can also display the appliance information in the
basic settings.
"Basic settings", Page22
Information regarding Free and Open Source Software27 Information regarding Free and Open Source Software
This product includes software components that are li-
censed by the copyright holders as free or open source
software.
The applicable licence information is stored on your
home appliance. You can also access the applicable li-
cence information via your HomeConnect app: "Profile
-> Legal information -> Licence Information".
1
You can
download the licence information on the brand product
website. (Please search on the product website for your
appliance model and additional documents). Alternat-
ively, you can request the relevant information from oss-
[email protected] or BSH Hausgeräte GmbH, Carl-
Wery-Str. 34, 81739 Munich, Germany.
The source code will be made available to you on re-
quest.
Please send your request to [email protected] or
BSH Hausgeräte GmbH, Carl-Wery-Str.34, 81739 Mu-
nich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request will be charged to
you. This offer is valid for three years from the date of
purchase or at least as long as we offer support and
spare parts for the relevant appliance.
Declaration of Conformity28 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen-
tial requirements and other relevant provisions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at
www.bosch-home.com
among the additional docu-
ments on the product page for your appliance.
Hereby, BSH Hausgeräte GmbH declares that the appliance with HomeConnect functionality is in compliance with
relevant statutory requirements.
2
A detailed Declaration of Conformity can be found online at
www.bosch-home.co.uk
among the additional documents
on the product page for your appliance.
2
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5 GHz band (5150–5350MHz + 5470–5725MHz): max. 200mW
BE BG CZ DK DE EE IE EL ES
1
Depending on the appliance specifications
2
Only applies to Great Britain
37
en How it works
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
28.1 Statement of Compliance for Great
Britain
The full Statement of Compliance according to the
Product Security and Telecommunications Infrastructure
(Security Requirements for Relevant Connectable
Products) Regulations 2023 can be found online at
www.bosch-home.co.uk among the additional docu-
ments on the product page for your appliance.
Product type
This statement of compliance covers the products de-
scribed in this information for use whose model identi-
fier group is seen on the title page. The full model identi-
fier is made up of the characters before the slash in the
product number (E no.) which can be found on the rat-
ing plate. Alternatively, you can also find the model iden-
tifier in the first line of the UK Energy Label.
Name and address of manufacturer
BSH Hausgeräte GmbH, Carl-Wery-Strasse 34, 81739
München, Germany
This statement of compliance is prepared by the manu-
facturer.
The manufacturer, BSH Hausgeräte GmbH deems that it
has complied with
provision 5.1-1 of ETSI EN 303 645 v2.1.1 and,
where relevant, provision 5.1-2 of ETSI EN 303 645
v2.1.1;
provision 5.2-1 of ETSI EN 303 645 v2.1.1;
provision 5.3-13 of ETSI EN 303 645 v2.1.1.
Support period
BSH Hausgeräte GmbH will provide security updates
that are necessary to maintain the main functions free of
charge until at least 28/02/2034.
How it works29 How it works
Here, you can find the ideal settings for various types of
food as well as the best accessories and cookware. We
have perfectly tailored these recommendations to your
appliance.
Tip: A lot of other information about the preparation,
corresponding adjustment values and recipes can be
found in the HomeConnect app or on our website
www.bosch-home.com
.
29.1 General cooking tips
Take note of the following information when cooking all
types of food.
The temperature and cooking time depend on the
amount of food and the recipe. Settings ranges are
specified for this reason. Try using the lower values to
start with.
The setting values apply to food placed in the cook-
ing compartment while the cooking compartment is
still cold. If you want to preheat anyway, do not place
accessories into the cooking compartment until it has
finished preheating.
Remove any accessories that are not being used
from the cooking compartment.
You can buy suitable accessories from customer ser-
vice, from specialist retailers or online.
"Other accessories", Page11
29.2 Baking tips
Dark-coloured metal baking tins are most suitable for
baking cakes, bread and other baked goods.
Use wide, shallow cookware for bakes and gratins.
Food takes longer to cook in deep, narrow cookware
and it browns more on top.
If you are cooking bakes directly in the universal pan,
place the universal pan into the cooking compartment
at level1.
The setting values for bread dough apply to both
dough placed on a baking tray and dough placed in
a loaf tin.
ATTENTION
When the cooking compartment is hot, any water inside
it will create steam. The change in temperature may
cause damage.
Never pour water into the cooking compartment when
it is still hot.
Never place cookware containing water on the cook-
ing compartment floor.
Shelf positions
You will obtain the best results if you use the following
shelf positions.
If you are baking on one level, use shelf position 1.
Baking on 2levels Height
Universal pan
Baking tray
3
1
Baking tins/dishes on two wire racks 3
1
Use the 4Dhot air heating function.
Note: Items that are placed in the appliance on baking
trays or in baking tins/dishes at the same time will not
necessarily be ready at the same time.
38
How it works en
29.3 Roasting, braising and grilling tips
The recommended settings are for fridge-temperature
food and unstuffed, oven-ready poultry.
Place the poultry onto the cookware breast-side or
skin-side down.
Turn roasting joints, grilled items or whole fish after
approx. ½ to ⅔ of the specified time.
Roasting on the wire rack
Food roasted on the wire rack will become very crispy
on all sides. You can roast large poultry, for example, or
multiple individual pieces at the same time.
Roast pieces of a similar weight and thickness. The
grilled food will brown evenly and will remain succu-
lent and juicy.
Place the food to be roasted directly on the wire rack.
To catch any liquids that drip down, place the univer-
sal pan, with the wire rack inside it, into the cooking
compartment at the specified shelf height.
Add up to ½litre of water to the universal pan, de-
pending on the size and type of food that you want to
roast.
You can make a sauce from the juices that are collec-
ted. This also means that less smoke is produced
and the cooking compartment does not become as
dirty.
Roasting in cookware
If you cover the cookware when you cook your food,
this will keep the cooking compartment cleaner.
General information about roasting in cookware
Use heat-resistant, ovenproof cookware.
Place the cookware on the wire rack.
Glass cookware is best.
Follow the manufacturer's instructions for your roast-
ing dishes.
Roasting in uncovered cookware
Use a deep roasting dish.
If you do not have any suitable cookware, you can
use the universal pan.
Roasting in covered cookware
Use a suitable lid that seals well.
When roasting meat, there should be at least 3cm
between the food and the lid. The meat may expand.
WARNING‒Risk ofscalding!
Very hot steam may escape when the lid is opened after
cooking. Steam may not be visible, depending on the
temperature.
Lift the lid in such a way that the hot steam can es-
cape away from you.
Keep children away from the appliance.
Grilling
Grill food if you want it to be crispy.
The "Grill" type of heating is good for cooking thinner
pieces of poultry, meat and fish such as steaks, drum-
sticks and burgers. It is also excellent for toasting
bread.
Circulated air grilling is very well suited to cooking
whole poultry and fish, as well as meat, e.g. roast pork
with crackling.
When grilling several food items, choose pieces that
are of a similar weight and thickness. The grilled food
will brown evenly and will remain succulent and juicy.
Place the food to be grilled directly onto the wire
rack.
To catch any liquids that drip down, place the univer-
sal pan into the cooking compartment at least one
level below the wire rack.
Notes
The grill element switches on and off continuously.
This is normal. The grill setting that you use determ-
ines how frequently this occurs.
Smoke may be produced when grilling.
29.4 Cooking tips for steaming
Cook your food gently. The food remains particularly
succulent.
In contrast to cooking with added steam, the meat does
not become crispy on the outside.
Use uncovered, heat-resistant cookware that is suit-
able for cooking with steam.
The perforated steaming tray, size XL, is the best op-
tion here. To catch any liquid that drips down, slide
the universal pan into the cooking compartment one
level below.
Alternatively, you can place a glass dish onto the wire
rack.
Cover food that you would normally cook in a bain
marie with film, e.g. cling film.
You do not need to turn the food.
To obtain a slightly different flavour, you can sear the
meat, poultry or fish before steaming. Reduce the
cooking time.
Larger food items require a longer heat-up time and a
longer cooking time.
If you are using several pieces which are the same
weight, the appliance's heat-up time is increased. The
cooking time remains the same.
Open the door as infrequently as possible during
steaming. Wipe the condensate drip tray after prepar-
ation. If the condensate drip tray overflows, this may
cause damage to kitchen units.
The main part of the user manual contains informa-
tion on how to configure the steam settings.
"Steam", Page16
Vegetables on several levels
You can easily cook more than one type of food or even
whole menus, e.g. broccoli and potatoes, on 2 levels.
Page42
Rice or cereal products
Add water or liquid in the specified ratio.
For example, 1:1.5 means add 150ml liquid for every
100g rice.
29.5 Cooking instructions for ready meals
The cooking result greatly depends on the quality of
the food. Pre-browning and irregularities may already
be present in the food before cooking.
Do not use frozen products that are covered with a
thick layer of ice. Remove any ice on the food.
Take ready meals out of the packaging.
39
en How it works
If you are warming or cooking the ready meal in
cookware, make sure that the cookware is heat-resist-
ant.
Distribute foods that are in the form of separate
pieces, such as bread rolls and potato products, so
that they are spread out flat and evenly on the ac-
cessory. Leave a little space between the individual
pieces.
Follow the manufacturer's instructions on the pack-
aging.
29.6 List of foods
Recommended settings for a variety of foods, sorted
into food categories.
Recommended settings for various types of food
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C/grill setting
Steam
level
Cooking time
in mins
Sponge cake, delicate Ring-shaped tin
or
Loaf tin
1 150-170 - 60-80
Fruit tart or cheesecake
with shortcrust pastry
base
Springform cake
tin, diameter 26 cm
1 170-180 - 60-80
Sponge flan, 6 eggs Springform cake tin
Ø 28 cm
1 150-160 1
Off
1. 10
2. 25-35
Sponge flan, 6 eggs Springform cake tin
Ø 28 cm
1 150-160 - 50-60
Shortcrust tart with moist
topping
Universal pan 1 160-180 - 60-80
Yeast cake with moist
topping
Universal pan 1 180-190 - 30-45
Swiss roll Baking tray 1 190-210
1
1 10-15
Muffins Muffin tray 1 170-190 - 15-30
Small yeast cakes Baking tray 1 160-180 2 25-35
Biscuits Baking tray 2 140-160 - 15-30
Biscuits, 2levels Universal pan
+
Baking tray
3+1 130-150 - 20-35
Bread, 750g Universal pan
or
Loaf tin
1 1. 210-220
2. 180-190
3
Off
1. 10-15
2. 25-35
Bread, 1500g Universal pan
or
Loaf tin
1 1. 210-220
2. 180-190
3
Off
1. 10-15
2. 45-55
Bread, 1500g Universal pan
or
Loaf tin
1 200-210 - 35-45
Flatbread Universal pan 2 220-230 3 20-30
Bread rolls, fresh Baking tray 1 200-220 2 20-30
Pizza, fresh Baking tray 1 180-200 - 20-30
Pizza, fresh, 2 levels Universal pan
+
Baking tray
3+1 180-190 - 35-45
Pizza, fresh, thin-crust, on
a pizza tray
Pizza tray 1 210-230 - 20-30
Börek Universal pan 1 180-190 - 35-45
Quiche Dark coated quiche
tin
1 190-210 - 30-45
Tarte flambée Universal pan 1 240-250
1
- 10-18
1
Preheat the appliance.
40
How it works en
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C/grill setting
Steam
level
Cooking time
in mins
Bake, savoury, cooked
ingredients
Ovenproof dish 1 200-220 - 35-55
Bake, savoury, cooked
ingredients
Ovenproof dish 1 160-170 2 40-50
Potato gratin, raw ingredi-
ents, 4cm deep
Ovenproof dish 1 170-180 - 50-65
Chicken, 1.3kg, un-
stuffed
Wire rack 1 200-220 - 60-70
Chicken, 1.3kg, un-
stuffed
Wire rack 1 200-220 2 50-60
Chicken breast fillet,
steaming
Perforated steam-
ing tray
2 100 - 15-25
Small chicken portions,
250g each
Wire rack 2 200-220 2 30-45
Goose, unstuffed, 3kg Wire rack 1 160-180 - 120-150
Goose, unstuffed, 3kg Wire rack 1 1.
2.
3.
1. 130-140
2. 150-160
3. 170-180
2
2
Off
1. 110-120
2. 20-30
3. 30-40
Joint of pork without rind,
e.g. neck, 1.5kg
Wire rack 1 180-200 - 120-130
Joint of pork without rind,
e.g. neck, 1.5kg
Uncovered cook-
ware
1 180-190 - 120-140
Joint of pork with rind,
e.g. shoulder, 2kg
Uncovered cook-
ware
1 1.
2.
3.
1. 100
2. 170-180
3. 200-210
Off
1
Off
1. 25-30
2. 60-80
3. 20-30
Fillet of beef, medium,
1kg
Wire rack 1 210-220 - 40-50
Fillet of beef, medium,
1kg
Uncovered cook-
ware
1 190-200 1 50-60
Pot-roasted beef, 1.5 kg Covered cookware 1 200-220 - 130-140
Pot-roasted beef, 1.5 kg Covered cookware 1 200-220 - 140-160
Sirloin, medium, 1.5kg Wire rack 1 220-230 - 60-70
Sirloin, medium, 1.5kg Uncovered cook-
ware
1 190-200 1 65-80
Burger, 3–4cm thick Wire rack 2 3 - 20-30
1
Leg of lamb, boned, me-
dium, 1.5kg
Wire rack 1 170-190 - 50-70
Leg of lamb, boned, me-
dium, 1.5kg
Uncovered cook-
ware
1 170-180 1 80-90
Fish, grilled, whole,
300g, e.g. trout
Wire rack 1 170-190 - 20-30
Fish, baked, whole,
300g, e.g. trout
Universal pan 1 1. 170-180
2. 160-170
2
Off
1. 15-20
2. 5-10
Fish, steamed, whole,
300g, e.g. trout
Perforated steam-
ing tray
2 80-90 - 15-25
Fish fillet, plain, steamed Perforated steam-
ing tray
2 80-100 - 10-16
Cauliflower, whole,
steaming
Perforated steam-
ing tray
2 120 - 20-30
Sliced carrots, steaming Perforated steam-
ing tray
2 120 - 5-7
1
Turn the dish 2/3 of the way through the cooking time.
41
en How it works
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C/grill setting
Steam
level
Cooking time
in mins
Spinach, steaming Perforated steam-
ing tray
2 100 - 2-3
Unpeeled boiled pota-
toes, whole
Perforated steam-
ing tray
2 120 - 30-35
Long-grain rice, 1:1.5 Shallow cookware 1 110 - 12-17
Eggs, hard-boiled Perforated steam-
ing tray
2 100 - 9-12
Desserts
Making crème caramel or crème brûlée
1.
Use your preferred recipe to make the mixture for the
crème.
2.
Pour the mixture into moulds until the mixture is
2-3cm deep.
3.
Place the moulds into the perforated steaming tray
(size XL).
4.
Cover food that you would normally cook in a bain
marie with film, e.g. cling film.
5.
Use the recommended settings when configuring the
appliance settings.
6.
If the moulds are made from very thick material, ex-
tend the cooking time.
Making yoghurt
1.
Remove the accessories and shelves from the cook-
ing compartment.
2.
Heat 1litre of whole milk (3.5% fat) to 90°C on the
hob and then leave it to cool down to 40°C.
It is sufficient to heat UHT milk to 40°C.
3.
Mix 150g of chilled yoghurt into the milk.
4.
Pour the mixture into small containers, e.g. cups or
small jars.
5.
Cover the containers with film, e.g. cling film.
6.
Place the containers on the cooking compartment
floor.
7.
Use the recommended settings when configuring the
appliance settings.
8.
After making the yoghurt, leave it to cool in the refri-
gerator for at least 12hours.
Recommended settings for desserts and compote
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Crème brûlée Individual moulds 1 85 - 20-30
Crème caramel Individual moulds 1 85 - 25-35
Yoghurt Individual moulds Cooking
compart-
ment floor
35-40 - 300-360
Cooking whole menus with steam
Recommended settings and further information for
cooking a whole menu at once.
Tips for cooking whole menus
Use suitable accessories and ensure that you place
them into the oven the right way round.
Page10
Shelf positions:
– Steaming tray, size M: Shelf position 3
– Steaming tray, size XL: Shelf position 2
– Universal pan: Shelf position1
Place the food with the longest cooking time into the
cooking compartment first. Add the rest of the food at
the appropriate time. This means that all the food will
be ready at the same time.
Follow the cooking instructions for each of the differ-
ent foods.
– The heat-up time varies depending on the size and
weight of the food.
– The cooking time is unaffected by the quantity of
food.
– Use cookware that is steam-resistant.
– Cover the soufflé with film, e.g. cling film.
– Always insert the universal pan at level 1.
The overall cooking time is extended when cooking
whole meals with steam, as a little steam escapes
each time the appliance door is opened and the
cooking compartment has to be reheated.
Wipe the cooking compartment and dry the condens-
ate drip tray after using it to cook the meal.
42
How it works en
Recommended settings for cooking whole menus
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Peeled boiled potatoes,
quartered
Frozen salmon fillets
Broccoli
Perforated steam-
ing tray, size M
+
Unperforated
steaming tray, size
M
+
Steam containers,
XL size
3+3+2 100 - 1. 30
2. 20
3. 10
29.7 Special cooking methods and other
applications
Information and recommended settings for special
cooking methods and other applications, e.g. low-tem-
perature cooking.
Low-temperature cooking
For all prime cuts which are to be cooked rare or "à
point". When slow cooking at low temperatures, meat
and poultry remain juicy and tender.
Low-temperature cooking poultry or meat
Note: When using the low-temperature cooking type of
heating, you cannot delay the start of the programme by
setting an end time.
Requirement: The cooking compartment is cold.
1.
Use fresh, hygienically perfect meat. Pieces without
bones and without a lot of connective tissue are most
suitable.
2.
Place the cookware onto the wire rack at level 1 in
the cooking compartment.
3.
Preheat the cooking compartment and cookware for
approx. 15minutes.
4.
Sear the meat on all sides on the hob at a very high
heat.
5.
Immediately place the meat into the pre-warmed
cookware in the cooking compartment.
To ensure that the temperature in the cooking com-
partment remains constant, keep the cooking com-
partment door closed during low-temperature cook-
ing.
Tips for low-temperature cooking
Here you will find tips for achieving good results when
low-temperature cooking food.
Issue Tip
You want to cook a
duck breast at a low
temperature.
Place the cold duck breast into
a pan.
Sear the skin side first.
Cook the duck breast at low
temperature.
After low-temperature cooking,
grill the duck breast for 3 to
5minutes until crispy.
You want to serve
your low-temperature
cooked meat as hot
as possible.
Preheat the serving plate.
Make sure that the accompa-
nying sauces are very hot
when you serve them.
Recommended settings for low-temperature cooking
Food Accessory/
cookware
Height Searing
time in
mins
Type of
heating
Temperat-
ure in °C
Steam
level
Cooking time
in mins
Duck breast, medium
rare, 300g each
Uncovered
cookware
1 6-8 95
1
- 45-60
Fillet of pork, whole Uncovered
cookware
1 4-6 85
1
- 45-70
Fillet of beef, 1kg Uncovered
cookware
1 4-6 85
1
- 90-120
Veal medallions, 4cm
thick
Uncovered
cookware
1 4 80
1
- 40-60
Saddle of lamb,
boned, 200g each
Uncovered
cookware
1 4 85
1
- 30-45
Sterilisation and hygiene
You can sterilise heat-resistant cookware or baby bottles
that are in perfect condition. The process is equivalent
to normal sterilisation by boiling.
Sterilising bottles
1.
Clean the bottles with a bottle brush immediately after
use.
2.
Wash the bottles in the dishwasher.
1
Preheat the appliance.
43
en How it works
3.
Place the bottles into the steaming tray (size XL) in
such a way that they do not touch one another.
4.
Start the "Sterilise" programme.
5.
Dry the bottles with a clean cloth.
6.
Wipe down the appliance interior after sterilising.
Useful information on sterilising
Please take note of the following information if you are
sterilising cookware.
You can use your appliance to prepare jam jars or
preserving jars and their lids.
You can perform an additional processing step at the
end in order to improve the jam's shelf life.
Sterilise only heat-resistant cookware that is suitable
for cooking with steam.
Only use clean jars and lids that are in perfect condi-
tion.
Ideally, you should wash the cookware in the dish-
washer before sterilising it.
Recommended settings for hygiene
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Sterilise clean cookware Perforated steam-
ing tray
1 100 - 15-20
Proving dough
Yeast dough proves more quickly in your appliance than
at room temperature and does not dry out.
Requirement: The cooking compartment is cold.
1.
Slide the wire rack into the cooking compartment.
2.
Place the dough onto the wire rack in a bowl.
Do not cover the bowl.
3.
Use the recommended settings when configuring the
appliance settings.
The values are guide values only. The temperature
and proving time are dependent on the type and
quantity of the ingredients.
4.
Do not open the appliance door while the dough is
proving, otherwise moisture will escape.
5.
Wipe the cooking compartment dry before baking in
it.
Recommended settings for proving dough
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Rich dough, e.g. pan-
ettone
Bowl on wire rack 1 40-45 - 40-90
White bread Bowl on wire rack 1 35-40 - 30-40
Reheating
Gently warm up food with added steam. The food tastes
and looks as though it has been freshly cooked. You
can even warm and crisp up baked goods from the day
before.
Tips for reheating food
Use uncovered, heat-resistant cookware that is suit-
able for cooking with steam.
Use wide, shallow cookware. Cold cookware extends
the reheating time.
Place the cookware on the wire rack.
Place food that you are not reheating in cookware
(e.g. bread rolls) directly onto the wire rack at level1.
Do not cover the food.
Do not open the cooking compartment door while the
food is being reheated, otherwise large amounts of
steam will escape.
Wipe the cooking compartment and dry the condens-
ate drip tray after using it to reheat food.
Recommended settings for heating and reheating
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Plated meal, chilled,
1portion
Uncovered cook-
ware
1 120-130 - 15-25
Pizza, cooked, chilled Wire rack 1 170-180
1
- 5-15
Bread rolls, baguette,
baked
Wire rack 1 150-160
1
- 10-20
Pizza, cooked, frozen Wire rack 1 170-180
1
- 5-15
Bread rolls, baguette,
baked, frozen
Wire rack 1 160-170
1
- 10-20
1
Preheat the appliance.
44
How it works en
Keeping food warm
Tips for keeping food warm
Using the "Keep warm" heating function prevents con-
densation from forming. You will not have to wipe
down the cooking compartment.
Do not cover the food.
Do not keep food warming for longer than 2 hours.
Be aware that some types of food will actually con-
tinue cooking when you are keeping them warm in
the oven.
The different added steam levels are suitable for keep-
ing the following foods warm:
Level 1: Joints and briefly roasted food
Level 2: Bakes and side dishes
Level 3: Stews and soups
29.8 Test dishes
The information in this section is provided for test insti-
tutes to facilitate testing of the appliance in accordance
with EN 60350‑1.
Baking
The setting values apply to food that is placed into a
cold cooking compartment.
Take note of the information on preheating in the re-
commended settings tables. These setting values ap-
ply without rapid heat-up.
For baking, use the lower of the temperatures indic-
ated first.
Items that are placed in the appliance on baking trays
or in baking tins/dishes at the same time will not ne-
cessarily be ready at the same time.
Shelf positions when baking on 2levels:
– Universal pan: Shelf position3
Baking tray: Shelf position1
Hot water sponge cake
– When baking on 2levels, place the springform tins
at diagonally opposite corners of the wire racks.
– As an alternative to a pan support, you can also
use the Air Fry baking tray offered by us.
Recommended settings for baking
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Shortbread Baking tray 1 150-160
1
- 25-40
Shortbread Baking tray 1 140-150
1
- 25-35
Shortbread, 2 levels Universal pan
+
Baking tray
3+1 140-150
1
- 25-35
Small cakes Baking tray 1 160
1
- 25-35
Small cakes Baking tray 1 150
1
- 25-35
Small cakes, 2 levels Universal pan
+
Baking tray
3+1 150
1
- 25-35
Hot water sponge cake Springform cake
tin, diameter 26 cm
1 160-170
2
- 25-35
Hot water sponge cake Springform cake
tin, diameter 26 cm
1 160-170
2
- 25-35
Hot water sponge cake Springform cake
tin, diameter 26 cm
1 1. 150-160
2. 150-160
2
1
Off
1. 10
2. 20-30
Steaming
Slide the universal pan into the cooking compartment
below the perforated steaming tray (sizeXL) if instructed
to do so in the recommended settings table.
Shelf positions
Shelf positions when steaming on one level:
Use a maximum of 2.5kg.
Perforated steaming tray, sizeXL: Shelf position2
Shelf positions when steaming on two levels:
Use a maximum of 1.8kg per level.
Perforated steaming tray, sizeXL: Shelf position3
Perforated steaming tray, sizeXL: Shelf position2
1
Preheat the appliance for five minutes. Do not use the rapid heating function.
2
Preheat the appliance. Do not use the rapid heating function.
45
en Installation instructions
Recommended settings for steaming
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C
Steam
level
Cooking time
in mins
Peas, frozen, two contain-
ers
x 2
Steam containers,
XL size
+
Universal pan
3+2+1 100 - -
1
Broccoli, fresh, 300g Steam containers,
XL size
2 100
2
- 8-9
3
Broccoli, fresh, one con-
tainer
Steam containers,
XL size
2 100
2
- 10-11
3
Grilling
Recommended settings for grilling
Food Accessory/cook-
ware
Height Type of
heating
Temperature in
°C/grill setting
Steam
level
Cooking time
in mins
Toasting bread Wire rack 3 3
4
- 3-6
Installation instructions30 Installation instructions
Observe this information when installing the appliance.
30.1 General installation instructions
Follow these instructions before you start in-
stalling the appliance.
¡ The safe operation of this appliance can only
be guaranteed if it has been installed to a
professional standard in accordance with
these installation instructions. The installer
shall be liable for damages incurred as a
result of incorrect installation.
¡ Check the appliance for damage after un-
packing it. Do not connect the appliance if it
has been damaged in transit.
¡ Before starting up the appliance, remove any
packaging material and adhesive film from
the cooking compartment and the door.
¡ Proceed in accordance with the installation
sheets for installing accessories.
¡ Fitted units must be heat-resistant up to
95°C, and adjacent unit fronts up to 70°C.
¡ Do not install the appliance behind a decor-
ative door or the door of a kitchen unit.
There is a risk of overheating.
¡ Cut-out work on the units should be carried
out before installing the appliance. Remove
any shavings. Otherwise, the correct opera-
tion of electrical components may be ad-
versely affected.
¡ Position the appliance on a horizontal sur-
face.
¡ The mains socket for the appliance must
either be located in the hatched area or
outside of the area where the appliance is in-
stalled.
1
The test is over when 85 °C is reached at the coldest spot (see IEC 60350-1).
2
Preheat the appliance.
3
A comparable degree of cooking between the reference sample and the main sample is achieved if the reference sample is
cooked for 5 minutes (produced as described in IEC 60350-1).
4
Do not preheat the appliance.
46
Installation instructions en
1
0.
Any unsecured units must be secured to the
wall using a standard bracket .
¡ For appliances that have a hinged switch
panel, make sure that the switch panel does
not hit adjacent kitchen units when you open
it.
¡ Wear protective gloves so that you do not
cut yourself. Parts that are accessible during
installation may have sharp edges.
¡ Dimensions of the figures in mm.
WARNING‒Risk of electric shock!
Once the appliance has been installed, the
openings in the back panel of the appliance
must not be accessible to children, not even
through the drawers and kitchen cabinets un-
derneath. This must be ensured through the in-
stallation. In the case of an island unit, a
closed back panel is required.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord
and non-approved adapters.
Do not use extension cables or multiple
socket strips.
Only use adapters and power cords ap-
proved by the manufacturer.
If the power cord is too short and a longer
one is not available, please contact an elec-
trician to have the domestic installation ad-
apted.
ATTENTION
Carrying the appliance by the door handle
could break it. The door handle cannot sup-
port the weight of the appliance.
Do not carry or hold the appliance by the
door handle.
30.2 Appliance dimensions
You will find the dimensions of the appliance here
30.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
To ventilate the appliance, the intermediate floor must
have a ventilation cut-out.
The worktop must be secured to the fitted unit.
Observe any available installation instructions for the
hob.
Observe different national installation instructions for
the hob.
47
en Installation instructions
30.4 Installation underneath a hob
If the appliance is installed under a hob, the following minimum dimensions must be adhered to (including substruc-
ture, if applicable).
The minimum worktop thickness a is based on the required minimum clearance .
Hob type a raised in mm a flush in mm b in mm
Induction hob 42 43 5
Full-surface induction hob 52 53 5
Gas hob 32 43 5
1
Electric hob 32 35 2
30.5 Installation in a tall unit
Observe the installation dimensions and the installation
instructions when installing in a tall unit.
To ventilate the appliance, the intermediate floors
must have a ventilation cut-out.
Only fit the appliance up to a height which allows ac-
cessories to be easily removed.
30.6 Installing two appliances on top of each
other
Your appliance can also be installed above or below an-
other appliance. Observe the installation dimensions
and the installation instructions when installing appli-
ances on top of each other.
To ventilate the appliances, the intermediate floor
must have a ventilation cut-out.
To ensure sufficient ventilation of the two appliances,
there must be a ventilation opening of at least
200cm² in the base area. To do this, trim the base
panel or fit a ventilation grille.
1
Observe different national installation instructions for the hob.
48
Installation instructions en
Ensure that air exchange is guaranteed in accord-
ance with the diagram.
Only fit appliances up to a height that allows ac-
cessories to be easily removed.
30.7 Corner installation
Observe the installation dimensions and the installation
instructions when installing in a corner.
To ensure that the appliance door can be opened,
you must take the minimum dimensions into consider-
ation when installing in a corner. The dimension is
dependent on the thickness of the unit front and the
handle.
30.8 Electrical connection
In order to safely connect the appliance to the electrical
system, follow these instructions.
The appliance corresponds to protection class I and
must only be operated with a protective earth connec-
tion.
The fuse protection must correspond to the power rat-
ing specified on the appliance's rating plate and to
the local regulations.
The appliance must be disconnected from the power
supply whenever installation work is being carried
out.
The appliance must only be connected using the
power cable provided.
The power cable must be plugged in at the rear of
the appliance until you hear a clicking sound. A 3 m
power cable can be obtained from customer service.
The power cable must only be replaced with a cable
from the original manufacturer. This is available from
after-sales service.
Contact protection must be guaranteed by the install-
ation.
If the display on the appliance remains dark, it has
not been connected correctly. Disconnect the appli-
ance from the mains and check the connection.
Electrically connect the appliance with the
protective contact plug
Note: The appliance must only be connected to a pro-
tective contact socket that has been correctly installed.
Insert the plug into the protective contact socket.
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access
is not possible, an isolating switch must be integrated
into the permanent electrical installation according to
the installation regulations.
Electrically connecting an appliance without a
protective contact plug
Note: Only licensed specialists may connect the appli-
ance. Damage caused by incorrect connection is not
covered under the warranty.
An isolating switch must be integrated into the perman-
ent electrical installation according to the installation
regulations.
1.
Identify the phase and neutral conductors in the
socket.
The appliance may be damaged if it is not connected
correctly.
2.
Connect the hob in accordance with the connection
diagram.
See the rating plate for the voltage.
3.
Connect the wires of the mains power cable accord-
ing to the colour coding:
Green/yellow = Protective conductor
Blue = Neutral conductor
Brown = Phase (external conductor)
49
en Installation instructions
30.9 Installing the appliance
1.
Slide the appliance in fully and centre it.
2.
Screw the appliance into place.
Note: The gap between the worktop and the appliance
must not be closed by additional battens.
Thermal insulation strips must not be fitted to the side
panels of the surround unit.
30.10 For handleless kitchens with vertical
bar handle strips:
1.
Attach a suitable filling piece on both sides in order
to cover any sharp edges and to guarantee safe in-
stallation.
2.
Secure the filling piece to the unit.
3.
Pre-drill the filling piece and the unit to establish a
screw connection.
4.
Secure the appliance using a suitable screw.
30.11 Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Undo the fastening screws.
3.
Lift the appliance slightly and pull it out completely.
50
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9001681959*
9001681959 (050311) REG25
en
