Model: HW0015
User Manual
Wireless 2D Barcode Scanner
with Display and Charging Base
Ver. 08.1.02
Connect the Scanner
Connect with Charging Station
1. Press the button to power up the scanner.
2. Plug the charging station into a working USB port on
the computer.
(If the scanner emits three beeps after scanning a
barcode and nothing appears on the computer screen,
please follow the instructions in the “Pair the scanner with
its Station” section to re-establish the connection.)
Plug-and-Play Functionality and Testing
When the scanner is connected to a host device, it will be
identified as a keyboard, and the host device will
automatically load the in-box keyboard driver to ensure
proper functionality. Therefore, the scanner is
plug-and-play and can be tested immediately in any text
application (e.g., Notepad, Microsoft Word, Excel).
Charging Instructions
Please Read Before Charging
Power Requirements:
This scanner charges by sitting on the charging station.
The charging station should only be connected to a 5V/1A
power source. It is essential to use a power source that
provides a stable 5V/1A output. Using a power source
with higher voltage or amperage may damage the device
and void the warranty.
Charging with the Charging Station:
1.Connect the charging station to a known working USB 3.0
port on your computer using the provided USB cable.
2.Place the scanner on the charging station to begin
charging.
Avoid using charging sources that do not meet these
specifications, as this could lead to slow or insufficient
charging, or potentially damage the device.
Charging Safety:
Do not modify or tamper with the USB cable or charging
port on the charging station.
Ensure the charging station is securely connected to
the power source.
If using a USB wall adapter, ensure it is from a reputable
brand and meets the required 5V/1A output.
Keep the charging area well-ventilated and free from
flammable materials.
Always unplug the USB cable from the power source
when the scanner is not in use.
Failure to follow these guidelines could damage the
device and void the warranty. Our company is not
responsible for any damages caused by the use of
incompatible power sources.
Please do not hesitate to contact us if your
have questions.
Customer Service
Note:
Email: [email protected]
Phone: +1 (626) 438-1404
When contacting the Tera support, please have the
following information available:
Serial number of the unit (found on manufacturing
label)
Model number (found on manufacturing label)
You can visit our official website via the link below or
by scanning the provided QR code:
https://www.tera-digital.com
Follow us:
Instagram: tera_digital
Youtube: Tera Digital
Twitter: Tera Digital
Facebook: Tera
Contents
Factory Reset ..............................................................
Beeper Volume ...........................................................
Battery Level ...............................................................
Vibration ......................................................................
Power Timeout Timer .................................................
Keyboard Layout .........................................................
Operation Modes ........................................................
Pairing the Scanner with its Charging Station ..........
Pairing the Scanner with Bluetooth Devices .............
Enter/Tab Suffix ..........................................................
Timestamp ..................................................................
Removal of Characters ...............................................
Scan Modes ................................................................
01
01
01
02
02
02
03
04
04
05
05
06
07
Factory Reset
If you aren't sure what programming options are in your scanner, or you
have changed some options and want to restore the scanner to factory
default settings, scan the barcode below.
Restore Defaults
Beeper Volume
The beeper volume codes modify the volume of the beep the scanner
emits on a good read.
High Medium*
Low Mute
Battery Level
To check the remaining battery level, please scan the following barcode.
Ensure your cursor is in a text field when scanning.
Show Battery Level
1
Need Support?
+1(626)438-1404
https://www.tera-digital.com
Vibration
300s*
Vibration OffVibration On*
Power Timeout Timer
When there is no activity within a specified time period, the scanner
turns off. Scan the appropriate scanner power timeout barcode to
change the timeout duration.
The scanner vibrates once when a barcode is successfully read. To
disable the vibration, scan the Vibration Off barcode.
Never Turn Off Turn Off Immediately
1800s
Keyboard Layout
The keyboard layout default on the scanner is a US keyboard. To change
this layout, scan the appropriate Keyboard Country barcode below.
(Please note that if the keyboard layout on the scanner doesn't match
your computer's, the outputs may be incorrect. )
GermanyUnited States*
2
France Spain
Operation Modes
Real Time Mode
By default, the barcode scanner is in real time mode, transmitting
scanned data to the host device immediately.
Real Time Mode*
Storage Mode
Storage mode allows the scanner to store barcode data when it's out of
range of its receiver or during inventory. The data is saved in memory
and won’t be lost when the scanner is powered off. When the scanner's
buffer space is full, any barcodes scanned generate an error tone. In
order to clear the scanner's buffer, you must scan Clear All Stored
Codes.
Storage Mode
Upload All Stored Codes
In storage mode, the scanner does not transmit data to the host device,
even when it is back in range. To transmit the stored data, you need to
scan the following code.
Upload All Stored Codes
United KingdomItaly
3
Total Records
If you wish to output the total number of barcodes scanned when in
storage mode, scan Total Records.
Total Records
Clear All Stored Codes
If you want to clear the scanner's buffer of all data accumulated in
storage mode, scan Clear All Stored Codes.
Clear All Stored Codes
Pairing the Scanner with its Charging Station
If the scanner doesn’t connect to the charging station automatically,
please follow these steps to re-establish the connection.
Step 1: Unplug the charging station (If the station is not plugged in,
please disregard this step).
Step 2: Scan the “2.4GHz Mode” barcode.
Step 3: Scan the “Pairing” barcode.
Step 4: Plug the charging station into a known working USB3.0 port on
your computer.
2.4GHz Mode Pairing
4
Pairing the Scanner with Bluetooth Devices
The scanner can be paired with Bluetooth devices such as personal
computers, laptops, and tablets.
Step 1: Scan the “Bluetooth Mode” barcode and the “Pairing” barcode
below to establish one-way communication with the scanner.
Bluetooth Mode Pairing
5
Step 2: Set your personal computer, laptop, or tablet so it searches for
other Bluetooth devices.
Step 3: Once your personal computer, laptop, or tablet has located the
scanner, select the scanner name. They will automatically pair with the
scanner.
None
Enter/Tab Suffix
By default, the scanner adds a carriage return suffix to every scan. If
you don’t want the scanner to “press” the Enter key after every scan,
please scan the “None” barcode below to remove it. If you need the
scanner to “press” the Tab key after every scan, please scan the
“Horizontal Tab” barcode below.
Carriage Return* Horizontal Tab
Timestamp
If you want to record the time and date for every scan, scan either Time
& Date Prefix or Time & Date Suffix.
Show Current Time & Date Time & Date Prefix
Report missing or damaged items?
+1(626)438-1404
https://www.tera-digital.com
Time & Date Suffix Clear Timestamp
6
Removal of Characters
If you need to remove leading and/or trailing characters from scanned
bar codes, please follow these steps:
1. Scan the “Remove characters from the start” barcode or the “Remove
characters from the end” barcode
Remove characters from the start Remove characters from the end
1 digit 2 digits 3 digits
4 digits
5 digits
6 digits
7 digits 8 digits
9 digits
2.Scan the appropriate code from the digit codes below：
(Example: If a barcode reads "ABC123" and you want to extract "BC1”
from it, you should first scan the “Remove characters from the start”
barcode, followed by the “1 digit” barcode. Then, scan the “Remove
characters from the end” barcode, followed by the “2 digits” barcode.)
10 digits
11 digits 12 digits
13 digits 14 digits 15 digits
16 digits
For returns, contact us!
+1(626)438-1404
https://www.tera-digital.com
7
Scan Modes
Manual Trigger Mode
A scan mode for reading barcodes by pulling the trigger.
Manual Trigger Mode
Continuous Scan Mode
A scan mode where the scanner constantly scans barcodes without the
need to press the trigger.
Continuous Scan Mode
