aus Table of contents
Table of contentsTable of contents
1 Safety ............................................ 3
1.1 General information .................... 3
1.2 Intended use ................................ 3
1.3 Restriction on user group .......... 4
1.4 Safe installation ........................... 4
1.5 Safe use ........................................ 6
1.6 Damaged appliance ................... 7
1.7 Risk to children ........................... 7
2 Preventing material damage ...... 9
2.1 Safe installation ........................... 9
2.2 Safe use ........................................ 9
3 Environmental protection and
saving energy ............................ 10
3.1 Disposing of packaging ........... 10
3.2 Saving energy ............................ 10
3.3 Aqua sensor ............................... 10
3.4 Sensors ....................................... 10
3.5 Efficient Dry ................................ 10
4 Installation and connection ...... 11
4.1 Scope of supply ........................ 11
4.2 Installing and connecting the
appliance .................................... 11
4.3 Drainage connection ................ 11
4.4 Drinking water connection ...... 12
4.5 Electrical connection ................ 12
5 Familiarising yourself with
your appliance ........................... 13
5.1 Appliance .................................... 13
5.2 Controls ...................................... 14
6 Programmes .............................. 16
6.1 Information for test institute ..... 19
6.2 Favourite ................................ 19
7 Additional functions .................. 20
8 Features ..................................... 21
8.1 Top basket ................................. 21
8.2 Etagere ........................................ 21
8.3 Extra Clean Zone ...................... 22
8.4 Bottom basket ........................... 22
8.5 Folding prongs .......................... 23
8.6 Cutlery basket ............................ 23
8.7 Cutlery drawer ........................... 24
8.8 Basket heights ........................... 24
9 Before using for the first time .. 25
9.1 Making settings for initial start-
up ................................................. 25
10 Rinse aid system .................... 25
10.1 Rinse aid .................................. 25
10.2 Setting the amount of rinse
aid .............................................. 26
10.3 Switching the rinse aid sys-
tem off ....................................... 26
11 Detergent ................................. 26
11.1 Suitable detergents ................ 26
11.2 Unsuitable detergents ............ 28
11.3 Information on detergents ..... 28
11.4 Adding detergent .................... 28
12 Tableware ................................ 29
12.1 Damage to glass and table-
ware ........................................... 29
12.2 Arrange tableware .................. 30
12.3 Removing tableware .............. 31
13 Basic operation ....................... 31
13.1 Switching on the appliance .. 31
13.2 Setting a programme ............. 31
13.3 Setting additional functions .. 31
13.4 Setting timer programming ... 31
13.5 Starting the programme ........ 32
13.6 Interrupting programme ........ 32
13.7 Terminate programme ........... 32
13.8 Switching off appliance ......... 32
14 Basic settings .......................... 32
14.1 Overview of basic settings .... 32
14.2 Changing basic settings ........ 36
15 HomeConnect ....................... 36
15.1 Setting up HomeConnect ..... 36
15.2 HomeConnect settings ......... 37
15.3 Remote Start .................... 37
2
Safety aus
15.4 Smart Start
1
............................. 37
15.5 Remote Diagnostics .............. 37
15.6 Software update ...................... 37
15.7 Data protection ........................ 38
16 Cleaning and servicing ........... 38
16.1 Cleaning the tub ..................... 38
16.2 Cleaning products .................. 38
16.3 Tips on appliance care .......... 38
16.4 Machine Care .................. 39
16.5 Filter system ............................. 40
16.6 Cleaning spray arms .............. 41
16.7 Cleaning Extra Clean Zone ... 41
17 Troubleshooting ...................... 42
17.1 Clean wastewater pump ........ 55
18 Transportation, storage and
disposal .................................... 55
18.1 Removing the appliance ....... 55
18.2 Protect appliance from
frost ........................................... 56
18.3 Transporting the appliance ... 56
18.4 Disposing of old appliance ... 56
19 Customer Service ................... 56
19.1 Product number (E-Nr.), pro-
duction number (FD) and
consecutive numbering (Z-
Nr.) ............................................. 57
19.2 AQUA-STOP guarantee ......... 57
20 Technical specifications ........ 57
20.1 Information regarding Free
and Open Source Software .. 58
21 Declaration of Conformity ...... 58
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
Only use this appliance:
¡ For cleaning household tableware.
¡ in closed rooms in the home and with similar applications, e.g.:
in canteens in shops, offices and other work environments; in
agricultural businesses; use by customers in hotels, motels and
other typical home environments; in bed and breakfasts.
¡ Up to an altitude of 4000 m above sea level.
1
Depending on the appliance specifications
3
aus Safety
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
1.4 Safe installation
WARNING‒Risk of injury!
Improper installation may cause injury.
When installing and connecting the appliance, follow the instruc-
tions in the manual and installation instructions.
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
Connect and operate the appliance only in accordance with the
specifications on the rating plate.
Always use the supplied power cable for the new appliance.
Connect the appliance to a power supply with alternating cur-
rent only via a properly installed socket with earthing.
The protective conductor system of the domestic electrical in-
stallation must be properly installed.
Never equip the appliance with an external switching device,
e.g. a timer or remote control.
When the appliance is installed, the mains plug of the power
cord must be freely accessible. If free access is not possible, an
isolating switch must be integrated into the permanent electrical
installation according to the installation regulations.
When installing the appliance, check that the power cable is not
trapped or damaged.
4
Safety aus
Cutting through the supply hose or immersing the Aqua-Stop
valve in water is dangerous.
Never immerse the plastic housing in water. The plastic housing
on the supply hose contains an electric valve.
Never cut through the supply hose. The supply hose contains
electric power cables.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved
adapters.
Do not use extension cables or multiple socket strips.
Only use adapters and power cords approved by the manufac-
turer.
If the power cord is too short and a longer one is not available,
please contact an electrician to have the domestic installation
adapted.
Contact between the appliance and installation lines may lead to a
defect in these lines, e.g. gas pipes and power lines. Gas from a
corroded gas pipe can ignite. A damaged power line can cause a
short circuit.
Check that there is a distance of at least 5cm between the ap-
pliance and installation lines.
WARNING‒Risk of injury!
Hinges move when opening and closing the appliance door and
can cause injury.
If built-under or integrable appliances are not in a cavity so that
one side is accessible, the hinge area must be covered at the
side. Covers are available from Customer Service or specialist
outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance to tip up.
Only install built-under or integrable appliances under a continu-
ous worktop that is securely connected to adjacent cabinets.
5
aus Safety
1.5 Safe use
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for use on
packagings of detergent and rinse aid products may cause seri-
ous harm to health.
Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
WARNING‒Risk of explosion!
Adding solvents to the interior of the appliance may cause explo-
sions.
Never add solvents to the interior of the appliance.
Highly caustic alkaline or highly acidic cleaning agents in conjunc-
tion with aluminium parts in the interior of the appliance may
cause explosions.
Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in con-
junction with aluminium parts (e.g. grease filters of extractor
hoods or aluminium pans), e.g. for the Machine Care pro-
gramme.
WARNING‒Risk of injury!
Leaving the appliance door open may result in injury.
Only open the appliance door to load or unload tableware in or-
der to prevent accidents, e.g. through tripping.
Do not sit or stand on the appliance door when open.
Knives and utensils with sharp points can cause injuries.
Arrange knives and utensils with sharp points in the cutlery bas-
ket with the points downwards, on the knife shelf or in the cut-
lery drawer.
WARNING‒Risk ofscalding!
If you open the appliance door while the programme is running,
hot water may splash out of the appliance.
Open the appliance door carefully if the programme is still run-
ning.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Only use the appliance in enclosed spaces.
6
Safety aus
Never expose the appliance to intense heat or humidity.
Do not use steam- or high-pressure cleaners to clean the appli-
ance.
If the insulation of the power cord is damaged, this is dangerous.
Never let the power cord come into contact with hot appliance
parts or heat sources.
Never let the power cord come into contact with sharp points or
edges.
Never kink, crush or modify the power cord.
1.6 Damaged appliance
WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
Never operate a damaged appliance.
Never operate an appliance with a cracked or fractured surface.
Never pull on the power cord to unplug the appliance. Always
unplug the appliance at the mains.
If the appliance or the power cord is damaged, immediately un-
plug the power cord or switch off the fuse in the fuse box and
turn off the water tap.
Call customer service.
Page56
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained
specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance
is damaged, it must be replaced with a special power cord or
special appliance power cable, which is available from the man-
ufacturer or its Customer Service.
1.7 Risk to children
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
Keep packaging material away from children.
Do not let children play with packaging material.
7
aus Safety
Children may breathe in or swallow small parts, causing them to
suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Children may become trapped in the appliance and suffocate.
Use the childproof lock if fitted.
Never let children play with or operate the appliance.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
With redundant appliances, unplug the power cord. Then cut
through the cord and damage the lock on the appliance door
beyond repair so that the appliance door will no longer close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
Keep an eye on children when opening and closing the appli-
ance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the mouth,
throat and eyes.
Keep children away from detergent and rinse aid products.
Keep children away from the appliance when open. The water in
the interior of the dishwasher is not drinking water. It may con-
tain residues of detergents and rinse aid.
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet col-
lecting tray and injure themselves.
Keep children away from the appliance when open.
8
Preventing material damage aus
Preventing material damage2 Preventing material
damage
2.1 Safe installation
ATTENTION
Improper installation of the appliance
may cause damage.
If the dishwasher is installed above
or below other domestic appli-
ances, follow the information on in-
stallation in combination with a
dishwasher in the installation in-
structions for the individual appli-
ances.
If there is no information or if the
installation instructions do not in-
clude the relevant information, con-
tact the manufacturer of these ap-
pliances to check that the dish-
washer can be installed above or
below these appliances.
If no information is available from
the manufacturer, the dishwasher
should not be installed above or
below such appliances.
To ensure the safe operation of all
domestic appliances, continue fol-
lowing the installation instructions
for the dishwasher.
Do not install the dishwasher un-
der a hob.
Do not install the dishwasher near
heat sources, e.g. radiators, heat
storage tanks, ovens or other ap-
pliances that generate heat.
Contact between the appliance and
water pipes may lead to corrosion of
these pipes, possibly causing them
to leak.
Check that there is a distance of at
least 5cm between the appliance
and the water pipe. The pipes sup-
plied for the drinking water and
waste water connections are not
affected here.
Modified or damaged water hoses
may result in material damage and
damage to the appliance.
Never kink, crush, modify or cut
through water hoses.
Only use the water hoses supplied
with the appliance or genuine
spare hoses.
Never re-use water hoses that
have been used before.
If the water pressure is too high or
too low, the appliance may not be
able to operate properly.
Make sure that the water pressure
in the water supply system is min.
50kPa (0.5bar) and max.
1000kPa (10bar).
If the water pressure exceeds the
maximum value specified, a pres-
sure-reducing valve must be in-
stalled between the drinking water
connection and the hose set of the
appliance.
2.2 Safe use
ATTENTION
Escaping water vapour can damage
fitted units.
When the programme ends, leave
the appliance to cool down for a
while before opening the door.
Unsuitable cleaning agents may dam-
age the appliance.
Do not use a steam cleaner.
So as not to scratch the finish on
the appliance, do not use sponges
with a rough surface or abrasive
cleaning agents.
To prevent corrosion, do not use
sponge cloths on dishwashers with
a stainless steel front or rinse such
cloths thoroughly several times be-
fore using them for the first time.
9
aus Environmental protection and saving energy
Environmental protection and saving energy3 Environmental protec-
tion and saving energy
3.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
Sort the individual components by
type and dispose of them separ-
ately.
3.2 Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco Wash programme.
The Eco Wash programme is en-
ergy-efficient and environmentally
friendly.
"Programmes", Page16
Change the sensor setting to the de-
fault.
Consumption is reduced.
"Sensors", Page10
3.3 Aqua sensor
The aqua sensor is an optical meas-
uring device (light barrier) which
measures the turbidity of the washing
water. You can save water with the
aqua sensor.
Use of the aqua sensor depends on
the programme. If the soiling level is
high, the rinsing water is drained off
and replaced with fresh water. If the
soiling level is lower, the rinsing wa-
ter is used in the next wash cycle, so
reducing water consumption by 3-6
litres. In the automatic programmes
the temperature and running time are
additionally adjusted to the level of
soiling.
3.4 Sensors
The sensors adjust the programme
sequence and strength in the auto-
matic programmes depending on the
level and type of soiling.
The sensor has different sensitivity
settings that can be changed in the
basic settings.
Sensor set-
ting
Description
SE:00 Optimum setting for a
mixed load and heav-
ily soiled tableware.
Saves both energy
and water.
SE:01 Adjusts the pro-
gramme strength for
effective removal of
food remnants even
with low soiling levels.
Energy and water
consumption are ad-
justed accordingly.
SE:02 Adjusts the pro-
gramme strength for
difficult conditions of
use, e.g. stubborn
dried-on food rem-
nants. Recommended
setting when using or-
ganic or ecological
detergents containing
low levels of active
agents. Energy and
water consumption
are adjusted accord-
ingly.
3.5 Efficient Dry
The appliance door opens automatic-
ally during the drying phase. This en-
sures a particularly economical dry-
ing result.
10
Installation and connection aus
For best drying results wait until the
end of programme before unloading
the tableware. The programme has
ended when the display shows
"00h:00m".
If automatic door opening is deactiv-
ated, energy consumption increases
and the drying phase is usually
shortened.
"Overview of basic settings",
Page32
If this additional function has been
selected, automatic door opening is
deactivated.
"Additional functions", Page20
Installation and connection4 Installation and con-
nection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the spe-
cified criteria and the installation in-
structions.
4.1 Scope of supply
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli-
ance or our Customer Service.
Note: The appliance has been tested
at the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
Dishwasher
Operating instructions
Installation Instructions
Further information documents
Installation material
Steam protection
Mains cable
4.2 Installing and connecting
the appliance
You can position your built-under or
integrable appliance in a fitted kit-
chen between wooden and plastic
walls.
1.
Follow the safety instructions.
Page3
2.
Follow the instructions for electrical
connection.
3.
Check the Scope of supply and
the condition of the appliance.
4.
Consult the installation instructions
for the installation dimensions re-
quired.
5.
Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6.
Install the drainage connection.
Page11
7.
Install the drinking water connec-
tion.
Page12
8.
Connect the appliance to the
power supply.
4.3 Drainage connection
Connect your appliance to drainage
connection so dirty water is dis-
charged via the wash cycle.
Installing the drainage connection
1.
Consult the installation instructions
supplied for the steps required
here.
2.
Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3.
When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4.
Also check that there is no cover
in the drainage system preventing
11
aus Installation and connection
the wastewater from being dis-
charged.
4.4 Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water con-
nection
Note: If you are replacing the appli-
ance, you must use a new water sup-
ply hose.
1.
Consult the installation instructions
supplied for the steps required
here.
2.
Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the Technical data.
3.
When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
4.5 Electrical connection
Connect your appliance to the power
supply.
Connecting the appliance to the
electricity supply
Notes
Follow the Safety instructions
Page4
.
Please note that the water safety
system is only functional if there is
a power supply.
1.
Insert the non-heating appliance
plug of the power cable into the
appliance.
2.
Insert the mains plug of the appli-
ance into a nearby socket.
The connection data for the appli-
ance can be found on the rating
plate.
3.
Check that the mains plug is inser-
ted properly.
12
Familiarising yourself with your appliance aus
Familiarising yourself with your appliance5 Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
10
11
12
Rating plate
Rating plate with E number and FD number
Page57
.
The data you need for Customer Service
Page56
.
Detergent dispenser
Add detergent to the detergent dispenser.
"Detergent", Page26
Bottom basket Bottom basket
Page22
13
aus Familiarising yourself with your appliance
Lower spray arm
The lower spray arm washes the tableware
in the bottom basket.
If the tableware has not been washed prop-
erly, clean the spray arms.
"Cleaning spray arms", Page41
Tablet collecting tray
During the wash cycle tablets automatically
fall out of the detergent dispenser into the
tablet collecting tray where they can fully
dissolve.
Top basket Top basket
Page21
Cutlery drawer Cutlery drawer
Page24
Cutlery shelf
1
Cutlery shelf
Page21
Upper spray arm
The upper spray arm washes the tableware
in the top basket.
If the tableware has not been washed prop-
erly, clean the spray arms.
"Cleaning spray arms", Page41
Filter system Filter system
Page40
Cutlery basket
Cutlery basket
"Cutlery basket", Page23
Dispenser for rinse aid
Add rinse aid to the dispenser for rinse aid.
"Rinse aid system", Page25
5.2 Controls
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
1
Depending on the appliance specifications
14
Familiarising yourself with your appliance aus
With some buttons you can perform different functions.
1 2 3 4 5 6 7
89101112
ON/OFF button and reset
button
Switching on the appliance
Page31
Switching off the appliance
Page32
Terminating the programme
Page32
Programme buttons Programmes
Display
The display shows information about
the remaining running time or the basic
settings. You can change the basic set-
tings via the display and the setting
buttons.
"Changing basic settings", Page36
Timer programming and set-
ting buttons
Setting timer programming
Page31
Changing basic settings
Page36
Remote Start
"Remote Start ", Page37
Programme buttons and addi-
tional functions
Programmes
Additional functions
"Additional functions", Page20
Start button
Starting the programme
"Starting the programme", Page32
WLAN display Home Connect
Page36
Water supply display Display for water supply
15
aus Programmes
Door handle
1
Open the appliance door.
Rinse aid refill indicator
Rinse aid system
"Adding rinse aid", Page25
button
If you press for approx. 3
seconds, you can open the basic set-
tings.
"Changing basic settings", Page36
Symbols on the display
1
The display shows the following sym-
bols depending on the model. See
here for an explanation.
Symbol Description
If the symbol for machine
care lights up on the dis-
play, run machine care.
"Machine Care ",
Page39
If the rinse aid refill indic-
ator lights up on the dis-
play, top up with rinse
aid.
"Adding rinse aid",
Page25
Symbol Description
If the appliance is con-
nected to a wireless
WLAN home network, the
symbol lights up on the
display.
"HomeConnect ",
Page36
If you have activated the
electronic start timer, the
symbol lights up on the
display.
"Setting timer program-
ming", Page31
If the water inflow or
drainage malfunctions,
the symbol lights up or
flashes on the display.
Programmes6 Programmes
You can find an overview of the programmes that can be selected here. Differ-
ent programmes, which can be found on the control panel of your appliance,
are available depending on the appliance configuration.
The running time may vary depending on the programme selected. The running
time depends on the water temperature, the quantity of tableware, the level of
soiling and the Additional function selected. The running time will change if the
rinse aid system is switched off or rinse aid needs to be added.
The programme data is based on values measured in the laboratory according
to AS/NZS 2007. Different influencing factors such as water temperature or
pipe pressure may result in deviations.
1
Depending on the appliance specifications
16
Programmes aus
Programme Consumption val-
ues
1) Duration in
hrs:mins
2) Energy con-
sumption in kWh
3) Water con-
sumption in litres
Use Programme se-
quence
Auto Gentle
1) 1:40-1:50
2) 0.650-
0.800
3) 11.5-14.0
Tableware:
Delicate table-
ware, cutlery,
temperature-
sensitive
plastics,
glasses and
stemware in the
stemware bas-
ket
Level of soiling:
Lightly adhering
fresh food rem-
nants
Sensor-controlled:
Optimised by
sensors depend-
ing on the soil-
ing level of the
washing water
Auto Wash
1) 2:35 -3:45
2) 0.900 -
1.450
3) 7.6 -15.4
Tableware:
Mixed table-
ware and cut-
lery
Level of soiling:
Common
household food
remnants lightly
dried on
Sensor-controlled:
Optimised by
sensors depend-
ing on the soil-
ing level of the
washing water
Auto Intensive 65
-75°
1) 2:10-2:35
2) 1.100-
1.300
3) 11.5-13.5
Tableware:
Pots and pans,
non-fragile
tableware and
cutlery
Level of soiling:
Stubborn
burned or dried-
on food rem-
nants contain-
ing starch and
protein
Sensor-controlled:
Optimised by
sensors depend-
ing on the soil-
ing level of the
washing water
17
aus Programmes
Programme Consumption val-
ues
1) Duration in
hrs:mins
2) Energy con-
sumption in kWh
3) Water con-
sumption in litres
Use Programme se-
quence
Eco Wash
1) 3:45
2) 0.660
3) 12.2
Tableware:
Mixed table-
ware and cut-
lery
Level of soiling:
Normally soiled
load
Most economical
programme:
Pre-Rinse
Cleaning 45°C
Intermediate
rinse
Final rinse 44°C
Drying
Extra Quiet
1) 4:00
2) 0.950
3) 10.8
Tableware:
Mixed table-
ware and cut-
lery
Level of soiling:
Common
household food
remnants lightly
dried on
Reduced noise:
Pre-Rinse
Cleaning 50°C
Intermediate
rinse
Final rinse 63°C
Dry
Quick 1h
1) 1:35
2) 1.150
3) 10.5
Tableware:
Mixed table-
ware and cut-
lery
Level of soiling:
Common
household food
remnants lightly
dried on
Time-optimised:
Cleaning 65°C
Intermediate
rinse
Final rinse 69°C
Dry
Express Wash
1) 1:20
2) 0.900
3) 10.5
Tableware:
Delicate table-
ware, cutlery,
temperature-
sensitive
plastics and
glasses
Level of soiling:
Lightly adhering
fresh food rem-
nants
Time-optimised:
Cleaning 45°C
Intermediate
rinse
Final rinse 55°C
18
Programmes aus
Programme Consumption val-
ues
1) Duration in
hrs:mins
2) Energy con-
sumption in kWh
3) Water con-
sumption in litres
Use Programme se-
quence
Machine Care
1) 2:10
2) 1.350
3) 15.2
Use only if appli-
ance is unloaded.
Machine Care
70°C
Favourite
1) 0:15-0:15
2) 0.050-
0.050
3) 4.0-4.0
- -
6.1 Information for test insti-
tute
Test institutes can request the condi-
tions for comparison tests, e.g. ac-
cording to AS/NZS2007, by sending
an e-mail to dishwasher@test-appli-
ances.com.
These are the conditions for conduct-
ing the tests, however not the results
or consumption values.
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat-
ing plate on the appliance door.
Open ajar using a block of approxim-
ately 100mm upon completion of dry
test.
6.2 Favourite
You can save a combination of a pro-
gramme and an additional function to
the button.
Save the programme via the
HomeConnect app or on the appli-
ance.
The pre-rinse program is saved to
this button at the factory. Pre-rinse is
suitable for all types of tableware.
The tableware undergoes intermedi-
ate cleaning via cold rinsing.
Tip: You can use the HomeConnect
app to download additional pro-
grammes and save them to the
button.
1
Saving Favourite on the appli-
ance
1.
Open the appliance door.
2.
Press .
3.
Press the right programme button.
4.
Press the button for the relevant
additional function.
5.
Press for 3 seconds.
The selected programme and the
additional function will flash.
flashes.
The programme and the additional
function are saved.
Tip: To reset the programme to the
pre-rinse programme stored at the
factory, use the HomeConnect app
1
1
Depending on the appliance specifications
19
aus Additional functions
or reset your appliance to the factory
settings.
"Overview of basic settings",
Page32
Additional functions7 Additional functions
You can find an overview of the additional functions that can be selected here.
Different additional functions, which can be found on the control panel of your
appliance, are available depending on the appliance configuration. You can se-
lect certain additional functions depending on the programme.
Symbol Additional func-
tion
Use
EfficientDry The appliance door opens automatically dur-
ing the drying phase.
Depending on the basic setting selected,
automatic door opening is activated or deac-
tivated by the additional function. The addi-
tional function button lights up when auto-
matic door opening is activated.
"Efficient Dry", Page10
HygienePlus To ensure a higher hygiene status for the ap-
pliance and tableware, the temperature is
raised and maintained for an extra-long
period.
Especially suitable for cleaning chopping
boards or baby bottles.
Continuous use of this function increases the
hygiene status.
This will increase the running time and en-
ergy consumption.
SpeedPerfect The run time is shortened by 15% to 75%
1
depending on the rinse programme.
The additional function can be activated be-
fore the start of the programme and at any
time when the programme is running.
Energy and water consumption are in-
creased.
If you select this additional function, automatic
door opening is deactivated.
1
1
Depending on the appliance specifications
20
Features aus
Features8 Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
8.1 Top basket
Arrange cups, glasses and small
items of tableware in the top basket.
You can adjust the height of the top
basket to make room for larger items
of tableware.
Adjusting top basket with side
levers
To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.
1.
Pull out the top basket.
2.
To prevent the basket from sud-
denly dropping down, hold the
side of the basket by the top edge.
3.
Press in the levers on the right and
left on the outside of the basket.
4.
Raise or lower the basket evenly to
the right level.
Check that the basket is level on
both sides.
5.
Release the levers.
The basket clicks into position.
6.
Slide the basket back in.
8.2 Etagere
Use the cutlery shelf and space un-
derneath for small cups and glasses
21
aus Features
or for large items of cutlery, e.g.
cooking spoons or serving cutlery.
If you do not need the cutlery shelf,
you can fold it up.
8.3 Extra Clean Zone
Use the Extra Clean Zone in the top
basket to clean soiled tableware thor-
oughly, e.g. muesli bowls.
Selecting Extra Clean Zone
Note: Consumption will increase if
you operate your appliance with the
Extra Clean Zone switched on.
1.
Pull out the top basket.
2.
Set the slider to ON or OFF.
3.
Push in the top basket.
8.4 Bottom basket
Arrange pans and plates in the bot-
tom basket.
Cutlery basket
1
Large plates up to a diameter of
34cm can be arranged in the bottom
basket as shown.
1
Depending on the appliance specifications
22
Features aus
8.5 Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to po-
sition pans, bowls and glasses
better.
1
Folding down prongs
1
If you do not need the prongs, fold
them down.
1.
Push the lever forwards and fold
down the prongs .
2.
To use the prongs again, fold them
back up.
The prongs audibly click into posi-
tion.
8.6 Cutlery basket
Arrange cutlery in the cutlery basket,
always without sorting it and with the
sharp points downwards.
1
Depending on the appliance specifications
23
aus Features
8.7 Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and
sharp edges downwards.
You can reorganise the cutlery
drawer to make more space for
longer/wider items of cutlery.
Reorganising cutlery drawer
You can fold down the side shelves
and folding spines to make more
space for longer/wider items of cut-
lery.
1.
To fold down a side shelf, push the
lever forwards and fold down the
side shelf .
2.
To fold down the folding spines,
push the lever forwards and fold
down the folding spines .
1
Tip: If you want to return the cutlery
drawer to the original position, fold
the side shelf back up until it clicks
into position.
8.8 Basket heights
Set the baskets at the right height.
Appliance height 86.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 24 cm 33 cm/34 cm
Page22
24
Before using for the first time aus
Level Top basket Bottom basket
2 max. ø 26.5 cm 30.5 cm
3 max. ø 29 cm 28 cm
Appliance height 86.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 18 cm 33 cm/34 cm
Page22
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm
Before using for the first time9 Before using for the
first time
9.1 Making settings for initial
start-up
On initial start-up or after a reset to
the factory settings, you will need to
make settings.
Tip: Connect your appliance to a mo-
bile device. You can conveniently
change all settings via the
HomeConnect app.
"HomeConnect ", Page36
Requirement: The appliance has
been installed and connected.
Page11
1.
Add rinse aid.
Page25
2.
Switch on the appliance.
Page31
3.
Set the amount of rinse aid to be
dispensed.
Page26
4.
Add detergent.
5.
Start the Programme with the
highest cleaning temperature
Page16
without tableware.
To remove any marks from water
or other residues, we recommend
you operate the appliance without
tableware before using it for the
first time.
Tip: You can change this setting and
other Basic settings
Page32
at
any time again.
Rinse aid system10 Rinse aid system
10.1 Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish-
washers.
Adding rinse aid
If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.
1.
Press the catch on the lid of the
dispenser for rinse aid and lift .
25
aus Detergent
2.
Add rinse aid up to the max mark.
3.
If rinse aid spills out, remove it
from the tub.
Spilled rinse aid can cause ex-
cessive frothing during the wash
cycle.
4.
Close the lid of the dispenser for
rinse aid.
The lid clicks into position.
10.2 Setting the amount of
rinse aid
If there are streaks or water marks on
tableware, change the amount of
rinse aid.
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows .
3.
Press repeatedly until the
display shows the value set at the
factory r:05.
4.
Press or repeatedly until the
right amount of rinse aid has been
set.
– A low setting adds less rinse aid
during the wash cycle and re-
duces streaking on tableware.
– A higher setting adds more
rinse aid during the wash cycle,
reduces water marks and im-
proves the drying result.
5.
To save the settings, press
for 3 seconds.
10.3 Switching the rinse aid
system off
If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid compon-
ent, you can switch the rinse aid sys-
tem off.
Tip: The function of rinse aid is lim-
ited with combined detergents. You
will generally get better results using
rinse aid.
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows .
3.
Press repeatedly until the
display shows the value set at the
factory r:05.
4.
Press or repeatedly until the
display shows r:00.
5.
To save the settings, press
for 3 seconds.
The rinse aid system is switched
off and the rinse aid refill indicator
is deactivated.
Detergent11 Detergent
11.1 Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res-
ults, use separate detergent together
with Rinse aid
Page25
.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygen-
based bleaching agents are generally
used to remove coloured stains, e.g.
tea or ketchup.
Note: Follow the manufacturer's in-
structions for each detergent.
26
Detergent aus
Detergent Description
Tabs Tabs are suitable
for all cleaning
functions and do
not need to be
measured out.
With shorter Pro-
grammes
Page16
tabs
sometimes do not
dissolve entirely
and leave
residues of deter-
gent. This may im-
pair the cleaning
effect.
Powder deter-
gent
Powder detergent
is recommended
for shorter Pro-
grammes
Page16
. The
dosage can be
adjusted to the
level of soiling.
Liquid detergent Liquid detergent
works faster and
is recommended
for shorter Pro-
grammes
Page16
without
PreRinse.
Detergent Description
Sometimes liquid
detergent may
leak out despite
the detergent dis-
penser being
closed. This is not
a fault and is non-
critical if you re-
member the fol-
lowing:
Only choose a
programme
without PreR-
inse.
Do not select
timer program-
ming for start-
ing the pro-
gramme.
The dosage can
be adjusted to the
level of soiling.
Tip: Suitable detergents are available
online via our website or from Cus-
tomer Service
Page56
.
Separate detergents
Separate detergents are products
that do not contain components other
than detergent, e.g. powder or liquid
detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the table-
ware.
For better washing and drying res-
ults, please also use Rinse aid
Page25
.
Combined detergents
Besides conventional separate deter-
gents, a number of products are
available with additional functions.
These products not only contain de-
tergent, but also rinse aid and salt re-
27
aus Detergent
placement substances (3in1) and,
depending on the combination (4in1,
5in1,...), additional components such
as glass protection or stainless steel
cleaner.
Note: Follow the manufacturer's in-
structions for each detergent.
If you are using combined detergent,
the washing programme is adjusted
automatically to ensure the best pos-
sible washing and drying result.
11.2 Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Detergent Description
Hand wash-
ing-up liquid
Hand washing-up li-
quid can cause in-
creased frothing and
damage the appli-
ance.
Detergent
containing
chlorine
Chlorine residue on
tableware may
present a risk to
health.
11.3 Information on detergents
Follow the instructions on detergents
in everyday use.
Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or com-
pletely dispense with certain sub-
stances. The cleaning effect may
be restricted here.
Set the rinse aid system to the
separate or combined detergent in
use.
Follow the manufacturer's instruc-
tions for each detergent.
To prevent sticking, only touch de-
tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.
Even if the rinse aid refill indicator
lights up, washing programmes will
still run properly with combined de-
tergents.
The function of rinse aid is limited
with combined detergents. You will
generally get better results using
rinse aid.
Use tablets with a special drying
performance.
11.4 Adding detergent
1.
To open the detergent dispenser,
press the locking latch.
2.
Add the detergent to the dry deter-
gent dispenser.
If you are using tablets, one is
enough. Insert the tablets in a hori-
zontal position.
If you are using powder or liquid
detergent, follow the manufac-
turer's instructions and quantities
for dosage in the detergent dis-
penser.
20ml–25ml detergent is suffi-
cient for normal soiling. If table-
ware is only lightly soiled, slightly
less than the amount of detergent
specified is usually sufficient.
28
Tableware aus
3.
Close the lid of the detergent dis-
penser.
The lid clicks into position.
The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the tab-
let collecting tray and dissolve in
the right dosage. In order to en-
sure that tablets can dissolve
evenly, do not place any other ob-
jects in the tablet collecting tray.
Tip: If you use powder detergent and
select a program with pre-rinse, you
can also add a little detergent to the
interior door of the appliance.
Tableware12 Tableware
Only clean tableware that is suitable
for dishwashers.
Note: Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.
12.1 Damage to glass and tableware
Only put glasses and china in the dishwasher if it is marked as dishwasher-safe
by the manufacturer. Avoid damage to glass and tableware.
Cause Recommendation
The following tableware is not dish-
washer-safe:
Items of cutlery and tableware
made from wood
Decorated glassware, antique and
hand-crafted tableware
Plastic parts not resistant to heat
Tableware made from copper or tin
Tableware soiled with ash, wax, lub-
ricating grease or paint
Very small items of tableware
Only put tableware in the dishwasher if
it is marked as dishwasher-safe by the
manufacturer.
The chemical composition of deter-
gent causes damage.
Use a detergent marked by the manu-
facturer as gentle on tableware.
Highly caustic alkaline or highly acidic
cleaning solutions, in particular com-
mercial or industrial cleaners, are not
safe to use in the dishwasher with alu-
minium.
If you are using highly caustic alkaline
or highly acidic cleaning agents, in par-
ticular commercial or industrial clean-
ing agents, do not put aluminium parts
in the dishwasher interior.
29
aus Tableware
Cause Recommendation
The water temperature of the pro-
gramme is too high.
Select a programme with lower temper-
atures.
After the programme has ended, take
glassware and cutlery out of the appli-
ance without delay.
12.2 Arrange tableware
Arrange tableware correctly to optim-
ise the dishwashing result and pre-
vent damage to both the appliance
and tableware.
Note: Load the baskets so that no
projecting items of tableware interfere
with closing of the door. Projecting
items of tableware may push the ap-
pliance door open during the pro-
gramme, so allowing steam to es-
cape and water to leak out around
the door. This could damage your kit-
chen units.
Tips
Using the appliance allows you to
save energy and water compared
to washing-up by hand.
See our website for examples of
how to load your appliance effi-
ciently.
To save energy and water, load
the machine with the number of
place settings specified (standard
load with tableware and cutlery).
For better washing and drying res-
ults, position items with curves or
recesses at an angle so water can
run off.
1.
Remove large remnants of food
from tableware.
To save resources, do not pre-
rinse tableware under running wa-
ter.
2.
Observe the following when arran-
ging tableware:
– Put heavily soiled tableware in
the bottom basket, e.g. pans.
The more powerful the spray jet,
the better the dishwashing result
will be.
– To prevent damage to table-
ware, arrange it so it is stable
and cannot tip over.
– To prevent injury, arrange cut-
lery with the points and sharp
edges facing down.
– Position containers with the
openings facing down so no wa-
ter can collect in them.
– Do not block the spray arms -
make sure that they can turn
freely.
– Do not place small parts in the
tablet collecting tray and do not
30
Basic operation aus
block it with tableware so as not
to obstruct the lid of the deter-
gent dispenser.
12.3 Removing tableware
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.
When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.
1.
To prevent water dripping on the
tableware, unload it starting at the
bottom and working up.
2.
Check the washing tank and ac-
cessories for soiling and clean if
necessary.
"Cleaning and servicing",
Page38
Basic operation13 Basic operation
13.1 Switching on the appli-
ance
Press .
The programme last selected and
the additional function last selec-
ted will be set by default.
If you do not perform any actions
on the appliance for 10 minutes,
the appliance will automatically
switch off.
13.2 Setting a programme
To adjust the washing programme to
the soiling level of the tableware, se-
lect a suitable programme.
Press the right programme button.
The programme is set and the pro-
gramme button flashes.
The remaining running time of the
programme appears on the dis-
play.
13.3 Setting additional func-
tions
You can set additional functions to
complete the washing programme
selected.
Note: The additional functions which
can be used depend on the pro-
gramme selected.
Press the button for the relevant
additional function.
"Additional functions", Page20
The additional function is set and
the additional function button
flashes.
13.4 Setting timer program-
ming
You can delay the start of the pro-
gramme by up to 24hours.
1.
Press or .
"00h:01m" appears on the display.
2.
Use or to set the required
start time for the programme.
3.
Press .
This activates time preselection.
Tip: To deactivate timer program-
ming, press or repeatedly
until "00h:00m" appears in the dis-
play.
31
aus Basic settings
13.5 Starting the programme
Press .
While the programme is running,
status information about timer pro-
gramming, the programme or the
remaining running time is projec-
ted onto the floor below the appli-
ance door. If the base panel is
pulled forwards or if the appliance
is installed at eye level with the
cabinet front fitted flush, the dis-
play is not visible.
The programme has ended when
"00h:00m" is shown on the floor
below the appliance door and on
the display.
Notes
If you want to add more tableware
while the appliance is running, do
not use the tablet collecting tray as
a handle for the top basket. You
might touch the partially dissolved
tablet.
You can only change a pro-
gramme when running if you can-
cel it.
"Terminate programme",
Page32
The appliance switches off auto-
matically 1minute after the end of
the programme to save energy. If
you open the appliance door im-
mediately after the programme has
ended, the appliance will switch off
after 4 seconds.
Tip: To assist the drying, we recom-
mend that the door will be partially
opened after the cycle.
13.6 Interrupting programme
Note: When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.
1.
Open the appliance door carefully.
2.
Press .
The programme is saved and the
appliance switches off.
3.
Press to resume the pro-
gramme.
4.
Close the appliance door.
13.7 Terminate programme
To end a programme early or to
switch from a programme that has
already started, you will need to can-
cel it first.
1.
Open the appliance door.
2.
Press for approx.
4seconds.
3.
Close the appliance door.
The programme is cancelled and
ends after approx. 1minute.
13.8 Switching off appliance
1.
Please note the information on
Safe use
Page9
.
2.
Press .
Tip: If you press during the wash
cycle, the programme currently run-
ning will be interrupted. When you
switch the appliance back on, the
programme continues automatically.
Basic settings14 Basic settings
You can configure the basic settings
for your appliance to meet your
needs.
14.1 Overview of basic settings
The basic settings depend on the features of your appliance.
32
Basic settings aus
Basic setting Display text Selection Description
Rinse aid dis-
pensing
r:05
1
r:00 - r:06 Set the amount of rinse aid to
be dispensed.
"Setting the amount of
rinse aid", Page26
Switch the rinse aid system
off with level r:00.
Sensor setting SE:00
1
SE:00 - SE:02 Set the water sensor for
identifying soiling.
"Sensors", Page10
Extra Dry d:00
1
d:00 - d:01 The temperature is increased
during the final rinse, which
improves the drying result.
This may increase the run
time slightly.
Note: Not suitable for delicate
items of tableware.
Switch Extra Dry on "d:01" or
off "d:00".
Hot water A:00
1
A:00 - A:01 Set cold water or hot water
connection. Only set the ap-
pliance to hot water if this
can be prepared with little en-
ergy and a suitable installa-
tion is available, e.g. solar
heating system with circula-
tion line. The water temperat-
ure should be at least 40°C
and max. 60°C.
Switch hot water on "A:01" or
off "A:00".
TimeLight S:01
1
S:00 - S:01 Switch TimeLight on or off.
While the programme is run-
ning, status information is
projected onto the floor below
the appliance door relating to
timer programming, the pro-
gramme or the time remain-
ing. If the base panel is
pulled forwards or if the appli-
ance is installed at eye level
1
Factory setting (may vary according to model)
33
aus Basic settings
Basic setting Display text Selection Description
with the cabinet front fitted
flush, the display is not vis-
ible.
Level "S:00" switches Time-
Light off.
Start programme SP:00
1
SP:00 - SP:01 Set a default programme for
when the appliance is
switched on.
With the setting "SP:00",
the last programme selec-
ted and the last additional
function selected are set
by default when the appli-
ance is switched on.
With the setting "SP:01",
the standard programme is
set by default when the ap-
pliance is switched on.
Tone volume SL:02
1
SL:00 -SL:03 Adjustment of tone volume.
Level "SL:00" switches the
signal tone off.
If the Eco drying function is
activated, the end of the pro-
gramme is not indicated by
an audible signal tone.
Button volume bL:02
1
bL:00 - bL:03 Set the button volume during
operation. Level "bL:00"
switches the button tones off.
Efficient Dry o:01
1
o:00 - o:02 Activate or deactivate auto-
matic opening of the appli-
ance door during the drying
phase.
If the function has been activ-
ated, the running time may in-
crease.
1
Factory setting (may vary according to model)
34
Basic settings aus
Basic setting Display text Selection Description
The following settings are
possible:
With the setting "o:00"
automatic door opening is
deactivated in all pro-
grammes.
With the setting "o:01"
automatic door opening is
activated in all pro-
grammes.
With the setting "o:02"
automatic door opening is
activated only in the pro-
gramme Eco Wash .
"Efficient Dry", Page10
WiFi Cn:00 Cn:00 - Cn:01 Switch the wireless network
connection on or off.
Level "Cn:00" switches the
wireless network connection
off.
This basic setting is not avail-
able until you have connected
the appliance with the
HomeConnect app.
"HomeConnect ",
Page36
Remote Start rc:01 rc:00 - rc:02 Activate or deactivate remote
start.
The following settings are
possible:
With the setting "rc:00", the
function is permanently de-
activated.
With the setting "rc:01", the
function can be selected
via the button.
"Activating Remote Start
", Page37
With the setting "rc:02", the
function is permanently ac-
tivated.
This basic setting is not avail-
able until you have connected
35
aus HomeConnect
Basic setting Display text Selection Description
the appliance with the
HomeConnect app.
"HomeConnect ",
Page36
Factory setting rE: Start with
Y:ES
Confirm with
Restore changed settings to
the factory settings.
The settings for initial start-up
must be configured.
14.2 Changing basic settings
Tip: Connect your appliance to a mo-
bile device. You can conveniently
change all settings via the
HomeConnect app.
1.
Open the appliance door.
2.
Press .
3.
To open the basic settings, press
for 3 seconds.
The display shows .
4.
Press repeatedly until the
display shows the required setting.
5.
Press or repeatedly until the
display shows the right value.
You can change several settings.
6.
To save the settings, press
for 3 seconds.
7.
Close the appliance door.
HomeConnect 15 HomeConnect
This appliance is network-capable.
Connect your appliance to a mobile
device to control its functions via the
HomeConnect app.
The HomeConnect services are not
available in every country. The avail-
ability of the HomeConnect function
depends on the availability of the
HomeConnect services in your coun-
try. You can find information about
this at:
www.home-connect.com
.
To be able to use HomeConnect,
you must first set up the connection
to the WLAN home network (Wi-Fi
1
)
and to the HomeConnect app.
The HomeConnect app guides you
through the entire login process. Fol-
low the instructions, noting the in-
formation in the HomeConnect app.
Note: Please note the safety precau-
tions in this instruction manual and
make sure that they are also ob-
served when operating the appliance
via the HomeConnect app.
"Safety", Page3
15.1 Setting up HomeConnect
Requirement: The appliance is re-
ceiving signals from the WLAN home
network (Wi-Fi) at its installation loca-
tion.
1.
Scan the following QR code.
You can install the HomeConnect
app and connect your appliance
via the QR code.
1
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
36
HomeConnect aus
2.
Follow the instructions in the
HomeConnect app.
15.2 HomeConnect settings
Adapt HomeConnect to your needs.
You can find the HomeConnect set-
tings in the basic settings for your ap-
pliance. Which settings the display
shows will depend on whether
HomeConnect has been set up and
whether the appliance is connected
to your home network.
15.3 Remote Start
You can use the HomeConnect app
to start the appliance with your mo-
bile device.
Tip: If you select "rc:02" in the Basic
settings
Page35
of this function,
the function is permanently activated
and you can start your appliance with
a mobile device at any time.
Activating Remote Start
When you have selected "rc:01" in
the basic settings of this function, ac-
tivate the function on your appliance.
Requirements
The appliance is connected to your
WLAN home network.
The appliance is connected to the
HomeConnect app.
"rc:01" is selected in the Basic set-
tings
Page35
of this function.
A programme is selected.
Press .
If you open the appliance door, the
function is automatically deactiv-
ated.
button lights up.
Tip: To deactivate the function, press
.
15.4 Smart Start
1
Smart Start automatically determines
the optimal time for the programme
to start.
You can use the HomeConnect app
to activate or deactivate the function.
Activating Smart Start
Requirements
Smart Start is activated via the
HomeConnect app.
Preferences for time and energy
are set in the HomeConnect app.
1.
Press .
"E:nG" lights up in the display.
The display shows the optimal
start time and the duration of the
selected programme.
2.
Press .
Smart Start is active.
The programme starts as soon as
the optimal time is reached.
Tip: Deactivate the function a single
time by pressing .
15.5 Remote Diagnostics
Customer Service can use Remote
Diagnostics to access your appliance
if you contact them, have your appli-
ance connected to the HomeCon-
nect server and if Remote Dia-
gnostics is available in the country in
which you are using the appliance.
Tip: For further information and de-
tails about the availability of Remote
Diagnostics in your country, please
visit the service/support section of
your local website:
www.home-
connect.com
.
15.6 Software update
You can use this function to update
the software of your appliance, e.g.
1
Depending on the appliance specifications
37
aus Cleaning and servicing
for optimisation, troubleshooting or
safety-relevant updating.
The HomeConnect app informs you
about available software updates.
15.7 Data protection
Please see the information on data
protection.
The first time your appliance is re-
gistered on a home network connec-
ted to the Internet, your appliance will
transmit the following types of data to
the HomeConnect server (initial re-
gistration):
Unique appliance identification
(consisting of appliance codes as
well as the MAC address of the
Wi-Fi communication module in-
stalled).
Security certificate of the Wi-Fi
communication module (to ensure
a secure data connection).
The current software and hardware
version of your appliance.
Status of any previous reset to
factory settings.
This initial registration prepares the
HomeConnect functions for use and
is only required when you want to
use the HomeConnect functions for
the first time.
Note: Please note that the
HomeConnect functions can only be
utilised with the HomeConnect app.
Information on data protection can be
retrieved in the HomeConnect app.
Cleaning and servicing16 Cleaning and servi-
cing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
16.1 Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
Never use detergents containing
chlorine.
1.
Remove any coarse soiling in the
interior with a damp cloth.
2.
Add detergent to the detergent dis-
penser.
3.
Select the programme with the
highest temperature.
4.
Start the programme without table-
ware.
Page32
16.2 Cleaning products
Only use suitable cleaning products
to clean your appliance.
"Safe use", Page9
16.3 Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door
seals, the front of
the dishwasher
and the control
panel regularly
using a damp
cloth and wash-
ing-up liquid.
This ensures the
parts of the appli-
ance will remain
clean and hy-
gienic.
If the appliance
is not going to
be used for a
while, leave the
door slightly ajar.
This will prevent
unpleasant
odours.
38
Cleaning and servicing aus
16.4 Machine Care
Deposits, e.g. from remnants of food and limescale, can cause your appliance
to malfunction. To avoid such faults and reduce odours, we recommend clean-
ing your appliance at regular intervals.
Machine Care combined with machine care products and machine cleaners is
the right programme for the care of your appliance.
Tip: You can get our tested and approved Dishwasher Care and Machine
Cleaner for Dishwashers online at
https://www.bosch-home.com/store
or from
customer service.
Machine Care is a programme which removes various deposits in one washing
cycle. Cleaning takes place in two phases:
Phase Removal of Detergent Placement
1 Grease and limes-
cale
Liquid machine care
product or machine
descaler in powder
form.
Appliance interior, e.g.
bottle hung in the cut-
lery basket or powder
in the interior.
2 Food remnants and
deposits
Machine cleaner Detergent dispenser
To ensure optimum cleaning perform-
ance, the programme doses the de-
tergents independently of each an-
other during the relevant cleaning
phase. Correct placement of the de-
tergents is necessary here.
Run Machine Care without tableware
if the indicator for Machine Care
lights up on the control panel or if ad-
vised to do so by the display. The in-
dicator will go out after you have run
Machine Care. If your appliance does
not have a reminder function, we re-
commend performing Machine Care
every 2months.
RunningMachine Care
Notes
Run the Machine Care programme
without any tableware in the dish-
washer.
Only use machine care products
and machine cleaners specially
designed for dishwashers.
Make sure that there are no alu-
minium parts, e.g. extractor hood
grease filters or aluminium pans, in
the interior of the appliance.
If you have not run Machine Care
after 3 washing cycles, the indic-
ator for Machine Care will go out
automatically.
For optimum cleaning perform-
ance, ensure the correct place-
ment of cleaners.
Follow the safety instructions given
on the packagings of the machine
care products and machine clean-
ers.
Activate the function.
"Extra Clean Zone", Page22
1.
Remove any coarse soiling in the
interior with a damp cloth.
2.
Clean the filters.
3.
Place the machine care product in
the appliance interior.
Only use machine care products
specially designed for dishwash-
ers.
39
aus Cleaning and servicing
4.
Pour the machine cleaner into the
detergent dispenser until it is filled
completely.
Do not place any additional ma-
chine cleaner in the appliance in-
terior.
5.
Press .
6.
Press .
Machine Care is run.
Once the programme has ended,
the indicator for Machine Care
goes out.
16.5 Filter system
The filter system removes coarse
soiling from the dishwashing cycle.
1
2
3
Micro filter
Fine filter
Coarse filter
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1.
After each wash check the filters
for residue.
2.
Turn the coarse filter anticlockwise
and remove the filter system .
Check that no foreign objects
fall into the sump.
3.
Pull down the micro filter to re-
move.
4.
Press the locking catches to-
gether and lift the coarse filter out
.
5.
Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
40
Cleaning and servicing aus
6.
Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7.
Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
Make sure that the arrow mark-
ings match up.
Tip: Connect your appliance to a mo-
bile device. The HomeConnect app
will tell you as soon as you need to
clean the filters.
"HomeConnect ", Page36
16.6 Cleaning spray arms
Limescale and soiling in the dish-
washing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.
1.
Unscrew the upper spray arm
and pull down to remove .
2.
Pull up the lower spray arm to re-
move.
3.
Check the outlet nozzles on the
spray arms for blockages under
running water and remove any for-
eign objects.
4.
Insert the lower spray arm.
The spray arm clicks into position.
5.
Insert the upper spray arm and
screw it firmly in place.
16.7 Cleaning Extra Clean
Zone
Limescale and soiling from the dish-
washing water can block the nozzles.
Note: Always operate the appliance
with the Extra Clean Zone fitted.
1.
Pull out the top basket.
2.
Pull the tab on the Extra Clean
Zone up and forwards .
3.
Set the slider to ON.
4.
Clean under running water.
41
aus Troubleshooting
5.
Place the Extra Clean Zone in the
top basket and lock in place .
Check that the mounts are in the
correct position.
The Extra Clean Zone audibly
clicks into position .
6.
Push in the top basket.
Troubleshooting17 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist
staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged,
it must be replaced with a special power cord or special appliance power
cable, which is available from the manufacturer or its Customer Service.
Fault Cause and troubleshooting
Appliance door does
not open at the end of
the programme.
Automatic door opening is not activated.
Activate the automatic door opening.
"Overview of basic settings", Page32
Door is not correctly adjusted.
Adjust the appliance door as described in the install-
ation instructions.
The door gap must be at least 70mm to 120mm.
Appliance door and door seal are soiled.
Clean the appliance door and door seal with a damp
cloth and a little washing-up liquid.
Wrong screws used to adjust the door gap.
Use size 4X30 bolts to adjust the door gap.
The bolts are included in the scope of supply.
If you use bolts that are too long, this can deactivate
the function of automatic door opening.
42
Troubleshooting aus
Fault Cause and troubleshooting
Appliance door does
not open at the end of
the programme.
The safety device switches off automatic door opening.
Call Customer Service.
Page56
Appliance door brushes against the appliance or kit-
chen cabinets
Install the appliance correctly as described in the in-
stallation instructions and align.
Appliance door opens
too wide at the end of
the programme.
Door is not correctly adjusted.
Adjust the appliance door as described in the install-
ation instructions.
The door gap must be at least 70mm to 120mm.
Wrong screws used to adjust the door gap.
Use size 4X30 bolts to adjust the door gap.
The bolts are included in the scope of supply.
If you use bolts that are too long, this can deactivate
the function of automatic door opening.
Display "Check water
supply" flashes
A technical fault is present.
1.
Press .
2.
Unplug the appliance or switch off the fuse.
3.
Wait at least 2minutes.
4.
Insert the mains plug of the appliance in a socket or
switch on the fuse.
5.
Switch the appliance on.
6.
If the problem occurs again:
Press .
Turn off the water tap.
Pull out the mains plug.
Contact Customer Service
Page56
and give
the error code.
E:20-60 lights up al-
ternately.
Appliance has detected calcified heating element.
1.
Descale the appliance.
2.
Operate the appliance with the water softening
system.
1
E:30-00 will light up
alternately.
Water protection system is activated.
1.
Turn off the water tap.
2.
Call Customer Service
Page56
.
E:31-00 will light up
alternately.
Water protection system is activated.
1.
Turn off the water tap.
2.
Call Customer Service
Page56
.
1
Depending on the appliance specifications
43
aus Troubleshooting
Fault Cause and troubleshooting
E:32-00 will light up
alternately or indicator
for water supply lights
up.
Supply hose is kinked.
Install the inlet hose without kinks.
Water tap is turned off.
Turn on the water tap.
Water tap is jammed or furred up.
Turn on the water tap.
The flow rate must be at least 10 l/min when the wa-
ter supply is open.
The filters in the water connection of the supply or
AquaStop hose are blocked.
1.
Switch off the appliance.
2.
Pull out the mains plug.
3.
Turn off the water tap.
4.
Unscrew the water connection.
5.
Remove the filter from the inlet hose
6.
Clean the filter.
7.
Re-insert the filter in the inlet hose.
8.
Screw the water connection back on.
9.
Check the water connection for leaks.
10.
Restore the power supply.
11.
Switch the appliance on.
E:34-00 will light up
alternately.
Water is continuously running into the appliance.
1.
Turn off the water tap.
2.
Call Customer Service
Page56
.
E:61-02 will light up
alternately.
Not an appliance fault. Wastewater pump is blocked or
the cover of the wastewater pump is loose.
1.
Clean the wastewater pump.
"Clean wastewater pump", Page55
2.
Secure the cover of the wastewater pump so it clicks
into position.
"Clean wastewater pump", Page55
44
Troubleshooting aus
Fault Cause and troubleshooting
E:61-03 will light up
alternately. Water is
not drained.
Not an appliance fault. Siphon connection is still closed
or the wastewater hose is kinked or blocked.
1.
Check the connection to the siphon and open if ne-
cessary.
2.
Install wastewater hose without kinks.
3.
Remove residues.
Not an appliance fault. Wastewater pump is blocked or
the cover of the wastewater pump is loose.
1.
Clean the wastewater pump.
"Clean wastewater pump", Page55
2.
Secure the cover of the wastewater pump so it clicks
into position.
"Clean wastewater pump", Page55
E:90-01 will light up
alternately.
Mains voltage is too low.
This is not a fault with the appliance.
1.
Contact an electrician.
2.
Have the mains voltage and electrical installation
checked by an electrician.
E:92-40 will light up
alternately.
Filters are soiled or blocked.
Clean the filters.
"Cleaning filters", Page40
45
aus Troubleshooting
Fault Cause and troubleshooting
A different error code
appears in the display
window.
E:01-00 to E:90-10
A technical fault is present.
1.
Press .
2.
Unplug the appliance or switch off the fuse.
3.
Wait at least 2minutes.
4.
Insert the mains plug of the appliance in a socket or
switch on the fuse.
5.
Switch the appliance on.
6.
If the problem occurs again:
Press .
Turn off the water tap.
Pull out the mains plug.
Contact Customer Service
Page56
and give
the error code.
Tableware is not dry. No rinse aid used or dosage set too low.
1.
Add Rinse aid
Page25
.
2.
Set the amount of rinse aid to be dispensed.
"Setting the amount of rinse aid", Page26
Programme or programme option has no drying phase,
or the drying phase is too brief.
Select a programme with drying, e.g. intensive,
strong or ECO programme.
Some option buttons decrease the drying result, e.g
varioSpeed.
Water collects in recesses of the tableware or cutlery.
Position tableware at an angle where possible.
The combined detergent used has a poor drying per-
formance.
1.
Use rinse aid to improve drying performance.
2.
Use a different combined detergent with a better dry-
ing performance.
Extra Dry not activated to improve drying performance.
Activate Extra Dry.
46
Troubleshooting aus
Fault Cause and troubleshooting
Tableware is not dry. Tableware removed too early or drying process not yet
ended.
1.
Wait until the programme ends.
2.
Only remove tableware 30minutes after the pro-
gramme has ended.
Rinse aid used has a limited drying performance.
Use a name-brand rinse aid.
Eco products may have limited effectiveness.
Appliance door does not open automatically at the end
of the programme
Adjust the appliance door as described in the install-
ation instructions.
The door gap must be at least 70mm to 120mm.
Plastic tableware is
not dry.
Not a fault. As plastic does not store heat so well, it
also does not dry as well.
No remedial action possible.
Cutlery is not dry. Cutlery not arranged properly in the cutlery basket or
cutlery drawer.
Droplets can form on the cutlery contact points.
1.
Arrange cutlery individually where possible.
Page30
2.
Avoid points of contact.
Appliance interior still
wet after wash cycle.
Not a fault. The condensation drying principle causes
water droplets in the tub – they are indeed desirable
here. The moisture in the air condenses on the inside
walls, runs off and is pumped out.
No action required.
Remnants of food on
tableware.
Tableware is placed too close together or basket is
overfilled.
1.
Arrange tableware with sufficient space in between.
The spray jets must reach the surfaces of the table-
ware.
2.
Avoid points of contact.
Spray arm rotation is blocked.
Arrange tableware so that it does not obstruct spray
arm rotation.
Spray arm nozzles are blocked.
Clean the spray arms.
"Cleaning spray arms", Page41
47
aus Troubleshooting
Fault Cause and troubleshooting
Remnants of food on
tableware.
Filters are soiled.
Clean the filters.
"Cleaning filters", Page40
Filters are inserted incorrectly and/or not engaged.
1.
Insert the filters properly.
"Filter system", Page40
2.
Engage the filters.
Washing programme selected too weak.
Select a more intensive washing programme.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Tall narrow receptacles in corner areas are not rinsed
adequately.
Do not position tall narrow receptacles at too great
an angle or in corner areas.
Top baskets on right and left are not set to same
height.
Set the upper basket on the left and right to the
same height.
"Top basket", Page21
Detergent residue in
the appliance
Lid of the detergent dispenser is blocked by items of
tableware parts and will not open.
1.
Arrange tableware in the top basket tableware so
the tab collecting tray is not obstructed by tableware.
"Arrange tableware", Page30
Items of tableware are blocking the dispenser lid.
2.
Do not place tableware or fragrance dispensers in
the tablet collecting tray.
48
Troubleshooting aus
Fault Cause and troubleshooting
Detergent residue in
the appliance
The lid of the detergent dispenser is blocked by the tab
and will not open.
Position the tab in the detergent dispenser cross-
wise, not vertically.
Tabs are used in the quick or short programme. Dis-
solving time of the tab is not attained.
Select a more intensive Programme or use Powder
detergent.
Washing effect and dissolving performance are re-
duced after a prolonged storage time or detergent is
very lumpy.
Change your detergent.
Water marks on
plastic parts.
Due to laws of physics droplet formation on plastic sur-
faces is unavoidable. After drying water marks are vis-
ible.
Select a more intensive programme.
Position tableware at an angle.
"Arrange tableware", Page30
Use rinse aid.
"Rinse aid", Page25
Wipeable or water-sol-
uble coatings are
present inside the ap-
pliance or on the
door.
Detergent substances are deposited there. These coat-
ings cannot generally be removed with chemicals.
Change your detergent.
Clean the appliance mechanically.
Stubborn white coat-
ings are present on
tableware, inside the
appliance or the door.
Detergent substances are deposited there. These coat-
ings cannot generally be removed with chemicals.
Change your detergent.
Clean the appliance mechanically.
Too little detergent is being used.
Increase the amount of detergent used or change
Detergent .
Washing programme selected too weak.
Select a more intensive washing programme.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Tea residue or lipstick
marks on tableware.
Washing temperature is too low.
Select a programme with a higher washing temperat-
ure.
Too little detergent is being used or is unsuitable.
Use a suitable Detergent and follow the manufac-
turer's instructions for the amount to be used.
49
aus Troubleshooting
Fault Cause and troubleshooting
Tea residue or lipstick
marks on tableware.
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Coloured coatings
(blue, yellow, brown)
that are difficult or im-
possible to remove
are present inside the
appliance or on stain-
less steel tableware.
The formation of films is due to substances contained
in vegetables (cabbage, celery, potatoes, noodles, etc.)
or tap water (manganese).
Clean the appliance.
You can remove deposits with Mechanical cleaning
Page38
or a machine cleaning product. It may not
always be possible to completely remove deposits
but they are harmless to health.
The formation of films is due to metal components on
silver or aluminium tableware.
Clean the appliance.
You can remove deposits with Mechanical cleaning
Page38
or a machine cleaning product. It may not
always be possible to completely remove deposits
but they are harmless to health.
Plastic parts inside the
appliance are discol-
oured.
Plastic parts inside the appliance may become discol-
oured during the life of the dishwasher.
Discolouration can come about and will not impair
functioning of the appliance.
Plastic parts are dis-
coloured.
Washing temperature is too low.
Select a programme with a higher washing temperat-
ure.
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Removable streaks
are present on
glasses, glassware
with a metallic appear-
ance and cutlery.
Amount of rinse aid to be dispensed is set too high.
Set the rinse aid system to a lower setting.
"Setting the amount of rinse aid", Page26
No rinse aid has been added.
Add rinse aid.
"Adding rinse aid", Page25
50
Troubleshooting aus
Fault Cause and troubleshooting
Removable streaks
are present on
glasses, glassware
with a metallic appear-
ance and cutlery.
Detergent residue is present in the final rinse. Lid of the
detergent dispenser is blocked by tableware items and
will not open fully.
1.
Arrange tableware in the top basket tableware so
the tab collecting tray is not obstructed by tableware.
"Arrange tableware", Page30
Items of tableware are blocking the dispenser lid.
2.
Do not place tableware or fragrance dispensers in
the tablet collecting tray.
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Adjust the sensitivity of the sensors.
"Sensors", Page10
Irreversible clouding
of glassware.
Glasses are not dishwasher-proof, only suitable for
dishwashers.
Use dishwasher-proof glasses.
Glasses are usually only suitable for use in a dish-
washer, i.e. long-term wear or long-term changes
must be expected.
Avoid a lengthy steam phase (standing time after
wash cycle ends).
Use a programme with a lower temperature.
Use detergent with a glass protection component.
Rust spots on cutlery. Cutlery is not sufficiently rust-resistant. Knife blades are
often more severely affected.
Use rust-resistant tableware.
Cutlery may also rust if washed together with rusting
items.
Do not wash rusting items.
Detergent residue is
present in the deter-
gent dispenser or the
tablet collecting tray.
Spray arms were blocked by tableware so detergent
was not rinsed out.
Check that the spray arms are not blocked and can
rotate freely.
Detergent dispenser was damp when detergent was
added.
Only add detergent to a detergent dispenser when
dry.
51
aus Troubleshooting
Fault Cause and troubleshooting
Excessive formation of
foam occurs.
Hand washing-up liquid is present in dispenser for
rinse aid.
Immediately add rinse aid to the dispenser.
"Adding rinse aid", Page25
Rinse aid has been spilled.
Remove the rinse aid with a cloth.
Detergent or appliance care product used causes ex-
cessive foaming.
Change the brand of detergent.
Connection to home
network is not estab-
lished.
WLAN on router is not active.
Check the wireless network connection of your
router.
WLAN display is flash-
ing.
Connection to home network is not available.
Activate the wireless network connection on your
router.
Home Connect cannot
be implemented cor-
rectly.
Home Connect set incorrectly.
Please consult the documents supplied for
HomeConnect.
Technical fault is present.
Please consult the information about support in the
documents supplied for HomeConnect.
Refill indicator for
rinse aid lights up.
Insufficient rinse aid.
1.
Add Rinse aid
Page25
.
2.
Set the amount of rinse aid to be dispensed.
"Setting the amount of rinse aid", Page26
Refill indicator for
rinse aid does not
light up.
Rinse aid system is switched off.
Set the amount of rinse aid to be dispensed.
"Setting the amount of rinse aid", Page26
All LEDs lit up or
flashing.
A software update is possibly installing.
1.
Wait until the software update has been installed.
This process can take approx. 30minutes.
2.
If the appliance is not ready to use after 30minutes,
perform a reset.
Press the main switch button for approx.
4seconds.
Your appliance is resetting.
52
Troubleshooting aus
Fault Cause and troubleshooting
All LEDs lit up or
flashing.
Electronics have detected a fault.
1.
Press the main switch button for approx. 4seconds.
"Controls", Page14
The appliance is reset and restarted.
2.
If the problem occurs again:
Switch off the appliance.
Pull out the mains plug or switch off the fuse in
the fuse box.
Wait at least 2minutes.
Switch on the fuse in the fuse box or insert the
mains plug.
Switch the appliance on.
3.
If the problem occurs again:
Contact customer service.
"Customer Service", Page56
Water is left in the ap-
pliance at the end of
the programme.
Filter system or area under the filters is blocked.
1.
Clean the Filters
Page40
.
2.
Clean the Wastewater pump
Page55
.
Programme has not yet ended.
Wait until the programme ends or cancel the pro-
gramme with Reset.
"Terminate programme", Page32
Appliance cannot be
switched on or oper-
ated.
Software update is taking place.
Wait until the software update has finished.
Appliance functions have failed.
1.
Pull out the mains plug or switch off the fuse.
2.
Wait at least 2minutes.
3.
Connect the appliance to the power supply.
4.
Switch the appliance on.
Appliance does not
start.
The mains fuse has tripped.
Check the relevant fuse.
Mains cable is not inserted.
1.
Check whether the socket works.
2.
Check whether the mains cable is properly inserted
in the socket and on the rear of the appliance.
Appliance door is not closed properly.
Close the appliance door.
Programme starts
automatically.
You did not wait until programme ended.
"Terminate programme", Page32
Appliance stops dur-
ing the programme or
cuts out.
Appliance door is not closed properly.
Close the appliance door.
53
aus Troubleshooting
Fault Cause and troubleshooting
Appliance stops dur-
ing the programme or
cuts out.
Power and/or water supply has been interrupted.
1.
Check the power supply.
2.
Check the water supply.
Top basket is pressing against inner door and prevent-
ing appliance door from being closed securely.
Check whether the rear panel of the appliance is be-
ing pressed in by a socket or hose holder that has
not been removed.
Arrange the tableware so that no parts project bey-
ond the basket and prevent the appliance door from
closing properly.
Appliance door can-
not be closed.
Door lock has been activated.
1.
Close the appliance door with greater force.
2.
If the installation conditions prevent quick realign-
ment of the closing system, you can move the door
lock back to the home position using a spoon.
See the animation for how to move the door lock to
the home position.
Door cannot be closed due to installation method.
Check whether the appliance has been installed
properly.
When closed, the appliance door, its decor or at-
tached parts should not knock against adjacent cab-
inets or the worktop.
Lid on the detergent
dispenser cannot be
closed.
Detergent dispenser or lid are blocked by sticky deter-
gent residue.
Remove detergent residue.
Filling valves making
knocking noises.
Caused by the domestic installation. No appliance fault
present. Does not affect functioning of the appliance.
Can only be remedied in the domestic installation.
Knocking or rattling
noise.
Spray arm is striking tableware.
Arrange tableware so that the spray arms do not
strike tableware.
With a small load the water jets directly strike against
the tub.
Distribute the tableware evenly.
Load the appliance with more tableware.
54
Transportation, storage and disposal aus
Fault Cause and troubleshooting
Knocking or rattling
noise.
Light items of tableware move about during the wash
cycle.
Position light items of tableware securely.
17.1 Clean wastewater pump
Large remnants of food or foreign
bodies can block the waste water
pump. As soon as the rinsing water
no longer drains properly, the waste
water pump must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or frag-
ments of glass may block the waste
water pump and cause injury.
Remove any foreign bodies care-
fully.
1.
Disconnect the appliance from the
mains.
2.
Remove the top and bottom bas-
ket.
3.
Remove the filter system.
4.
Scoop out any water.
Use a sponge if necessary.
5.
Prise off the pump cover using a
spoon and grip it by the
crosspiece.
6.
Lift the pump cover inwards at an
angle and remove.
You can now reach the impeller
with your hand.
7.
Remove any remnants of food and
foreign bodies in the area of the
impeller.
8.
Insert the pump cover and press
down .
The pump cover clicks into posi-
tion.
9.
Install the filter system.
10.
Insert the top and bottom basket.
11.
Connect the appliance to the
mains.
Transportation, storage and disposal18 Transportation, stor-
age and disposal
18.1 Removing the appliance
1.
Disconnect the appliance from the
mains power supply.
2.
Turn off the water tap.
3.
Detach the drainage connection.
4.
Detach the drinking water connec-
tion.
5.
Loosen any screws fastening the
appliance to cabinet parts.
6.
Remove the base panel if fitted.
7.
Pull the appliance out carefully,
along with the hose behind it.
55
aus Customer Service
18.2 Protect appliance from
frost
If there is a risk of frost where the ap-
pliance will be standing, e.g. in a holi-
day home, empty the appliance com-
pletely.
Empty the appliance.
"Transporting the appliance",
Page56
18.3 Transporting the appli-
ance
To avoid damage to the appliance,
empty it before transporting.
Note: Always transport the appliance
upright to prevent residual water get-
ting into the machine's controls and
damaging the appliance.
1.
Remove tableware from the appli-
ance.
2.
Secure loose parts.
3.
Switch on the appliance.
Page31
4.
Select the programme with the
highest temperature.
5.
Start the programme.
Page32
6.
To drain the appliance, terminate
the programme after approx.
4minutes.
"Terminate programme",
Page32
7.
Switch off the appliance.
Page32
8.
Turn off the tap.
9.
To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
18.4 Disposing of old appli-
ance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
so that the appliance door will no
longer close.
1.
Unplug the appliance from the
mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is labelled
in accordance with
European Directive
2012/19/EU concerning
used electrical and elec-
tronic appliances (waste
electrical and electronic
equipment - WEEE).
The guideline determines
the framework for the re-
turn and recycling of
used appliances as ap-
plicable throughout the
EU.
Customer Service19 Customer Service
Detailed information about the war-
ranty period and the warranty condi-
tions in your country is available via
the QR code on the enclosed docu-
ment on service contacts and war-
ranty conditions, from our customer
service or on our website.
56
Technical specifications aus
If you contact Customer Service, you
will require the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) of
your appliance.
You can find the contact details for
our customer service via the QR
code on the enclosed document on
service contacts and warranty condi-
tions or on our website.
19.1 Product number (E-Nr.),
production number (FD)
and consecutive number-
ing (Z-Nr.)
You can find the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
The rating plate is located inside the
appliance door.
"Familiarising yourself with your ap-
pliance", Page13
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
19.2 AQUA-STOP guarantee
In addition to warranty claims against
the seller under the purchase agree-
ment and in addition to our manufac-
turer's warranty, we offer compensa-
tion under the following conditions.
If our Aqua-Stop system is defect-
ive and causes water damage, we
will make good the damage for
private users. To ensure protection
from water damage, the appliance
must be connected to the power
supply.
The liability guarantee is valid for
the service life of the appliance.
A claim can only be made under
the guarantee if the appliance has
been correctly installed and con-
nected with Aqua-Stop according
to our instructions; this also in-
cludes correctly fitting the Aqua-
Stop extension (genuine access-
ory). Our guarantee does not cover
defective supply lines or fittings up
to the Aqua-Stop connection on
the tap.
If your appliance is fitted with
Aqua-Stop, you can in principle
leave your appliance unattended
during operation and the tap
turned on afterwards. The tap only
needs to be turned off if you are
away from home for a long period,
e.g. on holiday for several weeks.
Technical specifications20 Technical specifications
Weight Max.: 60kg
Voltage 220-240V, 50Hz or 60Hz
Power rating 2000 - 2400W
Fuse 10A
Water pressure min. 50kPa (0.5bar)
max. 1000kPa (10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
57
aus Declaration of Conformity
Hot water max.: 60°C
Capacity 15place settings
20.1 Information regarding
Free and Open Source
Software
This product includes software com-
ponents that are licensed by the
copyright holders as free or open
source software.
The applicable licence information is
stored on your home appliance. You
can also access the applicable li-
cence information via your
HomeConnect app: "Profile -> Legal
information -> Licence Information".
1
You can download the licence in-
formation on the brand product web-
site. (Please search on the product
website for your appliance model
and additional documents). Alternat-
ively, you can request the relevant in-
formation from oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str. 34, 81739
Munich, Germany.
The source code will be made avail-
able to you on request.
Please send your request to oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str.34, 81739
Munich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request
will be charged to you. This offer is
valid for three years from the date of
purchase or at least as long as we
offer support and spare parts for the
relevant appliance.
Declaration of Conformity21 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect
functionality conforms to the essential requirements and other relevant provi-
sions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at
www.bosch-
home.com
among the additional documents on the product page for your ap-
pliance.
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5-GHz band (5150–5350MHz + 5470–5725MHz): max. 180mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
1
Depending on the appliance specifications
58
Declaration of Conformity aus
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
59
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service
directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
*9001967982*
9001967982 (050605) 650 A5
aus
