MEI LING
FROST-FREE REFRIGERATOR-FREEZER
INSTRUCTION MANUAL
Model No.:INKF 8251 W5E
Dear users, this manual contains the product’s basic knowledge, how to use
it, fault diagnosis and basic troubleshooting methods. In order to better under-
stand and use this product, please take good care of this manual and read it
carefully.
2 / 13
EN
SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
Before using the appliance, read these safety
instructions. Keep them nearby for future
reference.
These instructions and the appliance itself
provide important safety warnings, to be
observed at all times. The manufacturer declines
any liability for failure to observe these safety
instructions, for inappropriate use of the
appliance or incorrect setting of controls.
Very young children (0-3 years) should be kept
away from the appliance. Young children (3-8
years) should be kept away from the appliance
unless continuously supervised. Children from 8
years old and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge can use this appliance
only if they are supervised or have been given
instructions on safe use and understand the
hazards involved. Children must not play with
the appliance. Cleaning and user maintenance
must not be carried out by children without
supervision.
Children aged from 3 to 8 years are allowed to
load and unload refrigerating appliances.
PERMITTED USE
CAUTION: The appliance is not intended to be
operated by means of an external switching
device, such as a timer, or separate remote
controlled system.
This appliance is intended to be used in
household and similar applications such as: sta
kitchen areas in shops, oces and other working
environments; farm houses; by clients in hotels,
motels, bed & breakfast and other residential
environments.
This appliance is not for professional use. Do
not use the appliance outdoors.
The bulb used inside the appliance is
specically designed for domestic appliances
and is not suitable for general room lighting
within the home (EC Regulation 244/2009).
The appliance is designed for operation in
places where the ambient temperature comes
within the following ranges, according to the
climatic class given on the rating plate. The
appliance may not work properly if it is left for a
long time at a temperature outside the specied
range.
Climatic class ambient temperatures:
SN: From 10°C to 32°C ;
N: From 16°C to 32°C
ST: From 16°C to 38°C ;
T: From 16°C to 43°C
This appliance does not contain CFCs. The
refrigerant circuit contains R600a (HC).
Appliances with Isobutane (R600a):
isobutane is a natural gas without
environmental impact, but is ammable.
Therefore, make sure the refrigerant circuit
pipes are not damaged, especially when
emptying the refrigerant circuit.
WARNING: Do not damage the appliance
refrigerant circuit pipes.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING: Do not use mechanical, electric or
chemical means other than those recommended
by the Manufacturer to speed up the defrost
process.
WARNING: Do not use or place electrical
devices inside the appliance compartments if
they are not of the type expressly authorised by
the Manufacturer.
WARNING: Ice makers and/or water dispensers
not directly connected to the water supply must
be lled with potable water only.
WARNING: Automatic ice-makers and/or
water dispensers must be connected to a water
supply that delivers potable water only, with
mains water pressure between 0.17 and 0.81 MPa
(1.7 and 8.1bar).
Do not store explosive substances such as
aerosol cans and do not place or use gasoline or
other ammable materials in or near the
appliance.
Do not swallow the contents (non-toxic) of
the ice packs (provided with some models). Do
not eat ice cubes or ice lollies immediately after
taking them out of the freezer since they may
cause cold burns.
For products designed to use an air lter
inside an accessible fan cover, the lter must
always be in position when the refrigerator is in
function.
Do not store glass containers with liquids in
the freezer compartment since they may break.
Do not obstruct the fan (if included) with food
items.
After placing the food check that the door of
compartments closes properly, especially the
freezer door.
Damaged gaskets must be replaced as soon
as possible.
3 / 13
Use the refrigerator compartment only for
storing fresh food and the freezer compartment
only for storing frozen food, freezing fresh food
and making ice cubes.
Do not store unwrapped food in the
refrigerator or freezer compartments to avoid
direct contact with internal surfaces.
Appliances could have special compartments
(Fresh Food Compartment, Zero Degree Box,...).
Unless dierently specied in the specic booklet
of product, they can be removed, maintaining
equivalent performances.
C-Pentane is used as blowing agent in the
insulation foam and it is a ammable gas.
The most appropriate compartments of the
appliance where specic types of food are to be
stored, taking into account dierent temperature
distribution in dierent compartments in the
appliance, are as follows:
- Refrigerator compartment:
1) Upper area of the refrigerator compartment &
door - temperature zone: Store tropical fruit,
cans, drinks, eggs, sauces, pickles, butter, jam
2) Middle area of the refrigerator compartment -
cool zone: Store cheese, milk, dairy food, deli
food, yoghurt
3) Lower area of the refrigerator compartment
- coldest zone: Store cold cuts, desserts, meat
and sh, cheesecake, fresh pasta, sour cream,
pesto/salsa, home-cooked food, pastry cream,
pudding and cream cheese
4) Fruit & vegetable drawer at the bottom of the
refrigerator compartment: Store vegetables and
fruits (excluding tropical fruits)
5) Chiller compartment: Only store meat and sh
in the coldest drawer - Freezer compartment:
4 star zone (****) compartment is suitable for
freezing foodstus from ambient temperature
and for storing frozen food as the temperature is
evenly distributed throughout the entire
compartment.
Purchased frozen food has the storage expiration
date stated on the packaging. This date takes
into account the type of food being stored and
therefore this date should be respected. Fresh
food should be stored for the following time
periods: 1-3 months for cheese, shellsh, ice
cream, ham/sausage, milk, fresh liquids; 4 months
for steak or chops (beef, lamb, pork); 6 months
for butter or margarine, poultry (chicken, turkey);
8-12 months for fruits (except citrus), roast meat
(beef, pork, lamb), vegetables. Expiration dates
on the packaging of foods in the 2-star zone
must be respected.
To avoid food contamination, please observe the
following:
– Opening the door for long periods can cause a
signicant increase of the temperature in the
compartments of the appliance.
– Regularly clean surfaces that may come into
contact with food and accessible drainage
systems.
– Clean water tanks if they have not been used
for 48 h; ush the water system connected to a
water supply if water has not been drawn for 5
days.
– Store raw meat and sh in suitable containers
in the refrigerator, so that it does not come into
contact with or drip onto other food.
– Two-star frozen food compartments are
suitable for storing pre-frozen food, storing or
making ice cream and ice cubes.
– Do not freeze fresh food in one, two or three-
star compartments.
– If the refrigerating appliance is left empty for
long periods, switch o, defrost, clean, dry, and
leave the door open to prevent mould developing
inside the appliance.
INSTALLATION
The appliance must be handled and installed
by two or more persons - risk of injury. Use
protective gloves to unpack and install - risk of
cuts.
Installation, including water supply (if any),
electrical connections and repairs must be
carried out by a qualied technician. Do not
repair or replace any part of the appliance unless
specically stated in the user manual. Keep
children away from the installation site. After
unpacking the appliance, make sure that it has
not been damaged during transport. In the event
of problems, contact the dealer or your nearest
After-sales Service. Once installed, packaging
waste (plastic, styrofoam parts etc.) must be
stored out of reach of children - risk of suocation.
The appliance must be disconnected from the
power supply before any installation operation -
risk of electrical shock.
During installation, make sure the appliance does
not damage the power cable - risk of re or
electrical shock. Only activate the appliance
when the installation has been completed.
Be careful not to damage the oors (e.g.
parquet) when moving the appliance. Install the
appliance on a oor or support strong enough to
take its weight and in a place suitable for its size
and use. Make sure the appliance is not near a
heat source and that the four feet are stable and
4 / 13
resting on the oor, adjusting them as required,
and check that the appliance is perfectly level
using a spirit level. Wait at least two hours before
switching the appliance on, to ensure that the
refrigerant circuit is fully ecient.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or
damaged.
WARNING: To avoid a hazard due to instability,
positioning or xing of the appliance must be
done in accordance with the manufacturer
instructions.
It's forbidden to place the refrigerator in such
way that the metal hose of gas stove, metal gas
or water pipes, or electrical wires are in contact
with the refrigerator back wall (condenser coil).
To guarantee adequate ventilation, leave a
space on both sides and above the appliance.
The distance between the rear of the appliance
and the wall behind the appliance should be 50
mm, to avoid access to hot surfaces. A reduction
of this space will increase the Energy consumption
of product.
Please remove the power cord from condenser
hook during installation before connecting
product to power supply.
ELECTRICAL WARNINGS
It must be possible to disconnect the appliance
from the power supply by unplugging it if plug is
accessible, or by a multi-pole switch installed
upstream of the socket in accordance with the
wiring rules and the appliance must be earthed
in conformity with national electrical safety
standards.
Do not use extension leads, multiple sockets
or adapters. The electrical components must not
be accessible to the user after installation. Do not
use the appliance when you are wet or barefoot.
Do not operate this appliance if it has a damaged
power cable or plug, if it is not working properly,
or if it has been damaged or dropped.
If the supply cord is damaged, it must be
replaced with an identical one by the
manufacturer, its service agent or similarly
qualied persons in order to avoid a hazard - risk
of electrical shock.
WARNING: Do not locate multiple portable
socket-outlets or portable power supplies at the
rear of the appliance.
CLEANING AND MAINTENANCE
WARNING: Ensure that the appliance is
switched o and disconnected from the power
supply before performing any maintenance
operation. To avoid risk of personal injury use
protective gloves (risk of laceration) and safety
shoes (risk of contusion); be sure to handle by
two persons (reduce load); never use steam
cleaning equipment (risk of electric shock). Non-
professional repairs not authorised by the
manufacturer could result in a risk to health and
safety, for which the manufacturer cannot be
held liable. Any defect or damage caused from
non-professional repairs or maintenance will not
be covered by the guarantee, the terms of which
are outlined in the document delivered with the
unit.
Do not use abrasive or harsh cleaners such as
window sprays, scouring cleansers, ammable
uids, cleaning waxes, concentrated detergents,
bleaches or cleansers containing petroleum
products on plastic parts, interior and door liners
or gaskets. Do not use paper towels, scouring
pads, or other harsh cleaning tools.
This refrigerating appliance is not intended to be
used as a built-in appliance.
Doors and lids of the refrigeration appliance
should be removed before disposal in the landll,
to avoid children or animals getting trapped
inside.
Recommended setting:
• Refrigerator compartment: +4°C or MED
• Freezer compartment: -18°C or -20°C
To optimise freezing speed and get more storage
space, the freezer compartment can be used
without the freezer drawers and the food can be
placed directly on the bottom of the
compartment. The quantity of fresh food that
can be frozen in a specic time period is indicated
on the rating plate.
Load limits are determined by baskets, aps,
drawers, shelves etc. Make sure that these
components can still close easily after loading. To
avoid food waste, please refer to the
recommended setting and storage times found
in the online user manual.
Fill 2/3 of the ice tray with water and put it back
in the freezer compartment. Do not, under any
circumstances, use sharp or pointed objects to
remove the ice. The model information can be
retrieved using the QR-Code indicated on the
energy label. The label also includes the model
identier that can be used to consult the https://
eprel.ec.europa.eu database portal.
Policies, standard documentation, ordering
spare parts and additional product information
can be found at this address:
https : / / parts - selfservice . europeanappliances . c
om
5 / 13
®
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable and is marked with
the recycle symbol
. The various parts of the packaging must
therefore be disposed of responsibly and in full compliance with
local authority regulations governing waste disposal.
DISPOSAL OF HOUSEHOLD APPLIANCES
This appliance is manufactured with recyclable or reusable materials.
Dispose of it in accordance with local waste disposal regulations.
For further information on the treatment, recovery and recycling
of household electrical appliances, contact your local authority,
the collection service for household waste or the store where you
purchased the appliance. This appliance is marked in compliance
with European Directive 2012/19/EU, Waste Electrical and Electronic
Equipment (WEEE) and with the Waste Electrical and Electronic
Equipment regulations 2013 (as amended). By ensuring this product
is disposed of correctly, you will help prevent negative consequences
for the environment and human health.
The symbol
on the product or on the accompanying
documentation indicates that it should not be treated as domestic
waste but must be taken to an appropriate collection center for the
recycling of electrical and electronic equipment.
ENERGY SAVING TIPS
Install the appliance in a dry, well ventilated room far away from any
heat source (eg. radiator, cooker, etc.) and in a place not exposed
directly to the sun. If required, use an insulating plate.
To guarantee adequate ventilation follow installation instructions.
Insucient ventilation at the back of the product increases energy
consumption and decreases cooling eciency.
Frequent door opening might cause an increase in Energy
Consumption.
The internal temperature of the appliance and the Energy
Consumption may be aected also by the ambient temperature, as
well as location of the appliance. Temperature setting should take
into consideration these factors. Reduce door opening to minimum.
When thawing frozen food, place it in the refrigerator. The low
temperature of the frozen products cools the food in the refrigerator.
Allow warm food and drinks to cool down before placing in the
appliance.
Positioning of the shelves in the refrigerator has no impact on the
ecient usage of energy. Food should be placed on the shelves in
such way to ensure proper air circulation (food should not touch
each other and distance between food and rear wall should be kept).
You can increase storage capacity of frozen food by removing
baskets and, if present, Stop Frost shelf.
Do not worry about noises coming from the compressor which are
normal operation noises.
6 / 13
Product Features
• Total no frost design
• Multi air-ow cooling system
• Electronic temperature control
• Interior LED lighting
Parts name:
No Description
1 Temperature modes & LED Light
2 Fridge glass shelves
3 Temperature control knob
4 Crisper cover
5 Crisper
6 Drawer tray
7 Freezer drawers
8 Leveling feet
9 Bottle racks
Due to technological innovations, the product descriptions
in this manual may not be completely consistent with your
refrigerator. Detailed information is in accordance with the
nal product.
Preparations for use
Installation location:
1. Ventilation condition
The position you select for the refrigerator installation should be well-ventilated and has less hot air. Do not locate the refrigerator
near a heat source such as cooker, boiler, and avoid it from direct sunlight, thus guaranteeing the refrigeration eect while saving
energy consumption. Do not locate the refrigerator in the damp place, so as to prevent the refrigerator from rusting and leaking
electricity. The result of the refrigerant charge amount of the refrigerator being divided by the total space of the room in
which the refrigerator is installed shall be less than 8g / m³.
Note: The amount of refrigerant charged for the refrigerator can be found on the nameplate.
2. Heat dissipation space
When working, the refrigerator gives o heat to surroundings. Therefore, at least 30mm of free space should be spared at the top
side, more than 100mm on both sides, and above 50mm at the back side of the refrigerator.
Dimensions in mm:
W D H A B C (°) E F
540 576 1807 845 1095 125±5 50 100
Fig.1 Fig.2
Note: Figure 1, Figure 2 only illustrate the space demand of the product.
3. Level ground
Place the refrigerator on the solid and at ground (oor) to keep it stable, or else, it will give rise to vibration and noise. When the
refrigerator is placed on such ooring materials as carpet, straw mat, polyvinyl chloride, the solid backing plates should be applied
underneath the refrigerator, so as to prevent color change due to heat dissipation.
Unobstructed ventilation shall be maintained around the appliance or in an embedded structure.
7 / 13
Preparations for use
1. Standing time
After the refrigerator is properly installed and well cleaned, do not switch it on immediately. Make sure to energize the refrigerator
after more than 1 hour’s standing, so as to ensure its normal operation.
2. Cleaning
Conrm the accessory parts inside the refrigerator and wipe the inside with a soft cloth.
3. Power-on
Insert the plug into the solid socket to start the compressor. After 1 hour, open the refrigerator door, if the temperature inside the
refrigerator compartment drops obviously, it indicates the refrigeration system is working normally.
4. Storage of food
After the refrigerator runs for a period of time, the internal temperature of the refrigerator will be automatically controlled according
to the user’s temperature setting. After the refrigerator is fully cooled, put in foods, which usually need 2~3 hours to be fully coo-
led. In summer, when the temperature is high, it takes more than 4 hours for the foods to be fully cooled (Try to open the refrige-
rator door as less as possible before the internal temperature cools down).
If the refrigerator is installed in the moisture place, make sure to check whether the ground wire and leakage circuit breaker
are normal. If vibration noises are produced due to the refrigerator contacting the wall or if the wall gets blackened by air con-
vection around the compressor, move the refrigerator away from the wall. Setting up the refrigerator may cause jamming noise or
image chaos to the mobile phone, xed-line telephone, radio receiver, television surrounding it, so try to keep the refrigerator as
far away as possible in such case.
Functions
1. Functions
When the refrigerator system is powered on for the rst time, all icons on the display panel gets illuminated for 2s.
1.1 Temperature setting
Temperature can be adjusted by pressing the ‘SET’ key. Every time when the “SET” key is pressed, the current mode indicator
lights o while the next mode indicator lights up, with the said mode setting validated if no key operation within 5s (or else, the
mode setting will be invalid). After the setting takes eect, temperature will be immediately controlled as per the mode setting.
The temperature modes cycle as following: “5→4→3→2→1→FAST COOL→5”
COLDEST
COLD
5
When the user needs a colder temperature.
4
3 When in normal use.
2
When the user does not need a colder temperature.
1
The Freezing temperature control
Freezer temperature control
• The freezer temperatures are controlled by the knob switch (as illustrated on
the right) in the following manner:
• When the temperature mode keeps unchanged, turn the temperature control
knob switch clockwise, then the refrigerator temperature decreases while the
freezer temperature gets increased.
• When the temperature mode keeps unchanged, turn the temperature control
knob switch anticlockwise, then the refrigerator temperature increases while
the freezer temperature gets decreased.
• It is recommended to adjust the temperature control knob switch to the middle
position. When you need a lower freezer temperature, turn the temperature
control knob switch properly in the anticlockwise direction to decrease the
freezer temperature (note that the refrigerator temperature will increase con-
currently). When the temperature satises the need, be sure to turn the control
knob switch back to the middle position in a timely manner.
8 / 13
The fridge thermostat and the air regulating rod should be used in combination.
Temperature adjustment
Use
environment
Recommended panel mode settings
Recommended knob switch
positions
Tips
Higher than 35°C
1) It is recommended to
set at the middle mode.
2) The temperature
mode can be adjusted
as recommended in
the left table in case of
change to the ambient
temperature around the
refrigerator.
16°C - 35°C
Lower than 16°C
• When the ambient temperature around the refrigerator is higher than 35 °C, do not set the thermostat at Mode 5 and adjust
the temperature control knob to the leftmost position, so as not to aect the normal refrigeration of the refrigerator.
• Do not set the thermostat at Mode 5 and adjust the temperature control knob to the rightmost position, in order to avoid the
fridge compartment undercooling.
• If the fridge temperature is not cool or undercooled, set the thermostat at the middle mode and adjust the temperature control
knob in the middle position.
• In case the ‘Fast cool’ function is enabled, adjust the temperature control knob to the middle position.
1.2 “PUSH&GO”
Cooling down the temperature in a rapid manner is benecial to the prevention of food nutrition against lost and the preservation
of freshness.
After a cumulative running period of 26 hours, the fast cooling function will exit automatically, with the temperature mode restored
to that set before the fast cooling function is enabled.(max 30 hours)
1.3 Door open alarm
If the fridge door is open for more than 3 minutes, buzzer alarms will be continuously issued, which can be stopped when the set
key is pressed, but will be restored after 3 minutes if the door keeps open. The alarms will not be lifted until the door is closed.
1.4 Power cut memory
In case of power failure, the refrigerator will maintain the operating state before power failure when power supply is restored.
1.5 Power-on delay
In order to protect the refrigerator compressor from being damaged in the case of short-time power failure (i.e., less than 5 minu-
tes), the compressor will not be started immediately after it is powered on.
1.6 Fault alarm
When the indicator light of Mode 5 or Mode3 or Mode 1 keeps ashing, it indicates fault with the refrigerator. Please contact the
aftersales person for visiting service in such case.
Instructions for food storage
Precautions for use
• The appliance might not operate consistently (there is possibility of defrosting or temperature becoming too warm in the frozen
food compartment) when sited for an extended period of time below the cold limit of the temperature range for which the refri-
gerating appliance is designed
• The information of climate type of the appliance is provided on the rating plate.
• The internal temperature could be aected by such factors as the location of refrigerating appliance, ambient temperature,
and frequency of door open, etc., and if appropriate, a warning that setting of any temperature control device might have to be
varied to allow for these factors should be made.
• Eervescent drinks should not be stored in the freezer compartment or the low-temperature compartment, and some products
such as water ices should not be consumed too cold.
9 / 13
Food storage location
Due to the cold air circulation in the refrigerator, the temperature of each area in the refrigerator is dierent, so dierent kinds of
food should be placed in dierent areas.
The fresh food compartment is suitable for the storage of such foods as need not to be frozen, the cooked food, beer, eggs, some
condiments that need cold preservation, milk, fruit juice, etc. The crisper box is suitable for the preservation of vegetables, fruits,
etc.
The freezer compartment is suitable for the storage of ice cream, frozen food and the foods to be preserved for a long time.
Use of the fresh food compartment
Fridge shelf: When removing the shelf, lift it up rst, and then pull it out; and when installing the shelf, place it into position before
putting it down. Keep the shelf rear ange upward, to prevent foods from contact the liner wall. When taking out or putting in the
shelf, hold it rmly, and handle with care to avoid damage.
Crisper box: Pull out the crisper box for access to food. After using or cleaning the cover plate of the crisper box, be sure to put it
back onto the crisper, so that the internal temperature of the crisper box will not be aected.
Use of the crisper humidity regulating rod
The humidity regulating rod of the crisper box is design to maintain the humidity and freshness of the vegetables stored inside.
When the humidity regulating rod is slide to the right, with more holes exposed, lower humidity will be kept inside the crisper box.
When the humidity regulating rod is slide to the left, with less holes exposed, higher humidity will be kept inside the crisper box.
Cautions for food storage
You’d better clean the foods and wipe them dry before storing them inside the refrigerator. Before foods are put in the refrigerator,
it is advisable to seal them up, so as to prevent water evaporation to keep fresh fruits and vegetables on one hand, and prevent
taint of odor on the other hand.
Do not put too many or too heavy foods inside the refrigerator. Keep enough space between foods; if too close, the cold air ow
will be blocked, thus aecting the refrigeration eect. Do not store excessive or overweight foods, to avoid the shelf from being
crushed. When storing the foods, keep a distance away from the inner wall; and do not place the water-rich foods too close to the
fridge rear wall, lest they get frozen on the inner wall.
Categorized storage of foods
Foods should be stored by category, with the foods you eat every day placed in front of the shelf, so that the door open duration
can be shortened and food spoilage due to expiration can be avoided.
Energy-saving tips: Allow the hot food cool down to the room temperature before putting it in the refrigerator. Put the frozen food
in the fresh food compartment to thaw, using the low temperature of the frozen food to cool the fresh food, thus saving energy.
Storage of fruits and vegetables
In the case of refrigerating appliances with chill compartment, a statement to the eect that some types of fresh vegetables and
fruits are sensitive to cold and therefore are not suitable for storage in this kind of compartment should be made.
Use of the frozen food storage compartment
The freezer temperature is controlled below -18 °C, and it is advisable to store the food for long-term preservation in the freezer
compartment, but the storage duration indicated on the food packaging should be adhered to.
The freezer drawers are used to store food that needs to be frozen. Fish and meat of large block size should be cut into small
pieces and packed into fresh-keeping bags before they are evenly distributed inside the freezer drawers.
• Allow the hot foods to cool down to the room temperature before putting them in the freezer compartment.
• Do not put a glass container with liquid or the canned liquid that is sealed in the freezer compartment, so as to avoid burst due
to volume expansion after the liquid gets frozen up.
• Divide the food into appropriately small portions
• You’d better pack the food up before freezing it, and the packing bag used should be dry, in case the packing bags are frozen
together. Foods should be packed or covered by such suitable materials as are rm, tasteless, impervious to air and water,
non-toxic and pollution-free, to avoid cross-contamination and transfer of odor.
Tips for shopping the frozen foods
1. When you are buying frozen food, look at the Storage Guidelines on the packaging. You will be able to store each item of
frozen food for the period shown against the star rating. This is usually the period stated as “Best to use them before×”, found
on the front of the packaging.
2. Check the temperature of the frozen food cabinet in the shop where you buy the frozen foods.
3. Make sure the frozen food package is in perfect condition.
4. Always buy frozen products last on your shopping trip or visit to the supermarket.
5. Try to keep frozen food together whilst shopping and on the journey home, as this will help to keep the food cooler.
6. Don’t buy frozen food unless you can freeze it straight away. Special insulated bags can be bought from most supermarkets
and hardware shops. These keep the frozen foods cold longer.
7. For some foods, thawing before cooking is unnecessary. Vegetables and pasta can be added directly to boiling water or ste-
am cooked. Frozen sauces and soups can be put into a saucepan and heated gently until thawed.
8. Use quality food and handle it as little as possible. When foods are frozen in small quantities, it will take less than for them to
freeze up and thaw.
9. Estimate the amount of foods to be frozen up. When freezing large amounts of fresh food, adjust the temperature control knob
to the low mode, with the freezer temperature lowered. So, foods can be frozen up in fast manner, with the food freshness
well kept.
10 / 13
Tips for special needs
Moving the refrigerator/freezer
• Location
Do not place your refrigerator/freezer near a heat source, e.g. cooker, boiler or radiator. Avoid it from direct sunlight in out-buildin-
gs or sun lounges.
• Leveling
Make sure to level your refrigerator/freezer using the front leveling feet. If not level, the refrigerator/freezer door gasket sealing
performance will be aected, or even it may lead to the operating failure of your refrigerator/freezer.
After locating the refrigerator/freezer in position, wait for 4 hours before using it, so as to allow the refrigerant to settle.
• Installation
Do not cover or block the vents or grilles of your appliance.
When you are out for a long time
• If the appliance will not be used for several months, turn it o rst, and then unplug the plug from the wall outlet.
• Take out all foods.
• Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door ajar: block it open or have the door
removed if necessary.
• Keep the cleaned appliance in a dry, ventilated place and away from the heat source, place the appliance smoothly, and do
not place heavy objects on top of it.
• The unit should not be accessible to child’s play.
Maintenance and cleaning
Before cleaning, unplug the power plug rst; Do not plug in or plug out the plug with wet hand, because there is
a risk of electric shock and injury. Do not spill water directly on the refrigerator, to avoid rust, electricity leakage and
accidents. Do not stretch your hands into the bottom of the refrigerator, since you might be scratched by sharp metal
corners.
Internal cleaning and external cleaning
The food residuals in the refrigerator are liable to produce bad odor, so the refrigerator must be cleaned regularly. The fresh food
compartment is usually cleaned once a month.
Remove all shelves, crisper box, bottle racks, cover board, and drawers etc., and clean them with a soft towel or sponge dipped
in warm water or neutral detergent.
Clear o the dusts accumulated on the rear panel and side plates of the refrigerator often.
After using detergent, be sure to rinse it with clean water, and then wipe it dry.
Do not use bristle brush, steel wire brush, detergent, soap powder, alkaline detergent, benzene, gasoline, acid, hot
water and other corrosive or soluble items to cleanse the cabinet surface, door gasket, plastic decorative parts, etc., so
as to avoid damage.
Carefully wipe dry the door gasket, clean the groove using a wooden chopstick wrapped with cotton string. After the cleaning, x
the four corners of the door gasket rst, and then embed it segment by segment into the door groove.
Interruption of power supply or failure of the refrigerating system
• Take care of the frozen foods in the event of an extended non-running of the refrigerating appliance (such as interruption of
power supply or failure of the refrigerating system).
• Try to open the refrigerator door as less as possible, in this way can food safely and freshly kept for hours even in hot sum-
mer.
• If you get the power outage notice in advance:
1) Adjust the thermostat knob to the high mode an hour in advance, so that foods get fully frozen (Do not store new food during
this time!). Restore the temperature mode to the original setting when power supply becomes normal in a timely manner.
2) You can also make ice with a watertight container, and put it in the upper part of the freezer, so as to extend the time for fresh
food to be stored.
Note: Once the refrigerator is used, you’d better use it continuously; and under normal circumstance, do not stop
its use, so as not to aect the service life.
Defrosting
This appliance is designed with automatic defrosting function, thus no need to defrost it manually.
Changing the lamp
The LED lamp is used by the refrigerator for lighting, which features low energy consumption and long service life. In case of any
abnormality, please contact the after-sales personnel for visiting service.
Lamp type: LED light.
Energy eciency level: N/A
Safety-check after maintenance
Is the power cord broken or damaged?
Is the power plug rmly inserted into the socket?
Is the power plug abnormally overheated?
11 / 13
Note: Electric shock and re accident may be caused in case the power cord and plugs are damaged or stained by
dust. If any abnormality, please unplug the power plug and get in contact with the vendor.
How to dissemble the parts
Fridge door bottle rack:
Hold the bottle rack with both hands, and then push it up.
Fridge shelf:
Hold one end of the shelf to lift it up, and meantime pull it outward, in this way can the shelf be taken out.
Simple fault analysis and elimination
With regard to the following small faults, not every failure needs to be xed by the technical service personnel; you can try to
solve the problem.
Case Inspection Solutions
• Completely non-refrigera-
tion
• Is power plug o?
• Are breakers and fuses broken?
• No electricity or line trip?
• Where is the refrigerator installed? Is it
placed in balconies, garages, storage ro-
oms and other places where the ambient
temperature is below 10°C?
• Re-plug
• Opening the door and checking whether
the lamp is lit.
• Power outage or line tripping?
• Install refrigerator in a location that is
protected and the ambient temperature
is above 10 °C. If your refrigerator is in-
stalled in too low temperature,the internal
cooling system may not work correctly.
• Abnormal noise • Is refrigerator stable?
• Does refrigerator reach the wall?
• Adjusting refrigerator’s adjustable feet.
• O the wall.
• Poor refrigerating eciency • Do you put hot food or too much food?
• Do you open the door frequently?
• Do you clip food bag to the seal of door?
• Direct sunlight or near a furnace or stove?
• Is it well-ventilated?
• Temperature setting in too high?
• Putting food into refrigerator when hot
food becomes cool.
• Checking and closing the door.
• Removing the refrigerator from the heat
source.
• Emptying the distance to maintain good
ventilation.
• Setting to the appropriate temperature.
• Peculiar smell in refrigerator • Any spoiled food?
• Do you need to clean refrigerator?
• Do you pack food of strong avors?
• Throwing away spoiled food.
• Cleaning refrigerator.
• Packing food of strong avors.
• LED lamp always ashing • Is the door open for more than 10 minu-
tes?
• Close the fridge door, open it again in 2s,
checking whether the LED lamp restores
to normal.
Note: If the above descriptions are inapplicable to troubleshooting, do not disassemble and repair it yourself. Repairs car-
ried out by inexperienced persons may cause injury or serious malfunctioning. Contact the local store where your purchase was
made. This product should be serviced by an authorized engineer and only genuine spare parts should be used.
When the appliance is not in use for long periods, disconnect from the electricity supply, empty all foods and clean the appliance,
leaving the door ajar to prevent unpleasant smells.
12 / 13
Certications
Electrical information
This electrical appliance must be grounded.
This product is equipped with a plug, which is suitable for all houses equipped with sockets meeting the current specications
If the tted plug is not suitable for your socket outlets, it should be cut o and carefully disposed of. To avoid a possible shock
hazard, do not insert the discarded plug into a socket.
Warnings for disposal
• Refrigerant and cyclopentane foaming material used for the refrigerator are ammable. Therefore, when the refrigerator is
scrapped, it shall be kept away from any re source and be recovered by a special recovering company with corresponding
qualication other than be disposed by combustion, so as to prevent damage to the environment or any other harm.
• When the refrigerator is scrapped, disassemble the doors, and remove gasket of door and shelves; put the doors and shelves
in a proper place, so as to prevent trapping of any child.
Safe recovery instructions
Disposal
Old appliances still have some surplus value. An environmentally friendly approach will ensure that valuable raw materials are
recycled.
The refrigerants used in your equipment and insulation materials require special handling procedures. Make sure there is no pipe
damage on the back of the equipment before handling.
Up-to-date information on the options for disposing of old equipment and packaging from old equipment can be obtained from the
local municipal oce.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased. They can take this
product for environmentally safe recycling.
13 / 13
OPERATING INSTRUCTIONS
DOOR REVERSAL INSTRUCTIONS
If the appliance is placed on its back or side during this process
it must be allowed to stand upright for 6 hours before plugging in
to avoid damage to internal components.
1. Remove the screw hole cover from the top left side of the
cabinet. Remove the upper hinge cover and the upper hinge
from the top right side of the cabinet. Remove the refrigerator
door from the cabinet
2. Remove the center hinge from the right side of the cabinet.
Remove the freezer door from the cabinet. Remove the
screw hole covers from the left side of the cabinet. Remove
the freezer door from the cabinet.
3. Remove the lower hinge from the bottom right side of the
cabinet.
4. Remove the pin shaft to the right hole on the lower hinge,
then insert the pin shaft into the left hole on the lower hinge.
5. Install the lower hinge onto the lower left side of the cabinet.
6. Remove the freezer door stop from the lower right side to the
left side of the door. Remove the refrigerator door stop from
the lower right side to the left side of the door.
7. Move the door bushing from the top right side of the refrige-
rator door and remove the hinge hole cover from the top left
side of the door. Exchange their positions.
8. Install the freezer door onto the cabinet. Install the center
hinge on the left side of the cabinet. Install the screw hole
covers on the right side of the cabinet.
9. Install the refrigeratordoor onto the cabinet. Install the upper
hinge on the top left side of the cabinet. Install the screw hole
cover onto the top right side of the cabinet.
Note: These instructions reference the models that come from
the factory with a right hand swing door. If your appliance comes
with a left hand swing, ensure that you ip the “left” and “right’ in
these instructions.
