OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
T1185NEHT / T1185NEHT2 / T1385NEHT2 / T1385NEHTG
MFL71985813
Rev.00_100824
www.lg.com
Copyright © 2024 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
INSTALLATION
Parts and Specifications ....................................................................................8
Installation Place Requirements ....................................................................10
Connecting the Water Inlet Hoses.................................................................11
Installing the Drain Hose ................................................................................13
Levelling the Appliance ...................................................................................14
OPERATION
Operation Overview.........................................................................................16
Preparing the Wash Load ...............................................................................16
Adding Detergents, Softeners and Bleaches................................................18
Control Panel ....................................................................................................20
Programme Table ............................................................................................22
Extra Options and Functions ..........................................................................25
SMART FUNCTIONS
LG ThinQ Application.......................................................................................28
Smart Diagnosis ...............................................................................................28
MAINTENANCE
Cleaning after Every Wash ..............................................................................29
Cleaning the Appliance Periodically ..............................................................29
TROUBLESHOOTING
Before Calling for Service................................................................................33
3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following:
Technical Safety
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
This symbol is displayed to indicate matters and operations that
can cause risk. Read the part with this symbol carefully and
follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can cause
serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can cause
minor injury or damage to the product.
4
SAFETY INSTRUCTIONS
• Children should be supervised to ensure that they do not play with
the appliance.
• Cleaning and user maintenance shall not be made by children
without supervision.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• Ventilation openings must not be obstructed by a carpet.
• This appliance is intended to be used in household only.
• Use a new hose or hose-set supplied with the appliance. Reusing old
hoses can cause a water leak and subsequent property damage.
• The inlet water pressure must be between 50 and 800 kPa.
Maximum Capacity
The maximum capacity in some cycles for dry clothes to be washed is:
Installation
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• This appliance should only be transported by two or more people
holding the appliance securely.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Make sure the power plug is completely pushed into the power
outlet.
• Do not plug the appliance into multiple outlet sockets or an extension
power cable.
T1185NEHT / T1185NEHT2 T1385NEHT2 / T1385NEHTG
11 kg 13 kg
5
SAFETY INSTRUCTIONS
ENGLISH
• Do not modify the power plug provided with the appliance. If it does
not fit the power outlet, have a proper outlet installed by a qualified
electrician.
• This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current.
• This appliance is equipped with a power cord having an equipment-
grounding conductor and a grounding power plug. The power plug
must be plugged into an appropriate outlet socket that is installed
and grounded in accordance with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
• Tighten and secure the drain hose at connecting ends to avoid
separation.
• For models with only one inlet water supply valve, do not connect to
hot water. Connect to cold water only.
Operation
• Do not apply any sharp objects to the control panel in order to
operate the appliance.
• Do not attempt to separate any panels or disassemble the appliance.
• Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner's Manual. Use only
authorized factory parts.
• Do not put animals, such as pets into the appliance.
• Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
• Do not leave the appliance door open. Children may hang on the door
or crawl inside the appliance, causing damage or injury.
• Do not put in, wash or dry articles that have been cleaned in, washed
in, soaked in, or spotted with combustible or explosive substances
6
SAFETY INSTRUCTIONS
(such as waxes, wax removers, oil, paint, gasoline, degreasers,
drycleaning solvents, kerosene, petrol, spot removers, turpentine,
vegetable oil, cooking oil, acetone, alcohol, etc.). Improper use can
cause fire or explosion.
• Do not use or store flammable or combustible substances (ether,
benzene, alcohol, chemical, LPG, combustible spray, insecticide, air
freshener, cosmetics, etc.) near the appliance.
• Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
• In case of a water leak from the appliance, disconnect the power plug
and contact the LG Electronics customer information centre.
• Turn off water taps to relieve pressure on hoses and valves and to
minimize leakage if a break or rupture should occur. Check the
condition of the fill hoses; they may need replacement after 5 years.
• If there is a gas leakage (isobutane, propane, natural gas, etc.) within
the home, do not touch the appliance or power plug and ventilate the
area immediately.
• If the drain hose or inlet hose is frozen during winter, use it only after
thawing.
• Keep all washing detergents, softener and bleach away from
children.
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.
• Do not put your hand, foot or anything under the appliance while the
appliance is in operation.
• Avoid touching any water that is drained from the appliance during
the wash.
• Make sure that drainage is working properly. If water is not drained
properly, your floor may get flooded.
• If, during spinning, opening the door does not stop the drum within
about 10 seconds, immediately discontinue operating the appliance
and contact your dealer or LG Electronics service centre.
7
SAFETY INSTRUCTIONS
ENGLISH
• Do not use a power outlet, wiring equipment and extension cord of
which the electric capacity is lower than the appliance's rated
capacity.
• When the air temperature is high and the water temperature is low,
condensation may occur and thus wet the floor.
• Wipe off dirt or dust on the contacts of the power plug.
Maintenance
• Disconnect the appliance from the power supply before cleaning the
appliance. Setting the controls to the OFF or stand by position does
not disconnect this appliance from the power supply.
• Securely plug the power plug in the outlet socket after completely
removing any moisture and dust.
• Do not spray water inside or outside the appliance to clean it.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the outlet
socket.
• Only qualified service personnel from LG Electronics service centre
should disassemble, repair, or modify the appliance. Contact an LG
Electronics customer information centre if you move and install the
appliance in a different location.
Disposal
• Before discarding an old appliance, unplug it. Cut off the cable
directly behind the appliance to prevent misuse.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Remove the door before disposing of or discarding this appliance to
avoid the danger of children or small animals getting trapped inside.
8
INSTALLATION
INSTALLATION
Parts and Specifications
NOTE
• Appearance and specifications may change without notice to improve the quality of the appliance.
Front View
a
Door
b
Handle
c
Tempered Glass
d
Detergent Dispenser Drawer
e
Fabric Softener Dispenser
f
Bleach Dispenser
g
Drum
h
Levelling Feet
i
Drain Hose
*1
j
Control Panel
k
Lint Filter
*1
l
Power Cord
m
Hot and Cold Water Inlets
*1 This feature is only available on some models.
Accessories
*1 The included accessories vary depending on the
model you purchased.
*2 This accessory is not included in the product, but
you can purchase it from the LG service centre.
a
Cold and Hot Water Inlet Hoses
*1
b
Drain Hose
*1
c
Anti-Rat Cover
*2
d
Screw for Anti-Rat Cover
*2
9
INSTALLATION
ENGLISH
Specifications
Dimension(mm)
Model
TT1185NEHT / T1185NEHT2 / T1385NEHT2 /
T1385NEHTG
Power Supply 220 V~, 50 Hz
Product Weight Approx. 38 kg
W 590 D 610 H 965
D' 620 H' 1310
H
H’
D
D’
W
10
INSTALLATION
Installation Place
Requirements
Before installing the appliance, check the following
information in order to install the appliance in a
correct place.
Unpacking Shipping Material
1
Lift the appliance off of the foam base.
• After removing the carton and shipping
material, lift the appliance off the foam base.
• Make sure the plastic tub support
a
comes
off with the base and is not stuck to the
bottom of the appliance.
• If you must lay the appliance down to
remove the carton base
b
, always protect
the side of the appliance and lay it carefully
on its side. Do not lay the appliance on its
front or back.
NOTE
• Do not use the appliance on carton base
b
.
Doing so may damage the appliance.
2
Remove the foam tub insert.
• To prevent damage, do not remove the foam
insert
c
from the tub until the appliance is in
the final location.
NOTE
• Once removed, save the foam insert for future
use. If the appliance needs to be moved, the
foam insert will help prevent damage during
transportation.
3
Unfasten the power cord.
• Unfasten the power cord from the back of
the appliance.
Installation Location
• Install the appliance on a flat floor of hard
material that is strong enough to support a fully
loaded appliance. (Allowable slope under the
appliance: 1º)
• Never try to level any uneven floor by putting
pieces of wood, cardboard or similar materials
under the appliance.
11
INSTALLATION
ENGLISH
• If it is impossible to avoid positioning the
appliance next to a gas cooker or coal burning
stove, an insulation (85 X 60 cm) covered with
aluminium foil on the side facing the cooker or
stove must be inserted between the two
appliances.
• Ensure that when the appliance is installed, it is
easily accessible for a service technician in the
event of a breakdown.
• Additional clearance for the wall should have
10
cm
for the rear and
2 cm
for right and left side.
WARNING
• This appliance must only be used for domestic
household purposes and should not be used
with movable home or house.
NOTE
• Do not install this appliance on a raised surface
or platform, plinth or stand. It may cause injury
or serious malfunctioning.
Ventilation
• Make sure that air circulation around the
appliance is not impeded by carpets, rugs, etc.
Ambient Temperature
• Do not install the appliance in rooms where
freezing temperatures may occur. Frozen hoses
may burst under pressure. The reliability of the
electronic control unit may be impaired at
temperatures below freezing point.
• If the appliance is delivered in winter and
temperatures are below freezing, place the
appliance at room temperature for a few hours
before putting it into operation.
Electrical Connection
• Do not use an extension cord or double adapter.
• Always unplug the appliance and turn off the
water supply after use.
• Connect the appliance to an earthed socket in
accordance with current wiring regulations.
• The appliance must be positioned so that the
plug is easily accessible.
• Power outlet must be within 1.5 meters of either
side of the appliance.
WARNING
• Repairs to the appliance must only be carried out
by qualified personnel. Repairs carried out by
inexperienced persons may cause injury or
serious malfunctioning. Contact your local
authorised LG repairer.
• The power plug must be plugged into an
appropriate outlet socket that is installed and
grounded/earthed in accordance with all local
codes and ordinances.
Connecting the Water Inlet
Hoses
Before connecting the water inlet hose to the water
tap, check the hose fitting type and follow the
instructions for that hose fitting.
Note for Connection
• Water supply pressure must be between
50 kPa
and
800 kPa
(0.5 - 8.0 kgf / cm
2
). If the water
supply pressure is more than
800 kPa
, a
decompression device should be installed.
• Do not overtighten the water inlet hose to the
valve.
• Periodically check the condition of the hose and
replace the hose if necessary.
12
INSTALLATION
Checking the Rubber Seals
Two rubber seals
a
are supplied with the water
inlet hoses. They are used to prevent leaks when
the connections to the taps are properly tightened.
Do not over tighten connections.
• Do not use mechanical devices such as multi
grips to tighten the inlet hoses. Ensure that the
curved end of the water inlet hose is connected
to the appliance.
Connecting the Hose to the
Water Tap
Connecting Screw-Type Hose to Tap with Thread
Screw the hose connector onto the water supply
tap.
Connecting Screw-Type Hose to Tap Without
Thread
1
Loose the 4 fixing screws
a
.
2
Remove the guide plate
b
if the tap is too large
to fit the adapter.
3
Push the adapter onto the end of the tap so
that the rubber seal is connected to be
watertight. Tighten the 4 fixing screws.
4
Push the inlet hose
c
vertically upwards so
that the rubber seal within the hose can adhere
completely to the tap and then tighten the
hose by screwing it to the right.
Connecting One Touch Type Hose to Tap
Without Thread
1
Unscrew the adapter ring plate
d
and loose
the 4 fixing screws.
13
INSTALLATION
ENGLISH
2
Remove the guide plate
e
if the tap is too large
to fit the adapter.
3
Push the adapter onto the end of the tap so
that the rubber seal is connected to be
watertight. Tighten the 4 fixing screws and the
adapter ring plate.
4
Pull the connector latch plate
f
down, push
the inlet hose onto the adapter, and release the
connector latch plate. Make sure the adapter
locks into place.
NOTE
• After connecting the water inlet hose to the
water tap, turn on the water tap to flush out
foreign substances (dirt, sand, sawdust, and etc.)
in the water lines. Let the water drain into a
bucket, and check the water temperature.
Connecting the Hose to the
Appliance
Screw the water inlet hose to the water inlet valve
on the back of the appliance.
• On models with only one water inlet, do not
connect the hose to the hot water supply.
Connect to the cold water supply only.
NOTE
• After completing the connections, check for
leaks and tighten or reassemble the connections
if needed.
Installing the Drain Hose
Before connecting the drain hose, check your drain
hose model and follow the instructions for that
model.
Installing the Drain Hose in a
Floor Drain
1
Push the elbow end of the hose onto the drain
outlet on the back of the appliance.
14
INSTALLATION
2
To change the direction of the drain hose,
remove it and reinstall it facing in the correct
direction.
Positioning the Drain Hose
• The length
a
of the drain hose should not
exceed
300 cm
. Do not place the drain hose
b
more than
6 cm
above the floor.
• The outlet of the drain hose should not be
submerged in water.
• Make sure the drain hose is not kinked.
Levelling the Appliance
Checking the Level
Levelling the appliance prevents unnecessary
noise and vibration. Check whether the appliance is
perfectly level after installation.
• If the appliance rocks when pushing the top
plate of the appliance diagonally, adjust the feet
again.
Adjusting and Levelling the
Feet
When the appliance is not perfectly level, turn the
adjustable feet until the appliance no longer
wobbles.
• Turn the adjustable feet clockwise to raise or
turn the adjustable feet counterclockwise to
lower the appliance.
NOTE
• Do not insert pieces of wood etc. under the feet.
• Timber or suspended type flooring will
contribute to excessive vibration and unbalance.
Reinforcing or bracing the timber floor may be
need to stop or reduce excessive noise and
vibration.
• Do not install the appliance on any elevated
surface or platform, as it may become unstable
and cause serious injury and damage.
• If the appliance is installed on a uneven, weak or
tilted floor causing excessive vibration, spin
failure or
UE
error can occur. It must be placed
on a firm and level floor to prevent spin failure.
15
INSTALLATION
ENGLISH
Assembling the Anti-Rat Cover
You can insert the anti-rat cover according to the
type to protect the appliance from the rat.
1
Lay the anti-rat cover so that the word
UP
is
visible.
2
Stand at the back of the appliance and tilt it
inward.
3
Insert the anti-rat cover to the assembling hole
at the bottom of the appliance.
16
OPERATION
OPERATION
Operation Overview
Using the Appliance
Before the first wash, select the
Normal
programme and add a half amount of detergent.
Start the appliance without clothes.
• This will remove residue and water from the
drum that may have been left during
manufacturing.
1
Sort clothes and load items.
• Sort clothes by fabric type, soil level, colour
and item size as needed. Open the door and
load items into the appliance.
2
Add detergent, fabric softener and/or bleach.
• Add the proper amount of detergent to the
detergent dispenser drawer. If desired, add
bleach or fabric softener to the appropriate
areas of the dispenser.
3
Turn on the appliance.
• Press the
POWER
button to turn on the
appliance.
4
Choose the desired wash cycle.
• Press the
Program
button repeatedly until
the desired programme is selected.
• Select the option button to adjust wash
temperature, spin speed, etc. Refer to a
fabric care label of your clothes for any
warning or special instructions.
5
Begin cycle.
• Press the
START/PAUSE
button to begin the
cycle.
• The appliance will agitate briefly without
water to measure the weight of the clothes.
• If the
START/PAUSE
button is not pressed
within a certain time, the appliance will shut
off and all settings will be lost.
6
End of cycle.
• When the cycle is finished, a melody will
sound. Immediately remove your clothing
from the appliance to reduce wrinkling.
NOTE
• The
Auto Restart
function allows the cycle to
restart by itself in case of power failure. It
resumes from the stage where it stopped.
Preparing the Wash Load
Sort the wash load for best washing results, and
then prepare the clothes according to the symbols
on their care labels.
Sorting the Clothes
• For best washing results, sort your clothes
according to a care label stating fabric type and
washing temperature. Adjust the spin speed to
wash them.
• Soil level (Heavy, Normal, Light): Separate
clothes according to soil level. If possible, do not
wash heavily soiled items with lightly soiled
ones.
• Colour (White, Lights, Darks): Wash separately
dark or dyed clothes from whites or light colours.
Mixing dyed clothes with light clothes can result
in dye transfer or discolouration of lighter
clothes.
• Lint (Lint producers, Collectors): Wash separately
lint producing fabrics from lint collecting fabrics.
Lint producers can result in pilling and linting on
the lint collectors.
17
OPERATION
ENGLISH
Checking the Fabric Care Label
This will tell you about the fabric content of your
clothes and how it should be washed.
Symbols on the Care Labels
NOTE
• The dashes under the symbol give you
information about the type of fabric and the
maximum allowance of mechanical stress.
Checking the Laundry before
Loading
• Combine large and small items in a load. Load
large items first. Large items should not be more
than half of total load.
• Do not wash single small items. Add 1 - 2 similar
items to the load to prevent an out-of-balance
load.
• Make sure to empty all pockets. Items such as
hair clips, lighters, pens, coins and keys can
cause irreparable damage to both your
appliance and clothes.
• Wash delicates (stockings, underwired bras) in a
wash net.
• Close zippers, hooks and strings to make sure
that these items do not snag other clothes.
• Pre-treat dirt and stains by saturating the dirt
and stains with dissolved detergent and
brushing them in order to remove dirt.
CAUTION
• Do not wash or spin any item labelled or known
to be water-proof or water-resistant, even if the
product care label on the item permits machine
washing. Failure to follow these instructions
could result in severe damage to your washing
load, your appliance and/or property damage as
a result of abnormal load friction or vibration of
the appliance.
- Examples of water-proof or water-resistant
items include certain mattress pads, mattress
covers, rain gear, camping gear, skiing
apparel, outdoor gear and similar items.
Symbol Wash / Fabric type
• Normal Wash
• Cotton, Mixed Fabrics
• Easy Care
• Synthetic, Mixed Fabrics
• Special Delicate Wash
• Delicates
• Hand Wash Only
• Wool, Silk
• Do not wash
18
OPERATION
Adding Detergents,
Softeners and Bleaches
Detergent Dosage
• Detergent should be selected according to fabric
type, colour, soil level and washing temperature
and should be used according to the detergent
manufacturer’s instructions.
• Too much detergent results in excessive suds
which cause poor washing.
• When you use liquid detergent, follow the
guidelines provided by the detergent
manufacturer.
• You can pour liquid detergent directly into the
main detergent drawer if you are starting the
wash cycle immediately. It is also recommended
that it be added into the drum when loading the
clothes.
• Do not use liquid detergent if you are using delay
or pre-wash function as the liquid may harden.
• Reduce the amount of detergent if too many
suds are formed.
• Detergent usage may need to be adjusted for
water temperature, water hardness, size and soil
level of the laundry. For best results, avoid
oversudsing.
• Refer to the label of the clothes, before choosing
the detergent and water temperature.
• Use only suitable detergents for the respective
type of clothing:
- General powdered detergents for all types of
fabric
- Powdered detergents for delicate fabric
- Liquid detergents for all types of fabric or
designated detergents only for wool
• For better washing performance and whitening,
use detergent that contains general powdered
bleach.
• Detergent is dispensed from the dispenser at the
beginning of the cycle.
• Dilute liquid detergent with water, pour into the
drum and start the cycle.
CAUTION
• Using liquid detergent without diluting, or
leaving laundry for a long time after pouring
diluted liquid detergent into the drum might
cause the clothes to be damaged, bleached,
discoloured.
NOTE
• Do not let the detergent harden. Doing so may
lead to blockages, poor rinse performance or
odour.
• Full load: According to manufacturer’s
recommendation.
• Part load: 3/4 of the normal amount
• Minimum load: 1/2 of full load
Adding Detergents
• Add the measured amount of detergent into the
detergent compartment
a
.
• Use more detergent if you have hard water,
large items, greasy or oily soils or lower water
temperature.
• Soap flakes or granulated soap powders should
not be used in the appliance. When washing
woollens, remember to use detergent suitable
for washing woollens.
NOTE
• Use the appropriate amount of detergent. Too
much detergent, bleach or softener may cause
an overflow or a malfunction.
19
OPERATION
ENGLISH
Adding Fabric Softeners
• Dilute fabric softener with water. Undiluted
fabric softener may result in spots that look like
oil stain.
• Measure and add the recommended amount of
fabric softener into the compartment marked
with the symbol on the top tub.
- Follow manufacturer’s direction.
- Fabric softener is automatically dispensed in
the final rinse with indication beep.
- If you add the number of rinse or select one of
the two programmes (
Duvet
or
Extra Clean
),
you must add fabric softener by hand during
the rinse cycle when a melody sounds. The
softener permeates into fabric fibers, making
clothes feel softer.
• Do not overfill. The dispenser holds max 35 mL.
Never add more than 35 mL. Overfilling can
cause early dispensing of the fabric softener
which could result in stained clothes. A cup with
a pouring spout will help you avoid spelling.
• The effect of adding fabric softener may vary
according to its viscosity. The sticker fabric
softener makes its effect lower. For a sticky
softener it is recommended that it be diluted
with water, then be manually put during the time
when the washer beeps several times before the
final rinse. This function informing correct time
dispense manually is optionally applied to some
models. Please keep it in mind that fabric
softener has to be diluted with water before
dispensed and poured directly on clothes.
NOTE
• Do not mix with detergent or bleach.
• Never pour fabric softener directly on clothes. It
may stain them.
• Do not stop the washer during the first spin for
timely dispensing.
• Option washing is not designed to be used with
fabric softener dispenser.
Adding Liquid Bleaches
• Before starting the appliance, pour the
measured amount of bleach directly into the
bleach dispenser
a
. Avoid splashing or
overfilling.
• Mix powdered bleach with water to a liquid
consistency and pour it into the bleach
dispenser.
• Check clothing care label for special instructions
and separate the laundry to be bleached.
• Dilute liquid chlorine bleach with water.
• Measure the recommended amount of liquid
bleach carefully according to instructions on the
bottle.
CAUTION
• Never pour undiluted liquid bleach directly onto
laundry or into the wash basket. This may cause
change of colour or damage to the laundry.
• Do not pour powdered bleach into the bleach
dispenser. Powdered bleach may harden, so it
will block the bleach dispenser.
20
OPERATION
Control Panel
Control Panel Features
a
POWER
Button
• Press this button to turn on or off the appliance.
• The appliance automatically turns off once a certain time has passed after the wash has completed.
b
START/PAUSE
Button
• Press this button to start or pause a wash cycle.
• Press this button to stop a wash cycle temporarily.
NOTE
• If the wash is not recommenced within
60 minutes
when in pause, then the appliance will automatically
turn off.
c
Program
Button
• Programmes are available according to the laundry type.
• The lamp will light up to indicate the selected programme.
d
Extra Options and Functions
• You can use the extra options and functions to customize the programmes.
e
Cycle Status Indicator
• The cycle status indicator is turned on before the start.
• The cycle status indicator blinks during that process, and then the indicator turns off when that
process has completed.
f
Display
• The display shows the settings, remaining estimated time, options, and status messages. When the
appliance is turned on, the default settings in the display will light up.
21
OPERATION
ENGLISH
•
88
: When a programme is selected, the default time for that programme is displayed. The time can
change as options are selected.
- The time shown is only an estimate. Several external factors (laundry size, room temperature,
incoming water temperature, etc.) can affect the actual time.
•
F
: This icon turns on when the load sensing has detected the laundry size.
•
Y
: This icon turns on when the
Water Level
button is pressed to adjust the water level. When the
water level is selected, the water level is indicated in the time display.
•
min
: This icon turns on when the remaining time is indicated in the time display.
•
Q
: This icon turns on when the
Program
button is pressed to select the desired programme.
22
OPERATION
Programme Table
Washing Programme
Wash programmes are designed for the best wash performance for different types of clothes.
• Press the
Program
button to select the desired programme.
• When you select a wash programme, the light for the corresponding wash programme will turn on.
Normal
Description Use this programme to wash normal laundry. The built-in sensor detects the
weight of the laundry, calculating wash, rinse and, spin settings accordingly.
• If water or wet laundry is already in the drum before the start, the water level
will be increased.
• For lightweight and bulky items, the water level may be too low. Increase the
water level manually.
Wool
Description Use this programme to wash delicate fabrics such as lingerie and woollens. Before
washing, check the care label for the washing instructions.
• This programme uses a slow spin to prevent the clothes from being damaged,
so the laundry has more moisture than normal.
NOTE
• Hang or lay your delicates flat when you dry them.
• Only cold water will be used for this programme as hot water may damage
laundry.
23
OPERATION
ENGLISH
Duvet
Description Use this programme to wash a blanket or bedclothes that have the hand wash sign
on the care label.
• Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket,
infilling (polyester 101), and bed sheets might be damaged if they are allowed
to float. It is recommended to purchase a separate laundry net to wash.
• Separate bed clothes from general clothes. It might cause laundry to be
unbalanced, which results in abnormal washing.
• Spin dry might take longer to redistribute the laundry evenly if bedclothes are
lumped to a side.
• Never wash an electric blanket, carpets, rugs, pet accessories, soft toys or shoes.
It can cause damage to the appliance and other items in the wash.
• Put bedclothes into a laundry net and then soak and sink them in water so that
they are less likely to float. If the items float during the wash or spin, it may
damage the appliance and the clothes.
• Regardless of size, we recommend washing bedclothes individually. If two
bedclothes with different materials are washed at the same time, it might cause
a spin malfunction due to imbalance.
CAUTION
• When putting a blanket into the drum, do not load it over the maximum line
a
.
The blanket must also be submerged in the water. Failure to do so or
overloading the blanket in the appliance will result in damage to the wash load
and the appliance.
Rinse+Spin
Description Use this programme to rinse and spin laundry separately from a regular
programme.
• This can be helpful in preventing fresh stains from setting in fabrics.
CAUTION
• When you select this option, do not add the fabric softener into the softener
dispenser. It may cause stain clothes.
24
OPERATION
Pre Wash+Normal
Description Use this programme to pretreat immediate stain without handwash.
• It is necessary for clothes which could smell bad if they are not washed
promptly.
Quick Wash
Description Use this programme to wash lightly soiled clothes for a short time.
• This programme's recommended laundry amount is under
2.5 kg
.
Extra Clean
Description Use this programme to increase rinsing performance.
• This programme is recommended for underwear and baby clothes.
• If someone has sensitive skin or skin trouble, use this programme.
Tub Clean
Description This is a special function to clean inside the drum of your appliance.
• To use this function, refer to the
MAINTENANCE
for details.
25
OPERATION
ENGLISH
Extra Options and
Functions
You can use the extra options and functions on
some programmes to customize the cycle.
Customising a Washing
Programme
Each programme has default settings that are
selected automatically. You may also customise
these settings using these buttons.
Water Level
This appliance detects the amount of laundry
automatically, then sets the water level. However,
manually increasing the water level may be
required and recommended to avoid linting and
unbalanced errors when the load is bulky but
lightweight.
• Press
Water Level
option to adjust water level.
• When you select a wash programme, the water
level will be shown on the control panel.
• When water level is automatically detected, it
may differ depending on the amount of laundry
even though the same water level is indicated on
the control panel.
Temp.
Press the
Process
button for 3 seconds repeatally
to select the desired water temperature.
• The default water temperature is cold.
• The selected water temperature is confirmed by
the letters on the control panel.
- Cold water:
[
- Warm water:
H[
- Hot water:
H
• When the washing machine is turned off and on
again, the water temperature is set to cold
water.
Using Basic Options
Process
When you need a wash+rinse+spin, spin only,
rinse+spin, rinse only, wash+rinse, wash only cycle,
these can be set manually.
• Press the
Process
button to select wash, rinse
and spin options as desired.
1
Press the
POWER
button.
2
Press the
Process
button until the LED lights
up.
• When you select a programme, the LED in
front of each option lights up.
3
Press the
Water Level
button to adjust the
water level according to the amount of laundry.
4
Add laundry into the drum.
5
Press the
START/PAUSE
button to start the
cycle(s).
6
Add the detergent into the detergent
dispenser and close the door.
NOTE
• When you set a washing cycle manually such as
rinse only, wash only or wash and rinse, the
water will not be drained out after the wash is
completed. If you wish to drain the water, select
a spin only cycle after the wash has completed.
• If a rinse only cycle is selected, the water supply
is started after detecting the load and this cycle
will start. However this cycle will start to supply
water of the selected water level if there is
already water in the drum.
• If you do not select or change the
Water Level
,
the water level will be set automatically.
Setting
Child Lock
Use
Child Lock
function to disable the controls.
This function can prevent children from changing
programmes or operating this appliance.
26
OPERATION
NOTE
• Once this function is set, all buttons are locked
except the
POWER
button.
• When the controls are locked,
CL
and the
remaining time are alternatively shown on the
display during the wash while the child lock is
engaged.
• Turning off the power will not reset this function.
You must deactivate this function before you can
access any other options and functions.
Locking the Control Panel
1
Turn on the power.
2
Press and hold the
Water Level
and
Program
buttons simultaneously for 3 seconds to
activate this function.
Unlocking the Control Panel
1
Turn on the power.
2
Press and hold the
Water Level
and
Program
buttons simultaneously for 3 seconds to
deactivate this function.
• When this function is deactivated, a beeper
will sound and the remaining time for the
current cycle will reappear on the display.
27
OPERATION
ENGLISH
Manual Washing
When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually.
NOTE
• When you set a washing cycle manually such as rinse only, wash only or wash and rinse, the water will
not be drained out after the wash is completed. If you wish to drain the water, select a spin only cycle
after the wash has completed.
• If a rinse only cycle is selected, the water supply begins after detecting the load and the cycle will start.
However the water will still fill to the selected water level even if there is water already in the tub.
• If you do not select or change the water level, the water level will be set automatically.
Spin only Rinse and Spin Rinse only Wash and Rinse Wash only
1
s
or
t
Press the
POWER
button.
2
Press the
Process
button.
Press the
Process
button 2 times.
Press the
Process
button 3
times.
Press the
Process
button 4 times.
Press the
Process
button 5
times.
3
Spin is
automatically
selected.
Rinse and spin are
automatically
selected.
Rinse is
automatically
selected.
Wash and rinse
are automatically
selected.
Wash is
automatically
selected.
4
u
Press the
START/PAUSE
button to start the cycle(s).
28
SMART FUNCTIONS
SMART FUNCTIONS
LG ThinQ Application
The
LG ThinQ
application allows you to
communicate with the appliance using a
smartphone.
LG ThinQ Application Features
Smart Diagnosis
This function provides useful information for
diagnosing and solving issues with the appliance
based on the pattern of use.
Installing the LG ThinQ
Application
Search for the
LG ThinQ
application from the
Google Play Store or Apple App Store on a
smartphone. Follow instructions to download and
install the application.
Smart Diagnosis
Use this feature to help you diagnose and solve
problems with your appliance.
NOTE
• The feature may be subject to change without
prior notice and may have a different form
depending on where you are located.
Using Audible Diagnosis to
Diagnose Issues
Follow the instructions below to use the audible
diagnosis method.
• Launch the
LG ThinQ
application and select the
Smart Diagnosis
feature in the menu. Follow
the instructions for audible diagnosis provided
in the
LG ThinQ
application.
1
Press the
POWER
button to turn on the
appliance.
• Do not press any other buttons.
2
Place the mouthpiece of your smartphone
close to the
POWER
button.
3
Press and hold the
Water Level
button for 3
seconds or longer while holding the
smartphone mouthpiece to the
POWER
button
until the data transfer is complete.
• Keep the smartphone in place until the data
transfer has finished. Time remaining for
data transfer is displayed.
4
After the data transfer is complete, the
diagnosis will be displayed in the application.
NOTE
• For best results, do not move the smartphone
while the tones are being transmitted.
29
MAINTENANCE
ENGLISH
MAINTENANCE
WARNING
• Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning
may result in serious injury, fire, electric shock, or death.
• Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the
finish.
Cleaning after Every Wash
What to Clean
• If you always use cold water, we recommend
that a warm or hot wash be used at regular
intervals e.g. every 5th wash should be at least a
warm one.
• Turn off taps after use to prevent the chance of
flooding, otherwise an inlet hose may burst.
• Always unplug the power cord after use.
• After the cycle, wipe the door and inside the door
to remove any moisture. Also wipe the inside of
the tub thoroughly to prevent stains in the upper
part of the tub.
• Clean around the bleach dispenser with water to
flush any residual bleach from the dispenser
opening as bleach can be corrosive if left
undiluted.
WARNING
• Leave the door open to dry the drum interior but
only if it is safe and any children are supervised.
Cleaning the Exterior
Proper care of the appliance can extend the service
life.
Exterior
• Immediately wipe off any spills.
• Wipe with a damp cloth and then again with a
dry cloth ensuring there is no moisture in
cabinet joints or crevices.
• Do not press on the surface or the display with
sharp objects.
Dispenser Drawer
Detergent may build up in the dispenser drawer.
Remove the drawer and inserts from the dispenser
drawer and clean any buildup once or twice a
month.
Cleaning the Appliance
Periodically
Tub Clean
This is a special function to help clean the inside of
the appliance by soaking, washing, rinsing and
spinning.
Run this function
once a month
(or more often if
needed) to reduce build-up of detergent and
softener and other residue.
• If there is a bad smell or mildew inside the
appliance, run this function once a week for 3
weeks in addition to the regularly prompted
intervals.
NOTE
• For models with a lint filter, remove lint or dirt
from the inside of the lint filter before and after
using this programme.
• For models without a lint filter, the lint is
discharged when the water drains during
washing.
30
MAINTENANCE
NOTE
• Washing small loads regularly (less than half a
tub). This may result in stains being left on the
edge of the tub that do not reach the top of the
tub. To avoid stains at the top of the tub, wash
larger amounts of laundry or use the
Tub Clean
function regularly.
1
Remove any clothing or items from the
appliance.
2
Open the dispenser drawer and add anti-
limescale to the main wash compartment.
WARNING
• Do not add any detergent to the detergent
dispenser drawer for this function. Doing so may
generate excessive suds and leak out from the
appliance and cause damage to property.
3
Close the dispenser drawer slowly and close
the door.
4
Press the
POWER
button.
5
Press the
Program
button to select
Tub Clean
.
6
Press the
START/PAUSE
button to start.
7
Leave the door open to dry the inside of the
appliance completely.
• When the inside of the appliance is not dried
completely, it may cause a bad smell or
mildew.
WARNING
• Leave the door open to dry the drum interior but
only if it is safe and any children are supervised.
Cleaning the Water Inlet Filter
Water inlet filter collects lime or any small objects
that may be in water supplied to the appliance.
Clean the water inlet filter regularly.
• Turn off the water taps to the appliance if the
appliance is to be left for any length of time (e.g.
holiday), especially if there is no floor drain
(gully) in the immediate vicinity.
•
IE
error message will be displayed on the
control panel when water is not entering the
detergent drawer.
• If the water is very hard or contains traces of
limescale, the filter on the water inlet may be
clogged.
1
Turn off the power and the water tap and then
unscrew the water inlet hose.
2
Remove the water inlet filter with small pliers
and then clean the filter using a medium bristle
tooth brush.
Cleaning the Lint Filter
The filter is an important part for an efficient
washing performance result, so take a special care.
Clean the filter regularly.
31
MAINTENANCE
ENGLISH
CAUTION
• Clean the lint filter after at least 2 - 3 washes.
• Do not drop the filter on the floor.
• Be careful not to get your fingernails caught in
the filter when you handle the filter.
• The lint filter should be back into its original
position after being washed to avoid damage to
your laundry items. Do not operate the
appliance with the lint filters removed.
• If the mesh hole of the lint filter is clogged,
foreign objects in the laundry may not be
filtered.
• Do not leave iron objects (such as clothes pins,
hairpins, etc.) in the lint filter as they promote
rust.
1
Push down on the release tabs on both sides of
the filter cover and pull forward.
2
Open the lid and remove the lint.
3
Wash the filter.
4
Close the lid and then insert the lower part of
the filter into the wash drum. Press the top of
the filter until you hear a click sound.
Cleaning the Drain Pump Filter
The drain filter collects threads and small objects
left in the laundry. Check regularly that the filter is
clean to ensure smooth running of the appliance.
1
Turn on the appliance.
2
Press the
Process
button to select
Spin
to
empty all the water from the drum.
3
Turn off the appliance and unplug it from the
power outlet socket.
4
Place a towel on the floor under the drain
pump cap.
• Residual water may remain in the drain hose
and the water may leak from the drain hose.
5
Turn the cap
a
on the rear of the appliance
counter-clockwise and pull it out.
32
MAINTENANCE
6
Remove any foreign objects and fluff inside
pump casing and from the filter.
7
Insert the filter along the guide ribs inside the
pump casing and turn the cap clockwise to refit
the cap.
• Securely turn the cap clockwise until it is
tight.
8
Turn on the power and check for leaks before
repositioning the appliance.
CAUTION
• Be careful when draining, as any residual water
may be hot.
33
TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
Before Calling for Service
Operation of the appliance can lead to errors and malfunctions. The following tables contain possible
causes and notes for resolving an error message or malfunction. You can remedy most of the problems by
yourself, consequently save time and money, since you do not need to call LG Electronics service centre.
The following table should assist you by troubleshooting.
Error Messages
The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at
an early stage. If this appliance does not function properly or does not function at all, check the following
before you call LG Electronics service centre.
Symptoms Possible Cause & Solution
dE
DOOR ERROR
The door is not closed properly.
• Close the door completely. If the error code is still displayed, call for
service.
The door is opened while the washing machine is operating.
• Press
Start/Pause
to cancel the door error. Press
Start/Pause
again to
start the washing programme.
1E
INLET ERROR
Water supply tap(s) are not completely open.
• Fully open tap.
Water supply hose(s) are kinked, pinched, or crushed.
• Straighten or reinstall the water supply hose(s).
The filter of the supply hose(s) are clogged.
• Check and clean the filter of the supply hose(s).
Water supply pressure to tap or house is too low or too high.
• Contact a plumber to have the water pressure checked or restored to the
operating requirements.
Water supply is connected with leak limiting hose(s).
• Do not use leak limiting hose(s).
OE
WATER OUTLET ERROR
Drain hose is kinked, pinched, or clogged.
• Clean and straighten the drain hose.
Drain discharge is more than 1.2 m above the bottom of the appliance.
• Adjust the hose or reconfigure the drain pipe. Maximum drain height is 1.2
m.
UE
UNBALANCE ERROR
Rebalancing operation is not successful.
• The automatic attempt to rebalance the laundry was not successful. The
cycle has been paused to allow the laundry to be manually adjusted.
34
TROUBLESHOOTING
Noises
UE
UNBALANCE ERROR
The load is too small.
• Add more items to allow the appliance to balance the laundry.
Heavy items are mixed with lighter items.
• Wash items of somewhat similar weight.
The load is out of balance.
• Manually redistribute the laundry if laundry have become tangled.
FE
OVERFLOW ERROR
Water overfills due to the faulty water valve.
• Close the water taps, unplug the appliance, and call for service.
PE
PRESSURE SENSOR
ERROR
The water level sensor is not working correctly.
• Close the water taps, unplug the appliance, and call for service.
LE
MOTOR LOCKED ERROR
A motor error has occurred.
• Allow the appliance to stand for 30 minutes and then restart the cycle.
• If the error code is still displayed, call for service.
Symptoms Possible Cause & Solution
Rattling and clanking
noise
Foreign objects, such as keys, coins, or safety pins may be in the drum.
• Stop the appliance, check the drum for foreign objects. If noise continues
after the appliance is restarted, call for service.
Thumping sound Heavy laundry may produce a thumping sound. This is usually normal.
• If the sound continues, the appliance is probably out of balance. Stop and
redistribute the laundry.
The laundry may be out of balance.
• Pause the cycle and redistribute the laundry after the door unlocks.
Vibrating noise Packaging materials are not removed.
• Remove packing materials.
The laundry may be unevenly distributed in the drum.
• Pause the cycle and redistribute the laundry after the door unlocks.
Not all levelling feet are resting firmly and evenly on the floor.
• See the section
Levelling the Appliance
to adjust and level the feet.
Floor is not rigid enough.
• Check if the floor is solid and does not flex. See the section
Installation
Place Requirements
to select the proper location.
Symptoms Possible Cause & Solution
35
TROUBLESHOOTING
ENGLISH
Operation
Symptoms Possible Cause & Solution
Appliance will not
operate.
Control panel has powered off due to inactivity.
• This is normal. Press the
POWER
button to turn on the appliance.
Appliance is unplugged.
• Make sure that the cord is plugged securely into a working outlet.
Water supply is turned off.
• Turn on the water supply tap completely.
Controls are not set properly.
• Make sure the cycle is correctly set. Close the door and press the
START/
PAUSE
button.
Circuit breaker/fuse is tripped/blown.
• Check house circuit breakers/fuses. Replace fuses or reset breaker. The
appliance should be on a dedicated branch circuit. The appliance will
resume the cycle where it stopped once power is restored.
Control needs to be reset.
• Press the
POWER
button, then reselect the desired programme and press
the
START/PAUSE
button.
START/PAUSE was not pressed after a cycle was set.
• Press the
POWER
button, then reselect the desired cycle and press the
START/PAUSE
button. If the
START/PAUSE
button is not pressed within a
certain time, the appliance will be turned off.
Extremely low water pressure.
• Check another tap in the house to make sure that household water
pressure is adequate.
Appliance is too cold.
• If the appliance has been exposed to temperatures below freezing for an
extended period of time, allow it to warm up before pressing the
POWER
button.
Appliance is heating the water or making steam. (some models only)
• The drum in the appliance may stop operating temporarily during certain
cycles, while water is safely heated to a set temperature.
Detergent is not
dispensed completely
or not dispensed at all.
Too much detergent is used.
• Follow the guidelines provided by the detergent manufacturer.
Water leaking Water inlet hose connection is loose at tap or appliance.
• Check hoses for leaks, cracks and splits.
• Tighten hose connections.
36
TROUBLESHOOTING
Water leaking House drain pipes are clogged.
• The appliance pumps out water very rapidly. Check for water backing up
out of the drain pipe during drain. If water is seen coming out of the drain,
check for proper drain hose installation and check for restrictions in the
drain. Contact a plumber to repair drain pipe.
Drain hose has come out of drain or is not inserted far enough.
• Tie drain hose to supply hose or standpipe to prevent it from coming out
during drain. For smaller drain pipes, insert the drain hose into the pipe as
far as the drain hose flange. For larger drain pipes, insert the drain hose
into the pipe 2.5 - 5 cm past the flange.
A large item such as a pillow or blanket is above the top of the drum.
• Stop the appliance and check the item. Make sure the item does not crest
above the top edge of the drum.
Appliance is not filling
properly.
Filter is clogged.
• Make sure the inlet filters on the fill valves are not clogged.
Supply hoses may be kinked.
• Check that supply hoses are not kinked or clogged.
Insufficient water supply.
• Make sure that both hot and cold water taps are turned on all the way.
Hot and cold supply hoses are reversed.
• Check supply hose connections.
Appliance will not
drain water.
Drain hose is kinked.
• Ensure that the drain hose is not kinked.
Drain is located higher than 1.2 m above the floor.
• Make sure that the drain hose is no higher than 1.2 m above the bottom of
the appliance.
Cycle time is longer
than usual.
The load is too small.
• Add more items to allow the appliance to balance the laundry.
Heavy items are mixed with lighter items.
• Always try to wash items of somewhat similar weight to allow the
appliance to evenly distribute the weight of the laundry for spinning.
The load is out of balance.
• Manually redistribute the laundry if laundry have become tangled.
Symptoms Possible Cause & Solution
37
TROUBLESHOOTING
ENGLISH
Performance
Symptoms Possible Cause & Solution
Incomplete or no
dispensing of
detergent
Too much detergent is used.
• Follow the guidelines provided by the detergent manufacturer.
Poor stain removal Previously set stains.
• Items that have previously been washed may have stains that have been
set. These stains may be difficult to remove and may require hand washing
or pretreating to aid in stain removal.
Staining Bleach or softener dispensed too soon.
• Dispenser compartment is overfilled causing bleach or softener to
dispense immediately. ALWAYS measure bleach to prevent overfilling.
• Close the dispenser drawer gently.
Bleach or softener was added directly to the laundry in the drum.
• Always use the dispensers to ensure that laundry products are properly
dispensed at the right time in the cycle.
Clothes were not properly sorted.
• Always wash dark colours separately from light colours and whites to
prevent discolouration.
• Never wash heavily soiled items with lightly soiled items.
Wrinkling Appliance is not unloaded promptly.
• Always remove items from the appliance as soon as the cycle is complete.
Appliance is overloaded.
• The appliance can be fully loaded, but the drum should not be tightly
packed with items. The door of the appliance should be closed easily.
Hot and cold water supply hoses are reversed.
• Hot water rinse can set wrinkles in clothes. Check the supply hose
connections.
Musty or mildewy
odour in the appliance
Inside of drum was not cleaned properly.
• Run the
Tub Clean
function regularly.
Memo
Memo
